TIME SWITCHES IN-WALL TIMERS PHOTO CONTROLS - TSPC PRODUCT CATALOG
TSPC
PRODUCT CATALOG

TIME SWITCHES
IN-WALL TIMERS
PHOTO CONTROLS
TIME SWITCHES IN-WALL TIMERS PHOTO CONTROLS - TSPC PRODUCT CATALOG
ELECTRICAL INNOVATION SINCE 1909

    Benjamin Franklin Flegel founded Reliance Automatic Lighting Company in 1909 with a passion
    for inventing innovative, highly engineered, quality products that would make life easier for a
    rapidly growing group of U.S. consumers.
    His first product, a superior mechanical lighting time control, quickly gained acceptance for
    its quality, durability and accuracy. Reliance’s reputation for excellence in engineering and
    manufacturing fueled the company’s growth over the succeeding 110 years.
    The present-day Reliance Controls Corporation now offers over 700 products in 14 categories.
    Reliance Controls is still based in Racine, Wisconsin and remains family owned and operated with
    pride by the fourth generation of the Flegel family.
    This catalog outlines our offering of
    Time Switches, In-Wall Timers and Photo Controls

1
TIME SWITCHES IN-WALL TIMERS PHOTO CONTROLS - TSPC PRODUCT CATALOG
TABLE OF CONTENTS
                                          MECHANICAL TIME SWITCHES 24 Hour������������������5
                                           Metal Enclosures - Indoor Type 1 ������������������������������������������� 9
                                           Polycarbonate Enclosures- Indoor/Outdoor Type 3R��������� 9
                                           Metal Enclosures Indoor/Outdoor Type 3R��������������������������� 9
                                           Water Heater Timer- Indoor Type 1 �������������������������������������15
                                           Replacement Mechanisms�����������������������������������������������������16
                                           Time Switch Accessories�������������������������������������������������������18
                                          IN-WALL TIMERS� �����������������������������������������������������19
                                           Springwound ���������������������������������������������������������������������������23
                                           Countdown�������������������������������������������������������������������������������24
                                           Programmable Electronic �����������������������������������������������������25
                                           Electronic ���������������������������������������������������������������������������������26
                                          PHOTO CONTROLS� �������������������������������������������������27
                                           Thermal �����������������������������������������������������������������������������������28
                                                 Button and Wall Mount���������������������������������������������������29
                                                 Fixed Position Stem Mount���������������������������������������������30
                                                 Stem and Swivel Mount���������������������������������������������������31
                                                 Locking Mount�����������������������������������������������������������������32
                                           Electronic ���������������������������������������������������������������������������������33
                                                 Button and Wall-Mount ���������������������������������������������������33
                                                 Fixed Stem Mount �����������������������������������������������������������33
                                                 Stem and Swivel Mount���������������������������������������������������33
                                                 Locking Mount�����������������������������������������������������������������34
                                           Locking Mount Receptacles and Shorting Cap�����������������34
                                           Photo Controls Specifications�����������������������������������������������35
                                          CROSS REFERENCE������������������������������������������������37

All products in this catalog are listed
by Underwriters Laboratories Inc.

RelianceControls.com

                                                                                                                                             2
TIME SWITCHES IN-WALL TIMERS PHOTO CONTROLS - TSPC PRODUCT CATALOG
Using our Catalog
    ������������������������������������������������������������������������������������������������������

    PRODUCT CATEGORY
    COLOR CODED
    PAGE TAB

                                                                                                                   ELECTRICAL INNOVATION SINCE 1909

    MODEL/SERIES                                                                                                                                                                                                                          MODEL NUMBERS
    COLOR CODED                                                              120 VAC SPST                                                        INDUSTRIAL GRADE
                                601 / 601P / 601R MECHANICAL TIMERS

                                                                                                                                                                                                       Rated

    PAGE TAB                                                          MODEL NUMBER                                  MODEL NUMBER                                           MODEL NUMBER
                                                                      601     METAL - Indoor                        601P
                                                                                                                   NON-METALLIC                      METAL - Indoor/Outdoor601R
                                                                                                                                                                                                                                          PRODUCT MATERIAL


                                                                                                                                                                                                                                          & LISTINGS
                                                                                         NEMA 1
                                                                                         Rated
                                                                                                                                         NEMA 3R
                                                                                                                                         Rated
                                                                                                                                                                                                          NEMA 3R
                                                                                                                                                                                                          Rated

    PRODUCT PHOTOS                                                                      POWDER COATED
                                                                                        STEEL
                                                                                                                                           HIGH IMPACT
                                                                                                                                           POLYCARBONATE                                               POWDER COATED
                                                                                                                                                                                                       STEEL

                                                                      FEATURES                                                              RATINGS
                                                                      • Industrial grade high-impact cabinets                               Switch �������������������������������������������������� SPST
                                                                      • All models have reversible door hinges for tight spaces             Timing Motor ������������������������������������ 120 VAC 60 Hz, 4 Watts
                                                                      • NEW low-profile housings- lockable                                  Contact Voltage ������������������������������ 120-240 VAC, 60Hz
                                                                                                                                            Resistive, Inductive, Tungsten ��� 40A, 120-240 VAC
                                                                      • Large 3 1/2” dials rotate clockwise for intuitive time setting

    FEATURES,
                                                                                                                                            Electronic Ballast / LED��������������� 16A 120 VAC, 8A 240 VAC
                                                                      • Up to 16 ON/OFF operations per day
                                                                                                                                            Motor Load ���������������������������������������� 2 HP 120 VAC, 5HP 240 VAC

    DESCRIPTIONS &
                                                                      •
                                                                      •
                                                                        Large finger-set trippers for no-tools operation
                                                                        Fully enclosed long life timing motors
                                                                                                                                            Operating Temperature���������������� -40*F to 130*F (-40*C to 54*C)
                                                                                                                                            Pilot Duty �������������������������������������������� 1000 VA, 120-240 VAC
                                                                                                                                                                                                                                          RATINGS &
    APPLICATIONS
                                                                      • 600P and 600R-series models have locking swing down wiring
                                                                        compartment cover with extra tripper storage
                                                                      • 600-series models have sturdy plastic screw-down wiring
                                                                                                                                            Enclosure ������������������������������������������� NEMA 1 600P and 600R-Series
                                                                                                                                                                                                      NEMA 3R / Lockable Hasp
                                                                                                                                            Enclosure Dimensions������������������ 600P and 600R-Series
                                                                                                                                                                                                                                          WIRING DIAGRAMS
                                                                        compartment covers                                                                                                            H� 7 3/4” x W� 4 5/8” x D� 2 7/8”
                                                                      • 600P-series has patented POP-FAST hole knockouts -                                                                            600-Series
                                                                                                                                                                                                      LEAVE OPEN AND MARK
                                                                        no tools required
                                                                                                                                            Knockouts������������������������������������������ Combination 1/2” - 3/4” nominal,
                                                                                                                                                                                                      one on back and on each side
                                                                      GREAT FOR CONTROLLING                                                                                                           and two on bottom (600P-series
                                                                      Pumps and compressors              Commercial lighting                                                                          has reusable knockouts)
                                                                                                         and signs                          Wire Size �������������������������������������������� #8 - #14 AWG
                                                                      Pools and spas
                                                                                                         Electric motors                    Warranty ��������������������������������������������� 2 Years
                                                                      Heating and air conditioning

                                                                                                                                            WIRING DIAGRAM
                                                                      FOR USE WITH THESE LIGHTING TYPES                                      601                                                                            G
                                                                                                                                             WIRING DIAGRAM                          SWITCH
                                                                                                                                             SPST

                                                                                                                                                                                       TIMING
                                                                                                                                                                                       MOTOR

                                                                                                                                                            L1                                                        L1
                                                                                                                                                           120V                                                      120V

    HOW TO VIDEOS
                                                                                                                                               AC                                                                           LOAD
                                                                                                                                             SUPPLY               L1 in      L2 in      N        L2 out     L1 out

    AVAILABLE ONLINE
                                                                               INSTALLATION VIDEO AT                                                    NEUTRAL                                                   NEUTRAL
                                                                               RELIANCECONTROLS.COM

                                        9

    Icon Legend
         Product is made from metal                                                                                                                                                                          Product is industrial grade

          Product is made from polycarbonate                                                                                                                                                                 Product has installation video online

         Product is made from Powder Coated Steel                                                                                                                                                            Snap-In timer mechanism

    NEMA  3R Product is weather proof / NEMA 3R Rated                                                                                                                                                        Product has full clock dial numbering
    Rated

         Product is made from a high-impact UV-Coated polycarbonate                                                                                                                                          Lockable tamper-resistant enclosure

           Product is LED Rated                                                                                                                                                                              Hinged locking wiring compartment cover

         Product is Halogen Rated                                                                                                                                                                            Product has large head easy-to-grip tripper screws

         Product is HID Rated                                                                                                                                                                                Product has left or right hinging options

         Product is Incandescent Rated                                                                                                                                                                       Saves Energy

         Product is Fluorescent Rated                                                                                                                                                                        Dusk To Dawn Light Control

         Single or Multigang

3
TIME SWITCHES IN-WALL TIMERS PHOTO CONTROLS - TSPC PRODUCT CATALOG
Using our Website
��������������������������������������������������������������������������������������������������

This catalog is available online at RelianceControls.com in an easy to navigate flip-page format. Products can be

                                                                                                                            MECHANICAL TIME SWITCHES
located quickly by entering the model number in the search box. Our online catalog is designed for on-location product
presentations as well as for end user reference during installations. Installation videos accompany many of our products.

                                                                                                                            4
TIME SWITCHES IN-WALL TIMERS PHOTO CONTROLS - TSPC PRODUCT CATALOG
24 Hour Mechanical

    TIME SWITCHES

    Based on over 100 years of manufacturing the most innovative products of
    its era, Reliance Controls offers its 2020 version of a full-line of time switches
    packed with all-new user and safety features:
    For controlling lighting, pools and spas, pumps and compressors, heating and
    air conditioning, farm, commercial and municipal lighting and signs, electric
    motors and many other types of electrical loads.

