GGB DX 10
®
MAINTENANCE-FREE, METAL-POLYMER TRIBOLOGICAL
SOLUTIONS FOR HIGH-DEMAND ENVIRONMENTS
INTRODUCTION
DX 10
®
DX®10 is a value-engineered, steel-backed solution with
a tough, abrasion-resistant polymer surface, designed for
heavy-duty applications and harsh environments where high
loads, shock, heat and abrasive contamination are present.
DX®10 leads the way to lower maintenance and lower
operational costs. In existing designs, DX®10 can replace
troublesome bronze, bimetallic and roller bearings for
a longer service life.
DX®10 IS NOW AVAILABLE IN
PLAIN BORE, UNINDENTED FORM.
DX®10 is now available in plain bore, unindented form, which performs well in highly loaded,
oil-lubricated applications that require:
High-temperature capability High fatigue strength Erosion resistance
Good wear resistance Excellent chemical resistance Lead Free
CHARACTERISTICS
— High load capacity — Very good performance with — Available in bushings, washers
— High pU capability grease and oil lubrication and special shaped parts
— Excellent abrasion resistance — Available with pin-indented — Machinability: DX®10 is a
surfaces for better lubricant machinable product (consult
— Good temperature resistance
retention, or unindented for our Applications Engineering
oil-lubricated applications Department for guidelines)
1 GGBEARINGS.COM
RECOMMENDED MARKET APPLICATIONS*
GGB DX®10 is intended for greased or oil-lubricated, heavy-duty
applications with high load, elevated temperature and potential
for abrasive contamination:
— Kingpins for trucks and — Automotive oil pumps
off-highway equipment — Small reciprocating
— Truck and automotive bushings
suspensions
— Mechanical handling
— Construction equipment and lifting equipment
— Lift equipment — Recreational equipment
— Cranes — Industrial machinery
*Inquire with GGB Applications Engineering
Team for other possible applications.
BEARING PROPERTIES
BEARING PROPERTIES IMPERIAL VALUE METRIC VALUE MICROSECTION
GENERAL
36,000 psi 250 N/mm2 Sliding Layer
Maximum Load, p - Static
(high-tech polymer
Maximum Load, p - Dynamic 20,000 psi 140 N/mm2 with lubricant indents)
Operating Temperature - Min -40°F -40°C
Porous Bronze
Operating Temperature - Max 350°F 175°C Sinter
G RE AS E LU B RICATE D
Maximum Sliding Speed, U 500 fpm 2.5 m/s
Steel Backing
Maximum pU Factor 80,000 psi x fpm 2.8 N/mm2 x m/s
Coefficient of Friction f 0.01 - 0.10 0.01 - 0.10
OI L LU B RICATE D
Maximum Sliding Speed, U 2,000 fpm 10.0 m/s
Maximum pU Factor 80,000 psi x fpm 2.8 N/mm2 x m/s
Coefficient of Friction f 0.01 - 0.06 0.01 - 0.06
RE CO M M E N DATIO NS
Shaft Surface Roughness, Ra ≤ 16 µin ≤ 0.4 µm
Shaft Surface Hardness - Normal HB > 200
Shaft Surface Hardness, For longer service life HB > 350
THE TRIBOLOGICAL SOLUTION FOR INDUSTRIAL
PROGRESS, REGARDLESS OF SHAPE OR MATERIAL 2
G G B D X ®1 0
Bearing Performance
WEAR RESISTANCE – EXTREME LOADS
DX®10 produces maximum wear resistance under a greased oscillation from low loads to the extreme load of 150 MPa.
DuraStrong™ technology works by developing a solid lubricant between the polymer liner system and the metallic interface,
which prevents excess wear of the liner and significantly decreases the frictional response. The self-lubricating system is
proven to be effective at maintaining an operational wear resistance at loads as high as 200 MPa.
O P E R AT I O N A L W E A R T E S T
Operational Wear Resistance
10 0 %
Oscillation ±30° at 15cpm
20.3%
3 5 .7 %
10 0 %
75 %
Temperature 22°C [72°F]
50%
Shaft Diameter 25.4mm [0.9998 inch]
Shaft Hardness 55 HRC 25%
DX 10
DX 10
DX 10
Zinc based grease greased
Grease Mixture
once upon installation 0.0
150 MPa 175 MPa 200 MPa
Test Duration 50 hours [21.8 ksi] [25.4 ksi] [29.0 ksi]
Operating Load
ABRASION RESISTANCE
To confirm DX®10’s superb abrasion wear resistance, DX®10 was compared against DX® and HI-EX®. Each thrust
washer was pin-indented. The grease was contaminated with 50% by weight Arizona road dust. Testing indicated
that DX®10 abrasive wear resistance was better than GGB standard product DX® and on par with GGB premium
product HI-EX®.
THRUST WASHER TEST 0.05
Applied Load 13.8 MPa [2000 psi]
0.023
0.052
0 . 0 21
0.04
WEAR [mm]
Speed 0.15 m/s [30 fpm] 0.03
Temperature 105°C [221° F] 0.02
50% Lithium grease + 50% Arizona
Grease Mixture
road dust; % by weight 0.01
DX 10
HI-EX
DX
Test Duration 12 hours 0.0
3 GGBEARINGS.COM
OSCILLATION WITH GREASE
To prove the durability of DX®10 in oscillation, DX®10 was compared with DX®, HI-EX® and bronze alloy (90% Cu, 10% Sn)
in greased oscillation tests. Each bearing was pin-indented. The graph below shows the superior performance of DX®10.
Testing indicated that DX®10 greased oscillation wear resistance was substantially better than bronze; better than GGB
standard product DX®. GGB premium product HI-EX® was better than DX®10.
O S C I L L AT I O N T E S T
0.5
Applied Load 70 MPa [10,000 psi]
0.243
0.500
Oscillation
0.088
0.050
±30° at 15 cpm 0.4
Temperature 22°C [72°F]
WEAR [mm]
0.3
Shaft Diameter 25 mm [0.984 inch]
0.2
Shaft Hardness 60 Rc
Lithium grease, greased 0 .1
DXDX10
Bronze
Grease Mixture
HI-EX
once at startup
DX
0.0
Test Duration 250,000 cycles [278 hours]
THERMAL DIMENSIONAL STABILITY
To demonstrate the long-term thermal dimensional stability of GGB tape products, creep resistance tests were
performed at 100°C comparing DX®, HI-EX® and DX®10. The test data indicated that DX®10 was significantly
better than DX® and on par with GGB premium product HI-EX®.
0.030
AF TE R 1000 H OURS [ mm ]
THERMAL DIMENSIONAL
TOTAL D EF ORM ATIO N
0.025
Load 36 MPa [5220 psi]
0.020
Material Thickness 1.5 mm [0.059 inch]
0.0205
0 . 0 2 75
0 . 0 18 0
0 . 0 15
Temperature 100°C [212° F] 0 . 0 10
DX 10
0.005
HI-EX
Test Duration 1000 hours
DX
0.0
THE TRIBOLOGICAL SOLUTION FOR INDUSTRIAL
PROGRESS, REGARDLESS OF SHAPE OR MATERIAL 4
