PALUX TOUCH 'N' STEAM
–
Our comfortable and flexible combi steamer series.
PALUX TOUCH 'N' STEAM - Our comfortable and flexible combi steamer series.
YOU CAN FOCUS
     ON PERFECT
     DISHES.
     WE TAKE CARE
     OF THE REST.

2|
PALUX TOUCH 'N' STEAM - Our comfortable and flexible combi steamer series.
PALUX Touch 'n' Steam

The PALUX Touch 'n' Steam is the perfect appliance for professional kitchens – for
steaming, vitalising, grilling, frying, thawing, stewing or baking. Whether using the
electrical or gas version: The Touch 'n' Steam is ideal for the à la carte and banquet
business.

All advantages at a glance:

„   Intuitive touchscreen user interface       „   ECO-Autoclean EAC: Standard auto-
    in Basic or Comfort version                    matic liquid or solid cleaning at three
                                                   levels
„   Preparation of dishes through individu-
    ally adaptable cookbook                    „   AQA Automatic Quantity Adjustment:
                                                   Preparation time adjusts to the
„   Prima Clima: intelligent climate control       quantity of food to be cooked
    for top food quality
                                               „   Triple (optionally quadruple) glazed
„   Advanced-Cool-Down function for                door with infrared reflective coating
    the rapid cooling down of the cooking
    chamber                                    „   4 manual operating modes

„   Steam Eco System for optimal fresh         „   5 fan speeds
    steam generation

                                                                                             |3
PALUX TOUCH 'N' STEAM - Our comfortable and flexible combi steamer series.
Die große Freiheit:
     Experience “the great freedom” with PALUX

     We have been developing innovative                More room means to us more space in the
     product solutions since 1929, engineer-           kitchen:
     ing and planning integrated kitchen               „ To improve work processes
     concepts together with our partners in            „ To shorten working distances
     Germany and abroad combined with the              „ To optimise stowing space
     pursuit of top production quality. The
     overall goal: to provide chefs with maxi-         to make the chef’s job exciting, versatile
     mum freedom in every day work.                    and flexible while enjoying freedom to cre-
                                                       ate.
     We design a workplace that provides chefs
     with freedom:                                     PALUX represents state of the art profes-
     „ For being at ease during work                   sional kitchen engineering. Our approach,
     „ To be creative                                  counteracting the permanent stress and
     „ For excellent quality of dishes                 deficient work conditions of chefs, is based
                                                       on a kitchen with concept and matching
                                                       technology. We provide customised solu-
                                                       tions and accompany our customers from
     MORE SPACE                                        planning of the workflows via production to
                                                       the first cooking experience in the new
     FOR THE CHEF.                                     kitchen.

                                                       Diversity is important to us, and we there-
     Our solutions provide more room for pas-          fore realise gastronomy concepts i. a. for
     sion, creativity, flexibility, ideas and there-   large hotel chains, cosy small bistros,
     fore freedom.                                     country inns or star restaurants.

4|
PALUX TOUCH 'N' STEAM - Our comfortable and flexible combi steamer series.
PALUX TOUCH 'N' STEAM - Our comfortable and flexible combi steamer series.
PALUX TOUCH 'N' STEAM - Our comfortable and flexible combi steamer series.
MORE
SPACE
PALUX TOUCH 'N' STEAM - Our comfortable and flexible combi steamer series.
Smart Kitchen Solutions
“made in Germany” since 1929

As experts for professional kitchens     Together with our customers we develop
we are aware of the importance of        well-planned, individual kitchen solutions
comprehensive consulting and longterm    and assist with the entire concept design,
assistance to customers.                 implementation, startup and after-sales
                                         service.
We design and produce state of the art
kitchen technology for maximum demands   We realise precision-made and efficient
in:                                      concepts, local and abroad – with our
„ Hotel business                         partners and consultants.
„ À la carte gastronomy – from
    country inn to star restaurant
„ Communal catering
„ System gastronomy
„ Bistros & snacks
PALUX TOUCH 'N' STEAM - Our comfortable and flexible combi steamer series.
Everything from a single source
The comprehensive know-how of our staff       All our knowledge, our experience and
secures the high quality standards of the     commitment contribute to our work –
PALUX products as well as their profes-       because a good concept saves time and
sional on-time installation.                  prevents stress.

