ALPHA ACTIVE PERFORMANCE GEAR SYSTEM MANUAL
JOIN THE ACTIVE MOVEMENT
CONTENTS.
WELCOME.
2
ACTIVE.
3
INSIDE.
4
ALPHA ACTIVE PERFORMANCE GEAR USER GUIDE
SAFETY.
WARNING: Exercise caution when using this device as
part of your active lifestyle. Always be aware of your
surroundings to avoid injury to yourself and others.
6
CONTRAINDICATIONS.
¢
¡
¢
¢
¢
¢
¡
¢
7
ALPHA ACTIVE PERFORMANCE GEAR USER INSTRUCTIONS
USER GUIDE.
¢
9
¢
¢
¢
£
¤
£
£
10BATTERY.
¤
¥
¦
¤
WARNING: Only use chargers marked: Output 5V 1A. If you
do not know the voltage and current of your charger, use
the included USB cable to charge the device from your
computer. Using a wall charger other than the
recommended specifications can damage the battery and
could result in fire or leakage.
11
12Stimulation On Intensity Level
Play/Pause Battery Level
Muscle Group Countdown Timer
Power
Switch on/off
Arms Up
Biceps Brachii Increase intensity
Triceps Brachii
Chest Down
Pectoralis Major Decrease intensity
Pectoralis Minor
Upper Back
Mid Trapezius Selector
Latissimus Dorsi Skip Warm-Up phase
Teres Major
Teres Minor
Abs/Lower Back
External Oblique
Rectus Abdominis
Erector Spinae
Glutes
Gluteus Medius
Gluteus Maximus
Legs
Quadriceps
Hamstrings
USB-C
Charging Port
13ALPHA ACTIVE PERFORMANCE GEAR CARE INSTRUCTIONS
SUIT MAINTENANCE.
¥
¢
¡
15SUIT MAINTENANCE.
¤
WARNING: Do not wash the
suit with the box attached.
The Active box should not be
in contact with water or
moisture under any
circumstances.
16MAINTENANCE.
¦
¢
¡ ¦
17Technical Specifications
Name of product: ALPHABODYTEC
Model: ACTIVE
Weight: 350g
Dimensions: 74mm x 115mm x 20mm
Power Consumption: 5 Watt
Powered by: Rechargable Li-Polymer Battery
Battery Capacity: 1050mAh
Charging Input: USB Type C (5V)
Display: Monochrome OLED
Waveform: Biphasic symmetrical
Shape: Rectangular and bipolar
Max Out. Volt: 60v
Max Out. Current: 100mAh
Pulse Duration: 10s
Pulse Pause: 5s
Pulse Width: 250us – 400us
Frequency: 50Hz – 100Hz
Channels: 7 channels
Duration: 30 mins
18ALPHA ACTIVE PERFORMANCE GEAR TRAINING GUIDE
TRAINING GUIDE.
Precautions
Active Performance Gear is designed to enhance your daily physical activity and improve
your training regime with the use of electrical muscular stimulation. No other use is
intended or implied.
Minimizing Possible Risks
Physical activity and exercising may include some risks. Before beginning a regular
exercise program, answer the following questions concerning your health status. If you
answer yes to any of these questions, consult a physician before starting any exercise
program.
Children:
• Have you been physically inactive?
• Do you have symptoms of any disease?
• Are you taking heart or any other medication?
• Do you have a history of breathing problems?
• Are you recovering from a serious illness or medical treatment?
• Do you use a pacemaker or other implanted electronic device?
Adolescents and adults:
• Have you been physically inactive for the past five years?
• Do you have high blood pressure or high blood cholesterol?
• Do you have symptoms of any disease?
• Are you taking any blood pressure or heart medication?
• Do you have a history of breathing problems?
• Are you recovering from a serious illness or medical treatment?
• Do you use a pacemaker or other implanted electronic device?
• Do you smoke?
• Are you pregnant?
If you feel unexpected pain or excessive fatigue when exercising, stop the exercise or
continue at a lighter intensity.
If you are allergic to any substance that comes into contact with your skin or if you suspect
an allergic reaction due to using the product, check the listed materials in Technical
Specifications.
The materials of this product have been tested and should not contain allergens or
substances hazardous to health. However, if symptoms do appear, stop using the product
immediately.
