DATA SHEET | 05/2021
B R O A D B A N D T E S T E R
data sheet: technical data subject to change.
DATA SHEET | 05/2021
ARGUS® 260: The broadband tester intec Gesellschaft für Informationstechnik mbH
The new ARGUS® 260 all-in-one tester delivers improved perfor- intec Gesellschaft für Informationstechnik mbH has been
mance for testing broadband interfaces. The high-quality mul- successfully developing products for the international telecom
tifunction tester is ideally equipped for the expansion of future markets for 30 years. Meanwhile specialized in high-quality
networks. telecommunication measuring devices, we belong to the leading
suppliers of xDSL, IP and fiber optic measuring technology in
Modern design and new housing concept Europe and beyond.
Its robust design combines the requirements for a compact
hand-held meter in daily field use with the performance of a The ARGUS® product range provides a convenient solution for
high-end tester. As the first ARGUS® tester with touch-screen commissioning and troubleshooting on xDSL and Ethernet
display, it enables intuitive navigation of the familiar ARGUS® connections. Specifically designed for user requirements in
menu structure. Thanks to the use of numerous graphical daily, praxis-related operations for international network
elements, the redesigned GUI makes this sophisticated operators, service providers and installation companies.
multifunction tester as easy to use as a smartphone. A new, The ARGUS® measuring devices have already been purchased
innovative internal help function supports rapid, reliable inter- more than 100,000 times.
pretation of test results.
Our customers have appreciated the quality of our products and
All necessary broadband interfaces services for many years. In the last 20 years alone, we have deli-
The ARGUS® 260 reliably tests all broadband interfaces, from vered more than 100,000 ARGUS® testers worldwide - many of
GPON and G.fast (106 + 212 MHz) to super vectoring, Bonding, them to international companies such as Deutsche Telekom,
ADSL and VDSL accesses, in the uncompromising quality you KPN or Austria Telecom.
have come to expect. It is also equipped with a wide range of
further interfaces and test functions, such as 2.5 Gigabit Ether-
net, WLAN, copper, TDR, RFL, triple play and many more.
data sheet: technical data subject to change.
Additional features
The integrated WIFI interface enables the ARGUS® 260 to
communicate with its environment directly - a PC link is no
longer required.
Once integrated in your job management system, the
ARGUS 260® marks the advent of a new generation of broadband
testing.
www.argus.info -2- sales@argus.info
DATA SHEET | 05/2021
Specification Broadband Interfaces:
General: Application, Settings + Results:
G.fast G.fast Modem Simulation, FTU-R, CPE G.fast / VDSL / ADSL G.fast / VDSL
Tester G.fast Bridge + G.fast Router • Net Data Rate d/u [kBit/s] • Signal Attenuation [dB]
ITU-T G.9700/9701 Profile 106a/212a • Attainable Data Rate d/u [kBit/s] • Showtime no Sync [Number]
Time Division Duplexing (TDD) • Relative Capacity d/u [%] • Seamless Rate Adaption (SRA)
VDSL • SNR Margin /Loop Attenuation d/u [dB] • Data Transmission Unit (DTU)
VDSL2 Modem Simulation, VTU-R, CPE
Tester VDSL2 Bridge + VDSL2 Router • Output Power d/u [dBm] • INP REIN + INP SHINE [Symbols]
