Technical Information Package - Managed By: Leon's Centre
Technical
  Information
    Package

Managed By:
Technical Information Package - Managed By: Leon's Centre
Table of Conents

3. Leon’s Centre Overview/            16. Lighting
   Management                             Assisted Hearing
                                          Communications
4. Management Directory
                                      17. Power/Electrical
5. Hours of Operation
                                      18. Pyrotechnics/Special Effects
6. Location of Arena
   Directions to Arena                19. Rigging Specification
                                          Score Clock Information
9. Arena Seating Information
                                      20. Dressing Rooms/Change Rooms
10. Configuration Maps/Layouts
                                      21. Venue Map
11. Portable Seating/Staging
                                      22. Marketing/Advertising
12. Theatre Curtains                         Information
    Loading Docks
    Crowd Control

13. Elevators/Parking

14. On-Site Equipment
Technical Information Package - Managed By: Leon's Centre
Welcome to the Leon’s Centre

Thank you for allowing us to introduce you to the
Leon’s Centre, the home of the Kingston Frontenac’s
and centre for sports and entertainment, situated in
the heart of downtown Kingston, Ontario, Canada.
We hope the enclosed information addresses any
question that you may have about our facility. The
policies outlined herein are designed to provide event
planners/promoters with the details for efficient utili-
zation of the Leon’s Centre in order to create the best
event experience.

Management

ASM Global was formed in October 2019 from the
merge of AEG Facilities, the global innovator in live
entertainment venues and SMG, the gold standard in
event management. ASM Global manages the Le-
on’s Centre on behalf of the City of Kingston. ASM
Global provides management and consulting ser-
vices for arenas, stadiums and convention centres
worldwide. ASM Global also manages the Meridian
Centre in St. Catharines, the Canalta Centre in Medi-
cine Hat AB and the Avenir Centre in Moncton NB!
Technical Information Package - Managed By: Leon's Centre
Leon’s Centre

                            Management Directory

Name                 Title                 Phone          Email
Lynn Carlotto        General Manager       613-650-5079   lcarlotto@leonscen-
                                                          tre.com

Brittany Durham      Director, Finance     613-650-5066   bdurham@leonscen-
                                                          tre.com

Brandon Tattersall   Director, Events &    613-650-5065   btattersall@leonscen-
                     Marketing                            tre.com

Catherine            Manager, Events       613-650-5035   cdonegan@leonscen-
Donegan                                                   tre.com

Rob Moeys            Manager, Operations   613-483-9969   rmoeys@leonscentre.
                                                          com

Sean Ganley          Director, Food & Bev- 613-650-5083   sganley@leonscen-
                     erage                                tre.com

Erica Vallier         Manager, Ticketing   613-650-5067   evallier@leonscentre.
                                                          com

Christine Luney      Manager, Marketing    613-650-5036   cluney@leonscentre.
                                                          com
Technical Information Package - Managed By: Leon's Centre
Hours of Operation

                            Leon’s Centre Box Office

Located at Gate #4                           Winter Hours (Labour Day – April 30th)
Summer Hours (May 1st - Labour Day)          Monday to Friday - 9:00 am to 6:00 pm Sat-
Monday to Friday - 9:00 am to 6:00 pm Sat-   urday - 11:00am to 2:00 pm
urday - Sunday – Closed

Mailing Address:

Leon’s Centre

Tel Number: 613-650-5000

1 The Tragically Hip Way

Kingston, ON K7K 0B4

Fax Number: 613-650-5001
Technical Information Package - Managed By: Leon's Centre
Location

The Leon’s Centre is located at 1 The Trag-
ically Hip Way in Kingston, Ontario. It is ap-
proximately 2.5 hours east of Toronto and 2
hours south west of Ottawa. The arena is eas-
ily accessed from Highway 401.
Technical Information Package - Managed By: Leon's Centre
Directions to the arena

      From the West                                      From the East

Highway 401 East to Kingston.               Highway 401 West to Kingston.
Take the Montreal Street exit and head      Take exit 623 (Hwy 15 south) to Hwy 2 -
west toward the city centre. Turn left      Turn right.
onto Queen Street, and left again onto      Go through the lights at the bottom of the
King Street.                                hill and over the lift bridge. After you cross
Cross the Tragically Hip Way and the        the bridge stay to the right, this will take you
entrance to the loading dock will be on     onto Place
the right, on the corner of King Street     D’Armes. Entrance to the loading dock is on
and Place d’Armes.
                                            the left, on the corner of Place D’Armes and
                                            King Street.
OR

Take the Sir John A. MacDonald Blvd
exit and head south.
Turn left onto Princess Street, and left
again onto Concession Street. Turn
right on Division Street and then left on
Queen Street.
Turn left on to King Street and follow
until you arrive.
Technical Information Package - Managed By: Leon's Centre
Directions to the arena                              Driving Time
                                                  from Other Cities

