Automatic Door Systems Price List 16 Effective June 1, 2021
Automatic Door Systems Table of Contents
Automatic Door Systems
Table of Contents
Terms & Conditions 3–5
Contacts 6
Automatic Sliding Doors
ESA100, ESA200 & ESA300 Automatic Sliding Doors 7
ESA100T, ESA200T & ESA300T Telescopic Automatic Sliding Doors 8
ESA200-HP & ESA300-HP Hurricane Impact Rated Automatic Sliding Door 9
ESA400 & ESA400T Fine Frame Automatic Sliding Doors 10
ESA500 & ESA500T All Glass Automatic Sliding Doors 11
iRevive Automatic Sliding Door Conversion Kit 12
ESA Series Options 13–15
MAGNEO Magnetic Drive Power Assisted Manual Sliding Doors 16
MAGNEO Power Assisted Manual Door Options 17
ICU Manual Sliding Doors
ICU200 & ICU300 Manual Sliding Doors 18
ICU200T & ICU300T Telescopic Manual Sliding Doors 19
ICU1200 Combination Manual Bi-Fold/Swing Doors 20
ICU Series Manual Door Options 21
ESA & ICU Finish Options
Wet Paint & Powder Coat 22
Anodize & Clad 23–24
ESA 500 Finish Options 25
ED Series Swing Door Operators
Narrow 4"× 6" Header 26–27
Fine Cover 28–29
ED-OHC Overhead Concealed (Side Load) 30–31
ED-IG Concealed In Ground Operator 32
ED Series Swing Door Operators Options 33-34
ED Series Swing Door Operators Finish Options
Wet Paint, Powder Coat & Anodize 35
Clad 36
Automatic Door System Accessories
Sliding Door Accessories and Individual Components 37
Swing Door Sensor Packages 38–39
Sensors and Individual Components 40–46
Crane Revolving Doors 47
2 June 1, 2021 Automatic Door Systems Price List 16Terms & Conditions Automatic Door Systems Terms & Conditions 1. Price & Payment Terms. List and quoted prices on the products are exclusive of all sales, excise, and other taxes, and exclusive of freight, installation, handling, and storage charges, any or all of which, as applicable, will be added to the invoice as separate charge(s), any or all of which, as applicable will be added to the invoice as a separate charges to the paid by the Buyer or otherwise charged as indicated in these Terms and Conditions. Prices are effective for all purchase orders received from Buyer within 60 days of the date of dormakaba USA’s formal price quotation, and thereafter subject to changes. Unless otherwise agreed to in writing by dormakaba USA, all prices quoted are exclusive of transportation and insurance costs, duties, and all taxes, including, but not limited to, federal, state, provincial, and local taxes, excise, value added, goods and services taxes and any other taxes. Buyer agrees to pay these taxes unless Buyer has provided dormakaba USA with an exemption resale certificate in the appropriate form for the jurisdiction of Buyer’s place of business and any jurisdiction to which Products are to be directly shipped hereunder, or unless the sale is otherwise exempt from these taxes. Buyer agrees to indemnify and hold dormakaba USA harmless for any liability for tax in connection with the sale, as well as the collection or withholding thereof, including penalties and interest thereon. When applicable, transportation and taxes shall appear as separate items on dormakaba USA’s invoice, Pricing for undeliverable Product may be increased in the event of any increase in dormakaba USA’s cost, change in market conditions or any other causes beyond dormakaba USA’s Reasonable control. dormakaba USA reserves the right to increase prices in cases where modifications requested by the Buyer give rise to additional costs Verbal price estimates are not binding. Buyer agrees to pay the total amount shown as due on each invoice within 30 days after the date of such invoice notwithstanding any repairs, corrections or adjustments that may need to be made. Special orders for products pursuant to Buyer specifications are subject to payment of 50% of quoted price at time of acceptance of purchase order. Invoices will be dated as of date of shipment or installation except if products are stored at Buyer’s request for more than 30 days beyond completion of their manufacture, in which case, invoices will be dated as of the ate of product completion. dormakaba USA shall reserve the right to charge interest at a rate not to excess of 18% per annum (but in no event more than the amount permitted by applicable law) upon any sum not paid by the due date. dormakaba USA shall be entitled to collect from Buyer for all expenses of collection, including attorneys’ fees. 1. Ordering Information. All orders submitted to dormakaba USA, Inc. must be submitted on the product specific Order Form. In some situations, a sketch or drawing may be helpful in determining order requirements and assist in reducing ordering errors. Sketches or drawings are required for all Special Engineering requests. A sales order acknowledgment will be forwarded to the Buyer for all accepted orders. The sales order acknowledgement must be reviewed by the Buyer and any error corrections or revisions which must be made shall be submitted to dormakaba USA in writing within three working days of order acknowledgment issuance. Verbal orders will not be accepted. All orders are subject to acceptance by dormakaba USA, Inc. It is the sole responsibility of the Buyer to determine product suitability in accordance with codes, standards or regulations as required by the Authority Having Jurisdiction (AHJ). dormakaba USA does not represent or warrant that every product complies with every code, standard or regulation in every locale or Authority Having Jurisdiction (AHJ) except as specifically stated in current technical documentation. 2. Delivery. All shipments are F.O.B. dormakaba USA's point of manufacture. All freight costs and risk of loss in transit are borne by the Buyer. Dormakaba USA makes no representation or commitment as to the time deliveries and/ or installation can be made against this order. Estimated shipment dates and times are a guideline only. dormakaba shall not be liable for any loss, damage, injury, failure, delay in performance, delivery or installation caused by strikes, riots, war, governmental restrictions and regulations, acts of God, or any other resultant conditions beyond the reasonable control of dormakaba USA. Damaged freight is the sole responsibility of the Buyer. It is recommended that the Buyer follow guidelines as provided by the freight carrier, and that visible or suspected freight damage be indicated on the bill of lading at the time of delivery, and claims be filed with the freight carrier within five working days of receipt to avoid potential claim rejection. Additional freight insurance is available upon Buyers request and will be provided at the Buyer's expense. Automatic Door Systems Price List 16 June 1, 2021 3
Automatic Door Systems Terms & Conditions Continued 3. Cancellations and Change Orders. Accepted purchase orders may be cancelled or changed only with dormakaba’s written consent and upon terms that will indemnify dormakaba against all losses, costs, and damages it sustains directly or indirectly related to the cancellation or change. Typical restocking charges are 20%. All special orders are non-cancellable and non-refundable. Changes to special orders may request in a price increase. 4. Inspection and Rejection. All products shall be examined by Buyer upon receipt of Buyer. If products are damaged upon receipt or do not conform to agreed specifications, products shall not be moved from point of delivery, and a written claim must be filed with dormakaba USAA within 5 business days of date of delivery. Upon receipt of a written claim for damage or nonconforming products, dormakaba USA will notify Buyer in writing if products are to be returned, or if products will be repaired or if a credit will be issued. Whether products are returned or repaired or whether a credit is issued, is with dormakaba’s full and complete discretion, subject to the limited warranty set forth below, and shall be Buyer’s sole remedy at law or equity. dormakaba USA has no control over installation locations or conditions under which its products are used, and specifically excludes responsibility for the applicability, adequacy or sufficiency of any device to perform in any manner not in strict accordance with manufacturers directives for the original purpose for which the product is intended, and applicable codes and standards governing product installation, application, speeds, forces and behavior, or for any 5. Title Upon issuance of Buyer’s purchase order and dormakaba USA’s acceptance thereof, Buyer shall be considered to have granted to dormakaba Inc. a security interest in all products delivered to secure the payment of invoiced amounts due. Buyer agrees to execute and deliver to dormakaba USA, upon request, UCC financing statements and other documents reasonably requested by dormakaba USA to perfect its security interest in the products. 