October 2018 @qualcomm_tech VR and AR pushing connectivity limits Qualcomm Technologies, Inc.
AR and VR are revolutionary interfaces
Sharing many of the same underlying technologies
Virtual reality Augmented reality
2
VR will offer unprecedented
experiences and possibilities
Play Learn Communicate
Immersive movies Immersive education Social interactions
and shows Training and demos Shared personal
Live concerts, sports, 3D design and art moments
and other events Empathetic storytelling
Interactive gaming and
entertainment
3
AR will serve a broad spectrum of roles in daily life
Applicable across ages, genders, and activities
Children Young Families Professionals Fitness Enthusiasts
Playing Adults Exploring Communicating Working Thriving
Kids chasing virtual A young man exploring Families virtually Architects collaborating Group running
characters in more Rome and seeing brought together with on a shared design with a virtual trainer
interactive and the Colosseum as life-like communication to improve efficiency to motivate them
immersive games originally built
4
A glimpse into the future — sleek and stylish XR glasses
How do we get there?
Bone conduction transducers Multimode connectivity
(4G, 5G, etc.)
Directional speakers
Many passive and active cameras
with fisheye and telephoto lenses
Optoelectronic night vision
and thermal imaging sensors
Ambient light sensors
Tracking and recording cameras
Eye tracking cameras
Inertial, haptic,
and health sensors
New optics and projection
Multiple high sensitivity technologies within a durable,
audio microphones semitransparent display
5
AR technologies and use cases evolve from mobile
VR usage primarily comes from console/TV/PC, but it’s also moving towards AR
Ultimately,
this becomes an imperceptible
Landline
PDA device that replaces
nearly all others
Handheld
Camera
gaming AR glasses
Laptop Smartphone VR HMD
TV
Desktop PC Gaming consoles
6
We are accelerating the adoption of VR and AR
Designed to make it easy to develop premium mobile VR and AR experiences
Qualcomm® Snapdragon VR Snapdragon 845 VR
Snapdragon™ 845 SoC SDK HMD
Purpose built silicon Access to advanced VR features Accelerating the development
for superior mobile to optimize applications and of standalone head-mounted
VR & AR simplify development displays
Qualcomm Snapdragon is a product of Qualcomm Technologies, Inc. 7
Platform Software Advanced Ref Design, HMD Accelerator Devices
Algorithms SDKs &Tools Program (HAP)
Eye 3D
VR SDK KPI
tracking Audio
Foveated ODM ISV
6DoF Profiles
rendering
Scene IHV Components
Hand
Under-
tracking
standing
advantage.qualcomm.com/hap
Actively working with ecosystem innovators 8
VR and AR will push connectivity requirements
More capacity, lower cost Low latency Uniform experience
Increased throughput per user Reduces throughput requirements, buffering Full immersion everywhere requires
as quality of immersion improves, requirements, and lag for interactive content consistent throughput, even at the
and more simultaneous usage like tactile Internet and 6 DoF* cell edge
*6 DoF: Six degrees of freedom 9
VR and AR require efficient increase in wireless capacity
Constant up/download on Richer visual content
an all-day wearable • Higher resolution, higher frame rate
• Stereoscopic, High Dynamic Range (HDR), 360° spherical content, 6 DoF
2 Mbps 5 to 25 Mbps 50 to 200 Mbps
Video conferencing Two-way telepresence Next-gen 360° video (8K, 90+
FPS, HDR, stereoscopic)
Downlink /
Consume
Bandwidth
Uplink / Share
1 Mbps 2 to 20 Mbps 10 to 50 Mbps 200 to 5000 Mbps
Image and workflow 3D model and data Current-gen 360° 6 DoF video
downloading visualization video (4K) or free-viewpoint
Source: ABI Research Critical for immersive experiences10Low wireless latency is critical for immersion
The air interface is one component of the overall end-to-end latency
“Motion” Telco edge latency (down to ~1 ms)
Ultra-low latency (close to over-the-air
latency) possible with local source
Internet
Telco cloud latency (~20 - 50 ms)
“to Photon”
Lower latency sufficient for many interactive services
Public cloud latency (~50 - 100 ms)
Sufficient latency for many streaming services that tolerate buffering
(less interactive content)
Motion to Photon (MTP) latency below
15 ms generally avoids discomfort —
processed on the device1
1
1 Specific use cases, e.g. local edge content, may allow some processing to be intelligently split over the air-interface 11 1A uniform experience is paramount for AR and VR
