ACADIA MODELS
2023 FEATURES, SPECS AND OPTIONS
Due to current supply-chain shortages, certain features shown have limited or late availability, or are no longer available. See the window
label or a dealer regarding the features on an individual vehicle.
We have tried to make this guide comprehensive and factual. We reserve the right, however, to make changes at any time, without notice,
in prices, colors, materials, equipment, specifications, models and availability. Specifications, dimensions, measurements, ratings
and other numbers in this guide and other printed materials provided at the dealership or affixed to vehicles are approximations based
on design and engineering drawings, prototypes and laboratory tests. Your vehicle may differ due to variations in manufacture and equipment.
Since some information may have been updated since the time of publication, please check with your GMC dealer for complete details.
2 EXTERIOR
YOUR ACADIA AWAITS
DENALI
KEY FEATURES
AT4
SLE
SLT
See your GMC dealer or gmc.com for more feature details and requirements.
EXTERIOR
SLE
18" Machined Aluminum Wheels With Dark Accents ● — — —
18" Aluminum Wheels — ● — —
20" Gloss-Black Painted Aluminum Wheels ● ● — —
20" Machined Aluminum Wheels With Dark Accents — ● — —
17" Gloss-Black Painted Aluminum Wheels With All-Terrain Tires — — ● —
SLT 20" Ultra-Bright Machined Aluminum Wheels — — — ●
20" Aluminum Wheels With After Midnight Finish — — — ●
LED Headlamps and Taillamps ● ● ● ●
LED Fog Lamps — ● ● ●
Hands-Free Programmable Power Liftgate With GMC Logo Projection ● ● ● ●
Roof Rails ● ● ● ●
AT4
Heated Power-Adjustable, Manual-Folding Mirrors ● ● ● —
Heated Power-Adjustable, Power-Folding Mirrors With Driver-Side
— ● ● ●
Auto-Dimming
● Standard ● Available — Not Available
Due to current supply-chain shortages, certain features shown have limited or late availability, or are no longer available. See the window label or a dealer regarding the
DENALI features on an individual vehicle.
3 INTERIOR
YOUR ACADIA AWAITS
DENALI
KEY FEATURES
AT4
SLE
SLT
See your GMC dealer or gmc.com for more feature details and requirements.
INTERIOR
SLE
Cloth Seating ● — ● —
Perforated Leather-Appointed First- and Second-Row Seating — ● ● ●
Heated Front Seats ● ● ● —
Heated and Ventilated Front Seats — ●1 ●1 ●
Heated Second-Row Outboard Seats — ● ● ●
SLT 8-Way Power Driver Seat With 2-Way Lumbar Control ● ● ● ●
8-Way Power Passenger Seat With 2-Way Lumbar Control — ● ● ●
Heated Steering Wheel — ● ● ●
Remote Start ● ● ● ●
Universal Home Remote ● ● ● ●
6-Speaker Audio System ● — — —
AT4
Bose® Premium 8-Speaker Audio System With Subwoofer ● ● ● ●
Dual SkyScape Sunroof ● ● ● ●
● Standard ● Available — Not Available
Due to current supply-chain shortages, certain features shown have limited or late availability, or are no longer available. See the window label or a dealer regarding
the features on an individual vehicle.
DENALI Feature will not function on certain models without dealer retrofit. See dealer for details.
1
4 CAPABILI T Y
YOUR ACADIA AWAITS
DENALI
KEY FEATURES
AT4
SLE
SLT
See your GMC dealer or gmc.com for more feature details and requirements.
CAPABILITY
SLE
2.0L Turbo Engine ● ● — ●
3.6L V6 Engine — ● ● ●
Traction Select System ● ● ● ●
Hill Start Assist and Hill Descent Control — — ● —
Active Torque Control AWD System — — ● —
SLT Trailering Package ● ● ● ●
Adaptive Ride Control — — — ●1
● Standard ● Available — Not Available
AT4
Due to current supply-chain shortages, certain features shown have limited or late availability, or are no longer available. See the window label or a dealer regarding the
features on an individual vehicle.
DENALI AWD only.
1
5 SAFET Y AND TECHNOLOGY
YOUR ACADIA AWAITS
DENALI
KEY FEATURES
AT4
SLE
SLT
See your GMC dealer or gmc.com for more feature details and requirements.
