EQUIPMENT & ACCESSORIES GUIDE
BL ADES & BRUSHES
DIAMOND U BLADE 10” JOINT CLEANING/ STELLITE JOINT FILLER
PREP DIAMOND BLADE REMOVAL BLADE
.25” x 5” Blade
7” x .125 Blade
.375” x 5” Blade
7” Blade 7” x .187 Blade
8” Blade 8” x .125 Blade
10” Blade 8” x .187 Blade
TIGER TOOTH BLADE
JUSTCUT TURBO
4.5” ZEC
U BLADE
HEAVY ABRASIVE PAD
4.5” Blade 16 grit
4.5” x .090 Blade
7” Blade 24 grit
7” x .090 Blade
8” Blade 36 grit
8” x .095 Blade
NYALOX NYALOX NYALOX
CUP BRUSH WHEEL END BRUSH
.75” Brush
3” Cup
2.5 Cup 4” Cup
TELESCOPING FLOOR
MEDIUM GRIT RAZOR SCRAPER
FINISHING PAD
Distributed By
8” Scraper
Blue (coarse) Scraper Blades
Orange (extra coarse) (pack of 10)
info@metzgermcguire.com
CARTRIDGE GUNS
ALBION 250ML SINGLE CARTRIDGE GUN ALBION T1500 DUAL CARTRIDGE GUN
FOR USE WITH RAPID REFLOOR 250 ML CARTRIDGES FOR USE WITH SPAL-PRO RSF OR
RAPID REFLOOR PIT GROUT 1500 ML CARTRIDGES
NEWBORN #632 BULK CAULKING GUN ALBION T900 DUAL CARTRIDGE GUN
FOR HAND APPLYING MM-80 FOR USE WITH SPAL-PRO 2000 900 ML CARTRIDGES
NEWBORN MODEL 435XSP ALBION T600 DUAL CARTRIDGE GUN
CARTRIDGE GUN FOR USE WITH SPAL-PRO RS88,
FOR USE WITH SPAL-PRO 2000 450 ML CARTRIDGES EDGE-PRO 80, RAPID REFLOOR, & RS65
600 ML CARTRIDGES
Distributed By
info@metzgermcguire.com
1-800-223-6680
S TAT I C M I X E R S & LO C K N U T S
STATIC MIXER FOR STATIC MIXER FOR STATIC MIXER FOR
RAPID REFLOOR 250 ML SPAL-PRO 2000 450 ML EDGE-PRO 80 600 ML
STATIC MIXER FOR STATIC MIXER FOR STATIC MIXER FOR
RAPID REFLOOR 600 ML SPAL-PRO 2000 900 ML RS-88 & RS-65 600 ML
STATIC MIXER FOR
DUAL-COMPONENT
PUMPS OR 1500 ML LOCK NUT CLEAR LOCK NUT ALUMINUM
CARTRIDGES
LOCK NUT SQUARE LOCK NUT BLACK ALUMINUM NIGHT CAP
www.metzgermcguire.com
Cartridge/Mixer Matches
RAPID REFLOOR 250 ML RAPID REFLOOR 600 ML
Static mixer: Static mixer:
1/4” x 32 element static mixer 10.7 mm x 24 element square static mixer
Flow Restrictor Cap Flow Restrictor Cap
EDGE-PRO 80 600 ML & EDGE-PRO 90 600 ML SPAL-PRO RS-65 600 ML & SPAL-PRO RS-88 600 ML
Static mixer: Static mixer:
3/8” x 24 element static mixer 3/8” x 32 element static mixer
for Metzger/McGuire Products
SPAL-PRO 2000 450 ML SPAL-PRO 2000 900 ML
Static mixer: Static mixer:
8.7 mm x 24 element static mixer 1/2” x 24 element static mixer
PIT GROUT 1500 ML, SPAL-PRO STABLIZER EXP 1500 ML & SPAL-PRO RSF 1500 ML
Static mixer:
1/2” x 30 or 32 element static mixer
These machines are designed to clean-out existing control joints, remove old
joint fill material that needs to be replaced and rout out random cracks in
concrete surfaces. Durability, ease of use, high accuracy and production
rates are the key components to our industry leading line of saws.
