IN Series IN120 WiFi & IN220 PoE Intelligent IP-Enabled Access Control Available through Authorized Channel Partners only. Contact your local ASSA ABLOY Door Security Solutions sales consultant for details. Product Catalog
About ASSA ABLOY’s Authorized Channel
Partner and Certified Integrator Programs
The Corbin Russwin IN120 and IN220 are part of the expanding ASSA ABLOY family of innovative products combining our proven
mechanical locking devices with leading-edge technologies to provide integrated electronic access control solutions. As such, these
products require training and certification for resellers and integrators to ensure proper product selection, successful deployment
and customer satisfaction.
To aid our customers in this area, ASSA ABLOY has created two programs that provide the necessary training to sell, order, install
and service our technology products, including Aperio® wireless, Integrated Wiegand, IP-enabled and self-configurable intelligent
components:
• The Authorized Channel Partner (ACP) program is open to resellers, who sell ASSA ABLOY’s technology products to certified
integrators and help with product selection based on the application.
• The Certified Integrator (CI) program provides hands-on training for security systems integrators and network administrators.
Not only does this training familiarize certified integrator candidates with product features and applications, it also gives them
valuable experience installing, commissioning and troubleshooting the products in a real-world environment.
For more information on the qualifications for becoming an ACP or CI, contact your local ASSA ABLOY Door Security Solutions
sales consultant for details.
Sold through: Installed by:
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
IN Series.2 45450 04/21
Sold through:
Introduction
IN Series Intelligent IP-Enabled Access Control
Index The Corbin Russwin IN Series of IP-enabled locks pairs a sleek, attractive design with
the latest in access control technology to address the evolving needs of today’s facilities.
Featuring HID® multiCLASS SE® technology, our innovative WiFi and PoE locks make
Features and Benefits ...................... 4 it easy and affordable to expand your access control system by leveraging existing
Overview ........................................ 5 network infrastructure.
ML20100 Mortise Locks
Features .......................................... 6
How to Order ..............................7-8 Provided by others
Quick Codes ................................... 9
Network Cable
Surface Mount Box
ML20200 Mortise Locks
Network Switch (RJ45)
Features ........................................ 10 (802.3af)
How to Order ..........................11-12 A
Quick Codes ................................. 13
Purchased through ASSA ABLOY:
CL33100 Cylindrical Locks A. Cable - PoE Frame side Harness Assembly
Features ........................................ 14 B. PoE Data Hinge (Patent Pending)
How to Order ............................... 15 C. Cable - PoE Door Harness Assembly* D
Quick Codes ................................. 16 D. IN220 PoE Lock
E. Door Position Switch (DPS) - Not required for B C
ML20200 and multipoint devices. E
ED5000N Exit Devices *Door width determines length
Features ........................................ 17 For a detailed explanation of the above, please
How to Order ..........................18-19 refer to Application Diagram on page 27.
Quick Codes ................................. 20
BL6600/FE6600/MP6600
Multi-Point Locks
Features ........................................ 21
How to Order ..........................22-23
802.11 b/g/n
Wireless Access Point
IN Series Retrofit Kits for Von
®
Duprin 98/99 series
Features ........................................ 24
How to Order ............................... 25
Options & Accessories ..............26-27
IN220 Application Diagram ........... 28
Lock Management Tool ................. 29
Available Trim Options .............30-32
How to Order Museo Piet Levers ... 33 IN120 IN120
Common Replacement Parts ....34-35
EAC Server
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
45450 04/21 IN Series.3
Sold through:
Overview
IN Series Intelligent IP-Enabled Access Control
IN120 IN220
Features Benefits
WiFi Lock PoE Lock
Utilizes IEEE 802.3af PoE-enabled • Streamlines the installation process, reducing costs
network infrastructure for both power
and data
• Eliminates the need for any proprietary equipment •
• Enables real-time communication
• Significantly reduces installation costs
Utilizes IEEE 802.11 WiFi infrastructure • Eliminates the need for any proprietary equipment •
• Ideal for hard-to-wire locations
802.11b/g/n radio • Interoperability with other WiFi equipment •
• Provides heightened security
• Supports:
multiCLASS SE® Technology from
HID Global®
– Multiple credential types • •
– HID Mobile Access® powered by Seos®, for iOS® and
Android™ devices
Field selectable communication
frequency
• Allows you to balance security requirements with battery life •
• Significantly less power consumption in standby mode than
traditional access control •
Reduced energy consumption and
product sustainability measures
• Leverages existing network infrastructure • •
• Streamlined system architecture provides improved reliability
and reduces materials • •
• Lock operates regardless of network status • •*
Intelligence built into lock for local
decision making*
• Supports up to 2,400/10,000 users** • •
• Provides a 10,000 event transaction history/audit trail • •
• Enables shelter in place/local lockdown
Privacy button
• Offers privacy capabilities for applications such as restrooms • •
Integrated ANSI/BHMA Grade 1 • Flexibility to support various openings
hardware, available in cylindrical lock,
mortise lock, exit device, and multi-point
• Assurance of high quality Corbin Russwin hardware
• •
lock configurations
• Blends into any environment seamlessly
• Designed to meet the requirements of designers and architects
Superior aesthetics
• Available with a wide range of finishes and decorative levers • •
• Suites with other IN Series locks, regardless of technology
*Requires backup power for IN220
**Contact your access control system manufacturer for more information
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
IN Series.4 45450 04/21
Sold through:
Overview
IN Series Intelligent IP-Enabled Access Control
Credential Support: IN220
The IN Series IP-enabled locks feature HID® • Conforms to IEEE 802.3af Class 1
multiCLASS SE® technology to support the standard, requiring less than 3.84 watts
following credentials:
• Mobile Credentials: Security:
– HID Mobile Access® support,
featuring Secure Identity Object™ • Optional, protocol level, 128-bit AES
encryption (IN120, IN220)
(SIO) on mobile IDs (BLE and NFC)
– LenelS2 BlueDiamond™ • IN120 supports current WiFi network
– Apple Wallet Seos or DESFire® (NFC) security standards, including:
– Google Pay DESFire® (NFC) – WEP, WPA and WPA2
• High Frequency (13.56 MHz): – 802.1x
– HID iCLASS® • For specific security information, please
– HID iCLASS SE® (SIO-enabled) contact your local ASSA ABLOY Door
– HID iCLASS® Seos™ Security Solutions sales representative or
call 800-810-Wire.
– HID MIFARE® SE
– HID DESfire® EV1 SE
– MIFARE Classic Software:
– DESfire EV1 • Works with ASSA ABLOY IP-Enabled *Excludes CREK series.
– Felica Access Control Partner software,
allowing simple integration into existing
– PIV/PIV-I (40-bit BCD, 64-bit BCD, 75 or new systems
bit, 128-bit or 200-bit outputs)
• Software Development Kits (SDK) and
• Low Frequency (125 kHz): support available to integrate into other
– HID Prox® third party access control systems.
• Optional keypad For assistance, email:
– PIN only usage or dual authentication OEMSupport_Group@assaabloy.com
needs
Note: If your site is planning to use multi-technology
• Lock Management Tool available for
cards, please contact 800-810-WIRE for more small installations
information.