SAFETY AND TECHNOLOGY
SLE
8" Diagonal GMC Infotainment System1 ● — — —
8" Diagonal GMC Infotainment System1 With Navigation2 ● ● ● ●
Lane Change Alert With Side Blind Zone Alert3 ● ● ● ●
Rear Cross Traffic Alert3 ● ● ● ●
Front and Rear Park Assist (Feature Will Not Function on Certain Models
3
● ● ● ●
Without Dealer Retrofit; See Dealer for Details)
Automatic Emergency Braking3 ● ● ● ●
SLT
Following Distance Indicator3 ● ● ● ●
Forward Collision Alert3 ● ● ● ●
Front Pedestrian Braking3 ● ● ● ●
IntelliBeam—Auto High Beams ● ● ● ●
Lane Keep Assist With Lane Departure Warning3 ● ● ● ●
Safety Alert Seat3 — ● ● ●
AT4
● Standard ● Available — Not Available
CONTINUED
Due to current supply-chain shortages, certain features shown have limited or late availability, or are no longer available. See the window label or a dealer regarding
the features on an individual vehicle.
Functionality varies by model. Full functionality requires compatible Bluetooth® and smartphone, and USB connectivity for some devices. 2Map coverage available
1
in the United States, Puerto Rico and Canada. 3Safety or driver-assistance features are no substitute for the driver’s responsibility to operate the vehicle in a safe
DENALI manner. Read the vehicle Owner’s Manual for important feature limitations and information.
6 SAFET Y AND TECHNOLOGY
YOUR ACADIA AWAITS
DENALI
KEY FEATURES
AT4
SLE
SLT
See your GMC dealer or gmc.com for more feature details and requirements.
SAFETY AND TECHNOLOGY CONTINUED
SLE
In-Vehicle Apps1 ● ● ● ●
Wi-Fi® Hotspot 2 ● ● ● ●
myGMC Mobile App3 ● ● ● ●
High Definition Surround Vision4 — ● ● ●
Adaptive Cruise Control 4 — — — ●
Rear Camera Mirror 4 — — — ●
SLT
6" Diagonal Color Head-Up Display — ● ● ●
● Standard ● Available — Not Available
AT4
Due to current supply-chain shortages, certain features shown have limited or late availability, or are no longer available. See the window label or a dealer regarding
the features on an individual vehicle.
Available on select 2017 model year and newer GM vehicles with compatible hardware. Third-party trademarks are the property of their respective third-party owners
1
and used under agreement. Requires active service plan and paid AT&T® vehicle data plan. See onstar.com for details and limitations. 2Service varies with conditions
and location. Requires active service plan and paid AT&T data plan. See onstar.com for details and limitations. 3Available on select Apple® and AndroidTM devices.
Service availability, features and functionality vary by vehicle, device and the plan you are enrolled in. Terms apply. Device data connection required. See onstar.com
for details and limitations. 4Safety or driver-assistance features are no substitute for the driver’s responsibility to operate the vehicle in a safe manner. Read the
DENALI vehicle Owner’s Manual for important feature limitations and information.7 PACK AGES
YOUR ACADIA AWAITS
SELECT PACKAGES
See your GMC dealer or gmc.com for more package details and requirements.
SLE GMC PRO SAFETY PLUS1 Automatic Emergency Braking, Front Pedestrian Braking, IntelliBeam—auto high beams, Lane Keep Assist with Lane Departure Warning,
Following Distance Indicator, Forward Collision Alert, Lane Change Alert with Side Blind Zone Alert, Rear Cross Traffic Alert and Rear Park Assist (feature will not function
on certain models without dealer retrofit; see dealer for details) (standard on SLE, SLT, AT4 and Denali)
DRIVER CONVENIENCE PACKAGE 8-way power driver-seat adjuster, driver and front-passenger heated seats, power driver lumbar control, remote start,
hands-free programmable power liftgate with GMC logo projection and 120-volt power outlet (available on SLE)
INFOTAINMENT PACKAGE 8" diagonal GMC Infotainment System2 with Navigation3 and Bose Premium 8-Speaker Audio System with subwoofer (available on SLE)
LUXURY PACKAGE Memory Package for power driver seat and outside mirrors; 8-way power front-passenger seat adjuster; outside heated power-adjustable,
power-folding, body-color mirrors with integrated turn-signal indicators and driver-side auto-dimming; power passenger lumbar control; heated and ventilated4 driver
and front-passenger seats; heated second-row outboard seats; and power-tilt and -telescopic steering column (available on SLT and AT4)
PREFERRED PACKAGE Luxury Package and heated steering wheel (available on SLT and AT4)
SLT
TECHNOLOGY PACKAGE High Definition Surround Vision1 and 6" diagonal color Head-Up Display (available on SLT and AT4)
ELEVATION EDITION 20" gloss-black painted aluminum wheels, black center caps with black GMC logo, gloss-black roof rails, black grille, black exterior accents
and Jet Black/Jet Black interior (available on SLE and SLT)
DENALI TECHNOLOGY PACKAGE High Definition Surround Vision,1 Adaptive Cruise Control,1 Enhanced Automatic Emergency Braking1 and Rear Camera Mirror 1
with Washer (available on Denali)
DENALI ULTIMATE PACKAGE Denali Technology Package, dual SkyScape power sunroof, Adaptive Ride Control (AWD only), factory-installed Class III hitch,
7-pin wiring harness, heavy-duty cooling system and Hitch Guidance with Hitch View1 (available on Denali)
BLACK DIAMOND EDITION Denali Ultimate Package and 20" aluminum wheels with After Midnight finish
AT4
Due to current supply-chain shortages, certain features shown have limited or late availability, or are no longer available. See the window label or a dealer regarding
the features on an individual vehicle.
