STORM TIDE EVACUATION GUIDE - TOWNSVILLE
TOWNSVILLE
         STORM TIDE
   EVACUATION GUIDE
                                         This guide is used to inform residents of predicted
                                      storm tide flooding associated with a tropical cyclone
The Storm Tide Evacuation Guide has been made possible through funding provided under the Community Development and Recovery Package,
        which is a joint initiative of the Australian and Queensland Governments under the Natural Disaster Relief and Recovery Arrangements.

                                                           1
STORM TIDE EVACUATION GUIDE - TOWNSVILLE
MESSAGE FROM THE MAYOR
North Queensland is one of the most cyclone-prone areas in              If you are told you have to evacuate, you should make your way
Australia. Like many of our neighbouring coastal communities,           to family or friends in ‘higher places’ outside the threatened
natural disasters are a price Townsville residents pay for living       zone. Townsville’s Local Disaster Management Group has
in paradise.                                                            cyclone shelters available for community members who have no
                                                                        other alternative. Remember that these shelters are intended for
Along the coast, storm tides can occur as a result of a cyclone.
                                                                        use only when all other plans have failed. Shelters unfortunately
Cyclone threats in our region could result in an evacuation of
                                                                        do not have the capacity to cater for people with special needs;
particular areas in our city. We will only order an evacuation if
                                                                        and there is also no support services such as bedding, food,
a storm tide threatens to inundate developed areas.
                                                                        drink or material aid.
This Storm Tide Evacuation Guide is to help you, as a resident,
                                                                        I urge you to read the information provided in this booklet
prepare for cyclone events that result in an evacuation. If you
                                                                        and understand the evacuation procedures. In the event of a
are not required to evacuate, your home is often the safest
                                                                        cyclone or storm tide, take immediate action by following the
place for you. Before a cyclone event you will need to make
                                                                        checklists included in this booklet.
sure that you are secure in your home. If you feel you are not
secure in your home please make alternative arrangements
with friends and family.

                                                                    2
STORM TIDE EVACUATION GUIDE - TOWNSVILLE
WHAT IS A STORM TIDE?
A storm tide is a rise above the normal water level along a shore that is the result of a tropical cyclone.
When a cyclone forms over open waters the strong winds pushing the water, combined with the low atmospheric pressure in
the eye of the cyclone cause the level of the sea to rise, which results in the formation of large waves.
If this happens away from land, the water can escape and move freely away from the building storm. As the cyclone moves
towards land and the depth of the water becomes shallower, the ever-increasing wall of water does not have a chance to flow
away. These large waves may inundate land and cause destructive damage to anything in its path.
Please note that inundation by storm tide is not comparable with riverine flooding. Storm tides will be accompanied by gale
force winds, with successive waves of seawater rapidly moving across the foreshore. Trees, building material and other debris
may be carried along by the storm tide. Any evacuation must occur prior to the storm tide event.
A storm tide event should not be confused with a tsunami. A tsunami is a series of waves generated by a sudden upward
movement of the ocean floor, normally due to earthquakes and is NOT related to a cyclonic event.

                                HIGH TIDE
                      MEAN SEA LEVEL
                                 LOW TIDE

                                              NORMAL HIGH TIDE

                                                                                                       Storm Tide

                                                                                                       Storm
                                                                                                       Surge
                                HIGH TIDE
                                                                                      Normal High Tide
                      MEAN SEA LEVEL
                                 LOW TIDE

                                              STORM TIDE
                                    Storm Surge + Normal Tide = Storm Tide

                                                                 3
STORM TIDE EVACUATION GUIDE - TOWNSVILLE
WHAT IS A CYCLONE?
A tropical cyclone is a violent collection of whirling winds and dense cloud mass. Winds spiral clockwise around a central eye of
exceptionally low pressure. With winds reaching speeds in excess of 200km/h, cyclones can be extremely dangerous.

WHAT ARE CYCLONE CATEGORIES?
The severity of a tropical cyclone is measured by a category determine by the Bureau of Meteorology.
Cyclone categories range from 1 for weaker cyclones to 5 for the most severe cyclones. This helps the community assess the
severity of the cyclone and take appropriate actions.
The category of a cyclone refers to the severity of winds in a maximum wind zone. You may not experience the effects of the
maximum winds. Damage experienced may vary according to location factors.
The category of a cyclone does not refer to an associated storm tide. Warnings for a storm tide will be issued separately by the
Bureau of Meteorology (BOM).

CYCLONE WATCH
A cyclone watch is issued at six hourly intervals if a cyclone or potential cyclone exists, and there is a likelihood gale force winds
or stronger will affect coastal or island communities within the next 24 to 48 hours.

CYCLONE WARNING
A cyclone warning is issued at three hourly intervals if gale force winds or stronger are expected to affect coastal or island
communities within the next 24 hours. Warnings are updated every hour when a cyclone is close to landfall. The Standard
Emergency Warning Signal (SEWS) may be used with some cyclone warnings.

SEVERE WEATHER WARNING
A severe weather warning may be issued if the system is no longer a cyclone but communities are still being threatened by
damaging winds, flooding rains or pounding seas.

        CATEGORY             STRONGEST GUST (km/h)                                      TYPICAL EFFECTS

                            Less than 125 km/h             Minimal house damage. Damage to some crops, trees and caravans.
 1 Tropical Cyclone
                            Gales                          Boats may drag moorings.