20WARM UP.
Prior to any training sessions with Active system, warm up has to be done. This is to
ensure that the muscles are ready for any physical activity and also to prevent any
exercise injuries. When you switch the system on, the warm-up sequence will begin.
You will be given a 5 minutes countdown timer to complete your warm up. Its
recommended to do dynamic (movement based) warm up exercises to ensure that the
muscles are really warm and ready for training. Once you have completed the 5 minutes
mandatory warm up sequence, you will then be able to move into intensity adjustments
and commence with your training. Never try to skip the warm up sequence as it may
endanger safety and lead to unnecessary injuries which can be avoided.
TRAINING
ENVIRONMENT.
Ensure to observe the following safety guidelines before using the Active system.
• Make sure you keep yourself well hydrated before, during and after your training
session.
• Consume your meals at least 45 minutes to 1 hour prior to training.
• Trainings should be done in an area with adequate space and not in a space where
movements are restricted.
• Avoid training in wet conditions or on a wet area.
• Do not expose the system to water.
• Training in cold conditions might require you to warm up longer than usual.
RULES OF USE.
• Please go through the contraindications in the manual for safety purposes.
• Ensure that you are clear for any form of physical training before using the Active
system, if unsure always check with your doctor.
• Warm up is compulsory before training.
• If you feel unwell during or before training stop the training immediately.
Medical Devices In Professional Use
Medical devices in professional use sets high standards for the manufacturer, distributor
and user of a medical device. Alpha Active offers user instructions and training for
professional users in order to ensure the safe use of Alpha devices.
21ALPHA ACTIVE PERFORMANCE GEAR TECHNICAL SUPPORT
ONLINE
REGISTRATION.
Getting Started
Please scan the QR code provided on your welcome card or proceed to the website,
www.alphabodytec.com/registration and begin your registration process.
This is a nessesary step in order for you to activate your warranty.
Once you have filled in your personal details, please download the online manual for the
instructions on how to use your Active EMS Performance Gear.
Data Protection
Please note that all the data collected through the online registeration is under
the Personal Data Protection Act (PDPA) therefore all our consumer data will remain
confidential.
23WARRANTY.
Warranty
Warranty Coverage
Alpha Bodytec’s warranty obligations are limited to the terms set forth below: Alpha
Bodytec. as defined below, warrants all Alpha software and training suit against defects in
materials and workmanship under normal use for a period of SIX (6) MONTHS from the
date of retail purchase by the original end-user purchaser (“Warranty Period”) whereas,
the Alpha Control Box will be under normal use for a period of ONE (1) YEAR from the
date of retail purchase by the original end-user purchaser (“Warranty Period”).
If a hardware and/or software defect arises and a valid claim is received within the
Warranty Period, at its option, Alpha Bodytec will either (1) repair the hardware defect at
no charge, using new or refurbished replacement parts, or (2) exchange the product with
a product that is new or which has been manufactured from new or serviceable used parts
and is at least functionally equivalent to the original product. (3) update or repair software
bugs or glitches that may arise or (4) will repair or replace parts at a charge if Alpha
Bodytec considers the product to be ineffective under the warranty obligations. A
replacement product or part provided by Alpha Bodytec assumes the remaining warranty
of the original product. When a product or part is exchanged, any replacement item
becomes your property and the replaced item becomes Alpha Bodytec’s property.
Exclusions & Limitations
This warranty does not apply: (a) to damage caused by use with non-Alpha Bodytec
products; (b) to damage caused by accident, abuse, misuse, rust, flood, fire, or other
external causes; (c) to damage caused by operating the product outside the permitted or
intended uses described by Alpha Bodytec ; (d) to damage caused by service (including
upgrades and expansions) performed by anyone who is not a representative of Alpha
Bodytec; (e) to a product, part or software that has been modified to significantly alter
functionality or capability without the written permission of Alpha Bodytec ; (f) to
consumable parts, unless damage has occurred due to a defect in materials or
workmanship; or (g) if any Alpha Bodytec serial number or security seal has been
removed or defaced. (h) or internal and external damage of the product due to wear and
tear, rustiness found on metal counterparts, furring and/or sheering, torn and holes of
fabric on the Power suit and/or broken zippers.