From the South:

                                           City            Driving Time
Take Hwy 81 North to 1000 Islands          Toronto         2.5 Hours
Bridge.
Follow directions to Highway 401           Oshawa          2.0 Hours
West to Kingston/Toronto. Take exit
623 (Hwy 15 south) to Hwy 2 - Turn
right.                                     Ottawa          2.0 Hours
Go through the lights at the bottom of
the hill and over the lift bridge. After   Montreal        3.0 Hours
you cross the bridge stay to the right,
this will take you onto Place
D’Armes. Entrance to the loading           Syracuse        2.5 Hours
dock is on the left, on the corner of
Place D’Armes and King Street.
Technical Information Package - Managed By: Leon's Centre
Arena Seating Information:

Seating Capacity: See Diagrams   Note:
                                 Seat count may vary with indi-
Quarter House: 1,900
                                 vidual event set up
Half House: 2,950
                                 Floor Size:
Three-Quarter House: 4,100       The 17,000 square foot floor
                                 portion of the arena is a stan-
End Stage 180: 5,100
                                 dard NHL hockey rink 200ft.
End Stage 270: 5,600             X85ft; the 43in. high dasher
                                 boards can be removed com-
End Stage 360: 6,050
                                 pletely in the west end of the
Max Capacity: 6,390              arena floor

                                 Fire Isles:
                                 6 ft. minimum on concourse,
                                 4ft. minimum on the floor
Technical Information Package - Managed By: Leon's Centre
Configuration Maps
Below are a few standard layouts with capacities. These represent normal sight-
     lines and conditions which may be impacted by show specific needs.

                         Full Venue 360º (6395)

     Full Mode (5061 Cap)                      ¾ Mode (3911 cap)

  Theatre Mode (2952 Cap)                      ¼ Mode (2021 Cap)
Portable Seating:

1,700 Clarin, black, padded, cloth
upholstered folding chairs are avail-
able.

Staging:

The Leon’s Centre is fully equipped with a rolling, StageRight stage. Our stage can vary in
height at any dimension between 4 ft. to 5 ft. We have (101) 4 ft. x 8 ft. stage decks. We
also have one ADA compliant handicap ramp and 3 portable stairs, 3 ft. wide, capable of
clamping to a stage, all from StageRight as well.
Upstage Theatre Curtain:                   Loading Docks:

Curtain has 4 static locations. Curtain    Two loading docks are located at the
is comprised of 8 panels and extends       northwest corner of the Leon’s Centre,
from concourse wall to concourse wall.     approximately 150 ft. from the centre
Please review map on p.10 for static lo-   floor. Each dock can service a 54 ft.
cations. Please bear to mind that venue    transport truck and has a ramp that is
does not have black seating masking for    adjustable to accommodate smaller
killed sections.                           trucks and alternate vehicles. The push
                                           to the centre of the arena floor is ap-
                                           proximately 120 ft. A third loading bay is
Crowd Control:
                                           located on the west end of the building,
                                           directly off of King Street, and may be
We have 84 ft. of blow-thru stage barri-
                                           used to load in/out pending an approved
cade, 300 ft. of bike rack barricade and
                                           road closure from the City of Kingston.
200 ft. of Modu-Lok fencing with black
                                           The push to the centre of the arena floor
skrim.
                                           from this bay is approximately 110 ft.
                                           and a forklift is required to off load equip-
                                           ment from trucks at street level.
Elevators:

The building is equipped with four passen-
ger elevators located on each corner of
the building. The elevator in the northwest
corner has direct access to back of house
and is adjacent to the loading dock area

Parking:

There is adequate parking for (3) three tour
buses or (2) two transport truck outside
the loading dock on the north side of the
building. In addition, King Street, between
Barrack and Place D’Armes may be closed
upon request to accommodate additional
show vehicles pending advance approv-
al from the City of Kingston. There is a
$335.70 fee to close King Street for park-
ing purposes for the day. If further parking
is required, please advise event manager
a minimum of 2 weeks prior to arrival to
make special arrangements. Please refer
to venue parking map on p. 10. There is
no parking in fire lane. Warning - Idling is
not prohibited around our building at any
time.
Forklift:

The arena has one propane powered forklift with 6ft. extensions. Its maximum load
capacity is 5000 lbs., and its maximum working height is 14 ft. Additional forklift rent-
als can be added, please request from the event manager minimum of 2 weeks prior to
make arrangement for a fee.

Scissor Lift:

The arena has a JLG 35 ft. high scissor lift, which can reach the top of the video boards
on the score clock. Please note that our low steel is 45 ft. and our scissor lift will not
reach.
Ice Resurfacing:

The area has (1) one propane powered Zam-
boni model 525 and (1) one propane pow-
ered Zamboni model 520, and one electric
powered Zamboni Power edger.