6. Limited Warranty dormakaba USA, Inc. (dormakaba USA) warrants to Buyer (Distributor or Dealer and its agents, employees, successors, installers, technicians, and/or assigns) all products they manufacture to be free from defects in material and workmanship, under normal use and service. THIS WARRANTY IS MADE EXPRESSLY IN LIEU OF ANY OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE OR NON-INFRINGEMENT AND IN LIEU OF ANY OTHER OBLIGATIONS OR LIABILITIES ON THE PART OF DORMAKABA USA AND DORMAKABA USA NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO ASSUME FOR IT ANY OTHER LIABILITY OR OBLIGATIONS IN CONNECTION WITH THE SALE OF SUCH PRODUCTS BY THE BUYER. Warranty Period: ED50, ED100 and ED250 Swing Door Operators shipped prior to November 13, 2017 are warranted for 12 months from date of shipment. ED50, ED100, ED250, ED-IG and ED-OHC Swing Door Operators shipped on or after November 13, 2017 are warranted for 24 months from date of shipment. ESA100, ESA200, ESA300, ESA400 and ESA500 Automatic Sliding Doors (and sub-models), ICU Doors, and MAGNEO products are warranted for 12 months from date of shipment. iRevive Sliding Door Conversion Kits are warranted for 18 months from date of shipment. Accessories, sensors, push plates, switches, hardware, service parts, components, etc., carry a 12-month warranty from date of shipment. All standard or custom finish warranties are covered under the applicable manufacturer’s warranty in effect at time of purchase. For specific finish warranties, contact customer service. Finishes include, but are not limited to, anodized, powder coating, wet paint, and all clad materials. All products not specifically defined herein are warranted for one year from date of shipment. Extended product warranties are available at additional cost for products installed in the United States and Canada. 4 June 1, 2021 Automatic Door Systems Price List 16
Terms & Conditions Automatic Door Systems Terms & Conditions Continued Warranty for all products shipped or installed outside the United States or Canada is superseded by a limited warranty period of 12 months from date of manufacture. Limitations: Dormakaba USA's obligation under this warranty is limited to repair, replacement or issuing credit for any items or parts proven to be other than warranted, which shall be returned to dormakaba USA with transportation charges prepaid by the shipper and which after examination, prove to be defective. dormakaba USA retains the sole right to determine whether such parts shall be repaired or replaced, or whether credit shall be issued. dormakaba is not responsible for defects or damages caused by failure to follow manufacturer’s instructions and directives, normal use, wear and tear, water damage, variations or disruptions in the power supply, transient voltage, consumable materials, vandalism, civil disorder, fires, storms, floods, acts of God, misuse or abuse. dormakaba USA is not responsible for labor, travel, or other costs and charges arising from product replacement, adjustment, repair or any other work, which are the sole responsibility of the Buyer and are not covered by the terms of this warranty. In no event shall dormakaba USA be liable to Buyer for any incidental, consequential, liquidated, exemplary, punitive, or other indirect damages, including without limitation, profits or loss of use damages arising out of the manufacture, sale, supplying, or failure or delay in supplying the products or the services related thereto, whether based upon warranty, contract, tort, strict liability, or otherwise, should not exceed the price paid for the product or service. Said warranty shall not apply to such products which shall have been installed, altered, or repaired by any person not expressly authorized in writing for such purpose by dormakaba USA, or subjected to misuse, negligence, or accident. dormakaba is not responsible for defects, damages, injuries or any condition resulting from alteration by any company or entity other than dormakaba. In the event that the Buyer, its agents, employees, successors, installers, technicians, owner, and/or assigns tampers with, misuses, removes any parts, or adds any parts or equipment, Buyer agrees to indemnify, save and hold harmless dormakaba, its agents, employees, successors, and/or assigns, from any and all liability, damages, or losses, including reasonable attorney’s fees, arising out of, or incidental to, the aforementioned conduct. 7. Controlling Provisions. To the extent there is a conflict between these Terms and Conditions of Sale and Buyer’s purchase order, these Terms and Conditions of Sale shall be controlling. 8. Termination. Each purchase order issued by Buyer in connection with dormakaba USA’s quotation is subject to acceptance by dormakaba. If Buyer defaults in the payment of any sum due dormakaba USA or commits any other breach of any of the terms or conditions herein or if there is a material change in the ownership or financial condition of the Buyer which is considered unsatisfactory to dormakaba USA, dormakaba USA may, without prejudice to any other rights which may have accrued or which may accrue to it, whether under contract or at law or equity, refuse to accept any purchase order and may terminate any order immediately. 9. Governing law. Any contract between the parties shall be construed and governed in accordance with the laws of the state of Indiana. 10. dormakaba USA’s property. All specifications, drawings, tools, jigs, dies, fixtures, materials, equipment, and other items furnished by dormakaba USA, or at a cost of which is charged against this order shall be confidential and shall be and remain the property of dormakaba USA. The sale of products by dormakaba to Buyer shall not be construed as a license of any trade secret rice, trademark, patent, or copyright. 11. Indemnification. Buyer will indemnify, defend, and hold harmless (including payment of reasonable attorneys’ fees and court costs), dormakaba USA’s and its employees, agents, and permitted assigns against all liability to third parties that (1) arises from Buyer’s negligence or willfully, wrongful, wanton, or reckless conduct that results in death or bodily injury or damage to real or tangible personal property; or (2) arises from or in connection with Buyer’s use or resale of any product furnished under this Agreement that violates any third party’s trade secrets, proprietary information, trademark, copyright or patent rights. Automatic Door Systems Price List 16 June 1, 2021 5
Automatic Door Systems Contacts Contacts Automatics Sales Support 844-773-2669 automaticssupport.us@dormakaba.com Customer Service Orders/ Acknowledgements 877-367-6211 automaticorders.us@dormakaba.com Technical Services 800-523-8483 techserv.us@dormakaba.com Crane Revolving Doors Please contact Crane Revolving Doors directly for technical assistance and all revolving door quote requests. Crane Revolving Doors 924 Sherwood Drive Lake Bluff, IL 60044 800-942-7263 salescranedoor.us@dormakaba.com 6 June 1, 2021 Automatic Door Systems Price List 16
ESA100/200/300 Automatic Sliding Doors Automatic Door Systems
ESA100, ESA200 & ESA300 Automatic Sliding Doors
PACKAGE WIDTH PACKAGE WIDTH
PACKAGE HEIGHT
PACKAGE HEIGHT
HEADER HEIGHT
HEADER HEIGHT
BREAKOUT WIDTH BREAKOUT WIDTH
INTERIOR INTERIOR
EXTERIOR EXTERIOR
EMERGENCY EMERGENCY
ESA300 SHOWN BREAKOUT TYP. BREAKOUT TYP.