5
TIME SWITCHES IN-WALL TIMERS PHOTO CONTROLS - TSPC PRODUCT CATALOG
MECHANICAL TIME SWITCHES

                           6
TIME SWITCHES IN-WALL TIMERS PHOTO CONTROLS - TSPC PRODUCT CATALOG
ELECTRICAL INNOVATION SINCE 1909

                           INDUSTRIAL STRENGTH
MECHANICAL TIME SWITCHES

                           POLYCARBONATE HOUSING                   LARGER 3.5” HIGH-VISIBILITY BLUE DIAL
                                                                   WITH FULL CLOCK DIAL NUMBERING

                                                                            LARGE HEAD EASY-TO-GRIP
                                                                            TRIPPER SCREWS
                           HINGED
                           LOCKING WIRING
                           COMPARTMENT
                           COVER ON
                           600P AND                                                    LOW PROFILE CABINET
                           600R-SERIES

                                                                                           LEFT OR RIGHT
                                                                                           HINGING OPTIONS FOR
                                                                                           BEST-FIT INSTALLATION
                             POP-FAST                                                      IN TIGHT PLACES
                             KNOCKOUT
                             HOLES /
                             REPLACEABLE
                             NO TOOLS
                             REQUIRED ON
                             600P-SERIES
                                                                                           LOCKABLE
                                                                                           TAMPER-RESISTANT
                                                                                           ENCLOSURE

                               2 EXTRA TRIPPERS
                               WITH HANDY STORAGE
                               ON 600P AND
                               600R-SERIES

                                                                      COLORFUL,
                                                                  INFORMATIONAL
                                                                        CARTON

                                      NEMA
                                      Rated
                                            3R NEMA
                                               Rated
                                                     1
                                                                Rated

     7
TIME SWITCHES IN-WALL TIMERS PHOTO CONTROLS - TSPC PRODUCT CATALOG
24 HOUR MECHANICAL TIME SWITCHES

Product Features

                                                                                                                                               MECHANICAL TIME SWITCHES
CIRCUIT ID LABELS                                                                                                  POLYCARBONATE CABINET HAS
                                                                                                                   POP-FAST KNOCKOUT HOLES-
                                                                                                                   NO TOOLS REQUIRED

METAL CABINET                                                                                                      POLYCARBONATE CABINET
REVERSIBLE HINGES                                                                                                  REVERSIBLE HINGES

      MOOD EL 6W0IT1CR
                     H
                                                                                     NEMA 3R
                                                                                        Rated
         UR TIME S  ROW (SPS
                            T)
      24 H POLE SINGLE TH IVE, TUNGSTEN 120 VAC              INDOOR
                                                                    / OUTD                      OOR

      SINGLE SISTIVE, INDUCT C
      40 AM P RE           12 0 VA
                  LOT DUTY
       1000 VA PI0V AC               T 120 VAC
       2 HP – 12 ECTRONIC BALL AS                               .
       16 AMP  EL                                   LTS - 60 HZ
                                           0-125 VO             SPECIFIED.
                                  OTOR: 11
                       CLOCK M              CY CL E M UST BE AS
                                 LTAG E AND
                       OTOR VO
              CLOCK M

INSIDE COVER INSTRUCTION LABELS                                                                                    EXTRA TRIPPER STORAGE

                                                                                  L
                                                                          TIME DIA
                                                            RE
                                            VER BEFO                                  T TIME
                          WIRING CO                                           CURREN R
            REPL ACE N ELECTRICIT Y                                            INDICATO

                 RN  IN G O
            TU                                ROTATE                            ON
                             LL DIAL –                                          TRIPPER
             DO NOT PU TO SET TIME
                  O C KW  ISE                                 rre nt             OFF
             CL                               ates from cu ” terminal            TRIPPER
                            motor oper                   d “N
             The timing “L1 in” terminal an connected
              supplied toand these must be ltage and                              ON/OFF
                                                                                  LEVER
              (prewired) terrupted circuit of vo
               to an unin shown above.                                                                    rmit
                                                                                               ough to pe
                frequency                                                       b screws en
                                                                  pper thum
                                          TI  M ES  : loosen tri e dial.
                              N/OFF                          of th
                 TO SET O slide along the edge                          N
                 trippers to                               e to turn O
LOCKABLE DOORS    1. Set silve
                                r
                                k
                                  tri
                                   tri
                                      pp
                                       pp
                                         er  for the tim
                                          er fo r th e  tim e to turn O
                                                                    firm
                                                                          FF
                                                                         ly with fingers
                                                                                           (not tools)
                                                                                                       and should  CLEARLY MARKED TERMINALS
                  2. Set bl ac                      retighten   ed
                                   ws must be ainst the dial.                                         se until the
                   Tripper scre                                                          dial clockwithe actual time.
                                    d tightly ag                            AL) rotate
                   be positione                    (D  O  NO   T PULL DI of the dial points to               th
                                                Y:               the center                      position wi
                                  ME OF DA
                    TO SET TI says “current time” on
                    pointer that
                                   that   th e di al and tripper
                                                                   s are set in
                                                                                   the correct
                                                                                                                                               8
                     Make sure night and day.                                       DIAL                         s
                             t to                                  ENTER OF                       the marking
TIME SWITCHES IN-WALL TIMERS PHOTO CONTROLS - TSPC PRODUCT CATALOG
ELECTRICAL INNOVATION SINCE 1909

                                             120 VAC SPST                                                      INDUSTRIAL GRADE
601 / 601P / 601R MECHANICAL TIMERS

                                                                                                                                                                     Rated

                                      MODEL NUMBER                                  MODEL NUMBER                                         MODEL NUMBER
                                      601
                                      �������������������������������� 601P
                                                 METAL - Indoor
                                                                        �������������������������������� 601R
                                                                                                   NON-METALLIC
                                                                                                          ��������������������������������                   METAL - Indoor/Outdoor

                                                         NEMA
                                                         Rated
                                                               1                                         NEMA
                                                                                                         Rated
                                                                                                               3R                                                       NEMA
                                                                                                                                                                        Rated
                                                                                                                                                                              3R

                                                        POWDER COATED                                     HIGH IMPACT                                                POWDER COATED
                                                        STEEL                                             POLYCARBONATE                                              STEEL

                                      FEATURES                                                            RATINGS
                                      • Industrial grade high-impact cabinets                             Switch	�������������������������������������������������� SPST
                                      • All models have reversible door hinges for tight spaces           Timing Motor	������������������������������������ 120 VAC 60 Hz, 4 Watts
                                                                                                          Contact Voltage	������������������������������ 120-240 VAC, 60Hz
                                      • NEW low-profile housings- lockable
                                                                                                          Resistive, Inductive, Tungsten	��� 40A, 120-240 VAC
                                      • Large 3 1/2” dials rotate clockwise for intuitive time setting    Electronic Ballast / LED	��������������� 16A 120 VAC, 8A 240 VAC
                                      • Up to 16 ON/OFF operations per day                                Motor Load	���������������������������������������� 2 HP 120 VAC, 5HP 240 VAC
                                      • Large finger-set trippers for no-tools operation                  Operating Temperature	��������������� -40*F to 130*F (-40*C to 54*C)
                                      • Fully enclosed long life timing motors                            Pilot Duty	�������������������������������������������� 1000 VA, 120-240 VAC
                                      • 600P and 600R-series models have locking swing down wiring        Enclosure	������������������������������������������� 600-Series NEMA 1 600P
                                        compartment cover with extra tripper storage                                                                                and 600R-Series NEMA 3R /
                                                                                                                                                                    Lockable Hasp
                                      • 600-series models have sturdy plastic screw-down wiring           Enclosure Dimensions	������������������ 600P-Series
                                        compartment covers                                                                                                          H. 8 5/8” x W. 6 3/8” x D. 3 1/8’
                                      • 600P-series has patented POP-FAST hole knockouts -                                                                          600R-Series
                                        no tools required                                                                                                           H. 9” x W. 5 3/8” x D. 3”
                                                                                                                                                                    600-Series
                                                                                                                                                                    H. 7 7/8” x W. 4 1/2” x D. 2 3/4”
                                      GREAT FOR CONTROLLING                                               Knockouts	������������������������������������������ Combination 1/2” - 3/4” nominal,
                                                                                                                                                                    one on back and on each side
                                      Pumps and compressors              Commercial lighting                                                                        and two on bottom (600P-series
                                      Pools and spas                     and signs                                                                                  has reusable knockouts)
                                      Heating and air conditioning       Electric motors                  Wire Size	�������������������������������������������� #8 - #14 AWG
                                                                                                          Warranty	��������������������������������������������� 2 Years

                                                                                                          WIRING DIAGRAM
                                      FOR USE WITH THESE LIGHTING TYPES                                    601                                                                            G
                                                                                                           WIRING DIAGRAM                          SWITCH
                                                                                                           SPST

                                                                                                                                                     TIMING
                                                                                                                                                     MOTOR

                                                                                                                          L1                                                       L1
                                                                                                                         120V                                                     120V
                                                                                                             AC                                                                           LOAD
                                                                                                           SUPPLY               L1 in      L2 in      N        L2 out    L1 out

                                                                                                                      NEUTRAL                                                  NEUTRAL

        9
24 HOUR MECHANICAL TIME SWITCHES

                INDUSTRIAL GRADE                                                208-277 VAC SPST

                                                                                                                                                                      602 / 602P / 602R MECHANICAL TIMERS
                                                         Rated

MODEL NUMBER                                   MODEL NUMBER                                            MODEL NUMBER
602
�������������������������������� 602P
           METAL - Indoor
                                  �������������������������������� 602R
                                                                 NON-METALLIC
                                                                    ��������������������������������                      METAL - Indoor/Outdoor

                   NEMA
                   Rated
                         1                                           NEMA
                                                                     Rated
                                                                           3R                                                      NEMA
                                                                                                                                   Rated
                                                                                                                                         3R

                  POWDER COATED                                        HIGH IMPACT                                                POWDER COATED
                  STEEL                                                POLYCARBONATE                                              STEEL

FEATURES                                                               RATINGS
• Industrial grade high-impact cabinets                                Switch	�������������������������������������������������� SPST
• All models have reversible door hinges for tight spaces              Timing Motor	������������������������������������ 208-277 VAC 60 Hz, 4 Watts
                                                                       Contact Voltage	������������������������������ 120-277 VAC, 60Hz
• NEW low-profile housings- lockable
                                                                       Resistive, Inductive, Tungsten	��� 40A, 120-240 VAC
• Large 3 1/2” dials rotate clockwise for intuitive time setting       Electronic Ballast / LED	��������������� 16A 120 VAC, 8A 240 VAC
• Up to 16 ON/OFF operations per day                                   Motor Load	���������������������������������������� 2 HP 120 VAC 5HP 240 VAC
• Large finger-set trippers for no-tools operation                     Operating Temperature	��������������� -40*F to 130*F (-40*C to 54*C)
• Fully enclosed long life timing motors                               Pilot Duty	�������������������������������������������� 1000 VA, 120-240 VAC
• 600P and 600R-series models have locking swing down wiring           Enclosure	������������������������������������������� 600-Series NEMA 1 600P
  compartment cover with extra tripper storage                                                                                   and 600R-Series NEMA 3R /
                                                                                                                                 Lockable Hasp
• 600-series models have sturdy plastic screw-down wiring              Enclosure Dimensions	������������������ 600P-Series
  compartment covers                                                                                                             H. 8 5/8” x W. 6 3/8” x D. 3 1/8’
• 600P-series has patented POP-FAST hole knockouts -                                                                             600R-Series
  no tools required                                                                                                              H. 9” x W. 5 3/8” x D. 3”
                                                                                                                                 600-Series
                                                                                                                                 H. 7 7/8” x W. 4 1/2” x D. 2 3/4”
GREAT FOR CONTROLLING                                                  Knockouts	������������������������������������������ Combination 1/2” - 3/4” nominal,
                                                                                                                                 one on back and on each side
Pumps and compressors              Commercial lighting                                                                           and two on bottom (602P has
Pools and spas                     and signs                                                                                     reusable knockouts)
Heating and air conditioning       Electric motors                     Wire Size	�������������������������������������������� #8 - #14 AWG
                                                                       Warranty	��������������������������������������������� 2 Years