                            125 - 164 km/h                 Minor house damage. Significant damage to signs, trees and caravans. Heavy
 2 Tropical Cyclone
                            Destructive Winds              damage to some crops. Risk of power failure. Small boats may break moorings.

 3 Severe                   165 - 224 km/h                 Some roof and structural damage. Some caravans destroyed. Power failure
 Tropical Cyclone           Very destructive winds         likely.

 4 Severe                   225 - 279 km/h                 Significant roofing and structural damage. Many caravans destroyed and
 Tropical Cyclone           Very destructive winds         blown away. Dangerous airborne debris. Widespread power failures.

 5 Severe                   More than 280 km/h
                                                           Extremely dangerous with widespread destruction
 Tropical Cyclone           Extremely destructive winds

                                                                  4
STORM TIDE EVACUATION GUIDE - TOWNSVILLE
WHAT IF I AM IN AN EVACUATION ZONE?
If your property is located in an evacuation zone, you need to read this booklet. This important booklet also includes coloured
labels. Council suggests that you place one coloured label in your meter box and one under your kitchen sink. It is important to
understand what you need to do in the event of a storm tide.
Identify where your residence is located on the evacuation map and familiarise yourself with your evacuation zone and routes.
If you are in a red, orange, yellow or blue zone, there is a chance that your property may be inundated in a storm tide event. The
height of the predicted storm tide during the disaster event will determine which zones are affected.
If you are not located in a coloured zone, you are outside the storm tide inundation threat area.

HOW TO READ AND THE USE THE STORM TIDE EVACUATION MAPS
1. Identify where your residence is on the map.
2. If you are in one of the coloured zones, you may be at risk from storm tide flooding during cyclones.
3. 	Identify your evacuation route to your pre-determined safer location. For further information on evacuation visit council’s
     website www.townsville.qld.gov.au.
4. During a cyclone event tune into warnings, authorities will advise which zones need to evacuate.

EVACUATION ZONES
 RED EVACUATION ZONE - INDICATES AREAS AT HIGHEST RISK OF FLOODING FROM CYCLONE STORM TIDE.
 ORANGE EVACUATION ZONE - INDICATES AREAS AT HIGH RISK OF FLOODING FROM CYCLONE STORM TIDE.
 YELLOW EVACUATION ZONE - INDICATES AREAS AT MODERATE RISK OF FLOODING FROM CYCLONE STORM TIDE.
 BLUE EVACUATION ZONE - INDICATES AREAS AT LOW RISK OF FLOODING FROM CYCLONE STORM TIDE.

WHAT DO STORM TIDE EVACUATION ZONES MEAN?
Residents in the Red Zone face the highest risk of inundation from a cyclone storm tide. The Red Zone includes low-lying coastal
areas and areas that may experience storm tide inundation up to approximately 1 metre above HAT.
Residents in the Orange Zone face a high risk of inundation from a cyclone storm tide. The Orange Zone may experience storm
tide inundation up to 1m above the top of the red zone (approximately 2 metres above HAT).
Residents in the Yellow Zone face a moderate risk of inundation from a cyclone storm tide. The Yellow Zone may experience
storm tide inundation at levels up to 2m above the top of the orange zone (approximately 2 to 4 metres above HAT).
Residents in the Blue Zone face a low risk of inundation from a cyclone storm tide. The Blue Zone may experience storm tide
inundation up to 2m above the top of the yellow zone (higher than approximately 4 metres above HAT).

WHAT IS HAT?
HAT stands for Highest Astronomical Tide. A HAT is comparable to a king tide. It is the highest level of water which can be
predicted to occur under any combination of astronomical conditions. BOM advices regarding storm tide will refer to a height
(in metres) above HAT. Council will use this BOM information to advise which zones may be affected.

WHAT IS AN EVACUATION SHELTER?
An evacuation shelter is a building, or part of a building, specifically designed and constructed to provide protection from wind
and debris during the passage of a severe tropical cyclone.
Evacuation shelters are a safe place that will allow for seating and may not necessarily be capable of accommodating persons
for extended periods.
Where possible, evacuees should be encouraged to seek shelter with family and friends in higher places outside the at risk area.
If you are self evacuating and not be staying within a public shelter building, please register your location via the National
Registration and Inquiry System available on the Australian Red Cross website (N.B. this will be activated at the time of the pending
disaster).

                                                                 5
STORM TIDE EVACUATION GUIDE - TOWNSVILLE
EMERGENCY CONTACT DETAILS
All Life Threatening/Urgent Emergency Calls                                                      000

Townsville Local Disaster Management Group - Coordination Centre                    1800 738 541

Townsville State Emergency Service (SES) - Tarping/Branches Down                           13 25 00

Police Link (Non life-threatening calls)                                                   13 14 44

Ambulance (Non life-threatening calls)                                                     13 12 33

Fire Brigade (Non life-threatening calls)                                            07 4771 2111

Townsville City Council - Emergency After Hours                                     1300 878 001

Ergon Energy - Loss of Supply and Emergencies                                              13 22 96

Origin Energy Natural Gas and LP Gas Emergencies - Leaks only                       1800 808 526

RACQ - Road Reports                                                                 1300 130 595

Telstra - Faults                                                                           13 22 03

Townsville Hospital                                                                  07 4796 1111

PREPARING YOUR HOUSEHOLD FOR AN EVACUATION EVENT
CHECKLIST FOR EVACUATION
   Are you in an evacuation (coloured) zone?
   Is the zone you are in currently under threat?
   Has official advice been given to evacuate?
   Do you know where you will be evacuating to?
   Is your evacuation point further inland, on higher ground and secure?
   Do you know the preferred route for evacuation?
   Is your vehicle full of fuel?
   If your not staying in a local public shelter, have you registered your location on the national registration and enquiry system?
   Have you included your Emergency Kit and a copy of your Emergency Plan?
   Do you have essential medications for your family?

