OAK RANGE //
100kW – 700KW CO2 AIR SOURCE HEAT PUMPS
August 2021 //
CALDE OAK RANGE //
THE OAK //
LOW CARBON
HEATING
TECHNOLOGY
Clade CO2 heat pumps will reduce carbon emissions
whilst maximising efficiency with existing cooling and
heating systems. Our full-service offering makes heat
pumps a simple and low risk way to improve your
ESG and operational performance.
2
CALDE OAK RANGE //
POTENTIAL SOLUTIONS TO DECARBONISE HEAT //
There are many factors to consider when selecting your preferred heating technology. The table below illustrates some key factors for consideration.
Overall
Flow Carbon Local air Flexible Operational
Technology Availability environmental
Temperature g/KWh quality input tariff cost
impact
CO2 heat
85ºC 83 At all scales £
pump
At all scales for low temp
heat pump 60ºC 83 ££
applications
Direct Yes but peak power demands
85ºC 250 £££££
electrical are high
Natural gas
85ºC 280 Yes, requires flue £££
boilers
Solar No, seasonal generation,
85ºC 25 n/a £
thermal requires large non shaded area
Not available commercially, fuel
Hydrogen
85ºC - not available, high NOX -
boiler
emissions
Biomass No - physical size, emissions,
85ºC 95 ££££
boiler fuel supply and larger flue
Bio gas No - available gas certificates
85ºC 60 ££££
boiler constraints
3
CALDE OAK RANGE //
BENEFITS OF THE CLADE OAK CO2 RANGE //
100-700kW of heating capacity, with COPH of up to 3.84*
Compressor inverter drive to
control compressor speed,
enabling smoother running in
Integrated electrical control low load conditions, whilst
panel to work seamlessly minimising electrical input.
alongside client selected
BMS system.
Specialist compressors
Full mechanical service integration,
provide a greater operating
incorporating pumps for simplified installation.
temperature range and
increased COP.
* COPH is based on a specific flow, return and ambient conditions
4
CALDE OAK RANGE //
BENEFITS OF THE CLADE OAK RANGE //
100-700kW of heating capacity
Low noise weather proof housing ensures low noise levels Supplied with one fan per evaporator coil section, reducing noise levels and enabling
as expected by local Environmental Health Authorities. advanced defrost adaptive control whilst simplifying the overall control process.
Gas cooler plate heat Removable panels for access Plug and Play - Close coupled V block evaporator
exchanger transfers heat to individual evaporator eradicates the requirement for on-site connections
from refrigerant to water. expansion devices. between the heat pump and heat source.
5
CALDE OAK RANGE //
CO2 HEAT PUMPS PERFORMANCE //
COPH of R744* TC ASHP vs. R450A COPH of R744* TC ASHP vs. R450A COPH of R744* TC ASHP vs. R450A
ASHP @ -5 °C ambient ASHP @ 5 °C ambient ASHP @ 15 °C ambient
3 4 5.5
3.5 4.5
2.5 3
3.5
2 2.5
2 2.5
1.5 1.5 1.5
R450 HP COPH (-) R744 HP COPH (-) R450 HP COPH (-) R744 HP COPH (-) R450 HP COPH (-) R744 HP COPH (-)
AT HIGHER FLOW TEMPERATURES THE CO2 HEAT PUMP DELIVERS SIGNIFICANTLY BETTER PERFORMANCE
* R744 is CO2, R450A is a typical HFO
6
CALDE OAK RANGE //
UK BASED MANUFACTURE AND TECHNICAL SUPPORT //
Clade manufacture all our products in the UK and are
committed to continue to do so. This will create jobs in
the green economy.
Clade’s technical team are based in the UK and can
provide support before, during and after installation.
Clade offer an aftercare service staffed by highly trained
technicians and backed by our technical team.
7CALDE OAK RANGE //
ABOUT CLADE //
UK based
35 years of engineering experience
Leeds manufacturing division
Delivered first Heat pump in 2019.
New production facility from August 2021 –
increasing capacity by 120 - 130%.
Project division delivering first class installations –
excellent customer feedback
Committed to sustainable business and sustainable
products
Non leveraged, owner operated
ACCREDITATIONS CERTIFICATIONS
ISO 9001: 2015 Altius Assured Vendor Award
ISO14001: 2015 Altius CDM Vendor Award
CHAS
OHSAS ISO 18001: 2007 Sales Contractor
