ITS upgrade Meeting Gruppi INFN - V. Manzari - CERN, 6 Novembre 2012 - CERN Indico
ITS upgrade
Meeting Gruppi INFN

  V. Manzari – CERN, 6 Novembre 2012
ITS upgrade Meeting Gruppi INFN - V. Manzari - CERN, 6 Novembre 2012 - CERN Indico
Upgrades: status
On September 27 after the third round of discussions with ALICE, the
LHCC has endorsed our Upgrade LoI and ITS CDR. Minutes are not out
yet, but there is a statement which we can quote issued by the LHCC
chair:
“There is an interest amongst the collider experiments (ALICE, ATLAS and CMS)
for a continued heavy ion programme that gives access to rare final states. This
programme will extend well into the 20ies assuming the current HI running mode of
one month per year.
The physics programmes of the two general purpose detectors and ALICE are
complementary: while the former may focus on selected hard probes ALICE will be
optimized for particle identification at low transverse momenta. The experiments
are hence sensitive to different ”messenger“ signals and phases of the evolution of
the quark gluon plasma.
This increase in sensitivity for ALICE entails an upgrade of the rate capability of
the TPC, a high resolution ITS, and a major upgrade of the online system and the
read-out electronics.
The LHCC commends this joint approach to heavy ion physics and endorses the
upgrade plans of the ALICE collaboration. The committee is looking forward to the
seeing detailed technical solutions presented in the respective TDRs.. ”
ITS upgrade Meeting Gruppi INFN - V. Manzari - CERN, 6 Novembre 2012 - CERN Indico
Upgrades: next steps

RRB 29 Oct -1 Nov
o   Extension of the construction MoU
o   General Endorsement of the Upgrade
TDRs to be prepared in O(1 year)
o Will define the construction design
o Will contain the specific commitments of the Institutions to the
projects
o Followed by MoU addendum (or addenda)

R&D
o Will have to continue vigorously throughout the process, with
substantial funding, agreed within each project
Target date for ITS TDR August 2013 for submission to LHCC in
September 2013
Running scenario after the upgrades
• Pb–Pb
   •   int. luminosity per year 2.85 nb -1 (peak L = 7x1027 cm-2s-1)
   •   needed int. luminosity 10 nb -1, statistics 8x1010 events
   •   3.5 month of running
   •   +1 month of special run at low field for dileptons
• p–Pb
   • max event rate 200 kHz, flat (L = 1029 cm-2s-1)
   • needed int. luminosity 50 nb -1, statistics 1011 events
   • 0.5 month of dedicated p–Pb run
• pp
   • max event rate 200 kHz, flat (L = 3x1030 cm-2s-1)
   • needed int. luminosity 6 pb -1, statistics 4x1011 events
   • 2 month of dedicated pp run, assumed in 1 year
  The list above fulfills the ALICE physics program as presented in the LoI.
   A run with lower mass nuclei (e.g. Ar) could be considered in addition, if a
  physics case for it would emerge.
Upgrades: a possible running scheme

• ALICE plans to run 6 years with upgraded detector, i.e. until 2026
  (assuming start in 2019 and 2 years break of LS3)
• Possible scenario:
   • 2019 – Pb–Pb 2.85 nb-1
   • 2020 – Pb–Pb 2.85 nb-1 (low magnetic field)
   • 2021 – pp reference run

    • 2022 – LS3
    • 2023 – LS3
    • 2024 – Pb–Pb 2.85 nb-1
    • 2025 – ½ Pb–Pb 1.42 nb-1 + ½ p–Pb 50 nb-1
    • 2026 – Pb–Pb 2.85 nb-1
• This would not require pp running during high-luminosity runs, only a
  short time before a heavy-ion run for setting up and commissioning.
Organization, Timeline and Cost
    Participating Institutes (subject to funding)
                                                                           Contribution of Institutes
    •   CERN
    •   China (Wuhan, SINAP)
                                                                          to be defined within
    •   Czech Republic (Prague)                                            the next 8 months
    •   France IN2P3-CNRS (Strasbourg)
    •   Italy INFN (Bari, Cagliari, Catania, Frascati, Legnaro, Padova, Roma, Torino, Trieste)
    •   Korea (Yonsei University Seoul)
    •   Pakistan (Islamabad COMSATS)
    •   Russia (St. Petersburg)                                        Already members of ITS project
    •   Slovakia (Kosice IEP)
    •   UK STFC (Univ. of Birmingham, Daresbury Lab, RAL)               New members of ITS project
    •   Ukraine (Kharkov, Kiev)
Upgrade Timeline
   2012–2014         R&D                                             Cost Estimate (Option A and B) (*)
   2012              evaluation of technologies & prototyp            R&D                             4 MCHF
•   2013              selection of technologies, eng. Design, TDR
•   2014              final design and validation                      Option A (All pixels)           10 MCHF
•   2015-18           Construction and Installation                    Option B (pixels + strips) 16 MCHF
•   2015-16           production, construction and test of detector
                      modules                                                 (*)   detailed cost breakdown
•   2017              assembly and pre-commissioning
                                                                                    in Table 6.2 of CDR
•   2018              installaiton in the cavern
ITS Upgrade
                         Breakdown of the CORE Cost Estimate
                                                                   Option 1:
                                                                   7 layers of monolithic pixel
                                                                   detectors, which would provide
                                                                   excellent standalone tracking
                                                                   efficiency and pt resolution, but
                                                                   limited PID capability.

