PE-Xa pipe production technology with Borealis
PE-Xa pipe production
    For more information :
    visit www.borealisgroup.com and www.borouge.com
    Borealis AG • IZD Tower
    Wagramer Strasse 17-19 • A-1220 Vienna • Austria

                                                        technology
    Tel +43 1 22 400 000 • Fax +43 1 22 400 333
    Borouge Pte Ltd • Sales and Marketing Head Office
    1 George Street 18-01 • Singapore 049145

                                                        with Borealis
© 2013 Borealis AG . © 2013 Borouge Pte Ltd
PF BROCH 141 GB 2013 08 BB
PE-Xa pipe production technology with Borealis
Contents

                                      04         Borealis – your experienced
                                                 PE-Xa partner

                                      05         The benefits of PE-Xa pipe

                                      06         Recent developments in
                                                 PE-Xa pipe producton

                                      07         PE-Xa - the smart investment
                                                 over time

                                      08         Tailored solutions for
                                                 PE-Xa pipe production

     Picture courtesy of LK Systems                        Picture courtesy of Rehau

10                                                                                     3
PE-Xa pipe production technology with Borealis
Borealis –                                                 The benefits of
your experienced                                           PE-Xa pipe
PE-Xa partner                                                More Safety and Comfort with Cross-linking

                                                             • Flexibility
For decades Borealis has been a major supplier of            • Increased heat resistance
crosslinkable polyethylene (PE-X) for both Pipe and
Wire & Cable applications serving customers around           • High impact resistance at very low temperatures
the world with high quality products. Our global network     • Fast and easy installation
of customers, co-operations and industry key contacts
inspire us to devise new developments and ideas.             • Increased creep resistance under load and
                                                               temperature
The Borealis PE-Xa product range is tailored for the         • Increased chemical resistance
production of plumbing and heating pipes and covers two
                                                             • Very high notch resistance
methods of producing PE-X:
                                                             • Memory effect
                                                             • Chlorine resistance
    • Peroxide crosslinkable (PE-Xa)
                                                             • Abrasion resistance
    • Irradiation crosslinkable (PE-Xc)
                                                                                                                           Picture courtesy of LK Systems

                                                           Since its introduction, peroxide crosslinked PE pipe
Borealis offers much more than PE-Xa solutions. Our        has been recognised as the preferred choice of an ever
dedicated technical support team and the experience        increasing number of designers, installers and end-users.
built up over more than 20 years are part of our long-     Its popularity stems from the outstanding combination of
term commitment to service in this demanding industry.     strength, flexibility and the general quality appearance
Continuous product innovation through our passionate       of PE-Xa materials. Today the track record includes more
Research and Development organisation ensures future       than 30 years of proven success.
competitiveness for our customers.
                                                           Peroxide crosslinked PE pipe is the most flexible type of all
                                                           PE-X pipes since the crosslinking reaction takes place in
                                                           the pipe forming process in the molten stage rather than in
                                                           the pipe post-treatment step.

                                                           PE-Xa pipes enjoy good recognition worldwide in a broad
                                                           variety of applications such as heating and plumbing,
                                                           gas and domestic water supply, geothermal applications
                                                           and district heating, as well as in medical and industrial
                                                           applications.

4    PE-Xa pipe production technology with Borealis                                                                                                         5
PE-Xa pipe production technology with Borealis
Recent developments                                                                                                      PE-Xa - the smart
in PE-Xa pipe producton                                                                                                  investment over time
PE-Xa pipe production typically requires three separate   PE-Xa pipe manufacturers purchase their polyethylene
components:                                               resin, peroxide and additives directly from the producers.     Top 5 reasons for your PE-Xa investment
                                                                                                                                                                                                                 PE-Xa line speed development over time
                                                          The components are dry mixed into a homogeneous
                                                                                                                         • Inline crosslinking with no post treatment
                                                          mixture. The peroxide is then allowed to soak into the
    • PE resin                                                                                                             necessary
                                                          PE over time. Finally, in one step, pipe is extruded and                                                                                   35

                                                          crosslinked.                                                   • Increased line speed now possible with new                                30
    • Peroxide                                                                                                                                                                                       25
                                                                                                                           infrared and twin-screw technology

