FOXTEL MANAGEMENT PTY LIMITED
Satellite MultiStacker Installation Requirements
FXTL-T-0219
Last Updated: 22/02/2018 11:35:00 AM
ISSUE 1 Revision 2
Satellite MultiStacker Installation Requirements
Document Control
© Copyright FOXTEL Management Pty Ltd. All rights reserved. This document
contains information proprietary to FOXTEL Management Pty Ltd. Except for the
purposes of evaluation, this document may not be reproduced, in whole or in part, in
any form, or distributed to any party outside of FOXTEL Management Pty Ltd, by any
means, without permission in writing, from FOXTEL Management Pty Ltd.
This document is classified to the level indicated at the top of this page. Any
classification containing the word confidence or confidential means the document is to
be placed out of sight when not in use and placed in a drawer or cupboard when the
room will be unattended. Any classification containing the word secret means the
document is always to be in someone’s hand or under secure lock when not in use.
Issue Issue Date Revision Revision Comments Prepared By Authorised By
# Date
1 15/09/17 0 SMS Launch Install Steven Circosta Thomas Russo
Specification
1 1 22/09/17 Frequency List & Steven Circosta John Mitsios
Wallplate - quality levels
added.
Optical systems.
1 22/02/18 2 22/02/18 Page 15 Steven Circosta Steven Circosta
Active Tap Powering
Maximum 1800mA
Maximum 4 Active Taps
Disclaimer
This document is correct at time of publication, Foxtel reserves the right to modify
channel plans or any other item within the document without prior notice to the field.
Refer to the Foxtel website for the latest version.
https://www.foxtel.com.au/index.html
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 2
Satellite MultiStacker Installation Requirements
Distribution List
Name Position Company
Dough Fewtrell Head of Field Operations Foxtel
Adam Brown Operations Manager Field Operations Foxtel
Thomas Russo Middleware and Security Development Foxtel
Manager
Enver Vasfi Hardware Development Manager Foxtel
Christopher Smith Strata Accounts Manager Foxtel
Martin Walsh Strata Accounts Manager Foxtel
Jason Gooch Commercial Business Manager Foxtel
Mark Bishop Commercial Business Manager Foxtel
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 3
Satellite MultiStacker Installation Requirements
Document Approval
Enver Vasfi Hardware Development Manager
15/09/2017
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 4
Satellite MultiStacker Installation Requirements
Table of Contents
1. OVERVIEW ................................................................................................................... 7
2. OBJECTIVE .................................................................................................................. 9
3. SCOPE.......................................................................................................................... 9
4. INSTALLATION REQUIREMENTS ............................................................................. 12
STB INSTALLATION .......................................................................................................... 16
STB FREQUENCY LIST SELECTION ................................................................................ 17
APPENDIX A. LIST OF OPTUS C1 – D3 STACKED AND NON-STACKED
FREQUENCIES INCLUDING FOXTEL TEST CHANNELS ................................................. 18
APPENDIX B. SCOPE OF WORKS ................................................................................ 19
Post Installation ................................................................................................................ 19
APPENDIX C. EARTHING .............................................................................................. 22
Equipotential Bonding Commercial Installation (Single Dwelling Residence – more than one
Wall plate) ............................................................................................................................ 22
Equipotential Bonding Multi-Dwelling Unit or Commercial Installation ..................................... 23
APPENDIX D. GLOSSARY OF TERMS .......................................................................... 24
APPENDIX E. REFERENCE DOCUMENTS .................................................................... 25
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 5
Satellite MultiStacker Installation Requirements
Table of Contents continued
Diagram 1 Typical Port Configuration of the Satellite Multistacker .......................................... 7
Diagram 2 Dip Switch default Position = Up On & Down Off ................................................... 9
Diagram 3 A small FTA – SAT Integrated no PDR system upgrade...................................... 12
Diagram 4 Single wire 4 way tap backbone with system calculations ................................... 14
Diagram 5 Single Wire 4 way splitter Concept Backbone using Active Taps to feed 128 outlets
over 4 levels ................................................................................................................. 15
Diagram 6 RF Cable Connection on an IQ3 STB .............................................................. 16
Diagram 7 RF Cable Connection on an IQ3 STB from a single wall plate ............................. 16
Diagram 8 RF Cable Connection on an IQ3 STB from twin diplexed wall plate ..................... 16
Diagram 9 – Equipotential Bonding in Single Premises ........................................................ 22
Diagram 10 – Equipotential Bonding Multi-Dwelling Unit and Commercial Premises ............ 23
Table 1 Shows Multistacker Dip Switch settings and STB State Settings.............................. 10
Table 2 shows vertical transponder groups stacked to the new H polarity transponder
Frequency .................................................................................................................... 11
Table 3 Frequencies for distribution through an SMS SMATV backbone .............................. 18
Table 4 – Wallplate Signal Level .......................................................................................... 20
Table 5 – Wallplate Digital Performance .............................................................................. 20
Table 6 – Wallplate Digital Slope / Tilt Performance ............................................................. 21
Table 7 – Post Installation Certification Test Locations......................................................... 21
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 6Satellite MultiStacker Installation Requirements
1. Overview
The Satellite Multistacker combines 2 horizontal & 2 vertical satellite services from 2
orbital locations and combines them on a single RF cable so that a single RF input port
on an IQ3 or later STB can receive the signals.