Technical Specifications: EAC Regulatory Compliance*:
IN120 • UL 294 Indoor Use
• Compatible with 802.11 b/g/n 2.4GHz • ULC-60839-11-1, Grade 1
wireless networks • BHMA A156.25
Optional Keypad
PIN only usage or dual authentication needs
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
45450 04/21 IN Series.5
Sold through:
Features
ML20100 Mortise Locks
The IN Series mortise lock has a clean, crisp design and is available with a variety of lever designs and
hardware finishes.
Auxiliary Latchbolt Monitoring
9/16" (14mm) effective throw and • Request to Exit
3/8" (10mm) effective auxiliary latch
deadlocking. • Door Position (external)
Deadbolt Warranty
One-piece stainless steel, 19/32" (15mm) x 10-year limited mechanical.
1-1/4" (32mm) x 1" (25mm) throw. 2-year limited electrical.
Hub Shipping Weight
Steel, 5/16" (8mm). Approx. 11 lbs.
Mortise Lock Certification/Compliance
Strike
ML20100
Wrought brass, bronze or stainless steel ANSI
ANSI straight lip standard, 4-7/8" (124mm) Meets A156.13, Grade 1 requirements.
x 1-1/4" (32mm) x 1-1/8" (29mm) lip to Meets A117.1 Accessibility Code.
center. Meets A156.25 requirements.
Features Optional strikes, lip lengths and ANSI
wrought strike box available.
Handing
Cylinder UL /ULC-UL10C Positive Pressure
Handed; quick reversibility. The lockset can
1000-118-A01, 6-pin, L4, keyed random, All locks listed for A label and lesser class
be re-handed without disassembling the
furnished standard for 1-3/4" (44mm) doors, 4' (122cm) x 10' (305cm) single
lock body.
door. or 8' (244cm) x 10' (305cm) pair. Letter F
Door Thickness Optional cylinders available. and UL symbol on armored front indicate
1-3/4" (44mm) standard.
Keying Features Available listing.
Optional 2" (50mm) to 2-1/4" (57mm); see
Master keying Any retrofit or other field modification to
Quick Code section.
Construction master keying a fire rated opening can potentially impact
Backset Visual key control the fire rating of the opening, and Corbin
2-3/4" (70mm). Concealed key control Russwin, Inc. makes no representations or
Lockcase Interchangeable core (IC) warranties concerning what such impact
Heavy-gauge chrome plated steel, Security may be in any specific situation. When
5-7/8" (149mm) x 4" (102mm) x 15/16" Security IC retrofitting any portion of an existing fire
(24mm). Access 3 rated opening, or specifying and installing
Access 3 IC a new fire-rated opening, please consult
Front
Pyramid with a code specialist or local code official
Heavy-gauge steel, 8" (203mm) x 1-1/4"
Pyramid IC (Authority Having Jurisdiction) to ensure
(32mm) x 3/32" (2mm). Accommodates
non-beveled and beveled doors 1/8" Environmental Specifications compliance with all applicable codes and
(3mm) in 2" (51mm). Operating Temperature: ratings.
-13°F (-25°C) to 151°F (66°C)
Armored Front
Wrought brass, bronze or stainless steel Operating humidity:
attached by machine screws to lockcase Operates in condensing environments*
front. *always refer to the installation instructions for
correct procedure when installing in condensing
Latch environments
Patented, quick, reversible 2-piece
EcoFlex®
mechanical with anti-friction insert 5/8"
EcoFlex technology reduces power
(16mm) x 1" (25mm) x 3/4" (19mm). U.S.
consumption up to 96% as certified by
Patent #6,349,982.
GreenCircle
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
IN Series.6 45450 04/21Sold through:
How to Order
ML20100 IN Series Mortise Locks
Build your order string:
Required Options Other Options
Cylinder, Strike, Door
Function Trim Finish Handing Technology Code Reader Code Reader Modifier
Thickness
ML201_ _ ___ ___ ___ _____ ___ __ ____
For finish, additional cylinder, and/or mechanical options, please refer to page 9.
Series/Function Type Function Description Reader Code Credentials
HID Prox®, iCLASS®, iCLASS SE®,iCLASS® Seos®, SIO on
• Deadlocking latch
MIFARE® Classic, SIO on MIFARE DESFire® EV1 MIFARE
ML20133 • Latch retracted by inside lever at all times BIPS
Classic, MIFARE DESFire EV1, HID Mobile Access, Apple
No Key Override Entry • Outside lever rigid except when in
No Deadbolt
Wallet, Google Pay
"passage" mode or valid credential
presented BIKPS All credentials supported by the BIPS option plus keypad
• Deadlocking latch PIV/PIV-I (40-bit BCD, 64-bit BCD, 75 bit, 128-bit BCD or
IPV
• Latch retracted by inside lever at all times 200-bit outputs)
ML20134 • Outside lever rigid except when in IKPV All credentials supported by the IPV option plus keypad
With Key Override Entry "passage" mode or valid user code
No Deadbolt entered Options supporting FeliCa credentials. Contact Blackboard
BCP/ BCKP
• Key outside retracts latch for more details.
• No deadbolt function Options supporting LenelS2 BlueDiamond™ mobile
DIPS/DIKPS*
credentials.
Reader Modifier Description
B Black reader, black trim
W White reader, white trim
MB Black reader, metal trim
MW White reader, metal trim
Note: Metal trim is supplied in the finish specified in the order string.
Technology Code Description
IN120 WiFi
IN220 PoE
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
45450 04/21 IN Series.7Sold through:
How to Order
ML20100 IN Series Mortise Locks
Finishes
Description Specify Description Specify Description Specify
Polished Brass, Clear Coated 605 Polished Nickel 618 Satin Stainless Steel 629*
Satin Brass, Clear Coated 606 Satin Nickel 619 Bright Stainless Steel 630*
Polished Bronze, Clear Polished Chrome 625 Satin Stainless Steel with
611 630C*
Coated MicroShield®
Satin Chrome 626
Black Suede Powder Coat BSP
Satin Bronze, Clear Coated 612
Satin Chrome White Suede Powder Coat WSP
Dark Oxidized Satin Bronze, 613 626C
with MicroShield®
Oil Rubbed
*Metal escutcheon trim (MB and MW) plated to match
Black Oxidized Bronze,
Dark Oxidized Satin Bronze - 722
613E Oil Rubbed
Equivalent
Roses
The roses shown are some of our most popular styles. To see the complete list of available roses, refer to pages 32.
T X E2 E3 E41
Levers
The levers shown here are some of our most popular styles from the Muséo Collection. To see the complete range of levers, refer to pages 30-31.
