Euston Throat – Granby Terrace to
Hampstead Road
Construction update
04/03/2021 1
HS2 –Britain's new high speed railway 04/03/2021 2
Areas within the Euston Approaches
We have divided the Euston
Approaches worksites into three areas to help
us communicate which works are closest 1. Vehicle Holding Area & Parkway
and most relevant to you.
1. Vehicle Holding Area & Parkway
2. Camden Cutting (Parkway to Granby Terrace
bridge) 2. Camden Cutting
3. Euston Throat (Granby Terrace to Hampstead
Road)
This construction update is for Euston Throat.
To view the construction update for the Camden
Cutting and Vehicle Holding Area/Parkway
please visit HS2inCamden.co.uk
3. Euston Throat
Euston Approaches engagement programme 2021
Feb/Mar 2021 mid-2021 Sep/Oct 2021 late 2021/early 2022
• Newsletter • Euston Portal Headhouse • Newsletter • Euston Portal Headhouse
• Euston Cavern Headhouse scheme design (seek • Euston Approaches (inform final design)
events (inform final design) community feedback) construction update events /
• Euston Approaches drop-ins
construction update events
Ongoing engagement: community notices, stakeholder and resident briefings, Commonplace updates, HS2 Helpdesk, HS2
drop-in events and webinars, HS2 newsletters
Tunnel design for Euston Approaches will be available in spring 2022, when we will provide details to property owners and people
living nearby.
04/03/2021 4
Contents
1. Construction programme and key dates 6
2. Piling
5
3. Hampstead Road utilities diversions
4. Site office 2
5. Granby Terrace bridge deconstruction 4
6. Rail closure 7
7. Lorry routes and haul road 3
8. Surveys 4
Construction programme – 6 month lookahead
Jan - Mar Apr - Jun Jul - Sep
Hampstead Road bridge
• Utility diversions on Hampstead • Utility diversions on Hampstead • Utility diversions on Hampstead
Road Road Road
Granby Terrace bridge
• Piling • Piling • Piling
• Granby Terrace • Granby Terrace • Granby Terrace
bridge deconstruction bridge deconstruction bridge deconstruction
• 24/7 rail closure #1 • 24/7 rail closure #2
Euston Throat
• Piling • Piling • Piling
• Substation install • SCS main site offices install
• Please note, dates are subject to change
• We will provide further details ahead of key activities
04/03/2021 6
Euston Throat – key activities to September
Granby Terrace deconstruction Piling
20 Feb to 19 Jul Dec 2020 to May 2024
• Granby Terrace bridge deconstruction of “Span 4” • Granby Terrace bridge – Mar to Nov 2021
• 24/7 working and weekend works during rail closures • Euston Throat – 16 Dec 2020 to Nov 2022
• Hampstead Road bridge – 18 Oct 2021 to May 2024
Main site office install
Haul road by spring
May to summer
• New site access to/from Hampstead Road in Mar
• 5-storey site office on corner of Stanhope Street and
Granby Terrace in May (95 abnormal loads) • Haul road in worksite operational by spring
• We will maximise use of haul road to reduce use of
Stanhope Street site access
• There will be periods when construction activities mean
the haul road cannot be used – so we will use Stanhope
Street gate
Temporary site office
Harrington Street sewer construction works (CSJV) until Aug
Ongoing until summer 2021
• Required due to reduced capacity in existing and planned
• Phased road closures on Harrington Street site offices because of social distancing measures
Hampstead Road utilities diversion (phase 1 of 3)
Feb to Sep
Dates are subject to change. We • Diverting utilities from the footway into the road prior to
will keep you updated. piling next to Cartmel
Euston Throat – key programme dates 04/03/2021 8
Euston Throat
SCS started main works in Euston Approaches Works Planned dates*
between Hampstead Road and London Zoo car Piling – Granby Terrace to Hampstead Road Dec 2020 – Nov 2022
park in April 2020.
Utilities – Hampstead Road Feb – Oct 2021
Euston Throat includes piling, excavation, bridge
and utilities works between Granby Terrace and Granby Terrace bridge deconstruction Feb – Aug 2021
Hampstead Road bridges.