Model/Part # Product Single/Bi-Part Standard Handing Configurations List Price $
Single/Pair
ESA100 Automatic Sliding Door Single [O-X] [X-O] [P-X] [X-P] 4,730
ESA100 Automatic Sliding Door w/Transom Single [O-X] [X-O] [P-X] [X-P] 5,245
ESA200 Automatic Sliding Door Single [O-SX] [SX-O] [P-SX] [SX-P] 4,841
ESA200 Automatic Sliding Door w/Transom Single [O-SX] [SX-O] [P-SX] [SX-P] 5,355
ESA300 Automatic Sliding Door Single [SO-SX] [SX-SO] 4,925
ESA300 Automatic Sliding Door w/Transom Single [SO-SX] [SX-SO] 5,450
ESA100 Automatic Sliding Door Bi-Part [O-X-X-O] [P-X-X-P] 6,479
ESA100 Automatic Sliding Door w/Transom Bi-Part [O-X-X-O] [P-X-X-P] 7,114
ESA200 Automatic Sliding Door Bi-Part [O-SX-SX-O] [P-SX-SX-P] 6,620
ESA200 Automatic Sliding Door w/Transom Bi-Part [O-SX-SX-O] [P-SX-SX-P] 7,250
ESA300 Automatic Sliding Door Bi-Part [SO-SX-SX-SO] 6,736
ESA300 Automatic Sliding Door w/Transom Bi-Part [SO-SX-SX-SO] 7,355
Base Package Prices Include:
• Finishes: Clear or Dark Bronze Anodized • 4" Bottom Rail • Maximum Security Two-Point Mortise Lock
• Package Height up to 8'-0" (96") [Including 3/4" Wide Glass Stop] • 1/4" Glass Stops in Door Panels & Transom
• Transom Height up to 12'-0" (144") • 1-3/4" × 4-1/2" Double Pocket Jamb Tubes • Two Combination Motion/Presence Sensors
• Package Width: • Beveled Threshold: • Self-Learning & Self-Monitoring
[Single Slide up to 9'-0"] (108") [ESA300 4-1/2" × 1/2"] Microprocessor Controller
[Bipart Slide up to 14'-0"] (168") [ESA200 3-1/4" × 1/8"] • Jamb Mounted Rocker Switch Panel:
• 2-5/8" Narrow Stile Door Panels [ESA100 3-1/4" × 1/8"] [Auto-Off – Hold Open]
[Including 3/4" Wide Glass Stop] • One 1-3/4" × 4-1/2" Vertical Transom Mullion [Two Way Traffic – Exit Only]
• 3-1/4" Muntin Mounted at 41.75" All Panels • Surface Mounted Guide System [Full Open – Partial Open]
[Including 3/4" Wide Glass Stop] • Brush Weather Stripping
For additional options, please refer to ESA Series Options (see pages 13-14).
Automatic Door Systems Price List 16 June 1, 2021 7Automatic Door Systems ESA100T/200T/300T Automatic Sliding Doors
ESA100T, ESA200T & ESA300T Telescopic Automatic Sliding Doors
OPTIONAL
TRANSOM PACKAGE WIDTH PACKAGE WIDTH
OPTIONAL
TRANSOM
PACKAGE HEIGHT
PACKAGE HEIGHT
HEADER HEIGHT
HEADER HEIGHT
BREAKOUT WIDTH BREAKOUT WIDTH
EMERGENCY
EXTERIOR BREAKOUT EXTERIOR
TYP. EMERGENCY
BREAKOUT
ESA300T shown TYP.
Model/Part # Product Single/Bi-Part Standard Handing Configurations List Price $
Single/Pair
ESA100T Telescopic Automatic Sliding Doors Single Slide [O-X-X] [X-X-O] 8,138
ESA100T Telescopic Automatic Sliding Doors w/Transom Single Slide [O-X-X] [X-X-O] 8,652
ESA200T Telescopic Automatic Sliding Doors Single Slide [O-X-SX] [SX-X-O] 8,138
ESA200T Telescopic Automatic Sliding Doors w/Transom Single Slide [O-X-SX] [SX-X-O] 8,652
ESA300T Telescopic Automatic Sliding Doors Single Slide [SO-SX-SX] [SX-SX-SO] 8,138
ESA300T Telescopic Automatic Sliding Doors w/Transom Single Slide [SO-SX-SX] [SX-SX-SO] 8,652
ESA100T Telescopic Automatic Sliding Doors Bi-Part Slide [O-X-X-X-X-O] 10,952
ESA100T Telescopic Automatic Sliding Doors w/Transom Bi-Part Slide [O-X-X-X-X-O] 11,576
ESA200T Telescopic Automatic Sliding Doors Bi-Part Slide [O-X-SX-SX-X-O] 10,952
ESA200T Telescopic Automatic Sliding Doors w/Transom Bi-Part Slide [O-X-SX-SX-X-O] 11,576
ESA300T Telescopic Automatic Sliding Doors Bi-Part Slide [SO-SX-SX-SX-SX-SO] 10,952
ESA300T Telescopic Automatic Sliding Doors w/Transom Bi-Part Slide [SO-SX-SX-SX-SX-SO] 11,576
Base Package Prices Include:
• Finishes: Clear or Dark Bronze Anodized • 3-1/4" Muntin Mounted at 41.75" All Panels • Maximum Security Two Point Mortise Lock
• Package Height up to 8'-0" (96") [Including 33/4" Wide Glass Stop] • Two Combination Motion/Presence Sensors
• Transom Height up to 12'-0" (144") • 4" Bottom Rails • Self-Learning & Self-Monitoring Microprocessor
• Package Width: [Including 3/4" Wide Glass Stop] Controller
[Single Slide up to 10'-0"] (120") • 1/4" Glass Stops in Door Panels & Transom • Jamb Mounted Rocker Switch Panel:
[Bipart Slide up to 14'-0"] (168") • 2" × 6" Smooth Jamb Tubes [Auto-Off – Hold Open]
• 2-5/8" Narrow Stile Door Panels • One 1-3/4" × 4-1/2" Vertical Transom Mullion [Two Way Traffic – Exit Only]
[Including 3/4" Wide Glass Stop] • Full Width Surface Mounted Guide System [Full Open – Partial Open]
• Brush Weather Stripping
ESA Telescopic Automatic Sliding Door Options
ESA400T available (see page 10)
Wider telescopic packages may require the use of the Optex X-ZONE sensor to comply with ANSI A156.10 requirements
For additional options, please refer to ESA Series Options (see pages 13–14).
8 June 1, 2021 Automatic Door Systems Price List 16ESA200-HP/300-HP Automatic Sliding Doors Automatic Door Systems
ESA200-HP & ESA300-HP Hurricane Impact Rated Automatic Sliding Doors
PACKAGE WIDTH PACKAGE WIDTH
INCOMING
120VAC
PACKAGE HEIGHT
PACKAGE HEIGHT
BREAKOUT WIDTH BREAKOUT WIDTH
INTERIOR INTERIOR
EXTERIOR EXTERIOR
EMERGENCY
BREAKOUT TYP. EMERGENCY
ESA300-HP SHOWN BREAKOUT TYP.
Model/Part # Product Single/Bi-Part Standard Handing Package List Price $
Single/Pair Configurations Width
ESA200-HP Hurricane Impact Rated Automatic Sliding Doors Single [O-SX] [SX-O] 9'-0" 7,313
ESA300-HP Hurricane Impact Rated Automatic Sliding Doors Single [SO-SX] [SX-SO] 9'-0" 7,455
ESA200-HP Hurricane Impact Rated Automatic Sliding Doors Bi-Part [O-SX-SX-O] 14'-0" 9,602
ESA300-HP Hurricane Impact Rated Automatic Sliding Doors Bi-Part [SO-SX-SX-SO] 14'-0" 9,744
Base Package Prices Include:
• Finishes: Clear or Dark Bronze Anodized • Security Glass Stops in Door Panel (Required)
• Maximum Package Height up to 8'-8" (104") [Consult factory for glass types based on application
• Maximum Package Width: requirements.]
[Single Slide up to 9'-0"] (108") • MS 3 Point Mortise Lock/5 Point for Bi-Parts (Required)
[Bipart Slide up to 14'-0"] (168") • Surface Mounted Guide System
• 4-1/2" Medium Stile Door Panels (Required) • Vinyl Weather Stripping
[Including 3/4" Wide Glass Stop] • Two Combination Motion/Presence Sensors
• 7-1/2" Bottom Rails • Self-Learning & Self-Monitoring Microprocessor Controller
[Including 3/4" Wide Glass Stop] • Jamb Mounted Rocker Switch Panel:
• 1/2"× 7" Beveled Threshold (Required) [Auto-Off – Hold Open]
• 1-3/4" × 4-1/2" Smooth Jamb Tubes (Required) [Two Way Traffic – Exit Only
[Full Open – Partial Open]
ESA 200-HP & ESA300-HP Options List Price $
Surface Applied Muntins - Per Panel 137
Concealed Vertical Road Exit Device w/ Keyed Exterior Escutcheon 819
For applicable options, please refer to ESA Series Options (see pages 13–14).
