GTK MINTEC
MINERAL PROCESSING, MATERIALS RESEARCH AND CIRCULAR ECONOMY SOLUTIONS
#circulareconomy #gtk #exploration #mining #batteryminerals #rawmaterials, #gtkmintec #circularrawmaterialshub
LinkedIn: GTK Mintec , Twitter: @gtkmintec , www.gtkmintec.com
GTK MINTEC; HISTORY AND TODAY
3
GTK MINTEC PREMISES GTK MINTEC
Facilities
• Total area 5 500 m²
• Crushing plant, homogenization area,
concentrator plant
• Pilot Plant
• Bench Scale process laboratory
• Mineralogical Laboratory
• Storages for samples and equipment, 1 200 m2
• Tailings area, 1.5 hectares
Capacity
• 40tn/hr crushing, 5tn/flotation
• 24/7 and fully customizable process
• Normally 8 to 12 pilot scale studies per year
• Unit totally: around 80-100 projects/year
3.6.2021
4
GTK MINTEC SERVICES
Services for the entire mineral production process
• 1) Process mineralogy / Geometallurgy, 2) Pilot plant,
3) Bench Scale Laboratory, 4) Mini Pilot
The services we provide are:
• Mineralogical / geometallurgical research
• Bench-scale laboratory testing
• Continuous 24/7 minipilot- and pilot-scale test runs
• Fully customizable according to the needs
Scope
• Unit operation testing in the pilot plant (e.g milling)
• Full process testing in the pilot plant
• Commercial potential of a mineral deposit
Circular economy
• Sidestreams, re-mining, wastes
3.6.2021
RESEARCH CHAIN FROM
5
ORE DEPOSIT TO MINE
GTK can assist customers in
• Exploration - geochemistry, geophysics
• Ore Potential Evaluation
• Environmental studies
• Chemical analysis
• Geodata
• Water management
GTK Mintec can assist customers in
• Mineralogy and Geometallurgy
• Mineral processing
• Plant tests
• Feasibility studies
• Basic engineering participation
• Mine management, Mine Closure
• Re-mining studies
3.6.2021
6
PROCESS MINERALOGY
LABORATORY
Mineralogical analysis is used as a basis for the development of
beneficiation methods
• Mineralogical and geometallurgical research
• Mineralogical analysis is an essential tool in developing new
beneficiation methods
What we do:
Characterization of mineral products and environmental samples in
• Mining activities (green/brown field), ore prospecting, beneficiation
technology and smelting plants.
• Circular economy, side and waste streams of all sorts
Tools
• Scanning Electron Microscope (SEM) Mineral Liberation Analyser (MLA
• FE-SEM (MLA/QEMSCAN/AMICS): high resolution imaging, advanced
process mineralogy
• XRD: mineral identification and quantification using Rietveld method
• Raman microscope: e.g., Magnetite / Hematite , Li-minerals
(spodumene)
Technical facilities for sample preparation
3.6.2021
7
MINERAL PROCESSING AT
BENCH SCALE
• Process chemistry research, grinding, beneficiation
testing, determination of hydrophobicity and
electrode potential.
• Our focus is on flotation method.
• Gravity and magnetic separation and thickening is
also conducted as laboratory studies.
• Next step is minipilot- or pilot-scale tests.
• We have testing facilities suitable both for normal
and high-pressure leaching.
• Bioleaching has also been used to extract base
metals
• Our laboratory testing provides our customers with a
preliminary overview of the process required to
process their mineral deposit.
3.6.2021
8
MINI PILOT PLANT
First study in a continuous process
after bench scale results
• Sample size 400 – 2,000 kg
Samples types:
• drill cores, ore sample etc.
Samples are pre-crushed to feed size of
3 - 6 mm
Facility was originally designed and
constructed in a sea container
Feed capacity 10 - 50 kg/h.
