EUTELSAT COMMUNICATIONS VIA KA-SAT: GLOBAL COMMUNICATION SOLUTIONS FOR ANY SITUATION
2
3 WELCOME TO EUTELSAT THE LEADING SATELLITE OPERATOR FOR BROADCAST, BROADBAND AND DATA SERVICES In revenue terms, Eutelsat is one of the three leading satellite operators in the world. As well as reaching the Middle East, Africa, India and significant parts of Asia and the Americas, the company has commercialised capacity on 30 satellites that span the entirety of the European continent. As of October 2012, Eutelsat’s satellites were broadcasting more than 4,400 television channels to over 200 million cable and satellite homes in Europe, the Middle East and Africa. The Group’s satellites also serve a wide range of fixed and mobile telecommunications services, TV contribution markets, corporate networks, and broadband markets for Internet Service Providers and for transport, maritime and in-flight markets. Eutelsat’s broadband business unit, Eutelsat Broadband, markets and operates access to high speed Internet services through teleports in France and Italy that serve enterprises, local communities, government agencies and aid organisations in Europe, Africa, Asia and the Americas. Headquartered in Paris, Eutelsat and its subsidiaries employ over 750 commercial, technical and operational employees from 30 countries.
4
KA-SAT
THE FIRST HIGH THROUGHPUT
SATELLITE (HTS) IN EUROPE
KA-SAT, the first High Throughput Satellite (HTS) in Europe, marks a
new generation of multi-spotbeam, high capacity satellites. KA-SAT’s
revolutionary concept is based on a payload with 82 Ka-band spotbeams
connected to a network of ten ground stations. This configuration enables
frequencies to be reused 20 times and takes total throughput to beyond 90
Gbps. The ground network uses ViaSat’s SurfBeam® 2 technology.
type of heavier bandwidth use, the KA-SAT terminal
can deliver speeds of up to 50Mbps downstream and
20 Mbps upstream.
Benefits
• With 90+ Gbps of total capacity, KA-SAT has far
more throughput than regional Ku- and first
generation Ka-band satellites
• Integrated system designed and optimised for
data delivery
• Spot beam architecture enables more effective
Fast internet for everyone user bandwidth with frequency reuse
• Smaller, less expensive terminals with greater
As a powerful new platform for delivering high- speeds
bandwidth services, KA-SAT can deliver cost-effective
and competitive solutions. The new-generation
services on KA-SAT, targeted at users across Europe
and the Mediterranean Basin, provides an always-
on service delivering speeds of up to 20 Mbps
downstream and 6 Mbps upstream.
High throughput capability for professional
applications
KA-SAT responds to professional requirements for
higher volume and bandwidth for applications ranging
from Enterprises Networks to Internet Backhaul,
from Backup Services to M2M Connectivity. For thisHTS, a game changer
5
• A quantum leap in bandwidth offered
• Higher speeds for users for smaller antennas
•
•
Changes the cost and bandwidth equation
HTS is a new type of satellite that increases the
“Satellite communication is
market opportunities for satellite, in terms of probably the most ecological
capacity available, and in terms of applications
for consumer and professional markets.
way to communicate over long
distance today.”
Optimised for broadcast services
This allows one signal to be received simultaneously
by an unlimited number of users across an area
covering a continent or more.
KA-SAT: a green choice
Satellite communication is probably the most
ecological way to communicate over long distances
today. It is the only way to reach isolated areas with
high speed connectivity without having to install
environmentally-expensive land lines or build
complex ground infrastructure.
Unlike other wired communication technologies that
require energy-expensive civil engineering works at on a Boeing 747 in all its operational life (16 years)!