Diagram 1 Typical Port Configuration of the Satellite Multistacker
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 7Satellite MultiStacker Installation Requirements
The Multistackers have 4 input ports which cater for low & high band signals.
Low band via DC Voltage
High band via DC & 22 KHz tone.
Kingray
From left to right
Port 4 HH = 18 volts plus 22 KHz (future satellite)
Port 3 VH = 13 volts plus 22 KHz (future satellite)
Port 2 H L = 18 volts (Current Foxtel H pol services)
Port 1 V L = 13 volts (Current Foxtel V pol services)
Jonsa
From left to right
Port 4 V L = 13 volts (Current Foxtel V pol services)
Port 3 H L = 18 volts (Current Foxtel H pol services)
Port 2 V H = 13 volts plus 22 KHz (future satellite)
Port 1 H H = 18 volts plus 22 KHz (future satellite)
The units have 2 ports on the bottom.
Port 1 Stacked satellite output port with the option of line powering via a 12 volt
DC power injector and power pack.
Port 2 local powering via a 12volt DC power pack
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 8Satellite MultiStacker Installation Requirements
2. Objective
The satellite multistacker (SMS) is a standalone device that can be installed directly
after a twin or quad universal vertical - horizontal LNBF. It is typically installed before
the first distribution point in the SMATV system. An amplifier is installed where required
to provide a higher launch level of up to 108dBuV. (The multistacker typically outputs
a level of 80-85dBuV).
Due to the design of the multistacker there is no headend set up procedure, the Foxtel
N.I.T (Network Information Table) is updated which informs the SMS what frequencies
to tune to in the same way we update information to STB’s in the field. This becomes
a simple installation method for a large variety of building types which include:
Domestic homes that are difficult to re-cable.
MDU’s listed as “non-homes passed” which have been difficult to cable due to
cabling access.
MDU lite buildings that are H polarity only cabled.
Twin backbone no PVR buildings with single laterals.
Single wired Commercial Buildings.
Single wired residential Estates including RF or Optical distribution.
3. Scope
To install a multistacker, all RF distribution components within the network must be
capable of distributing the upper Frequency of 2400MHz, including:
Amplifiers
Power Injectors
Splitters
Taps
Cables
Connectors
Wall plates
Foxtel satellite transponders are distributed on frequencies between 950-2350MHz.
The SMS stacks V polarity transponders onto the H polarity so that a single cable can
distribute up to 32 satellite Transponders. This allows the integration of FTA services
on the one cable with the use of a FTA – Satellite diplexer that combines 45-862 MHz
FTA & 950-2400 MHz Satellite. Foxtel has updated the Installer Product List with
products capable of distributing signals at the higher frequency of 2400MHz which are
listed under the category “Multistacker”.
This allows the combined FTA – Satellite to be distributed down existing single cable
RF distribution networks that are fitted with a minimum of RG6 coaxial cable.
The stacker has been fitted with a 5 position dip switch which is switched to match the
State installed. This allows Foxtel to make better use of Transponder space in the
event that the total 32 transponders are used.
