     Following are excerpts from a 39 page document with multiple mission objectives including
                                       Ganymede landing….
Lunar mission Ganymede
The scientific value of a lunar mission to Ganymede:
Ganymede is the only moon in our solar system to own its own magnetic field. This planet has not been explored yet, and
may offer many opportunities in space exploration to see the
possibility of life and water on the planet.
The probe could take samples of the rock and sediment for
analysis and transfer the data back to earth.
Analysis of the atmosphere and the magnetic field would also
prove useful in gathering scientific data about the moon.
The surface could be monitored by mission control 24/7 to scan
for any anomalies or events that we would not have seen from
deeper space.
Teams could analyse different parts of the planet through
different parts of scientific equipment. As the payload is 30
Tonnes, a lot of science equipment can be stored, such as deeper
drills, mini rovers, larger surface scanners and telescopes.
My rocket can deliver large payloads, potentially even multiple
rovers or probes to explore multiple moons at once or the same
surface for a larger analysis of a given surface. This example is
given as a landing probe to Ganymede.
The rocket's power allows a payload to be delivered directly to
the needed planet, and the ion engines allow for extended
missions, with four times the power, it can slow down much
quicker than single ion engines which allow capture burns to be
quicker.
The given example uses a single heavy probe to a single
destination for simplicity as an example on how the rocket can be used to reach its destination. It assumes the perfect
circumstances for the given flight path.

DeltaV requirements:
Ground to Low Earth Orbit: 9400m/s
LEO to Geostationary Orbit: 2440m/s
GO to earth escape orbit: 770m/s
Earth to Jupiter Transfer: 3090m/s
Jupiter Transfer to Ganymede transfer: 2180m/s
Ganymede transfer to Ganymede Capture: 4790m/s
Ganymede Capture to low Ganymede orbit: 790m/s
Low Ganymede orbit to Ganymede: 1970m/s
Total DeltaV: 25 430m/s

The amount of DeltaV is much less than the total deltaV of the rocket,
thus much heavier payloads can be carried to a single moon or many
different moons.

Alexander

Design a Rocket Challenge 2020 – secondary entries 6

Shortlisted Secondary School Entry

Design a Rocket Challenge 2020 – secondary entries 7

           Shortlisted Secondary School Entry
THE AUGURY
The aim of the Augury is to further
explore Jupiter’s system, particularly the
icy Galilean moons – Europa, Ganymede
and Callisto – in order to gain a better
insight on the area for future crewed
missions and the setting up of
permanent bases following the success
of current efforts to settle on the Moon
and then Mars.
The rocket is named Augury partially
because this is defined as “a sign of
what will happen in the future”, which I
believe will be the case eventually as
humanity’s innate curiosity pushes us to
explore as far as we are capable of. The
other reason is its relation to
mythology: as Jupiter is an aerial god,
his primary sacred animal is the eagle
which held priority over other birds in
the ancient Roman religious practice of
Augury to interpret omens (good or
bad). This seems fitting as we will be
interpreting Jupiter’s system of moons
for a possible future there, as well as for
a better understanding of our solar
system.
To get to Jupiter’s orbit and be able to
access its moons, the Augury will have 4
stages, so is a relatively large rocket.
The first stage lifts the rocket off the
ground, and my design utilises solid fuel
boosters, which is advantageous as
greater thrust can be produced with a
simpler, safer and cheaper design so
that less thrust needs to be produced by
the main liquid engine, allowing more
fuel space for the other stages and
decreasing the rockets overall mass.
After MECO, the second stage will get
the spacecraft into low earth orbit, and
gravity assist around the planet will help
accelerate the craft without using more
fuel to propel towards Jupiter.
The second stage will help the third before it cuts off in executing the burn towards Jupiter, and the third will get the craft into
Jupiter’s orbit, as well as assisting transport close to specific moons.
The fourth will ensure the mission lasts and to assist sending separate spacecraft into orbit around the moons and until the
rockets suicide mission into Jupiter following how useful Cassini’s was in giving more precise data about the planet’s composition
while its antenna was able to point towards Earth. This also means re-entry to Earth isn’t a concern for the mission, allowing the
design to be cheaper.
The head of the rocket holds a capsule, part of final stage of the rocket. This will be fairly long, with its base holding a section for
fuel, which is surrounded in solar panels to get electricity to help power the electronics and equipment aboard. The next section
contains some hatches, which when necessary will use robotics to launch satellites and small spacecraft towards the specific moon
in order to collect data on it. Some of these may contain land vehicles to find information from the surface. They will all contain an
antenna allowing data to be sent back to Earth, whether this is directly or through the capsule.
The top of the capsule will contain a range of scientific instruments along with the daughter spacecraft in order to record data and
take photographs in different wavelengths (visible light, infrared, ultraviolet etc.). These could be temperature sensors, mapping,
magnetometers, spectrometers, sounding/radar instruments, and anything else that could be useful. This will allow the Augury to
send useful and in depth data of the moons and more on Jupiter itself for analysis on Earth.
Your first name and age: Dana, 17

Design a Rocket Challenge 2020 – secondary entries 8

   Shortlisted Secondary School Entry
This entrant provided a rather splendid associated animation of both space vehicles,
                        3D modelled, gliding through space.

Design a Rocket Challenge 2020 – secondary entries 9

We received many entries with brilliant
ideas and designs. Selecting ‘the best’
        was a very hard task.

 There is hope for the future of space
             engineering.

   Many thanks for all the brilliant
     submissions that follow.

Design a Rocket Challenge 2020 – secondary entries 10

Design a Rocket Challenge 2020 – secondary entries 11

       Akshar

Design a Rocket Challenge 2020 – secondary entries 12

I’m 18 and this is my idea for an asteroid farming space shuttle. The flight path is from Earth/ Mars