Lag, stutter, and stalls are unacceptable for user experience and comfort
Visuals
Consistent quality, e.g. latency
• No disruptions from buffering Sounds
• No reduction in quality from fluctuating bitrates
Anywhere usage
• From cities to rural area
• Reliable service even in challenging
environments or the cell edge
Interactions
High mobility
• Fast moving situations, like cars
• Constant head movement
Immersion must be
maintained at all times
12Our vision for 5G is a unifying connectivity fabric
Delivering always-available, secure cloud access
Enhanced mobile Mission-critical Massive Internet
broadband services of Things
Unifying connectivity platform for future innovation
Convergence of spectrum types / bands, diverse services, and deployments,
with new technologies to enable a robust, future-proof 5G platform
135G enhanced Above 6 GHz
mobile broadband
Below 6 GHz
Gigabit 5G
LTE NR
is required to take VR / AR Below 6 GHz
experiences to the next level
Extreme throughput — with Multi-Gbps
Ultra-low latency — down to 1 ms
Uniform experience — even at cell edge
Ubiquitous coverage with Wi-Fi and
Gigabit Gigabit LTE, the anchor of the 5G
LTE
broadband experience
14Automotive video streaming Crowded event sharing
High uniformity Extreme capacity
5GEssential for
next-gen AR / VR
experiences
6 DoF immersive content Remote control / Tactile Internet
High throughput, low latency Low latency
15Automotive video streaming
100 Mbps
User cell edge rate
with mobility
Uniform experience
Cars are becoming increasingly Coverage: Excellent user experience Capacity: ~700 Mbps per cell with 1%
autonomous and efficiently shared anywhere, even at cell edge while moving penetration (for 8-lane freeway example)
16Live streaming
Social sharing at crowded venues #9 Mitchell
Receptions: 12
122 yds
TD: 2
15,356 viewers
10,345 likes
12.5Tbps / km2
upload capacity
17uplink)
Assumptions: 1: 50,000 fans are simultaneously streaming in a 0.1 km2 stadium, 2: Each video is 4K 360° video @ 25 Mbps. Minimum 50 Mbps uplink is one of the IMT-2020 requirements, along with 10 Tbps/km2 downlink area density (example for6 DoF content
*
Next-gen video for more
immersive experiences
(move freely around)
Requirements
18Remote control
and tactile Internet
Reduced latency for better
interactivity and expanded
use cases
End-to-end latency requirements
195G NR massive MIMO brings a more uniform experience
With higher capacity and better coverage; also enables higher bands, e.g., 4 GHz
Exploit 3D beamforming with Median user Cell edge user
up to 256 antenna elements perceived throughput perceived throughput
195 Mbps
3.8x
200m inter-site distance
48dBm transmit power
79 Mbps
52 Mbps 2.9x
27 Mbps
4x4 MIMO 5G NR 4x4 MIMO 5G NR
Massive MIMO Massive MIMO
Assumptions: carrier frequency 4GHz; total bandwidth: 200MHz; base station: 256 antenna elements (x-pol), 48dBm Tx power over 200MHz; UE: 4 Tx/Rx antenna elements, 23dBm max. Tx power; full buffer traffic model, 80%
indoor and 20% outdoor UEs 205G NR mmWave is capable of delivering massive capacity
Exploiting higher bands and more flexible use of available bandwidth
1 GHz
6 GHz
High-bands
100 GHz
Large bandwidth Flexible capacity Small cell densification
Leveraging higher spectrum bands Adapting to network traffic needs with Enabling easy / low-cost
(e.g., at 28 GHz) previously not dynamic UL / DL switching, enabled deployment of small cells with
available to LTE by new self-contained TDD design integrated access and backhaul
Simultaneous connectivity with spectrum bands below 6GHz (Gigabit LTE or 5G NR)
ensures a seamless, ubiquitous user experience 215G NR scalable over-the-air latency down to 1 ms
Enhancing VR / AR user experience and enabling new use cases
Shorter transmission time interval (TTI)
5G NR scalable TTI
E2E Down to just two symbols for ultra-low latency control
Reduced round-trip time (RTT)
Ultra-low latency TTI
for real-time FDD Data 0 1 0 1
control and Fewer HARQ1
feedback interlaces
ACK ACK0 ACK1 ACK0
HARQ RTT
Scalable TTI
TDD Ctrl Data ACK DL
Guard
period
(Tx) (Tx) (Rx) example
Low latency beneficial for 6 DoF Self-contained
subframe design 2
to reduce amount of data Data and acknowledgement in the same subframe
1. Compared to LTE’s eight HARQ interlaces; 2. Retransmission may occur immediately in the next TDD subframe 22Making 5G