Automatic Door Systems Price List 16 June 1, 2021 9Automatic Door Systems ESA400 Fine Frame Automatic Sliding Doors
ESA400 & ESA400T Fine Frame Automatic Sliding Doors
PACKAGE WIDTH PACKAGE WIDTH
OPTIONAL OPTIONAL
TRANSOM TRANSOM
PACKAGE HEIGHT
HEADER HEIGHT
HEADER HEIGHT
BREAKOUT WIDTH BREAKOUT WIDTH
INTERIOR
INTERIOR
EXTERIOR
EMERGENCY EXTERIOR EMERGENCY
BREAKOUT TYP. BREAKOUT TYP.
Model/Part # Product Single/Bi-Part Standard Handing Configurations Package List Price $
Single/Pair Width
ESA400 Fine Frame Automatic Sliding Doors Single [SO-SX] [SX-SO] 7'-0" 7,308
ESA400 Fine Frame Automatic Sliding Doors w/Transom Single [SO-SX] [SX-SO] 7'-0" 7,786
ESA400 Fine Frame Automatic Sliding Doors Single [SO-SX] [SX-SO] 8'-0" 7,534
ESA400 Fine Frame Automatic Sliding Doors w/Transom Single [SO-SX] [SX-SO] 8'-0" 8,017
ESA400T Fine Frame Automatic Sliding Doors Telescopic [SO-SX-SX] [SX-SX-SO] 10'-0" 12,311
ESA400T Fine Frame Automatic Sliding Doors w/Transom Telescopic [SO-SX-SX] [SX-SX-SO] 10'-0" 13,067
ESA400 Fine Frame Automatic Sliding Doors Bi-Part [SO-SX-SX-SO] 10'-0" 9,104
ESA400 Fine Frame Automatic Sliding Doors w/Transom Bi-Part [SO-SX-SX-SO] 10'-0" 9,686
ESA400 Fine Frame Automatic Sliding Doors Bi-Part [SO-SX-SX-SO] 12'-0" 9,608
ESA400 Fine Frame Automatic Sliding Doors w/Transom Bi-Part [SO-SX-SX-SO] 12'-0" 10,190
ESA400 Fine Frame Automatic Sliding Doors Bi-Part [SO-SX-SX-SO] 14'-0" 10,054
ESA400 Fine Frame Automatic Sliding Doors w/Transom Bi-Part [SO-SX-SX-SO] 14'-0" 10,532
ESA400T Fine Frame Automatic Sliding Doors Telescopic [SO-SX-SX-SX-SX-SO] 14'-0" 15,876
ESA400T Fine Frame Automatic Sliding Doors w/Transom Telescopic [SO-SX-SX-SX-SX-SO] 14'-0" 15,876
Base Package Prices Include:
• Finishes: Clear or Dark Bronze Anodized • 4-1/2" × 1/2" Beveled Threshold • Vinyl & Brush Weather Stripping
• Package Height up to 8'-0" (96") • 1-3/4" × 4-1/2" Double Pocket Jamb Tube • Self-Learning & Self-Monitoring
• Transom Height up to 12'-0" (144") • One 1-3/4" × 4-1/2" Vertical Transom Mullion Microprocessor Controller
• Factory Glazed Panels with 3/8" Clear • 1/4" Glass Stops in Transom • Jamb Mounted Rocker Switch Panel:
Tempered Glass • Single Point Dead Bolt Floor Locks in Active [Auto-Off – Hold Open]
• 1" Nominal Fine Frame Stile Door Panels Panels [Two Way Traffic – Exit Only]
• 3-1/2" Bottom Rails • Two Combination Motion/Presence Sensors [Full Open – Partial Open]
ESA400 Fine Frame Automatic Sliding Door Options List Price $
For all other applicable options,
Package Width Greater than Standard (14'-0" Bi-Part) – Per Foot or Fraction Thereof * 551
please refer to ESA Series
Header Height Greater than 8'-0" (96") For Single Slide – Per Foot or Fraction Thereof * 383 Options (see pages 13–14).
Header Height Greater than 8'-0" (96") For Bi-Part Slide – Per Foot or Fraction Thereof * 520
DG1000 Exit Device – Per SX Panel 6,374
* Dimensions greater than standard
Low Iron Glass - Per Panel (Contact Customer Service for Quote) Quote Only
package sizes are subject to
Heat Soaked Glass - Per Panel (Contact Customer Service for Quote) Quote Only factory review and approval to
ensure reliable breakout.
3/8" Tinted or Etched Glass – Per Panel Quote Only
ESA400 Automatic Sliding Doors are factory glazed and crated for shipment. Price includes crating for
destinations within the continental United States, Canada and Mexico. Crating to international
destinations and locations, provinces, or territories outside the continental United States, Canada or
Mexico, as well as Air Freight shipments, are not included and are by quote only.
10 June 1, 2021 Automatic Door Systems Price List 16ESA500 All Glass Automatic Sliding Doors Automatic Door Systems
ESA500 & ESA500T All Glass Automatic Sliding Doors
PACKAGE WIDTH PACKAGE WIDTH
OPTIONAL
TRANSOM
PACKAGE HEIGHT
PACKAGE HEIGHT
HEADER HEIGHT
HEADER HEIGHT
BREAKOUT BREAKOUT
WIDTH WIDTH
INTERIOR INTERIOR
EXTERIOR EMERGENCY EXTERIOR
EMERGENCY
BREAKOUT TYP.
BREAKOUT TYP.
Model/Part # Product Single/Bi-Part Standard Handing Package List
Single/Pair Configurations Width Price $
ESA500 All Glass Automatic Sliding Doors Single [O-SX] [SX-O] 7'-0" 7,182
ESA500 All Glass Automatic Sliding Doors w/Transom Single [O-SX] [SX-O] 7'-0" 7,660
ESA500 All Glass Automatic Sliding Doors Single [O-SX] [SX-O] 7'-6" 7,392
ESA500 All Glass Automatic Sliding Doors Single [O-SX] [SX-O] 7'-6" 7,870
ESA500 All Glass Automatic Sliding Doors Single [O-SX] [SX-O] 8'-0" 7,686
ESA500 All Glass Automatic Sliding Doors w/Transom Single [O-SX] [SX-O] 8'-0" 8,164
ESA500 All Glass Automatic Sliding Doors Bi-Part [O-SX-SX-O] [P-SX-SX-P] 10'-0'' 9,193
ESA500 All Glass Automatic Sliding Doors w/Transom Bi-Part [O-SX-SX-O] [P-SX-SX-P] 10'-0'' 9,781
ESA500 All Glass Automatic Sliding Doors Bi-Part [O-SX-SX-O] [P-SX-SX-P] 12'-0" 9,807
ESA500 All Glass Automatic Sliding Doors w/Transom Bi-Part [O-SX-SX-O] [P-SX-SX-P] 12'-0" 10,390
ESA500 All Glass Automatic Sliding Doors Bi-Part [O-SX-SX-O] [P-SX-SX-P] 14'-0" 10,416
ESA500 All Glass Automatic Sliding Doors w/Transom Bi-Part [O-SX-SX-O] [P-SX-SX-P] 14'-0" 10,994
ESA500T All Glass Telescopic Automatic Sliding Door Single [O-X-SX] [SX-X-O] 9'-0" 11,424
ESA500T All Glass Telescopic Automatic Sliding Door w/Transom Single [O-X-SX] [SX-X-O] 9'-0" 12,117
ESA500T All Glass Telescopic Automatic Sliding Door Bi-Part [O-X-SX-SX-X-O] 16'-0" 13,062
ESA500T All Glass Telescopic Automatic Sliding Door w/Transom Bi-Part [O-X-SX-SX-X-O] 16'-0" 13,860
Base Package Prices Include:
• Finishes: Clear or Dark Bronze Anodized • 6" Sight Line Top & Bottom Rails • Two Combination Motion/Presence Sensors
• Package Height up to 8'-0" (96") • 4-1/2" × 1/2" Beveled Threshold • Self-Learning & Self-Monitoring
• Transom Height up to 12'-0" (144") • 1-3/4" × 4-1/2" Double Pocket Jamb Tubes Microprocessor Controller
• Glass Clamp Rail System • One 1-3/4" × 4-1/2" Vertical Transom Mullion • Jamb Mounted Rocker Switch Panel:
[For 1/2" Tempered Glass] • 1/4" Glass Stops in Transom [Auto-Off – Hold Open]
[Glass Center Set within Each Rail] • Single Point Dead Bolt Floor Locks in [Two Way Traffic – Exit Only]
[Glass Not Included] SX Panels [Full Open – Partial Open]
• Brush Weather Stripping
ESA500 All Glass Automatic Sliding Door Options
For all other applicable options,
Product List Price $
please refer to ESA Series
Header Height Greater than 8'-0" for Single & Bi-Part Slide – Per Foot or Fraction Thereof * 22 Options (see pages 11–12).