102 103 110
1242 1252 1232
Premium Levers
21M 21S 133 134 136 138
1 Rose design suites with IN220 reader.
2 Lever returns within 1/2" (13 mm) of door face.
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
IN Series.8 45450 04/21Sold through:
Quick Codes
ML20100 IN Series Mortise Locks
Cylinders and Keying Cylinders and Keying (Cont.) Door Thickness
Description Specify Description Specify Door Thickness Specify
Conventional 6-pin (standard) Concealed Key Control 1-3/4" (44mm) (standard)
Conventional 7-pin 7P (CKC)
LC 1-7/8" (48mm) D178
Less Cylinder(s) - CKC Cylinders with CKC2
C6 VKC Keys 2" (51mm) D200
IC 6-pin
IC 6-pin with Temporary - CKC Cylinders Only CKC3 2-1/8" (54mm) D218
Construction Core (not for PHS, PCHS)
2-1/4" (57mm) D214
Red CT6R 2 Keys per Lock (standard)
Blue CT6B KY# Strikes
CT6G More than 2 Keys (e.g.,
Green ANSI ANSI Curved
KY6)
CI 6-pin Less Core CL6 Lip to Center Straight Lip Lip
SFIC 6-pin with Less Core CLS6 Specify Specify
CT6SD Finish
SFIC 6-pin with SFIC disposable 7/8" (22mm) SS078 N/A
temporary core Description Specify
1-1/8" (29mm) (standard) N/A
IC 7-pin C7 Polished Brass, Clear Coated 605
Satin Brass, Clear Coated 606 1-1/4" (32mm) SS114 SA114
IC 7-pin with Temporary
Construction Core Polished Bronze, Clear 611 1-3/8" (35mm) SS138 SA138
Red CT7R Coated 1-1/2" (38mm) SS112 SA112
Blue CT7B Satin Bronze, Clear Coated 612 1-3/4" (44mm) SS134 SA134
Green CT7G Dark Oxidized Satin Bronze, 613
Oil Rubbed 2" (51mm) SS200 SA200
IC 7-pin Less Core CL7
Dark Oxidized Satin Bronze - 613E 2-1/4" (57mm) SS214 SA214
SFIC 7-pin with Less Core CLS7
Equivalent 2-1/2" (64mm) SS212 SA212
SFIC 7-pin with SFIC disposable CT7SD
Polished Nickel 618
temporary core 2-3/4" (70mm) SS234 SA234
HS Satin Nickel 619
Security 3" (76mm) SS300 SA300
CHS Polished Chrome 625
Security IC Open Back Strike Door Thickness Specify
AP Satin Chrome 626
Access 3® Patented
Satin Chrome 626C 1-3/4" (44mm) SB134
Access 3® Security AS
with MicroShield® 2" (51mm) SB200
Access 3® High Security AHS
Satin Stainless Steel 629* 2-1/4" (57mm) SB214
Access 3® Patented IC ACP
Bright Stainless Steel 630*
Access 3® Security IC ACS Rabbeted front and strike - Specify SR118
Satin Stainless Steel with
Access 3® High Security IC ACHS 630C*
MicroShield®
Pyramid Fixed Core PHS Black Oxidized Bronze, 722 Thumbturns
Pyramid IC PCHS Oil Rubbed Description Specify
Pyramid IC Less Core CLP Black Suede Powder Coat BSP Decorative MT1
Pyramid with Temporary CTP
White Suede Powder Coat WSP Decorative Square MT2
Construction Core
Pyramid Security PS *Metal escutcheon trim (MB and MW) plated to match Decorative Cylinder MT2
Pyramid Security IC PCS
CTPD Handing
Pyramid Disposable Core Miscellaneous Options
CT6D Hand Specify
6-pin Disposable Core Description Specify
7-pin Disposable Core CT7D Right Hand RH
Torx® head screws M04
Keyed Random (Standard) KR Left Hand LH
CMK ANSI wrought strike box M17
Construction Master Eyed (not Right Hand Reverse RHR
available for Pyramid) Knurling outside and inside* M20
Left Hand Reverse LHR
Visual Key Control Knurling outside only* M21
- No Keying Data Stamped VKC0
Knurling inside only* M22
- on Key or Cylinder LH RH
VKC1 Abrasive coat outside and M23
- Keys Only inside* Left Hand Right Hand
- Cylinders and Keys VKC2
Abrasive coat inside only* M24 LHR RHR
-(not for HS, CHS, PHS
- or PCHS) Abrasive coat outside only* M25
Left Hand Reverse Right Hand Reverse
- Cylinders Only (not for - VKC3 *Not available with Vineyard or Museo levers.
HS, CHS, PHS or PCHS) Note: Arrow indicates secure side of door.
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
45450 04/21 IN Series.9Sold through:
Features
ML20200 IN Series Mortise Locks
The IN Series mortise lock has a clean, crisp design and is available with a variety of lever designs and
hardware finishes.
Auxiliary Latchbolt Monitoring
9/16" (14mm) effective throw and • Request to Exit
3/8" (10mm) effective auxiliary latch • Deadbolt
deadlocking. • Auxiliary latch
Deadbolt • Latch bolt
One-piece stainless steel, 19/32" (15mm) x • DPS cylinder monitoring (indirect)
1-1/4" (32mm) x 1" (25mm) throw. integrated into lock body
Hub Warranty
Steel, 5/16" (8mm). 10-year limited mechanical.
Mortise Lock 2-year limited electrical.
Strike
ML20200 Shipping Weight
Wrought brass, bronze or stainless steel
ANSI straight lip standard, 4-7/8" (124mm) Approx. 11 lbs.
x 1-1/4" (32mm) x 1-1/8" (29mm) lip to Certification/Compliance
center. ANSI
Features Optional strikes, lip lengths and ANSI
Meets A156.13, Operational Grade 1 and
wrought strike box available.
Handing Security Grade 1 requirements.
Cylinder
Handed; quick reversibility. The lockset can Meets A117.1 Accessibility Code.
1000-118-A01, 6-pin, L4, keyed random,
be re-handed without disassembling the Meets A156.25 requirements.
furnished standard for 1-3/4" (44mm)
lock body.
door.
Door Thickness Optional cylinders available. UL /ULC-UL10C Positive Pressure
1-3/4" (44mm) standard.
Keying Features Available All locks listed for A label and lesser class
Optional 2" (50mm) to 2-1/4" (57mm); see
Master keying doors, 4' (122cm) x 10' (305cm) single
Quick Code section.
Construction master keying or 8' (244cm) x 10' (305cm) pair. Letter F
Backset Visual key control and UL symbol on armored front indicate
2-3/4" (70mm). Concealed key control listing.
Lockcase Interchangeable core (IC)
Security Any retrofit or other field modification to
Heavy-gauge chrome plated steel,
Security IC a fire rated opening can potentially impact
5-7/8" (149mm) x 4" (102mm) x 15/16"
Access 3 the fire rating of the opening, and Corbin
(24mm).