Piling – Granby Terrace Mar 2021 – Nov 2021
Key structures are
Rail closure #1 including vibratory piling 2 Apr – 17 May 2021
• Granby Terrace bridge
• Euston Throat Retained Cut Main site office corner Granby Terrace & Stanhope Street May 2021
• Hampstead Road bridge Rail closure #2 17 Jul – 31 Aug 2021
We will continue to provide updates to the Tower cranes Sep 2021 – May 2026
community ahead of our works at Piling – Hampstead Road Bridge Oct 2021 – May 2024
HS2inCamden.co.uk, where you can also find maps
and content from our online construction updates. Utilities – Granby Terrace and Throat Jun 2022 – 2023
Granby Terrace bridge extension works Mar 2021 – Jul 2026
Hampstead Road bridge extension works at surface Jul – Aug 2023
Jan – Feb 2025
*Dates are subject to change. We will keep you updated.
Utilities – Hampstead Road Nov 2024 – 2025
Hampstead Road bridge extension complete Dec 2025
Piling 04/03/2021 10
Euston Approaches piling summary
Area Location Piling dates No. of piles Piles are concrete and steel structures
that are installed into the ground to
Camden Cutting Parkway – Mornington St Jun 2021 – Aug 2021 152 provide strength, stability and
support to an above-ground structure
or an excavation
Mornington St – Granby Terrace Nov 2020 – Jun 2022 984 The method of piling is determined
by the type of pile required, the
nature of the ground, the location of
surrounding railway structures and
Euston Throat Granby Terrace – Hampstead Road Dec 2020 – Nov 2022 360 residences, and the size of the work
area.
We aim to use the quietest method
possible for each set of works.
Granby Terrace Mar 2021 – Nov 2021 159
Auger-boring and pressed sheet
piling are our preferred methods
however, we will need to use vibratory
Hampstead Road Bridge Oct 2021 – May 2024 472 piling during the April/May Network
Rail closure
TOTAL Euston Nov 2020 – May 2024 2127 For more information please see our
piling factsheet at
Approaches HS2inCamden.co.uk
Dates are subject to change. We will keep you updated.Hampstead Road – utilities diversion 04/03/2021 12
Hampstead Road utilities diversion – 3-phase approach
Feb – Sep 2021
Phase 1 - diversion of utilities
from the footway into the
carriageway for piling works Phase 3
Jun 2022 – 2023 Phase 2
Phase 2 - temporary diversion
around west side retaining wall
and Granby Terrace Bridge
Nov 2024 – 2025
Phase 1
Phase 3 - permanent
reinstatement on Hampstead
Road BridgeSite offices 04/03/2021 14
SCS site offices
Main SCS site offices
• 5 storey offices installed from May to
summer 2021 – Eskdale block previously 8
storeys
• 95 cabins lifted into site from Stanhope
Former buildings
Street by a crane
• Footway closures and parking bay
suspensions on Stanhope Street to provide
a safe exclusion zone
• Operational for duration of project
• Increased security presence once
operational
Temporary site offices
• Operational till Aug
• Acoustic blankets around generators
• Angled lighting to reduce glareGranby Terrace bridge - deconstruction 04/03/2021 16
Granby Terrace bridge deconstruction – Mar to Jul
• Deconstruction of span 4 of Granby Terrace bridge
o Remove bridge surface
o Cut bridge into pieces
o Lift sections away using a 750-t mobile crane
• 24/7 working and weekend works during Network
Rail closures
o Phase 1: weekend of 6-7 Mar and 13-14 Mar
o Phase 2: weekend of 17-18 Apr, 24-25 Apr, 1-2
May, and 8-9 May
o Phase 3: weekend of 5-6 Jun, 12-13 Jun, and 19-
20 Jun
• Cranes and rigs on site
• Large loads during off peak hoursRail closure – 24/7 works
2 April to 17 May
04/03/2021 18Rail closure – 2 April to 17 May 2021
Auger piling
• 24/7 works scheduled for 5 April – 16 May