Maximum 10'-0" (depending on unit width to maintain reliable breakout)
* Dimensions greater than standard
Package Width Exceeds 8'-0" (96") for Single or 14'-0" (168") for Bi-Part – Per Foot or 357 package sizes are subject to
Fraction Thereof * factory review and approval to
ensure reliable breakout.
10" bottom rail – Per Panel 168
Automatic Door Systems Price List 16 June 1, 2021 11Automatic Door Systems iRevive Converison Kit
iRevive Automatic Sliding Door Conversion Kit
Intelligent iRevive benefits
• iRevive technology meets ANSI 156.10 standard for monitoring
• 18-month Warranty on the motor control and gear box
• Improves sliding door performance, safety, and reliability
• Cost-effective alternative to complete door replacement
• Compatible with:
– Stanley DuraGlide 2-panel Single Slide and 4-panel Bi-part up to 18' wide
– Horton 2001, 2003, 2500, 2-panel Single Slide and 4-panel Bi-part up to 18' wide
Indicates Stock item (other items available special order)
Model/Part # Description List Price $
DS1869-010 ESA II iRevive conversion kit 2,699
Complete with ESA II standard components:
• Motor
• Control board
• Power Supply
• Belt
• Return pulley
• 2 monitored combination motion presence sensors
• Wiring diagram to existing switches
• ANSI decals
• All required mounting hardware and brackets
DS2890-010 ESA II Rechargeable Battery 189
Function module in housing (emergency closing, airlock control, etc…)
DX2889-010 ESA Expansion Module/Auxiliary 225
Provides the following additional functions:
• Pharmacy Function
• Door Status Contact monitoring
• Safeguarding of main closing edge and secondary closing edges
• Panic Closing Function
• Bell Contact
• Airlock Function
• Synchronous Operation
DC3586-010 Bi-Stable Autolock (Lock is field configured: fail-safe or fail-secure) 389
NOTE: Fail safe and fail secure
DX3091-02A 5 Position ESA Rocker Switch 134
DX2889-020 ESA Sensor Interface Module 382
Provides functionality for use with secondary closing edge sensors like beams and
sidelite sensors. It also provides additional functionality for manual lock release of the
locking functions, and emergency opening/closing in conjunction with a rechargeable
battery pack.
12 June 1, 2021 Automatic Door Systems Price List 16ESA Series Options Automatic Door Systems
ESA Series Options
Model/Part # Function Options List Price $
DS3281-010 Triple Key Switch Panel – Replaces Standard Rocker Switch Panel – Jamb Mounted – Per Unit 168
ESA Series Sensor Beam Kit – Includes (DX2889-020) ESA Sensor Interface Module, (DX3335-016) 649
OPTEX OS-12CT Beam Controller, and (DX3335-017) OPTEX SH-10MC Sensor Heads with Cable
(2-Transmitters/2-Receivers)
SX Cut-Off Switch (ESA200 Only) – Per Unit 211
Omit ESAII Mini Drive Unit (Controller & Operator) & Activation Sensors for Manual Operation Deduct 800
DX2889-002 ESA Module Cable Only (Expansion Module or Sensor Interface Module) 39
DS2889-010 ESAII Expansion Module with cable – Required for Syncronizing Vestibules & Some Other Advanced Control 231
Functions – Each
DX2889-020 ESA sensor interface module with cable (provides functionality for use with secondary closing edge sensors 394
like beams and sidelite sensors. It also provides additional functionality for manual lock release of the locking
functions, and emergency opening/closing in conjunction with a rechargeable battery pack.)
– Per Unit
DS3286-010 Single Key Switch Panel – Replaces Standard Rocker Switch Panel – Limited Functions –Jamb Mounted 108
– Per Unit
DS0979-010 Autolock Bi-Stable Locking – Per Unit 400
DK3200-001 Kit, ESA Heater 290
DC3370-010 Key, Extra, ESA Key Switch 14
DS2890-010 Configurable Battery Backup – Open/Close/Normal Function – Per Unit 194
Bi-Stable Locking & Battery Backup – Per Unit 627
Paddle Exit Device – Per SX Panel 492
Concealed Vertical Rod Exit Device – ESA300 and ESA300HP Only – Clear or Dark Bronze Only – Per SX Panel 629
Concealed Vertical Rod Exit Device – Less than 29" Wide – Additional over base charge – Per SX Panel 340
Recessed Mount Exit Device w/ matching 5-1/2" Sidelite Muntins – Per SX Panel (ESA200 & ESA300) 914
DX2774-020 Magnetic Security Contact – Per SX Panel 51
Stainless Steel Reinforced Armored Strike – Each 108
Lock Status Indicator – Clear or Dark Bronze Only – Per Unit 55
DC0147-310 dormakaba ITS-96 Concealed In-Door Closer – Included on ESA200 SX Panels – Per Panel 481
DC2057-010 Maximum Security Mortise Lock – 3 point locking (Replaces Standard 2 Point Mortise Lock) 100
DD3483-010 Decal, "THIS DOOR TO REMAIN UNLOCKED DURING BUSINESS HOURS" 8
Model/Part # Package Options List Price $
ESA100/200/300 Package Width Greater than 9'-0" (108") for Single & 14'-0" (168") for Bi-Part – 289
Per Foot or Fraction Thereof *
ESA100/200/300 Package Width Greater than Standard with Transom (9'-0" Single – 14'-0" Bi-Part) – 64
Per Foot or Fraction Thereof *
Header Height Greater than 8'-0" (96") for Single Slide – Per Foot or Fraction Thereof 158
Header Height Greater than 8'-0" (96") for Bi-Part Slide – Per Foot or Fraction Thereof 252
Transom Height Greater than 12'-0" (144") – Per Foot or Fraction Thereof 128
Additional Transom Verticals – Each 119
1" Transom Glass Prep – One Veritcal Mullion – Per Transom 182
1" Transom Glass Prep – Additional Veritical Mullion – Each 106
3/8", 1/2", 5/8", or 3/4" Transom Glass Prep – One Vertical – Per Transom 320
3/8", 1/2", 5/8", or 3/4" Transom Glass Prep – Additional Veritical Mullion – Each 211
Transom Horizontal Muntin – Per Foot or Fraction Thereof 33
1" Transom Glass Prep With Horizontal Muntin – Per Foot or Fraction Thereof 36
3/8", 1/2", 5/8", or 3/4" Transom Glass Prep with Horizontal Muntin – Per Foot or Fraction Thereof 70
Extended ESA Header – Per Foot or Fraction Thereof 139
1-3/4" × 4-1/2" Smooth Jamb Tubes up to 8'-0" Tall (96") – Replaces Standard Jamb Tubes – Per Unit N/C
2" × 6" Smooth Jamb Tubes Up To 8'-0" Tall (96") – Replaces Standard Jamb Tubes – Per Unit 93
2" × 6" Single Slide Transom – Required When Ordering Transom with 2" × 6" Jambs – Each 779
* Dimensions greater than standard package sizes are subject to factory review and approval to ensure reliable breakout.