ITU-T G.993.2 (Profiles 8, 12, 17a, 30a) • Interleave Delay d/u [ms] • Expected Throughput Rate (ETR) [kBit/s]
ITU-T G.993.2 Annex Q (Profile 35b), • Impulse Noise Protection d/u [Symbols] • Electrical Length @1 MHz R/C [dB]
Super Vectoring (Vplus) • FEC + CRC, far/near [Errors] • EFM Statistics: Frames + Bytes
ITU-T G.993.5, G.vector (Vectoring) • ES, SES, LOSS + UAS, far/near [sec]
VDSL
ITU-T G.998.4, G.INP (Retransmission) • Reset /Resync [Number]
• Vectoring Mode
ITU-T G.998.2, G.bond, 35b Bonding • Bitswap Events d/u
• Retransmission d/u (G.INP) • Graphical Long-time Trace in ARGUS®
ADSL ADSL Modem Simulation, ATU-R, CPE • Vendor, far/near [Name/ Number] ADSL
Tester ADSL Bridge + ADSL Router • Modem Trace • Latency Mode
ITU-T G.992.1, Annex A+B (ADSL) • Bits/SNR/QLN/Hlog/Noise Graphs
ITU-T G.992.2, Annex A (G.lite) • Graphical Long-time Trace in ARGUS®
• OK /Fail Evaluation: Bitrate, CRC, FEC
ITU-T G.992.3, Annex A+B+L+M (ADSL2)
• DC Voltage, UDC
ITU-T G.992.5, Annex A+B+J+M (ADSL2+)
GigE Ethernet according to IEEE 802.3 • Link Status, Autonegotiation, far/near • SFP: Digital Diagnostic Mode (DDM):
Tester 1 x 10/100/1000 Base-T (RJ45/8P8C) • Auto-MDI(X) Function - Manufacturer Name, OUI, Item Number,
• 2.5 GBase-T (IEEE 802.3bz, NBase-T) • Speed (10, 100, 1000 Mbit/s) Revision, Serial Number, Date, Coding,
1 x SFP Interface, supports: • Duplex Mode (full, half) / Flow Control Medium, Speed
• 100 Base-FX/LX • Polarity/Wire Pair (+/-) - Optical Level (Tx/Rx), ±3 dB
• 1000 Base-BX/LX/SX/ZX • Pair skew/Wire Pair [ns] - Optical class of the OLT
• 2.5 GBase-T (IEEE 802.3bz, NBase-T) • Frames (Rx/Tx) [Number] - Optical, PWR (Tx/Rx), ±3 dB
• FTTx (PtP), Active Ethernet • Errors, Bytes (Rx/Tx) [Number] - Temperature, Voltage, Current (Tx)
DDM according to SFF-8472 • Collisions [Number] - Max. Cable Length (Cu, SM, MM/OM1-4)
GPON GPON Modem Simulation, ONT, CPE • Link Status / Link Speed • GPON Modem Trace
Tester ITU-T G.984 • ONT Status / OLT Tx Power • Serial Number / Password Configurable
via ARGUS® GPON ONT • Optical Network Unit ID (ONU ID) • Scan PLOAM message (ONU ID, S/N)*
• GigaBit Passive Optical Network • Passive Optical Network ID (PON ID, • SFP: Digital Diagnostic Mode (DDM)
DDM accord. to SFF-8472 (see Ethernet) Vendor + Equipment ID / Version) • Optical Level (Rx), ±0.7 dB
• Optical Line Attenuation in dB
PON GPON installation test • guided measurement sequence • calibrated measurement of the insertion
installation PON level check • target attenuation can be entered as loss with ±0.5 dB accuracy
test threshold value • Assistance for up to 64 fibers
• automatic OK /Fail evaluation • Evaluation PON-ID
• PDF measurement protocol • Query of the job data
• SFP parameters (s. Eth/GPON)
WLAN WLAN Access Point Mode • WLAN Access Point Scan • Access Point Mode (WLAN Router) for
WLAN Client Mode - Number / List Access Points mobile devices
IEEE 802.11b/g/n (2.4 GHz) - Number 2.4 GHz / 5 GHz Networks - IP Tests (Data, VoIP, IPTV)
IEEE 802.11a/an/ac (5 GHz)* - Network/Name (SSID) • AP Management (save etc.)
• via WLAN USB Stick or - Signal Strength (RSSI) [dBm] • Test Result Upload via Web Server,
• internal FPC Antenna - Signal Quality [%] WebDAV and FTP
data sheet: technical data subject to change.