HVAC:

The Leon’s Centre has a state of the art
HVAC system that creates a comfortable
environment for fans and performers in all
weather conditions. Any specific temperature
requirement should be brought to the atten-
tion of the event manager.
House Lights

House Lighting:

House lights are controlled via the Com-
mand Centre within the building. Com-
munication is required via radio or Clear
Com to establish lighting. Bowl lighting
is LED and dimmable. Lights are all
pre-programmed with basic scenic ele-
ments.
Spot Lights:

The Leon’s Centre has (4) four Lycian 3K Followspots in static locations at the east end
of the bowl.

Assisted Listening Devices:

Venue comes equipped with portable assisted listening devices. Please note that show
is accountable for tying into house system, if required.

House Clear-Com:

The Leon’s Centre has an in-house Clear-Com communication system with stations in
the spotlight locations on the catwalk, the Zamboni vomitory at the west end of the are-
na, the AV room located on the 4th floor and at the penalty box, located at centre ice on
the arena floor. Venue is equipped with 6 (six) Belt packs and 6 (six) headsets.
Electrical Power:

Primary event power is located back of house, on the west end of the building, north of
the Zamboni vomitory.
We have (3) 400 amp services and (1) 200 amp service available.

Please Note:

•    You must supply your own cables for tie-in.
•    Distribution Panels and feeder cables can be rented for tradeshows
•    Electrician is required to be onsite for load in, show call and load out

Shore Power:

We have (2) 60 amp services available for shore power, located on the north side of the
building (Place D’ Armes). In addition, we have (5) 40 amp services available for shore
power located on the west end of the building just inside the loading bay door. These 40
amp services pull from our main show power supply. Note that an electrician must be
onsite to connect Shore Power on King Street access.
Pyrotechnics/Special Effects:

Leon’s Centre requires advanced notification of all special effects/pyrotechnics. At least
one month prior to your event please forward necessary approvals and permits to the
Event Manager.
This is in accordance with the by-laws and regulations of the City of Kingston Fire Pre-
vention office and the Province of Ontario.

City of Kingston Fire Prevention Office contact information:
Fire Prevention Bureau
500 O’Connor Drive
Kingston, ON K7P1N3
Phone (613)548-4001
www.cityofkingston.ca
Rigging Information:

Distance from centre floor to the roof high steel is
58 ft. Distance from floor to the low steel is 45 ft.
Total rigging weight for an end stage and centre
stage configuration is 90,000 lbs. Rigging weight
for a theatre configuration is 65,000 lbs.
All structural steel is divided into 10 ft. x 10 ft.
bays.
Leon’s Centre rigging plans are available from the
venue upon request. Please pay special attention
to Crow’s Nests and Score Clock when rigging.

Score Clock Information:

The structure’s overall size is 15 ft. in diameter at
the top, 12 ft. in diameter at the bottom, and 13 ft.
high and weighs approximately 6,500 lbs and is
situation at center ice. The Daktronics scoreboard
section is 10 ft. x 2.5 ft. on each. The Daktronics
video screen is 15 ft. wide x 6.5 ft. high. An 18
inch high circular advertising panel encompass-
es the bottom of the structure. While a 14 inch
square advertising panel encompasses the top. A
Jaemar winch with braking devices and a double
drum system is used for raising and lowering. The
video board can be raised to the point where it is
fully recessed into the low steel.
Dressing Rooms:

The Leon’s Centre has the following furniture for dressing rooms:
•   Cloth covered arm chairs
•   Small couches
•   Coffee tables
•   6 ft. tables
•   Floor lamps
•   Coat racks
•   Wardrobe racks
•   Carpets
•   End tables

The entire building has a secured wireless internet connection. The password
will be made available to you upon your arrival.

Room Name / #     Size          Bathroom      Shower        Electrical Outlets   Phone/Internet

                                                                                 Access
Dressing Room 1   364 Sq. Ft.   Yes           Yes           2                    Yes
Dressing Room 2   308 Sq. Ft.   Yes           Yes           2                    Yes
Dressing Room 3   364 Sq. Ft.   Yes           Yes           2                    Yes
Dressing Room 4   364 Sq. Ft.   Yes           Yes           2                    Yes
Dressing Room 5   66 Sq. Ft.    Yes/Private   Yes/Private   2                    Yes
Dressing Room 6   68 Sq. Ft.    Yes/Private   Yes/Private   2                    Yes
First Aid Room    85 Sq. Ft.    No            No            1                    Yes
Green Room        350 Sq. Ft.   Yes/Private   No            4                    Yes
Marketing Your Event at the Leon’s Centre

Thank you for choosing the Leon’s Centre in Kingston, Ontario to host your next
event. As a full service in house marketing department we are available to assist
you in the marketing and promotion of your event at a local, regional and interna-
tional level.