PREPARING YOUR HOUSEHOLD FOR A DISASTER EVENT
CHECKLIST FOR A DISASTER EVENT
   Have you packed important documents and valuables?
   Have you turned off all the power, gas and water mains to your home?
   Are your pets safe and secure?
   Have you secured and locked your home?
   Have you packed emergency water supplies?
   Have you checked on neighbours who are elderly or disabled?
   I
     f you have completed the items above, then ensure you have your Emergency Kit and Evacuation Kit and commence your
    Evacuation Plan.

                                                                 6
ITEMS TO PACK IN YOUR EMERGENCY KIT
WATER
 Water in plastic containers
 A three day supply; minimum five litres of water per day per person
 Esky

FOOD
   Minimum three day supply
   Cooking facilities such as gas BBQ/camping stove
   Ready to eat canned meats, fruit and vegetables
   Canned juices, milk and soups
   Staples such as sugar, pepper, salt and high energy foods such as peanut butter, honey, jams, biscuits and muesli bars

VITAMINS
 Food for babies, children, elderly persons or any special dietary requirements
 Comfort foods such as biscuits, lollies, cereals, coffee and tea

TOOLS AND SUPPLIES
   Plates, bowls, cups, utensils (paper or plastic plates don’t require washing)
   Battery operated radio and spare batteries
   Battery operated/solar powered/wind up torches (and spare batteries if battery operated)
   Cash
   Utility knife
   Toilet paper
   Soap/detergent
   Personal hygiene items
   Duct and masking tape
   Matches in waterproof container
   Disinfectant
   Mobile phone and charger
   Insect repellent and sunscreen
   Tools for temporary repairs
   Rope and chains for securing outdoor items
   Extension cords and power boards
   Plastic sheeting or tarps

FIRST AID KIT
 Replace any used contents

CLOTHING AND BEDDING
   At least one complete change of clothing and footwear per person
   Long sleeve shirts and long trousers
   Sturdy shoes
   Rain gear
   Blankets or sleeping bags
   Hats and work/gardening gloves
   Sunglasses

                                                              7
SPECIAL ITEMS
   Baby needs such as nappies and bottles
   Medications
   Contact lenses or prescription glasses
   Important family documents in a waterproof container
   Wills, insurance policies
   Passports and immunisation records
   Bank account and credit card numbers
   Inventory of household contents
   Important telephone numbers
   Family records such as birth and marriage certificates
   Pet food and supplies
   Games, books and puzzles for entertainment
   Ice
   Ensure you have enough cash on hand to last one week
   Fuel for car

ITEMS TO PACK IN YOUR EVACUATION KIT
	Multiple changes of clothes for all household members, stored in watertight plastic bags (long pants, long sleeved shirts,
   hats and strong shoes are recommended)
 Extra essential medicines and repeat prescriptions
 Extra First Aid supplies, sunscreen, insect repellent
 Extra toiletry and sanitary supplies
 Pillows, sleeping bags and blankets for each household member
 Books and games for children
 Extra baby formula, food and nappies (if required)
 Valuables, photos (prints, compact disks, USB data stick) and mementos in waterproof plastic bags
 Cash
 Mobile phone, spare battery and charger

IMPORTANT DOCUMENTS
 Keep original or certified copies of all the following documents in your Emergency Kit and your Evacuation Kit
	Scan copies of these documents and save on a USB memory stick or CD to include in your kit as well. Keep all these items in
   sealed plastic bags
 Insurance papers for house and contents
 Insurance papers for vehicles and valuable items
 Inventory of valuable household goods
 Wills and life insurance documents
 House deeds/mortgage documents
 Birth and marriage certificates
 Passports/visa details
 Stocks and bonds
 Medicare and pension cards
 Immunisation records
 Bank account and credit card details
 Back-up copies of important computer files
 Copy of household Emergency Plan
 Emergency contact telephone numbers

                                                              8
9
7

                                                                       6

                                                                                                                4
                                                                                    5

                                                                                                        3

1
0
                                                                                                            2
                                                                                                                1

                                                                                                                                9
                                                                                                                                                8

DISCLAIMER                                                                 RED      Evacuation Routes               TOWNSVILLE STORM TIDE
Storm Tide Evacuation Zones are based upon geographical data.
Evacuation Zones are designed to provide an easy to understand
method for the public to identify coastal areas that may be affected       ORANGE   Suburbs                           EVACUATION ZONES
by storm tides caused by tropical cyclones or severe east coast
storms. Every effort has been made to ensure that the information          YELLOW   Detail Maps
contained within these Public Information Maps is accurate.                                                          0   2,500 5,000   10,000       15,000   20,000
However, Townsville City Council does not give any warranty or
accept any liability in relation to the content of these maps.             BLUE
                                                                                                                                       Meters
TOWN
        COMMON

