Dell EMC XC Family
Modernisieren Sie Ihr Rechenzentrum mit der Dell
EMC XC-Series und Nutanix Enterprise Cloud OS

 Alfred Meßing, Sr. Manager Business Partner
Dell EMC XC Family Modernisieren Sie Ihr Rechenzentrum mit der Dell EMC XC-Series und Nutanix Enterprise Cloud OS - Dell Technologies
Inhalte

      1   Hyper-converged infrastructure - Überblick
      2   XC Family on 14th Generation PowerEdge
      3   XC Family - Vorteile
      4   Software Architektur - Überblick
      5   Was treibt Unternehmen an und um?

2
Dell EMC XC Family Modernisieren Sie Ihr Rechenzentrum mit der Dell EMC XC-Series und Nutanix Enterprise Cloud OS - Dell Technologies
HCI Overview
Dell EMC XC Family Modernisieren Sie Ihr Rechenzentrum mit der Dell EMC XC-Series und Nutanix Enterprise Cloud OS - Dell Technologies
What’s driving interest?
                                               Main drivers

           Agility                  Simplicity              Modernization                Scalability
    Ability to respond quickly   Simplify operations with    Public-cloud efficiency   Start small and easily
     to business threats or           software-driven       and economics, but with    scale up or scale out
           opportunities              automation and           peace of mind of          while maintaining
                                 life cycle management            on premises           performance levels

                      Improve efficiency and lower operational costs

4
Dell EMC XC Family Modernisieren Sie Ihr Rechenzentrum mit der Dell EMC XC-Series und Nutanix Enterprise Cloud OS - Dell Technologies
HCI is running both traditional and cloud-native workloads

Traditional business                         Virtual Desktop                                Big Data
        apps               Test/Dev                                  IaaS, PaaS
                                              Infrastructure                                analytics

         Today the majority of HCI deployments are running a variety of workloads as well as VDI

5
Dell EMC XC Family Modernisieren Sie Ihr Rechenzentrum mit der Dell EMC XC-Series und Nutanix Enterprise Cloud OS - Dell Technologies
Key building blocks for HCI

    Software-defined storage                                x86 servers
    • Abstracts storage functions from hardware             • High-performance processors, large
    • Virtualizes direct-attach storage into                  memory
      shared pool                                           • Flash media delivers consistent,
    • Automates provisioning, load balancing                  predictable performance
                                                   Server
    Virtualization                                  SAN     High-speed Ethernet
    • Abstracts compute and network functions               • Connects nodes together to create
    • Enables physical resources to be shared                 cluster
    • Greatly improves utilization, mobility and            • Enables HCI to deliver high IOPS and
      security                                                reduced latencies

9
Dell EMC XC Family Modernisieren Sie Ihr Rechenzentrum mit der Dell EMC XC-Series und Nutanix Enterprise Cloud OS - Dell Technologies
Scalable Distributed System Design
                            Tier 1 Workloads                                    Nutanix Controller VM

                    Node 1                             Node 2                                      Node N
             VM    VM       VM   CVM           VM      VM      VM    CVM                      VM   VM       VM   CVM

                    Hypervisor                          Hypervisor                                 Hypervisor

                                                                Distributed Storage Fabric

     Enterprise Storage                 Data Protection
•    Data Locality
                                                                               Resiliency                         Security
                                  •    Converged backups
•    Tiering and caching                                               •   Tunable redundancy           •   Data at rest encryption
                                  •    Integrated DR
•    Compression                                                       •   Data path redundancy         •   Nutanix Security DL
                                  •    Cloud Connect
•    Deduplication                                                     •   Data integrity checks        •   Cluster Shield
                                  •    Metro availability
•    Shadow clones                                                     •   Availability domains         •   Two-factor authentication
                                  •    3rd party backup solutions
•    Snapshots and clones

10
Dell EMC XC Family Modernisieren Sie Ihr Rechenzentrum mit der Dell EMC XC-Series und Nutanix Enterprise Cloud OS - Dell Technologies
Dell EMC XC Family on 14th
Generation PowerEdge
Dell EMC XC Family Modernisieren Sie Ihr Rechenzentrum mit der Dell EMC XC-Series und Nutanix Enterprise Cloud OS - Dell Technologies
Dell EMC XC Family Hyperconverged Appliances
     The ideal selection when choice across industry leading hypervisors is a requirement

