1Quote Submission Form
Tender Number: PW 2023-11
Quotation for a Crack Sealing Trailer, Router and
Description:
Compressor
Closing Date: March 2, 2023
Closing Time: 4:00:00 PM
Company Name:
Specifications and General Conditions of these units shall be the latest models with all
standard equipment plus all other equipment outlined in this specification, if not standard.
Make:
Model:
The preferred specification is for a:
• Cimline M2 2020 230 Gallon Crack Seal Trailer Melter Applicator (appendix A)
• Cimline 30HP R3 Asphalt Crack Router (Appendix B)
• DMAC Diesel Drive D60 Air Compressor including heat lance and compressor wand
(Appendix C1 and C2)
These specifications are not intended to be restrictive but are meant to describe the kind and size
of unit desired to be purchased in detail. If bidder is basing the proposal on equipment other than
what is specified in these bid documents and wishes the equipment to be considered as an
"approved equal" they shall submit on a separate sheet, an item-by-item description of that which is
proposed.
THE LOWEST OR ANY QUOTE NOT NECESSARILY ACCEPTED.
The Township reserves the right to accept or reject any or all quotations and to waive irregularities
at its discretion. The Township reserves the right to accept a proposal other than the lowest price
without stating the reasons such as delivery date. By the act of submitting its proposal, the bidder
waives any right to contest, in any legal proceeding or action, the right of the Township to award
the tender to whomever it chooses, and for whatever reasons the Township deems appropriate.
Item Make, Model Year Price (excl. HST)
CRACK SEALING TRAILER
ASPHALT CRACK ROUTER
COMPRESSOR
HST
Total including HST
2I/We the undersigned have read and understand this quotation document and agree to perform the
work required in accordance with this quotation form, at the price(s) listed above.
Signed and submitted for and on behalf of:
Company Name
Address City Postal Code
Signature of Authorized Signing Officer Print Name and Title
Date Email Address
Telephone Number Fax Number
3Cimline™
Cimline M2™ 230 Gallon Crack Sealing Unit
Detailed Specification Trailer Melter/Applicator
Revision Date: 09/2020
1.0 Purpose: Yes No
1.1 The crack sealing unit (melter/applicator) must be able to safely melt, agitate, circulate and apply all
grades of asphalt rubber sealants, specification joint sealants, jet fuel resistant sealants and fiber
modified asphalt sealants. The machine must be capable of starting at ambient temperature and
bringing material to pouring temperature in less than one hour. The unit must have continuous
sealant agitation with internal recirculation of sealant (not hose recirculation) to eliminate
temperature stratification of sealant being applied. Complete operation manual, parts lists, and
training video must be furnished with the unit. A factory-trained representative will be available for
initial startup and training.
1.2 The equipment being bid must be new, current year production and meet the needs of this
specification without modification. The model must be currently advertised, have been in production
for a min. of two years and have a working volume of not less than called for in this specification.
Hybrid, one-off or prototype equipment is unacceptable.
1.3 These specifications are not intended to be restrictive, but are meant to describe the kind and size of
unit desired to be purchased in detail. If bidder is basing the proposal on equipment other than what
is specified in these bid documents and wishes the equipment to be considered as an "approved
equal" they shall submit on a separate sheet, an item by item description of that which is proposed.
The bidder’s specifications must be complete and of sufficient detail to cover all items included in this
bid specification and in a manner that allows a direct comparison. Any item not covered will be
deemed as not meeting specifications. Such bidder shall also include, but not as a substitute for the
above, any manufacturer's literature. In addition, if the bidder takes exception to any item they shall
note this and describe in detail the exception and how the proposal is an "approved equal". Failure to
carry out the provisions noted herein may be deemed sufficient reason to reject the bidder's
proposal. Check yes if demonstration has been performed prior to bid letting.