Before commissioning, our chefs share         PALUX is the only manufacturer and full-
tips and tricks for the handling and opera-   range provider of professional commer-
tion of the new kitchen.                      cial kitchens and represents excellent
                                              quality – simply “made in Germany”.
PALUX TOUCH 'N' STEAM - Our comfortable and flexible combi steamer series.
From chef to chef!
       Time-shifted production – a solution we often employ

       We know the industry, and with our kitch-                              1. O R G A NI S IN G
       en concepts we respond to your custom
                                                                              2 . P R E PA R IN G
       demands. An example is the time-shifted
       production, which makes for stress-free                                3 . C O O K IN G
       working by utilising, amongst others, the                              with PALUX Vario Pan

       PALUX Touch 'n' Steam, PALUX Pressure               PALUX
                                                                              4 . BL A S T CHIL L IN G
       Steamer, PALUX Vario Pan and the PALUX           time-shifted          with PALUX BlastChiller BC
                                                         production
       GreenVAC®.
                                                                              5 . S T O R IN G
                                                                              with GreenVAC ®
       Serving a menu to hotel guests, preparing
                                                                              6 . V I TA L I S IN G
       the culinary aspect of events or handling                              with PALUX Touch ‘n‘ Steam
       catering orders without effort: Time-shift-
                                                                              7. S E R V IN G
       ed production lets you easily master all
       these challenges while leaving more time
       for the great freedom in the kitchen. We        We enable you to prepare and cook food
       realise your custom-tailored kitchen – co-      or menus, independently of the daily rou-
       ordinated to your individual kitchen routine    tine, for example, by moving mise en place
       – with high-performance multifunction           production to less busy operating times.
       appliances.                                     If necessary, you can vitalise the compo-
                                                       nents to the point with high quality.
       Your advantages:
       „  Saving time and energy                       The PALUX concept of time-shifted pro-
       „ Optimising personnel resources                duction is one of the keys for permanent
       „ You will cook at a consistently high level   economic success.

10 |
OUR SERVICES
       – TOGETHER WITH OUR LOCAL PARTNERS –

   DEMAND ANALYSIS AND CONSULTING

   CONCEPTUAL DESIGN AND PLANNING

      MANUFACTURING IN GERMANY

IMPLEMENTATION AND PROJECT MANAGEMENT

                AFTER-SALES
PALUX TOUCH 'N' STEAM QL

FLEXIBLE AND
HIGHLY EFFICIENT.
PALUX Touch 'n' Steam QL in gas and electrical version
   True capacity and flexibility genius – thanks to larger cooking chamber.

The starter model            The all-rounder                       The powerful team               The capacity genius
PALUX Touch 'n' Steam        PALUX Touch 'n' Steam                 PALUX Touch 'n' Steam           PALUX Touch 'n' Steam
611 QL / 621 QL with         1011 QL / 1021 QL with                Combi Mix Station QL with       2011 L / 2021 Q with
6 inserts GN 1/1 or GN 2/1   10 inserts GN 1/1 or GN 2/1           6/10 inserts GN 1/1 or GN 2/1   20 inserts GN 1/1 or GN 2/1

                                      More information on the Touch 'n' Steam product series
                                                 is available at www.palux.com                                                   | 13
All the advantages of the powerful QL models at a glance:

       „   Flexible 4-in-1 Maxi Rack System –                   „   Wide range of models – from table-top
           vary at any time between 4 possible                      6 x GN 1/1 up to large free-standing
           container sizes                                          20 x GN 2/1

       „   GN 1/1 lengthwise and crosswise                      „   Adjustment of equipping and loading
           insertion, GN 2/1 crosswise insertion,                   according to requirements
           Baking Tray or Maxi Tray
                                                                „   Best cooking results even when cook-
       „   Unbeatable in terms of capacity, flexi-                  ing chamber is fully loaded
           bility and quality
                                                                „   Gas version with state-of-the-art
       „   A plus in plates in the banquet business                 forced draught burner technology

            Efficient and versatile: the large cooking              300, 600 or more plates can be perfectly
            chamber and the 4-in-1 rack system offer                vitalised and immediately served hot in no
            space for a wide variety of GN containers,              time with the mobile rack for plates for the
            trays, inserts and grates.                              banquet system.

