SNOOKER MONOPOINT RECESSED CANOPY SUSPENSION L30825- Zaneen
←
→
Page content transcription
If your browser does not render page correctly, please read the page content below
PROJECT
TYPE
SPECIFIER
SNOOKER MONOPOINT RECESSED CANOPY QUANTITY
SUSPENSION DATE
L30825- - - -
base number Color Finishes Finishes Cable
Temperature (Diamond) (Triangle) Color/Length
1.To build a product code in our configurator select the specify button on
the base model # product page
2. To build a manual product code on this datasheet choose from the
options listed below in blue font and add the suffix to the base model #
GENERAL
Division: Architectural
Series: Snooker
Subseries: Snooker Monopoint Recessed Canopy
Mounting Type: Suspension
Mounting Location: Ceiling
Subcategory: Pendant
Brand: Prolicht
PHYSICAL
Shape: Round
Diameter (mm): 72
13
Diameter (in): 2 ⁄16
Height (mm): 72
13
Height (in): 2 ⁄16
Max. Overall Height (mm): 2072
Max. Overall Height (in): 81 9⁄16
Ceiling Thickness (mm): 10 / 12.5 / 15 / 25
Ceiling Thickness (in): 3/8 or 1/2 or 9/16 or 1
Min. Recessing Depth (mm): 75
Min. Recessing Depth (in): 2 15⁄16
Light Distribution: Downlight
Weight (kg): 0.597
Weight (lbs): 1.316
Fixture Finish: SSR / BLV / CRW / CRY / HAB / LAG / UFT / ITH / RUA / RUR
/ MIC / FTG / MYG / TWT / LOD / PUS / FRO / FUP / KIA / POP / BLS / SPG /
MEY / GOH / GUM / CHC / COM / ANB / JAG
Fixture Material: Aluminum Die Cast
Cable Details: 2000mm or 4000mm Cable - Color Options: Black / White /
Orange / Red / Green
Cut-out Measurements: 68mm / 2 11/16"
ELECTRICAL
Lamp Type: LED
Input Wattage (W): 6.6
Total Output Wattage (W): 6
Dimming: Tri-Mode (Non-Dimming and Phase Dimming (120Vac only)
and 0-10V Dimming)
Driver Included: Yes
Driver Location: External
Driver Type: Constant Current - Universal
Driver Class: Class 2
Housing: ENCP3 w/Quick Connect
Input Voltage (V): 120 / 277
Constant Current (MA): 500
LED
Number of LEDs: 1
Color Temperature (°K): 2700 / 3000 / 4000
Max. Delivered Lumen (lm): 270 / 290 / 310
CRI: >90 CRI
Efficiency (%): 60
Lamp Life (hrs): 50000
OPTICAL
Optic°: 55
RATINGS AND CERTIFICATIONS Page 1/10
Zaneen Group
Certified By:Inc. © 2022, for
Certified T 1800-388-3382, F 416-247-9319,
North American Standards www.zaneen.com
Available forIP20
IP rating: International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
January 6, 2022, 2:38 pmPROJECT
TYPE
SPECIFIER
SNOOKER MONOPOINT RECESSED CANOPY QUANTITY
SUSPENSION DATE
L30825-
Page 2/10
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
January 6, 2022, 2:38 pmPROJECT
TYPE
SPECIFIER
SNOOKER MONOPOINT RECESSED CANOPY QUANTITY
SUSPENSION DATE
L30826- - - - -
base number Color Finishes Finishes Cable Shine Ring
Temperature (Diamond) (Triangle) Color/Length
1.To build a product code in our configurator select the specify button on
the base model # product page
2. To build a manual product code on this datasheet choose from the
options listed below in blue font and add the suffix to the base model #
GENERAL
Division: Architectural
Series: Snooker
Subseries: Snooker Monopoint Recessed Canopy
Mounting Type: Suspension
Mounting Location: Ceiling
Subcategory: Pendant
Brand: Prolicht
PHYSICAL
Shape: Round
Diameter (mm): 72
13
Diameter (in): 2 ⁄16
Height (mm): 72
Height (in): 2 13⁄16
Max. Overall Height (mm): 2072
Max. Overall Height (in): 81 9⁄16
Ceiling Thickness (mm): 10 / 12.5 / 15 / 25
Ceiling Thickness (in): 3/8 or 1/2 or 9/16 or 1
Min. Recessing Depth (mm): 75
Min. Recessing Depth (in): 2 15⁄16
Light Distribution: Downlight
Weight (kg): 0.614
Weight (lbs): 1.354
Diffuser: Shine Ring - White / Yellow / Orange / Red / Blue / Green