Access 3 IC Russwin, Inc. makes no representations or
Front warranties concerning what such impact
Pyramid
Heavy-gauge steel, 8" (203mm) x 1-1/4" may be in any specific situation. When
Pyramid IC
(32mm) x 3/32" (2mm). Accommodates retrofitting any portion of an existing fire
non-beveled and beveled doors 1/8" Environmental Specifications rated opening, or specifying and installing
(3mm) in 2" (51mm). Operating Temperature: a new fire-rated opening, please consult
-13°F (-25°C) to 151°F (66°C) with a code specialist or local code official
Armored Front
Wrought brass, bronze or stainless steel Operating humidity: (Authority Having Jurisdiction) to ensure
attached by machine screws to lockcase Operates in condensing environments* compliance with all applicable codes and
front. *always refer to the installation instructions for ratings.
correct procedure when installing in condensing
Latch environments
Patented, quick, reversible 2-piece The IN120/IN220 ML20235/ML20236
EcoFlex®
mechanical with anti-friction insert 5/8" functions required for escape return
EcoFlex technology reduces power
(16mm) x 1" (25mm) x 3/4" (19mm). U.S. functionality (a residential requirement in
consumption up to 96% as certified by
Patent #6,349,982. Canada) on a mortise lock.
GreenCircle
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
IN Series.10 45450 04/21Sold through:
How to Order
ML20200 IN Series Mortise Locks
Build your order string:
Required Options Other Options
Cylinder, Strike, Door
Function Trim Finish Handing Technology Code Reader Code Reader Modifier
Thickness
ML202_ _ ___ ___ ___ _____ ___ __ ____
For finish, additional cylinder, and/or mechanical options, please refer to page 13.
Series/Function Type Function Description Reader Code Credentials
HID Prox®, iCLASS®, iCLASS SE®,iCLASS® Seos®,
• Deadlocking latch
SIO on MIFARE® Classic, SIO on MIFARE DESFire® EV1
ML20233 • Latch retracted by inside lever at all times BIPS
No Key Override Entry • Outside lever rigid except when in MIFARE Classic, MIFARE DESFire EV1, HID Mobile Access,
No Deadbolt "passage" mode or valid user code Apple Wallet, Google Pay
entered BIKPS All credentials supported by the BIPS option plus keypad
• Deadlocking latch PIV/PIV-I (40-bit BCD, 64-bit BCD, 75 bit, 128-bit BCD or
• Latch retracted by inside lever at all times IPV
200-bit outputs)
ML20234 • Outside lever rigid except when in
With Key Override Entry "passage" mode or valid user code IKPV All credentials supported by the IPV option plus keypad
No Deadbolt entered Options supporting FeliCa credentials. Contact
• Key outside retracts latch BCP/ BCKP
Blackboard for more details.
• No deadbolt function
Options supporting LenelS2 BlueDiamond™ mobile
• Deadlocking latch DIPS/DIKPS*
credentials.
• Latch and deadbolt retracted by inside
ML20235 lever at all times
No Key Override Entry
With Deadbolt1
• Outside lever rigid except when in
"passage" mode or valid user code
entered
• Deadlocking latch
• Latch and deadbolt retracted by inside
lever and deadbolt at all times
ML20236 • Outside lever rigid except when in
With Key Override Entry
With Deadbolt1
"passage" mode or valid user code
entered
• Key outside projects or retracts deadbolt
and retracts latch
1 Deadbolt required for escape return functionality (a residential requirement in Canada)
Reader Modifier Description
B Black reader, black trim
W White reader, white trim
MB Black reader, metal trim
MW White reader, metal trim
Note: Metal trim is supplied in the finish specified in the order string.
Technology Code Description
IN120 WiFi
IN220 PoE
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
45450 04/21 IN Series.11Sold through:
How to Order
ML20200 IN Series Mortise Locks
Finishes
Description Specify Description Specify Description Specify
Polished Brass, Clear Coated 605 Polished Nickel 618 Satin Stainless Steel 629*
Satin Brass, Clear Coated 606 Satin Nickel 619 Bright Stainless Steel 630*
Polished Bronze, Clear Polished Chrome 625 Satin Stainless Steel with
611 630C*
Coated MicroShield®
Satin Chrome 626
Black Suede Powder Coat BSP
Satin Bronze, Clear Coated 612
Satin Chrome White Suede Powder Coat WSP
Dark Oxidized Satin Bronze, 613 626C
with MicroShield®
Oil Rubbed
*Metal escutcheon trim (MB and MW) plated to match
Black Oxidized Bronze,
Dark Oxidized Satin Bronze - 722
613E Oil Rubbed
Equivalent
Roses
The roses shown are some of our most popular styles. To see the complete list of available roses, refer to pages 31.
T X E2 E3 E41
Levers
The levers shown here are some of our most popular styles from the Muséo Collection. To see the complete range of levers, refer to pages 29-30.
102 103 110
1242 1252 1232
Premium Levers
21M 21S 133 134 136 138
1 Rose design suites with IN220 reader.
2 Lever returns within 1/2" (13 mm) of door face.
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
IN Series.12 45450 04/21Sold through:
Quick Codes
ML20200 IN Series Mortise Locks
Cylinders and Keying Cylinders and Keying (Cont.) Door Thickness
Description Specify Description Specify Door Thickness Specify
Conventional 6-pin (standard) Concealed Key Control 1-3/4" (44mm) (standard)
Conventional 7-pin 7P (CKC)
LC 1-7/8" (48mm) D178
Less Cylinder(s) - CKC Cylinders with CKC2
C6 VKC Keys 2" (51mm) D200
IC 6-pin
IC 6-pin with Temporary - CKC Cylinders Only CKC3 2-1/8" (54mm) D218
Construction Core (not for PHS, PCHS)
2-1/4" (57mm) D214
Red CT6R 2 Keys per Lock (standard)
Blue CT6B KY# Strikes
CT6G More than 2 Keys (e.g.,
Green ANSI ANSI Curved
KY6)
CI 6-pin Less Core CL6 Lip to Center Straight Lip Lip
SFIC 6-pin with Less Core CLS6 Specify Specify
CT6SD Finish
SFIC 6-pin with SFIC disposable 7/8" (22mm) SS078 N/A
temporary core Description Specify
1-1/8" (29mm) (standard) N/A
IC 7-pin C7 Polished Brass, Clear Coated 605
Satin Brass, Clear Coated 606 1-1/4" (32mm) SS114 SA114
IC 7-pin with Temporary
Construction Core Polished Bronze, Clear 611 1-3/8" (35mm) SS138 SA138
Red CT7R Coated 1-1/2" (38mm) SS112 SA112
Blue CT7B Satin Bronze, Clear Coated 612 1-3/4" (44mm) SS134 SA134
Green CT7G Dark Oxidized Satin Bronze, 613
Oil Rubbed 2" (51mm) SS200 SA200
IC 7-pin Less Core CL7
Dark Oxidized Satin Bronze - 613E 2-1/4" (57mm) SS214 SA214
SFIC 7-pin with Less Core CLS7
Equivalent 2-1/2" (64mm) SS212 SA212
SFIC 7-pin with SFIC disposable CT7SD
Polished Nickel 618
temporary core 2-3/4" (70mm) SS234 SA234
HS Satin Nickel 619
Security 3" (76mm) SS300 SA300
CHS Polished Chrome 625
Security IC Open Back Strike Door Thickness Specify
AP Satin Chrome 626
Access 3® Patented
Satin Chrome 626C 1-3/4" (44mm) SB134
Access 3® Security AS
with MicroShield® 2" (51mm) SB200
Access 3® High Security AHS
Satin Stainless Steel 629* 2-1/4" (57mm) SB214
Access 3® Patented IC ACP
Bright Stainless Steel 630*
Access 3® Security IC ACS Rabbeted front and strike - Specify SR118
Satin Stainless Steel with
Access 3® High Security IC ACHS 630C*
MicroShield®
Pyramid Fixed Core PHS Black Oxidized Bronze, 722 Thumbturns
Pyramid IC PCHS Oil Rubbed Description Specify
Pyramid IC Less Core CLP Black Suede Powder Coat BSP
Decorative MT1
Pyramid with Temporary CTP White Suede Powder Coat WSP
Construction Core Decorative Square MT2
PS *Metal escutcheon trim (MB and MW) plated to match
Pyramid Security Decorative Cylinder MT2
Pyramid Security IC PCS
CTPD Handing
Pyramid Disposable Core Miscellaneous Options
CT6D Hand Specify
6-pin Disposable Core Description Specify
7-pin Disposable Core CT7D Right Hand RH
Torx® head screws M04
Keyed Random (Standard) KR Left Hand LH
ANSI wrought strike box M17
Construction Master Eyed (not CMK Right Hand Reverse RHR
available for Pyramid) Knurling outside and inside* M20
Left Hand Reverse LHR
Visual Key Control Knurling outside only* M21
- No Keying Data Stamped VKC0 Knurling inside only* M22
- on Key or Cylinder LH RH
Abrasive coat outside and M23
- Keys Only VKC1
inside* Left Hand Right Hand
- Cylinders and Keys VKC2
Abrasive coat inside only* M24 LHR RHR
-(not for HS, CHS, PHS
- or PCHS) Abrasive coat outside only* M25
Left Hand Reverse Right Hand Reverse
- Cylinders Only (not for - VKC3 *Not available with Vineyard or Museo levers.