JS131 GAS WALK
BEHIND JOINT JS160 PROPANE JOINT
CLEAN-OUT SAW CLEAN-OUT SAW
CC100 WALK
BEHIND CRACK
5” HAND HELD
CHASER
MARK III DUST CRACK CHASER
BUGGY
TO PREVENT SERIOUS INJURY DO NOT OPERATE SAW WITHOUTPROPER TRAINING AND.
UNDERSTANDING OF THE OWNERS MANUAL
WHEN OPERATING THIS MACHINE
ALWAYS WEAR SAFETY APPROVED
HEARING PROTECTION
EYE OR FACE PROTECTION
PROTECTIVE HELMET
PROTECTIVE GLASSES OR FULL FACE PROTECTION
WEAR HAND PROTECTION
Polymer Pumps are easy to use machines for filling control joints with semi-rigid epoxy and polyurea joint fill WARNING: Improperly maintaining the JS including the Honda engine or failing to correct a problem before
operation could cause a malfunction resulting in a serious injury. Always perform a pre-operation inspection before
each operation and correct any problem. See Honda Engines Owner's Manual.
materials. The simple design makes maintenance easier and less time-consuming. The semi-transparent 5.2 Check the condition of the Honda engine. See the section titled "Before operation - is your
poly tanks allow OF THE the operator to monitor the level of material used.
engine ready to go?" in the Honda Engines Owner's Manual.
TO PREVENT SERIOUS INJURY DO NOT OPERATE SAW WITHOUTPROPER TRAINING AND.
UNDERSTANDING OWNERS MANUAL
WHEN OPERATING THIS MACHINE
WARNING: Exhaust gas from gasoline engines contains dangerous carbon monoxide. Breathing it can cause
US SAWS TWO MAN
unconsciousness and even kill you. Always operate gasoline engine machines in a well-ventilated area. Do not
operate in areas where exhaust fumes could accumulate without wearing appropriate respiratory protection.
US SAWS ONE MAN
Consult your employer and OSHA regarding use of appropriate respirator for dangerous carbon monoxide
POLYMER PUMP
gases. See Figure 7.
POLYMER PUMP
ALWAYS WEAR SAFETY APPROVED
HEARING PROTECTION
EYE OR FACE PROTECTION
Engine exhaust contains
PROTECTIVE HELMET poisonous carbon
PROTECTIVE GLASSES OR FULL FACE PROTECTION monoxide gas. Breathing
it could cause death.
Operate machine in well
ventilated area.
WEAR HAND PROTECTION
Figure 7 - Warning label - engine exhaust contains carbon monoxide gas 11
WARNING: Improperly maintaining the JS including the Honda engine or failing to correct a problem before
operation could cause a malfunction resulting in a serious injury. Always perform a pre-operation inspection before
each operation and correct any problem. See Honda Engines Owner's Manual.
5.2 Check the condition of the Honda engine. See the section titled "Before operation - is your
engine ready to go?" in the Honda Engines Owner's Manual.
WARNING: Exhaust gas from gasoline engines contains dangerous carbon monoxide. Breathing it can cause
unconsciousness and even kill you. Always operate gasoline engine machines in a well-ventilated area. Do not
operate in areas where exhaust fumes could accumulate without wearing appropriate respiratory protection.
Consult your employer and OSHA regarding use of appropriate respirator for dangerous carbon monoxide
gases. See Figure 7.
Engine exhaust contains
poisonous carbon
monoxide gas. Breathing
it could cause death.
Distributed By
Operate machine in well
ventilated area.
Figure 7 - Warning label - engine exhaust contains carbon monoxide gas 11
TO PREVENT SERIOUS INJURY DO NOT OPERATE SAW WITHOUTPROPER TRAINING AND.