                                                                                                                                                                                  line speed m/min
    • Additive package                                    Twin-screw and infrared in PE-Xa                                                                                                           20

                                                          Over the last decade, twin-screw extrusion together with       • PE-Xa now accessible to all thanks to turn-key                            15

                                                          infrared heating has widely become the bench-mark                solutions on the market                                                   10

                                                          production concept in PE-Xa.                                   • Possibility to diversify with quality on the market
                                                                                                                                                                                                      5

                                                                                                                                                                                                      0
                                                                                                                           with crosslinking                                                              1970   1980        1990           2000    2010         2020
                                                          This established production technology concept offers                                                                                                                     Years
                                                          vastly increased output compared to conventional PE-Xa         • Favourable economics over the investment period
                                                          production rates in combination with outstanding quality         vs. other line concepts
                                                          control. Furthermore, at the end of the line, pipe producers
                                                                                                                                                                                 The linespeeds mentioned in the above graph are only indicative and are no guarantee of the
                                                          will have a ready-crosslinked pipe with no additional steps                                                            actival performance
                                                          required. Borealis can offer tailored solutions for your
                                                          twin-screw and infrared processing production line.

                                                                                                                                                                                                                                                                    Picture courtesy of Krauss-Maffei
                                                                      Picture courtesy of Maincor

6    PE-Xa pipe production technology with Borealis                                                                                                                                                                                                                                                     7
PE-Xa pipe production technology with Borealis
Tailored solutions for
                                                                                                                              Benefits of Borealis HE1878E                                  Benefits of Borealis HE1878E-C2
                                                                                                                                                                                            • Tailored for PE-Xa (twin screw)
                                                                                                                              • Effective mixing
                                                                                                                                                                                            • Class 5 listing (NSF)
                                                                                                                              • Fast and trouble-free screw extrusion

PE-Xa pipe production                                                                                                         • High and stable output

                                                                                                                              • High crosslinking response
                                                                                                                                                                                            • Fully stabilised – only peroxide to be added

                                                                                                                                                                                            • Best in class stabilisation

                                                                                                                                                                                            • Mini pellets solution
                                                                                                                              • Long-term resin availability
                                                                                                                                                                                            • Material tested in accordance with ASTM F876
                                                                                                                              • Pipe meets relevant PE-X standards including
                                                                                                                                                                                              and F2023
                                                                                                                                ISO15875, ASTM F876, DIN16892.
                                                                                                                                                                                            • Material listed at NSF and PPI
                                                                                                                              (Note: Pipe performance largely depends on the
                                                                                                                              additional components used by the pipe producer
                                                                                                                              and on the processing parameters applied.)

