Easy control of your air conditioning via your mobile phone or computer - MOV90550_EPLE05-42 - Cyan Magenta Yellow Black
MOV90550_EPLE05-42

                            Easy control of your air conditioning
                            via your mobile phone or computer

Cyan Magenta Yellow Black
Easy control of your air conditioning via your mobile phone or computer - MOV90550_EPLE05-42 - Cyan Magenta Yellow Black
MOV90550_EPLE05-42

                                                                                          p. 2

                                   i n t r o d u c t i o n

         Daikin Europe N.V.
                                              Daikin has a worldwide reputation based on over 80 years’
                                              experience in the successful manufacture of high quality air
                                              conditioning equipment for industrial, commercial and
                                              residential use.

         Table of Contents
                                              I. C ONTROL     YOUR AIR CONDITIONING
                                                   UNITS VIA YOUR MOBILE PHONE                          3
                                                      System Layout                                     3
                                                      Features                                          4
                                                      - Monitoring Functions                            4
                                                      - Control Functions                               4
                                                      - Error Notification                              4

                                              II.C ONTROL     YOUR AIR CONDITIONING
                                                   UNITS VIA YOUR COMPUTER                              5
                                                      System Layout                                     5
                                                      Features                                          6
                                                      - Monitoring Functions                            6
                                                      - Control Functions                               6
                                                      - Error Notification                              6
                                                      - Rotation Function                               7
                                                      - Back-up Operation Function                      7

                                              III.S PECIFICATIONS                                       8

Cyan Magenta Yellow Black Vernis
Easy control of your air conditioning via your mobile phone or computer - MOV90550_EPLE05-42 - Cyan Magenta Yellow Black
MOV90550_EPLE05-42

                                                                                      p. 3

                  I. Control your air
                  conditioning units
                  via your mobile phone
                Up to 4 Daikin air conditioning units (Sky Air or VRV) can be connected to a special DS-NET
                adapter and modem to allow operation and control via your mobile phone.

                  System Layout

                                                                DS-NET adapter
                                                                                             GSMmodem

                                                                                   RS232C

                                                                                             Malfunction

                                 Up to 4 units / 1 adapter

                                                                    Mobile phone        ON/OFF

Cyan Magenta Yellow Black Vernis
Easy control of your air conditioning via your mobile phone or computer - MOV90550_EPLE05-42 - Cyan Magenta Yellow Black
MOV90550_EPLE05-42

                 p. 4

                                             f e a t u r e s

                   Features

                3.
                1 M ONITORING F UNCTIONS                                Sending                       Response
                                                                         Screen                        Screen
                You can monitor your air conditioning units by simply
                sending an SMS with your mobile phone with the
                word “Report”:                                          Report                         DAIKIN DS-NET
                                                                                                       #1 On 20degC Cool
                                                                                                       #2 On 30degC Heat
                • Start/stop                                                                           #3 On 20degC Fan
                                                                                                       #4 Error A0

                • Operation mode (fan/cool/heat)
                • Temperature setting
                • Error code

                3.
                2 C ONTROL F UNCTIONS                                   Sending                       Response
                                                                         Screen                        Screen*
                You can control your air conditioning units by simply
                sending an SMS via your mobile phone:
                • Start/stop                                            #1
                                                                        #4
                                                                             on #2 off #3 on
                                                                             on
                                                                                                       #1
                                                                                                       #4
                                                                                                            on #2 off #3 on
                                                                                                            on
                                                                        #1   cool                      #1   cool
                • Operation mode (fan/cool/heat)                        #3   fan                       #3   fan
                                                                        #4   20                        #4   20
                • Temperature setting

                                                                                               * You can select whether or
                                                                                                 not you want to receive
                                                                                                       a response.

                                                                                                      Response
                3.
                3 E RROR N OTIFICATION                                                                 Screen

                When an error occurs, an SMS will be sent
                automatically to your mobile phone                                                      DAIKIN DS-NET
                                                                                                        #2 Error  A0
                (error notification).

Cyan Magenta Yellow Black Vernis
Easy control of your air conditioning via your mobile phone or computer - MOV90550_EPLE05-42 - Cyan Magenta Yellow Black
MOV90550_EPLE05-42

                                                                                                     p. 5

                   II. Control your air
                   conditioning units
                   via your computer
                Manage air conditioning units at remote locations easily via public telephone lines. Receive
                e-mail notifications of any malfunctions, while an emergency operation starts automatically.
                Enables centralized management for up to 2,000 air conditioning units (Sky Air and VRV units) in
                50 locations.

                   System Layout

                                                                                                            Enables
                                                        Modem                         Max. 4 Units          centralized
                                                                RS232C                                      management
                                                                                                            of 50 locations
                                                                                                            of this type
                                                                                                            of system.

                                       Building

                                                           Public   RS485
                                                           phone
                                                           line

                   PC for monitoring

                                                                               Enables access to
                                                        Modem                  up to 10 adapters
                                                                               at 1 location.

                              Malfunction

                                                         ...
                                             Building               Building

Cyan Magenta Yellow Black Vernis
Easy control of your air conditioning via your mobile phone or computer - MOV90550_EPLE05-42 - Cyan Magenta Yellow Black
MOV90550_EPLE05-42

                                                                                                 p. 6

                                       f e a t u r e s

                                                                                         Main Screen

                    Features

                1    M ONITORING F UNCTIONS
                You can monitor your
                air conditioning units via your computer:
                • Start/stop

                                                                                          Q
                • Set temperature
                • Operation mode                                                         Site Screen
                • Room temperature
                • Error code
                • Filter sign reset

                                                                                        Access Screen

                2    C ONTROL F UNCTIONS
                You can control
                your air conditioning units via your computer.

                3    E RROR N OTIFICATION
                The system informs you immediately by e-mail if an air conditioning unit malfunctions. If it is
                possible to arrange for your computer to forward such e-mail notifications to a mobile phone,
                you can remain informed of breakdowns at all times with no limitations on time or location.