          61%
          Lower cost of                                                                                                                        50%
           operations1                                                                                                                         More GPU

                                               99%
                                             Less unplanned                                                                  93%
                                                                                                                                                power2

                                               downtime1                                                                    More compute for
                                                                                                                             storage dense
                                                                                                                                 apps2

1. IDC: “Dell EMC XC Series Creating Value as Scalable, Efficient, Hyperconverged Platform”, November 2017 Ad # G17000262
2. Based on Dell EMC internal analysis, Nov, 2017 Ad# G17000260

    15
Dell EMC XC Family Modernisieren Sie Ihr Rechenzentrum mit der Dell EMC XC-Series und Nutanix Enterprise Cloud OS - Dell Technologies
XC Family solution overview
     PRISM
              One-click infrastructure             Operational simplicity               Powerful analytics            3 level licensing model
              management                           • One-click upgrades                 • Customizable dashboards     • Starter, Pro, Ultimate
                                                   • Automated provisioning             • Integrated search
              • Cluster management                 • REST API                           • Capacity/performance
              • VM management                                                             trending
              • Storage management                                                      • Optimization advisor

          PowerEdge Servers 1U, 2U, 4N/2U, 3U                 HW flexibility            Optimized nodes                Industry-leading
                                                              • Short depth
                                                              • Compute-intensive       • GPU                           PowerEdge
                                                              • Performance-
                                                                intensive
                                                                                        • Storage                          Servers
                                                              • Storage-heavy           • ROBO                         and WW support
                                                              • Graphics-intensive
                                                              • Compute-dense

                        Multihypervisor flexibility            Proven data center resiliency              Distributed storage fabric
                        • VMware, Microsoft, AHV               • Non-disruptive upgrades                  •   Tunable redundancy
                                                                 and scaling                              •   Snapshots and clones
                        Cloud integration                      • Availability domains                     •   Dedupe and compression
                        • Cloud Connect—B/U to cloud           • Metro availability cluster               •   Erasure coding
                        • Stateful containers                                                             •   Caching, tiering, data locality
       ACROPOLIS                                                                                          •   Data encryption
     Operating system                                                                                     •   File and block storage services

17
XC Series and XC Core models on 14th Gen PowerEdge Servers
    XC640-10, 4, 4i               XC740xd-24                     XC740xd-12             XC740xd-12C/12R                  XC940-24                    XC6420-6

                                                                                                                      Memory and
      VDI, test/dev,         High performance                 Storage-heavy             Storage capacity,                                       Rack-dense VDI,
                                                                                                                      performance-
     private cloud,           Microsoft SQL,                 Exchange, Share-           no workload VMs/                                       service providers,
                                                                                                                   intensive SQL and
    virtualized apps           Oracle OLTP                    Point, big data            virtual desktops                                       enterprise cloud
                                                                                                                      Oracle OLTP
                                                          Hypervisor choice: Hyper-V 2016, AHV and ESXi
                Platform based on Dell EMC 14th Generation PowerEdge servers with Intel® Xeon Scalable Processors
                          Higher performance CPUs, more memory bandwidth, SAS/SATA SSDs and HDDs,
         NVMe SSDs (XC640, XC740xd, XC940 only), PCIe Card w/Mirrored boot drives, 10Gb SFP+, 10Gb BaseT, 25Gb SFP28
•    1 node 1U                                                                          •   1 node, 2U
•    10x 2.5” Drives (-10)                                                              •   12C: cold tier
                             •   1 node, 2U                                                                                                    •   4 node, 2U
•    4x 3.5” Drives                                                                         storage, AHV only      •   1 node, 3U
                             •   4x 2.5” Drives             •   1 node, 2U
     XC640-4/4i                                                                         •   12R: 1-node            •   24x2.5” Drives          •   6x2.5” Drives*
                             •   128GB – 1.5TB              •   12x 3.5” Drives
•    NVME (only on -10)                                                                     replication target,    •   1024GB – 4TB            •   128GB – 1024
                                 memory                     •   128GB – 1.5TB               AHV only                                               memory*
•    128GB – 1.5TB                                                                                                     memory
                             •   Hybrid, all flash, and         memory                  •   12x 3.5” Drives                                    •   Hybrid and all flash
     memory                                                                                                        •   Hybrid, all flash and
                                 NVME+SSD                   •   Hybrid, all flash and   •   64GB – 768GB
•    Hybrid, all flash                                                                                                 NVME+SSD
                             •   Optional Nvidia M10            NVME+SSD                    memory                     configurations
     configurations,             and M60 GPUs                                                                                                      * per node
     NVME+SSD only on                                                                   •   Hybrid and all flash
     XC640-10
     18                                                                                 •   XC Core unavailable
Dell EMC XC …. Consumption Options