• Trackside piling works in Camden Cutting south of Mornington Street bridge
• This piling method is no different to that currently ongoing on site
Sheet piling
Sheet piling (vibration method)
• To be installed along the length of the track from Mornington Street bridge to
Parkway tunnels, 5 - 30 April (Monday to Friday 8am – 6pm)
• Designed to stabilise the ground and prevent any horizontal ground Auger piling
movement, protecting the railway
• We will use a vibration sheet-piling method for this work
Granby Terrace bridge – Span 4
• De-construction scheduled for the weekends of 17 April – 15 May
• The end of the bridge will be removed to make way for ground excavation De-construction
and bridge extension works of bridge span 4
04/03/2021 19Rail closure – activities and consented hours
Activity in Euston Approaches Date W/E Working hours
Closure #1 2 Apr – 17 May
Camden Cutting
2 – 4 Apr Y 24/7
Mobilisation & pile mat construction (including concrete)
Piling 8am – 6pm, concreting works to 10pm most
Piling – contiguous 5 Apr – 15 May
weeknights
Breaking out concrete works 19 Apr – 17 May Mon – Fri 8am – 6pm, Sat 8am – 1pm
Capping beam construction work 19 Apr – 17 May Y 24/7
Cavern
Mon – Fri 8am – 6pm
Vibration sheet piling 5 – 30 Apr
Euston Throat Piling 8am – 6pm, concreting works to 10pm most
Piling – contiguous ongoing weeknights
Granby Terrace bridge 17 –18 Apr
De-construction of span 4 (NR weekend possessions) 24 – 25 Apr
Y Sat 9pm – Sun 12pm
1 – 2 May
8 – 9 May
15 – 16 May
Demobilisation. Return of Line E to Network Rail 14 – 17 May Y 24/7
04/03/2021 20Vibration sheet piling
Reason Method Noise and vibration mitigations
Why vibration sheet piling? 1. A small hole is drilled into the ground • Vibration sheet piling will take place
• Due to the proximity of the railway and to limit vibration Mondays to Fridays, 8am to 6pm
underground tunnels, we must use 2. Sheet piles are positioned within the • Noise and vibration monitoring will be
smaller piles than those used hole and dirt is replaced carried out on a regular basis
previously in other areas onsite throughout the works
3. A machine drives piles down to the
• These smaller piles must be installed desired depth using a combination of • We will investigate noise and vibration
using a vibration piling method push-force and vibration alerts as quickly as possible to resolve
• We will continue to use pressed sheet 4. To view a video of this method please the issue and ensure the level of noise
piling (Giken method) wherever search online for ‘Movax sheet piling’ and vibration remains within the
possible agreed limitNetwork Rail works 04/03/2021 22
OFFICIAL
Network Rail HS2 enabling work 10 & 17 April Saturday night
LED Signal head installation
April 2 – 17 May 2021
NO PLANNED WORKS
Sunday 4 April 07:00 to 20:00
Installation of equipment to safely isolate Saturday 15 May 08:30 to Monday 17 May 04:00
overhead electrical lines for piling work Removal of isolation equipment to restore
Sunday 4 April 15:00 to 23:59 working line
Safety checks on electrical isolating equipmentOFFICIAL
Network Rail HS2 Enabling work April 1 – 22 May
Work to take out electrical supply for This electrical work plus work to A mobile elevated working
period of possession, this will take monitor these electrical platform will need to be used
place adjacent to railway line in connections will take place midweek from 4-April for some of
Euston approaches over weekend of overnight midweek from 4-April for the time to check overhead line
3 – 4 April safety reasons.
connections. This is not expected to
be noisy though when mobile it will
need to intermittently sound the
horn for staff safety.