                                                                                                         HE
                                                                                                            AT
                                                                                                               LE                                                               ST
                                                                                                                  Y      S                                                IT
                                                                                                                                                                            T
                                                                        ROWES                                                   PD                                       W
                                                                                                                                     E                                 HO
                                                                         BAY
                                                                                                                                                                  WA
                                                                                                                                                                     R   BU
                                                                                                                                                                            RT
                                                                                                                                                                              ON

                                                                                                                                                                                                TH
                                                                                                          BELGIAN                                                                                 E S
                                                                                                                                                                                       ST

                                                                                                                                                                                                        TR
                                                                                                          GARDENS

                                                                                                                                                                                                          AN
                                                                                                                                                                                                            D
                                                                                                                                                                                         NORTH
                                                                        ACK DR                                                                                                           WARD
                                                                      BL

                                                                                                  ST

                                                                                                                                                                                                                 EY
                                                                  N

                                                                                                                                                                                                            ST                                  TOWNSVILLE

                                                                                                                                                                                                                    R
                                                               TO

                                                                                                   K
                                                                                                                                                                                                       RY

                                                                                                                                                                                                                     E
                                                                                                                                                                                                                                                   CITY

                                                                                               NDOC
                                                             EL

                                                                                                                                                                                                                      ST
                                                                                                                                                                                                O
                                                     JOH N M                                                                                                                                   G
                                                                                                                                                                                             RE

                                                                                                                                                                                                                                                                                         BENW
                                                                                                                                                                                            G                         DE
                                                                                           T BU                                                 CASTLE HILL                                                              NH

                                                                                                                                                                                                                                                        ST
                                                                                                                                                                                               ST
                                                                                                                                                                                                                           AM

                                                                                                                                                                                                                                                                                             ELL R
                                                                                                                                                                                                                                                                  ST
                                                                                                                                                                                                 AN

                                                                                                                                                                                                                                                     NG
                                                                                                                                                                                                   L

                                                                                                                                                                                                                                                              SS
                                                                                                         ST                                                                                            EY

                                                                                                                                                                                                                                                  KI
                                                                                                           A

                                                                                                                                                                                                                                        ST
                                                                                           CY S

                                                                                                                                                                                                                                                              O
                                          GARBUTT                                                                                                                                                           ST

                                                                                                                                                                                                                                                                                                   D
                                                                                                            G

                                                                                                                                                                                                                                                             R
                                                                                                             PO

                                                                                                                                                                                                                 ST
                                                                                                               LE                                                                                                                                                       AR
                                                      ST

                                                                                        PER

                                                                                                                                                                                                                                                                           CH

                                                                                                                                                                                                           T

                                                                                                                                                                                                                                       AN ST
                                                                                                                         ST                                                                                                                                                   ER

                                                                                                                                                                                                        UR
                                               MEENAN

                                                                                                                                                                                                                                                                                 S   T
                                                                                                                                                                                                                                                               SOUTH

                                                                                                                                                                                                     ST
                                                                                                         WEST                                                                                                                                                TOWNSVILLE

                                                                                                                                                                                                                                       DE
                                                                                                                           ST

                                                                                                         END
                                                                               H ST

                                                                                                                                         T

                                                                                                                                                                                       KN
                                                                                                                                     ECHLIN S
                                                                                                                    COWLEY

                                                           INGHAM RD

                                                                                                                                                                                                                             ST
                   ON ST

                                                                                                                                                                                         AP

                                                                                                                                                                                                                      RS
                                                                          HUG

                                                                                                                                                                                           P

                                                                                                                                                                                                                    DE
                                                                                                                                                                                               ST
           PILKINGT

                                                                                                                                                                                                                  UN
                                                   RD

                                                                                                                                                                                                             SA
                                            LE                                                                   WOO LCOC
                                                                                                                          K                           ST
                                 Y        MP
                                                                                                              KINGS RD

                                                                                                                                                                                                 RY ST
                               LR                                                                                                                                                     B O UNDA
                             DA

                                                                                                                                                                                                                         RAILWAY AVE
                                          BAYSWATE
                                                   R RD
                                                                                                                                                        RD

                                                                                                                         HYDE PARK
                                                       CURRAJONG                                                                                                                                                                       RAILWAY
                                                                                                                                                       S
                                                                                                                                                    ER

                                                                                                                                                                  AC                                                                   ESTATE
                                                                                                                                                                       KER
                                                                                                                                                  OW

                                                                                                                                                                             SS
                                                                                                                                                                                  T
   VINCENT                                 PALMERST
                                                                                                                                                ST

                                                   ON ST                                                                                                             HERMIT
                                                                                                                                            TER

                                                                                                                                                                     PARK
                                   ST
                    GE ST

                                                                                              PIMLICO
                                                                                                                                         AR
                                 MOONEY

                                                                                                                                     CH

                                          GULLIVER
                BRID
           C AM

                                                                                                           MYSTERTON                                         RD
                                                                                                                                                         S
                                                                                                                                                      EN                                                                                                                 STUART
                                                                                       FULHAM R
                                                                                                D                                                   UE                                                  OONOONBA
                                                                                                                                                Q
                                                                                 ST