• WEP to WPA2 Enterprise - MAC Address of AP • Configuration Download via WebDAV
- Used Channel/Frequency and FTP
- Used Protocol • Remote Control via VNC, Web Server
- Negotiated Encryption - Firmware Update via FTP Download
- Authentification
- Group Cipher, Pairwise Cipher
WLAN • optional: ARGUS® 2G4 Scope • Real-time Analysis /Graphics • Detection of
• passive (no WLAN Interference) - Bluetooth Devices
spectrum graph. WLAN spectrum analysis for
analysis 2.4 GHz for the specific WLAN trouble- • Channel Load - Motion Sensors
shooting • Graphical representation - Microwave Ovens
- Baby Phones
www.argus.info -3- sales@argus.info
DATA SHEET | 05/2021
Specifications Protocol and IP tests (Triple Play):
General: Applications, Settings + Results:
Protocol Tests • Configurable MAC Address • Display of BRAS Information
• Use of Virtual Lines (VL): Maximum Flexibility as well - AC Name, Service Name, Session ID
as Control and Priorization under Real Conditions by • Display of PPP Information
Several VLs simultaneously - PPP Packets/Bytes (Tx/Rx)
• One VL/Service each (Data, VoIP, IPTV, opt.) - PPP Trace (PPP Commands, Time)
• VL Configurable in Profiles (20) • Display of IP Information
- IP, PPPoE via xDSL, G.fast + Eth (PPTP) - IPv6: Global Unicast/Link Local Address
- EoA, IPoA, PPPoA via ADSL - IPv4: Assigned IP, Gateway, DNS
- VPI/VCI, VLAN (Modus, ID, Prio., TPID) • Recording of a Data Log for Evaluation on PC
- PPP Profiles (Username, Password) (e.g. Wireshark)
- IP Version (IPv4, IPv6, Dual) + DHCP
- Automatic receiving of connection-dependent
dial-in data: PPP, VoIP (phone number)
Data Tests • Memory with up to 10 IP Addresses, • Round Trip Time (min/max/avg) [ms]
(Dowload Tester) (IPv4/6 Address as Number or Name) • Display Results Down- /Upload
PC/Terminal Simulation • Number of Pings, Pause Configurable (Ping), Packet - Current/Total Number [Number]
IP Ping Test Size + Fragmentation Configurable - Already Loaded Data [%]
Traceroute Test • Traceroute: Max. Hops, Probes + Timeout Conf. - Average Speed [Mbit/s]
HTTP Up-/Download Test • Down-/Upload: Server Profiles (10): - Loaded Bytes [MB]
FTP Up-/Download Test Server Addr., File Name/Size, Number, Number of - Transfer Time /Remaining Time [h:min:s]
FTP Server Test Parallel Downloads Configurable • Speedtest® by Ookla
Webbrowser - FTP: Username + Password - Download /Upload Speed
Ookla • Display Results IP Ping - Latency, Jitter, Packet Loss
iperf - Display of Packets (Tx/Rx/repeated) - Server Selection via Server ID
ARGUS® Real Speed - Checksum Error [Number] • iperf v2 /3
- Error Packets [Number] - Client /Server Mode
• Display Results Traceroute - TCP Throughput Down- /Upload
- Current Hop + Probe / List of Hops
- ARGUS® against ARGUS®
- Response Time of Hops [s]
- IP Address of Current Hops • ARGUS® Real Speed
- Evaluation according to RFC 6349
VoIP Tests (VoIP Tester) • Configuration in VoIP Profiles (20): • Duration of Connection [h:min:s]
IP Telephone Simulation SIP Username, Password, Registrar Server, Out- • MOS Plain Text Evaluation, According to E Model
Testing of VoIP Connections bound Proxy/SBC, Domain, Listen + Remote Port, R Factor, ITU-T G. 107 (current/avg),
incl. Acoustics (dif. Codecs) Authentification, Caller ID, User Agent, Qualify, Pro- MOS (current/avg/min/max/ideal)
MOS Evaluation (ITU-T P.800) cess of Registration • Statistics: RTP Packets (Tx/Rx),
Call Generator (up to 30 Calls) • Phone Settings: RTP Port Area, Silence Detection, • Error Counter: RTP Drop, RTP Error
Jitterbuffer, Codecs, DTMF • RTP Jitter Rx (current/avg/min/max)
• STUN Server • Lost RTP Packets (avg/min/max)
• MOS Threshold for OK/Fail Evaluation • RTCP Contents:
• VoIP QoS, Layer 3 Diffserv: RTP/SIP: ToS, DSCP - RTP Jitter far (current/avg/min/max) [ms]
• VoIP QoS, Layer 2 VLAN Prio.: RTP/SIP: VLAN Prio. - Lost RTP Packets of Remote Side
• Codecs: G.726 (16/24/32/40), G.729 (A/B), - Network Delay (current/avg/min/max) [ms]
G.711 (a-law/μ-law), G.722 - Display of Registration Details: SIP Codes,
• Display of Own Number, Number of Called Person Registrar IP, Proxy, URI
• Simulation (VoIP NT)
IPTV Tests (IPTV Tester) • Configuration in IPTV Profiles (3): • RTP/UDP Packet Loss Rate [%]
data sheet: technical data subject to change.