     XC Core is the existing Dell EMC XC Series with licensing provided
               separately, and software support from Nutanix

                      XC Series                      XC Core

                   XC Series hardware            XC Series hardware
                     + Nutanix AOS                 + Nutanix AOS
                       + Licensing                   - Licensing

                  A new consumption model for all Nutanix customers

19
XC Family advantages
XC Family with optimized ecosystem
                                                         Integrated Data Protection

  Workload optimized                                       Easy
                                                          Button
PowerEdge configurations

         “Glue”                                                                       Microsoft optimization
enhances deploy, manage,
    recover, automate

           Software          Dell EMC XC Family
                                                                                Cloud Native Application
     Global Support for XC                                                           Development
        Series solution                           Best Practices &
                                          VM VM
                                                   Whitepapers
                                          VM VM

                                          VDI General              Networking
                                             Workloads

23
Dell EMC Ready System for VDI on XC Series
VDI on HCI for customers wanting ultimate flexibility – powered by Nutanix
                                                                            Nutanix SDS software
Solution benefits
                                                                            Choice of hypervisor and connection broker:
     •   Predictable per-seat cost & performance, and linear scale to         ▪ Microsoft Hyper-V, VMware ESXi
         support a growing workforce                                          ▪ Citrix XenDesktop/XenApp, VMware Horizon
     •   Ideal for rapid deployments
     •   Scale rapidly with workload specific configurations per platform
     •   6X faster time to value compared to traditional VDI solutions*
         and 27% lower cost than traditional solutions*

Differentiation
     •   Choice of hypervisor and connection broker                         Hyper-converged nodes on XC640 and XC740xd

     •   Highly scalable                                                    NVIDIA GRID M10 or M60 GPUs
     •   Deduplication and data compression                                 Choice of Hybrid or All Flash storage configurations
     •   Optimized Dell EMC hardware on Nutanix software
                                                                            Available from 3 to 1000+ nodes per cluster
     •   5-year working relationship between Dell EMC and Nutanix
                                                              General
                                                                Workloads
                                                                            Services: Deployment, Integration, Support

28
Customer results achieved with XC Series
                        lower total                                                                                                                             five-year ROI
                        cost of                                                                 lower cost
                                                                                                over 5 years                                                    up to *
                        operations on
     61      %          average over 5
                        years
                                                                                                for HW,
                                                                                                maintenance,
                                                                                                power and
                                                                                                                                                      498%
                     51
                      less time to
                                    %                          29                  %            datacenter
                                                                                                space*                                              99%          reduced
                                                                                                                                                    impact of unplanned
                      manage and                                                                                                                    downtime on user
                      support                                                             Up to      31%                                            productivity
                                                                                          less power and                                                     Payback period

                   0             downtime
                                 upgrades*
                                                                         57         %         less data
                                                                                              center space*
                                                                                                                                                             as short as

                                                                                                                                                             8      months*

     Sources: *Based on an IDC Business Value Whitepaper commissioned by Dell EMC, "Dell EMC XC Series Creating Value as Scalable, Efficient Hyperconverged Platform,"
     November 2017, where IDC interviewed IT Managers and decision makers from 8 organizations in the U.S. and India representing several verticals, with an average of 498
32   business applications. Results are normalized based on survey participant's use cases with the Dell EMC XC Series.
Software architecture
overview
Scalable Distributed System Design
                            Tier 1 Workloads                                    Nutanix Controller VM

                    Node 1                             Node 2                                      Node N
             VM    VM       VM   CVM           VM      VM      VM    CVM                      VM   VM       VM   CVM

                    Hypervisor                          Hypervisor                                 Hypervisor

