REVERSE COSTING® – STRUCTURAL, PROCESS & COST REPORT
Triple Forward Camera from Tesla Model 3
Ref: TPN 1143746-00-B
SP20509 - System report by Philippe VANDAR
January 2020 – SAMPLE
22 Bd Benoni Goullin
+33 2 40 18 09 16 info@systemplus.fr www.systemplus.fr
44200 NANTES - FRANCE
©2020 by System Plus Consulting | Triple Forward Camera from Tesla Model 3 1
Table of Contents
Overview / Introduction 4 Cost Analysis 38
o Executive Summary o Accessing the BOM
o Main Chipset o PCB Cost
o Block Diagram o CIS Cost
o Reverse Costing Methodology o BOM Cost – Board
o Housing Parts – Estimation
Company Profile 11 o BOM Cost - Housing
o ON Semiconductor o BOM Cost - Support
o Material Cost Breakdown
o Accessing the Added Value (AV) cost
Teardown Analysis 16
o Details of the Electronic Board AV Cost
o Views and Dimensions of the System
o Details of the Housing Assembly AV Cost
o System Opening o Details of the System Assembly AV Cost
o Electronic Board o Added-Value Cost Breakdown
Top Side – Global view o Manufacturing Cost Breakdown
Top Side – High definition photo
Top Side – Main Components markings Manufacturer Price Analysis 70
Top Side – Main Components identification o Financial Ratios
Bottom Side - Global view o Estimation of the Manufacturer Price
Bottom Side – High definition photo
Bottom Side – PCB Markings Give us your Feedbacks!
Bottom Side – Components Markings
Bottom Side – Components Identification
Company services 75
o Lenses Modules