                                                                   Option 2:
                                                                   a combination of 3 innermost
                                                                   layers of hybrid pixel detectors
                                                                   and 4 outermost layers of strip
                                                                   detectors, which would provide
                                                                   better PID capability but worse
                                                                   standalone tracking efficiency
                                                                   and momentum resolution.

V. Manzari - INFN Bari               CSN III – 18 Settembre 2012                                      7
ITS Upgrade
                           Timeline

V. Manzari - INFN Bari   CSN III – 18 Settembre 2012   8
ALICE Upgrade
                                     CORE Cost Estimates
 Overall cost estimate for the major upgrade projects
       Detector components and production costs
       Upgrade items and Common Project

              -    ZDC included in “Trigger Detectors”, EMCal and HMPID require minor funds
              -    The Offline cost is the investment needed for the offline central services at CERN
V. Manzari - INFN Bari                        CSN III – 18 Settembre 2012                               9
ALICE Upgrade
                               Spending Profile

 Memorandum of Understanding
       An Addendum for each Project to the ALICE MoU
       Addendum for the Common Projects including M&O A

V. Manzari - INFN Bari           CSN III – 18 Settembre 2012   10
ALICE    Upgrade
                                   Cost Estimate
                         INFN Estimated Contributions

         Overall cost estimate: ≈ 60 MCHF

         Italian Contribution: ≈ 10 MCHF

                             Detector                      Cost (KCHF)
                             ITS                           6000
                             VHMPID                        1000
                             TOF                           600
                             Muon                          600
                             ZDC                           100
                             CommonFunds                   1000

V. Manzari - INFN Bari                  CSN III – 20 Marzo 2012          11
ContributoCost
                            INFN       all’upgrade
                                Estimate

 Partecipazione INFN in ALICE: “Scientist” 107/574 (19%)
 Costo Totale Upgrade ALICE: 36 - 42 MCHF  30 - 35 M€
 Costo Totale Upgrade ITS: 10 - 16 MCHF (+ 4 MCHF per R&D)
 Contributo INFN per upgrade ITS: 4.7 - 6.7 MCHF (33%)  3.9 - 5.6 M€
 Common Projects: 0.9 M€
 TOF: 0.6 M€
 Muon: 1.8 M€ x 0.2  0.4 M€

 Stima finanziamento globale INFN per upgrade ALICE:

                        5.8 M€ spalmato su 5-6 anni
Contributi
                              Cost gruppi
                                   Estimate INFN

 Consultazione in corso con i vari gruppi che hanno espresso interesse a
  partecipare all’upgrade dell’ITS per definire contributi e responsabilità in base
  alle risorse disponibili (finanziarie, personale e infrastrutture) 
          Discussione all’IB meeting durante la mini-week in Dicembre

 Come procediamo?

       Individuare attività/sotto-progetti di interesse comune
       Salvaguardare contributi, specificità e visibilità dei vari gruppi
       Leadership in alcuni sotto-progetti
       Sviluppi tecnologici
       Utilizzo delle infrastrutture esistenti
       Negoziazione delle risorse locali con i rispettivi Direttori di Sez/Lab:
        tecnici, tecnologi e servizi.
List of activities
Activities                                          People
Development, design and production of
front-end electronics
Front-end wafer probing
Sensor development and production (in case
of hybrid pixels and/or μstrips)
Wafer thinning &dicing
Detector interconnect technologies (bump-,
tab-, wire-bonding, BGA, other)
Development and fabrication of test systems
Characterization and mass production tests
of individual detector components
Power and Signal on-detector buses
On-detector readout and interface
electronics
Radiation tests
Design and production of the Stave
mechanical support
Activities                                     People
Design and production of the Integration and
Installation mechanics
On-detector cooling
Cooling plant
Stave assembly
Barrel assembly and integration
Power Supply System
Detector Control and Interlock System
Construction Database
Off-detector readout electronics
Power and Signal Connections
Beam tests (hardware, software, analysis)
Online software (monitoring, DAQ, HLT)
Offline (MC, calibration and reconstruction)
Physics performance studies
Backup