Safety or driver-assistance features are no substitute for the driver’s responsibility to operate the vehicle in a safe manner. Read the vehicle Owner’s Manual for
1
important feature limitations and information. 2Functionality varies by model. Full functionality requires compatible Bluetooth and smartphone, and USB connectivity
for some devices. 3Map coverage available in the United States, Puerto Rico and Canada. 4Feature will not function on certain models without dealer retrofit.
DENALI See dealer for details.8 TR AILERING OVERVIEW
ACADIA TOWING
Due to current supply-chain shortages, certain features shown have limited or late availability, or are no longer available. See the window label or a dealer regarding the features on an individual vehicle.
KEY TRAILERING FEATURES KEY SPECIFICATIONS POWERTRAIN
HITCH GUIDANCE WITH HITCH VIEW1 MAXIMUM AVAILABLE TRAILERING: 4,000 LBS2 2.0L TURBO ENGINE
IS AVAILABLE
MAXIMUM AVAILABLE HORSEPOWER: 3103 3.6L V6 ENGINE IS AVAILABLE
TRACTION SELECT SYSTEM WITH
AVAILABLE TOW/HAUL MODE MAXIMUM AVAILABLE TORQUE: 271 LB-FT 3
MAXIMUM CARGO VOLUME: 79.0 CU. FT.4
MAXIMUM SEATING CAPACITY: UP TO 7
Safety or driver-assistance features are no substitute for the driver’s responsibility to operate the vehicle in a safe manner. Read the vehicle Owner’s Manual for important feature limitations and information.
1 2
Requires available 3.6L V6 engine and
Trailering Package. Maximum trailering ratings are intended for comparison purposes only. Before you buy a vehicle or use it for trailering, carefully review the trailering section of the Owner’s Manual. The trailering capacity of your specific vehicle may
vary. The weight of passengers, cargo and options or accessories may reduce the amount you can trailer. 3
Requires available 3.6L V6 engine. 4
Behind first row with rear seats folded flat. Cargo and load capacity limited by weight and distribution.9 POWERTR AIN SPECS
POWERTRAIN SPECIFICATIONS
SPECIFICATIONS
MAX GVWR MAX TRAILER WEIGHT RATING
ENGINE MODEL AXLE RATIO
(LBS)1 (LBS)2
2.0L Turbo I4 with
SLE/SLT/Denali 6,001 3.47 3,500
available Trailering Package
3.6L V6 with
SLT/AT4/Denali 6,001 3.49 4,000
available Trailering Package
ENGINE SPECIFICATIONS
BLOCK CYLINDER HEAD COMPRESSION TORQUE
ENGINE BORE & STROKE (IN./MM) VALVETRAIN FUEL DELIVERY HORSEPOWER
MATERIAL MATERIAL RATIO (LB-FT)
Dual overhead camshafts, four valves Direct Injection with
2.0L Turbo I4 3.26 x 3.63 / 83 x 92.3 Cast aluminum Cast aluminum 10.0:1 228 @ 5000 258 @ 1500-4000
per cylinder with tri-power system electronic throttle control
Cast aluminum Dual overhead camshafts, four valves
Direct Injection with
3.6L V6 3.74 x 3.37 / 95 x 85.8 with cast-in-place Cast aluminum 11.5:1 per cylinder, continuously Variable 310 @ 6600 271 @ 5000
electronic throttle control
iron bore liners Valve Timing
TRANSMISSION SPECIFICATIONS
GEAR RATIOS
TRANSMISSION TYPE FIRST SECOND THIRD FOURTH FIFTH SIXTH SEVENTH EIGHTH NINTH REVERSE FINAL DRIVE RATIO
(:1)
9T60 9-speed automatic (2.0L) 10:1 4.69 3.31 3.01 2.45 1.92 1.45 1.00 0.75 0.62 2.96 3.47
9T65 9-speed automatic (3.6L) 10:1 4.69 3.31 3.01 2.45 1.92 1.45 1.00 0.75 0.62 2.96 3.49
Maximum Gross Vehicle Weight Rating (GVWR). When properly equipped; includes weight of vehicle, passengers, cargo and equipment.
