Measurement technology
for medical and environmental application
m-u-t GmbH – Your strong partner
Company presentation m-u-t GmbH
November 2020 – Medica & Compamed
Präsentationsname 1
8 powerful brands within the nynomic group
ensure successful solution development
Präsentationsname 2
Worldwide footprint of the nynomic group
supporting our customers
LayTec AG
tec5 AG Berlin, GER m-u-t GmbH
Oberursel, GER Wedel, GER
tec5 USA Inc. APOS GmbH
Plainview, USA Avantes B.V. Wedel, GER Spectral Engines OY
Apeldoorn, NED Helsinki, FIN
Avantes China Ltd.
Beijing, CHN
Avantes Inc.
Louisville, USA
tec5 China Ltd.
LemnaTec GmbH Beijing, CHN
Avantes UK Ltd. Aachen, GER
Leatherhead, GBR
Sensortherm GmbH
Sulzbach, GER
Avantes Hong Kong Ltd.
Hong Kong, HKG
Präsentationsname 3
The Nynomic group and its subsidiaries:
Strong partners for solution development
Board of Directors: Fabian Peters, Maik Müller
Net Sales 2019: 64.9 Mio. EUR
Employees: > 425
Foundation: 1995
IPO: 2007, Stock Segment "Scale"
Stock code: A0MSN1
Further Information: www.nynomic.com
Group Nynomic / development of sales
Präsentationsname 4
History of the nynomic group Präsentationsname 5
Together the Nynomic Group expands and
complements their reach and portfolio
Industrial and pro handheld, Prosumer and consumer,
Industrial, low-volume
mid-volume high-volume
Solutions
Value Creation / Level of Integration
Systems
Components
Präsentationsname 6
Eight Brands – one Product Portfolio
The whole spectrum of non-destructive optical measurement!
Präsentationsname 7
Brief overview of m-u-t GmbH
Management: Fabian Peters, Axel Witte
Net Sales: >20 Mio. EUR
Employees: approx.120
Foundation: 1995
Location: Wedel (Hamburg-region)
Further Information: www.mut-group.com
Präsentationsname 8
Growing markets within the m-u-t GmbH:
Spectrometric measurement and automation technology
Green Tech
• Agricultural Technology
Clean Tech • Environmental Technology
• Transportation
• Fire Detection
• Industrial Sensing
Life Science
• Medical Technology
• Lab Automation
Präsentationsname 9
Integrated product development process
guarantees fast, safe and efficient results
Technical support during concept phase
Detailed concept-planning
and development at fixed cost and time
Series development
certification and documentation
Cost efficient production
State-of-the-Art Quality Systems
Lifecycle Management
Präsentationsname 10Application development
from detector to mathematics
Example 1: Moisture and content detection in-line
• NIRS or NIR-Photometer technology
• Measurement of quality parameters during the harvesting process
• In-line dry mass detection on the field chopper for corn, grass, lucerne
• Optimization of the machine control
Example 2: Manure turnout & harvest control
• Contents analysis of manure in-line during turnout
• Directly in the goods flow
• Direct communication with central machine control
• Nutrient matter balancing and proof of turnouts
• Flexible use for different analysis methods through
individual calibration
Präsentationsname 11Spectrometer systems for control
safeguarding your investment
Example 1: Multi Gas Sensor for oxygenated hydrocarbons
• Infrared Multi Gas Sensor using NDIR-Technology
• No chemical reaction inside Multi Gas Sensor, no calibration gases
necessary – high long-term stability
• 8 gases in 1 Sensor - no interference between gases
• CO, CO2, CH4, C2H2, C2H4, C2H6, mm to be detected
Example 2: Early Fire Detection
• Integrated distance measurement
• Unique object detection: Detection of smallest hot
spots surrounded by much larger ‟allowed“ heat
sources (e.g. trucks)
• Modularity
• 24/7 usability in rough environments
Präsentationsname 12Medical technology and lab automation
‟one-stop-solution” to sort, identify and control
quality
Example 1: Bulk-Input-Module for a Total Laboratory Automation (TLA)
Solution
• Fast-track product development footing on the modular m-u-t concept
for lab automation applications
• Bulk sample seperation at input station
• Identification and quality control of the sample (barcode, geometry,
cap color, mm.)
• Placing the sample tube in the rack of your TLA-System
Example 2: Sensors for quality control
• For instrument processing devices
• Identification of the instrument and of the personnel using
smart RFID-Technology
• Process documentation of tightness and flow rate control of the
instrument
Präsentationsname 13Cloud possibilities of the m-u-t GmbH
• Industry 4.0
• High availability
• Easiest update and maintenance options
• Measured values can be stored and recalled in the cloud
• Maintenance and update of devices via remote access (internal or external)
Cloud-database
Upload of spectra and Display of measured
measurement data values and spectra
Upload of warning and error Remote maintenance of
messages the sensor
Download of firmware and model Upload of new models
updates and firmware
Access to measured
values via app/web
portal possible
Präsentationsname 14Applications of various specifications and
Business Cases
Process Data Network Functions/Scope
Communication
m-u-t or
customer device Status
Storage
Cloud Functions/
Data Analysis/
Calibration
Device
Administration
Maintenance
Präsentationsname 15Service examples of the m-u-t Cloud
Response times can be greatly improved by the cloud
• If you need support as an end customer, we can react immediately via the cloud
• Warning and error messages can be read and important tests can be performed
Customers receive important updates for the calibration models via the cloud
• New model versions can be transferred to the measuring devices via the cloud
• If required, spectra can be stored and a reference sample can be taken
Web server and mobile app offer a better service to the end customer
• Web server and mobile app can be created in the corresponding design of the customer
• The customer has access to his measurement data via the web portal and the app
• Measurement data can be easily exported (e. g. as Excel file)
• Calibration models could be bought or updated via the web portal or the app
• After purchase, the calibration models are transferred to the meter via the cloud
• Current measured values can be read out in real time
Präsentationsname 16Our service as an
OEM developer and manufacturer
Technology Development
• The full spectrum of photonic innovations • Creative and agile during the concept phase
• Robotics, automation, control-systems, • Efficient in product development
software
• Lifecycle management
• Component portfolio for laboratory
• Obsolescence management
automation
Production Logistics
• Flexible batch-controlled serial • A modern ERP-system for fast order
production based on LEAN and SIX- processing and optimal traceability
SIGMA principles
• Warehousing and material
• Short production times management
• Fast and efficient serial transfers • Supplier management and
qualification
Regulatory
• Clear product compliance
§ Service
• In-house and on-site support
• Medical devices, In-Vitro Diagnostics • Remote maintenance and phone support
• Automotive, semiconductor • All service levels possible
• Agricultural, railway, VdS Quality • ESD and separate desinfection area
• State of the art quality system
• Separate quality assurance for development,
production and logistics
• ISO 13485, ISO 9001
Präsentationsname 17Thank you for your attention! Präsentationsname 18