IPTV Device Simulation Editable Channel List (up to 250 Channels), • Delay [ms] + Delay Factor [ms]
IPTV STB Simulation Multicast IP + Port, Channel Name, IGMP version • Media Loss Rate (MLR) [%]
(Set-top Box) • Thresholds for IPTV OK/Fail-Evaluation: IGMP • IP Address of Channel + Port
OK/Fail Evaluation Latency, Sync Error, PCR Jitter, Error Indication, CC • IGMP Latency (Activation Time) [ms]
IPTV Channel Scan Errors, CC Error Rate, Audio + Video Bytes, RTP Jit- • For Correlation: xDSL CRC Counters
ter, RTP Sequence Error, Current + Total RTP Loss • RTP Errors, RTP Sequence Errors
IPTV Monitor (IPTV passive)
Rate • MPEG Bitrate + Packets (min/max/…), Bytes
• Different VLs for IGMP + RTP (current/min/max/...), PCR Jitter (current/min/max/
• Scan Profiles (3) Configurable: max. Zapping Time avg) [ms], CC Errors + Error Rate (current/max) [%],
• Display of Selected IPTV Channel, Test Duration, Error Sync + Indication
current Bitrate, OK or Fail • Codecs and PIDs (Packet Identifier)
• Packets Loss (current/min/max/avg) [Number] • Channel Zapping Time (min/max/avg) [ms]
www.argus.info -4- sales@argus.info
DATA SHEET | 05/2021
Specifications Ethernet and Fiber Tests:
General: Applications, Settings + Results:
Ethernet Cable Tests • Ethernet Port LED Flash • Port LED Flash with Timing
Network Scan • Auto Mode (manual, autom.) • Display of Detected Services, e. g. Mail, Print, Web, File,
• Network Address + Net Mask Configurable Database and many more
• Client Information: IP + Open Ports, MAC, Computer • Display of DHCP Discovery, Gateway, DHCP + DNS
Name, NetBIOS Name Server, Net Mask, No. of Detected Clients/Subnet
• Number of Open Ports/Clients
ARGUS OPM • Optical Power Meter in SFP form factor • Live display of the level
Optical Power Meter • Powerful InGaAs Photo Diode • Storage of the measurement in measurement protocols
• Optical Level Measurement with wavelengths from • Output in QR code
850, 1300, 1310, 1490, 1550, 1610, 1650 nm • Robust and protected by use in SFP slot
• Measuring range: • Optional Calibration at 1310, 1490 and 1550 nm (-20 dBm),
-60 dBm up to +6 dBm, ± 0.25 dB 20 °C
Optical Fault Finder • simple fault finder • distance to every event
• detects different types of optical faults • robust and protected by use in SFP slot
• up to 15 event with one test
Fiber Inspection Tool • USB Microscope for the ARGUS • min. Particle Size 0.5 μm
Video Microscope • optical Fiber Inspection • Defects: Core, Cladding, Adhesive, Contact
• manual Focusing with separate key • Scratches: Core, Cladding, Adhesive, Contact
• optional: Autofocus • different Tips /Adapters included in scope of delivery
• digital Zoom • PC, UPC, APC
• Pass /Fail evaluation according to IEC 61300-3-35 • Single Mode /Multi Mode
