Emergent User Interfaces
CS-E4200
Lecture 4
–
Sound and auditory interfaces
4 Feb 2021
4 Feb 2021
What is Sound
Vibrations (pressure variations) in elastic media (such as
air), and detected by a receiver (ears, microphone, …)
Sound signal can be analysed with Fourier transform, and
chacterized by the frequency spectrum
Two different types
tonal sounds, consisting of sinusoidal components with
frequencies in harmonic (integer) relation
noises – with variable spectra
Human-made sounds are often tonal (vowels, singing,
musical instruments), most natural sounds are not
4 Feb 2021
Sinusoidal Sound
Elementary component in sound analysis, rare in nature
Two key properties
frequency, measured in Hertz (Hz)
1 Hz = one cycle per second
A
inverse of cycle period ( f = 1/ T )
amplitude (pressure level, A )
T
4 Feb 2021
Hearing Sounds
Humans can hear approx. 20 Hz - 20 kHz
reduces with age to about 15 kHz
Pressure level (amplitude)
measured in relation to "standard" sound pressure level on a
logarithmic scale as decibels (dB)
Examples:
normal conversation 65 dB, chainsaw 120 dB
above 85 dB is to be avoided
Note: this is not the same as "loudness", which means
subjectively perceived strength of the sound
4 Feb 2021
4 Feb 2021
Auditory Thresholds Humans hear frequencies from 20 – 22,000 Hz Most everyday sounds from 40 – 80 dB 4 Feb 2021
Tonal pitch and timbre
Non-sinusoidal but repeating waveform
base frequency (F0) + harmonic overtones (n x F0)
pitch = perceived base frequency
timbre = sound "color", defined by spectral proportions
Not constant loudness
sound envelope
4 Feb 2021
Non-tonal sounds
Non-repeating waveform
a) Discrete spectral components with non-harmonic frequencies
bells, resonating everyday objects
b) Continuous spectrum = noise
random (not predictable) signal
noises are different: distribution of
frequencies and signal values matter
white noise, pink/blue noise,
popcorn noise, etc.
4 Feb 2021
Voice and Speech
Formed by the vocal tract
Vowels (a, e, i, …) have a harmonic
spectrum characterized by formants
(peaks at certain kHz frequencies)
Consonants
harmonic: voiced nasals (b, m, n, j, …)
transients (k, p, t)
continuous noise (f, s, …)
https://en.wikipedia.org/wiki/Articulation_(phonetics)
4 Feb 2021Hearing 4 Feb 2021
Anatomy of the Ear
4 Feb 2021How the Ear Works https://www.youtube.com/watch?v=pCCcFDoyBxM 4 Feb 2021
How the Ear Works
Cochlea performs kind of Fourier analysis
different frequencies are distributed along the basilar
membrane, and sensed by different hair cells
Important for sound perception is the instant spectral content
over short time (ca. 5–50 ms)
signal sonogram
Example: "cochlea"
from http://www.neuroreille.com/promenade/english/sound/fsound.htm
4 Feb 2021Distance to Listener
Relationship between sound
intensity and distance to the listener
Inverse-square law
The intensity varies inversely with the
square of the distance from the source.
So if the distance from the source is
doubled (increased by a factor of 2),
then the intensity is quartered
(decreased by a factor of 4).
4 Feb 2021Sound Localization
Humans have two ears
localize sound in space
Sound can be localized
using 3 coordinates
Azimuth, elevation,
distance
4 Feb 2021Sound Localization
Azimuth Cues
Difference in time of sound reaching two ears
Interaural time difference (ITD)
Difference in sound intensity reaching two ears
Interaural level difference (ILD)
Elevation Cues
Monaural cues derived from the pinna (ear shape)
Head related transfer function (HRTF)
Range Cues
Difference in sound relative to range from observer
Head movements (otherwise ITD and ILD are same) 4 Feb 2021Sound Localization
https://www.youtube.com/watch?v=FIU1bNSlbxk
4 Feb 2021Sound Localization (Azimuth Cues)
Interaural Time Difference (ITD)
Interaural Level Difference (ILD)
4 Feb 20214 Feb 2021
HRTF (Elevation Cue)
Pinna and head shape affect frequency intensities
Sound intensities measured with microphones in ear and
compared to intensities at sound source
Difference is HRTF, gives clue as to sound source location
4 Feb 2021Accuracy of Sound Localization
People can locate sound
Most accurately in front of them
2-3° error in front of head
Least accurately to sides and behind head
Up to 20° error to side of head
Largest errors occur above/below elevations and behind head
Front/back confusion is an issue
Up to 10% of sounds presented in the front are perceived coming
from behind and vice versa (more in headphones)
BUTEAN, A., Bălan, O., NEGOI, I., Moldoveanu, F., & Moldoveanu, A. (2015). COMPARATIVE RESEARCH ON SOUND
LOCALIZATION ACCURACY IN THE FREE-FIELD AND VIRTUAL AUDITORY DISPLAYS. InConference proceedings of»
eLearning and Software for Education «(eLSE)(No. 01, pp. 540-548). Universitatea Nationala de Aparare Carol I.