Diagram 2 Dip Switch default Position = Up On & Down Off
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 9Satellite MultiStacker Installation Requirements
The dip switches on the multistacker are switched to match the state installed
Switch 1 2 3 4 5 STB
Number Setting
National Off Off Off Off Off National 01
NSW On Off Off Off Off NSW 02
VIC Off On Off Off Off VIC 03
QLD On On Off Off Off QLD 04
SA Off Off On Off Off SA 05
WA On Off On Off Off WA 06
TAS Off On On Off Off TAS 07
NT On On On Off Off NT 08
Table 1 Shows Multistacker Dip Switch settings and STB State Settings
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 10Satellite MultiStacker Installation Requirements
Vertical Stacked Transponder Frequencies
The following tables shows the vertical stacked transponders for each state throughout
Australia. The multistacker is shipped with all dip switched set to the National Plan or
off position. This plan has higher frequencies which are used to commission an SMATV
or Optical Backbone before the correct state is selected. The new state is retuned
within 30 seconds of selecting the required plan. Meter plans have been listed on the
left from 01 to 08.
Meter Plan 12853.5 12895 12936.5 12978 13019.5
G31 G32 G33
S NAT 01 G35 T4 G34 T8 T10 T11 T12
11679 12227.5 12318 12729 12770.5
G31 G32 G33
S NSW 02 T10 T11 T12 G34 T8 G35 T4
G32 G33 G31
S VIC 03 T11 T12 G34 T8 G35 T4 T10
G33 G31 G32
S QLD 04 T12 G34 T8 G35 T4 T10 T11
G31 G32 G33
S SA 05 G35 T4 T10 T11 T12 G34 T8
G31 G32 G33
S WA 06 G34 T8 G35 T4 T10 T11 T12
G32 G31 G33
S TAS 07 T11 T10 T12 G34 T8 G35 T4
G33 G31 G32
S NT 08 T12 T10 T11 G34 T8 G35 T4
Table 2 shows vertical transponder groups stacked to the new H polarity
transponder Frequency
Important Note: It is crucial that the correct plan is selected for the required state, if
this is not carried out the subscriber will be missing some if not all vertical channel
groups. Resulting in a “No Signal” status.
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 11Satellite MultiStacker Installation Requirements
4. Installation Requirements
All Components within a SMATV backbone system must pass frequencies from 45
to 2400MHz. Any exception to this is shown in the following bullet points.
Backbone upgrades:
Upgrade existing FTA RG6/RG11 backbone system must have all devices
rated for the FTA and satellite bands from 45 - 2400MHz.
No PDR buildings with end of line multiswitches must have all components
rated from 45-2400MHz. The only exception to the rule is when using the
existing end of line multiswitch which are rated below 2400MHz. This may
result in a drop of signal level for transponders above 2150MHz. In most cases
signal attenuation will be minimal, but installers should take this attenuation in
signal level into account when calculating system losses.
Existing RG6 crimp connectors are permitted in upgraded systems.
Upgraded systems with RG11 crimp connectors must have the connectors
upgraded to RG11 compression connectors.
Backbone upgrades only requires 2 coaxial cables from a twin LNBF to the
multistacker
Diagram 3 A small FTA – SAT Integrated no PDR system upgrade
No PDR buildings are cabled with a single lateral cable to the wall plate, the SMS
allows the single lateral cable to provide satellite Horizontal pole and Vertical pole
transponders stacked onto Horizontal pole, plus FTA to an IQ3 or later STB.
Note: A GPO is required in the headend location. If this is not achievable line powering
via an in-line power injector with a dedicated “common property” GPO in another
location is possible. The unit is not to be powered from a private resident’s power
source.
Note: When local powering of SMS is used the installation of a power block at the RF
output of the SMS must be installed.
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 12Satellite MultiStacker Installation Requirements
New Backbone:
4 Cables run from the LNBF to the Multistacker.
A 5th Cable is installed from the roof FTA antenna to the multistacker / headend
location.
RG11 compression connectors are to be used for all RG11cables.
RG6 compression connectors are to be used for all RG6 cables.
Standalone satellite systems only require amplifiers with an operational range
of 950-2400MHz, no FTA amplifier is required.
When integrating FTA services, the FTA amplifiers are to operate in the range
45 – 862MHz.
Refer to the Foxtel Installer Product List for a full range of products that can be
used for SMS installations.
https://www.foxtel.com.au/content/dam/foxtel/support/pdf/installer-product-
list.pdf
When local powering of SMS is used the installation of a power block at the RF
output of the SMS must be installed.
Optical Systems and Residential Estates:
When integrating into an optical fibre network, the components used must be capable
of transmitting signals in the range of 5-2400MHz. Carriers networks that use RF
overlay for combining television services typically use the wavelength of 1550nm for
distribution through the network. Please check with the carriers requirements when
choosing the wavelength to be used.
