TMALL 0141 Presentation v 1.0
four tracks
Lund-Arlöv,
Project review during the tender period
Agenda
12:30-12:45 Purpose of the meeting and presentation of participants
12:45-13:30 Business proposal
13:30-13:45 Short break
13:45-15:15 Orientation of the project according to AFB.24
2
The Law governing the project review during tender period
(LUF Ch 1 § 24)
The purchasing unit shall treat all suppliers in an equal an non-
discriminating way, as well as executing the procurement in an open and
transparent way.
• The same identical presentation is shown to all invited tenderers.
• The only questions that will be answered are:
– Questions for which the answer can be read straight from the tender
documents
– General questions about the project
– General questions about procurement law/LUF
• Questions & answers will be sent out to all invited tenderers.
• This presentation will be published on the project website.
The presentation will not be part of the tender documents.
3
4
Project Organisation
Senior
Project Manager
Jens-Peter
Eisenschmidt Special support
Engineering -
Construction
Project Manager Procurement
Manager Engineering -
Performance
Systems
Management Malin Isaksson
Patrik Dymling Engineering -
Environment
Land Negotiation
Project Manager Project Manager
Project Manager Project Manager
Railwayplan Construction Communication
Civil works Railway
Lund-Flackarp
HSQ
Jenny Åkerholm Marie Minör Thomas Hallgren Kristofer Söderberg
5
Where 6
What
• Expansion from two to four tracks, 11 kilometres
Lund-Flackarp 3 km + Flackarp-Arlöv 8 km
• Rebuilding of three stations in Hjärup, Åkarp and
Arlöv. New station, Klostergården (Lund)
• Total budget approx. Total budget 520 M EUR
Flackarp-Arlöv 400 M EUR
Lund-Flackarp 120 M EUR
(at 2015 price levels)
7
Why
• Higher capacity on the railway
• Reduce noise pollution
• Reduce traffic disturbances and congestions
• Reduce the railway barrier effect
8
Preliminary Time plan 9
Where are we now?
• Tender Documents, June 2016
• The railwayplan Flackarp-Arlöv gained legal force, November 2016
• Tenders, March 14th 2017
• Contract signed, May/June 2017
10Contract form Lund-Arlöv
Board decision 2016-04-20
• Design and Build contract
• Procurement procedure: Negotiated procedure, (LUF)
• Collaborative business relationship
• Payment form: current account with incentives
• Incentive 80/20 over och under the target cost
• Added value: 25 %
• Contract period: 2017-2022, Lund- Flackarp 2023
• ECI on the part Lund-Flackarp as an Option with a possibly exit
• Warranty period: 5 år
11Risk sharing Lund-Arlöv
Risk (higher cost than target
cost) – is split 80/20 between
Client and Contractor
Incentives Target cost =Tender amount
(lower cost than target
cost) – is split 80/20
between Client and
Contractor
Fixed compensation=
9% of the target cost
12What is ECI - Early Contractor Involvement?
• The contractor will enter the project at an early
stage
• Collaboration
• The contractor affects the design of the project
early on as much influence as possible in time,
cost and content
13Early Contractor Involvement - Phases
ECI - Contrakt
Phase 1 ABT Phase 2 ABT
Phase 1 The planning and development phase
• Necessary planning
• Production Cost
• Detailed time schedule
• Risk Management
• Target cost for phase 2
14Roadmap
Client’s control of constructability
2017 – Start of design/construction
2019 – 2021 Traffic on temporary tracks
2021 Traffic on new 4-track Flackarp - Arlöv
2023 Traffic on new 4-track Lund - Arlöv
15Start 1/8 2017 16
2017-2018 17
Civil works
• Design
• Noise barrier in Arlöv moves west.
• Bridge over Lommavägen i Arlöv, completed Jan 2018
• Bridge E6 over road and temporary tracks, completed April 2018
• Pipes which cross E6 east and west of the railway.
• When the project starts Gränsvägen will be ready between
Lundavägen and section 1/100.
• Temporary bridge Gränsvägen and accending road, completed Jan
2018
• Temporary bridge Vragerupsvägen and accending road, completed
April 2018.
• Tunnel for walking and bicycling at Burlövs station, completed June
2018
18Civil works
Temp. bridge
Vragerupsvägen and road
april 2018
Temp. bridge
Gränsvägen and road
jan 2018
E6 two bridges and
pipes that cross E6 Level crossing
april 2018 Alnarpsvägen closed
jan 2018
Tunnel, Burlöv station
West part juni 2018
Bridge,
Lommavägen Noise barrier
jan 2018 moves
19BEST
Design
Reconstrution of the western part of Arlöv railway yard
5 switches removed
12 new switches to be installed
About 2000m new track
About 3000m new catenery
Signalling system Bombardier interlocking 95 (Side contractor)
One of the most busiest tracks in Sweden
Lommabanan closed for about 3 month
20July 2018 21
2018-2019 22
Civil works
New pipes and cables in Bruksvägen
Pond near E6
Construction for Alnarpsån under Sockervägen completed Jan 2019
Bridge over Kronetorpsvägen the west part, completed Jan 2019
Excavation work for temporary tracks
23Civil works
Pipes and cables,
Bruksvägen.