                                                                                                                           Borealis HE1878E-C2: Setting a new level of
                                                                                                                           performance with Class 5 listing (NSF)
                                                                                                                           Borealis HE1878E-C2 was developed to meet the higher
                                                                                                                           requirements of resistance to disinfectants in thot and cold
                                                                                                                           water pipe applications, thereby providing end-users with
                                                                                                                           additional peace of mind. The target was to make a ready-
                                                                                                                           made compound which would meet the highest standards
                                                                                                                           whilst also making PE-Xa pipe production easier, safer and
                                                                                                                           more cost efficient. Tailored for PE-Xa, Borealis HE1878E-C2
                                                                                                                           has already been established on the market as a leading
                                                                                                                           high performance, cost saving and safe material solution
Borealis HE1878                                              Borealis HE1878E was specifically designed to be              for crosslinked pipes in plumbing applications. Borealis
For decades Borealis and Borouge have served the PEX         the high-speed solution for machinery set-ups such            HE1878E-C2 has now further been accredited with the
pipe industry with tailored Borealis polyethylene products   as twin-screw extrusion equipment combined with               highest available chlorine resistance requirements, Class
best suited for specific production methods.                 infrared crosslinking technology. Now regarded as a           5 listing, according to the ASTM F876 standard for PE
                                                             benchmarkin the PE-Xa industry, Borealis HE1878E              crosslinked pipes. This accreditation not only confirms the
Many recognise our resin, Borealis HE1878, as the top        offers a well-balanced molecular weight and higher MFR        competitive edge of Borealis HE1878E-C2 but also con-
choice for the so-called Engel process. Why? Because         than traditional PE-Xa resins, as well as a combination       siderably broadens its potential markets, bringing greater
Borealis HE1878 was specifically designed in the 1970s       of significant advantages: Borealis HE1878E was               benefits to pipe producers and the whole pipe value chain.
for the RAM extrusion process, which was invented by         developed as a result of our dialogue with pipe designers,                                                                   Borealis tailor-developed offering in PE-Xa
Professor Thomas Engel. Characterised by a high              manufacturers and pipe end-users, listening to market         In addition to the well-known benefits associated with
                                                                                                                                                                                                                      MFR 190°C/21.6 kg      Density
molecular weight and Melt Flow Rate (MFR), the resin still   demands. Pipe producers can trust Borealis HE1878E to         PE-Xa pipe, such as high temperature resistance,                                              (g/10 min)          (kg/m³)
remains the perfect choice for the RAM extruder. Borealis    be the high-performance PE resin for the future.              excellent flexibility and low creep, the Borealis
HE1878 is arguably the most used PE resin in PE-X pipe                                                                     HE1878E-C2 solution offers a fundamental production             Borealis HE1878                   3                955
history.                                                     Borealis HE2591                                               advantage; it is a fully formulated, minipelletised
                                                                                                                                                                                           Borealis HE1878E                  10               951
                                                             Borealis HE2591 is the solution for pipe producers wishing    compound that requires only peroxide to be added.
Borealis HE1878E                                             to target maximum pipe flexibility. With this unique resin,   Furthermore, its state-of the-art stabilisation package         Borealis HE2591                   10               944
Over time, screw extruder technology development and         the pipe producer can effectively balance flexibility with    also opens it up for use in certain industrial applications.
                                                                                                                                                                                           Borealis HE1878E-C2               9                952
high output demand triggered the birth of a new PE resin,    hydrostatic performance. From the processing point of
Borealis HE1878E. Twin-screw extruders have become           view, Borealis HE2591 provides the same advantages
the preferred process method for producing PE-Xa pipe        as Borealis HE1878E. It is a true high-speed performer,
due to their ability to offer superior mixing and safe       especially when used in screw extruders.
homogenisation without overheating and prematurely
crosslinking PE-Xa formulations. All of this contributes
to higher production line speeds and longer trouble-free
PE-Xa pipe production runs.

8   PE-Xa pipe production technology with Borealis                                                                                                                                                                                                     9
PE-Xa pipe production technology with Borealis
Leading providers
of innovative
plastic solutions
Borealis and Borouge are leading providers of innovative                      Borealis also creates real value for the agricultural
plastics solutions that create value for society.                             industry with a large portfolio of fertilizers. The company
                                                                              distributes approximately 2.1 million tonnes per year. This
Building on the unique Borstar and Borlink technologies
                                     ®               TM
                                                                              volume will increase to around 5 million tonnes by the end
and 50 years of experience in polyolefins, Borealis and                       of 2014.
Borouge support key industries including infrastructure,
automotive and advanced packaging.                                            Borealis and Borouge proactively benefit society by
Their manufacturing capacity reaches over 5.4 million                         taking on today’s challenges and are working to drive
tonnes of polyethylene and polypropylene per year.                            ideas forward. Both companies are committed to the
                                                                              principles of Responsible Care , driving improved safety
                                                                                                                    ®

Borealis is headquartered in Vienna, Austria, and operates                    performance within the chemical industry and contributing
in over 120 countries with around 6,200 employees                             to addressing the world’s water and sanitation challenges
worldwide. Borouge, its joint venture with the Abu Dhabi                      through product innovation and their Water for the World              TM

National Oil Company (ADNOC), employs approximately                           programme.
1,700 people, has customers in more than 50 countries
and its headquarters are in Abu Dhabi in the UAE and                          For more information visit:
Singapore. Together, both companies provide services and                      www.borealisgroup.com
products to customers around the world.                                       www.borouge.com
                                                                              www.waterfortheworld.net
Borealis offers a wide range of base chemicals, including
melamine, phenol, acetone, ethylene and propylene
servicing a wide range of industries. Together with Borouge
the two companies will produce approximately 6 million
tonnes of Base Chemicals in 2014.