Automatic Door Systems Price List 16 June 1, 2021 13Automatic Door Systems ESA Series Options
ESA Series Options
Model/Part # Package Options List Price $
2" × 6" Single Bi-Part Transom – Required when Ordering Transom with 2" × 6" Jambs – Each $984
Extended Jamb Tubes Over 8'-0" Tall (96") – Two Jambs – Per Foot or Fraction Thereof (above header) $22
1/2" × 4-1/2" Square Edge Track/Threshold with Two 1-1/4" Bevels (Three Piece System 7" Overall) – Each $201
1/4" × 7" Threshold– Replaces Standard Threshold – Per Unit $108
1/4" × 7" Full Width Threshold – Replaces Standard Threshold & Runs Underneath Entire Package – Per Unit $216
1/2" × 4-1/2" Full Width Continuous Track – Replaces Standard Threshold (ESA100 or ESA200) $86
1/2" × 4-1/2" Square Edge (Recessed) Track – Replaces Standard Track – ESA300 & ESA300T Only – Per Unit N/C
Custom/Special Finishes Including Paint, Special Anodized, and Cladding Pg 22 & 25
Custom/Special Engineering and/or Items not Listed in Price Book Quote Only
Model/Part # Door Panel Options List Price $
3-3/4" Medium Stiles – Replaces Standard Narrow Stiles – Per Panel 70
4-3/4" Stacked Stile – Per panel 141
5-3/4" Stacked Stile – Per panel 141
7-1/2" Bottom Rail – Replaces Standard 4" Bottom Rail – Per Panel 48
10" Bottom Rail – Replaces Standard 4" Bottom Rail – Per Panel 76
12" Bottom Rail – Replaces Standard 4" Bottom Rail – Per Panel (stacked) 92
1/4" Sloped Glass Stops – Per Panel N/C
1" Panel Glass Stops – Per Panel N/C
5/8" & 5/8" Sloped, 3/8", 3/8" Sloped, 1/2" & 3/4" Glass Stops – Per Panel 92
Secure Exterior Glass Stops – Per Panel 110
Additional 3-1/4" Muntins – Each 98
5-1/2" Muntins– Replaces Standard 3-1/4" Muntin – Per Panel 156
Additional 5-1/2" Muntins – Each 352
5-9/16" Muntins– Replaces Standard 3-1/4" Muntin – Each 156
Additional 5-9/16" Muntins – Each 302
6-13/16" Muntins– Replaces Standard 3-1/4" Muntin – Each 156
Additional 6-13/16" Muntins – Each 314
9-5/16" Muntins– Replaces Standard 3-1/4" Muntin – Each 156
Additional 9-5/16" Muntins – Each 324
Rubber Weather Seal– Replaces Standard Brush Weather Seal – Per Panel 81
Crash Bar – up to 4'-6" Wide (54") – Each (ships loose) 43
Crash Bar – Greater than 4'-6" (54") Wide – Per Foot or Fraction Thereof (ships loose) 16
Additional Sidelite – up to 4'-6" (54") Wide × 7'-4" (88") Tall – Each 695
Replacement O Narrow Stile Panel – up to 4'-6" (54") Wide × 7'-4" (88") Tall – Each 910
Replacement SO Narrow Stile Panel – up to 4'-6" (54") Wide × 7'-4" (88") Tall – Each 1,021
Replacement SX Narrow Stile Panel – up to 4'-6" (54") Wide × 7'-4" (88") Tall – Each 1,361
Replacement Narrow Stile Panel Width Greater than 4'-6" (54") – Per Foot or Fraction Thereof 143
Replacement Narrow Stile Panel Height Greater than 7'-4" (88") – Per Foot or Fraction Thereof 75
DK3572-01A Clear, Surface Applied, Weather Sweep Kit (bottom rail) 43
DK3752-01B Dark, Surface Applied, Weather Sweep Kit (bottom rail) 55
14 June 1, 2021 Automatic Door Systems Price List 16ESA Series Options Automatic Door Systems
ESA Series Options
Model/Part # Door Panel Options Continued List Price $
DK3584-010 ESA Fail Safe Autolock Kit 604
DS0979-010 ESA Fail Secure Autolock Retrofit Kit 214
DK0992-001 ESA Autolock Carrier Bracket & screws 22
DC0962-020 ESA "SO" limit arm [250mm] 24
DX3281-001 ESA Triple Key Switch 168
DS0901-010 ESA SX Bottom Pivot SO-SX 24
DS0901-020 ESA SX Bottom Pivot SX-SO 24
DS1475-010 ESA SO Top Pivot 32
DS0650-010 ESA Drive Roller 62
DS0651-010 ESA Offset Anti-Rise Assembly 42
DS0704-010 SX Bottom Guide Assembly – Left 51
DS0704-020 SX Bottom Guide Assembly – Right 51
DC3999-010 Handheld Programmer 840
Model/Part # Thresholds List Price $
DE0233-01A ESA Threshold ½” x 4-1/2”, CL (Priced per inch) 1.94
DE0233-01B ESA Threshold ½” x 4-1/2”, DB (Priced per inch) 1.94
DE0195-03A ESA Bottom Track 9/16”_1/2” x 4-12/”, CL (Priced per inch) 1.64
DE0195-03B ESA Bottom Track 9/16”_1/2” x 4-12/”, DB (Priced per inch) 1.64
DE0214-01A ESA Threshold ¼” x 7”, CL (Priced per inch) 5.72
DE0214-01B ESA Threshold ¼” x 7”, DB (Priced per inch) 5.72
DE0209-01A ESA Recessed Bottom Track, ½” x 4-1/2”, CL (Priced per inch) 1.74
DE0209-01B ESA Recessed Bottom Track, ½” x 4-1/2”, DB (Priced per inch) 1.74
DE0246-01A ESA Threshold ½” x 7”, CL (Priced per inch) 6.50
DE0246-01B ESA Threshold ½” x 7”, DB (Priced per inch) 6.50
DE3282-01A ESA Threshold Add-On ½” x 1-7/16”, CL (Priced per inch) .70
DE3282-01B ESA Threshold Add-On ½” x 1-7/16”, DB (Priced per inch) .70
Model/Part # Extended Warranties List Price $
ESA Series Two Year Extended dormakaba USA, Inc. Standard Manufacturer's Warranty – One Additional Year 238
ESA Series Three Year Extended dormakaba USA, Inc. Standard Manufacturer's Warranty – Two Additional Years 476
ESA Series Five Year Extended dormakaba USA, Inc. Standard Manufacturer's Warranty – Four Additional Years 1,109
Automatic Door Systems Price List 16 June 1, 2021 15Automatic Door Systems MAGNEO Manual Sliding Doors
MAGNEO Magnetic Drive Power Assisted Manual Sliding Doors