                    Malfunction
                    Notification

                                                      Adapter
                                     Modem           DTA113B51
                                                                                           Backup Operation Star

                                     Modem

                                             E-mail transferred

Cyan Magenta Yellow Black Vernis
Easy control of your air conditioning via your mobile phone or computer - MOV90550_EPLE05-42 - Cyan Magenta Yellow Black
MOV90550_EPLE05-42

                                                        f e a t u r e s                                            p. 7

                4   R OTATION F UNCTION
                The rotation function automatically shuts down the air conditioning units one at a time in a
                single group, at fixed intervals. This lowers the operating load on each unit, extends service life
                and reduces the rate at which breakdowns occur.

                                                                                   ON

                                      Adapter                                      ON
                                     DTA113B51                                                          Units are stopped alternately
                                                                                                        at fixed intervals

                                                                                   ON

                                                                                   OFF

                                            Sequential rest periods help to extend the service life of the system overall.

                5   B ACK - UP O PERATION F UNCTION
                The back-up operation function automatically switches the remaining units to emergency
                operation mode if one of the air conditioning units in a group malfunctions. This prevents the
                entire air conditioning system from shutting down at once and ensures that the indoor
                temperature does not rise suddenly before repairs can be completed.

                                                 ON                   ON                     OFF                   OFF
                                                             Q Q

                                      Malfunction
                                                                      ON                     OFF                   OFF

                                                                                                                              Operation of other
                                                                                                                              air conditioning units
                                                                                                                              in the group backed up
                                                                                                                              automatically.
                                      Malfunction                     ON                 Emergency                 OFF
                                                                                         Operation

Cyan Magenta Yellow Black Vernis
Easy control of your air conditioning via your mobile phone or computer - MOV90550_EPLE05-42 - Cyan Magenta Yellow Black
MOV90550_EPLE05-42

             III. Specifications
                                                                                                                                                DTA113B51

      Supply - Voltage                                                                                                                    DC 16V supplied from R/C line
      Maximum number of connectable indoor units                                                             4 units per adapter PCB (via GSM), 40 units if 10 adapters connected (via computer)
      Forced ON/OFF input                                                                                                         Non-voltage (normal) 'a' contact x each point
      Dimensions (mm)                                                                                                                               100x100x35
      Installation method                                                                                             Built into the indoor unit or placed inside a box especially built for it
      Communication functions                                 via GSM                                                                        RS232C, GSM modem
                                                              via computer                                                                 RS232C, AT modem, RS485
      Ambient temperature/humidity conditions for operation                                                                              -10 ~ 50°C, max. of 95% RH
      Control functions                                       via GSM                                                    Start/stop, operation mode (fan/cool/heat), temperature setting
                                                              via computer                      Start/stop, operation mode (fan/cool/heat), temperature setting, air flow direction, air flow rate, filter sign reset
      Monitoring functions                                    via GSM                                              Start/stop, operation mode (fan/cool/heat), temperature setting, error code
                                                              via computer                         Start/stop, operation mode (fan/cool/heat), temperature setting, air flow direction, air flow rate, filter sign
      Malfunction monitoring functions                                                                                                    Malfunction reporting function
      Automatic alternating operation functions               via GSM                                                                                   Yes
                                                              via computer                                                                              Yes
      Back-up operation functions                             via GSM                                                                                   Yes
                                                              via computer                                                                              Yes

             Model Variations                                                                                                 Applicable Models
      • DS-NET adapter: DTA113B51                                                                                     All Sky Air and VRV units can be connected.
      • Monitoring panel software: DPC001B51

             Notes
      1. A remote control is required for each indoor unit connected to this adapter.
      2. If this adapter is attached, dual remote control operation is not possible. Also, combined use with an infrared remote control is not possible.
      3. Combined use with centralized remote controls, Intelligent Touch controller, BACnet® Gateway and a group distance control adapter is not possible.
      4. This adapter is compatible with a wide range of indoor units equipped with remote control wiring. However, in certain cases an installation box or
         installation board will be required. (4 power cables with different lengths are included in the package.)
      5. Network equipment, an Internet service provider contract, an AT modem as specified above etc., are in order to connect to the Internet.

      Note that it may not be possible to install the system due to the condition of the telephone line.

                                                                             Daikin Europe N.V. is approved by LRQA for                                                  Daikin units comply with the European regulations
                                                                             its Quality Management System in accordance                                                 that guarantee the safety of the product.
                                                                             with the ISO9001 standard.
                                                                             ISO9001 pertains to quality assurance regarding
                                                                             design, development, manufacturing as well as
                                                                             to services related to the product.

                                                                             ISO14001 assures an effective environmental
                                                                             management system in order to help protect
                                                                             human health and the environment from the
                                                                             potential impact of our activities, products and
                                                                             services and to assist in maintaining and
                                                                             improving the quality of the environment.

                                                                             Specifications are subject to change without prior notice
                                                                                                                                                                                                                             Printed on non-chlorinated paper / Printed in Belgium