                                                                       WIRING DIAGRAM
FOR USE WITH THESE LIGHTING TYPES                                       602                                                                           G
                                                                        WIRING DIAGRAM                          SWITCH
                                                                        SPST

                                                                                                       TIMING
                                                                                                       MOTOR

                                                                                        L1                                                     L1
                                                                           AC                                                                          LOAD
                                                                         SUPPLY              L1 in      L2 in      N        L2 out    L1 out

                                                                                        L2                                                     L2

                                                                                                                                                                     10
ELECTRICAL INNOVATION SINCE 1909

                                             120 VAC DPST                                                      INDUSTRIAL GRADE
603 / 603P / 603R MECHANICAL TIMERS

                                                                                                                                                                     Rated

                                      MODEL NUMBER                                  MODEL NUMBER                                          MODEL NUMBER
                                      603
                                      �������������������������������� 603P
                                                 METAL - Indoor
                                                                        �������������������������������� 603R
                                                                                                   NON-METALLIC
                                                                                                          ��������������������������������                   METAL - Indoor/Outdoor

                                                         NEMA
                                                         Rated
                                                               1                                         NEMA
                                                                                                         Rated
                                                                                                               3R                                                     NEMA
                                                                                                                                                                      Rated
                                                                                                                                                                            3R

                                                        POWDER COATED                                     HIGH IMPACT                                                POWDER COATED
                                                        STEEL                                             POLYCARBONATE                                              STEEL

                                      FEATURES                                                            RATINGS
                                      • Industrial grade high-impact cabinets                             Switch	�������������������������������������������������� DPST
                                      • All models have reversible door hinges for tight spaces           Timing Motor	������������������������������������ 120 VAC 60 Hz, 4 Watts
                                      • NEW low-profile housings- lockable                                Contact Voltage	������������������������������ 120-240 VAC, 60Hz
                                                                                                          Resistive, Inductive, Tungsten	��� 40A, 120-240 VAC
                                      • Large 3 1/2” dials rotate clockwise for intuitive time setting
                                                                                                          Electronic Ballast / LED	��������������� 16A 120 VAC, 8A 240 VAC
                                      • Up to 16 ON/OFF operations per day
                                                                                                          Motor Load	���������������������������������������� 2 HP 120 VAC, 5HP 240 VAC
                                      • Large finger-set trippers for no-tools operation                  Operating Temperature	��������������� -40*F to 130*F (-40*C to 54*C)
                                      • Fully enclosed long life timing motors                            Pilot Duty	�������������������������������������������� 1000 VA, 120-240 VAC
                                      • 600P and 600R-series models have locking swing down wiring        Enclosure	������������������������������������������� 600-Series NEMA 1 600P
                                        compartment cover with extra tripper storage                                                                                and 600R-Series NEMA 3R /
                                      • 600-series models have sturdy plastic screw-down wiring                                                                     Lockable Hasp
                                        compartment covers                                                Enclosure Dimensions	������������������ 600P-Series
                                      • 600P-series has patented POP-FAST hole knockouts -                                                                          H. 8 5/8” x W. 6 3/8” x D. 3 1/8’
                                                                                                                                                                    600R-Series
                                        no tools required                                                                                                           H. 9” x W. 5 3/8” x D. 3”
                                                                                                                                                                    600-Series
                                                                                                                                                                    H. 7 7/8” x W. 4 1/2” x D. 2 3/4”
                                      GREAT FOR CONTROLLING                                               Knockouts	������������������������������������������ Combination 1/2” - 3/4” nominal,
                                      Pumps and compressors              Commercial lighting                                                                        one on back and on each side
                                      Pools and spas                     and signs                                                                                  and two on bottom (600P-series
                                                                         Electric motors                                                                            has reusable knockouts)
                                      Heating and air conditioning                                        Wire Size	�������������������������������������������� #8 - #14 AWG
                                                                                                          Warranty	��������������������������������������������� 2 Years
                                                                                                          WIRING DIAGRAM
                                      FOR USE WITH THESE LIGHTING TYPES
                                                                                                             603                                                                              G
                                                                                                             WIRING DIAGRAM                         SWITCH
                                                                                                              DPST

                                                                                                                                           TIMING
                                                                                                                                           MOTOR
                                                                                                                                                          SWITCH

                                                                                                                            L1
                                                                                                                AC                                                                      LOAD
                                                                                                              SUPPLY              L1 in     L2 in     N
                                                                                                                                                                               L1 out
                                                                                                                                                                    L2 out
                                                                                                                             L2

                                                                                                                                                    NEUTRAL

        11
24 HOUR MECHANICAL TIME SWITCHES

                INDUSTRIAL GRADE                                                208-277 VAC DPST

                                                                                                                                                                      604 / 604P / 604R MECHANICAL TIMERS
                                                         Rated

MODEL NUMBER                                   MODEL NUMBER                                           MODEL NUMBER
604
�������������������������������� 604P
           METAL - Indoor
                                  �������������������������������� 604R
                                                                 NON-METALLIC
                                                                    ��������������������������������                      METAL - Indoor/Outdoor

                   NEMA
                   Rated
                         1                                           NEMA
                                                                     Rated
                                                                           3R                                                        NEMA
                                                                                                                                     Rated
                                                                                                                                           3R

                  POWDER COATED                                       HIGH IMPACT                                                POWDER COATED
                  STEEL                                               POLYCARBONATE                                              STEEL

FEATURES                                                               RATINGS
• Industrial grade high-impact cabinets                                Switch	�������������������������������������������������� DPST
• All models have reversible door hinges for tight spaces              Timing Motor	������������������������������������ 208-277 VAC 60 Hz, 4 Watts
• NEW low-profile housings- lockable                                   Contact Voltage	������������������������������ 120-277 VAC, 60Hz
                                                                       Resistive, Inductive, Tungsten	��� 40A, 120-240 VAC
• Large 3 1/2” dials rotate clockwise for intuitive time setting
                                                                       Electronic Ballast / LED	��������������� 16A 120 VAC, 8A 240 VAC
• Up to 16 ON/OFF operations per day
                                                                       Motor Load	���������������������������������������� 2 HP 120 VAC, 5HP 240 VAC
• Large finger-set trippers for no-tools operation                     Operating Temperature	��������������� -40*F to 130*F (-40*C to 54*C)
• Fully enclosed long life timing motors                               Pilot Duty	�������������������������������������������� 1000 VA, 120-240 VAC
• 600P and 600R-series models have locking swing down wiring           Enclosure	������������������������������������������� 600-Series NEMA 1 600P
  compartment cover with extra tripper storage                                                                                   and 600R-Series NEMA 3R /
• 600-series models have sturdy plastic screw-down wiring                                                                        Lockable Hasp
  compartment covers                                                   Enclosure Dimensions	������������������ 600P-Series
• 600P-series has patented POP-FAST hole knockouts -                                                                             H. 8 5/8” x W. 6 3/8” x D. 3 1/8’
                                                                                                                                 600R-Series
  no tools required                                                                                                              H. 9” x W. 5 3/8” x D. 3”
                                                                                                                                 600-Series
                                                                                                                                 H. 7 7/8” x W. 4 1/2” x D. 2 3/4”
GREAT FOR CONTROLLING                                                  Knockouts	������������������������������������������ Combination 1/2” - 3/4” nominal,
Pumps and compressors              Commercial lighting                                                                           one on back and on each side
Pools and spas                     and signs                                                                                     and two on bottom (600P-series
                                   Electric motors                                                                               has reusable knockouts)
Heating and air conditioning                                           Wire Size	�������������������������������������������� #8 - #14 AWG
                                                                       Warranty	��������������������������������������������� 2 Years
                                                                       WIRING DIAGRAM
FOR USE WITH THESE LIGHTING TYPES                                        604                                                                          G
                                                                         WIRING DIAGRAM                         SWITCH
                                                                         DPST

                                                                                                       TIMING
                                                                                                       MOTOR
                                                                                                                     SWITCH

                                                                                        L1
                                                                           AC                                                                         LOAD
                                                                         SUPPLY              L1 in      L2 in               L2 out
                                                                                                                                            L1 out

                                                                                        L2

                                                                                                                                                                     12
ELECTRICAL INNOVATION SINCE 1909

                                              SPDT
                                      120 VAC 1NO/1NC                                                       INDUSTRIAL GRADE
605 / 605P MECHANICAL TIMERS

                                                                                                                                                                  Rated

                               MODEL NUMBER                                                            MODEL NUMBER
                               605
                               ������������������������������������������������� 605P
                                          METAL - Indoor                                                                   NON-METALLIC
                                                                                  �������������������������������������������������

                                                  NEMA
                                                  Rated
                                                        1                                                                              NEMA
                                                                                                                                       Rated
                                                                                                                                             3R

                                                 POWDER COATED                                                                        HIGH IMPACT
                                                 STEEL                                                                                POLYCARBONATE