Fixture Finish: SSR / BLV / CRW / CRY / HAB / LAG / UFT / ITH / RUA / RUR
/ MIC / FTG / MYG / TWT / LOD / PUS / FRO / FUP / KIA / POP / BLS / SPG /
MEY / GOH / GUM / CHC / COM / ANB / JAG
Fixture Material: Aluminum Die Cast
Cable Details: 2000mm or 4000mm Cable - Color Options: Black / White /
Orange / Red / Green
Cut-out Measurements: 68mm / 2 11/16"
ELECTRICAL
Lamp Type: LED
Input Wattage (W): 6.6
Total Output Wattage (W): 6
Dimming: Tri-Mode (Non-Dimming and Phase Dimming (120Vac only)
and 0-10V Dimming)
Driver Included: Yes
Driver Location: External
Driver Type: Constant Current - Universal
Driver Class: Class 2
Housing: ENCP3 w/Quick Connect
Input Voltage (V): 120 / 277
Constant Current (MA): 500
LED
Number of LEDs: 1
Color Temperature (°K): 2700 / 3000 / 4000
Max. Delivered Lumen (lm): 270 / 290 / 310
CRI: >90 CRI
Efficiency (%): 60
Lamp Life (hrs): 50000
OPTICAL
Optic°: 55 Page 3/10
RATINGS
Zaneen AND
Group Inc.CERTIFICATIONS
© 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available
CertifiedforBy:
International specifications
Certified for by addingStandards
North American ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
IP rating: IP20
January 6, 2022, 2:38 pmPROJECT
TYPE
SPECIFIER
SNOOKER MONOPOINT RECESSED CANOPY QUANTITY
SUSPENSION DATE
L30826-
Page 4/10
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
January 6, 2022, 2:38 pmPROJECT
TYPE
SPECIFIER
SNOOKER MONOPOINT SURFACE CANOPY QUANTITY
SUSPENSION DATE
L30827- - - -
base number Color Finishes Finishes Cable
Temperature (Diamond) (Triangle) Color/Length
1.To build a product code in our configurator select the specify button on
the base model # product page
2. To build a manual product code on this datasheet choose from the
options listed below in blue font and add the suffix to the base model #
GENERAL
Division: Architectural
Series: Snooker
Subseries: Snooker Monopoint Surface Canopy
Mounting Type: Suspension
Mounting Location: Ceiling
Subcategory: Pendant
Brand: Prolicht
PHYSICAL
Shape: Round
Diameter (mm): 72
Diameter (in): 2 13⁄16
Height (mm): 72
Height (in): 2 13⁄16
Max. Overall Height (mm): 2072
Max. Overall Height (in): 81 9⁄16
Light Distribution: Downlight
Weight (kg): 0.745
Weight (lbs): 1.642
Fixture Finish: SSR / BLV / CRW / CRY / HAB / LAG / UFT / ITH / RUA / RUR
/ MIC / FTG / MYG / TWT / LOD / PUS / FRO / FUP / KIA / POP / BLS / SPG /
MEY / GOH / GUM / CHC / COM / ANB / JAG
Fixture Material: Aluminum Die Cast
Cable Details: 2000mm or 4000mm Cable - Color Options: Black / White /
Orange / Red / Green
ELECTRICAL
Lamp Type: LED
Input Wattage (W): 6.6
Total Output Wattage (W): 6
Dimming: Tri-Mode (Non-Dimming and Phase Dimming (120Vac only)
and 0-10V Dimming)
Driver Included: Yes
Driver Location: External
Driver Type: Constant Current - Universal
Driver Class: Class 2
Housing: ENCP3 w/quick connect
Input Voltage (V): 120 / 277
Constant Current (MA): 500
LED
Color Temperature (°K): 2700 / 3000 / 4000
Max. Delivered Lumen (lm): 270 / 290 / 310
CRI: >90 CRI
Efficiency (%): 60
Lamp Life (hrs): 50000
OPTICAL
Optic°: 55
RATINGS AND CERTIFICATIONS
Certified By: Certified for North American Standards
IP rating: IP20
Page 5/10
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
January 6, 2022, 2:38 pmPROJECT
TYPE
SPECIFIER
SNOOKER MONOPOINT SURFACE CANOPY QUANTITY
SUSPENSION DATE
L30827-
Page 6/10
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
January 6, 2022, 2:38 pmPROJECT
TYPE
SPECIFIER
SNOOKER MONOPOINT SURFACE CANOPY QUANTITY
SUSPENSION DATE
L30828- - - - -
base number Color Finishes Finishes Cable Shine Ring
Temperature (Diamond) (Triangle) Color/Length