4 Feb 20214 Feb 2021
Sound Synthesis
Abstract algorithms
additive: sum up a number of sinusoidals (+noise)
subtractive: reduce white noise spectrum by filters
any computational signal generator: wavetable, FM, etc…
Physically based models – simulate vibrations in a material
excitation: impact, friction, air flow …
resonances of the object
damping in the material
Sound envelope
design choice: stationary vs. variable amplitude/spectrum
https://en.wikipedia.org/wiki/Category:Sound_synthesis_types 4 Feb 20214 Feb 2021
Sound Reproduction
Loudspeakers
Single sound source at one point
Stereo – two speakers, sound may move along the Left-Right axis
Multichannel – more directional / spatial effects
Surround sound in theaters, horizontal directionality (L-R, front-rear)
General spatialization (next slide)
Headphones
Normal stereo signal – L/R directionality
sound may appear coming from inside the head
Spatialized signal by filtering with HRTF (head-related transfer function)
4 Feb 2021Vector Base Amplitude Panning
Extension of usual stereo: Divide a virtual sound source's signal
among the three loudspeakers nearest to source direction
Can be realized with any number of loudspeakers
4 Feb 2021
http://legacy.spa.aalto.fi/research/cat/vbap/Sound in the user interface
Output: Auditory Display
analogous to visual display, but sound is a temporal medium
sonification = representing information with sound
continuous sound: system state / object property
transients: events
Input: Sound Recognition
analysing sound structure
interpreting as events / input values
4 Feb 2021more info & some examples: http://www.icad.org/audio.php
4 Feb 2021Sonic Finder demo – https://vimeo.com/158610127
4 Feb 20214 Feb 2021
Example of mapping features to sounds to help navigation
4 Feb 2021https://sonification.de/handbook/chapters/chapter2/
4 Feb 2021https://dl.acm.org/doi/10.1145/1978942.1979357
4 Feb 20214 Feb 2021
https://www.youtube.com/watch?v=dplpCW-P77o
4 Feb 2021http://dnasonification.org
4 Feb 2021visual attention
Example: signals at traffic crosswalks
• https://www.brantfordexpositor.ca/2013/05/23/resident-fed-up-with-audible-crosswalk-beeping/wcm/696e8e66-8e0c-9cc6-88d5-f11a0780175c
• https://nationalpost.com/news/canada/chirping-sound-at-intersections
• http://www.apsguide.org/appendix_c_signal.cfm
4 Feb 2021Sound as input
What sounds to use? Analyzing input signal: find
patterns in…
Active: voice, tactile
(eg. hand clapping), amplitude variation,
various instruments envelope
Ambient: environment frequency content
noises, traffic, footsteps, (spectrum)
etc.
temporal structure (rhythm)
Input device: microphone
Interpret found patterns as
highly variable amplitude –
auto-adjusting sound level events
ambient noise often a continuous values
problem
4 Feb 2021Voice input
Complex issue, developed for decades
Available as software libraries or web services
Based on analyzing various features from the sound signal
(short time spectra, envelope, etc.)
word-based: input is compared to prototype words, works in
simple cases
phoneme-based: more general, detecting phonemes and
their combinations in words
Has to be tuned for different speakers
4 Feb 2021Practical issues
Don’t limit your ideas to most obvious features only
(amplitude and frequency)
Pattern recognition is the easier the less you have
different options to detect (eg. just numbers or few
commands vs. full language vocabulary)
Sound is temporal medium – detecting input requires
time (eg. while driving: turning a physical wheel vs.
pronouncing left/right commands)
4 Feb 2021Demos
Audio libraries in Processing: Sound and Minim
examples: Libraries/Sound/Analysis, …/IO,
…/Soundfile/Keyboard
Contributed Libraries/Minim/Basics/SynthesizeSound
Sonogram analysis
Theremin controlled with Arduino
What is theremin?
https://www.youtube.com/watch?v=-QgTF8p-284
4 Feb 2021Next Steps
Get used to different technologies
Try out examples demonstrated in the lectures (camera,
sound, sensors)
Arduino packages will be available next week at Aalto
è check Doodle form in MyCourses for suitable times
Start thinking, what technologies and/or application cases
would interest you
è check questionnaire in MyCourses
Seek ideas in the net (links in the lecture slides, more will
appear in MyCourses)