                               FEATURES                                                                RATINGS
                               • Industrial grade high-impact cabinets                                 Switch	�������������������������������������������������� SPST 1 NO / 1 NC
                               • All models have reversible door hinges for tight spaces               Timing Motor	������������������������������������ 120VAC 60 Hz, 4 Watts
                               • NEW low-profile housings- lockable                                    Contact Voltage	������������������������������ 120-240 VAC, 60Hz
                                                                                                       Resistive, Inductive, Tungsten	��� 40A, 120-240 VAC
                               • Large 3 1/2” dials rotate clockwise for intuitive time setting
                                                                                                       Electronic Ballast / LED	��������������� 16A 120 VAC, 8A 240 VAC
                               • Up to 16 ON/OFF operations per day
                                                                                                       Motor Load	���������������������������������������� 2 HP 120 VAC, 5HP 240 VAC
                               • Large finger-set trippers for no-tools operation                      Operating Temperature	��������������� -40*F to 130*F (-40*C to 54*C)
                               • Fully enclosed long life timing motors                                Pilot Duty	�������������������������������������������� 1000 VA, 120-240 VAC
                               • 600P-series models have locking swing down wiring compartment         Enclosure	������������������������������������������� 600-Series NEMA 1 600P
                                 cover with extra tripper storage                                                                                                and 600R-Series NEMA 3R /
                               • 600-series models have sturdy plastic screw-down wiring                                                                         Lockable Hasp
                                 compartment covers                                                    Enclosure Dimensions	������������������ 600P-Series
                               • 600P-series has patented POP-FAST hole knockouts- no tools required                                                             H. 8 3/4” x W. 6 1/4” x D. 3 1/8”
                                                                                                                                                                 600-Series
                                                                                                                                                                 H. 7 7/8” x W. 4 1/2” x D. 2 3/4”
                                                                                                       Knockouts	������������������������������������������ Combination 1/2” - 3/4” nominal,
                               GREAT FOR CONTROLLING                                                                                                             one on back and on each side
                                                                                                                                                                 and two on bottom (600P-series
                               Pumps and compressors               Commercial lighting                                                                           has reusable knockouts)
                               Pools and spas                      and signs                           Wire Size	�������������������������������������������� #8 - #14 AWG
                               Heating and air conditioning        Electric motors                     Warranty	��������������������������������������������� 2 Years

                                                                                                       WIRING DIAGRAM
                               FOR USE WITH THESE LIGHTING TYPES
                                                                                                        605                                       N/C                                G
                                                                                                        WIRING DIAGRAM                           SWITCH
                                                                                                        SPDT

                                                                                                                                      TIMING
                                                                                                                                      MOTOR            N/O
                                                                                                                                                      SWITCH

                                                                                                          AC
                                                                                                        SUPPLY           L1                 L2                             L1 out
                                                                                                                                                                                    LOAD 1
                                                                                                         120 V                                    N            L2 out
                                                                                                                                JUMPER
                                                                                                                                                                                    LOAD 2

                                                                                                                                                 NEUTRAL

      13
24 HOUR MECHANICAL TIME SWITCHES

                INDUSTRIAL GRADE
                                                                                          SPDT
                                                                              208-277 VAC 1NO/1NC

                                                                                                                                                                       606 / 606P MECHANICAL TIMERS
                                                          Rated

MODEL NUMBER                                                            MODEL NUMBER
606
������������������������������������������������� 606P
           METAL - Indoor                                                                   NON-METALLIC
                                                   �������������������������������������������������

                   NEMA
                   Rated
                         1                                                                             NEMA
                                                                                                       Rated
                                                                                                             3R

                  POWDER COATED                                                                         HIGH IMPACT
                  STEEL                                                                                 POLYCARBONATE

FEATURES                                                                RATINGS
• Industrial grade high-impact cabinets                                 Switch	�������������������������������������������������� SPDT 1 NO / 1 NC
• All models have reversible door hinges for tight spaces               Timing Motor	������������������������������������ 208-277 VAC 60 Hz, 4 Watts
• NEW low-profile housings- lockable                                    Contact Voltage	������������������������������ 120-277 VAC, 60Hz
                                                                        Resistive, Inductive, Tungsten	��� 40A, 120-240 VAC
• Large 3 1/2” dials rotate clockwise for intuitive time setting
                                                                        Electronic Ballast / LED	��������������� 16A 120 VAC, 8A 240 VAC
• Up to 16 ON/OFF operations per day
                                                                        Motor Load	���������������������������������������� 2 HP 120 VAC, 5HP 240 VAC
• Large finger-set trippers for no-tools operation                      Operating Temperature	��������������� -40*F to 130*F (-40*C to 54*C)
• Fully enclosed long life timing motors                                Pilot Duty	�������������������������������������������� 1000 VA, 120-240 VAC
• 600P-series models have locking swing down wiring compartment         Enclosure	������������������������������������������� 600-Series NEMA 1 600P
  cover with extra tripper storage                                                                                                and 600R-Series NEMA 3R /
• 600-series models have sturdy plastic screw-down wiring                                                                         Lockable Hasp
  compartment covers                                                    Enclosure Dimensions 	���������������� 600P-Series
• 600P-series has patented POP-FAST hole knockouts- no tools required                                                             H. 8 3/4” x W. 6 1/4” x D. 3 1/8”
                                                                                                                                  600-Series
                                                                                                                                  H. 7 7/8” x W. 4 1/2” x D. 2 3/4”
                                                                        Knockouts	������������������������������������������ Combination 1/2” - 3/4” nominal,
GREAT FOR CONTROLLING                                                                                                             one on back and on each side
                                                                                                                                  and two on bottom (600P-series
Pumps and compressors               Commercial lighting                                                                           has reusable knockouts)
Pools and spas                      and signs                           Wire Size	�������������������������������������������� #8 - #14 AWG
Heating and air conditioning        Electric motors                     Warranty	��������������������������������������������� 2 Years

                                                                        WIRING DIAGRAM
FOR USE WITH THESE LIGHTING TYPES                                         606                                       N/C                               G
                                                                          WIRING DIAGRAM                           SWITCH
                                                                          SPDT

                                                                                                        TIMING
                                                                                                        MOTOR            N/O
                                                                                                                        SWITCH

                                                                            AC
                                                                          SUPPLY           L1                 L2                            L1 out
                                                                                                                                                     LOAD 1
                                                                          208-277 V                                 N            L2 out
                                                                                                 JUMPER
                                                                                                                                                     LOAD 2

                                                                                                                                                                      14
ELECTRICAL INNOVATION SINCE 1909

                                          208-277 VAC DPST                                               WATER HEATER TIME SWITCH
WH600 WATER HEATER TIME SWITCH

                                                            MODEL NUMBER
                                                            WH600                METAL
                                                            ������������������������������

                                                                                         POWDER COATED
                                                                                         STEEL

                                                                                NEMA
                                                                                Rated
                                                                                      3R

                                                                                 Rated

                                 TURNS OFF ELECTRIC WATER HEATERS                                        SWITCH RATINGS
                                                                                                         Switch	�������������������������������������������������� DPST
                                 WHEN NOT NEEDED TO SAVE ENERGY                                          Timing Motor	������������������������������������ 208-277 VAC 60 Hz, 4 Watts
                                                                                                         Contact Voltage	������������������������������ 120-277 VAC, 60Hz
                                 FEATURES                                                                Resistive, Inductive, Tungsten	��� 40A, 120-240 VAC
                                 •   Indoor low profile housing- lockable                                Electronic Ballast / LED	��������������� 16A 120 VAC, 8A 240 VAC
                                 •   Up to 16 ON/OFF operations per day                                  Motor Load	���������������������������������������� 2 HP 120 VAC
                                 •   Large 3 1/2” clockwise dial for easy-to-understand setting                                                                    5 HP 208-277 VAC
                                 •   Fully enclosed long life timing motor                               Operating Temperature	��������������� -40*F to 130*F (-40*C to 54*C)
                                 •   Safe, locking hinged wiring cover with extra tripper storage        Pilot Duty	�������������������������������������������� 1000 VA, 120-277 VAC
                                 •   Industrial grade high-impact cabinet                                Enclosure	������������������������������������������� NEMA 3R / Lockable Hasp
                                 •   External, easily accessible manual override lever                   Enclosure Dimensions	������������������ H. 7 3/4” x W. 4 5/8” x D. 2 7/8”
                                                                                                         Knockouts	������������������������������������������ Combination 1/2” - 3/4” nominal,
                                                                                                                                                                   one on back and on each side
                                 GREAT FOR CONTROLLING                                                                                                             and two on bottom
                                 Electric water heaters                                                  Wire Size	�������������������������������������������� #8 - #14 AWG
                                                                                                         Warranty	��������������������������������������������� 2 Years

                                        INDUSTRIAL GRADE
                                        INDOOR                                                           WIRING DIAGRAM
                                                                                                          WH600                                                                     G
                                                                                                          WIRING DIAGRAM                        SWITCH
                                                                                                          DPST

                                                                                                                                       TIMING
                                                                                                                                       MOTOR
                                                                                                                                                     SWITCH

                                                                                                                         L1
                                                                                                             AC                                                                     LOAD
                                                                                                           SUPPLY             L1 in     L2 in       N
                                                                                                                                                                          L1 out

                                                                                                                         L2                                             L2 out

      15
24 HOUR MECHANICAL TIME SWITCHES

                                                                                                                         SNAP-IN
                TIMER REPLACEMENT MECHANISMS

                                                                                                                                            TIME SWITCH REPLACEMENT MECHANISMS
                                       Rated
                                                                                          SNAP-IN

MECHANISM FEATURES
• All replacement mechanisms snap into existing Reliance Controls       • Temporary manual override lever
  and most brands of previously installed cabinets                      • Rigid plastic wiring compartment cover plate
• Up to 16 ON/OFF operations per day
• Large 3 1/2” clockwise dial for easy-to-understand setting
• Fully enclosed long-life timing motor

 Model Number                                  601M                               603M                                   604M
 Switch                                         SPST                               DPST                                    DPST
 Timing Motor                                             120 VAC 60 Hz 4 Watts                               208-277 VAC 60 Hz, 4 Watts
 Contact Voltage                                           120-240 VAC 60 Hz                                         120-277 VAC 60 Hz
 Resistive, Inductive, Tungsten                                                   40A 120-240 VAC
 Electronic Ballast / LED                                                   16A 120 VAC, 8A 240VAC
 Motor Load                                              2 HP 120; 5 HP 240VAC                                2 HP 120; 5 HP208-277 VAC
 Operating Temperature                                                    -40*F to 130*F (-40*C to 54*C)
 Pilot Duty                                               1000 VA, 120-240 VAC                                   1000 VA, 120-277 VAC
 Enclosure                                                      Snaps into existing Intermatic® and TORK® Cabinets
 Wire Size                                                                         #8 - #14 AWG
 Warranty                                                                             2 Years

                                                                                                                                           16
ELECTRICAL INNOVATION SINCE 1909

                     METAL AND POLYCARBONATE
                     ENCLOSURES
NEMA 3R ENCLOSURES

                                          MODEL NUMBER
                                          600RMC                 METAL
                                          ��������������������������������
                                                                                           POWDER COATED
                                                                                           STEEL

                                          FEATURES
                                          • Heavy gauge metal wall for added strength
                                            and protection
                                          • Reversible door hinge for left or
                                            right opening
                                          • Sturdy latch closure to lock cabinet
                                          • Safe, locking hinged wiring cover with extra
                                            tripper storage
                                          • Combination 1/2” - 3/4” knockouts, one on
                                            back and on each side and two on bottom
                                          • Convenient exterior mounting holes

