A range extension solution for non-intensive use segments
A range extension solution
for non-intensive use segments
A range extension solution for non-intensive use segments
A range extension solution
   for non-intensive use segments
                                                                                                 Recom
                                                                                                       me
                                                                                                   Less t nded
                                                                                                         han
                                                                                              3 cyc
                                                                                                       les da
                                                                                                                 y

        WASHER                                                                   WASHER + DRYER
            Heater       Electric or Non heater                                    Heater     Gas or electric
          Capacity           22,5lb (10,2Kg)                                      Capacity   22,5lb (10,2Kg)

                                                                                 /OPL stackable
                              /OPL single                                        (Washer + Dryer)

        Giant C+ WASHER
Each of the LG Washer’s five wash options is programmable to meet specific
fabric and load requirements. Once the programs are set, operators simply
select a wash option, add chemicals/detergents and press start. The washer
features programmable wash times, from five to 15 minutes; rinse times, from
8 to 15 minutes; extract speed, from 600 rpm to 1150 rpm; and rinses, from
one to five. Additionally, the control includes the ability to add or remove a
prewash. Super Wash is also programmable for an extra wash, an extra rinse,
or both together.

LG wash programs include, Whites (Hot), Colors (Warm), Permanent Press
(Warm), Delicates (Cold) and Super Wash (Added Function).

STINGY ON WATER & ENERGY                 NEVERRUST™ STAINLESS WASH               QUIET OPERATION & INVERTER
STAR QUALIFIED                           TUB & HIGH EXTRACT SPEEDS               DIRECT DRIVE
Delivering a quality clean using just    The rust-free washer drum features      LG front-load washers are among
11.2 gallons of water per load, the LG   large baffles for improved wash         the quietest in their class. Three
Washer is engineered to cut water        action and efficient removal of tough   washer dampers absorb excess
usage and improve wash quality.          stains and soils. And, unlike painted   vibrations to deliver quiet operation.
                                         drums that chip over time, the          LG’s Direct Drive system increases
                                         scratch-resistant stainless steel tub   motor stability and durability, while
                                         won’t stain laundry.                    lessoning vibrations. It eliminates
                                                                                 the need for belts and pulleys, found
                                                                                 in conventional washer motors,
                                                                                 decreasing maintenance and noise.
A range extension solution for non-intensive use segments
WASHER                                                                         WASHER + DRYER
     Heater        Electric or Non heater                                         Heater    Gas or electric
   Capacity           22,5lb (10,2Kg)                                            Capacity   22,5lb (10,2Kg)

                                                                                /COIN stackable
                                /COIN single                                    (Washer + Dryer)

         Giant C+ DRYER
The LG commercial dryer is simple to use. The control panel features a
digital display illuminating cycle time countdown, while LED lights indicate
cycle status. operators simply select one of the four fabric options – Whites
& Color (high heat), Perm. Press (medium heat), Delicates (low heat), or No
Heat – then press the start button. An end-of-cycle tone sounds upon cycle
completion, and an extra-large door makes loading and unloading a snap!

SIMPLE PROGRAMMING
Intuitive programming allows laundries to manage a variety of functions,
including cycle time, drying temperatures, cool-down time and top-offs.
Cycle time is programmable in one-minute increments and time countdown
can be set for minutes or seconds. Dryer
top-off options for adding more time can be programmed for one-minute
increments. Default settings include a 45-minute cycle time with two minute
cool-down, and a 15-minute top-off time.

QUIET OPERATION                         DURABLE FOR YEARS OF                    SECURE AND FLEXIBLE
LG Commercial Dryers are among          OPERATION                               AdaptAble™ Controls and a
the quietest in their class.            LG commercial dryers offer a            reversible door bring installation
                                        streamlined, modern look, and           flexibility for stacking with an LG
                                        a robust, stainless chrome door         commercial washer or dryer – fitting
                                        and stainless drum. Engineered to       any laundry area’s equipment and
                                        appeal and attract, the dryers also     space requirements. And, LG’s
                                        withstand rigorous use.                 unique Dual Lock System for the
                                                                                front panel access provides added
                                                                                security.
A range extension solution for non-intensive use segments
Main feature Giant C+ washers and dryers

Premium Powder Coated                Multi Heat Treatment                Stainless Steel Drum for Washer
Our powder coated finish creates     To ensure superior performance      The stainless steel drum helps
the same durability as it does       LG heat treats the shaft            prevent clothes from staining or
when painting a car. It is sure to   which connects our drums and        damages during the wash cycle.
last long and provide an easy to     motors. This protects
clean exterior.                      against gradual wear and tear.