HS, CHS, PHS or PCHS) Note: Arrow indicates secure side of door.
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
45450 04/21 IN Series.13Sold through:
Features
CL33100 IN Series Cylindrical Lock
The IN Series CL33100 design provides uniformity when used with other Corbin Russwin CL3300 locks at a
facility. The product features four different lever designs, thirteen hardware finishes and cylinder override.
Strike Warranty
Wrought brass or stainless steel ANSI 7-year limited mechanical;
curved lip standard, 4-7/8" (124mm) x 2-year limited electrical.
1-1/4" (32mm) x 1-1/4" (32mm) lip to
Shipping Weight
center.
Approx. 11 lbs.
Optional strikes, lip lengths and ANSI
wrought strike box available
Certification/Compliance
Cylinder
Cylindrical Lock Brass, 6-pin, L4 keyway, 0-bitted standard. ANSI/BHMA
CL33100
Keying Features Available Meets A156.2 Grade 1 requirements.
Master keying Federal
Features Construction master keying Meets FF-H-106C.
Visual key control
California State Reference Code
Non-handed Concealed key control
(Formerly Title 19, California State Fire
Interchangeable core (IC)
Door Thickness Marshal Standard) All levers with returns
Security
1-3/4" (44mm) to 2" (50mm) standard, comply; levers return to within 1/2"
Security IC
2" (50mm) to 2-1/4" (57mm) optional (13mm) of door face.
Access 3
Lock Chassis Access 3 IC C-UL US
Steel, zinc dichromated for corrosion Pyramid All locks with 1/2" (13mm) throw
latchbolt listed for A label and lesser class
resistance. Pyramid IC
4' x 10' single doors. All locks with 3/4"
Backset Environmental Specifications (19mm) throw latchbolt listed for A label
• Operating temperature: and lesser class 8' x 10' pairs of doors.
2-3/4" (70mm) standard.
Letter F and UL symbol on latch front
Optional: 3-3/4" (95mm) and 5" (127mm). -13°F (-25°C) to 151°F (66°C)
indicate listing.
• Operating humidity: Operates in
Latchbolt
condensing environments* Any retrofit or other field modification to
Stainless steel, 1/2" (13mm) throw. *always refer to the installation instructions for a fire rated opening can potentially impact
Optional: 3/4" (19mm) throw deadlocking correct procedure when installing in condensing
the fire rating of the opening, and Corbin
environments
fire latch for pair of doors. Russwin, Inc. makes no representations or
Keys warranties concerning what such impact
Auxiliary Latchbolt
Two nickel silver standard. may be in any specific situation. When
Deadlocking latchbolt prevents retrofitting any portion of an existing fire
manipulation when door is closed. Key Override rated opening, or specifying and installing
Standard. Not available with non-key a new fire-rated opening, please consult
Front with a code specialist or local code official
override.
Wrought brass or stainless steel, (Authority Having Jurisdiction) to ensure
2-1/4" (57mm) x 1-1/8" (29mm). Monitoring compliance with all applicable codes and
Accommodates non-beveled and beveled • Request to Exit (Non-Handed) ratings.
• Door Position Switch (Supplied and
doors 1/8" (3mm) in 2" (51mm).
mounted above the lock. Connects
Optional: rounded corners. directly into the lock's electronics.)
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
IN Series.14 45450 04/21Sold through:
How to Order
CL33100 IN Series Cylindrical Lock
Build your order string:
Required Options Other Options
Cylinder, Strike, Door
Function Trim Finish Handing Technology Code Reader Code Reader Modifier
Thickness
CL33134 ___ ___ ___ _____ __ __ —
For finish, additional cylinder, and/or mechanical options, please refer to page 16.
Series/Function Type Function Description Reader Code Credentials
• Latch retracted by inside lever at all HID Prox®, iCLASS®, iCLASS SE®,iCLASS® Seos®,
times. SIO on MIFARE® Classic, SIO on MIFARE DESFire® EV1
CL33134 BIPS
• Key outside retracts latch. MIFARE Classic, MIFARE DESFire EV1, HID Mobile Access,
With Key Entry
• Outside lever locked (freewheeling) Apple Wallet, Google Pay
Override
except when in “passage” mode or
BIKPS All credentials supported by the BIPS option plus keypad
valid user code entered.
PIV/PIV-I (40-bit BCD, 64-bit BCD, 75 bit, 128-bit BCD or
IPV
200-bit outputs)
Reader Modifier Description IKPV All credentials supported by the IPV option plus keypad
B Black reader, black trim Options supporting FeliCa credentials. Contact Blackboard
BCP/ BCKP
for more details.
W White reader, white trim
Options supporting LenelS2 BlueDiamond™ mobile
MB Black reader, metal trim DIPS/DIKPS*
credentials.
MW White reader, metal trim
Note: Metal trim is supplied in the finish specified in the order string.
Technology Code Description
IN120 WiFi
IN220 PoE
Available Trim Options
Standard
Lever D Rose
Armstrong AZD
Newport NZD
Princeton PZD
Armstrong Newport* Princeton*
Vineyard™
D Rose
Frascati FZD
Frascati
*Complies with codes requiring lever to return to within 1/2” (13mm) of door face.