                       INDUSTRIAL GRADE
                       INDOOR / OUTDOOR       NEMA
                                              CABINETS
                                                       3R

                                          MODEL NUMBER
                                          600RPC               NON-METALLIC
                                          ��������������������������������
                                                                                             HIGH IMPACT
                                                                                             POLYCARBONATE

                                          FEATURES
                                          • Industrial grade high-impact UL-tested
                                            polycarbonate
                                          • QUICK-SNAP reversible door hinge
                                            changes from left to right opening in
                                            seconds- no tools required
                                          • Channeled rainproof closure secures door
                                            and incorporates padlock hasp
                                          • Safe, locking hinged wiring cover with extra
                                            tripper storage
                                          • Combination patented POP-FAST no-tools
                                            required 1/2” - 3/4” knockouts, one on
                                            back and on each side and two on bottom
                                          • Convenient exterior mounting holes

                       INDUSTRIAL GRADE
                       INDOOR / OUTDOOR       NEMA
                                              CABINETS
                                                       3R

    17
24 HOUR MECHANICAL TIME SWITCHES

                                                                ACCESSORIES

                                                                                                                                    ACCESSORIES
 SEE-THROUGH CLEAR POLYCARBONATE DOOR
                                   MODEL NUMBER
                                   600CC
                                   �������������������������������������������������������������������
                                   Available for Reliance Controls polycarbonate cabinet models is a see-through clear door
                                   that snaps-ON either the left or right hinges of all 600P-series polycarbonate cabinets.
                                   This clear door allows full viewing of the 24 hour timing dial and tripper settings. Included
                                   1) the blue Reliance Controls label on the front cover and 2) a set of tri-lingual “This
                                   Time Switch Controls” front stickers.

 SET OF ON/OFF TIMER TRIPPERS
                                   MODEL NUMBER
                                   RTP4
                                   �������������������������������������������������������������������
                                   Two pairs of ON and OFF replacement trippers packed in a separate bag.

 REPLACEMENT TIMING MOTORS
                                   MODEL NUMBER
                                   RM120: 120 VAC 60 HZ
                                   MODEL NUMBER
                                   RM240:          208-277 VAC 60 HZ
                                   �������������������������������������������������������������������

Model    601 / 601R /   602 / 602R /   603 / 603R /      604 / 604R /       605 / 605P        606 / 606P          WH600
Number      601P           602P           603P              604P
RM120         X                               X                                   X                                   X
RM240                        X                                  X                                   X

                                                                                                                                   18
IN-WALL TIMERS

Reliance Controls commercial and residential in-wall timers are designed to replace any
standard wall switch to automatically limit the ON times for fans, lighting, motors, heaters
and other energy consuming loads.
Built to meet NEC and cULus requirements to easily maintain safe and reliable operation in
rugged commercial environments.
IN-WALL TIMERS
ELECTRICAL INNOVATION SINCE 1909

                          IN-WALL Timers
                              RATINGS - IN-WALL TIMERS
IN-WALL TIMERS RATINGS

                                   Model           Watts Tungsten           Amps Tungsten            Electronic Ballast   Amps Ballast   Volts
                              15 Minute Countdown Timers - With Decorator Faceplate
                                  WB015W                   1875                     15 A                   500W               10 A       125-277
                                  WB015A                   1875                     15 A                   500W               10 A       125-277
                                   WB015Y                  1875                     15 A                   500W               10 A       125-277
                                   WB015V                  1875                     15 A                   500W               10 A       125-277
                              30 Minute Countdown Timers - With Decorator Faceplate
                                  WB030W                   1875                     15 A                   500W               10 A       125-277
                                  WB030A                   1875                     15 A                   500W               10 A       125-277
                                  WB030Y                   1875                     15 A                   500W               10 A       125-277
                                  WB030V                   1875                     15 A                   500W               10 A       125-277
                              60 Minute Countdown Timers - With Decorator Faceplate
                                  WB060W                   1875                     15 A                   500W               10 A       125-277
                                  WB060A                   1875                     15 A                   500W               10 A       125-277
                                  WB060Y                   1875                     15 A                   500W               10 A       125-277
                                  WB060V                   1875                     15 A                   500W               10 A       125-277
                              120 Minute Countdown Timers - No Faceplate
                                  WB120W                   1250                     15 A                   500W               15 A       125-277
                              5 / 10 / 15 / 30 Minute Countdown Timers - With Decorator Faceplate
                                 WEA030W                   1000                    8.3 A                   500VA              8.3 A       120
                                  WEA030A                  1000                    8.3 A                   500VA              8.3 A       120
                                  WEA030Y                  1000                    8.3 A                   500VA              8.3 A       120
                              10 / 20 / 30 / 60 Minute Countdown Timers - With Decorator Faceplate
                                 WEB060W                   1000                    8.3 A                   500VA              8.3 A       120
                                  WEB060A                  1000                    8.3 A                   500VA              8.3 A       120
                                  WEB060Y                  1000                    8.3 A                   500VA              8.3 A       120
                              2 / 4 / 8 /12 Hour Countdown Timers - With Decorator Faceplate
                                 WED720W                   1000                    8.3 A                   500VA              8.3 A       120
                                  WED720A                  1000                    8.3 A                   500VA              8.3 A       120
                                  WED720Y                  1000                    8.3 A                   500VA              8.3 A       120
                              7-Day Programmable Timers - With Decorator Colored Faceplate
                                 WE7000W                   1000                       8A                   500VA              8A          125
                                  WE7000A                  1000                       8A                   500VA              8A          125
                                  WE7000Y                  1000                       8A                   500VA              8A          125
                              7-Day Astronomic Programmable Timers - With Decorator Colored Faceplate
                                  WE7100W                  1000                       8A                   500VA              8A          125
                                  WE7100A                  1000                       8A                   500VA              8A          125
                                  WE7100Y                  1000                       8A                   500VA              8A          125

                         21                   RelianceControls.com
IN-WALL TIMERS

                                                                                          ELECTRONIC COUNTDOWN IN-WALL TIMERS
   RUGGED TIME DIAL PLATE
   EASILY WITHSTANDS THE
   ABUSE ENCOUNTERED IN
COMMERCIAL ENVIRONMENTS

     REPLACES SINGLE-POLE
   SWITCHES IN A VARIETY OF
              APPLICATIONS

       OPERATES ALL LOAD
         TYPES INCLUDING
  INCANDESCENT, CFLs, LED
   LAMPS AND FAN MOTORS

 Timers available in white, almond, ivory
 and silver

                                    CFL COMPATIBLE
                READY

                               SINGLE OR       SAVES ENERGY
     INCANDESCENT              MULTI-GANG

                                                              RelianceControls.com   22
ELECTRICAL INNOVATION SINCE 1909

                               WB SERIES SPRING-WOUND COUNTDOWN TIMERS
SPRING WOUND IN-WALL TIMERS

                               ������������������������������������������������������������������������������������������������������
                               The WB-Series Auto-Shut-Off In-Wall Timers are designed to           heaters and other energy consuming loads. All models come
                               replace any standard single pole wall switch. These energy-          with rugged plastic decorator-style wall plates in white, light
                               efficient mechanical timers do not require electricity to operate.   almond, ivory or silver. All meet cULus and NEC requirements
                               They automatically limit the ON times for fans, lighting, motors,    for safety.
                               FEATURES
                               • Rugged time dial plate easily              • 15 Amp rated                                     • No neutral wire required
                                 withstands the abuse encountered in        • Operates all load types including                • Replaces any standard wall switch
                                 professional environments                    incandescent, compact fluorescent
                               • Press-on knob design ensures quick           and LED lighting and fan motors
                                 and easy installation

                                                    Model        Color          Time Cycle                UPC           Pack Qty.
                                                 15 Minute Countdown Timers - With Decorator Faceplate
                                                    WB015W        White            15 Min             8-15181-01140-6          6
                                                    WB015A       Almond            15 Min             8-15181-01141-3          6
                                                    WB015Y        Ivory            15 Min            8-15181-01139-0           6
                                   White
                                                    WB015V        Silver           15 Min            8-15181-01135-2           6
                                                 30 Minute Countdown Timers - With Decorator Faceplate
                                                                                                                                        120 Minute Auto Shut Off
                                                    WB030W        White            30 Min             8-15181-01143-7          6
                                                                                                                                        No Faceplate
                                                    WB030A       Almond            30 Min             8-15181-01144-4          6

                                                    WB030Y        Ivory            30 Min             8-15181-01142-0          6
                                                                                                                                        Rating:
                                                                                                                                        125 VAC, 15 Amp General Use
                                                    WB030V        Silver           30 Min            8-15181-01136-9           6        15 Amp Resistive
                                   Almond
                                                 60 Minute Countdown Timers - With Decorator Faceplate                                  1250 Watt Tungsten
                                                   WB060W         White            60 Min             8-15181-01146-8          6        500 Watt, Electronic Ballast
                                                    WB060A       Almond            60 Min             8-15181-01147-5          6        Motor:
                                                                                                                                        1/2 HP, 60 Hz, 125 VAC
                                                    WB060Y        Ivory            60 Min             8-15181-01145-1          6
                                                                                                                                        Switch:
                                                    WB060V        Silver           60 Min             8-15181-01137-6          6        Single Pole Single Throw (SPST)
                                                 120 Minute Countdown Timers - No Faceplate                                             Hold:
                                   Ivory
                                                    WB120W        White            120 Min            8-15181-01751-4          6        No

                                                   Rating:                                   Switch:
                                                   125 VAC, 20 Amp, 2500 Watt General Use    Single Pole Single Throw (SPST)
                                                   125 VAC, 15 Amp, 1875 Watt Resistive      Hold:                                      READY
                                                   125 VAC, 15 Amp, 1875 Watt Tungsten       No
                                                   500 Watt, Electronic Ballast;             Warranty:                                     INCANDESCENT
                                                   250 VAC, 10 Amp, 2500 Watt General Use    2 Year
                                   Silver
                                                   277 VAC, 10 Amp, 2770 Watt General Use                                                   Meets or Exceeds
                                                                                                                                            National Electrical Code® Requirements
                                                   Motor:                                                                                  CFL COMPATIBLE
                                                   1 HP, 60 Hz, 125 VAC
                                                   2 HP, 60 Hz, 250 VAC
                                                                                                                                            Meets or Exceeds
                                                                                                                                            National Electrical Code® Requirements

                                                                                                                                            Meets or Exceeds
                                                                                                                                            National Electrical Code® Requirements
                              23                RelianceControls.com
IN-WALL TIMERS