V. Manzari - INFN Bari   CSN III – 20 Marzo 2012   16
Link a Presentazioni Precedenti

 Riunione CSN3 28-29/03/2011
   • R&D activities for the ALICE inner tracker upgrade 
       http://agenda.infn.it/conferenceDisplay.py?confId=3202
 Riunione CSN3 13-14/06/2011
   • ALICE Inner Tracking System Upgrade 
       http://agenda.infn.it/conferenceDisplay.py?confId=3203
 Riunione CSN3 19-20/03/2012
   • ALICE Upgrade 
       http://agenda.infn.it/conferenceDisplay.py?confId=4296
 Referee meeting 9/05/2012:
   • Novità ITS e R&D status 
       http://agenda.infn.it/conferenceDisplay.py?confId=5002
 Referee meeting 20/07/2012:
   • ITS upgrade: consuntivo e richieste 
       http://agenda.infn.it/conferenceDisplay.py?confId=5291

V. Manzari - INFN Bari            CSN III – 18 Settembre 2012    17
Link a Documenti su Upgrade

 Web pages:
      • Inner Tracking System 
                          http://aliceinfo.cern.ch/ITS/
      • Inner Tracking System Upgrade 
                          http://aliceinfo.cern.ch/ITSUpgrade/

 Conceptual Design Report for the Upgrade of the ALICE ITS – Version:
  CDR-0, CERN-LHCC-2012-05 / LHCC-G-159; March 6, 2012 
       https://aliceinfo.cern.ch/ITSUpgrade/sites/aliceinfo.cern.ch.ITSUpgrade/files/d
        ocuments/AliceITSupgrade-CDR-0_1.pdf

 Progress report on the Conceptual Design Report for the Upgrade of the
  ALICE ITS; June 18, 2012 
       https://aliceinfo.cern.ch/ITSUpgrade/sites/aliceinfo.cern.ch.ITSUpgrade/files/
        documents/progress_report.pdf
V. Manzari - INFN Bari                  CSN III – 18 Settembre 2012                 18
Link a Documenti su Upgrade

 Upgrade of the ALICE Experiment – Letter of Intent; September 7, 2012 
  CERN-LHCC-2012-012 / LHCC-I-022 
    https://cdsweb.cer.ch/record/1475243/files/LHCC-I-022.pdf

 Upgrade of the ALICE Inner Tracking System – Conceptual Design
  Report; CERN-LHCC-2012-013 / LHCC-P-005; September 11, 2012 
       http://cdsweb.cern.ch/record/1475244/files/LHCC-P-005.pdf

V. Manzari - INFN Bari           CSN III – 18 Settembre 2012          19
Link alla Pagina Web ITS Upgrade

V. Manzari - INFN Bari             CSN III – 18 Settembre 2012   20
P.T. 2013-2015 (draft di piano finanziario, CSN3 30/1/2012)
    Upgrades : nostre previsioni presentata da Nico in CSN3

 Nel 2011-12 per R&D (ITS, VHMPID)    : 131, 194.5 K€ (77.5 +117 s.j.)
Previsioni costo upgrades (MB e CB meetings del 12/1/2012):
ITS : 14 MCHF (CERN, INFN, IN2P3, UK, COMSATS, BMBF, Ukraina, Russia, China,
                                                          Slovakia, Czech Republic)
2012-2014 R&D e prototipi
2014-2016 Costruzione
                                    Contributo INFN old ITS 49.1%
2016-2017 Integrazione e commissioning in laboratorio
2017-2018 Installazione e commissioning
VHMPID : 3 (- 4) MCHF (USA, INFN, India, Mexico, Korea, Brazil, Hungary)
2011-2012 R&D e prototipi
2013-2016 Costruzione e commissioning in lab./testbeam
2017-2018 Installazione e commissioning          Contributo INFN old HMPID 57.4%
Possibile contributo INFN (circa 16.7 %) : 500 KCHF tra 2013 e 2017
                                      (100 KCHF nel 2013, 150 nel 2014, 150 nel 2015)
Nuova strategia di upgrade del Central Barrel (MB e CB meetings del 12/1/2012):
Stime approssimative dei costi per rivelatori con contributo INFN:
TOF : 600 KCHF (100% INFN) → (72 schede DRM) 500 kEuro
Muon Trigger : 604 KCHF (IN2P3, INFN) → 160 (rivel.) + 30 (sistema gas) = 190 kEuro
Muon Tracking : 967 KCHF (IN2P3, INFN, India?, Russia?) → 200 – 250 kCHF
ZDC 70 kEuro (100% INFN)
                                             Contributo INFN old MUON 9.2% ……
 1 Marzo 2012                                                                     21
You can also read