     Inverter                        Unlike the traditional belt and pulley, the LG Commercial Laundry
                                     drum is directly attached to the motor providing superior durability
     Direct Drive                    and reliability. Less parts equal less repairs.

                                    VS

10° Tilted Drum                      Optimized Washing System            Easy Programming
LG’s Commercial Washer tub is        When an LG Commercial Washer        Intuitive programming controls
tilted at 10°.                       detects over-suds during a          allow operators to choose
It enables the washer to have a      washing cycle, it moves into a      from a variety of functions and
higher level of water in the tub     suds reduction process which        programs, including price, cycle
than the competition. This allows    delivers a better washing           time, cycle parameters, spin-
us to use less water while not       performance.                        speed and more, ensuring that all
sacrificing superior washing                                             washing requirements are met.
performance.
A range extension solution for non-intensive use segments
Space Saving                           Installation Flexibility            Easy Repair System
The small cabinet size with            Install your laundry to meet        LG Commercial Laundry
bigger washing capacity and            your needs and space with side      products are all front service
stackable design allows more           by side or stack configuration.     accessible. Valuable service time
customers and more machines in         Easy to bring and reinstall your    will never be wasted gaining
limited space.                         products even though you move       access to key service elements.
                                       to new house.

  Girbau perfect
  range extension
  for non-intensive
  use segments

Easy Access Lint filter                Excellent Dry Performance           Heavy Duty Motor
The surface of lint filter increased   Titan-C OnlyThanks to new wider     Titan-C Only LG Commercial
and it provides the easy access        big fan, air flow is improved and   Dryers incorporate the sturdy
and cleaning without opening           clothes can be dried faster than    motor
door. This creates better drying       before. Better dry performance,     additionally and it provides
action and helps to reduce             better energy efficiency.           better air flow and heating
frequency of cleaning.                                                     system. This creates better
                                                                           drying action and increases dry
                                                                           capacity.
Giant C+ WASHER
             MODEL NUMBER                                         FH069FD**(Non Heater type)
                                                                  FH069FD*PS(Heater type)
             Cylinder
             Drum volume                            cu. ft.(ℓ)    3.6 (102.7)
             Diameter                               in.(mm)       22.1 (560)
             Depth                                  in.(mm)       16.5 (419.3)
             Capacity                               kg(1:10)/lb   13 / 22.5
             Dimensions
             Product (WxHxD)                        in.(mm)       27 (686) x 38.7 (983) x 30.2 (767)
             with door opening                      in.(mm)       50.8 (1,291)
             Carton (WxHxD)                         in.(mm)       29.72 (755) x 44.4 (1,127) x 31.3 (795)
             Weight (Product/ Carton)               lb(kg)        191 (87) / 211 (96)
             Speed
             Wash                                   RPM           50
             Extract (High Speed)                   RPM           1.150
             G-force                                G             413
             Energy
             Electric Power Consumpsion             V/Hz/A        220~240/50/5
             Water Usage
             Water Consumption                      ℓ             50,8
             Noise & Cycle Time
             Noise Level (Sound Power)              dB            Lower than 62
             Program duration in minutes(Default)   min           36
             System & Control
             Inverter Direct Drive Motor                          Avialable
             Intelligent Electronics Controls                     Avialable
             Heating System                         W             2,000W(Non heater type / only use
                                                                  tub clean)
                                                                  3,200W(Heater)
             Compartment Dispenser                                3 Compartment Dispenser
             Forced Drain System                                  Avialable
             Pricing Program                                      Special Vended Price
             Wash Programs(Min)                                   Non heater / Heater
                                                                  Hot (36min) / 90°C (90min)
                                                                  Warm (36min) / 75°C (75min)
                                                                  Cold (36min) / 60°C (60min)
                                                                  Delicate (36min) / 40°C (40min)
                                                                  Add super wash / Cold (36min)
                                                                  Customized program(20courses)
             Covenience Features
             End of Cycle Beeper                                  Avialable
             Door Lock Display                                    Avialable
             Self Diagnosis                                       Avialable
             Auto Balancing                                       Avialable
             Auto Suds Removal                                    Avialable
             Forced Drain System                                  Avialable
             Remaining Time Display                               Avialable
             Status Indicator                                     Avialable
             4 Adjustable Leveling Legs                           Avialable
             LoDecibel Quiet Operation                            Avialable
             Coin Box Open Sensing                                Avialable
             External Finish
             Drum                                                 NeveRust™ Stainless Steel Drum
             Top Plate                                            Porcelain(Single)
                                                                  Powder painted steel(Stack)
             Transparent Glass Window Door                        Avialable
             Colors                                               Platinum
             Cabinet                                              Powder painted steel
             Control Panel                                        Powder painted steel
             Window Display                                       Silk Screen
             Window                                               Aluminum
             Circuit Protection
             PCB fuse - Main Control Board          amps          8 (220~240V)
                                                                  12 (120V)
             PCB fuse - Filter Assembly             amps          15
Giant C+ DRYER
             MODEL NUMBER                                             RN1329A**S(Gas type)
                                                                      RV1329A**S(Elec type)
             Cylinder
             Drum volume                                cu. ft.(ℓ)    7.3(207)
             Diameter                                   in.(mm)       26.1 (663)
             Depth                                      in.(mm)       22.5 (570.6)
             Capacity                                   kg(1:20)/lb   10.2 / 22.5
             Dimensions
             Product (WxHxD)                            in.(mm)       27 (686) x 38.7 (983)x 30.1 (764)
             with door opening                          in.(mm)       49.8 (1,264)
             Carton (WxHxD)                             in.(mm)       29.9 (760) x 46.1 (1,170) x 31.3 (795)
             Weight (Product/ Carton)                   lb(kg)        130 (59) / 143 (65)
             Operation
             Electrical Requirements                    V/Hz/amps     220~240/50/2.4
             Heating type                                             Gas / Elec
             Type of Drying                                           Ventilation
             Air Flow                                   CFM           160
             Motor                                      KW            0.32 (220~240V/ 50Hz)
             Gas Ratings                                KW/BTU        5.8/20,000
             Heating Element                            W             5.400
             Program duration in minutes(Default)       min           45
             Connections
             Air outlet diameter                        in.(mm)       4 (100)
             Exhaust airflow diameter                   in.(mm)       4 (100)
             System & Control
             Pricing Program                                          Special Vended Price
             Intelligent Electronic Controls                          Avialable
             Dry Programs
             Program list                                             High Temp
                                                                      Med Temp
                                                                      Low Temp
                                                                      No Heat
             Covenience Features
             End of Cycle Beeper                                      Avialable
             Heater Type                                              -
             Gas Valve Type                                           on / off
             Reversible Door                                          Avialable
             Remaining Time Display                                   Avialable
             Self Diagnosis                                           Avialable
             Status Indicator                                         Avialable
             4 Adjustable Leveling Legs                               Avialable
             Multilingual Readout                                     Avialable
             Coin Box Open Sensing                                    Avialable
             External Finish
             Top Plate                                                Porcelain(Single)
                                                                      Powder painted steel(Stack)
             Transparent Glass Window Door                            Avialable
             Colors                                                   Platinum
             Cabinet                                                  Powder painted steel
             Control Panel                                            Powder painted steel
             Window Display                                           Silk Screen
             Window                                                   Aluminum

