Construction update
North Melbourne
April – May 2021
Major construction of the Metro Tunnel is continuing at and around the
Arden Station site. This update provides an outline of current and
upcoming works in your area throughout April and May.
Construction snapshot When are we working?
Work at and around the Arden Station site during
April and May involves: Normal construction hours
— Realigning Laurens Street 7am to 6pm, Monday to Friday
— Arden Station entrance construction 7am to 1pm, Saturdays.
— Station services building construction
— Tunnelling support, TBM retrieval and Out of hours
disassembly
Some works are required to
— Station construction, including platform, over- take place out of normal
track exhaust and plant room construction construction hours.
— Cross passage construction
— North Melbourne electrical substation
24 hours
construction
24 hour works are sometimes
— Utility investigations on Arden, Laurens,
required during peak
Barwise and Queensberry streets
construction activities.
— Slurry treatment plant, water treatment plant
and concrete batching plant operation
— Out of hours oversize deliveries to and from site
— Surveying, and sampling and testing of
Health and safety
groundwater and soil
Works on the Metro Tunnel Project are
— Transporting concrete from the concrete
progressing with strict COVIDsafe Plans
batching plant to other Metro Tunnel Project
in place.
construction sites.
The health and safety of our workforce and
Further information on these works can be
community remains our top priority.
found overleaf or at metrotunnel.vic.gov.au.
For more information and advice about
the coronavirus (COVID-19), please visit
coronavirus.vic.gov.au.
Construction partner:
Design &
Construction
Works in your area — The Arden Station site will provide Tunnel Boring
Machine (TBM) and tunnelling support for the
duration of tunnelling to the CBD. This involves
Laurens Street realignment
delivery of tunnel lining segments, operation
Laurens Street of the slurry and water treatment plants and
From early May 2021 until end 2023 transportation of excavated material 24 hours a
day, seven days a week
From early May, Laurens Street will be realigned to
— The project team will continue to undertake
support service relocations and construction of the
survey and monitoring activities at ground level
Arden Station entrance. This will involve:
along the tunnel alignment.
— Closing on-street parking spaces on both sides
of Laurens Street, from Arden Street to just TBM retrieval and disassembly
south of Queensberry Street
Arden Station site
— Removing a section of timber hoarding and From April 2021 until late-2021
installing concrete barriers on the western side
of Laurens Street — Works will commence to retrieve and
— Realigning traffic and bicycle lanes around the disassemble TBM Joan
concrete barriers — TBM Joan will be disassembled inside the station
— Installing a pedestrian crossing on Laurens box using pneumatic (air-driven) wrenches,
Street, south of Queensberry Street welding equipment and hand tools
— Closing the western footpath on Laurens — Large cranes will be used to move and
Street, from Arden Street to just south of disconnect TBM pieces at ground level, as well
Queensberry Street. as lift them out of the station box
— This work will be undertaken at night as well as
Arden Station entrance construction during the day and is expected to generate low
Arden Station site levels of noise.
Ongoing until mid-2022
Tunnel internal structure works
The first stage of works to prepare for construction Arden Station site
of the station entrance on Laurens Street has been Ongoing until May 2021
completed. This involved installing piles to support
the station entrance structure. Works to occur in — Works to construct the tunnel invert (floor)
April and May will include: are ongoing
— Removal of sections of the station box — This involves pouring concrete within the
diaphragm walls (D-walls) to prepare for station tunnels in sections
entrance structural works
— Works commenced at the western tunnel
— Concrete pours for the entrance level slab and entrance in Kensington and are moving
entrance walls. progressively east towards the Arden
Station site.
Arden Station services building construction
Arden Station site Cross passage construction support
Ongoing until mid-2021
Arden Station site
Ongoing until early 2022
— Installing steel reinforcement and formwork,
including the use of cranes and hand tools, and
— The Arden Station site will provide cross passage
pouring concrete to construct the building’s
construction support until early 2022
slabs and walls
— Each cross passage is expected to take
— Installing brick lined, pre-cast panels to
approximately six months to construct. Works
construct the building facade
will occur concurrently at different cross
— Installing structural steel to form the building’s passage sites
columns and beams.