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
45450 04/21 IN Series.15Sold through:
Quick Codes
CL33100 IN Series Cylindrical Lock
Cylinders and Keying Finish Miscellaneous Options
Description Specify Description Specify Description Specify
Conventional 6-pin (standard) Polished Brass, Clear Coated 605 Torx® head screws M04
Conventional 7-pin 7P Satin Brass, Clear Coated 606 Less cylinder, with tailpiece for M06
Less Cylinder(s) LC Polished Bronze, Clear Coated 611 Schlage® cylinder
Security HS Satin Bronze, Clear Coated 612 Lever to accept 6 or 7-pin SFIC M08
Security IC CHS Dark Oxidized Satin Bronze, 613 (all designs)
Access 3® Patented Fixed Core AP Oil Rubbed Lever to accept Sargent® cylinder M09
Access 3® Security Fixed Core AS Dark Oxidized Satin Bronze - 613E (NZD & PZD design only)
Access 3® High Security Fixed Core AHS Equivalent Rounded corners on latch front M13
Access 3® Patented IC ACP Polished Nickel 618 3/4" (19mm) throw fire latch M16
Access 3® Security IC ACS Satin Nickel 619 ANSI wrought strike box M17
Access 3® High Security IC ACHS Polished Chrome 625 Knurling outside and inside M20
Pyramid Security PS Satin Chrome 626 Knurling outside only M21
Pyramid Security IC PCS Black Oxidized Bronze, 722 Knurling inside only M22
Pyramid High Security Fixed Core PHS Oil Rubbed Abrasive coat outside and inside M23
Pyramid High Security IC PCHS Satin Chrome 626C Abrasive coat inside only M24
Pyramid with Temporary with MicroShield® Abrasive coat outside only M25
CTP
Construction Core Black Suede Powder Coat BSP Lever to accept Schlage® M69
Pyramid Less Core CLP White Suede Powder Coat WSP interchangeable core (NZD & PZD
IC 6-pin C6 design only)
IC 6-pin with Temporary Construction Core
Red CT6R
Strikes
Blue CT6B
Green CT6G ANSI
Curved Lip Curved Lip
IC 6-pin Less Core CL6 Lip to Center Specify Box Specify
IC 7-pin C7 1" (25mm) SA100 SC100
IC 7-pin with Temporary Construction Core 1-1/8" (29mm) SA118 SC118
Red CT7R
1-1/4" (32mm) (standard) SC114
Blue CT7B
1-3/8" (35mm) SA138 SC138
Green CT7G
1-1/2" (38mm) SA112 SC112
IC 7-pin Less Core CL7
1-3/4" (44mm) SA134 SC134
Pyramid Disposable Core CTPD
2" (51mm) SA200 SC200
6-pin Disposable Core CT6D
2-1/4" (57mm) SA214 SC214
7-pin Disposable Core CT7D
2-1/2" (64mm) SA212 SC212
SFIC 6- or 7-pin Small Format
CTSD 2-3/4" (70mm) SA234 SC234
Disposable Core
0-Bitted with 2 Blank Keys (standard) 3" (76mm) SA300 SC300
Keyed Random KR Rabbeted front and strike Specify SR118
Construction Master Keyed CMK
Visual Key Control (VKC)
Door Thickness
- No Bitting or Keyset
VKC0 Description Specify
Stamping on Keys
- Keys Only VKC1 1-3/4" (44mm) - 2" (51mm) (standard)
- Cylinders and Keys (not for 2" (51mm) - 2-1/4" (57mm) D214
VKC2
HS, CHS, PHS or PCHS)
- Cylinders Only (not for HS,
VKC3
CHS, PHS or PCHS) Backset
Concealed Key Control (CKC) Description Specify
- CKC Cylinders with VKC Keys CKC2 2-3/4" (70mm) (standard)
- CKC Cylinders Only (not for
CKC3 3-3/4" (95mm) B334
PHS, PCHS)
2 Keys per Lock (standard) 5" (127mm) B500
KY#
More than 2 Keys
(e.g., KY6)
Schlage® C Keyway cylinder1 C
Schlage® LA Keyway cylinder2 LA
1 Available 0-bitted & keyed random (KR) only
2 Available 0-bitted only
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
IN Series.16 45450 04/21Sold through:
Features
ED5000N IN Series Exit Devices
Shim Kit
Optional for mounting device over raised
vision light molding; specify M58.
Warranty
Five-year limited mechanical
2-year limited electrical
Certification/Compliance
ANSI
Meets A156.3, Type 2, Grade 1.
UL /cUL
All devices listed for safety as panic
hardware; devices comply with UL 305
ED5000 Exit Device standards for panic hardware. Three-
With 9100 Series Trim hour fire-rated devices listed as fire exit
hardware for A label and lesser class
8’ x 8’ double doors; UL symbol on active
Features Materials case cover indicates listing.
Handing Heavy-duty cold-forged steel chassis;
Device is handed but easily field reversible. heavy-gauge steel mechanisms, Any retrofit or other field modification to a
Lever trim is handed. electroplated for corrosion resistance; fire- rated opening can potentially impact
Bar Length finished parts are brass, bronze or stainless the fire rating of the opening, and Corbin
Easily field cut to size. steel; stainless steel springs; nylon bearings. Russwin, Inc. makes no representations or
Standard: 36" (914mm) bar fits 30"- 36" Projection warranties concerning what such impact
(762mm-914mm) door. 3-1/4" (83mm) active, 2-3/4" (70mm) may be in any specific situation. When
Optional: 24" (610mm) bar fits 24" dogged. retrofitting any portion of an existing fire
(610mm) door; specify W024. rated opening, or specifying and installing
Dogging a new fire-rated opening, please consult
Optional: 48" (1219mm) bar fits 36"-48"
Standard on panic devices; single-point 1/4 with a code specialist or local code official
(914mm-1219mm) door; specify W048.
turn hex key dogging. Optional: less (Authority Having Jurisdiction) to ensure
Door Thickness dogging, specify M51. Optional: cylinder compliance with all applicable codes and
1-3/4" (44mm) standard. dogging, specify M52. Mechanical dogging ratings.
Optional: 2" (51mm); specify D200. not available on fire-rated devices.
Optional: 2-1/4" (57mm); specify D214. California State Reference Code
Fasteners This product has been approved by the
Stile Standard on panic devices: machine screws California State Fire Marshal pursuant to
Minimum width 4-1/2" (114mm). and wood door fasteners. section 13144.1 of the California Health
Latchbolt Standard on fire-rated devices: sex nuts and Safety Code.
Top: 3/4" (19mm) throw, stainless steel and bolts.
Optional on panic devices: sex nuts and NFPA
pullman-type with automatic deadlatching.
bolts for use on wood, composite, or All exit devices comply with NFPA 101 Life
Bottom: 5/8" (16mm) throw deadbolt, held
unreinforced metal doors; specify M54. Safety Code. All fire-rated devices comply
retracted during door swin
Optional wood screws for use on approved with NFPA 80 Fire Doors and Windows.