                                                                Distributed Storage Fabric

     Enterprise Storage                 Data Protection
•    Data Locality
                                                                               Resiliency                         Security
                                  •    Converged backups
•    Tiering and caching                                               •   Tunable redundancy           •   Data at rest encryption
                                  •    Integrated DR
•    Compression                                                       •   Data path redundancy         •   Nutanix Security DL
                                  •    Cloud Connect
•    Deduplication                                                     •   Data integrity checks        •   Cluster Shield
                                  •    Metro availability
•    Shadow clones                                                     •   Availability domains         •   Two-factor authentication
                                  •    3rd party backup solutions
•    Snapshots and clones

36
Simple management through Nutanix Prism

                                         Intuitive
                                       Eliminate
                                           Simple
                                       Complexity…

                                         Insightful

37
Rich and insightful analytics

     Configuration   Health     Risk   Efficiency

39
Actionable Capacity Forecasting
                                         What is it?
                                         • Detailed capacity trends
                                         • Intelligent recommendations
                                         • Powered by patent pending
                                           X-FIT algorithm

                                         Benefits:
                                         • Enables pay as you grow
                                           capacity expansion
                                         • Eliminates guesswork

                 Predictive Operations
40
Aber warum das überhaupt?
•    “Do more with less” - Kostendruck hat nicht abgenommen!

•    Rechenzentren und ihre Strukturen haben weiter an Komplexität zugenommen!

•    Demographischer Wandel - kaum mehr genug oder gut ausgebildete IT Experten!

•    Steigende Datensicherheitsanforderungen !

•    Themem wie: Industrie 4.0 / Internet der Dinge, die Digitale Transformation

       “YOU HAVE TO GET ALL YOUR STAFF INVOLVED IN THE DIGITAL TRANSFORMATION.”
                                                            PATRICK HOFFSTETTER, CDO RENAULT

                “The digital transformation of companies is no longer an option, it is a need, and a question of survival,” explains Emili SeguraExecutive
       Director of Gas Natural Fenosa

               SÉBASTIEN BAZIN Chairman and CEO, Accor Hotels, Maud Bailly, Chief Digital Officer chez Accor Hotels

               ….all these projects are committed to positioning our Group at the leading edge of digital innovation.

41
41
IT Steht am Scheideweg

     "Für eine Mehrheit der CIOs ist die größte Herausforderung, dass die
     Aufgabenstellungen in ihrem Detaillierungsgrad völlig unklar sind und sie ohne
     einen Blueprint in die Veränderungen gedrängt werden." Gartner 2018

     "Die Botschaft ist klar und deutlich: Um die digitale Transformation weiter
     voranzutreiben, müssen sich CIOs selbst transformieren." Gartner 2018

     Nur 12 Prozent aller Befragten geben an, dass ihre IT-Organisationen die digitale
     Transformation ihres Unternehmens sehr effektiv steuern – McKinsey

     43 Prozent der Unternehmensleiter bezeichnen die IT als signifikant oder
     vollständig durch Drittanbieter austauschbar - McKinsey

42
Die Digitale Transformation startet im Rechenzentrum
 Planen Sie die Digitalisierung Ihres Rechenzentrums - geben Sie wertvolle IT-Budgets und IT-
 Team-Ressourcen frei!

 Teilen Sie mit Ihren CxOs eine Investitionsrechnung (TCO Business Case), die den geschäftlichen
 Wert der digitalen Transformation Ihres Rechenzentrums mit Nutanix darstellt Geschäftswert ist die
 Sprache von CxOs!

 Beschreiben und definieren Sie die Zukunft Ihrer IT-Abteilung und deren Mitarbeiter, nehmen Sie
 die Menschen auf die Reise mit.

 Besprechen Sie die sich abzeichnenden Veränderungen und erörtern Sie mit allen IT Team-
 mitgliedern deren künftigen Aufgaben und Rollen

 Helfen Sie mit, auch aus der IT Sicht, den Kunden im Vordergrund zu sehen und die Lösungen und
 Dienstleistungen zu erstellen, die den Kunden an ihr Unternehmen bindet

 Akzeptieren Sie den Wandel und seine Auswirkungen

43
Die Unterschiede – Technisch gesehen!
                                       Dell EMC XC-Series powered by

44
Die Unterschiede – Wirtschaftlich!

                     Klassisch 3-Tier

                                          Klassisch 3-Tier

45
Customer deployments
Empowering an Agile team
 Societe Generale is one of the first and largest financial groups in Europe with over 140,000
 employees serving 31 million customers across 60+ countries

 Opportunity:
 Support digital transformation within organization through scalable private cloud allowing them to
 be more flexible empowering innovation while being cost conscious.

