LETTERS
6 Message from the SAIEE President
Dr. Pat Naidoo.
REGULARS page 8
8 wattsup
Current Affairs.
12 Engineering Nuggets
16 News
Industry updates.
62 Calendar of events
page 16
FEATURE
20 Lightning and surge protection for wind turbines
The risk of lightning striking a wind turbine increases dramatically due to its height.
30 Power supply of 4th generation mobile radio systems
Network transmission systems grow and change and this has consequences
for reliable lightning and surge protection.
TECHNOLOGY
34 The evolution of Medium Voltage Power Cables page 20
Taking a look at ow technology has improved over the past century.
MEMORIES
48 Memories of Lightning Protection on Distribution Lines
Anton Schmidt shares with us a memory from the 80's.
HISTORY
50 Faraday & Maxwell
Dudley Basson shares with us why these two scientists became icons of their
generations. page 50
YOUR OPINION
58 Keeping the Lights on
Opinion piece by Max Clarke.
LOOKING BACK
60 July
What happend on this day in July?
wattnow | july 2014 | 3
From the Editor's Desk | minx avrabos
o, July is upon us and
brings with it cold and
windy days - in some
areas in South Africa,
even wet days, filled with lightning and thunderstorms.
This issue of wattnow focuses on Lightning and our feature article,
“Lightning and Surge Protection for Wind Turbines” can be found
on page 20. This article takes an in-depth look at how to protect wind
turbines from downtime.
Our Technology section sports a brilliantly written article by Patrick
O’Halloran on the evolution of medium voltage power cables. In this
article he shares with us how technology has improved over the years,
and how to correctly install the latest technology.
Anton Schmidt shares with us his memories on protecting distribution
lines in the late 80’s. Read his memoir on page 48.
We have another lip-smacking good piece of history aptly written by
Dudley Basson on Michael Faraday & James Maxwell. This article, on
page 50, tells us about why these two scientists became giants in their
respective fields. An absolute must read!
“My Opinion”, page 58 is written by Max Clarke – about keeping the
lights on. I fully agree with him, let me know your thoughts.