                                   More information on the Touch 'n' Steam product series
14 |                                          is available at www.palux.com
MORE SPACE

FOR THE
PRODUC-
TIVITY.
STAY EXTREMELY
FLEXIBLE WITH
JUST ONE DEVICE.
WE OFFER YOU
OPTIMUM USE OF
COOKING SPACE.
S T E A M   1011 QL
         '
TOUCH 'N                          N
           S S W I S E INSERTIO
WITH CRO                   N TAINERS!
                    N  C O
          O 20 G
 FOR UP T

                                         MORE
                                        OUTPUT
PALUX TOUCH 'N' STEAM SL
                  S T E A M   1011 QL
                '
    TOUCH 'N                    IN S E R T ION
                  GT H W  I S E
    W I T H L EN                  N TAINERS
                          N  C  O
                 O 10 G
     FOR UP T

                                                 POWERFUL AND
                                                 SPACE-SAVING.


PALUX Touch 'n' Steam design SL in electrical version
                          Powerful and slim – thanks to compact design.

The smart starter model   The black design                  The powerful slim one             The space saver         The power tower
PALUX Touch 'n' Steam     PALUX Touch 'n' Steam             PALUX Touch 'n' Steam             PALUX Touch 'n' Steam   PALUX Touch 'n' Steam
623 SL with               623 SL Black Edition with         611 SL with                       1011 SL with            Combi-Duo-Station with
6 inserts GN 2/3          6 inserts GN 2/3                  6 inserts GN 1/1                  10 inserts GN 1/1       2x 6 inserts GN 1/1

                                               More information on the Touch 'n' Steam product series
                                                          is available at www.palux.com                                                        | 19
All the advantages of the compact SL models at a glance:

       „   Fits perfectly in small and large                   „   Wide range of equipment variations
           kitchens                                                and options

       „   Maximum performance and minimum                     „   Models 623 SL, 611 SL and 1011 SL
           space requirement                                       also available as Black Edition

       „   Width of only 550 mm – for best use of              „   Perfect for the PALUX concept of
           space in your kitchen                                   time-shifted production

               The SteamTeam                                             The Cool Combination
               Simultaneous roasting and steaming in                     Perfect addition to the PALUX concept
               the world's smallest kitchen – no prob-                   of time-shifted production: directly
               lem with the PALUX Pressure Steamer                       after preparation in the Touch 'n' Steam,
               and a matching Touch 'n' Steam 611 SL in                  pre-produced food can be cooled down in
               the substructure.                                         the PALUX BlastChiller BC 511 SL.

                                  More information on the Touch 'n' Steam product series
20 |                                         is available at www.palux.com
MORE SPACE

FOR THE
ESSEN-
TIALS.
PALUX TOUCH 'N' STEAM
BUILT-IN VERSION

ELEGANT AND
INTEGRATED.
PALUX Touch 'n' Steam Built-In Version

The Touch 'n' Steam 623 SL is also available as a built-in version with an elegant design
for perfect integration into your office kitchen, kitchens in communal facilities, kinder-
gardens or schools or for kitchens in residential groups in nursing homes and eat-in
kitchens in retirement homes.

All advantages of the integrated built-in version at a glance:

„   Space-saving and elegantly installed             „   Best cooking climate inside the cooking
                                                         chamber for perfect results
„   Especially easy to service and clean
    due to removable 90° rotary function             „   Quickly ready for operation and signifi-
                                                         cant reduction of operating costs
„   Access to the outside of the unit as well
    as to the inside of the cabinet is possi-        „   Integrated self-cleaning system for
    ble at any time                                      economical hygiene of the cooking
                                                         chamber
„   Easy, intuitive and safe operation

                        More information on the Touch 'n' Steam product series
                                   is available at www.palux.com                                    | 23
WHETHER ROASTING,
COOKING, GRILLING
OR BAKING.
WE HAVE EXACTLY
THE RIGHT ACCES-
SORIES FOR IT.
Equipment variants & accessories

Flexibility is when you can effortlessly handle a wide variety of workload situations
with one device. With the extensive PALUX Touch 'n' Steam accessories you can master
all types of preparation.