UNDERSTANDING OF THE OWNERS MANUAL
WHEN OPERATING THIS MACHINE
mminfo@metzgermcguire.com
ALWAYS WEAR SAFETY APPROVED
HEARING PROTECTION
no waiting time until the
motor can restart
BDN 511 Low operating cost
through an electronic and
Floor channel cutting system a mechanical clutch
Electronics for a smooth
start and an LED light for
dry Diamond floor optimal
channel cutting
cutter withefficiency
11 diamond
cutting blades for bridgeless milling
Dust-free milling with
up to 2” wide and 1.8”
excellent dust deep
suction
2.400 Watt power and best rotation
device, 1 1/2"speed for extensive
diameter
milling in the hardest of materials without effort
All cutting depths possible in one step with 11 diamond
cutting blades
Diamond channel cutter with 11 diamond cutting blades
for bridgeless milling up to 2" wide and 1.8" deep
Safe, with a unique and powerful overload electronic
Electronic control to prevent overload, therefore no waiting time
2.400 Watt power and best rotation speed foruntil
extensive
the motor can restart
milling in the hardest of materials without effort
Low operating cost through an electronic and a mechanical clutch
All cutting depths possible in one step
with 11 diamond cutting blades Electronics for a smooth start and an LED light for optimal cutting
efficiency
Applicable with the track system BRS 512, BRS 513, BRS 514
and the floor channel cutting system BDN 511Dust-free milling with excellent dust suction device,
1 1/2” diameter
POWER TORQUE BLADE Ø CUTTING WIDTH CUTTING DEPTH WEIGHT
2.400 W 7.800 rpm 6" up to 2" up to 1.8" 14.3 lbs
BDN 511 ID #
Diamond floor channel cutter BDN 511 with 11 diamond cutting blades GOLD II with carrying case and acc. 6926
Diamond floor channel cutter BDN 511 with 11 diamond cutting blades GOLD II with carriage + carrying case 7375
Special hook to tighten or loosen the BAIER diamond blades 11239
Carriage for BDN 511 7336
Diamond cutting blade GOLD II, diameter 6" x 1.2" for reinforced concrete, highly compressed 75333
lime stone, brick and poroton
Diamond cutting blade
800-223-6680
www.metzgermcguire.com
GCT-10 ELECTRIC JOINT SAW
SPECIFICATIONS
Power Requirements......... 120 volts, 20 amps
Cutting Depth..................... Adjustable 0” - 2.5”
Blade Size.......................... 9” maximum (7/8” arbor)
Grinder.............................. Metabo W24-230
Wheel Size:........................ 4”(D) x 2”(W)
Arbor Size.......................... 5/8”
Vacuum Requirement........ 250 c.f.m. minimum (2” dust port)
CC-6 ELECTRIC CRACK CHASER
SPECIFICATIONS
Power Requirements:........ 120 Volts, 20 Amps
Cutting Depth:.................... Adjustable 0” - 1”
Blade Size:......................... 6” (7/8” arbor)
Handle Positions:............... 4
Vacuum Requirements:...... 300 cfm (3” dust port)
Wheel size: ....................... 4”(D) x 2”(W)
GCT-X SERIES JOINT SAW
ELECTRIC JOINT SAW COMBUSTION JOINT SAW
Weight:........................... 150 lbs Power Head: Power Head:
Blade Size:...................... 8”or 10” Baldor 240 Volt, 5.5 HP, Honda GX-390, 11.7
Arbor size: ..................... 7/8” 26 lb-ft (Peak torque), HP, 19.5 lb-ft (Peak
Cutting Depth:................. up to 3” Honda GX-390 torque), Baldor 240
Vacuum Requirement:...... 250 cfm (8”), (Gas), 11.7 HP, 19.5 Volt, 5.5 HP, 26 lb-ft
250 cfm (10”) lb-ft (Peak torque) (Peak torque)
GP-1 DUAL COMPONENT PUMP GP-2 DUAL
Motor:................... 1 HP DC motor
Tank Size: ............. 2 Stainless 6.4 Gallon Tanks
Hoses: ................... PTFE lined SS Brained Lines
Applicator:............ Aluminum Dual Port Manifold
Controller:............. Variable Speed, Smooth Start/Stop
Viscosity:............... 200-7000 cPs
Flow Rate: ............ Up to 1 GPM
Ratio:..................... 1:1 (2:1 option available)
Power Source:....... 115 V AC (Standard,
Weight: 230 lbs. Dry 24V DC (optional) Weight:190 lbs. Dry Generator,
Mounting Bracket 20 lbs.
Distributed By 800-223-6680 info@metzgermcguire.comI ndustry s tandard I ndustrIal Floor JoInt FIllers and r epaIr products