— All works will be completed from within the
completed section of tunnels and are not
Tunnelling support expected to be audible at surface level
Arden Station site — Further information about cross passages can
Ongoing until mid-2021 be found at metrotunnel.vic.gov.au.
— TBM Joan has now completed tunnelling. TBM
Meg continues to tunnel in the Melbourne CBD
M
ac
au
la
Arden S
St
y
t
Rd
Moone ek
Lothian
Cre
e Pond
Barwise
St
h St
s
ace
Dryburg
Slurry nt
Terr
e
treatmnt
pla
ster
box
Station
Mun
Site fac
ilities Queensb
erry St
Legend
Site fac
ilities Construction site
St
Site gate
Laurens
ink
Concrete Services building construction
batchin
yL
g Station entrance construction
Cit
plant
Laurens Street realignment
Intermittent single lane closures
and pedestrian detours
Substation worksite
Substation vehicle access route
Intermittent short traffic holds
Arden Station construction site. Indicative only
Platform and over track exhaust — These activities are expected to generate periods
(OTE) construction of medium to loud noise
Arden Station site — These works may include intermittent impacts to
Ongoing until late-2021 traffic, footpaths and on-street parking. See the
‘traffic and transport impacts’ section for further
— Construction of the station platforms and OTE information.
(tunnel ventilation) system is ongoing
North Melbourne electrical substation
— This involves using cranes and hand tools to
install precast concrete units within the station construction
box, and pouring concrete North Melbourne
Ongoing until mid-2021
— Works will be undertaken in two stages, taking
approximately three months each. The first
stage of works will be completed in April 2021 — Service investigations using NDD trucks to
and the second stage of works is expected to locate underground services will be required
commence in mid-2021. intermittently as construction progresses
— Ongoing site investigations and monitoring
Utility investigation works activities including survey and soil sampling
Arden, Laurens, Barwise and Queensberry — Constructing the substation structure by
streets, North Melbourne installing precast concrete panels and structural
Ongoing until mid-2021 steel, and pouring concrete
— Short holds of traffic on the Moonee Ponds Creek
— Service investigations will be undertaken
Trail will be required intermittently while large
intermittently in Arden, Laurens, Barwise and
construction vehicles travel along the narrow
Queensberry streets
section of the existing access track near Arden
— This involves the use of non-destructive Street. Traffic controllers will be in place to direct
digging (NDD) trucks to locate underground cyclists and pedestrians
services and then reinstating the road surface
— For more information on the North Melbourne
and line marking
electrical substation visit metrotunnel.vic.gov.au.Traffic and transport impacts Utility investigation works
— Up to 400 trucks per day are expected to — Utility investigations will involve the intermittent
travel to and from site. Construction vehicles short-term closure of one lane on Arden,
and trucks will access the site via Laurens and Laurens and Barwise streets. Traffic will be
Arden streets maintained in both directions via a shuttle
flow arrangement
— All trucks carrying excavated materials will
be covered, and water carts and street — Some on-street parking spaces may be
sweepers will be used frequently to minimise temporarily impacted on Arden, Barwise,
the spread of dust Queensberry and Laurens streets
— Rumble grids and a wheel wash have been — Sections of footpath adjacent to works may
installed to remove debris from the wheels be temporarily closed, with local pedestrian
and carriages of vehicles to minimise the diversions in place
spread of dirt on local roads. — Access to businesses will be maintained
at all times
— Signage and traffic controllers will be in place
to direct vehicles, cyclists and pedestrians
around the work area.
Look ahead for 2021
April May June July
Laurens Street realignment works
Utility investigation works
Over track exhaust (OTE) and
platform construction
Tunnelling support
Cross passage construction
North Melbourne electrical
substation construction
Services building construction
Station entrance construction
Program is indicative and subject to change
More information
To find out more about the Metro Tunnel Project:
metrotunnel.vic.gov.au
1800 105 105 (24 hours a day, 7 days a week) It should be noted that this information is current at the time of
printing, however due to unforeseen circumstances, changes
Rail Projects Victoria may occur. Please visit railprojects.vic.gov.au for
CYP-WN00455