2.0 Basic Machine Requirements: Yes No
2.1 Double jacketed boiler type material tank design.
2.2 Trailer mounted and rated for highway class use.
2.3 Diesel powered and diesel heated.
2.4 Electric heated sealing hose equipped only.
2.5 Minimum working capacity of 230 gallons.
2.6 Two (2) insulated loading doors on machine.
2.7 LED sealed lighting including stop/turn and clearance lights.
2601 Niagara Lane North Page 1 of 5 Toll Free: +1-877-841-0848
Plymouth, MN 55447 U.S.A. www.cimline.com Fax: +1-866-557-19713.0 Melting System Minimum Requirements: Yes No
3.1 The material tank must be of double boiler design and have a minimum working volume of 230
gallons. Working volume can be described as the maximum usable amount of sealant that can be
contained in the material tank at one time and pumped out of the hose.
3.2 The material and oil tanks must be constructed of no less than 7 gauge (.179”) steel. The oil tank
must hold a maximum of 30 gallons of heat transfer oil (HTO) at ambient temperature. The oil
reservoir will be surrounded by a 10 gauge (.134”) air reservoir that will be filled with hot burner
gases heating both the bottom and sides of the oil tank for best heat transfer.
3.3 Tank must be insulated on top, sides and bottom with a min. 1.5” ceramic or FBX insulation.
3.4 Full sweep vertical direct driven reversible agitator design. Agitator shaft must include auger
flighting for best mixing.
3.5 Minimum 15 x 26 inch, insulated/angled loading door will be curbside and of “splash-free” design.
3.6 For safety, material loading height will be no more than 48 inches for proper lifting ergonomics.
3.7 For safety, unit must include a vented HTO expansion tank. Sealed expansion tanks will be
considered a fatal deviation.
3.8 Diesel burner maximum of 290,000 BTU for best fuel efficiency and fastest heat-up.
3.9 Minimum 6 inch round wand recirculation port located on the rear of the machine is required.
3.10 The material tank will have a minimum capacity of 230 US gallons.
4.0 Trailer Minimum Requirements: Yes No
4.1 The melting unit will be trailer mounted and capable of being towed at safe highway speeds when
fully loaded. The frame shall include minimum flat horizontal surface steel fenders to facilitate
handling and loading of material blocks. All lighting will be LED.
4.2 The frame is to be constructed of minimum 6”x 2”x 3/16” gusseted steel tube for safety and
strength.
4.3 A 2-1/2” towing ring that is adjustable in height from 15” to 30” high will be provided.
4.4 Minimum 12 gauge flat horizontal surface steel fenders to facilitate handling and loading of material
blocks.
4.5 A swing-away weight appropriate adjustable screw jack must be provided.
4.6 To insure towing mobility in both forward and reverse directions, the melter shall have a dual torsion
axle system and be rated at a GAWR (Gross Axle Weight Rating) of 7000 lbs
4.7 Electric brakes, emergency breakaway switch, radial tires, and two 3/8” x 4 foot long safety chains
with slip hooks will be included.
4.8 Oval LED stop, tail, and turn lights will be included. Clearance lighting will also be LED. A lighted
license plate bracket will be attached to the fender.
4.9 The lighting harness will be woven loom with weather proof connectors at all lights. The trailer
harness shall use a junction box at the front to allow easy changeover to different types of towing
vehicle plugs. A seven (7) pin flat RV round plug will be included.
2601 Niagara Lane North Page 2 of 5 Toll Free: +1-877-841-0848
Plymouth, MN 55447 U.S.A. www.cimline.com Fax: +1-866-557-19715.0 Pumping and Delivery System Minimum Requirements: Yes No
5.1 A positive displacement pump will provide material flow for sealing and recirculation. The material
pump and all related plumbing must be contained within a heated chamber. External oil jacketed
pumps are not acceptable. The re-circulation will be confined safely within the interior of the
machine (Internal Machine Recirculation). Hose recirculation is not an acceptable alternative.
Submerged pumping systems are unacceptable due to their reduction of sealant working volume,
their inability to recirculate sealant and their excessive maintenance down time.
5.2 The pump shall be direct coupled, driven hydraulically and run in either direction to permit cleaning of
plumbing system.