Specifications ISDN:
General: Applications, Settings + Results:
BRI S Interface • BRI S TE Mode, Terminal device simulation • Display L1, L2 and L3 of B Channel Status
ITU-T I.430 • Autom. Detection of Connection Configuration • incoming /outgoing Call
BRI S Terminal • L2 Mode: automatic, P-P, P-MP • Display of Call Parameters
BRI S Telephone • Test Availability of B Channels • own Acoustics
BRI S TE Simulation • BRI S Level and Voltage Evaluation • Connection: Call (Single/Block Dial)
• Protocol: DSS1
Specifications POTS:
General: Applications, Settings + Results:
POTS Tester • Fully-fledged POTS Butt Set, POTS Phone • Voltage Measurement + Display Polarity when Hook-on
Analogue Tester • POTS Terminal Equipment (TE) and Hook-off
POTS Butt Set • Analogue Phone w/ DTMF + Pulse Dial • CLIP + Caller-ID according to ETS 300 659/778
POTS Terminal Simulation • Incl. Fully-fledged Analogue Acoustics • Supports FSK + Display of Caller ID
POTS Monitor • High-impedance Listening on POTS • FLASH Function (40 up to 1000 ms)
• Configurable DTMF Signal Level
data sheet: technical data subject to change.
www.argus.info -5- sales@argus.infoDATA SHEET | 05/2021
Specifications Cable Multimeter:
General:
Measuring Range Resolution Accuracy
DC Voltage; UDC (U=): • 0 V to 9.99 V • 0.01 V • ± (0.5 % + 2 digits)
• 10 V to 200 V • 0.1 V • ± (0.5 % + 2 digits)
AC Voltage; UAC (U~): • 0 V to 9.99 V • 0.01 V • ± (2 % + 2 digits)
• 10 V to 200 V • 0.1 V • ± (1.5 % + 2 digits)
Frequency: 10 Hz to 200 Hz; 0.2 Hz; ±(1.5 % + 2 digits), sinus
Capacitive Symmetry • 10 nF to 4 μF • 0.01 nF • 0.1 % of the capacity against ground
Balance; CSym: Dielectric strength for external voltage up to 17 V DC or 17 V AC (with a load 200 kΩ).
Capacitance; C: • 0.01 nF to 9.99 nF • 0.01 nF • ± (4 % + 4 digits)
• 10 nF to 99.99 nF • 0.01 nF • ± (4 % + 4 digits)
• 100 nF to 999.9 nF • 0.1 nF • ± (3 % + 1 digit)
• 1 μF to 8 μF • 1 nF • ± (3 % + 1 digit)
Dielectric strength for external voltage up to 17 V DC or 17 V AC (with a load 200 kΩ). Measured by film capacitors.
Isolation Resistance • 0.1 kΩ to 99.9 kΩ • 0.1 kΩ • ± (2 % + 1 digit)
(105 V, max. 2 mA); Iso: • 100 kΩ to 999 kΩ • 1 kΩ • ± (2 % + 1 digit)
• 1 MΩ to 9.99 MΩ • 10 kΩ • ± (2 % + 1 digit)
• 10 MΩ to 99.9 MΩ • 100 kΩ • ± (5 % + 1 digit)
• 100 MΩ to 1 GΩ • 100 kΩ • ± (5 % + 1 digit)
Dielectric strength for external voltage up to 5 V DC or 30 V AC (with a load 200 kΩ).
Isolation Resistance • 0.1 kΩ to 99.9 kΩ • 0.1 kΩ • ± (2 % + 1 digit)
(8 V, max. 9 mA); Iso: • 100 kΩ to 999 kΩ • 1 kΩ • ± (2 % + 1 digit)
• 1 MΩ to 9.99 MΩ • 10 kΩ • ± (2 % + 1 digit)
• 10 MΩ to 40 MΩ • 100 kΩ • ± (5 % + 1 digit)
Dielectric strength for external voltage up to 5 V DC or 30 V AC (with a load 200 kΩ).