every house, a single satellite consumes little or no
operational fuel and can service entire continents. HTS: an innovation in satellite technology
The satellite transmissions run on 100% solar energy • High frequency re-use and multiple smaller spot
and the complete satellite launch procedure, using beams
hydrogen engines, generates about the same amount • Advanced development of ground infrastructure
of CO2 as a normal US coast-to-coast aeroplane trip and services centres
Some Numbers about KA-SAT
10 Gateways all over Europe
82 Ka-band spots of 250km diameter
Over 90 Gbps Total capacity
55 Countries covered in Europe and Mediterranean Basin
9° East Orbital position, located near Eutelsat’s premium HOT BIRDTM TV neighbourhood
at 13 ° East
26 December 2010 KA_SAT satellite launch
31 May 2011 Launch of services through KA-SAT infrastructure
16 years KA-SAT lifetime
www.eutelsat.com6
KA-SAT ACCESS
High throughput connectivity solution
for enterprises and institutions
Our standard offer has a maximum download speed of up to 20 Mbps and a
maximum upload speed of up to 6 Mbps. The offer includes one static public
IP address, minimum guaranteed bandwidth and a specialised technical
premium support contact 24/7. We have seven different standard packages
to satisfy every customer’s needs in terms of allowance, speed and cost:
KA-SAT Telemetry KA-SAT Symmetric The main advantages
• Download: 2 Mbps • Download: 6 Mbps that our solution can
• Upload: 2 Mbps • Upload: 6 Mbps supply are:
• Volume: 2 GB/Monthly • Volume: 75 GB/Monthly
• Min bandwidth before exceeding - Professional internet
KA-SAT Bronze volume: access
• Download: 20 Mbps · Download: 128 Kbps - LAN interconnection
• Upload: 6 Mbps · Upload: 128 Kbps - Back up solutions
• Volume: 25 GB/Monthly
KA-SAT Platinum There are three
KA-SAT Silver • Download: 20 Mbps different options that
• Download: 20 Mbps • Upload: 6 Mbps can be associated to
• Upload: 6 Mbps • Volume: 100 GB/Monthly KA-SAT Access:
• Volume: 60 GB/Monthly • Min bandwidth before exceeding
• Min bandwidth before exceeding volume: 1. Volume booster: this
volume: · Download: 256 Kbps option allows the
· Download: 128 Kbps · Upload: 128 Kbps customer to have a
· Upload: 64 Kbps
traffic basket they
KA-SAT Diamond can use after the
KA-SAT Gold • Download: 20 Mbps
• Download: 20 Mbps consumption of their
• Upload: 6 Mbps
• Upload: 6 Mbps monthly allowance.
• Volume: 125 GB/Monthly
• Volume: 75 GB/Monthly 2. VoIP: this option
• Min bandwidth before exceeding
• Min bandwidth before exceeding allows VoIP services
volume:
volume: with QoS
· Download: 512 Kbps
· Download: 256 Kbps 3. National IPs:
· Upload: 256 Kbps
· Upload: 64 Kbps on request, IP
addresses can be
provided.VNO’S SOLUTIONS 7
ON KA-SAT
THE VIRTUAL NETWORK OPERATOR (VNO) ON KA-SAT LEASES
BANDWIDTH IN ORDER TO PROVIDE TAILORED, FLEXIBLE
SOLUTIONS TO CUSTOMERS
It allows customers the creation of virtualised networks and repackage services
that satisfy different requirements for different markets. For web surfing or data
connectivity, for Cloud and even for legacy applications, VNO enables operators
to partition the satellite network and efficiently allocate resources to specific end
customers. VNO on KA-SAT integrates the latest satellite features and the most
advanced technology to provide excellent tailored and reliable services.
VNO solutions on KA-SAT represent the most flexible Benefits:
modular approach to establishing private networks
to increase revenues and obtain the full flexibility of • Quick deployment
technical and administrative control over a customer • Lowers the barrier to entry for resellers of
base. Furthermore, this avoids the cost of investment satellite services
in teleport infrastructure. • Scalable private network
• Design your network to fully support your desired
KA-SAT VNO solutions are highly scalable and business model
carefully engineered to meet the evolving needs of • Determine speeds, network performance and
users with various network requirements. rate plans as you see fit
• Support applications like VoIP, video and Private
Simple, flexible and scalable Networks
• Easily expand your service capacity as you build
VNOs on KA-SAT can configure different networks to customer demand
different speeds, performance and QOS. Expansion • Potential to reduce operating expenses for the
or change capabilities are easily permitted without primary satellite service provider since the VNO
altering remote site equipment in both directions. user assumes a greater role in managing its own
This type of hub architecture allows customers to assigned resources
grow their networks intelligently, with adaptations • A software development kit is available for
towards customised services enabling significantly custom applications
lower costs.
KA-SAT can offer new service packages for second-
tier provider, who in turn repackage these services to
their customers. This allows users to concentrate on
the more refined aspects of their purchased services
and to manage their own resources with minimal
support from the satellite operator.
www.eutelsat.com8
VNO’S SOLUTIONS:
IP CONNECT
HIGHLY FLEXIBLE, TWO-WAY SATELLITE SOLUTIONS FOR
INTERCONNECTING LOCAL AREA NETWORKS (LANS)
Ideal for linking corporate networks, or for communications between
educational, governmental or health-care institutions, IP Connect is a cost-
effective and reliable solution. With IP Connect you can interconnect any kind
and size of network, based on Star Topology, or for Closed Users Groups on
your dedicated bandwidth.
With IP Connect, an enterprise can communicate Your profile:
freely and constantly with branch offices, and
benefit from a wide range of services such as LAN • Corporations
interconnections, video conferencing, voice and data • Regional administrations
transmissions, and much more thanks to satellite • Rural communities
dedicated resource.
