4 EXECUTIVE SUMMARY
                                                                                                                  ICDP

 EXECUTIVE SUMMARY

Earth science goals                          The programme
Modern earth science has two basic           ICDP boasts a strong and active partici-      Through the unique
goals: seeking to unravel the histori-       pation of twenty-two member nations.          capacities of scientific
cal archives that are locked up in rocks     It has undertaken more than 30 drilling
                                                                                           drilling to provide
formed over the entire history of the        projects and run 75 workshops. Its cur-
Earth, and understanding the structure       rent budget of $3.5 million a year is a
                                                                                           exact, fundamental,
and dynamics of the active planet on         small fraction of that of the Internation-    and globally significant
which we live. To realise both goals sci-    al Ocean Discovery Program ( IODP ) or        knowledge of the
entific drilling is essential: it uncovers   other large earth science infrastructure      composition, structure,
rock archives containing the records of      projects. ICDP—already lean and mean
                                                                                           and processes of the
tectonic, climatic and biological cycles,    with a minimum of bureaucracy—is
and impacts from extraterrestrial bod-       making important ongoing changes to
                                                                                           Earth’s crust.
ies, from the present day, back into         its operations to build an even stronger
deep time. Targeted scientific drilling      technical base and reshaping its man-
allows us to sample, measure and moni-       agement structure to be more effective.
tor the Earth to help develop sustain-       Networking with other major earth sci-
able resources. Drillhole observatories      ence programmes is being strengthened,
give key insights into Earth’s internal      and bridges with the private and gov-
dynamic activities, such as fluctuations     ernment sector built, thus strengthening
in heat and the magnetic fields or earth-    ICDP’s economic and societal portfolio.
quakes and volcanoes.
                                             The spectrum
It would be impossible to undertake          ICDP has a broad portfolio centred on
modern earth science research with-          scientific drilling. Firstly, it provides a
out scientific drilling. The International   strategy for successful science deliv-
Continental Scientific Drilling Program      ery by funding workshops, leading and
( ICDP ) has played a primary role over      supporting technological innovation,
the past two decades, uncovering geo-        conducting outreach and teaching pro-
logical secrets from beneath the conti-      grammes and actively cooperating with
nents. It has enabled first-class science    programmes such as IODP. It provides
to be pursued, numerous targets to be        co-funding for coring as well as exper-
probed and hypotheses to be tested,          tise and advice on all matters technical
with the result that fundamental dis-        and logistical. It offers technological
coveries about ‘System Earth’ have been      support for geophysical logging and data
made, often bringing important socio-        management. ICDP is able to mobilise
economic benefits.                           multiple drilling platforms in diverse
UNRAVELLING THE COMPLEXITIES SCIENCE PLAN FOR 2014-2019 SCIENCE PLAN FOR 2014-2019 - GFZ-Potsdam
5 EXECUTIVE SUMMARY
                                                                                                                ICDP

environments: from lake sediment drill-     understanding spatial and temporal
ing for records of climate change over      variability, and the interconnectivity of
the past thousands of years, to special     systems. This is an organisational chal-
technology for drilling into high-tem-      lenge facing all drilling organisations.
perature hydrothermal systems and
micro-sampling for fluids using steri-      The science plan
lised drill-core sampling systems. Public   This document, the third ICDP Science
outreach and teaching are strong com-       Plan, came about by engaging the inter-
ponents of ICDP's profile, and is being     national science community around the         We cordially invite you
expanded further. ICDP is making            theme of ‘Unravelling the workings of         to read this White Paper.
significant difference in educating the     Planet Earth’. It lays out some of the big
                                                                                          You will discover why
public about our subsurface, providing      questions that confront the earth sci-
confidence that we know enough about        ences and suggests ways to answer them
                                                                                          earth science matters,
the upper kilometres in order to provide    that can be achieved by scientific drill-     and uncover the many
resilient solutions to infrastructure and   ing. Some of these questions are funda-       surprising ways in
resource development. A strong edu-         mental, for instance, the origin of life      which it affects your
cation programme will inspire young         on Earth, whereas others use the past
                                                                                          everyday life.
people and help create the next genera-     history of the Earth to imagine what a
tion of scientists who will be needed to    future Earth might look like. Some drill-
specialise in geology, geophysics, geo­     ing applications are highly specialised,
chemistry and geomicrobiology.              such as that for developing sensor net-
                                            works in underground observatories to
Process scales                              monitor earthquakes and volcanoes, the
Scientific drilling must deal with the      latter underpinning geothermal energy
Earth's fundamental processes that          production. To varying extents, these
work on timescales from microseconds,       scientific programmes have objectives
exemplified by stress transfer during       that are shared with the energy, water,
a fault rupturing, to hundreds of mil-      insurance, mining and other industries,
lions of years for plate tectonic cycles.   and with many government objectives,
The same is true of length, breadth and     but ICDP is firmly directed as a research
depth, from sub-micron bio-films and        enabler focused on cutting edge science
mineral defects, to thousands of kilo-      questions and innovations.
metres in fault movements, basin-filling    The main themes in this document are:
and mountain-building processes. The        •  active faults and earthquakes
interconnectivity of processes, including   •  heat and mass transfer
feedbacks, amplifications and degrees       •  global cycles, and
of organisation between them, is stag-      •  the hidden biosphere
geringly complex, involving chemical,       •  cataclysmic events
physical and biological components.         These will underpin societal challenges in:
Scientific drilling has made many fun-      •  water quality and availability
damental discoveries with individu-         •  climate and ecosystem evolution
al drill holes, but the coordination of     •  energy and mineral resources and
targeted activities is a key element in     •  natural hazards.
UNRAVELLING THE COMPLEXITIES SCIENCE PLAN FOR 2014-2019 SCIENCE PLAN FOR 2014-2019 - GFZ-Potsdam
UNRAVELLING THE COMPLEXITIES SCIENCE PLAN FOR 2014-2019 SCIENCE PLAN FOR 2014-2019 - GFZ-Potsdam
7 CONTENTS
                                                                                                                     ICDP

   EXECUTIVE SUMMARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
   ICDP—WHO WE ARE AND WHAT WE DO . . . . . . . . . . . . . . . . . . . . . . . . . . 8
   QUO VADIS, ICDP ? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
   CONFERENCE ACKNOWLEDGEMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
   CHALLENGES FOR SCIENCE AND SOCIETY . . . . . . . . . . . . . . . . . . . . . . . 12
   SCIENTIFIC DRILLING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
   MORE THAN SIMPLY DRILLING HOLES—A STRATEGY FOR SUCCESS 16
   PREAMBLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

PAVING THE WAY FORWARD—THE SCIENCE PLAN

   ACTIVE FAULTS AND EARTHQUAKES . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
   GLOBAL CYCLES AND ENVIRONMENTAL CHANGE . . . . . . . . . . . . . . . 32
   HEAT AND MASS TRANSFER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
   THE UBIQUITOUS HIDDEN BIOSPHERE . . . . . . . . . . . . . . . . . . . . . . . . . . 56
   CATACLYSMIC EVENTS —IMPACT CRATERS AND PROCESSES . . . . . . 66

   LINKS WITH OTHER ORGANISATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 74
   ROLE OF INDUSTRY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
   EDUCATION AND OUTREACH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
   EPILOGUE—ICDP IN ACTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