Resistive Symmetry Balance; • 10 Ω to 5 kΩ • 0.1 Ω • 0.2 % of Rs ± 0.2 Ω
RSym: Dielectric strength for external voltage up to 30 V DC or 30 V AC (with a load 200 kΩ).
Loop Resistance; R: • 1 Ω to 999.9 Ω • 0.1 Ω • ± (1 % + 3 digits)
• 1 kΩ to 9.999 kΩ • 1Ω • ± (1 % + 1 digit)
• 10 kΩ to 99.99 kΩ • 10 Ω • ± (1 % + 1 digit)
• 100 kΩ to 999.9 kΩ • 100 Ω • ± (1 % + 1 digit)
• 1 MΩ to 9.999 MΩ • 1 kΩ • ± (2 % + 1 digit)
• 10 MΩ to 40 MΩ • 10 kΩ • ± (5 % + 1 digit)
DC Current; IDC (I=): • 0 mA to 150 mA • 0.1 mA • ± (2.5 % + 3 digits)
Unbalance @ 1 MHz; LCL: • 0 dB to 55 dB • 0.1 dB • ± 1.5 dB
• 55.1 dB to 65 dB • 0.1 dB • ± 3 dB
The length of the test leads can influence the accuracy of the measurement.
Dielectric strength for external voltage up to 3 V DC or 3 V AC. At an internal resistance of the source of 1 MΩ it will be measured up to 3.5 V DC / AC.
NEXT @ 1 MHz; NEXT: • 0 dB to 65 dB • 0.1 dB • ± 1 dB
data sheet: technical data subject to change.
Dielectric strength for external voltage up to 3 V DC or 3 V AC. At an internal resistance of the source of 1 MΩ it will be measured up to 3.5 V DC / AC.
RFL • Display of: • Measuring ranges: • Accuracy Rx at Lx/L = 0.1
Resistance troubleshooting - Resistance to error (Rx), - Loop resistance (Rs): - Rs = 2000 Ω: ± 0.3 % ± 0.05 Ω
distance to error 10..9999 Ω - Rs = 200 Ω: ± 1.0 % ± 0.06 Ω
- Resistance from fault to short- - Fault resistance (Rfault):
circuit (Ry) 0..20 MΩ
- Loop resistance (Rs),
cable length
- Fault resistance (Rfault)
Remote Kit Control • Use ARGUS to control different Remote Kits to switch the Line on the remote side, e.g. TX916
- Short-circuit - Loop
- Exchange connect - Tone mode
- Open circuit - switch 2 ports simultaneously
Other Functions: • Autotest • Fast cable check • Signature detection (e.g. PPA)
Reference Conditions • Temperature: 23 °C ± 5 °C • Frequency of measurement type:
(calibration): • Relative humidity: 50 % ± 20 % relative humidity, non-condensing 50 Hz ± 5 Hz, sinus
www.argus.info -6- sales@argus.infoDATA SHEET | 05/2021
Specifications Copper Tests
General: Applications, Settings + Results:
TDR Test • Determination of the Loop Length • Res.: 0.025 % of Measurement Range; Accuracy: ±2 %
Time Domain Reflectometer • For Identification and Detection of Shorts, Opens, • Graphical Display of Reflection Course
Impedance Mismatches, Bridged Taps/Stubs, • Configureable gain: -26 dB up to +44 dB
Moisture, Loading Coils, Loose Contacts and more • Config. Pulse: 5 ns up to 3.2 μs, Pulse Height: 5 V and 20 V
• Pre-configured List of Cable Types, Velocity of • Dynamic range: 60 dB / Amplification Level
Propagation (VoP): 30 % (45 m/μs) up to 99.9 % • Zoom + Cursor for a Detailed Analysis
(149.7 m/μs), Line Resistance, Mutual Capacitance • Save + Set of Reference Curve
• Measurement Range: 3.5 up to 6000 m • Start/Stop Function (Realtime Mode)
Line Scope • Monitoring in Time/Frequency Domain on all Types • For Identification and Detection of different Access Types
DSL Spectrum Analysis of Lines for Telecommunications and on active • Graphical Display of FFT [dBm/Hz] and of Time
DSL Oscilloscope Lines with up to 200 VDC and 40 Vpp (Oscilloscope)