             1) Gas rating is different by countries.
             2) 4,500W for some countries due to power
             limitation
               (e.g. Australia)
BRANCHES
Argentina - Buenos Aires -Tel. +54-1 149017600 - girbauargentina@girbau.com.ar
Australia - Sydney - Tel. +61 2 96755860 - sales@girbau.com.au
Brazil - Sao Paulo - Tel. +55 11-29820446 - girbaudobrasil@girbau.com.br
China - Shenzhen & Hong Kong - Tel. +86-755-8211 1330 – info@girbau.com.cn
Cuba - La Habana - Tel. (+53-7) 8662071 al 73 - girbau@girbau.co.cu
Dominican Rep. - Punta Cana - Tel. +1 809-959-0615 - infodominicana@girbau.com
France - Roissy (Paris) - Tel. +33 1-49388585 - infofrance@girbau.com
Germany - Ratingen - Tel. +49 2102 9934619 - girbaugermany@girbau.com
Italy - Marcon (VE) - Tel. +39 0418654330 - infoitaly@girbau.com
Mexico - Cancún - T. +52 998 688 6336 - info.mexico@girbau.com
Portugal - Porto - Tel. +351 22 3758909 - vendasportugal@girbau.pt                           Automatic Industries
U.A.E. - Dubai - Tel. +971 4-8839951 - sales@girbau.ae                                       Maria Henriettalei 33, 2660 Hoboken
U.K. - Hitchin - Tel. +44(0)-1462 427780 - info@girbau.co.uk                                 T. 03 825 44 27
U.S.A. - Oshkosh, Wi & Los Angeles, Ca - Tel. +1(920) 2318222 - info@continentalgirbau.com   info@automatic-industries.com
                                                                                             www.automatic-industries.com

HEADQUARTERS
GIRBAU, S.A. Ctra de Manlleu, km. 1 - 08500 Vic (Barcelona) Spain - girbau.com
Tel. (+34) 93 886 2219 - sales@girbau.com
You can also read