WE SERIES ELECTRONIC COUNTDOWN TIMERS

                                                                                                                                                  ELECTRONIC COUNTDOWN IN-WALL TIMERS
������������������������������������������������������������������������������������������������������
The WE-Series Electronic Auto Shut-Off In-Wall Timers also            kitchens, they automatically limit the ON times for exhaust fans,
are designed to replace any standard single pole wall switch.         lighting, motors, heaters and other energy consuming loads
Available with white, almond or ivory colored faceplates, they        that may remain ON when not in use. All meet cULus and NEC
provide silent count down of minutes or hours with the press          requirements for safety
of a single button. Ideally suited for use in bathrooms and

FEATURES
• Silent operation in time ranges from      • 15 Amp rated                                        • Single button time selection
  5 minutes to 12 hours.                    • Operates all load types including                   • Features a HOLD countdown
• Replaces any standard wall switch           incandescent, compact fluorescent
• Requires a neutral wire                     and LED lighting and fan motors

                                      Model           Color                    Time Cycle                          UPC           Pack Qty.
                                  5 / 10 / 15 / 30 Minute Countdown Timers - With Decorator Faceplate
                                     WEA030W           White                  5/10/15/30 Min                  8-15181-01149-9        6
                                     WEA030A          Almond                  5/10/15/30 Min                  8-15181-01150-5        6
                                     WEA030Y           Ivory                  5/10/15/30 Min                  8-15181-01148-2        6
                                  10 / 20 / 30 / 60 Minute Countdown Timers - With Decorator Faceplate
                                     WEB060W           White                 10/20/30/60 Min                  8-15181-01152-9        6
                                     WEB060A          Almond                 10/20/30/60 Min                  8-15181-01153-6        6

                                     WEB060Y           Ivory                 10/20/30/60 Min                   8-15181-01151-2       6
White
                                  2 / 4 / 8 /12 Hour Countdown Timers - With Decorator Faceplate
                                     WED720W           White                    2/4/8/12 Hrs                  8-15181-01155-0        6
                                     WED720A          Almond                    2/4/8/12 Hrs                  8-15181-01156-7        6
                                     WED720Y           Ivory                    2/4/8/12 Hrs                  8-15181-01154-3        6

                                 Rating:                                                    Motor:
Almond                           120 VAC, 15 Amp, General Purpose                           1/4 HP, 60 Hz, 120 VAC
                                 120 VAC, 15 Amp, 1800 Watt Resistive                       Switch:
                                 120 VAC, 8.3 Amp, 1000 Watt Tungsten                       Single Pole Single Throw (SPST)
                                 1000 VA, Ballast                                           Hold:
                                 500 VA, Electronic Ballast                                 Yes
                                                                                            Warranty:
                                                                                            2 Year

Ivory
                                                        Meets or Exceeds
                                                    INCANDESCENT
                                                       National Electrical Code® Requirements
                                                                                      CFL COMPATIBLE
                                  READY

                                                        Meets or Exceeds
                                                        National Electrical Code® Requirements

                                                        Meets or Exceeds
                                                        National Electrical Code® Requirements

                                                                                           RelianceControls.com                              24
ELECTRICAL INNOVATION SINCE 1909

                               WE7000 SERIES 7-DAY PROGRAMMABLE TIMERS
PROGRAMMABLE IN-WALL TIMERS

                               ������������������������������������������������������������������������������������������������������
                               The WE7000-Series In-Wall Timers allow programming of                   security. These timers can replace any standard wall switch.
                               individual ON/OFF settings each day for 7 days. You can                 Easy, logical step by step on-screen programming instructions.
                               also program RANDOM time settings to automatically shut                 Available with white, almond or ivory colored faceplates. Ideally
                               lights OFF and ON at different times each day of the week               suited to control outdoor or indoor lighting.
                               to simulate building occupancy while away for enhanced

                               FEATURES
                               • Progam up to 7 ON/OFF events             • 15 Amp rated                                     • Built-in rechargeable NiMH battery
                                 per week                                 • Fold up cover plate to neatly hide                 to store settings during prolonged
                               • Compatible with incandescent, CFL          control panel buttons while showing                power outages
                                 and LED lighting                           actual time                                      • Requires neutral wire
                               • Automatic Daylight Savings time
                                 adjustment

                                                                   Model              Color                    Time Cycle                    UPC            Pack Qty.
                                                               7-Day Programmable Timers - With Decorator Colored Faceplate
                                                                 WE7000W               White                      7-Day                  8-15181-01158-1         6
                                                                  WE7000A             Almond                      7-Day                  8-15181-01159-8         6
                                                                  WE7000Y               Ivory                     7-Day                  8-15181-01157-4         6

                                                              Rating:
                                                              125 VAC, 15 Amp General Purpose
                                                              125 VAC, 15 Amp, 1875 Watt Resistive
                                                              125 VAC, 8 Amp, 1000 Watt Tungsten
                                                              125 VAC, 8 Amp, Standard Ballast
                                   White
                                                              500 VA, Electronic Ballast
                                                              Motor:
                                                              1/4 HP, 60 Hz, 125 VAC
                                                              Switch:
                                                              Single Pole Single Throw (SPST)
                                                              Warranty:
                                                              2 Year
                                   Almond

                                                                                                                   DUSK TO
                                                                                    SAVES ENERGY                   DAWN LIGHT
                                                              READY                                                CONTROL

                                                                      Meets or Exceeds
                                                                                   INCANDESCENT
                                                                      National Electrical Code® Requirements     CFL COMPATIBLE

                                   Ivory                              Meets or Exceeds
                                                                      National Electrical Code® Requirements

                                                                      Meets or Exceeds
                                                                      National Electrical Code® Requirements

                              25              RelianceControls.com
IN-WALL TIMERS

WE7100 SERIES 7-DAY ASTRONOMIC PROGRAMMABLE TIMERS

                                                                                                                                                     PROGRAMMABLE IN-WALL TIMERS
������������������������������������������������������������������������������������������������������
The WE7100-Series In-Wall Timers allow programming of                       These WE7100-series timers can replace any standard wall
individual ON/OFF settings each day for 7 days together with                switch. Available with white, almond or ivory colored faceplates.
an ASTRONOMIC feature that automatically adjusts to sunrise                 For low maintenance control of outdoor or indoor lighting all
and sunset times throughout the year. This saves you the                    year long.
inconvenience of re-programming the timer every few months.

FEATURES
• Progam up to 7 ON/OFF events                • 15 Amp rated                                       • Built-in rechargeable NiMH battery
  per week                                    • Requires neutral wire                                to store settings during prolonged
• Compatible with incandescent, CFL                                                                  power outages
                                              • Fold up cover plate to neatly hide
  and LED lighting                              control panel buttons while showing                • RANDOM “lived-in” setting
• Automatic Daylight Savings time               actual time
  adjustment

                                      Model               Color                   Time Cycle                      UPC             Pack Qty.
                                7-Day Astronomic Programmable Timers - With Decorator Colored Faceplate
                                      WE7100W              White                   24 Hr / 7-Day              8-15181-01164-2          6
                                      WE7100A             Almond                   24 Hr / 7-Day              8-15181-01165-9          6
                                      WE7100Y               Ivory                  24 Hr / 7-Day              8-15181-01163-5          6

                               Rating:
                               125 VAC, 15 Amp 1875 Watt General Purpose
                               125 VAC, 15 Amp, 1875 Watt Resistive
                               125 VAC, 8 Amp, 1000 Watt Tungsten
                               125 VAC, 8 Amp, Standard Ballast
White                          500 VA, Electronic Ballastt
                               Motor:
                               1/4 HP, 60 Hz, 125 VAC
                               Switch:
                               Single Pole Single Throw (SPST)
                               Warranty:
                               2 Year

Almond
                                                                                      DUSK TO
                                                     SAVES ENERGY                     DAWN LIGHT
                              READY                                                   CONTROL

                                                   INCANDESCENT                        AUTOMATIC
                                                                                       DUSK TO DAWN
                                                                                       TRACKING
                                       Meets or Exceeds
                                       National Electrical
                                                     CFLCode
                                                             ®
                                                               Requirements
                                                           COMPATIBLE

Ivory
                                       Meets or Exceeds
                                       National Electrical Code® Requirements

                                       Meets or Exceeds
                                       National Electrical Code® Requirements
                                                                                            RelianceControls.com                                26
PHOTO CONTROLS

Reliance Controls outdoor-rated thermal and electronic photo controls
product category includes fixed mount button, stem-type, swivel stem as
well as locking-type designs that allow dusk-to-dawn lighting control of
a wide assortment of outdoor lighting. All have sonic-welded cases and
lenses to seal out moisture. All feature delay activation which eliminates
lighting switching OFF due to car headlights, lightning and other
momentary illumination.

Capable of handling LED, CFL, HID, incandescent and induction lighting
loads, they are the perfect solution to creating safely lighted outdoor
spaces while conserving energy.
PHOTO CONTROLS
ELECTRICAL INNOVATION SINCE 1909

                                P4000 SERIES BUTTON AND WALL MOUNT
FIXED POSITION, THERMAL-TYPE

                                ������������������������������������������������������������������������������������������������������
                                Reliance P4000 Series Outdoor Fixed Position and Wall Mount                     and other nuisance light flashes. The design uses a dual
                                thermal photo controls fit into a standard outdoor outlet box,                  temperature compensating bi-metal and composite resistor for
                                a post lamp or a junction box. They provide dusk-to-dawn                        reliable long life operation over ambient temperature extremes.
                                lighting control, along with a delay action, which prevents lights              Night lighting deters crime and saves energy.
                                from switching ON and OFF due to car headlights, lightning
                                FEATURES
                                • 1/2” Conduit Mount                                    • Sonic welded polycarbonate             • Features 5/8”-18 NPSM, 3/4” long
                                • Cadmium sulfide photocell                               housing and lens                         stem (3/8”-18 NPSM 5/8” long stem on
                                • Compatible with incandescent,                         • Silver faceplates on -C models           model number P4024) with locking nut
                                  CFL, HID and LED lighting                             • Compact size fits into standard outlet   and washer gasket
                                                                                          box, junction box or lamp post         • 6“ wire leads

                                                                             Model              Type             Voltage           Hz          Tungsten     Ballast    Pack Warranty
                                                                              P4021             Button            120VAC        50-60 Hz        1800W       1100 VA          6   5 Years
                                                                              P4023             Button          208-277VAC      50-60 Hz        2000W       2000 VA          6   5 Years
                                                                             P4021C       Button w/Wallpate       120VAC        50-60 Hz        1800W       1100 VA          6   5 Years
                                                                             P4023C       Button w/Wallpate     208-277VAC      50-60 Hz        2000W       2000 VA          6   5 Years
                                                                              P4024          Mini Button          120VAC        50-60 Hz        1000W       1200 VA          6   5 Years
                                    P4021 / P4023
                                                                        See complete Photo Controls Product Specifications on pages 35-36

                                                                        P4024 MINI BUTTON LAMP POST PHOTOCONTROL
                                                                        Specifically designed for smaller 7/16” diameter holes in lamp posts

                                                                                                                                                          WORKS WITH

                                                                                                                                                          outdoor fixtures

                                                                                                                                                                  DUSK TO
                                                                                                                                                                  DAWN LIGHT
                                                                                                                                                                  CONTROL

                                                                                                                                                                  CFL COMPATIBLE
                                    P4021C / P4023C
                                                                                                                                                                  INCANDESCENT

                                          Meets or Exceeds                                                                                                        SAVES ENERGY
                                          National Electrical Code® Requirements

                                                                                                                                                                  DETERS CRIME

                                          Meets or Exceeds
                                          National Electrical Code® Requirements

                                          Meets or Exceeds
                                          National Electrical Code® Requirements

                               29                     RelianceControls.com
THERMAL PHOTO CONTROLS

P4100 & P4400 SERIES FIXED STEM MOUNT

                                                                                                                                                  STEM MOUNTING, THERMAL-TYPE
������������������������������������������������������������������������������������������������������
Reliance P4100 and P4400 Series Outdoor Fixed Position                incorporated to prevent lights switching ON and OFF
Photo Controls fit into 1/2” knockout holes in standard               due to car headlights, lightning and other nuisance light
outdoor light fixtures and electrical boxes for dusk-to-              flashes. Available in polycarbonate or die-cast aluminium
dawn control of outdoor light fixtures. A delay action is             housings.