Optical receivers should be capable of catering for a high channel load of 32 x 36MHz
satellite carriers and a minimum of 12 x 7 MHz COFDM FTA carriers. The channel load
may vary depending on the network requirments.
Wall plate signal levels & quality shall meet the requirements shown in tables 4, 5 & 6
of this document.
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 13Satellite MultiStacker Installation Requirements
Diagram 4 Single wire 4 way tap backbone with system calculations
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 14Satellite MultiStacker Installation Requirements
This type of backbone distributes both Satellite stacked services and FTA to a single
outlet. The use of a satellite / FTA diplexer is used to divide the satellite and FTA
signals to the Foxtel STB.
Diagram 5 Single wire 4 way splitter Concept Design using Active Taps to feed
128 outlets over 4 levels
The installation of active taps can be carried out with minimal signal loss to the
wall plate.
This design shows Optional Powering of Active Tap, Multistacker and LNBF
from Option 1 Local Power or Option 2 line powering from the active tap on
level 1.
Active Taps also have the option of being line powered from the input of the 4
way splitter. When this option is used powering of SMS & Active Tap from level
1 cannot be achieved.
Note: The maximum combined current draw from a single power supply
must not exceed 1800mA.
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 15Satellite MultiStacker Installation Requirements
STB Installation
Note: When connecting and IQ3 to a SMS wired backbone, satellite input 2 V pol is
not used.
Installation to the IQ3 STB is carried out by installing 1 satellite RF cable to
Input 1 and 1 FTA cable to TV input port.
Diagram 6 RF Cable Connection on an IQ3 STB
A single F type wall plate uses installation fit off code FD, connection to the
STB requires 3 RF cables and 1 Sat / FTA Diplexer.
Diagram 7 RF Cable Connection on an IQ3 STB from a single wall plate
A Twin diplexed F wall plate uses installation fit off code FM, connection to the
STB requires 2 RF cables.
Diagram 8 RF Cable Connection on an IQ3 STB from twin diplexed wall
plate
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 16Satellite MultiStacker Installation Requirements
STB Frequency List Selection
On Activating the sim card in the STB the State Frequency List selection is an
automated process. This field is updated via the postcode location for the installation
address.
In the event that a manual selection of the Frequency List is required, the following
setup can be selected under “Installer Setup – Satellite” in the electronic program guide
where the required frequency list or “correct state” can be entered.
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 17Satellite MultiStacker Installation Requirements
Appendix A. List of Optus C1 – D3 Stacked and non-stacked
Frequencies including Foxtel Test Channels
Non
Transponder Stacked NAT 01 NSW 02 VIC 03 QLD 04 SA 05 WA 06 TAS 07 NT 08
D3T4 1145.0 2153.5 2070.5 2029.0 1618.0 979.0 1527.5 2070.5 2070.5
D3T8 1311.0 2195.0 2029.0 1618.0 1527.5 2070.5 979.0 2029.0 2029.0
D3T10 1394.0 2236.5 979.0 2070.5 2029.0 1527.5 1618.0 1527.5 1527.5
D3T11 1435.5 2278.0 1527.5 979.0 2070.5 1618.0 2029.0 979.0 1618.0
D3T12 1477.0 2319.5 1618.0 1527.5 979.0 2029.0 2070.5 1618.0 979.0
D3T13 1020.5 1020.5 1020.5 1020.5 1020.5 1020.5 1020.5 1020.5 1020.5
D3T14 1062.0 1062.0 1062.0 1062.0 1062.0 1062.0 1062.0 1062.0 1062.0
D3T15 1103.5 1103.5 1103.5 1103.5 1103.5 1103.5 1103.5 1103.5 1103.5
D3T16 1145.0 1145.0 1145.0 1145.0 1145.0 1145.0 1145.0 1145.0 1145.0
D3T17 1186.5 1186.5 1186.5 1186.5 1186.5 1186.5 1186.5 1186.5 1186.5
D3T18 1228.0 1228.0 1228.0 1228.0 1228.0 1228.0 1228.0 1228.0 1228.0
D3T19 1269.5 1269.5 1269.5 1269.5 1269.5 1269.5 1269.5 1269.5 1269.5
D3T20 1311.0 1311.0 1311.0 1311.0 1311.0 1311.0 1311.0 1311.0 1311.0
