Northern Lights project:
Developing an ‘open source’ service for transport and
storage of European CO2

IVA, Stockholm 28 January 2019
Dr.ing. Per Sandberg, Equinor
prsa@equinor.com
+4748261451

                                                                                                           From words to action
Northern Lights project: Developing an 'open source' service for transport and storage of European CO2 - IVA
Northern Lights – “open source” CO2 transport and storage service

                Northern Lights

                                                                    Potential 3rd party

  2 |                                                                              Internal   07 January 2019
Northern Lights project: Developing an 'open source' service for transport and storage of European CO2 - IVA
Concept overview
                                                                                                                                  Pipeline                                    Subsea facilities
                                                                                                                                  • 110km un-insulated pipeline               • Connecting pipeline,
                                                                                                                                  • 12 ¼ inch                                    umbilical and well(s)
                                                                                                                                  • Single phase (liquid) CO2                 • Water depth ~300m
                                                                                                                                                                              • Connection for future step-
                                                                                                                                                                                 out

                                                                                                                                                                                                                  Subsea injection well
                                                                                                                                                                                                                  • Injection of CO2 into
                                                                                                                                                                                                                     reservoir at ~2-
                                                                                                                                                                                                                     3000m depth
                                                                                                                                                                                                                  • Pressure in
                                                                                                                                                                                                                     reservoir
                                                                                                                                                                                                                     ~2-300bar
                                                                                                                                                                                                                  • Temperature in
                                                                                                                                                                                                                     reservoir ~100 ºC

CO2 Capture Sites                                    Ship(s)                  Onshore facilities
• CO2 captured by Fortum, at Klemetsrud, and         • One ship per capture   • One jetty for ship mooring
    Norcem, in Brevik, and stored locally at their       site                 • Tank volume based on ship cargo size                                                                                          Umbilical
    jetties                                          • 7,500m3 of LCO2 per    • Pump system to provide required                                                                                          Connection
• Storage volume at each site required to                ship                    export pressure                                                                                                      from Oseberg-
    account for ship arrival every four days plus    • Pressure 13-18barg     • Evaporator to maintain vapour/liquid                                                                              field providing power
    a buffer for any upsets in the overall chain         at equilibrium          balance in storage tanks during                                                                                and signal from DC/FO and
• Jetty operations are assumed to be by                  temperature             injection                                                                                                   fluids through umbilical
    capture plant                                        (approx. -30 ºC)     • Heater to inject above pipeline                                                                              system
                                                                                 minimum temperature

5   Capacity (Mt/y)

                                                     + ship(s)                                                                                                                       Storage complex
                                                                                         + pump capacity                               + well(s)
                                                                                                                                                                                     • Planned in the Johansen formation south
                                                                                         + heater capacity
                                                                                                                                                                                         of Troll (“Aurora”) with an expected
                                                                                         + jetty
                                                                                                                                                                                         capacity of at least 100 Mt of CO2
1.5                                                                                      + tanks?

                                                                 2 x ship                                                           1 x injection well
                                                                 1 x ship                Onshore facilities            Pipeline            (tbc)           Umbilical system

                                                                                                                                                                                                                          Open
Northern Lights project: Developing an 'open source' service for transport and storage of European CO2 - IVA
Visualisation of intermediate storage facility

4 | Informasjonsmøte                                   Internal   07 January 2019
Northern Lights project: Developing an 'open source' service for transport and storage of European CO2 - IVA
Pipeline from the facility

 5 | Informasjonsmøte        Internal   07 January 2019
Northern Lights project: Developing an 'open source' service for transport and storage of European CO2 - IVA
Carbon capture and storage (CCS) needs to play an important role
in meeting climate goals

IPCCs Special report on Global Warming of 1,5 oC, 2018        “Carbon capture, utilisation and in
                                                              meeting climate goals…” storage (CCUS)
                                                              needs to play an important role
                                                              IEA World Energy Outlook 2018

Source: The Global Status of CCS 2018, Global CCS Institute
                                                                                   Internal            07 January 2019
Northern Lights project: Developing an 'open source' service for transport and storage of European CO2 - IVA
Despite new technology, there has never been any energy transition
To meet GHG targets, we need ALL solutions that contribute
…and we do NOT need those that do not contribute
                                                     ⋅ Shifts in primary energy supply has taken
                                                       decades in the past

                                                     ⋅ …but GROWTH in energy demand more than
                                                       outweigh shift between supply sources

                                                     ⋅ To meet the 1.5 degree target, all energy use
                                                       has to be carbon neutral by 2050!