FEATURES
• 1/2” Conduit Mount                     • Sonic welded polycarbonate housing • Fits into standard electrical boxes
• Cadmium sulfide photocell                and lens to seal out moisture        or outdoor light fixtures

• Compatible with incandescent,          • P4400-series has die-cast                                • 5/8”-18 NPSM, 3/4” long stem with
  CFL, HID and LED lighting                aluminium housing                                          locking nut and washer gasket
                                                                                                    • 6 “ wire leads

                         Model                Type                       Voltage           Hz        Tungsten Ballast Pack Warranty
                          P4121        Fixed Stem Side Lens               120VAC         50-60 Hz      2000 W     2000 VA      6   5 Years
                          P4123        Fixed Stem Side Lens            208-277 VAC       50-60 Hz      2000 W     2000 VA      6   5 Years
                          P4421    Fixed Stem Side Lens Aluminum          120VAC         50-60 Hz      2000 W     2000 VA      6   5 Years
                          P4423    Fixed Stem Side Lens Aluminum 208-277 VAC             50-60 Hz      2000 W     2000 VA      6   5 Years

                        See complete Photo Controls Product Specifications on pages 35-36
P4421
                                                                                                                WORKS WITH

                                                                                                                outdoor fixtures
                               ADJUSTABLE SLIDE BAR
                               TO ADJUST PHOTOCELL                                                                      DUSK TO
                                                                                                                        DAWN LIGHT
                                    LIGHT EXPOSURE                                                                      CONTROL

                                                                                                                        CFL COMPATIBLE
                                         SONIC-WELDED
                                      POLYCARBONATE
                                                                                                                        INCANDESCENT
                                  HOUSING AND LENS TO
                                    SEAL OUT MOISTURE
                                                                                                                        SAVES ENERGY
P4423
                                                                                                                        DETERS CRIME
                              5/8”-18 NPSM, 3/4” LONG
                               STEM WITH LOCKING NUT
                                  AND WASHER GASKET

                                                                                 P4123
                                             Meets or Exceeds
                                             National Electrical Code® Requirements

P4121                                        Meets or Exceeds
                                             National Electrical Code® Requirements

                                             Meets or Exceeds
                                             National Electrical Code® Requirements

                                                                                           RelianceControls.com                              30
ELECTRICAL INNOVATION SINCE 1909

                                          P4200 SERIES SWIVEL STEM MOUNT
STEM AND SWIVEL MOUNTING, THERMAL-TYPE

                                          ������������������������������������������������������������������������������������������������������
                                          Reliance P4200 Series Outdoor Swivel Mount Photo                a swivel arm which rotates 360 degrees and swivels 270
                                          Controls also fit into 1/2” knockout holes in standard outdoor degrees to aim the sensor specifically at the light source.
                                          light fixtures and electrical boxes for dusk-to-dawn control of Available in cube or pencil-style housings.
                                          outdoor light fixtures. The P4200 Series photo controls have

                                          FEATURES
                                          • 1/2” Conduit Mount                               • Sonic welded polycarbonate housing • 5/8”-18 NPSM, 3/4” long stem with
                                          • Cadmium sulfide photocell                          and lens to seal out moisture         locking nut and washer gasket
                                          • Compatible with incandescent,                    • Delay activation to prevent         • Rotating / swiveling stem
                                            CFL, HID and LED lighting                          nuisance light switching            • 6 “ wire leads
                                                                                             • Fits into standard electrical boxes
                                                                                               or outdoor light fixtures

                                                                          Model                   Type         Voltage      Hz      Tungsten     Ballast                Pack Warranty
                                                                           P4221            Swivel Side Lens    120VAC      60           2000W   2000VA                  6     5 Years
                                                                           P4223            Swivel Side Lens   208-277VAC   60           2000W   2000VA                  6     5 Years
                                                                           P4251             Swivel Top Lens    120VAC      60           1800W   1100VA                  6     5 Years
                                                                           P4253             Swivel Top Lens   208-277VAC   60           2000W   2000VA                  6     5 Years

                                                                       See complete Photo Controls Product Specifications on pages 35-36

                                                                                                                                                 WORKS WITH

                                                                                                                                                 outdoor fixtures
                                                                          SONIC-WELDED
                                              P4223                    POLYCARBONATE
                                                                   HOUSING AND LENS TO                                                                                DUSK TO DAWN
                                                                     SEAL OUT MOISTURE                                                                                LIGHT CONTROL

                                                                                                                                                                      CFL COMPATIBLE
                                                              ADJUSTABLE PENCIL-TYPE
                                                           HOUSING ALLOWS PIN-POINT
                                                           DIRECTION TO LIGHT SOURCE
                                                                                                                                                                      SAVES ENERGY
                                                                                                                                                  INDUSTRIAL GRADE
                                                                                                                                                   GRADO INDUSTRIAL

                                                                        5/8” - 18 NPSM 3/4” LONG                                                                      INDUSTRIAL GRADE
                                                                         STEM WITH LOCKING NUT                                   P4253
                                                                            AND WASHER GASKET
                                                             Meets or Exceeds
                                                             National Electrical Code® Requirements

                                                             Meets or Exceeds
                                                             National Electrical Code® Requirements

                                                             Meets or Exceeds
                                                             National Electrical Code® Requirements

                                         31              RelianceControls.com
THERMAL PHOTO CONTROLS

P4500 & P2000 SERIES LOCKING MOUNT

                                                                                                                                                      LOCKING-TYPE MOUNTING, THERMAL-TYPE
������������������������������������������������������������������������������������������������������
Reliance P4500 and P2000 Series Swivel Mount Photo                        is designed for easy, fast no-wiring replacement of
Controls install on light fixtures with ANSI C136.10                      PHOTO CONTROLS in high, or otherwise remote fixture
3-prong NEMA receptacles found on street light fixtures                   location. The P2000 has a heavy-duty electronic relay
for dusk-to-dawn control. The locking type connection                     designed for long life.

FEATURES
• Cadmium sulfide or electronic                    • UV-stabilized housing                     • Delay activation to prevent
  photo sensing (on P2000)                         • No-wiring connection with ANSI              nuisance switching caused by
• Compatible with incandescent,                      C136.10 NEMA 3-prong male                   automobiles, lightning or other
  CFL, HID and LED lighting                                                                      momentary light sources

                                 Model                 Type            Voltage       Hz      Tungsten    Ballast                Pack Warranty
                                  P4521                Locking          120VAC      50/60      1000W     1800VA                   6    5 Years
                                  P4523                Locking         208-277VAC   50/60      2000W     1800VA                   6    5 Years
                                  P2000           Locking Electronic   105-305VAC   50/60      1000W     1800VA                   6    6 Years
P4521
                            See complete Photo Controls Product Specifications on pages 35-36

                                                                                                          WORKS WITH

                                        UV-STABILIZED                                                     outdoor fixtures
                               THERMOPLASTIC HOUSING
                                                                                                                               DUSK TO DAWN
                                                                                                                               LIGHT CONTROL
                                       320 JOULE SURGE
P4523                                      SUPPRESSOR                                                                          CFL COMPATIBLE

                               ELECTRONIC SWITCHING                                                                            SAVES ENERGY
                                 RELAY FOR LONG LIFE                                                       INDUSTRIAL GRADE
                                                                                                            GRADO INDUSTRIAL

                                                                                                                               INDUSTRIAL GRADE
                                                                                            P2000
                                              NO-WIRING CONNECTION
P2000                                        WITH ANSI C136.10 NEMA
                                                       3-PRONG MALE

         Meets or Exceeds
         National Electrical Code® Requirements

         Meets or Exceeds
         National Electrical Code® Requirements

         Meets or Exceeds
         National Electrical Code® Requirements

                                                                                     RelianceControls.com                                        32
ELECTRICAL INNOVATION SINCE 1909

                             PE5000 SERIES ELECTRONIC PHOTOCONTROLS
ELECTRONIC PHOTO CONTROLS

                             BUTTON,         WALL-MOUNT, FIXED STEM & SWIVEL STEM
                             ������������������������������������������������������������������������������������������������������

                                                                                 Our Electronic Photo Controls install permanently in outdoor fixtures to match the
                                                                                 life expectancy of newer LED and other long-life lights. They feature a solid state
                                                                                 light sensor and relays with zero-crossing technology. Less moving parts equal more
                                                                                 accuracy and longer life for these premium Photo Controls.

