Deutschlands erster Solar-Radweg Dipl.-Ing.(FH) Donald Müller-Judex Nationaler Radverkehrskongress 14. Mai 2019, Dresden www.solmove.com
vorher
CHALLENGES
Erftstadt / Köln
SOLUTION
Asphalt 35 Jahre alt
Cost savings through e-winter-service
Blick nach Osten
Improved lighting design +
Safety potential through sensors +
Additional safety information for cars +
Dynamic traffic management +
Easy integration of comfortable inductive charging
Green power from sealed traffic areas
Noise reduction
2
nachher
CHALLENGES
Erftstadt / Köln
SOLUTION
Asphalt 35 Jahre alt
Cost savings through e-winter-service
Blick nach Osten
Improved lighting design +
Safety potential through sensors +
130 Module
Additional safety information for cars +
(1,2 x 1,2 m)
Dynamic traffic management +
Easy integration of comfortable inductive charging
12 – 16 MWh p.a.
Green power from sealed traffic areas
Noise reduction
3
APPRECIATION & AWARDS
Erftstadt / Köln Nov 12th, 2018: Opening 1st Solar Bikelane
Federal Ministry of Environment Svenja Schulze
https://www.tagesschau.de/inland/solar-radweg-101.html
4
SURFACE
SOLUTION
5
WAY & VISION
Most competitors offer plain solar roads with costly installation and the need for large machinery. SOLMOVE’s
Solar Street can be mounted efficiently due to an easy plug and play solution. In the future several smart services
are planned, such as lighting, inductive charging, monitoring etc.
Ecosystem / S3 platform
+ software based services
extended applications
specific hardware extentions
proof of concept
basic hardware
Sensors & communications for open data allows:
• Lighting
• Data based services
• Heating
• E.g. Toll control, parking,
Erftstadt 12.11.2018 • Inductive charging
• Billing & payment
• Monitoring
6
VALUE PROPOSITION: NORTH
lighting
In northern places SOLMOVE’s economics are based on winter service savings
e-winter-
service safety
energy
production and
Main current value and calculation base is heating green
transmission
pioneer comfortable
function, enabling up to 80 % cost reduction for image charging
winter service on remoted roads and paths while eye-
catcher
being environment-friendlier (no salt, no split) and
quicker (no timedelay). Lighting, safety and image are appealing
arguments for municipalities, matching political goals/talks.
Winter Services - Costs p.a.
250
200
Euro per sqm
150
100
50
0
Winter Electric SOLMOVE
illustration of
Services Under-Floor Heating heated bikelane
Classic Heating
photo January 2018 Classic
Average number of snow days Bikelane in Erftstadt
7
VALUE PROPOSITION: CASE NORTH
Other cases in northern countries may have same reasoning, as roads: more safety through clean
visible surface. Example project with Deutsche Bahn “safe work path“
Further projects with
Deutsche Bahn in joint
examination:
• platforms
• cable shaft covers
• local storage
Illustration of de-icing and lightning 20 lux at S-Bahn Station Herrmannstraße / Berlin
8
VALUE PROPOSITION: CASE NORTH
A municipality with 150 €/sqm winter service cost can save 120 €/sqm yearly starting from
the first year of operation
Regular street SOLMOVE
investment* investment*
- 1 € / m² / p.a. - 12 € / m² / p.a.
maintenance maintenance
- 1 € / m² / p.a. - 1 € / m² / p.a.
winter service
- 30 € / m² / p.a.
power production
winter service + 11 € / m² / p.a. **
-150 € / m² / p.a.
less noise
* Lifecycle 25 years better lighting
** Direct consumption,
safety features
Germany
9
PARTNERS
SOLMOVE’s close relationship to its well established partners helped the company to become known within the
industry in no time. Solmove is part of several innovation hubs and research cooperations and governmental grants.
research development distribution finance
10COMPLETED / CURRENT PROJECTS
End of April SOLMOVE will have 3 completed projects in Germany
Parking area Torhäuser at Entrance area at RheinEnergie
Bikelane in the City of Erftstadt Gelsenkirchen Training centre
187 sqm / 130 modules 40 sqm / 28 modules 3,2 sqm / 9 modules
11WORLDWIDE REQUESTS
Berlin – EUREF-Campus
Berlin – Gleisdreieckpark
Switzerland – Aeschlimann Berlin – Vattenfall
Switzerland – Allschwil Berlin – Deutsche Bahn
Switzerland – Kreuzlingen China – Winter Olympic 2022
Highway (BJ-ZJK)
USA – Hawaii China – Highway (HZ-NB)
Wolfsburg – VW
USA – Los Angeles Dubai – Entrance of German
pavilion at Expo 2020
Chile – Santiago „Chile Sunbelt“ Munich – BMW
Munich – Stadt
12
Munich – LandkreisIMPACT GERMANY
SOLMOVE Smart Streets support the goals of the German government:
Auszüge aus dem Erneuerbare Energien Report 2019 des Bundesamtes für Naturschutz
• Bei konstantem Verbrauch müsste die erneuerbare Energieerzeugung mehr als versiebenfacht werden, um
die erforderliche Dekarbonisierung des Energiebereichs zu erreichen.
• Der zukünftige erneuerbare Energiemix sollte den umfassenden Ausbau von Photovoltaik, insbesondere auf
bereits bebauten Flächen und Windenergie verfolgen und dabei die Entwicklung besonders effizienter und
verträglicher Technologien fortsetzen.
• Zukunftsaussichten bieten sich hier neben der weiteren Erschließung durch Aufdach-Anlagen z. B. in der
Integration in die Gebäudehülle oder Verkehrswege. Solche Lösungen stellen aus Naturschutzsicht
konfliktfreie Optionen dar, da sie nicht „in der Fläche“ verortet werden müssen und so die „freie“ Landschaft
entlasten.
• Förderung nach EEG sollte künftig auch an die Flächenkulisse gekoppelt werden.
• Strombasierte Anwendungen sind die effizientesten Optionen im Wärme- und Verkehrsbereich. Die
Energiewende mit einer strategischen Neuausrichtung dieser Bereiche und dem Ausbau der Sektorkopplung
ist daher voranzutreiben.
13IMPACT WORLD
Solmove Smart Streets support* the sustainable development goals (SDG´s) of the United Nations
Sustainablity
SOLMOVE produces renewable energy …
Urbanisation
… using sealed surfaces like streets, ways, squares …
E-mobility
… in combination with inductive charging enables
system integration of energy supply and demand …
Digitalisation
… and generates open traffic data for safety and
comfort improvement…
14
* relevance has been certified by imugYou can also read