                                 ST                                                                        BA
                           LES                                                                               LL
                                                                        GULLIVER

              R
           CHA                                                                                                 SL
                                                                                                                         N

                     RD
    SR          IVER                                                      MUNDINGBURRA
ROS
                                                                                                              LOVE LN                                        ROSSLEA
                    AITKENVALE
                                                                                                                                                        BO
                                                                                                                                                           WE
                                                                                                                                                              N

                                                                                                                                                                                                               D
                                                                                                                                                                                                           BA R
                                                                                                                                                                  RD

                                                                                                                                                                                                       OON
                                                                                                                                                                                                OON

                                                                                                                                                                                    S             IDALIA
                                                                                                                                                                                  DA T
                                                                                                                                                                             KO
                                                                                                                                                                        KO
                                                                                                                                                                                                                                               ABB

                                                                                                         ANNANDALE
                                                                                                                                                                                                                                                OTT

                                                                                                                                                                                                                                                                       CLUDEN
                                                                                                                                                                                                                                                   TS

                                 DA       DR
                           YOLAN

                                                                                                                                                                                                                 RACECO
                                                                                      UNIVERSITY RD                                                                                                                     UR                 SE RD          BRUCE HW
                                                                                                                                                                                                                                                                  Y
                                                                                                                                                                                                                    ST

DOUGLAS
                                                                                                                                                                                                                       U    AR

                                                                                            MURRAY                                                                                                WULGURU
                                                                                                                                                                                                                               T
                                                                                                                                                                                                                                       DR

                                                                                                                                                                                                                                                              1
                                                                                                  Evacuation Routes
                                                                                                                                          TOWNSVILLE STORM TIDE
DISCLAIMER
Storm Tide Evacuation Zones are based upon geographical data.
Evacuation Zones are designed to provide an easy to understand                                    RED

                                                                                                                                            EVACUATION ZONES
method for the public to identify coastal areas that may be affected
by storm tides caused by tropical cyclones or severe east coast                                   ORANGE
storms. Every effort has been made to ensure that the information
contained within these Public Information Maps is accurate.                                       YELLOW
However, Townsville City Council does not give any warranty or                                                                                       500       250      0                500                1,000                  1,500        2,000
accept any liability in relation to the content of these maps.
                                                                                                  BLUE                                                                                                                                               Meters
                                                                                                                                                           1
BUSHLAND                                                                                                                                                                  SHELLY
                    BEACH                                                                                                                                                                    BEACH

                                                                                                                                                                                                        ESPLANADE
                                                                NO
                                                                                                                                                                  TOWN COMMON

                                                                  RT
                                                                    H
                                              MOUNT

                                                                   SH
                                               LOW

                                                                     ORE B
                                                                                                                                                                                      PALLARENDA

                                                                          LVD

                                                                                                                                                                                                                    CAPE P
                                                                                                                                                                                       TOWN
                                                                                                                                                                                      COMMON

                                                                                                                                                                                                                          AL L A
                                                                                                                                                                                                                              ENDR
     RD

                                                                                                                                      BOHLE
   GARLAND

                                                                                                                                                                                                                                AR
                                                                                                                                                                           PALLARENDA INSET

                                                                                                                                                                                                                                     D
                                                                BURDELL

                                                                                                                                                                                     MOUNT
                                                                                                                                                                                     ST JOHN
                                        BR                                                                            T
             DEERAGUN                     UC                                                                     ES
                                             E                                                                 IS
                                                  HW
                                                                                                    ENT ERPR

                                                           Y

                                                                                                                          RD
                                                                                                                  HAM
                                                                                                               ING
                                                                        RD
                                                                      AW

                                                                                                                                                                  WOOLCOCK
                                                                   SH

                                                                                                                                                                           ST
                                                                                                                                                                                                                GARBUTT
                                                SHAW

                                                                                                                                                                                                        MATHER ST
                                                                                                COSGROVE
                                                                                                                                                                    MOUNT LOUISA

                                                                                                                                                                                                                    BANFI E
                                                                                                                                                                                                                       LD
                                                                                                                                                                                                                          DR

               BOHLE PLAINS
                                                                                                                                                                                                                       ANGU

                                                                                                                                                                                                        RD
                                                                                                                                                                                           DAL RYMPLE
                                                                                                                                                                                                                          S AV

                                                                                                                                                              T
                                                                                                                                                         ES
                                                                                                                                                                                                                              E

                                                                                                                                                       DW
                                                                                                                                                     ER
                                                                                                                                                PL                                                           HEATLEY
                                                                                                                                              YM
                                                                                                                                           ALR
                                                                                                                                                                             DR

                                                                                                                                          D
                                                                                                                                                                               A
                                                                                                                                                                             OW

                                                                                                                                                                                                                                         ST
                                                                                                                                                                      THURING

                                                                                                                                                                                                LN
                                                  THE RING RD

                                                                                                                                                     KIRWAN                                                                       S
                                                                                                                                                                                                                                LE
                                                                                                                                                                                               D

                                                                                                                                                                                                                              AR
                                                                                                                                                                                               OR

                                                                                                                                                                                                                     CH
                                                                                                                                                                                           BAMF