These enabling works have been No other work is currently planned We will advise residents of any
consented by Camden Council and in the Euston approaches over this change to our scheduled work
are included in the Network Rail six week period. plans via the HS2inCamden website
prenotification letter which covers Please note that we may
work from 20 February to 20 May sometimes need to carry out Please sign up for web alerts at
2021 essential maintenance and www.HS2inCamden.co.uk
emergency works on adjacent lines
at short noticeLorry routes and haul road 04/03/2021 25
Approved lorry routes and vehicle numbers per worksite
Compound Worksite HS2 Act forecast SCS forecast
2-way movements 2-way movements
(avg peak busy period) (avg peak busy period)
Park Village East (north) 90-136 20-30
cavern
Carriage Shed & Park Village 160-250
East
300-450
Granby Terrace Overbridge 260-280
A400 Hampstead Road 30-40
Overbridge
ZSL Lorry Holding Area No forecast of HGV’s 130-190
given within ES
• Vehicles use permitted routes during their journey to and from sites
• Vehicles prioritise main roads where possible
• There are times we need to deliver large loads overnight or early
morning for safety
• Forecasts above are 2-way movements to and from our worksites based
on calculations in the HS2 Act
• We always aim to minimise the number of construction vehicles by re-
using excavated materials on site, carefully planning our logistics and
using best practicable methods for our works
• We are continually reviewing our practices to reduce the impacts of our
works
04/03/2021 26Haul road Hampstead Road access • A haul road with access on/off Hampstead Road will help reduce HS2 construction traffic on residential streets • The haul road will change location over time to enable vehicles to continue using it whilst safely avoiding large-scale machinery and construction in our narrow worksite • We will use the haul road as often as possible, however there will be periods where there is insufficient space to keep it in use • When we cannot use the haul road, we will use approved lorry routes to access our worksite via Stanhope Street gate. • Haul road will be in use from end of Summer 2021 as a throughfare for site traffic 04/03/2021 27
Survey's update 04/03/2021 28
Pre-condition surveys
• Pre-condition surveys are visual inspections by an independent accredited surveyor to capture the existing condition of a proper ty
• Required for all properties along the HS2 route within the zone for predicted ground movement of more than 1mm for listed buildings
and more than 10mm for non-listed buildings
• These are the same as the surveys referred to in the C3 Information Paper regarding Settlement Deeds (but if completed earlier than the 3-6
months immediately before excavation works, we may need to refresh them, by agreement)
• In the case of any future claims for damage, the survey will provide an independent baseline record against which to compare condition
before and after our works – this will assist both parties by enabling a quicker assessment and claims process by reducing the need to prove
the damage was not pre-existing
• Copies of the report will be available on request and are normally issued just to property owners but will also be provided to long-term
leaseholders if requested
What is covered
• Walls and floors
o Cracks, sign of movement, vibration, deformation, damage and displacement to the property structure and fabric
o Bulges, include size and location
o Water damage or ingress
o Internal and external finishes
• Tree positions, types and diameters
04/03/2021 29COVID - 19
We are continually reviewing the works of our surveying team in line with Government and Public Health England (PHE) advice on dealing with
COVID-19.
The Government’s current Covid-19 strategy makes clear that construction activity can continue as long as it complies with this guidance and
those working in construction have been actively encouraged to go to work.
Several measures will be in place to protect residents and members of our surveying team. These will at least include
• when making contact we will confirm with you whether you are happy for us to attend and that that there are no health issues with people
that live in your home. We will also confirm that there are no health issues within our team
• we will keep staff numbers to a minimum within your property
• before entering any property, we will sanitise our hands and any equipment and we will wear appropriate personal protective equipment
• where possible, windows will be opened while our surveyors are working for better ventilation
• all surveyors will receive weekly COVID-19 testing
• all surveyors will carry laser thermometers and check their temperature before entering each property
• we will notify residents should any of our surveyors test positive within two weeks of entering their property
04/03/2021 30Compensation and repairs
Protection
The High Speed Rail (London – West Midlands) Schedule 2
Act 2017 • Allows HS2 to strengthen/support a structure in the course of carrying out
works
• Automatically protects home-owners in the unlikely event your property is
damaged by our works • Allows HS2 to leave in place (temporary of permanently) any materials
associated with the strengthening/support works
• Allows for owners/occupiers to be compensated for any loss they may suffer
as a result of the support/strengthening works
• Any disputes or disagreements regarding compensation are determined in
accordance with Part 1 of the Land Compensation Act 1961.
Using Crossrail and Channel Tunnel Rail Link
process – a tested mechanism for settling minor,
construction related residential, business or
Claims agricultural claims for which HS2 is responsible
Two ways to deal with compensation and claims under Schedule 2:
Overseen by independent Resident’s
• dedicated compensation claims service via LPClaims@hs2.org.uk Commissioner whose job it is to make sure HS2
keeps its promises and to mediate and respond
• parallel Small Claims Scheme (information Paper C10).
to complaints.
04/03/2021 31Information and enquiries
• Newsletters, community notices, updates and further information available at HS2inCamden
• Euston Approaches works map at HS2inCamden is updated weekly to keep you informed about
current and upcoming works
• For all enquiries, compliments or complaints please contact the HS2 Helpdesk
• Freephone 08081 434 434
• Email HS2enquiries@hs2.org.uk
04/03/2021 32You can also read