5.3 A minimum 20 gpm is required output. Pump speed will be variable.
5.4 A maximum of 25 rpm’s is allowed to achieve maximum pump output to provide long pump life.
5.5 When sealing valve is closed, sealant must be recirculated back to machine to provide fast recovery
and heat up time.
5.6 Sealing hose will be electrically heated. For safety, only floating ground design systems will be
acceptable. Due to weight, length and flexibility considerations, Oil or DC heated hoses will not be
considered. The hose will be a minimum of 3/4” inner diameter (ID) and no less than 20 feet long.
5.7 Hose boom(s) will be located at the rear center of the heating chamber. Boom height must be high
enough as to allow a 6’ 2” operator to walk under without risk of personal injury. The boom must be
supported by heavy duty collar and oilite type maintenance free bushing.
5.8 The wand will utilize a ball valve attached at the end of the wand to eliminate dripping when valve is
shut off. Rubber tips are not an acceptable substitution. Should the wand be accidently dropped, all
flow and line pressure must cease.
5.9 A 2.5" swivel disk will be included.
6.0 Temperature and Flow Control Minimum Requirements Yes No
6.1 For sealant placement temperature quality, the material temperature will be measured outside of
the sealant tank and before the placement hose. The digital control system must be able to operate
in manual or automatic mode. Sealant flow will be digitally controlled.
6.2 The display must have adjustable digital controllers with readout for oil, material and heated hose
temperatures. Control must have intervals no greater than 1 degree F and continuously monitor
thermocouples. Controllers must be stowed in a wather tight operators box on rear curbside of
machine.
6.3 The control panel will contain (3) LED Status indicators for pump, agitator and hose. When all three
indicators are green, operator can begin to work.
6.4 Digital controllers must display an error code and shut burner down should a thermocouple failure
occur.
6.5 The control system must be able to operate in manual or automatic mode. When in “Auto”, the
system will control agitation and pump start up by temperature autmatically. Control is to be placed
on outer control box with operator selection for Run / Clean Out / Cool Down / Off
6.6 Pump forward/reverse and agitator forward/reverse will be electrically controlled from rotary switch
on the control station door panel without having to open the weather proof box. A clear cover will
allow viewing of status LED’s and digital temperature readout without opening box.
6.7 A single hydraulic manifold system shall be provided with cartridge valves, which permit
maintenance without hose removal. Pressure relief valves included for protection of motors. Nine (9)
preset positions are available to adjust sealant flow.
2601 Niagara Lane North Page 3 of 5 Toll Free: +1-877-841-0848
Plymouth, MN 55447 U.S.A. www.cimline.com Fax: +1-866-557-19716.8 Additional status LED indicators shall provide burner, pump and hose heating status.
6.9 Additional analog gauges shall be included for agitator and material pump pressure and backup
material temperature.
7.0 Engine, Burner and Hydraulics Minimum Requirements: Yes No
7.1 The unit will be equipped diesel engine with spin-on type oil and fuel filters. It will be joined to the
frame with rubber engine mounts to prevent vibration transfer. The management system will be
located near the engine for ease of operation and maintenance. A self-igniting diesel fired burner will
be included.
7.2 The unit will be equipped with a 3 cylinder direct injected, 25hp, diesel engine. The engine will have
spin-on type oil and fuel filters.
7.3 The engine will be protected by a digital engine management system including integrated hour
meter and also burner failure indicator lamp.
7.4 Auto shutdown protection will be provided for alternator, oil pressure coolant temperature.
7.5 The exhaust will exit through a noise reduced cowl muffler.
7.6 The unit will include a minimum 33 gallon diesel fuel tank. The tank will incorporate a fuel fill cap with
integrated fuel gauge. For safety, hose type sight gauges are strictly forbidden.
7.7 The system will include separate dual spin-on type fuel filters with ball valve shut offs to simplify filter
replacement and supply fuel to the burner and engine. Filters will be located near the fuel tank for
ease of maintenance.
7.8 The hydraulic system shall have a minimum 33 gallon reservoir, shall be equipped with a suction
strainer and a return filter and a sight level with integrated temperature gauge.