IP Connect advantages:
Key applications:
• Global availability
• LAN interconnection • Standard end-to-end solutions
• Satellite VPN solutions • Operational excellence through knowledge and
• Video conference expertise
• Unified Communications Application • Round-the-clock customer supportVNO’S SOLUTIONS: 9
M-BEAT
flexible bandwidth allocation
over different beams
M-BEAT (Multi-beam Best Effort Aggregated Throughput) provides flexible
best effort bandwidth allocation over different beams: the best solution to
create a wide range of broadband services with the possibility to customise
peak rates, volume allowance and CIR.
M-BEAT provides best effort bandwidth over
selected beams.
A minimum and maximum aggregated peak rate is
defined accordingly with business needs where all
customer terminals contribute to reach it.
Once aggregated throughput is set up, customers
can flexibly define specific configurations and service
profiles for the end user through:
• Best effort peak rates being accessible to a single
user terminal for both traffic directions
• Monthly volume allowance (if any)
• CIR
The M-BEAT service model
The model allows you to choose your dedicated
bandwidth over different beams. Create your personal
network within a dedicated bandwidth, and specify:
• Terminals
• Priorities
• Allowances
• CIR
www.eutelsat.com10
VPN
EUTELSAT + ONEACCESS SOLUTIONS
Key applications
• Secure LAN extension to remote branch offices, customers and suppliers
• Extension of VPN coverage to regional offices with limited Internet access
• Extensionofthroughputandperformancesforexistingofficeconnections(offloadservice)
• Emergency back-up or permanent business continuity solutions
Plug-and-play satellite VPN solution
For organisations operating with a geographically The purpose-designed OneAccess dual-core router
dispersed network of offices and business locations, technology includes a standard DSL connection
maintaining a high-speed, secure, interbranch as well as an Ethernet port linked to the satellite
communications network is a critical part of the modem and antenna. Incorporating specialised WAN
corporate IT infrastructure. optimisation and standards-based security software,
the CPE device offers dynamic traffic optimisation
Traditionally this has been achieved using dedicated capabilities for high-priority applications. It can
leased-lines, or more recently, using IP-VPN be configured in a closed user group satellite-only
technology over a standard broadband connection. mode, or as an extension to an existing terrestrial
The Eutelsat/OneAccess technology partnership VPN system to reach remote locations without access
offers an industry-first: an integrated high-speed to a broadband service. The system can also be
satellite IP-VPN solution comparable to existing DSL configured in off-load mode for locations that already
performance, availability and pricing. enjoy broadband connectivity, thereby extending
the existing throughput, performance and services
Highly scalable, secure and resilient, the system gives already offered to subscribers.
major telcos and ISPs the ability to offer customers
operating with dispersed branch locations, including Supporting the TR-069 CPE Web Management
in areas with limited broadband access, a viable Protocol (CWMP) and including an intuitive web
alternative means of enabling a secure, bi-directional management GUI, the plug-and-play system can be
communication link under a single, unified SLA installed and operational within one hour with no
contract. requirement for specialist satellite knowledge.
1. Eutelsat and OneAccess win ‘Business Service Innovation’ transforming the landscape for satellite-based enterprise
Award for Provision of Advanced Enterprise Services on KA- communications across Europe, North Africa and the Middle East.
SAT Satellite. Paris, London 5 June, 2013.
Eutelsat Communications and OneAccess were recognised by
Eutelsat Communications and OneAccess Networks have judges for successfully enabling high-speed Internet access via
won the Business Service Innovation Award at the 2013 Global next-generation satellites to become secure and affordable for
Telecoms Business (GTB) Innovation Awards for radically businesses, delivering DSL-like service at DSLlike prices.11
NewsSpotter
Cost-effective Satellite News and Data
Gathering Service
Satellite news and data gathering across Europe and the Mediterranean Basin
has been made simple and cost-effective using NewsSpotter, the KA-BAND
news gathering and data service offered via Eutelsat’s KA-SAT satellite.
Using the compact, lightweight equipment, one NewsSpotter, an IP Contribution service solution for
person can start transmitting and receiving real- satellite news gathering
time, high-quality video, images and data from any
location, in just a few minutes. • EASY
Easy to deploy and point
• SIMPLE
Automatic scheduling, internet-based booking
and delivery of signal to your injection point
• TRANSPORTABLE
Lightweight kits with small antennas; simple and
easy to transport everywhere
• COST EFFECTIVE
Very competitive price of equipment and service
• FAST
High speed rate for IP Streaming Contribution up
to HD Contents
Ideal for occasional or nomadic use, NewsSpotter
delivers seamless integration into IP networks using
state-of-the-art satellite technology. Bandwidth can
be reserved online using the self-booking application
- perfect for occasional, last minute use, or for
guaranteeing reservations for dedicated use.
www.eutelsat.comka-sat@eutelsatbroadband.com www.eutelsat.com
You can also read