                                                                                                                                                                                                        CRANBROOK

                                                                                                                                                                                                2
                                                                                Evacuation Routes
                                                                                                               TOWNSVILLE STORM TIDE
DISCLAIMER
Storm Tide Evacuation Zones are based upon geographical data.
Evacuation Zones are designed to provide an easy to understand                  RED

                                                                                                                 EVACUATION ZONES
method for the public to identify coastal areas that may be affected
by storm tides caused by tropical cyclones or severe east coast                 ORANGE
storms. Every effort has been made to ensure that the information
contained within these Public Information Maps is accurate.                     YELLOW
However, Townsville City Council does not give any warranty or                                                        500       250   0       500       1,000      1,500           2,000
accept any liability in relation to the content of these maps.
                                                                                BLUE                                                                                                  Meters
                                                                                                                            1
                                                                                                                            2
YABULU

                                                                                                                                                                                                                    RD
                                                                                                                                                                                                                 GA RLAN D
                                                                                  BEACH HOLM
                                                                       WE NT RD

                                                                                                                                                                                 BUSHLAND
                                                                                                                                                                                  BEACH

                                                                                                                                                             MOUNT LOW PKW
                        BLACK RIVER                                                                                                                                                                 LVD
                                                                                                                                                                                     NORT H SHO RE B
                              RD
                            N
                          DE

                                                                                                                                                                              MOUNT LOW
                        W
                       BO

                                                                                                             S VE NS SO
              CH U
                RCH

                            WH

                                                                                                                   N RD
                            IT
                  RD

                              E
                                 RD

                                                                                                                          BR
                                                                                                                            UC
                                                                                                                              EH
                                                                                                                                WY
                                                                                                                                                                                                    RD
                                                                                                                                                                                                 GA RLAN D

                                                                                                                                                                                                                        BURDELL
                                                                  JENSEN
                                                                                                      VE ALES RD

                                                                                                                                            NE Y L N
                                                                                                                                          EA
                                                                                                                                      G

                                                                                                                                                       DEERAGUN
                                                                                                        JE NS EN R D
                                                                                               HAYN ES RD

                                                                                                                                                                                      BOHLE PLAINS           SHAW

                                                                                                                                                                                                             3
                                                                                  Evacuation Routes
                                                                                                                          TOWNSVILLE STORM TIDE
DISCLAIMER
Storm Tide Evacuation Zones are based upon geographical data.
Evacuation Zones are designed to provide an easy to understand                    RED

                                                                                                                            EVACUATION ZONES
method for the public to identify coastal areas that may be affected
by storm tides caused by tropical cyclones or severe east coast                   ORANGE
storms. Every effort has been made to ensure that the information
contained within these Public Information Maps is accurate.                       YELLOW
However, Townsville City Council does not give any warranty or                                                              500       250     0        500                   1,000     1,500   2,000
accept any liability in relation to the content of these maps.
                                                                                  BLUE                                                                                                             Meters
                                                                                                                                  1
                                                                                                                                  3
PA
                                                                                                                                                                 C   IFI
                                                                                                                                                                        C   DR
                                                                                                                                                                                                                                                    FLORENCE
                                                                                                                                                                                                                                                       BAY

                                                                                                                                                                                 HORSESHOE BAY      AP JOH N ST

                                                                                                                                                                                                               HO
                                                                                                                                                                                                                 RS
                                                                                                                                                                                                                   ES
                                                                                                                                                                                                                     HO
                                                                                                                                                                                                                       E
                                                                                                                                                                                                                                                  BA
                                                                                                                                                                                                                                                    Y
                                                                                                                                                                                                                                                        RD
                                           W EST

                                                                                                                                                                                                                                       RD
                                                   PT
                                                        RD                                            WEST POINT
                                                                                                                                                                                                                                             ND
                                                                                                                                                                                                                                         ISLA
                                                                                                                                                                                                                                MAGNETIC
                                                                                                                                                                                                                               Y

                                                                                                                                                                                                    ARCADIA

                                                                                                                                                                                                                       E
                                                                                                                                                                                                                       ARMAND W

                                                                                           W
                                                                                                                                                                                                                    PD

                                                                                           ES
                                                                                              T
                                                                                                                                                                                                               NE
                                                                                                                                                                                                            RI

                                                                                               PT
                                                                                                                                                                                                      A

                                                                                                  R
                                                                                                                                                                 NELLY
                                                                                                                                                                                                     M

                                                                                                  D

1
4
                                                                                                                                                                 BAY

                                                                                                                                                                                    ST          DIA RD
                                                                                                                                                                                            ARCA
                                                                                                                                                                                 NG
                                                                                                                                                                               NI

                                                                                                          PICNIC
                                                                                                                                                                            SOO

                                                                                                           BAY
                                                                                                                                                                        R   D
                                                                                                                                                                     AY
                                                                                                                                                                  LYB

                                                                                                                                                         ST
                                                                                                                                                                EL

                                                                                                                   WE ST
                                                                                                                                                               N

                                                                                                                           PT R
                                                                                                                                  D             RT
                                                                                                                                              BI

                                                                                                                                                     T
                                                                                                                                                   CS
                                                                                                                                              NI
                                                                                                                                       P IC