3.6.2021
PILOT PLANT Process: • Processes can easily be adapted to capacity ranges from 0.2 tph up to 5 tph • Sample sizes typically from 20 to 300 tonnes • Plant automation and process control of a high level, together with automatic sampling systems, ensure the highest quality results Objectives: • Testwork for feasibility studies of new ore deposits • Process development for existing plants • Develop comminution and benefication methods • and equipment for industry • Generate process information for plant design • Assist in bankable feasibility studies 3.6.2021
10 CRUSHING PLANT Crushing laboratory Crushing plant • Capacity around 40 tph. • Storing area for homogenised feed. Tools and equipment • Jaw crusher: Lokomo C 63 B, 45 kW • Gyratory crushers: Lokomo G158, G108,´75 kW each • Horizontal Shaft Impactor: 2 x Hazemag AP-S 0604,15 kW • Vertical Shaft Impactor: Sandvik B5100 • Vibrating screens: Lokomo B130, B230, 7.5 kW each • High pressure roller mill: LRM, Ø 300 x 100 mm, 2 x 11 kW 3.6.2021
11 RESULTS Results from test runs indicate the commercial value and process efficiency of a mineral deposit Test runs gives an overview on how efficient a full-scale beneficiation process will be Estimation on the commercial value of the mineral deposit. Intermediate and end products, such as concentrates and tailings, that can be used in further studies. Assisting in developing key solutions for the circular economy The applicability of mineral processing methods to environmental and recycling-related operations has been proven by several studies. The processes used to extract minerals from ore can be used in the remediation of contaminated soil and separating recyclable metals from industrial slag and other side streams and wastes 3.6.2021
13
GTK MINTEC DEVELOPMENT PLAN
Boosters / Megatrends
• Climate change, Digitalization (AI), Carbon Neutral Society, Zero-emission transport, Automation, Cities,
Sustainability, Circular Economy
Facts and needs:
• Ore grades getting lower
• New processing methods are needed
• Environmental and social licenses
• Technology suppliers needs testings and research sites
• Circular ecomony requires new methods – innovations – research
• ”New” sources for primary raw materials
GTK solutions and services
• Creating a collaboration platform for technology suppliers and research
• Total renewal of GTK Mintec to meet stakeholders requirements
• Remining of old tailings, industrial waste and sidestreams
• SMARTT Tailings Facility; research infrastructure for tailings and water recyclability
3.6.202114
TARGET: NUMBER #1 IN THE WORLD
GTK Mintec will be #1 Mineral Processing Pilot Plant globally, having non-parallel
competence processing know-how on:
• Primary minerals, geomaterials, ores, metals, etc
• Circular Economy materials
• Re-mining research of old tailings
• Digitalization of a Pilot Plant
• Tailings research
• Mine environment and Mine Closure
• Technology collaboration
Conversion to a test platform and facility for Technology Partners, Startups,
Universities, Research Centers
Circular Raw Materials Hub in Espoo with co-operation with Aalto and VTT
We are looking for strategic partners to make this happen
3.6.2021SMART TAILINGS AREA: SOLUTIONS FOR THE
15
TAILORED WASTES
Sensor / probes - technology enables short and long term studies
”SMART” tailings facility – feeds Digital Twin with Data
Re-mining studies
Dry stacking research
Bottom and cover structures
Water recyclability - collaboration and research
Morecovery – Water recovery for recycling – valuables
Technology supplier collaboration
3.6.202116
COLLABORATION
New office and laboratory building will have space that can be rented out (ready by 9/2023)
• New laboratory will have space for collaboration partners
• Lab scale testing
• Equipment and chemicals testing
• Product development
• Technology companies, research centers, universities etc
• Jointly funded projects
• Commercial projects
• Innovations, publications
• Wide range of research topics
3.6.202117
MINTEC NEXT STEPS
Present Mintec • New intelligent flotation cells (8/2021, M:O)
Pilot Plant • New HIG Mill (6/2021, M:O)
(Koetehdas) is • New Process Automation software (Schneider
under Electrics/PASRAM)
• ~30 investments in 2019-2021
refurbishment / • Digital twin is forming step by step
renewal
• Research collaboration in mineral processing,
Renewal plan: circular economy
Added capacity, • New line will have focus on water recycling in the
two processing process: Cost saving, environmental aspects
• Strong link to SMARTT and technology
lines collaboration on ”solid wastes”
3.6.202118
MORECOVERY
• The innovation EIT RawMaterials
project Morecovery
• Smart solutions for the sustainable
extraction and use of raw materials
from secondary sources
• Transportable water cleaning
container
• Solutions for the customers
• Active collaboration with companies
• Publications and innovations
• Contains e.g. on-line XRF (9/2021)
3.6.2021FULLY AUTOMATED
19
LABORATORY
• Sample throught put to empty
system: Milling sequence 5-
6min total, XRF: 15 min, XRD
10-15 min
• Stardized way of making sample
• 24/7
• Ores, Industrial Minerals,
Geomaterials, Side Streams,
Circular Materials
• Battery Minerals
3.6.2021OUTCOME: GTK MINTEC AT OUTOKUMPU MINING CAMP, FINLAND 3.6.2021
GTK MINTEC Digital Twin
Customer
Customer Data Process Automation
MiniPilot
Mineralogy Data
Geometallurgy Customer
”SMART” Tailings Facility
Chemical Research
Dry
Other: 3D
stacking
Technology analysis
suppliers,
Universities,
3.6.2021 research centersQUESTIONS?
22
• jouko.nieminen@gtk.fi
• LinkedIn: https://www.linkedin.com/in/joukonieminen/
• Twitter: @jouko_nieminen
• www.gtk.fi
Follow us on LinkedIn and Twitter!
3.6.2021You can also read