Model/Part # Product Single/Bi-Part Standard Configurations List Price $
Single/Pair
MAGNEO Magnetic Drive Power Assisted Manual Sliding Doors Solid Door 73" Header (27" - 34" Opening) 6,431
MAGNEO Magnetic Drive Power Assisted Manual Sliding Doors Solid Door 83" Header (30" - 39" Opening) 6,536
MAGNEO Magnetic Drive Power Assisted Manual Sliding Doors Solid Door 93" Header (33" - 44" Opening) 6,647
MAGNEO Magnetic Drive Power Assisted Manual Sliding Doors Clamp Rail 73" Header (27" - 34" Opening) 6,972
MAGNEO Magnetic Drive Power Assisted Manual Sliding Doors Clamp Rail 83" Header (30" - 39" Opening) 7,077
MAGNEO Magnetic Drive Power Assisted Manual Sliding Doors Clamp Rail 93" Header (33" - 44" Opening) 7,182
MAGNEO Magnetic Drive Power Assisted Manual Sliding Doors Manet 73" Header (27" - 34" Opening) 7,513
MAGNEO Magnetic Drive Power Assisted Manual Sliding Doors Manet 83" Header (30" - 39" Opening) 7,618
MAGNEO Magnetic Drive Power Assisted Manual Sliding Doors Manet 93" Header (33" - 44" Opening) 7,723
Base Package Prices Include:
• On-Wall Unit Mounting Configuration
• Ultra-Quiet Drive with LMD Technology
• Low Profile 3" × 2-3/8" Aluminum Header
• Finishes: Class II Clear Anodized
• Floor Mounted Bottom Guide
• Integrated Microprocessor Controller
• Sensor Communication Interface
• Three Position Program Switch with Connecting Harness:
[On – Off – Hold Open]
16 June 1, 2021 Automatic Door Systems Price List 16MAGNEO Door Options Automatic Door Systems
MAGNEO Power Assisted Manual Door Options
Model/Part # Unit Mounting Options & Accessories List Price $
In-Wall/Ceiling Mounting Configuration – Per Unit N/C
On-Glass Mounting Configuration – Per Unit 341
1/2" Aluminum Bar Shim-Kit – For On-Wall Mounting Configurations with Framed Door Openings – Each 210
Access & Security Options
DK3588-010 Concealed Automatic Lock 625
Package Options
DK3309-01G Recessed Pull Handle – Each 194
DK3308-01G 1" Stainless Steel Back-to-Back Vertical Pull Handles 13-3/4" Overall (350 mm) – Per Set of Two 509
DK3308-02G 1" Stainless Steel Back-to-Back Vertical Pull Handles 28-3/8" Overall (720 mm) – Per Set of Two 572
Custom Finish Options
Special Anodize Finish – Per Unit (Header Cover, Floor Guide and Glass Rails) 210
(Minimum Special Anodize Order $500 List)
Stock Interior Two-Coat Enamel Paint – Per Unit (Header Cover, Floor Guide and Glass Rails) 315
(Minimum Special Finish Order $1200 List)
Exotic Interior Two-Coat Enamel Paint – Per Unit (Header Cover, Floor Guide and Glass Rails) 473
(Minimum Special Finish Order $1200 List)
Stainless Steel #4 Satin Cladding – Per Unit (Cover Only) 630
Stainless Steel #8 Mirror Cladding – Per Unit (Cover Only) 656
Brass Muntz #4 Satin Cladding – Per Unit (Cover Only) 709
Brass Muntz #8 Mirror Cladding – Per Unit (Cover Only) 761
Brass Statuary & Lacquer Cladding – Per Unit (Cover Only) 761
Extended Warranties
MAGNEO Series Two Year Extended dormakaba USA, Inc. Standard Manufacturer's Warranty 446
– One Additional Year
MAGNEO Series Three Year Extended dormakaba USA, Inc. Standard Manufacturer's Warranty 578
– Two Additional Years
MAGNEO Series Five Year Extended dormakaba USA, Inc. Standard Manufacturer's Warranty 1,050
– Four Additional Years
Automatic Door Systems Price List 16 June 1, 2021 17Automatic Door Systems ICU200 & ICU300 Manual Sliding Doors
ICU200 & ICU300 Manual Sliding Doors
PACKAGE WIDTH PACKAGE WIDTH ICU300 shown
PACKAGE HEIGHT
PACKAGE HEIGHT
BREAKOUT WIDTH BREAKOUT WIDTH
CLEAR SLIDE CLEAR SLIDE
OPENING OPENING
EXTERIOR EXTERIOR
PACKAGE WIDTH PACKAGE WIDTH
Model/Part # Product Single/Bi-Part Standard Handing Configurations List Price $
Single/Pair
PACKAGE HEIGHT
PACKAGE HEIGHT
ICU200 Manual Sliding Doors w/Recessed Track Single [O-SX] [SX-O] 2,284
ICU200 Manual Sliding Doors – Trackless Single [O-SX] [SX-O] 2,977
ICU200 Manual Sliding Doors w/Recessed Track Bi-Part [O-SX-SX-O] 3,680
ICU200 Manual Sliding Doors – Trackless Bi-Part [O-SX-SX-O] 4,337
ICU300 Manual Sliding Doors w/Recessed Track Single [SO-SX] [SX-SO] 2,284
BREAKOUT WIDTH BREAKOUT WIDTH
ICU300 Manual Sliding Doors
CLEAR–SLIDE
Trackless Single [SO-SX] [SX-SO]
CLEAR SLIDE 2,977
OPENING EXTERIOR OPENING
ICU300 Manual Sliding Doors w/Recessed Track Bi-Part [SO-SX-SX-SO] 3,680
EXTERIOR
ICU300 Manual Sliding Doors – Trackless Bi-Part [SO-SX-SX-SO] 4,337
Base Package Prices Include:
• Finishes: Clear or Dark Bronze Anodized • 2-5/8" Narrow Stile Door Panels • 1-3/4" × 4-1/2" Double Pocket Jamb Tubes
• Package Height up to 8'-0" (96") [Including 3/4" Wide Glass Stop] • 1/4" Glass Stops in Door Panels
• Package Width: • 3-1/4" Muntin Mounted at 41.75" All Panels • Recessed Pull Handles
[Single Slide up to 9'-0"] (108") [Including 3/4" Wide Glass Stop] • Brush Weatherstrip
[Bi-Part Slide up to 14'-0"] (168") • 4" Bottom Rail • Smoke gasketing option available
[Including 3/4" Wide Glass Stop]
NOTE: ICU200 Manual Sliding Doors with Partial Breakout
are available at the same price as ICU300 units – see above.
For applicable options, please refer to ICU Series Manual Door Options (see page 19).