DISCLAIMER                                                             Evacuation Routes
Storm Tide Evacuation Zones are based upon geographical data.
Evacuation Zones are designed to provide an easy to understand         RED                                                                    TOWNSVILLE STORM TIDE
method for the public to identify coastal areas that may be affected                                                                                                                                                                                         4
by storm tides caused by tropical cyclones or severe east coast        ORANGE
storms. Every effort has been made to ensure that the information
                                                                                                                                                EVACUATION ZONES
contained within these Public Information Maps is accurate.            YELLOW
However, Townsville City Council does not give any warranty or                                                                        500     250        0             500          1,000   1,500   2,000           2,500
accept any liability in relation to the content of these maps.
                                                                       BLUE                                                                                                                                            Meters
TOOLAKEA

                                                                                                            RD
                                                                                                        H
                                                                                                     AC
                                                                                                BE
                                                                                            A
                                                                                      A   KE
                                                                                                                                                  DR
                                                                                    OL                                                   TE
                                                                                                                                              R
                                                                                  TO                                               LUE
                                                                                                                                       WA
                                 JOH

                                                                                                                               B                                                           SAUNDERS
                                                                                                                                                                                             BEACH
                                  NB
                                    REWE R DR

                                                                       BLUEWATER
BR

                                                                                                                                                                                                RD
     UC
            E                                                                                                                                                          W

                                                                                                                                                                                             CH
                                                                                                                                                                   PK
                   HW

                                                                                                                                                                                           EA
                                                                                                                                                                  NO

                     Y
                                                                                                                                                              RO

                                                                                                                                                                                           B
                                                                                                                                                                                        RS
                                                                                                                                                             PU
                                                               DR

                                                                                                                                                                                      DE
                            RD
                                                           ER

              T    RY                                                                                                                                                             UN
                                                         AT

           ES
                                                                                                                                                                                 SA
       R
                                                        W

  FO
                                                      UE
                                                    BL

                                                                       BR
                                                                          UC
                                                                             E
                                                                                 HW
                                                                                   Y
                                                                                                                              PK W

                                                                                                                                                                       YABULU
                                                                                                                            PU RO NO

  KA
    TA
           U
               G
                   H
                       AL
                            RD

               LYNAM
                                                                                                                                                                                                               BLACK
                                                                                                                                                                                                               RIVER

                                                                                                                                                                                                           5
                                                                             Evacuation Routes
                                                                                                             TOWNSVILLE STORM TIDE
DISCLAIMER
Storm Tide Evacuation Zones are based upon geographical data.
Evacuation Zones are designed to provide an easy to understand               RED

                                                                                                               EVACUATION ZONES
method for the public to identify coastal areas that may be affected
by storm tides caused by tropical cyclones or severe east coast              ORANGE
storms. Every effort has been made to ensure that the information
contained within these Public Information Maps is accurate.                  YELLOW
However, Townsville City Council does not give any warranty or                                                   500       250         0               500         1,000        1,500          2,000
accept any liability in relation to the content of these maps.
                                                                             BLUE                                                                                                                 Meters
                                                                                                                       1
                                                                                                                       5
TOOMULLA
                                           RD
                                           H
                                        AC
                                     BE
                                  LA
                               UL
                             OM
                           TO

                                                                       CLEMANT

                                                                                                B
                                                                                                 RU
                                                                                                   CE
                                                                                                        HW
                                                                                                             Y

                                                                                                                             BLUEWATER
                                                                                           D

                                                                                       TTER R
                                                                                  SE
                                                                                                                                                             R ALL RD

                                                                                                                                                              R
                                                                                                                                                           VE

                                                                                                                                                       6
                                                                       Evacuation Routes
                                                                                                TOWNSVILLE STORM TIDE
DISCLAIMER
Storm Tide Evacuation Zones are based upon geographical data.
Evacuation Zones are designed to provide an easy to understand         RED

                                                                                                  EVACUATION ZONES
method for the public to identify coastal areas that may be affected
by storm tides caused by tropical cyclones or severe east coast        ORANGE
storms. Every effort has been made to ensure that the information
contained within these Public Information Maps is accurate.            YELLOW
However, Townsville City Council does not give any warranty or                                   500       250   0   500   1,000   1,500   2,000
accept any liability in relation to the content of these maps.
                                                                       BLUE                                                                   Meters
                                                                                                       1
                                                                                                       6
MUTARNEE

                                                D
                                            R
                                   E   EK
                                CR
                            P
                        M
               N   CA
            HE

                                                    ROLLINGSTONE

                                                                                                                               AC HE RON
                                                                                                                                           DR
                                                                                                            B ALGA

                                                                                                                              BALGAL BEACH
                                                                                                                  L BEA

             CRYSTAL
              CREEK
                                                                                                                 CH RD

                                                                                             D
                                                                                    TI O N R
                                                                                  TA
                                                                             AN
                                                                        PL
                                                                                                  BR
                                                                                                    UC
                                                                                                      E
                                                                                                        HW
                                                                                                          Y

                                                                                                                                                                        CLEMANT

              N    RD
        TATIO
P LAN

                                                                                                                                                                            7
                                                                       Evacuation Routes
                                                                                                 TOWNSVILLE STORM TIDE
DISCLAIMER
Storm Tide Evacuation Zones are based upon geographical data.
Evacuation Zones are designed to provide an easy to understand         RED