                                                   Solution:
                                                   ✓ 350+ XC Series nodes - worldwide
                                                   ✓ Nutanix Enterprise Cloud OS
                                                   ✓ Private cloud supporting 9000+ VMs

                                                   Benefits:
                                                   ✓ Faster time to market
                                                   ✓ Reduced management costs
                                                   ✓ Quicker development cycles for
                                                      innovative additional services

47
No more guesswork in IT
  Opportunity:
  With a reorganization of local government expected, Commune
  de Villepinte needed to prepare its desktop environment for a
  major increase in network users.

Solution:                         Results:
The authority deployed XC         Minimizes the expense of doubling the IT
Series web-scale hyper-           user base
converged appliances with         Ensures that the authority is prepared for
Intel® Xeon® and Nutanix™         governmental changes
software for a flexible virtual
                z
desktop infrastructure
                                  Guarantees a high-performance
                                  virtualized desktop to maximize productivity
featuring software-defined
storage (SDS).                    Halves desktop management overheads
                                  with hyper-convergence and SDS
                                  Simplifies scaling with modular solution
                                  backed by responsive support

“   We can migrate public-sector employees from different regions to our Dell XC platform safe

                                                                        ”
    in the knowledge that we can meet their needs. – Bruno Viotty, Chief Information Officer, Commune de Villepinte

   48                                                                Retail
Harris County D.A. speeds up the court system
Largest county in Texas and 3rd in US
     Opportunity
     Harris County D.A. had many challenges: performance of enterprise
     applications, management complexity, constrained space and slow VM
     deployment due to legacy 3-tier infrastructure which led to infinitely
     delayed value projects.

     Solution                          Results
     Harris County D.A. installed XC   80% floor space reduction (84U to 16U)
     Series powered by Nutanix         Simplified infrastructure management via
     Enterprise Cloud Platform for:    one comprehensive, intuitive interface with
     • Microsoft Exchange              Nutanix Prism
     • Microsoft SQL Server            Realized increased performance beyond
     • Microsoft Lync                  previous 3-tier environment
     • VDI – Citrix XA/XD
     • Body Cam solution               Enabled the launch of new end-user
                                       computing project utilizing Citrix XenApp
                                       and XenDesktop

 “The simplicity of the [XC Series with Nutanix] hyper-converged platform, the lower cost, and having
 just one vendor to call for support was the most attractive solution.”
                                                                                     – Ryan McCarroll, Sr. Systems Administrator, Harris County

49
Driving Simplicity
 Opportunity:
 Williams constantly needs to refine its IT services to provide
 employees with the best solutions for competitive advantage.

 Solution:                         Results:
 Williams worked with Dell on      • Migration on time, within budget,
 two projects:                       with 99% user satisfaction

 1. Migrate email and instant      • HCI lets engineers access data in
                                     seconds instead of minutes
    messaging to Microsoft
    Office 365™                    • Simplified management frees up
                                     staff time
 2. Install Dell XC Series
    web-scale hyper-               • Compact trackside infrastructure
    converged appliances in          saves $150,000 on freight fees
    its trackside and factory        each season
    VDI environments

 “Dell ProSupport Plus is excellent. For example, we needed a replacement power supply for a server
 when we were trackside in Brazil. By the time the engineers got back to their hotel that evening there
 was a replacement waiting.”                            – Phil Cooper, IT Infrastructure Manager, Williams

 50
Accelerating innovation
 Improve VDI management, scalability and security
• Opportunity:
  The Department of Justice (DoJ) required a client virtualization solution with simplified
  deployment, provided scale out options, improved management and maintained high
  security capabilities.
 Solution:                                          Benefits:
 • 600+ XC Series appliances                        • Expanded the global footprint
 • Nutanix Acropolis and Prism                      • Lowered total cost of ownership
 • Dell Networking                                  • Simplified deployment sped time to value
 • Dell AppAssure data protection software          • Simplified VDI management
 • VMware ESXi                                      • Increased user mobility
 • VMware Horizon 6                                 • Maintained high security capabilities

 “As a trusted technology provider to federal agencies for more than 20 years, Dell is committed to providing its
 government customers with the tools they need to solve complex problems with efficient and effective IT solutions.”