                                                                                 8                       YEAR
                                                                                                         WARRANTY

                                                                                 FEATURES
                                 PE5051B
                                                       PE5051BW                  • Exceed 10,000 ON/OFF cycles                                  • Fail ON mode
                                                                                 • 15 Year design life                                          • Designed for single or multi-fixture HID
                                                                                 • Sturdy weatherproof construction                               and LED installations
                                                                                 • Silicon light sensor with IR filter                          • 160 J MOV surge protection
                                                                                 • DC Relay with Zero-Crossing circuitry                        • ½” – 14 NPSM threaded stems for
                                                                                 • 5 Amp electronic ballast                                       standard boxes

                                                                                     Model                      Type        Voltage        Hz       Tungsten   Ballast   Pack Warranty
                                                                                 PE5051B                        Button      120-277VAC   50-60 Hz    1800 VA    5 Amp      6     8 Years

                                                                               PE5051BW                        Button w/    120-277VAC   50-60 Hz    1800 VA    5 Amp      6     8 Years
                                                                                                               Wallplate

                                                                                PE5051PF                      Fixed Stem    120-277VAC   50-60 Hz    1800 VA    5 Amp      6     8 Years
                             PE5051PF                 PE5051PS                                                 Top Lens

                                                                                PE5051HF                      Fixed Stem    120-277VAC   50-60 Hz    1800 VA    5 Amp      6     8 Years
                                                                                                              Side Lens

                                                                                PE5051PS                      Swivel Stem   120-277VAC   50-60 Hz    1800 VA    5 Amp      6     8 Years
                                                                                                               Top Lens

                                                                                PE5051HS                      Swivel Stem   120-277VAC   50-60 Hz    1800 VA    5 Amp      6     8 Years
                                                                                                               Side Lens

                                                                                See complete Photo Controls Product Specifications on pages 35-36

                                                                                 WORKS WITH

                                                                                 outdoor fixtures

                                                                                                         DUSK TO DAWN
                                 PE5051HF                                                                LIGHT CONTROL

                                                        PE5051HS                                         CFL COMPATIBLE

                                                                                     INDUSTRIAL GRADE
                                                                                      GRADO INDUSTRIAL
                                                                                                         SAVES ENERGY
                                            Meets or Exceeds
                                            National Electrical Code® Requirements                       INDUSTRIAL GRADE

                                            Meets or Exceeds
                                            National Electrical Code® Requirements

                                            Meets or Exceeds
                                            National Electrical Code® Requirements
                            33                       RelianceControls.com
ELECTRONIC PHOTO CONTROLS

PE5000 SERIES ELECTRONIC PHOTOCONTROLS

                                                                                                                                                  ELECTRONIC PHOTO CONTROLS
LOCKING          STEM, LONG-LIFE
����������������������������������������������������������������������������������������������������

                                12                                                  8                                            6
                                 YEAR                                               YEAR                                          YEAR
                               WARRANTY                                           WARRANTY                                      WARRANTY

Model PE5081L                                   Model PE5051L                                     Model PE5021L
Our commercial use extended long-               Our contractor standard extended                  Our cost-effective extended life
life electronic photo control with a 12         long-life electronic photo control with           electronic photo control with a 6
Year limited warranty designed for              an 8 Year limited warranty designed               Year limited warranty designed for
20-year service for single or multi-            for 15-year service for single or multi-          10-year service for single-fixture
fixture long-life LED or HID fixtures           fixture long-life LED or HID fixtures             smaller LED or HID fixtures
FEATURES                                        FEATURES                                          FEATURES
• Exceed 15,000 ON/OFF cycles                   • Exceed 10,000 ON/OFF cycles                     • Exceed 5,000 ON/OFF cycles
• 20 Year design life                           • 15 Year design life                             • 10 Year design life
• UV stabilized impact resistant                • UV stabilized impact resistant                  • UV stabilized impact resistant
  polycarbonate (PC)                              polycarbonate (PC)                                polycarbonate (PC)
• Silicon light sensor with IR filter           • Silicon light sensor with IR filter             • Silicon light sensor with IR filter
• Zero-cross detection circuitry                • Zero-cross detection circuitry                  • 2 Amp electronic ballast
• 8 Amp electronic ballast                      • 5 Amp electronic ballast                        • Designed for single-fixture smaller
• Designed for single or multi-fixture          • Designed for single or multi-fixture              HID and LED installations
  HID and LED installations                       HID and LED installations                       • 320J MOV surge protection
• 320J MOV surge protection                     • 320J MOV surge protection

                                    Lens                                       Tungsten      Inductive      Electronic
   Model            Type                          Voltage            Hz                                                   Pack Warranty
                                  Location                                       Incan        Ballast         Ballast
   PE5021L         Locking           Side        120-277VAC       50/60 Hz       1000 W        1800 VA         2A           6     6 Years
   PE5051L         Locking           Side        120-277VAC       50/60 Hz       1000 W        1800 VA         5A           6     8 Years
   PE5054L         Locking           Side        347-480VAC       50/60 Hz       1000 W        1800 VA         5A           6     8 Years
   PE5081L         Locking           Side        120-277VAC       50/60 Hz       1000 W        1800 VA         8A           6     12 Years
   See complete Photo Controls Product Specifications on pages 35-36

P-SERIES       PHOTO CONTROLS ACCESSORIES
����������������������������������������������������������������������������������������                                        YEAR
                                                                                                                                 WARRANTY

Reliance Controls Accessories include wire-in mounting bases
for light fixtures that are not mounting base equipped, so that
Reliance Controls locking mount photo controls can be used.
Also included is an ALWAYS ON “shorting cap” that, when
installed, keeps lighting permanently ON.                                           P121           P122                P4500            P122M

  Model                                     Description                                      Voltage                UPC         Pack Qty.
    P121                Replacement Receptacle (Thin Style) 10” Wire Leads                  125 - 480 VAC     8-15181-01123-9       6
    P122               Replacement Receptacle (Thick Style) 10” Wire Leads                  125 - 480 VAC     8-15181-01121-5       6
   P122M       Replacement Receptacle (Thick Style) (with Metal Bracket) 10” Wire Leads     125 - 480 VAC     8-15181-01122-2       6
   P4500                           Shorting Cap - ALWAYS ON                                 125 - 480 VAC     8-15181-01750-7       6

                                                                                           RelianceControls.com                              34
ELECTRICAL INNOVATION SINCE 1909

                                     SPECIFICATIONS - RELIANCE CONTROLS PHOTO CONTROLS
PHOTO CONTROLS SPECIFICATIONS

                                       Model           Type            Lens      Voltage       Hz       Tungsten Incan   Inductive   Electronic   ON       OFF       Time Delay
                                                                     Location                                             Ballast      Ballast                          OFF
                                     BUTTON AND WALL MOUNT ELECTRONIC

                                      PE5051B         Button           Front    120-277VAC   50/60 Hz       1000 W       1800 VA        5A        1.5 fc   2.25 fc     3-15 Sec

                                     PE5051BW      Button w/Plate      Front    120-277VAC   50/60 Hz       1000 W       1800 VA        5A        1.5 fc   2.25 fc     3-15 Sec

                                     FIXED STEM MOUNT- ELECTRONIC

                                      PE5051PF      Fixed Stem         Top      120-277VAC   50/60 Hz       1000 W       1800 VA        5A        1.5 fc   2.25 fc     3-15 Sec

                                      PE5051HF      Fixed Stem         Side     120-277VAC   50/60 Hz       1000 W       1800 VA        5A        1.5 fc   2.25 fc     3-15 Sec

                                     STEM AND SWIVEL MOUNT ELECTRONIC

                                      PE5051PS      Swivel Stem        Top      120-277VAC   50/60 Hz       1000 W       1800 VA        5A        1.5 fc   2.25 fc     3-15 Sec

                                     PE5051HS       Swivel Stem        Side     120-277VAC   50/60 Hz       1000 W       1800 VA        5A        1.5 fc   2.25 fc     3-15 Sec

                                     LOCKING MOUNT ELECTRONIC

                                      PE5021L         Locking          Side     120-277VAC   50/60 Hz       1000 W       1800 VA        2A        1.5 fc   2.25 fc     3-10 Sec

                                      PE5051L         Locking          Side     120-277VAC   50/60 Hz       1000 W       1800 VA        5A        1.5 fc   2.25 fc     3-10 Sec

                                      PE5054L        Locking           Side     347-480VAC   50/60 Hz      1000 W        1800 VA        5A        1.5 fc   2.25 fc     3-10 Sec

                                      PE5081L         Locking          Side     120-277VAC   50/60 Hz       1000 W       1800 VA        8A        1.5 fc   2.25 fc     3-10 Sec

                                     BUTTON AND WALL MOUNT THERMAL

                                       P4021          Button           Front      120VAC     50/60 Hz       1800 W        1100 VA      9.1 A      1-2 fc   4-7 fc      3-15 Sec

                                       P4023          Button           Front    208-277VAC   50/60 Hz      2000 W        2000 VA        5A        1-2 fc   4-7 fc      3-15 Sec

                                       P4021C      Button w/Plate      Front      120VAC     50/60 Hz       1800 W        1100 VA      9.1 A      1-2 fc   4-7 fc      3-15 Sec

                                       P4023C      Button w/Plate      Front    208-277VAC   50/60 Hz      2000 W        2000 VA        5A        1-2 fc   4-7 fc      3-15 Sec

                                       P4024          Button           Front      120VAC     50/60 Hz       1000 W       1200 VA        2A        1-2 fc   4-7 fc      3-15 Sec

                                     FIXED STEM MOUNT- THERMAL

                                        P4121       Fixed Stem         Side       120VAC     50/60 Hz      2000 W        2000 VA       16.6 A     1-2 fc   4-7 fc      3-15 Sec

                                       P4123        Fixed Stem         Side     208-277VAC   50/60 Hz      2000 W        2000 VA       16.6 A     1-2 fc   4-7 fc      3-15 Sec

                                       P4421        Fixed Stem         Side       120VAC     50/60 Hz      2000 W        2000 VA       16.6 A     1-2 fc   4-7 fc      3-15 Sec

                                       P4423        Fixed Stem         Side     208-277VAC   50/60 Hz      2000 W        2000 VA       16.6 A     1-2 fc   4-7 fc      3-15 Sec

                                     Stem and Swivel Mount Thermal

                                       P4221        Swivel Stem        Side       120VAC     50/60 Hz      2000 W        2000 VA       16.6 A     1-2 fc   4-7 fc      3-15 Sec

                                       P4223        Swivel Stem        Side     208-277VAC   50/60 Hz      2000 W        2000 VA        5A        1-2 fc   4-7 fc      3-15 Sec

                                       P4251        Swivel Stem        Top        120VAC     50/60 Hz       1000 W        1100 VA      8.3 A      1-2 fc   4-7 fc      3-15 Sec

                                       P4253        Swivel Stem        Top      208-277VAC   50/60 Hz      2000 W        2000 VA        5A        1-2 fc   4-7 fc      3-15 Sec

                                     Locking Mount Thermal

                                       P4521          Locking          Side       120VAC     50/60 Hz       1000 W       1800 VA        15 A      1-2 fc   4-7 fc      3-15 Sec

                                       P4523          Locking          Side     208-277VAC   50/60 Hz      2000 W        1800 VA        5A        1-2 fc   4-7 fc      3-15 Sec

                                       P2000          Locking          Side     105-305VAC   50/60 Hz       1000 W       1800 VA       8.3 A      1-2 fc   4-7 fc      3-15 Sec

                                35                    RelianceControls.com
You can also read
