IN THIS EDITION
14 Special fuels & engines
Internal combustion engines play a
SWZ|Maritime in English
very dominant role in shipping. Is
that going to change under pres-
sure of environmental regulations?
In this special we look at engine de- Since the end of last year, we publish as much of our ma-
velopments and possible new fuels. gazine in English as possible. So far, we have received
one critical comment on this policy. Although it was just
one, you must take this serious as one reaction stands for
all those who do not react, but share the same thoughts.
33 Navigare necesse est That is why I will repeat my response here.
his is the third in a series of his-
T I’m sincerely sorry when our readers and especially members
toric articles with a focus on con- of our founding fathers the KNVTS and Stichting De Zee are
necting a vision on the future with a disappointed with the English content of our latest editions. But
view on the historic past of ship- we believe this is necessary for our magazine to survive. We
building practice. In this article: the changed to English for two reasons. First, to reach more poten-
Corinthians. tial readers. Both in our shipbuilding industry and the supplying
companies, but not least also on Dutch ships, where ever more
non-Dutch speaking people work, and English is the working
language. We would also like to reach them. We assume that
38 Improved efficiency for new
combat support ship
we still make an interesting magazine that unfortunately is read
by ever fewer subscribers. It is a lamentable fact that the num-
ber of members of maritime organisations is declining.
The second reason is a commercial one. For more than a deca-
On the 19th of February, the con- de, SWZ|Maritime has been struggling with a lack of advertise-
tract was signed for the new Com- ments. Extra money has to be spent on the magazine’s publicati-
bat Support Ship HNLMS Den on every year and if this continues, in a few years’ time the
Helder. The design will be based on bottom of our savings will be in sight. Our successive publishing
the HNLMS Karel Doorman, the so partners and now ProMedia indicate that advertisers prefer an
called Joint Support Ship. English magazine in order to communicate with their potential
customers. Popular digital newsletters such as the Shipping-
SWZ MARITIME • MARCH 2020
NewsClippings by Piet Sinke (who doesn't know him?) are enti-
rely in English, as is our own digital newsletter and website
Contents (www.swzmaritime.nl). Since we launched the new website last
summer, we have fortunately seen a strongly growing number
4 Dutch news of readers from a poor 1500 up to over 14,000 a month.
6 Markets Shipbuilders, suppliers, seafarers and ship owners have always
8 Maritime monthly spoken English to be able to do their job and do business. And
14 Tribute to the diesel engine we write in English to tell not only our friends and family, but
18 IMO GHG reductions 2030/2050 in perspective everyone who might be interested what our marine engineers
21 Global news have to offer. In this March issue, that’s again a lot about fuels
22 Using alternative fuels in combustion engines and engines, with a series of articles from different contribu-
tors. With special thanks to Johan de Jong, Manager Internati-
26 Future proof with ABC engines
onal Relations at MARIN, who coordinated this special.
30 Following in automotive’s footsteps
34 Ammonia as a marine fuel
36 AmmoniaDrive: a solution for zero-emission
shipping?! Antoon Oosting
40 Mars Report Editor-in-Chief
42 Book reviews swz.rotterdam@knvts.nl
43 Verenigingsnieuws KNVTS
Cover: MV Ankie was recently equipped with wind-assisted propulsion in the form
of an Econowind unit to cut fuel consumption and emissions. 3