24Obtaining Warranty Service
An Alpha Bodytec representative or service provider will help determine whether
your product requires service and, if it does, will inform you how Alpha Bodytec will
provide it. Alpha Bodytec or its service providers will provide warranty service on
products that are tendered or presented for service during the Warranty Period, as
permitted by law. You may be responsible for shipping and handling charges if the
product cannot be serviced in the country it is in. In accordance with applicable law,
Alpha Bodytec may require that you furnish proof of purchase details and/or comply
with registration requirements before receiving warranty service which can be
obtained through the online registeration. Please refer below for the details on how
to obtain the warranty service. If the Alpha product is still under a valid warranty,
please drop Alpha Bodytec an email with your name and serial number. The service
department team will then verify the product’s warranty status before issuing a reply
on the return and/or exchange instructions. Please allow 3 – 5 working days for this
procedure.
Contact us at:
Email: info@bodytec.com.sg
Telephone: +65 6221 8386
Alpha Bodytec Pte Ltd
47 Kallang Pudding Road
Crescent @ Kallang
#05-12
Singapore 349318
25FAQ.
Q: IS TRAINING WITH EMS HARMFUL, ARE THERE ANY SIDE EFFECTS?
A: No, the training is not at all dangerous. Electro Muscular Stimulation has been used by
chiropractors, physicians and osteopaths for decades, but only recently has it started to
make headway in personal training. The system itself use a very low voltage electrical
impulses. The electrical impulses only target the skeletal muscles and not the organs of
the body.
Q: SHOULD I AVOID EMS TRAINING IF I HAVE CERTAIN HEALTH COMPLICATIONS?
A: Most people can use EMS training but if you have a certain health condition that
prevents you from participating in conventional sport, we would advise you to get an
approval from your doctor.
Unfortunately, it will be unsafe for users with the following conditions to use the system.
Do not use the system if you are:
• Pregnant
• Using a heart pacemaker
• Suffering from severe circulatory disorder & arterial circulatory disorder
Q: IS EMS TRAINING PAINFUL?
A: EMS training is no more strenuous than a conventional workout. By the end of the
session you will need a rest and a drink of water, depending on the intensity of your
workout. The equipment uses low impulse frequency, the experience of receiving the
impulses may take a little getting used to, but it is not painful in any way.
Q: HOW OFTEN CAN I DO THE TRAINING?
A: We recommend that our users train twice or thrice a week to see results. After each
training session it usually takes around 24hours for the body to recover and
consequently, doing more than the recommended sessions is not advisable. You can
train more than thrice a week based on your fitness progression.
Q: DIFFERENCE BETWEEN CONVENTIONAL TRAINING AND EMS TRAINING?
A: You only need to work out once or twice per week to achieve comparable results
compared to several hours in the gym. This means you can literally save yourself hours
per week! The results will come quickest if you workout twice or thrice per week.
26Q: CAN I USE THE SYSTEM WITHOUT DOING ANY PHYSICAL ACTIVITY?
A: This is not how the technology works. The technology enhances the impact of the
movements you do, and you must be doing exercises in order to experience benefits.
As you work out, the electrical pulses will stimulate the muscles, dramatically
improving the efficiency of the exercise routine.
Q: SHOULD I LIFT HEAVY WEIGHTS WHILE USING THE SYSTEM?
A: The Active system provides adequate resistance for an effective and efficient
training session. Training tools can be incorporated into sessions as your fitness
progresses. However using heavy tools while on strong stimulation can be dangerous
as you can overload your muscles.
Q: WHAT DOES EMS DO TO MUSCLES?
A: Electrical muscle stimulation (EMS) is the elicitation of muscle contraction using
low electrical impulses. These impulses mimic the action potential that comes from
the central nervous system, causing the muscles to contract involuntary.
Q: DO I NEED TO CHARGE THE BOX EVERY TIME AFTER USE?
A: The box has 3 hours of run time after every full charge but it is highly
recommended to charge the box after every 3 sessions of use.
Q: CAN THE BOX STILL BE USED EVEN THOUGH THE BATTERY IS RUNNING LOW?
A: It is recommended to use the box with sufficient battery as using the box when
battery is running low might cause the stimulation to be weak.