                                                     ⋅ This cannot be solved by phasing in renewables
                                                       only - it is currently a small fraction

                                                     ⋅ We need to use the entire toolbox to have the
                                                       slightest chance of succeeding

                                                                          Internal         07 January 2019
Northern Lights project: Developing an 'open source' service for transport and storage of European CO2 - IVA
Norwegian processing industry roadmap, 2016

•   Aims for double production & negative emissions   • Requires CCS - national effort to build industrial CCS
    in 2050                                             value chain should continue
•   Need ambitious, long-term technology              • Requires sustainable biomass – opportunity for
    development programs – Process21                    Norwegian industry

                                                                                     Internal        07 January 2019
Northern Lights project: Developing an 'open source' service for transport and storage of European CO2 - IVA
CCS in Norway – 22 years of succesful industrial experience

                                      Snøhvit CCS
                                      i drift 2008

                         Fullskala
                         demonstrasjons              CO2 test senter (TCM)
                         prosjekt                    i drift 2012
                         (2016-2023)

          Sleipner CCS
          i drift1996

                                                                             ⋅ 22 år med driftserfaring
                                                                             ⋅ Ca 22 Mill tonn CO2 lagret

9
                                                                                  Internal        07 January 2019
Northern Lights project: Developing an 'open source' service for transport and storage of European CO2 - IVA
How we have confidence in CCS and CO2 storage

The operational experience argument
        “We know from 22 years of operations that CCS works”

The geophysical monitoring argument
        “We can see where the CO2 is and show it is safely stored”

The regulatory compliance argument
         “We can demonstrate regulatory conformance”

The underlying physics of CO2 storage in rock pores
        “CO2 is trapped in microscopic rock pores by the same process that has trapped natural gas for
        millions of years”
Storage mechanisms – increasing safety over time

                                                                                                     http://www.co2captureproject.org/co2_trapping.html
                                      After IPCC (2005): Carbon Dioxide Capture and Storage

   11 | CO2 storage safety and monitoring experience                                          Open                                                        27 June 2018
Provides "open access " to CO2 sources that want to start capturing

                                                    •   Hydrogen from natural gas
                                                    •   Waste incinerartion (60% biogenic)
                                                    •   Cement
                                                    •   Biomass and biofuels
                                                    •   Steel
                                                    •   Refining
                                                    •   Other industry

  12 | Northern Lights Project                                             Internal          07 January 2019
In dialogue with 4 facilities in Sweden

•   Preem Lysekil
•   Stockholm Exergi
•   Renova Gothenburg
•   Plagazi Köping

•   Estimated total of 2 MTPA capturable
    CO2
•   Several other sites are well positioned

       13 | Document Title                    Internal   07 January 2019
Potential in Sweden is much larger – how can pulp & paper industry rapidly
become the climate “double winners” they are destined to be?

•   96 facilities
•   48 MTPA of CO2
•   Estimated 37 MTPA of
    capturable CO2
•   Large amounts of bio-based
    CO2 emissions

     14 | Document Title                                              Internal   07 January 2019
Prosjekt status & future

•    Transport, intermediate storage, pipeline
          •   Concept report delivered 1.12.18, now FEED until Q3 201
          •   Geotechnical and seabed surveys done
•    Storage
          •   Use permission Nr. 001 given for «Aurora» south of Troll
          •   Confirmation well to be drilled November 2019, subsea equipment is
              being built now
•    Customers
          •   In dialogue with 15 possible users in 8 european countries
•    Investment decisions                                                          Aurora
          •   Planned for December 2020 (State budget)
          •   Then all emitters have a storage solution – start to capture!
•    Operational 2023