18 June 1, 2021 Automatic Door Systems Price List 16PACKAGE H
PACKAGE H
ICU200T & ICU300T Manual Sliding Doors Automatic Door Systems
ICU200T & ICU300T Telescopic Manual Sliding Doors
BREAKOUT WIDTH BREAKOUT WIDTH
CLEAR SLIDE CLEAR SLIDE
OPENING OPENING
EXTERIOR EXTERIOR
PACKAGE WIDTH PACKAGE WIDTH ICU300T shown
PACKAGE HEIGHT
PACKAGE HEIGHT
BREAKOUT WIDTH BREAKOUT WIDTH
CLEAR SLIDE CLEAR SLIDE
OPENING EXTERIOR OPENING
EXTERIOR
Model/Part # Product Single/Bi-Part Standard Handing List Price $
Single/Pair Configurations
ICU200T Telescopic Manual Sliding Doors w/Recessed Track Single Telescopic [O-X-SX] [SX-X-O] 4,284
ICU200T Telescopic Manual Sliding Doors - Trackless Single Telescopic [O-X-SX] [SX-X-O] 4,599
ICU200T Telescopic Manual Sliding Doors w/Recessed Track Bi-Part Telescopic [O-X SX-SX X-O] 6,190
ICU200T Telescopic Manual Sliding Doors - Trackless Bi-Part Telescopic [O-X SX-SX X-O] 6,447
ICU300T Telescopic Manual Sliding Doors w/Recessed Track Single Telescopic [SO-SX-SX] [SX-SX-SO] 4,284
ICU300T Telescopic Manual Sliding Doors - Trackless Single Telescopic [SO-SX-SX] [SX-SX-SO] 4,599
ICU300T Telescopic Manual Sliding Doors w/Recessed Track Bi-Part Telescopic [SO-SX SX-SX SX-SO] 6,190
ICU300T Telescopic Manual Sliding Doors - Trackless Bi-Part Telescopic [SO-SX SX-SX SX-SO] 6,447
Base Package Prices Include:
• Finishes: Clear or Dark Bronze Anodized • 2-5/8" Narrow Stile Door Panels • 1/4" Glass Stops in Door Panels
• Package Height up to 8'-0" (96") [Including 3/4" Wide Glass Stop] • Recessed Pull Handles
• Package Width: • 3-1/4" Muntin Mounted at 41.75" All Panels • Brush Weatherstrip
[Single Telescopic Slide up to 10’-0"] (120") [Including 3/4" Wide Glass Stop] • Smoke gasketing option available
[Bi-Part Telescopic Slide up to 14’-0"] (168") • 4" Bottom Rail
[Including 3/4" Wide Glass Stop]
• 1-3/4" × 4-1/2"Double Pocket Jamb Tubes
For applicable options, please refer to ICU Series Manual Door Options (see page 19).
Automatic Door Systems Price List 16 June 1, 2021 19Automatic Door Systems ICU1200 Manual Bi-Fold/Swing Doors
ICU1200 Combination Manual Bi-Fold/Swing Doors
Model/Part # Product Standard Handing Configurations List Price $
ICU1200 Combination Manual Doors Bi-Fold/Swing [S-FX-FS] [FS-FX-S] $3,255
Base Package Price Includes:
• Finishes: Clear or Dark Bronze Anodized • 1-3/4" × 4-1/2" Double Pocket Jamb Tubes
• Package Height up to 8'-0" (96") • 1/4" Glass Stops in Door Panels
• Package Width up to 9'-0" (108") • Brush Weather Stripping
• 36", 42", and 48" Nominal Swing Door Panel Widths • RTS88 Series Size 3 Overhead Concealed Double Acting
• 2-5/8" Narrow Stile Door Panels Manual Swing Door Closer with 90º Hold Open
[Including 3/4" Wide Glass Stop] . Stainless Steel Offset Push/Pull Handle on Swing Door
• 3-1/4" Muntin Mounted at 41.75" All Panels . Stainless Steel Pull Handle on Bi-Fold Doors
[Including 3/4" Wide Glass Stop]
• 4" Bottom Rail
[Including 3/4" Wide Glass Stop]
20 June 1, 2021 Automatic Door Systems Price List 16ICU Series Manual Door Options Automatic Door Systems ICU Series Manual Door Options Package Options List Price $ Package Width Greater than 9'-0" ICU200, ICU300, ICU1200 & 10'-0" ICU300T Singles – Per Foot or Fraction Thereof 208 Package Width Greater than 14'-0" ICU200, ICU300 & ICU300T Bi-Parts – Per Foot or Fraction Thereof 208 Header Height Greater than 8'-0" for Single Slide (ICU200, ICU300) – Per Foot or Fraction Thereof 158 Header Height Greater than 8'-0" for Combo Swing/Bi-Fold (ICU1200) – Per Foot or Fraction Thereof 196 Header Height Greater than 8'-0" for Telescopic Single Slide (ICU300T) – Per Foot or Fraction Thereof 196 Header Height Greater than 8'-0" for Bi-Part Slide (ICU200, ICU300) – Per Foot or Fraction Thereof 252 Header Height Greater than 8'-0" for Telescopic Bi-Part Slide (ICU300T) – Per Foot or Fraction Thereof 322 1/2" × 4-1/2" Full Width Continuous Track for ICU200, ICU300 Single – Per Unit 192 1/2" × 4-1/2" Full Width Continuous Track for ICU200, ICU300 Bi-Part – Per Unit 276 Rubber Weather Seal – Replaces Standard Brush Weather Seal – Per Panel 57 Smoke Rated Package for Single Slide Unit – Includes Positive Latching Hardware – ICU300 & ICU300T only 557 Smoke Rated Package for Bi-Part Slide Unit – Includes Positive Latching Hardware – ICU300 & ICU300T only 1,092 Access & Security Options Positive Latching Hardware Handle for Single Slide Unit – Vertical Rod Mechanism – Per Unit 460 Positive Latching Hardware Handle for Bi-Part Slide Unit – Vertical Rod Mechanism – Per Unit 893 Positive Latching Hardware Handle – Jamb Hook Mechanism – Only Available for Single Slide Units – Per Unit 359 Two Point Mortise Lock for Single Slide Package – Per Unit 83 Two Point Mortise Lock for Bi-Part Slide Package – Per Unit 139 Door Panel Options Medium Stiles – Replaces Standard Narrow Stiles – Per Panel 70 4-3/4" Stacked Stile – Per panel 141 5-3/4" Stacked Stile – Per panel 141 10" Bottom Rail– Replaces Standard 4" Bottom Rail – Per Panel 70 7-1/2" Bottom Rail– Replaces Standard 4" Bottom Rail - Per Panel 48 10" Bottom Rail– Replaces Standard 4" Bottom Rail – Per Panel 76 12" Bottom Rail– Replaces Standard 4" Bottom Rail – Per Panel (stacked) 92 1/4" Sloped Glass Stops – Per Panel N/C 1" Panel Glass Stops – Per Panel N/C 5/8" & 5/8" Sloped, 3/8", 3/8" Sloped, 1/2" & 3/4" Glass Stops – Per Panel 92 Additional 3-1/4" Muntins – Each 98 5-1/2" Muntins– Replaces Standard 3-1/4" Muntin – Each 103 Additional 5-1/2" Muntins – Each 265 Crash Bar – up to 4'-6" Wide (54") – Each (ships loose) 43 Crash Bar – Greater than 4'-6" (54") Wide – Per Foot or Fraction Thereof (ships loose) 16 Replacement Narrow Stile Swing Door Panel – up to 4'-6" (54") Wide × 7'-4" (88") Tall – Each 993 Replacement SO Narrow Stile Panel – up to 4'-6" (54") Wide × 7'-4" (88") Tall – Each 681 Replacement SX Narrow Stile Panel – up to 4'-6" (54") Wide × 7'-4" (88") Tall – Each 967 Replacement Narrow Stile Panel Width Greater than 4'-6" (54") – Per Foot or Fraction Thereof 143 Replacement Narrow Stile Panel Height Greater than 7'-4" (88") – Per Foot or Fraction Thereof 75 Replacement Medium Stile Panel Width Greater than 4'-6" (54") – Per Foot or Fraction Thereof 163 Replacement Medium Stile Panel Height Greater than 7'-4" (88") – Per Foot or Fraction Thereof 99 Custom/Special Finishes Including Paint, Special Anodized and Cladding Pages 22–25 Custom/Special Engineering and/or Items not Listed in Price Book Quote Only Extended Warranties ICU Series Two Year Extended dormakaba USA, Inc. Standard Manufacturer's Warranty – One Additional Year 163 ICU Series Three Year Extended dormakaba USA, Inc. Standard Manufacturer's Warranty – Two Additional Years 297 ICU Series Five Year Extended dormakaba USA, Inc. Standard Manufacturer's Warranty – Four Additional Years 568 Automatic Door Systems Price List 16 June 1, 2021 21
You can also read