Q: IF I ENCOUNTER A BROKEN WIRE/PAD ON THE SUIT. CAN I STILL CONTINUE
WEARING IT?
A: If you encounter any damage on the pads and wires, refrain from using the suit and
contact the help line to get it replaced. Please follow the maintenance guideline on
the manual to prolong the suit life.
Q: CAN I CHARGE AND USE THE BOX AT THE SAME TIME?
A: For safety reasons, never charge and train at the same time, when the charging
cable is connected to the box the screen will display as charging and it will not allow
users to have access to the training functions.
Q: HOW DO I KNOW IF MY SUIT IS THE CORRECT SIZE?
A: The suit has to be skin tight without any air pockets in between the skin and the
suit. This is to ensure that the electrodes are fully in contact with the muscles. Air
pockets will cause discomfort during stimulation. Arms/Legs/Waist straps can be
worn to secure the suit to the body further.
27Q: CAN I SUPPLEMENT MY EMS TRAINING WITH MY NORMAL GYM ROUTINE?
A: Yes. EMS can supplement your normal gym routine and users can save time and
achieve better results by doing so.
Q: WHEN SHOULD I DO STRETCHING? BEFORE OR AFTER?
A: Its best to do dynamic warm up before training session and stretching after training
session.
Q: WILL I FEEL MUSCLE SORENESS?
A: Yes. EMS allows users to recruit up to 90% muscle fibres during training which will
cause users to have muscle soreness like any other trainings. It is recommended to train
using EMS 2 to 3 times a week. Users can increase training frequency as they see
progression.
Q: IS WARM UP NECESSARY FOR EMS TRAINING?
A: Warm up is mandatory before EMS training. This is to ensure that the muscles are
warm and ready for the training sessions, and also to ensure proper functioning of the
electrodes on the suit. The suit will not be able to detect a connection if the muscles are
not warm enough.
Q: MY BOX IS NOT WORKING, WHAT SHOULD I DO?
A: Do not attempt to do any self-repair as damages incurred will lead to a void of
warranty. Always check if the box has been charged and also try restarting the device if
you face a problem. If the problem persists, contact customer support for further
instructions.
Q: I CANNOT FEEL THE STIMULATION OR I FEEL A PINCH ON THE SKIN DURING
STIMULATION?
A: This happens when the skin becomes too dry due to insufficient warm up and
hydration. Always start the sessions with dynamic warm ups and hydrate yourself
throughout the sessions. When muscles get cold you will not be able to feel the
stimulation.
Q: HOW LONG DO I NEED TO WAIT FOR THE BOX TO BE FULLY CHARGED?
A: The Active box takes 2 to 3 full hours to be fully charged. Please refrain from
charging it overnight.
Q: HOW HIGH SHOULD I ADJUST MY INTENSITY LEVEL?
A: Adjust the intensity according to the type of training you are about to do. Make sure
that the stimulation is not too strong as it might result in restricting your movements.
Start with a light intensity and progressively increase the intensity.
28DISCLAIMER.
The material in this manual is for informational purposes only. The products it describes
are subject to change without prior notice, due to the manufacturer’s continuous
development program.
Alpha Bodytec Pte Ltd makes no representations or warranties with respect to this
manual or with respect to the products described herein.
Alpha Bodytec Pte Ltd shall not be liable for any damages, losses, costs or expenses,
direct, indirect or incidental, consequential or special, arising out of, or related to the use
of this material or the products described herein.
Customer Support
We are dedicated to providing the best possible service. To reach Alpha Customer
Support, visit www.alphabodytec.com/support.
Regulatory Information
To see the complete list of country certfications, refer to the Important Product + Safety
Instructions included with your device or visit www.alphabodytec.com
Trademarks
Alpha Bodytec, Active, Active+, Aspire and their respective logos are trademarks or
registered trademarks of Alpha Bodytec Pte Ltd in Singapore and other countries.
All information in this document and on the product website is subject to copyright and
other intellectual property rights of Alpha Bodytec Pte Ltd and its licensors. This material
may not be modified, reproduced or copied, in whole or in part, without the prior written
permission of Alpha Bodytec Pte Ltd and its licensors. Additional information is available
upon request.
© 2021 Alpha Bodytec Pte Ltd. All rights reserved.
29You can also read