EcoFlex® ADA Lever trims and pulls comply with
fire-rated solid wood or wood core doors.
EcoFlex technology reduces power Americans with Disabilities Act.
Specify M64.
consumption up to 95% as certified by
GreenCircle Strike
Optional strikes available; see Options and
Monitoring
Accessories, page 20.
Request to Exit (Non-Handed)
Door Position Switch (Supplied and Cylinders
mounted above the lock. Connects directly Cylinder not included unless specified. See
into the lock's electronics.) Quick Codes, page 20.
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
45450 04/21 IN Series.17Sold through:
How to Order
ED5000N IN Series Exit Devices
Build your order string:
Required Options Other Options
Lever/ Cylinder, Strike, Door
Series Finish Handing Technology Code Reader Code Reader Modifier
Function Thickness, Door Width
ED5_ _ _ _ _ _ _____ ___ ___ _____ ___ __ ____
For finish, additional cylinder, and/or mechanical options, please refer to page 20.
Series/Function Type Function Description Reader Code Credentials
• Latch retracted by inside HID Prox®, iCLASS®, iCLASS SE®,iCLASS® Seos®,
push pad at all times SIO on MIFARE® Classic, SIO on MIFARE DESFire® EV1
BIPS
ED5200(A)N & MIFARE Classic, MIFARE DESFire EV1, HID Mobile Access,
Rim Exit Device • Outside lever locked
ED5200S(A)N Apple Wallet, Google Pay
No Key Override (freewheeling) except
x 9133
when in passage mode or BIKPS All credentials supported by the BIPS option plus keypad
valid user code entered PIV/PIV-I (40-bit BCD, 64-bit BCD, 75 bit, 128-bit BCD or
IPV
• Latch retracted by inside 200-bit outputs)
push pad at all times IKPV All credentials supported by the IPV option plus keypad
• Outside lever locked
ED5200(A)N & Rim Exit Device (freewheeling) except Options supporting FeliCa credentials. Contact
BCP/ BCKP
ED5200S(A)N With Key when in passage mode or Blackboard for more details.
x 9134 Override valid user code entered Options supporting LenelS2 BlueDiamond™ mobile
DIPS/DIKPS*
• Outside cylinder override credentials.
allows lever to retract
latch
• Latch retracted by inside
Mortise Exit push pad at all times
ED5633(A)LN
Device • Outside lever rigid except
x 9M133
No Key Override when in passage mode or
valid user code entered
• Latch retracted by inside
push pad at all times
Mortise Exit
• Outside lever rigid except
ED5634(A)LN Device
when in passage mode or
x 9M134 With Key
valid user code entered
Override
• Outside cylinder override
retracts latch
Reader Modifier Description
B Black reader, black trim
W White reader, white trim
MB Black reader, metal trim
MW White reader, metal trim
Note: Metal trim is supplied in the finish specified in the order string.
Technology Code Description
IN120 WiFi
IN220 PoE
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
IN Series.18 45450 04/21Sold through:
How to Order
ED5000N IN Series Exit Devices
Finishes
Description Specify Description Specify Description Specify
Polished Brass, Clear Coated 605 Polished Nickel 618 Satin Stainless Steel 629*
Satin Brass, Clear Coated 606 Satin Nickel 619 Bright Stainless Steel 630*
Polished Bronze, Clear Polished Chrome 625 Satin Stainless Steel with
611 630C*
Coated MicroShield®
626**
Satin Chrome Black Suede Powder BSP
Satin Bronze, Clear Coated 612 (Trim only)
Black Oxidized Bronze, White Suede Powder WSP
Dark Oxidized Satin Bronze, 613 722
Oil Rubbed
Oil Rubbed
Dark Oxidized Satin Bronze -
613E
Equivalent *Metal escutcheon trim (MB and MW) plated to match
**Contact factory for devices needed in 626 finish
Levers
The levers shown here are some of our most popular styles from the Muséo Collection. To see the complete range of levers, refer to pages 29-31.
102 103 110
1241 1251 1231
Premium Levers
21M 21S 133 134 136 138
1. Lever returns within 1/2" (13 mm) of door face.
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
45450 04/21 IN Series.19Sold through:
Quick Codes
ED5000N IN Series Exit Devices
Cylinders and Keying Cylinders and Keying (Cont.) Door Thickness
Description Specify Description Specify Door Thickness Specify
Conventional 6-pin (standard) Concealed Key Control 1-3/4" (44mm) (standard)
Conventional 7-pin 7P (CKC)
LC 2" (51mm) D200
Less Cylinder(s) - CKC Cylinders with CKC2
IC 6-pin C6 VKC Keys 2-1/4" (57mm) D214
IC 6-pin with Temporary - CKC Cylinders Only CKC3
Construction Core (not for PHS, PCHS)
Door Width
Red CT6R 2 Keys per Cylinder (standard)
KY# Door Width Specify
Blue CT6B
CT6G More than 2 Keys (e.g., 24" (610mm) W024
Green
KY6) 36" (914mm) (standard)
CI 6-pin Less Core CL6
SFIC 6-pin with Less Core CLS6 Finish 48" (1219mm) W048
SFIC 6-pin with SFIC disposable CT6SD Description Specify
temporary core Polished Brass, Clear Coated 605
IC 7-pin C7 Handing
Satin Brass, Clear Coated 606
IC 7-pin with Temporary Polished Bronze, Clear 611 Hand Specify
Construction Core Coated
CT7R Right Hand Reverse RHR
Red Satin Bronze, Clear Coated 612
CT7B Left Hand Reverse LHR
Blue Dark Oxidized Satin Bronze, 613
Green CT7G Oil Rubbed
IC 7-pin Less Core CL7 Dark Oxidized Satin Bronze - 613E LHR RHR
SFIC 7-pin with Less Core CLS7 Equivalent
Left Hand Reverse Right Hand Reverse
SFIC 7-pin with SFIC disposable CT7SD Polished Nickel 618
temporary core Satin Nickel 619 Note: Arrow indicates secure side of door.
Security HS Polished Chrome 625
Security IC CHS Satin Stainless Steel 629*
AP Bright Stainless Steel 630* Miscellaneous Options
Access 3® Patented
Access 3® Security AS Satin Stainless Steel with Description Specify
630C*
Access 3® High Security AHS MicroShield® Torx® head screws M04
Access 3® Patented IC ACP Black Oxidized Bronze, 722 Windstorm M107
ACS Oil Rubbed
Access 3® Security IC ANSI wrought strike box M17
ACHS Black Suede Powder Coat BSP
Access 3® High Security IC Knurling outside and inside* M20
Pyramid Fixed Core PHS White Suede Powder Coat WSP
PCHS Knurling outside only* M21
Pyramid IC *Metal escutcheon trim (MB and MW) plated to match
CLP Knurling inside only* M22
Pyramid IC Less Core
Pyramid with Temporary CTP Abrasive coat outside and inside* M23
Construction Core Strikes Abrasive coat inside only* M24
Pyramid Security PS Description Specify Abrasive coat outside only* M25
Pyramid Security IC PCS
Rim strike S02 S02 Less dogging M51
Pyramid Disposable Core CTPD
Mortise ANSI strike for pairs SS078 Cylinder dogging M52
6-pin Disposable Core CT6D
of doors with astragal
7-pin Disposable Core CT7D Sex nuts and bolts (SNBs) M54
Open back strike for 1-3/4" SB134
Keyed Random (Standard) KR doors Shim kit (for vision light) M58
Construction Master Eyed (not CMK
Open back strike for 2-1/4" SB214 Wood screws for use on fire-rated M64
available for Pyramid) doors solid wood or wood core doors
Visual Key Control *Not available with Vineyard or Museo levers.