Our services include:                           For assistance with all marketing,
                                                media buys, group sales please
•     Media Planning                            contact:
•     Media Buying
•     Promotional Planning & Execution          Christine Luney

•     Public Relation Campaign Creation         Marketing Manager

•     Group Sales                               cluney@leonscentre.com

•     And more…                                 613-650-5036
Venue Specific
             Advertising Inclusons

Here are some helpful hints when arranging your
marketing buys and developing your creative:

VENUE LOCATION
Leon’s Centre
1 The Tragically Hip Way Kingston, ON
K7K0B4

TICKET PURCHASE INFORMATION
Customers can purchase tickets online at www.leon-
scentre.com
Toll-free by phone 1-855-985-5000
At the Box Office, Gate 4 @ 1 The Tragically Hip
Way, Kingston, ON

Box Office Hours are: Monday – Friday (9 AM – 6
PM) Saturday – (11 AM – 2 PM) (Labour Day – May
1st only) Sunday – Closed

For all events the box office will be open TWO
hours prior to doors.

Ticketmaster is our official ticketing service provider.
Also remember to use the dash in the website ad-
dress to avoid any confusion
Venue Logo:

Here is our venue logo for use in all of your
marketing collateral.

Source files, as well as versions available for use on black backgrounds,
or alternative spaces are available on request.

If logo is not used, the word mark is: Leon’s Centre
Leon’s Centre Sponsors

Venue Naming Rights Sonsor:
Leon’s Furniture Kingston

Pouring Rights – Soft Drinks:

Coca Cola- Soft Drink
Contact: Geoff Fleming – 905-269-2607
gfleming@coca-cola.com

Pouring Rights – Beer

Molson Coors Ltd
Contact: Chad MacDonald – 613-217-
4200 Chad.MacDonald@molsoncoors.
com
Kingston Media Contacts

Radio:

Rogers Broadcasting

•K-ROCK 105 - Today’s Hits and Killer Classics (#1 Rock Sta-
tion in the marketplace)

•Country 93.5 – Country (#1 Country Station in the market-
place)

•Kiss 102.7 – Hot AC,Top 40

Contact: Geoff Falcon T: 613-507-8550
E.Geoff.Falcon@rci.rogers.com

Bell Media

•    98.3 Fly-FM – Hot AC, Top 40

•    98.9 The Drive - Alternative

•    103.7 Bob-FM – 80’s, 90’s

Contact: Anne Skrynsky T: 613-541-4148
E.Anne.Skrynsky@bellmedia.ca
Radio:

CORUS Entertainment

•    BIG FM – Classic Rock

•    Fresh FM 104.3 - AC, Current hits

Contact: Adam Bergeron T. 613 544-2345 ext.342
M.613 888-6886
Adam.Bergeron@corusent.com

The Kingston Whig-Standard (Post Media)

Daily Circulation, Monday to Saturday All other regional Sun
Media papers – Belleville, Brockville, Napanee, Picton.

Contact: Aleisha Proudfoot
Post Media (Contact for all local dailies and weeklies through-
out our region)
T. 613 544-5000 ext. 547193
aproudfoot@postmedia.com
Television:

Global Kingston – strong local news support

Contact: Adam Bergeron T. 613 544-2345 ext.342
M.613 888-6886
Adam.Bergeron@corusent.com

CTV & CTV2 Ottawa - Television Inc.

(local television, Kingston, Brockville, Cornwall, Ottawa)

Contact: Dave Chapin
T. 613-562-6673 M.613-290-2564
Dave.Chapin@bellmedia.ca
Regional Media Contacts:

Belleville                                 Community Broadcasters LLC

CIGL - Mix97 (Hot AC), CJTN Rock 107       ESPN 1400Am – for sporting events
(Classic Rock), CJBQ (Country)             The Border 106.7 – contemporary music
                                           (demo – 18-49 yrs)
Contact: Cassandra Bonn
T. (613) 969-5555                          Contact: Jim Leven
M. (613) 827-2250                          T.315-782-1240
cassandrabonn@mix97.com                    E: jim_leven@commbroadcasters.com

Starboard Communications

Cool 100.1 (Country), Hits 95.5 (Classic
Hits)

Contact: Marnie Babbs                      Stephens Media Group
T: 613-966-0955 ext. 233
E: marnieb@955hitsfm.ca                     (Watertown, NY) - FROGGY 97 (Coun-
                                           try), Z93 (Classic Hits)

                                           Contact: Mark Foster
                                           T: (315) 788-0790, Ext: 103
                                           E: mark.foster@smgny.com
You can also read