7.9 One 12 volt 250,000 BTU diesel burner will fire into an angled ceramic lined combustion chamber.
The burner will have a self-contained electronic spark igniter and proof of flame protection. To
minimize downtime the burner must be self-priming and be equipped with a fuel pressure gauge.
8.0 Paint and Safety Decals Minimum Requirements: Yes No
8.1 The unit shall be painted using safety green and black accents. It will be equipped with required
safety decals and signage.
9.0 Warranty Minimum Requirements: Yes No
9.1 The manufacturer shall warranty the equipment for a period of one year. Engine must be covered for
major components for a period of 2 years or 2000 hours. Bidder warranty policy must be included
with bid submittal.
10.0 Included Options: (if box is "X" items must be included) Yes No
Insulated noise reducing locking engine cover.
Agitator Stop (stops agitator when loading door opens).
Single Strobe, mounted on mast.
LED directional arrow stick, mounted with controller.
2601 Niagara Lane North Page 4 of 5 Toll Free: +1-877-841-0848
Plymouth, MN 55447 U.S.A. www.cimline.com Fax: +1-866-557-1971Tool box, mounted.
10 lb. fire extinguisher, mounted with bracket.
Operator horn, audible communication system.
Spare tire, mounted on frame.
Light weight aluminum sealing wand, 4' with heated hose in lieu of standard wand and heated hose.
11.0 Machine Upgrades: (if box is "X" items must be included) Yes No
Skid mount air compressor: The unit will be a stand alone skid mounted air compressor with
independent engine. Skid mount will fit into or onto standard truck beads and will have a boom with
pivot to swing over truck cab to front of vehicle. Will include air hose and cold air lance.
A 50 ft. self-retracting hose reel will be included.
12.0 Air Compressor Heat Lance Upgrade: (if box is "X" item must be included) Yes No
Integrated heat lance upgrade: As an upgrade to the skid mount air compressor, the unit shall include
an integrated heat lance package including the following: 50ft of 1/2" air line and 1/4" gas line. A
heat lance with regulator and a rack for a 40 lb. propane bottle.
2601 Niagara Lane North Page 5 of 5 Toll Free: +1-877-841-0848
Plymouth, MN 55447 U.S.A. www.cimline.com Fax: +1-866-557-1971Appendix B
Asphalt Crack Router
Rev 1 02/2023
1.0 PURPOSE Yes No
1.1 The crack router needs to be able to create clean cuts in an asphalt
surface and allow the operator to accurately maintain consistent cut depth
2.0 ENGINE
2.1 A heavy-duty air cleaner shall be installed on the engine.
2.2 The engine shall have a full-flow oil filter and oil cooler.
2.3 The router will be 27HP Kohler or equivalent petrol engine
3.0 FRAME
The entire assembly of the engine, cutter head, cutter head housing
and all other part assemblies shall be mounted on a heavy steel
frame, electrically welded through 100% of the metal thickness at
each joint for maximum strength and rigidity.