1.To build a product code in our configurator select the specify button on
the base model # product page
2. To build a manual product code on this datasheet choose from the
options listed below in blue font and add the suffix to the base model #
GENERAL
Division: Architectural
Series: Snooker
Subseries: Snooker Monopoint Surface Canopy
Mounting Type: Suspension
Mounting Location: Ceiling
Subcategory: Pendant
Brand: Prolicht
PHYSICAL
Shape: Round
Diameter (mm): 72
Diameter (in): 2 13⁄16
Height (mm): 72
Height (in): 2 13⁄16
Max. Overall Height (mm): 2072
Max. Overall Height (in): 81 9⁄16
Light Distribution: Downlight
Weight (kg): 0.76
Weight (lbs): 1.676
Diffuser: Shine Ring - White / Yellow / Orange / Red / Blue / Green
Fixture Finish: SSR / BLV / CRW / CRY / HAB / LAG / UFT / ITH / RUA / RUR
/ MIC / FTG / MYG / TWT / LOD / PUS / FRO / FUP / KIA / POP / BLS / SPG /
MEY / GOH / GUM / CHC / COM / ANB / JAG
Fixture Material: Aluminum Die Cast
Cable Details: 2000mm or 4000mm Cable - Color Options: Black / White /
Orange / Red / Green
ELECTRICAL
Lamp Type: LED
Input Wattage (W): 6.6
Total Output Wattage (W): 6
Dimming: Tri-Mode (Non-Dimming and Phase Dimming (120Vac only)
and 0-10V Dimming)
Driver Included: Yes
Driver Location: External
Driver Type: Constant Current - Universal
Driver Class: Class 2
Housing: ENCP3 w/quick connect
Input Voltage (V): 120 / 277
Constant Current (MA): 500
LED
Number of LEDs: 1
Color Temperature (°K): 2700 / 3000 / 4000
Max. Delivered Lumen (lm): 270 / 290 / 310
CRI: >90 CRI
Efficiency (%): 60
Lamp Life (hrs): 50000
OPTICAL
Optic°: 55
RATINGS AND CERTIFICATIONS
Certified By: Certified for North American Standards
IP rating: IP20
Page 7/10
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
January 6, 2022, 2:38 pmPROJECT
TYPE
SPECIFIER
SNOOKER MONOPOINT SURFACE CANOPY QUANTITY
SUSPENSION DATE
L30828-
Page 8/10
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
January 6, 2022, 2:38 pmPROJECT
TYPE
SPECIFIER
SNOOKER QUANTITY
COLOR FINISH CHART DATE
Sparkling Silver - 01 (SSR) Black Velvet - 02 (BLV) Crystal White - 03 (CRW) Creamy - 04 (CRY) Hampton Bay - 05 (HAB) Lagoon - 06 (LAG)
Urban Forest - 07 (UFT) In the Army - 08 (ITH) Rusty Angel - 09 (RUA) Rusty Rush - 10 (RUR) Milk and Chocolate - 11 (MIC) Fade to Gray - 12 (FTG)
Mysterious Gray - 13 (MYG) Twilight - 14 (TWT) Lost Dream - 15 (LOD) Purple Sky - 16 (PUS) Fresh Oh - 17 (FRO) Funky P. - 18 (FUP)
Kissing Aphrodite - 19 (KIA) Poseidon's Paradise - 20 (POP) Blue Sky - 21 (BLS) Spring Green - 22 (SPG) Mellow Yellow - 23 (MEY) Golden Heart - 24 (GOH)
Gun Metal - 25 (GUM) Champagne Cream - 26 (CHC) Copper Mine - 27 (COM) Ancient Bronze - 28 (ANB) Jazz Gold - 29 (JAG)
Digital: Not all screens are calibrated the same, and therefore, colors will appear differently between screens.
Physical: When texture is involved, there will be variations in color, character and tone within a product series and between product families.
Gun Metal: No Gun Metal finish is alike. It combines a mixture of transparent and black color particles which ensures a highly individual effect and no luminaire being identical.
Champagne Cream, Copper Mine, Ancient Bronze + Jazz Gold: These finishes have slight fading from specific powder coating production. Each luminaire will slightly vary.
Page 9/10
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
January 6, 2022, 2:38 pmPROJECT
TYPE
SPECIFIER
SNOOKER QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com Page 10/10
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com January 6, 2022, 2:38 pmYou can also read