D3T21 1352.5 1352.5 1352.5 1352.5 1352.5 1352.5 1352.5 1352.5 1352.5
D3T22 1394.0 1394.0 1394.0 1394.0 1394.0 1394.0 1394.0 1394.0 1394.0
D3T23 1435.5 1435.5 1435.5 1435.5 1435.5 1435.5 1435.5 1435.5 1435.5
D3T24 1477.0 1477.0 1477.0 1477.0 1477.0 1477.0 1477.0 1477.0 1477.0
C1T11 1578.0 1578.0 1578.0 1578.0 1578.0 1578.0 1578.0 1578.0 1578.0
C1T12 1658.0 1658.0 1658.0 1658.0 1658.0 1658.0 1658.0 1658.0 1658.0
C1T13 1698.0 1698.0 1698.0 1698.0 1698.0 1698.0 1698.0 1698.0 1698.0
C1T14 1738.0 1738.0 1738.0 1738.0 1738.0 1738.0 1738.0 1738.0 1738.0
C1T15 1778.0 1778.0 1778.0 1778.0 1778.0 1778.0 1778.0 1778.0 1778.0
C1T16 1818.0 1818.0 1818.0 1818.0 1818.0 1818.0 1818.0 1818.0 1818.0
C1T17 1858.0 1858.0 1858.0 1858.0 1858.0 1858.0 1858.0 1858.0 1858.0
C1T18 1898.0 1898.0 1898.0 1898.0 1898.0 1898.0 1898.0 1898.0 1898.0
C1T19 1938.0 1938.0 1938.0 1938.0 1938.0 1938.0 1938.0 1938.0 1938.0
C1T20 1989.0 1989.0 1989.0 1989.0 1989.0 1989.0 1989.0 1989.0 1989.0
Table 3 Frequencies for distribution through an SMS SMATV backbone
Table shows the I.F Frequencies for distribution through an SMS SMATV backbone.
Note: National plan 01 is used to commission all SMS SMATV back bone systems.
The higher frequencies are listed in the event that a total of 32 transponders are used,
this will result in new V pol stacked frequencies being used in stacked plans 02 through
to 08.
Foxtel’s satellite Test Channels are shown in yellow
Once the system logs have been taken on National Plan 01, a log is required out of
the stacker to confirm that the correct state plan has been chosen.
Please note: ACT uses the same plan as NSW 02.
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 18Satellite MultiStacker Installation Requirements
Appendix B. Scope of Works
Post Installation
At the completion of the installation, an approved ‘as built’ SOW document shall be
forwarded to FOXTEL to enable the building to be activated for the FOXTEL service.
Note: The National Service Provider / installation company submits an
electronic copy of the ‘as built’ Scope of Work document to FOXTEL.
Installation ‘As Built’ Drawing
An accurately electronic ‘as built’ design showing all the equipment that has been
installed in the system must be provided with the ‘as built’ SOW document.
Installation Photographs
Photographs shall be provided as appropriate for:
Dish location – showing skyline and Dish; LNB; Mount – close up photo
Headend location showing multistacker amplifiers and other devices
Tap location and earthing
FTA and FOXTEL integration point.
Installation Certification Testing
Post installation testing involves completion of a commissioning sheet contained within
the ‘as built’ SOW document.
All tests must comply with the wall plate specifications for installations tables and be
documented on the As Built SOW.
Testing by data logging is also acceptable.
LNB Tests
All ports on the LNB must be tested for Digital Channel Power, Modulation Error Ratio
and Bit Error Rate for the following Transponders (as a minimum).
C1 D3
T14, T20 T10, T12, T14,
T18, T22, T24
Amplifier Tests
The input and output signal levels are to be tested at the MATV launch amplifier.
Channel loading should be taken into account and launch level adjusted accordingly.
Passive Tap, Active Tap or MultiswitchTests
The Passive Tap, Active Tap, or (multiswitch on upgraded no PDR site) must be tested
for Digital Channel Power, Modulation Error Ratio and Bit Error Rate for Transponders
as per LNB Tests shown above (as a minimum). Testing by data logging is also
acceptable.
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 19Satellite MultiStacker Installation Requirements
Wall plate Tests
The signal levels must be tested at wall plates:
Closest to the Headend
Central to the Headend and
Furthest from the Headend.
All tests must comply with the wall plate specifications for installations tables.
Testing by data logging is also acceptable.