Pond near E6
Construction, Alnarpsån, (creek)
Sockervägen
jan 2019
West bridge, Kronetorpsvägen
jan 2019
24BEST
Temporary tracks Flackarp-Arlöv, about 5000m
Reconstruction of the west part of Arlöv railway yard
Temporary platforms in Åkarp and Hjärup
4 new switches in Åkarp
Bombardier signalling system on temporary track
10 000m track
15 new points
12 000m catenery
The option Lund-Flackarp must be called off
25July 2019 26
2019-2020 27
Civil works
Tunnel for walking and bicycling at Burlövs station east part, completed
Jan 2020
Station bridge Hjärup, completed June 2020
Excavation work for the new four tracks
Option
Excavation work for the new four tracks Lund-Flackarp
28Civil works
Station bridge, Hjärup
juni 2020
Tunnel, walking/bicycle,
Burlöv station
West part juni 2018
East part jan 2020
29BEST
Dismantling/demolition of excisting 2-track Flackarp-Arlöv
Design
Reconstruction of the east part of Arlöv railway yard
4 switches removed
8 new switches to be installed
About 1500m new track
About 2000m new catenery
Bombardier signalling system
30October 2019 31
2020-2021 32
Civil works
• E6 bridge over 4-tracks, complete oct 2020
• Bridge Alnarpsvägen, complete oct 2020
• Bridge Gränsvägen, complete oct 2020
• Bridge Lommavägen in Hjärup, complete oct 2020
• Bridge Vragerupsvägen, complete oct 2020
Option:
• Bridge Ringvägen in Lund, complete oct 2020
• New tunnel for walking and bicycling at Klostergården, complete oct
2020
• New bridge over Höje å, complete oct 2020
• New bridge over road108, complete oct 2020
33Ringvägen, Lund
Sept 2020 (option)
Civil works Tunnel walking/bicycle at
Klostergården Sept 2020 (option)
Höje å (creek)
Bridge Vragerupsvägen Sept 2020 (option)
Temp. april 2018
finished oct 2020
Road 108
Sept 2020 (option)
Bridge Lommavägen
in Hjärup, oct 2020
Bridge Gränsvägen
Temp. jan 2018
finished oct 2020 Bridge Alnarpsvägen,
oct 2020
E6 two bridges and
pipes that cross E6
april 2018
Bridge over 4-tracks,
oct 2020
34Civil works
Tunnel in Åkarp, finished jan 2021
Bridge over Kronetorpsvägen (east side), completed jan 2021
35Civil works
Tunnel Åkarp
Jan 2021
West bridge, Kronetorpsvägen
Jan 2019
East bridge jan 2021
36BEST
Construction of new 4-track Flackarp-Arlöv
Temporary platform in Hjärup, east side
New platform in Burlöv, east side
New platforms i Åkarp
35 000m track
20 new switches
40 000m catenery
Bombardiers signalling system
Option:
New 2-track Lund-Flackarp west side
6 000m new track
7 new switches
7 000m catenery
37July 2021 38
July 2021 39
2021-2022 40
Civil works
Completion east side of Hjärups station with support structures,
completed June 2022
Restoration of land continously. The big work with restoration will take
part when the temporary tracks are demolished.
Option:
Demolition existing bridge Ringvägen
Excavation and ground preparation for new tracks east side
41Demolition existing bridge
Ringvägen
Civil works
Hjärup station, support structures
East part, june 2022
42BEST
Start demolition/dismantling of temporary track
Completion and opening of new platform east side in Hjärup
Option:
Demolition/dismantling of existing 2-track Lund-Flackarp
43October 2021 44
July 2022 45
July 2022 46
2022-2023 47
Civil works
Option
New bridge over Ringvägen east part, completed sept 2022
New tunnel for walking and bicycling east side Klostergården,
completed sept 2022
New station Klostergården open June 2023
48Bridge , Ringvägen
East part sept 2022
Civil works Tunnel, walking/bicycle,
Klostergården, east part sept 2022
49BEST
Option
Construction of new 2-track Lund-Flackarp, east side
6 000m track
8 000m catenery
Bombardier signalling system
New platforms Klostergården
Restoration of land used for temporary occupation
50July 2023 51
Collaborative business relationship
• Commit to a close collaborative relationship!
• Collaboration is the critical factor for success
52Collaborative business relationship Co-location - Better understanding of the project - Improved teamwork - Shorten ways of decision 53
Collaborative business relationship Safe working environment - Always the highest priority - A mutual commitment to keep a high standard - From top to bottom and bottom to top 54
Collaborative business relationship
Risk management
- A joint effort and open sharing of risks
- Maximize opportunities and minimize threats
- Closely tied to form of payment 80/20
- Smart solutions benefit both parties
55Collaborative business relationship
Building information modeling (BIM)
- All digital deliveries
- Visualize:
- collision control
- track economy
- execution of construction work
- production planning
- planning for safe working enviroment
- Contractor supplies digital workspace
- Workspace and deliveries for all parties