Excerpt from our range of accessories:
                                                      „   Roll-in trolley for GN trays, grids and
„   Liquid or powder cleaner                              containers

„   Retractable spray nozzle                          „   Roll-in trolley for plates with thermal
                                                          hood for banquet system
„   Heat exchanger
                                                      „   Miscellaneous substructures made of
„    ondensation hood for condensing the
    C                                                     chromium nickel steel
    vapours produced during cooking
                                                      „   Numerous sheets, trays and grids for
„   Mobile rack for plates made of chromi-                frying, cooking, grilling and baking
    um nickel steel for banquet system

             For further information on the equipment variants and the range of accessories,
                             please contact your PALUX sales representative.                        | 25
REFERENCES –
FOR PASSION IN
PERFECTION.
STAR RESTAURANTS
Our references include:

„   Haus Stemberg in Velbert-Neviges (Germany)
„   Landhaus Feckl in Ehningen (Germany)
„   Maison Lameloise in Shanghai
„   Restaurant KUNO 1408 in Würzburg (Germany)
„   Restaurant Maximilian Lorenz in Cologne (Germany)

TRANSPORT AND
SYSTEM CATERING
Our references include:

„   bäck stage in Mössingen (Germany)
„   Landmetzgerei Witt (country butcher's shops) in
    Windischeschenbach (Germany)
„   SELGROS Cash & Carry Romania in Brasov

COMMUNAL, COMPANY AND
SOCIAL CATERING
Our references include:

„   Company restaurant of Bürkert Werke in
    Ingelfingen (Germany)
„   Diabetes Klinik in Bad Mergentheim (Germany)
„   School Canteen of the Children's, Youth and Culture
    House in Oberhaid (Germany)
BANQUET BUSINESS
Our references include:

„   Comfort Hotel Frankfurt/Main Airport West (Germany)
„   Courtyard by Marriott in Garching near Munich (Germany)
„   International Convention and Exhibition Center
     in Sydney (Australia)
„   Welcome Hotel in Neckarsulm (Germany)

EDUCATION AND
TRAINING CENTRES
Our references include:

„   Block Chef Akademie in Zarrentin (Germany)
„   Instytut Kulinarny Transgourmet in Piaseczno
    near Warsaw (Poland)

HOTELS UND RESTAURANTS
Our references include:

„   Brasserie Fleurie in Rosmalen (Netherlands)
„   Cucinino Pasta Bar in Brasov (Romania)
„   Hotel Eisenhut in Rothenburg o. d. T. (Germany)
„   Kaftan Restaurant in Dubai (U. A. E.)
„   Restaurant Joelia at the Hilton Hotel in Rotterdam (NL)
„   Restaurant Parkzicht in Roermond (Netherlands)
TECHNICAL DATA

                                623 SL          623 SL                                                                                             2011 L
       MODEL                                                  611 SL        1011 SL       611 QL        621 QL        1011 QL      1021 QL
                                (230 V)         (400 V)                                                                                          (34,6 kW)

       Dimensions              550 x 629 x     550 x 629 x   550 x 809 x   550 x 809 x   980 x 795 x   980 x 795 x   980 x 795 x   980 x 795 x   1115 x 875 x
       (L x D x H) mm             764             764           764           1004          840           840           1120          1120          1925

       Connected Load kW          3,8              6,3          8,6            11            11           18,6          16,4          33,5          34,6

                               230 V 1 N        400 V 3 N    400 V 3 N     400 V 3 N     400 V 3 N     400 V 3 N     400 V 3 N     400 V 3 N      400 V 3 N
       Voltage V/Hz
                               50/60 Hz         50/60 Hz     50/60 Hz      50/60 Hz      50/60 Hz      50/60 Hz      50/60 Hz      50/60 Hz       50/60 Hz

       Fuse A                    1 x 16          3 x 16        3x 16         3x 16         3 x 16        3 x 32        3 x 25        3 x50          3 x 63

       Direct Heat
                                  0,46            0,76          1,03          1,32          1,32          2,23          1,97          4,02          4,15
       Emission kW

       Latent Heat
                                  0,68            1,13          1,55          1,98          1,98          3,35          2,96          6,03          6,23
       Emission kW

       Steam
                                  1,01            1,67          2,28          2,92          2,92          4,93          4,35          8,87           9,17
       Emission kg/h

       Range of
                                30 - 250        30 - 250      30 - 250      30 - 250      30 - 250      30 - 250      30 - 250      30 - 250      30 - 250
       temperature °C

       Kind of inserts GN         2/3             2/3           1/1           1/1           1/1           2/1           1/1           2/1            1/1