1 2
Maximum trailering ratings are intended for comparison purposes only. Before you buy a vehicle
or use it for trailering, carefully review the trailering section of the Owner’s Manual. The trailering capacity of your specific vehicle may vary. The weight of passengers, cargo and options or accessories may reduce the amount you can trailer.10 DIMENSIONS
ACADIA DIMENSIONS
66.7"
193.4"
BASE CURB WEIGHT MAX AVAILABLE TRAILERING LEG ROOM
4,155 lbs 4,000 lbs1 (FIRST/SECOND/THIRD ROW)
41.0"/39.7"/29.7"
PASSENGER CAPACITY MAX CARGO VOLUME FUEL TANK CAPACITY
Seating for up to 7 (BEHIND FIRST/SECOND/THIRD ROW) (FWD/AWD)
79.0/41.7/12.8 cu. ft.2 Approx. 19.4/21.7 gallons
MAX HEAD ROOM
(FIRST/SECOND/THIRD ROW)
40.0"/39.6"/37.2"
1
equires available 3.6L V6 engine and Trailering Package. Maximum trailering ratings are intended for comparison purposes only. Before you buy a vehicle or use it for trailering, carefully review the trailering section of the Owner’s Manual.
R
The trailering capacity of your specific vehicle may vary. The weight of passengers, cargo and options or accessories may reduce the amount you can trailer. 2With rear seats folded flat. Cargo and load capacity limited by weight and distribution.11 TR AILERING TERMINOLOGY
IMPORTANT TERMS
CURB WEIGHT CARGO WEIGHT
The weight of a vehicle with all of the standard and optional equipment The weight of all items added to the curb weight of the vehicle, including
and a full tank of fuel, but without any passengers or cargo. cargo and optional equipment. When towing, cargo weight also includes
the trailer tongue or hitch weight.
GROSS VEHICLE WEIGHT (GVW)
The combined weight of the vehicle and all passengers and cargo. MAX PAYLOAD
The maximum allowable weight of passengers plus cargo that the vehicle
is designed to carry.
GROSS VEHICLE WEIGHT RATING (GVWR)
This number is the maximum amount a tow vehicle may weigh. Everything
that contributes to the weight of the tow vehicle is featured in this rating, GROSS AXLE WEIGHT (GAW)
including the weight of the vehicle, driver and all passengers, fuel, The total weight placed on a single axle (front or rear).
payload, tongue load of the trailer, the weight of the hitch and all optional
equipment. The GVWR is displayed on the driver’s door or door-lock pillar
label of your GMC vehicle. The GVW must never exceed the GVWR. GROSS AXLE WEIGHT RATING (GAWR)
This is the weight that each axle is capable of supporting. The load on each
axle must not exceed the GAWR. The GAWR for each GMC vehicle is displayed
GROSS COMBINED WEIGHT (GCW) on the driver’s door or door-lock pillar label.
The GVW plus the loaded trailer weight.
GROSS TRAILER WEIGHT
GROSS COMBINED WEIGHT RATING (GCWR) The weight of a loaded trailer.
The total allowable weight of the completely loaded vehicle and trailer,
including any fuel, passengers, cargo, equipment and accessories.
TONGUE (OR HITCH) WEIGHT
The tongue weight is the total amount of trailer weight that is pressing
down on the trailer hitch. Keep in mind that the way a trailer is loaded
affects the overall tongue weight and will also affect the handling of the
tow vehicle when trailering.
©2022 General Motors. All rights reserved. The marks appearing here are the trademarks or service marks of GM, its subsidiaries, affiliates or licensors.You can also read