Must have balanced and integrated lifting points or hooks
Easy access to the router bit for replacement and maintenance
4.0 SAFETY AND TRAINING
4.1 The crack sealer must be ergonomic to use for minimum operator fatigue
4.2 The crack sealer must be equipped with dust suppression equipment
4.3 The crack sealer must be ergonomic to use for minimum operator fatigue
4.4 The crack sealer must be equipped with dust suppression equipment
4.5 Must have functions for consistent cut depth control, must be able to easily
reset to the same depth as the last cut
4.6 Must have anti-kickback equipment installed
4.7 Must have quick shutdown system
4.8 Must include one in-person training session with a factory-trained
representative at equipment’s initial start-up
4Appendix C1
Skid mount Compressor with wand & heat lance
Rev 1 02/2023
1.0 PURPOSE Yes No
1.1 The skid mount compressor is to be mounted in the rear of a ¾ ton pick up
truck that is towing the crack sealing trailer mentioned in this tender to be
used during a crack sealing operation both to clean and dry the cracks
before the application of sealant by use of a compressor wand or heat
lance
Compressor wand to be heavy duty and usable in a standing position
similar to a calihose cannon
Heat lance to be useable in a standing position and connect to a standard
30lb propane tank
5Appendix C2 VMAC Diesel Drive D60 – Bid Specifications These specifications are for bid purposes only and are provided by VMAC. All specifications are subject to change without notice. AIR COMPRESSOR, Limited Engine Run Time, 60 CFM Diesel Engine Driven Standalone Above Deck Mounted Rotary Screw with Engine Standby Mode 60 CFM and 150 PSI rotary screw air compressor system mounted above deck on a truck chassis or skid. Air compressor output will be to ASME standards. Compressor Air End: The air compressor will be an oil flooded rotary screw capable of 100% duty cycle. Compressor will provide 60 CFM and 150 PSI. A high temperature cut off sensor is integrated on the compressor unit. The compressor is equipped with a low profile integrated air inlet control. The compressor is direct driven from the engine’s fly wheel without the use of a belt. Engine: The air compressor will be powered by a 3-cylinder diesel, naturally aspirated, Tier Four Final Compliant, liquid cooled, 23.5 HP engine. The engine will include an automated glow plug control. Digital Control System: A 12 volt digital control box with LCD display will be included that will show system hours, service reminders and safety/functional messages. The control system will integrate with the diesel engine to automatically start and stop the engine in response to air usage. Adjustable settings within the control system to include delay to stand-by, air use rate, restart pressure, system pressure, auto-restart disable and system top up pressure. Compressor and engine over-temperature shutdown, failed temperature probe, fan control, high idle activation and error messages will all be controlled by the control system. The controller will also provide for unload and stand-by functions; and auto restart when engine temperature drops below set point or when battery charge drops below set point. Air / Oil Separator Tank: It will be a vertical tank, mounted within the enclosure of the compressor. Material will be of high-grade aluminum material and will include a spin-on coalescing oil separator element and a replaceable spin on 25- micron oil filter with safety bypass feature. It will contain an 8 seconds or less integral pneumatically piloted blow down valve and minimum pressure check valve. A 200 PSI pressure relief valve will be integrated into the tank. Air Receiver Tank: A secondary tank will be installed with a minimum of 5 gallons of capacity, and it will be rated to 150 PSI working pressure.
Heat Exchanger: The heat exchanger will be the air-to-liquid type with a 11“ 12 volt electric fan. The fan will cycle on/off to meet cooling demands of the compressor. Throttle Control: Throttle control will be a 2 speed control and will automatically modulate engine RPM with air demand. Package: The overall package size will be no greater than 18" (w) x 34.5"(l) x 28" (h) – with optional fuel tank adding 5” to the length. Total dry weight will not exceed 418 lb. The sheet metal enclosure will be aluminum for the base material and 12 gauge aluminum for the sides and top cover. All sheet metal is to be powder coated. Fuel Supply Options: Fuel supply may be supplied by one of two options, the truck’s fuel tank or compressor-mounted fuel tank. 1. Fuel from the truck’s fuel tank requires an optional remote 12 volt activated diesel fuel priming pump. 2. Fuel from a compressor-mounted fuel tank requires an optional 7 gallon fuel tank with low fuel sensor and fuel gauge. Optional Wheel Kit: An optional factory-installed wheel kit will include three wheels for the package including a front caster wheel with friction brake. Wheel kit will include factory installed 7 gallon fuel tank and digital display panel. Wheel kit components will be rated for temperatures between 13°F (-25°C) and 104°F (+40°C). Safety Features The air compressor system will include an LED safety light and alarm to notify the user the system is in standby mode. An alarm will be included to notify the user that the diesel engine and air compressor are about to re-start. A 200 PSI pressure relief valve will be integrated into the tank and the control system includes compressor and engine over-temperature shutdown. Installation: Installation of air compressor must be completed only by the factory authorized distributor of the air compressor manufacturer.
You can also read