- No Keying Data Stamped VKC0
- on Key or Cylinder
- Keys Only VKC1
- Cylinders and Keys VKC2
-(not for HS, CHS, PHS
- or PCHS)
- Cylinders Only (not for - VKC3
HS, CHS, PHS or PCHS)
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
IN Series.20 45450 04/21Sold through:
Features
BL6600/FE6600/MP6600 Series Series Multi-Point Locks
Top Bolt Warranty
Adjustable stainless steel 3/4" square bolt 7-year limited mechanical.
with 11/16" engagement; 5/16" steel 2-year limited electrical.
reinforcement plate Shipping Weight
Installation Approx. 11 lbs.
Concealed vertical assembly (rods, latches
and cassette) pre-installed in door
Certification/Compliance
Bottom Bolt
Adjustable stainless steel 3/4" square ANSI
bolt with 5/8" engagement; 1/4" steel Meets A156.37, Operational Grade 1 and
reinforcement plate Security Grade 1 requirements.
Center Bolts Meets A117.1 Accessibility Code.
Latchbolt is stainless steel with 3/4" Meets A156.25 requirements.
projection. One piece, anti-friction UL /ULC-UL10C Positive Pressure
reversible catch. Deadbolt is one piece All locks listed for A label and lesser class
hardened stainless steel with 1" projection doors, 4' (122cm) x 8' (305cm) single or 8'
Lock Front (244cm) x 8' (305cm) pair. Letter F and UL
1/8" steel mortise front reinforced with symbol on armored front indicate listing.
13/64" thick lock edge stiffener Windstorm Certification
Features Center Bolt Strike Windstorm certification information is
Handing 1/4" thick stainless steel listed in the Corbin Russwin 6600 Series
Handed; quick reversibility. The lockset can
Backset catalog.
be re-handed without disassembling the
2-3/4" standard Any retrofit or other field modification to
lock body.
Door Thickness a fire rated opening can potentially impact
Door Thickness
1-3/4" standard the fire rating of the opening, and Corbin
1-3/4" thick door only; fully integrated –
Door Height Russwin, Inc. makes no representations or
6600 is part of a complete ASSA ABLOY
7'0" - 8'0" warranties concerning what such impact
windstorm solution
may be in any specific situation. When
Backset Maximum Opening retrofitting any portion of an existing fire
2-3/4" (70mm). Single door 4'0" x 8'0" and double doors rated opening, or specifying and installing
8'0" x 8'0" a new fire-rated opening, please consult
Lockcase
Heavy-gauge chrome plated steel, Strike with a code specialist or local code official
5-7/8" (149mm) x 4" (102mm) x 15/16" Wrought brass, bronze or stainless steel (Authority Having Jurisdiction) to ensure
(24mm). ANSI straight lip standard, 4-7/8" (124mm) compliance with all applicable codes and
x 1-1/4" (32mm) x 1-1/8" (29mm) lip to ratings.
Front
center.
Heavy-gauge steel, 8" (203mm) x 1-1/4"
(32mm) x 3/32" (2mm). Accommodates Environmental Specifications
non-beveled and beveled doors 1/8" Operating Temperature:
(3mm) in 2" (51mm). -13°F (-25°C) to 151°F (66°C)
Armored Front Operating humidity:
Wrought brass, bronze or stainless steel Operates in condensing environments
attached by machine screws to lockcase *always refer to the installation instructions for
front. correct procedure when installing in condensing
environments
Device Type
Available with both BL (Blast) and FE Monitoring
(FEMA) prefixes • Deadbolt
• Latch bolt
• DPS integrated into lock body
• Request to exit
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
45450 04/21 IN Series.21Sold through:
How to Order
BL6600/FE6600/MP6600 Series Multi-Point Locks
Build your order string:
Required Options
Technology Other Options
Function Trim Finish Handing Reader Code Reader Modifier
Code
66135 ___ ___ ___ IN___ ____ __ ____
For finish, additional cylinder, and/or mechanical options, please refer to page 13.
Series/Function Type Function Description Reader Code Credentials
HID Prox®, iCLASS®, iCLASS SE®,iCLASS® Seos®,
• Deadlocking latch
SIO on MIFARE® Classic, SIO on MIFARE DESFire® EV1
• Latch and deadbolt retracted by BIPS
BL/FE/MP66135 MIFARE Classic, MIFARE DESFire EV1, HID Mobile Access,
inside lever at all times Apple Wallet, Google Pay
No Key Override Entry
With Deadbolt1 • Outside lever rigid except when in
"passage" mode or valid user code BIKPS All credentials supported by the BIPS option plus keypad
entered PIV/PIV-I (40-bit BCD, 64-bit BCD, 75 bit, 128-bit BCD or
IPV
• Key outside retracts deadbolt. 200-bit outputs)
Key outside also retracts latch and IKPV All credentials supported by the IPV option plus keypad
unlocks outside when trim is locked
BL/FE/MP66136 Entry Options supporting FeliCa credentials. Contact
electronically BCP/ BCKP
Key Override With Blackboard for more details.
• Top and bottom rods retracted by
With Deadbolt Deadbolt
lever Options supporting LenelS2 BlueDiamond™ mobile
DIPS/DIKPS*
• Deadbolt projected and retracted by credentials.
thumbturn or key
Reader Modifier Description
B Black reader, black trim
W White reader, white trim
MB Black reader, metal trim
MW White reader, metal trim
Note: Metal trim is supplied in the finish specified in the order string.
Technology Code Description
IN120 WiFi
IN220 PoE
Finishes
Description Specify Description Specify Description Specify
Polished Brass, Clear Coated 605 Polished Nickel 618 Satin Stainless Steel 629*
Satin Brass, Clear Coated 606 Satin Nickel 619 Bright Stainless Steel 630*
Polished Chrome 625 Satin Stainless Steel with
Polished Bronze, Clear 630C*
611 MicroShield®
Coated
Satin Chrome 626 Black Suede Powder Coat BSP
Satin Bronze, Clear Coated 612
Satin Chrome White Suede Powder Coat WSP
626C
Dark Oxidized Satin Bronze, 613 with MicroShield®
Oil Rubbed
*Metal escutcheon trim (MB and MW) plated to match
Black Oxidized Bronze,
Dark Oxidized Satin Bronze - 722
613E Oil Rubbed
Equivalent
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or in part without the express
written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
IN Series.22 45450 04/21You can also read