RF Current Clamp • Modem Finder, via Handshake Tones • Config. X-Axis: FFT or Time [μs]
• Frequency Range: 20 kHz up to 35 MHz • Autom. Trigger in Time Domain
• Resolution: 67 Hz up to 8.625 kHz or 0.025 % of • Zoom + Cursor for a Detailed Analysis
Measurement Range, Accuracy: ±2 dB • Save + Set of Reference Curve
• High-impedance or Line Termination: • Start/Stop and Peak Hold Function)
- Input Impedance: 3.6 kΩ,DATA SHEET | 05/2021
Standard Package:
Basic device incl. Gigabit-Ethernet interface (10/100/1000 Base-T), ADSL (Annex A+L+M) + VDSL2 (up to profile 35b), Bridge/router mode, Wi-Fi-
Management, IP+Download package (IP ping, traceroute test, HTTP/FTP download, FTP upload/server, Speedtest® by Ookla), Line scope, Network
scan, Web browser, Cloud services, Lithium-Ion battery pack, Mains adaptor, Shock absorbing rubber jacket, Carrying case, 2 wire cable + xDSL
adaptor, Micro USB cable, Carrying strap, Hand strap and English manual
Additional Options:
• ADSL Annex B+J Enhancement Order number: 026008
• VDSL2 Bonding Enhancement (up to Profile 35b) requires Art.No.: 026045, incl. Bonding Cable Order number: 026050
• G.fast Enhancement (Profile 106a and 212a) Order number: 026045
• Time Domain Reflektometer (TDR) up to 6 km Order number: 026040
• Copper Package (Cable Multimeter/DMM) incl. banana cable red/black + green Order number: 026010
• RFL Option requires Art.No.: 026010 Order number: 026055
• ARGUS Active Probe II (high impedance probe for Line Scope) Order number: 015091
• ARGUS RF Current Clamp Order number: 000265
• Optical Light Source (OLS) Order number: 000280
• 2,5 Gigabit Ethernet Interface 10/100/1000/2.5 GigE via RJ45 and SFP Order number: 020035
• GPON Option incl. ARGUS GPON ONT SFP, incl. SC/LC-APC patch cable Order number: 026076
• GPON Option, calibrated incl. Art.No.: 026076 Order number: 026077
+ initial calibration of the level masurement
• PON Installation Test incl. Art.No.: 026077 Order number: 026078
• OPM Option incl. ARGUS Optical Power Meter (SFP), type 6006 Order number: 026080
• Optical Fault Finder Option w/o OFF SFP (000275) Order number: 026083
• Fiber Inspection Option w/o Fiber Inspection Tool Order number: 026094
• Wi-Fi Test Interface w/o Wi-Fi USB stick (000250) Order number: 026059
• ARGUS 2G4 Scope (2.4 GHz Spectrum Analysis) incl. USB 2G4 Scope stick Order number: 000240
• VoIP Option incl. MOS value, Call generator, NT Sim., SIP trunk Order number: 026060
• IPTV Option incl. IPTV STB mode, IPTV passive, channel scan Order number: 026065
• Entertain Package incl. VoIP and IPTV Option Order number: 026067
• ARGUS Real Speed RFC 6349, incl. iPerf v2/ v3 Order number: 026056
• iPerf v2/ v3 Client/ Server Order number: 026068
• ISDN BRI S/T TE Interface requires Art.No.: 026045 Order number: 026016
• POTS Option POTS Order number: 026070
• SFP Support supports various SFP types Order number: 026042
* We would be glad to provide further details and information about additional accessories on request.
data sheet: technical data subject to change.
Rahmedestraße 90
D-58507 Lüdenscheid
Tel: +49 2351 9070-0
Fax: +49 2351 9070-70
E-Mail: sales@argus.info
Internet: www.argus.info
www.argus.info -8- sales@argus.infoYou can also read