                                                                                                   EVACUATION ZONES
method for the public to identify coastal areas that may be affected
by storm tides caused by tropical cyclones or severe east coast        ORANGE
storms. Every effort has been made to ensure that the information
contained within these Public Information Maps is accurate.            YELLOW
However, Townsville City Council does not give any warranty or                                    500       250           0      500            1,000   1,500   2,000
accept any liability in relation to the content of these maps.
                                                                       BLUE                                                                                        Meters
                                                                                                        1
                                                                                                        7
ELAND RD
                                                                                            CAPE CLEV

                                                                                                                                          ME EH AN RD
                                                                         C ROCOD
                                                                           I LE

                                                                                                                     D

                                                                                                                     R
                                                                                                                 Y
                                                                                                            LE
                                                                              CRE

                                                                                                          RI
                                                                                                            CARTY RD
                                                                                   EK R D

                                                                                                                     CAPE CLEVELAND

                                                                                                                                                                                                                                        8
                                                                                                                                                                                                                                        1
                                                                                                                                                                                    GOODSELL
                                                                                                                                                                                                RD

                                                                                                                            ME EH AN RD
                                  NOME
     BR UC
          E       HWY
           ALLIGATOR
             CREEK
                                                                       MOUNT
                                                                       ELLIOT
                                                                                                                                                                                                                             CUNGULLA
                                                                                                                                                                                                                         8
                                                                       Evacuation Routes
                                                                                                                                                            TOWNSVILLE STORM TIDE
DISCLAIMER
Storm Tide Evacuation Zones are based upon geographical data.
Evacuation Zones are designed to provide an easy to understand         RED
                                                                                                                                                              EVACUATION ZONES
method for the public to identify coastal areas that may be affected
by storm tides caused by tropical cyclones or severe east coast        ORANGE
storms. Every effort has been made to ensure that the information
contained within these Public Information Maps is accurate.            YELLOW
However, Townsville City Council does not give any warranty or                                                                                          500 250   0   500   1,000   1,500   2,000    2,500   3,000
accept any liability in relation to the content of these maps.
                                                                       BLUE                                                                                                                                     Meters
STUART

                                                                          W ILL
                                                                                                                                                                    CAPE CLEVELAND

                                                                              ING
                                                                               DR
                                                                        PA

                                                                         U
                                                                             L J AMES
                                                                                      DR

                                                                                                               DR
                                                                                                           Y

                                                                                                               E
                                                                                                          TL
                                                                                                     EN
                                                                                                 B
                                                                                         NOME

JULAGO

                                                                                                                                                                RD
                                                                                                                                                                M
                                                                                                                                                               HA
                                                                                                                                                           RN
                                                                                                                                                          BA

                                                                             BARNH A M RD

      BR
        UC
                                                                                  Y DR

          E
                 HW
                      Y
                                                                               TLE
                                                                                N
                                                                             BE

                                                                                                                                                                                        RD

                                                                                                                                   BRU
                                                                                                                                                                                          N

                                                                                                                                         CE
                                                                                                                                                                                    MARRO

                                                                                                                                              HWY
                                                                                                                                                      RD
                                                                                                AL

                                                                                                                                                      K
                                                                                                                                                    EE
                                                                                                   LE
                                                                                                     ND

                                                                                                                                                CR
                                                                                                       AL

                                                                                                                                               R

                                                                       ALLIGATOR CREEK
                                                                                                                                             TO
                                                                                                                   E
                                                                                                                    DR

                                                                                                                                           GA
                                                                                                                                         LI
                                                                                                                                       AL

                                                                                                                                                                     S RD
                                                                                                                                                                    LIAM
                                                                                                                                                                WI L

                                                                                                                                                                                                           MOUNT
                                                                                                                                                                                                           ELLIOT

                                                                                                                                                                                                       9
                                                                        Evacuation Routes
                                                                                                      TOWNSVILLE STORM TIDE
DISCLAIMER
Storm Tide Evacuation Zones are based upon geographical data.
Evacuation Zones are designed to provide an easy to understand          RED

                                                                                                        EVACUATION ZONES
method for the public to identify coastal areas that may be affected
by storm tides caused by tropical cyclones or severe east coast         ORANGE
storms. Every effort has been made to ensure that the information
contained within these Public Information Maps is accurate.             YELLOW
However, Townsville City Council does not give any warranty or                                                     500       250   0          500         1,000             1,500         2,000
accept any liability in relation to the content of these maps.
                                                                        BLUE                                                                                                                  Meters
                                                                                                                         1
                                                                                                                         9
TUNE INTO WARNINGS
                                            RADIO STATIONS
                                            Tune into your local radio station
                                            for the latest emergency information.

                                            ABC LOCAL RADIO              630 AM
                                            4TO FM                       102.3 FM
                                            HOT FM                       103.1 FM
                                            ZINC                         100.7 FM
                                            106.3 Mix FM                 106.3 FM
                                            103.9 Tripple T              103.9 FM

                                            CONTACT DETAILS
                                            CUSTOMER SERVICE CENTRES
                                            103 Walker Street, Townsville City
                                            86 Thuringowa Drive, Thuringowa Central
                                            Opening hours: Monday to Friday 8.30am – 5pm
                                                1300 878 001
                                                enquiries@townsville.qld.gov.au
                                                Townsville Disaster Information
                                                @TCC_news

Although funding for the Storm tide Evacuation Guide has been provided by both the Australian and Queensland Governments, the material contained
herein does not necessarily represent the views or policies of either Government.
You can also read