Table 4 – Wallplate Signal Level
Wallplate Level (dBµV)
Commercial Single Dwelling Multi-Dwelling Unit, Multi-
Broadcast Type Residence (SDR) ONLY Residential Estate and Large
Commercial
Systems >20 RF Channels
Standard Modulation type Min Max Min Max
Analogue FM radio 45 80 54 71
DVB-S / S2 QPSK / 8PSK 58 79 58 76
DVB-T COFDM 64 QAM 40 75 54 77
DAB+ DQPSK (EEP3A) 60 86 60 77
Note: All digital levels are RMS voltage or Digital Channel Power. Digital Channel Power
measured values may be +/- 2 dB from the levels listed due to accuracy of meters.
Table 5 – Wallplate Digital Performance
Modulation Error
Broadcast type Bit Error Rate Ratio
(In band noise ratio)
Pre-Viterbi Pre – RS
Standard Modulation Type or Post-Viterbi Minimum (dB)
DVB-S QPSKSatellite MultiStacker Installation Requirements
Table 6 – Wallplate Digital Slope / Tilt Performance
Broadcast Type Wallplate Level Slope Tilt (dB)
Maximum level difference Maximum level difference
Standard Modulation Type at single wallplate ALL wallplates in system
DVB-S QPSK 12 18
DVB-T COFDM 64 QAM 6 12
DAB+ DQPSK (EEP3A) 6 12
Note: Measured values may be +/- 2dB from the levels listed owing to accuracy of meters.
Table 7 – Post Installation Certification Test Locations
Broadcast Type Test Locations
Active Taps
Standard Modulation type Amplifiers Multiswitches and
wallplates
DVB-S QPSK 8 Transponders 8 Transponders
Highest and lowest
DVB-T COFDM 64 QAM All channels
channels
Quality Control
FOXTEL’s quality expectations and processes focus on ensuring that the design and
field installation process is positive and beneficial to everyone involved in the FOXTEL
process and that they will happily recommend the FOXTEL process to others.
FOXTEL reserve the right to actively inspect the work performed by the National
Service Provider to ensure that their work meets the required standards. If
subsequently the work is found to be of an inferior standard then the National Service
Provider will be required to make the necessary reparations.
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 21Satellite MultiStacker Installation Requirements
Appendix C. Earthing
Earthing and Equipotential Bonding (CET) Designs
All system components must be earthed in compliance with
AS/NZS 1367:2000, AS/NZS3000, (earthing conductors), and AS/ACIF
S009:2006.
Equipotential bonding is used to ensure that no hazardous voltages are present on the
outer conductors of a cable or any metallic component within the network.
A licensed electrician must carry out connections within the electrical switchboard.
Note: A suitably qualified person can carry out the connection for protective earthing external
to the switchboard.
Refer to the following designs for specific diagrams for earthing outline the preferred
methods for connection of a CET and bonding conductor.
Equipotential Bonding Commercial Installation (Single Dwelling
Residence – more than one Wall plate)
Diagram 9 shows the method for Equipotential Bonding in a commercial (Single
Dwelling Residence) single premise installation with more than one outlet.
Diagram 9 – Equipotential Bonding in Single Premises
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 22Satellite MultiStacker Installation Requirements
Equipotential Bonding Multi-Dwelling Unit or Commercial Installation
Diagram 10 shows the method for Equipotential Bonding in a Multi-Dwelling Unit or
commercial multiple premise installation.
Diagram 10 – Equipotential Bonding Multi-Dwelling Unit and Commercial
Premises
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 23Satellite MultiStacker Installation Requirements
Appendix D. Glossary of Terms
Term/Acronym Description
SMS Satellite Multistacker
No PDR Existing twin backbone single lateral backbone with a “No PDR”
installation status
SOW Scope of Works
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 24Satellite MultiStacker Installation Requirements
Appendix E. Reference Documents
For further information on Foxtel’s dish sizes and other installation requirements, refer
to the following documentation.
FOXTEL MANAGEMENT PTY LIMITED
Satellite Installation Manual – SIM
for
Multi-Dwelling Units
Multi-Residential Estates and
Commercial Installations
FD/T/E/2207
https://www.foxtel.com.au/content/dam/foxtel/support/pdf/installation-manual-mdu-
mre-commercial.pdf
FXTL-T-0219 Satellite Multistacker Installation Requirements Issue 1 Revision 2
Printed: 22/02/18
© FOXTEL Management Pty Ltd 2018 25You can also read