       Quantity of inserts         6               6             6             10            6             6             10            10            20

       Grate distance mm           60              60            60            60            67            67            67            67            67

       Water Drain Ø mm            40              40            40            40            40            40            40            40            50

                               2x G 3/4 A      2x G 3/4 A    2x G 3/4 A    2x G 3/4 A    2x G 3/4 A    2x G 3/4 A    2x G 3/4 A    2x G 3/4 A    2x G 3/4 A
       Water Supply
                               KW/KWE          KW/KWE        KW/KWE        KW/KWE        KW/KWE        KW/KWE        KW/KWE        KW/KWE        KW/KWE

       Banquet system plates
                                   –               –             –             –             24            24            40            40          80/102
       (Ø 320mm/280mm)

       Nominal Thermal
                                   –               –             –             –             –             –             –             –              –
       Load kW

       CE Id.-No.                  –               –             –             –             –             –             –             –              –

30 |                                        Subject to changes in performance, dimensions and construction.
TECHNICAL DATA

                          2011 L          2021 Q        2021 Q          Gas           Gas            Gas          Gas            Gas            Gas
MODEL
                         (44 kW)        (51,5 kW)      (67,1 kW)       611 QL        621 QL        1011 QL      1021 QL         2011 L         2021 Q

Dimensions              1115 x 875 x    1115 x 875 x   1115 x 875 x   980 x 795 x   980 x 795 x   980 x 795 x   980 x 795 x   1115 x 875 x   1115 x 875 x
(L x D x H) mm             1925            1925           1925           840           840           1120          1120          1925           1925

Connected Load kW           44             51,5            67,1          0,8           0,8           0,8           0,8            0,8            1,6

                         400 V 3 N       400 V 3 N      400 V 3 N     230 V 1 N     230 V 1 N     230 V 1 N     230 V 1 N      230 V 1 N      230 V 1 N
Voltage V/Hz
                         50/60 Hz        50/60 Hz       50/60 Hz      50/60 Hz      50/60 Hz      50/60 Hz      50/60 Hz       50/60 Hz       50/60 Hz

Fuse A                     3 x 63          3 x 80        3 x 100        1 x 16        1 x 16        1 x 16        1 x 16         1 x 16         1 x 16

Direct Heat
                           5,28            6,18           8,05           2,07          3,3           3,3           4,8            6,6             9
Emission kW

Latent Heat
                           7,92            9,27           12,08          2,48          3,96          3,96          5,76          7,92           10,8
Emission kW

Steam
                           11,66           13,65          17,78         3,657          5,83          5,83          8,48          11,66          15,9
Emission kg/h

Range of
                         30 - 250        30 - 250       30 - 250       30 - 250      30 - 250      30 - 250      30 - 250      30 - 250       30 - 250
temperature °C

Kind of inserts GN          1/1             2/1            2/1           1/1           2/1           1/1           2/1            1/1            2/1

Quantity of inserts         20              20             20             6             6             10            10            20             20

Grate distance mm           67              67             67             67            67            67            67            67             67

Water Drain Ø mm            50              50             50             50            50            50            50            50             50

                        2x G 3/4 A      2x G 3/4 A     2x G 3/4 A     2x G 3/4 A    2x G 3/4 A    2x G 3/4 A    2x G 3/4 A     2x G 3/4 A     2x G 3/4 A
Water Supply
                        KW/KWE          KW/KWE         KW/KWE         KW/KWE        KW/KWE        KW/KWE        KW/KWE         KW/KWE         KW/KWE

Banquet system plates
                          80/102          80/102         80/102           24            24            40            40          80/102         80/102
(Ø 320mm/280mm)

Nominal Thermal
                             –               –              –            13,5           22            22            30            44             60
Load kW

CE Id.-No.                   –               –              –            0063          0063          0063          0063          0063           0063

                                       Subject to changes in performance, dimensions and construction.                                                      | 31
PALUX Touch 'n' Steam | 2nd Edition | 03.2020 | Order No. 800139
PALUX Aktiengesellschaft                                 Your regional contact
Wilhelm-Frank-Straße 36
D-97980 Bad Mergentheim
Germany
Contact:
Phone: +49 7931 55 0
Fax: +49 7931 55 88600
info@palux.de
www.palux.com
facebook-f instagram PINTEREST-P youtube xing LINKEDIN
You can also read