 51
Helping banks drive targeted marketing decisions
                                            Opportunity:
                                            Cardlytics needed a computing environment with high availability,
                                            resilience, security and speed to analyze payment data and power
                                            purchase-based marketing solutions, including its proprietary in-bank
                                            marketing channel.

                                            Solution:                        Results:
                                            The company deployed a           Sets up bank partners in days instead of
                                            Dell hyperconverged              weeks, improving time-to-value
                                            storage and computing            Quickly deploys an integrated system for
                                            solution powered by              50% less cost than a tiered solution
                                            Intel® because of its            Improves storage performance to about
                                            reliability, cost-               45,000 IOPS per node
                                            effectiveness and                Gains a unified view of performance and
                                            support.                         reduces IT management burden
                                                                             Maintains 99.9% availability

     “   In our efforts to be future ready, the Dell EMC XC Series is helping to increase our
         speed-to-market, which is a big thing for us. Our bank partners love a solution that

                                                                                                    ”
         allows them to get up and running fast, and ahead of the competition.
                                              – Jason Bray, Senior Vice President of Engineering, Cardlytics

52
Accelerating innovation
Retailer Makes Better Business Decisions
 Opportunity:
 Aubert, leading retailer in France, experienced response challenges for ERP
 system and website during peak times due to aged mixed vendor systems.

Solution:                                       Benefits:
•    XC Series web-scale converged appliances •   20% website traffic increase
     with Intel® Xeon® processors             •   2X web page loading speed
•    Nutanix Acropolis and Prism              •   83% faster ERP access
•    Dell Networking N4000 and N2000 switches •   50% faster backups
•    Dell DR4100 disk backup appliance        •   30% greater IT team efficiency

“Quicker access to business data means better decision-making, and with our XC web-scale hyper-converged
appliance, we’ve increased access speeds dramatically.”
                                                                              Julien Navarro, CEO, NAOS (IT services provider to Aubert)

53
Realising the power of hyper-
                                               convergence

Business needs                      Business results
AEW Energie wanted personnel        • Enables greater focus on specialised tasks due to fewer IT
to focus more time on specialised     issues
tasks instead of maintaining and    • Reduces storage costs with software-defined solution
managing the existing IT            • Enhances data-centre efficiency with scale-out architecture
infrastructure.                       that’s quick to deploy
                                    • Ensures redundant environment at head office

                                                                                    “Compared with a traditional environment,
                                                                                    we’ve cut our data-centre costs by
                                                                                    switching to Dell EMC hyper-converged
                                                                                    infrastructure and software-defined
                                                                                    storage.”
                                                                                    Thomas Heiz, control systems engineer, AEW Energie

                                                                                            Read the full case study ›
54
The wisdom of virtual
                                                  desktop infrastructure

Business needs                      Business results
To help drive expansion and         • Realizes business growth of 31 percent in one month
increase efficiencies, Zhongtong    • Cuts the costs for managing desktops by 80 percent
Information Service looked to       • Increases the efficiency of managing its desktop environment
replace its traditional PC            nine-fold
infrastructure with a cloud-based   • Maximizes data protection through secure operating system
desktop.                            • Optimizes investment long-term through detailed insight into
                                      performance

                                                                            “In one month, our business has improved 31 percent. We
                                                                            have nearly 100 cloud desktop terminals serving online,
                                                                            and employees from across multiple departments are
                                                                            responding well. We’ve started to promote the Dell EMC
                                                                            VDI solution in the market, hoping to create value for
                                                                            customers through cloud desktop services since we’ve
                                                                            seen how good the results are.”
                                                                            Huang Zhiqing, Project Manager, Zhongtong Information Service

                                                                                        Read the full case study ›
 55
Japanese hospital accelerates
                                                    analysis and research

Business needs                       Business results
Teikyo University Hospital wanted    • Improves the development of treatments for patients
to enhance patient care and          • Provides an infrastructure on which to enhance hospital
accelerate the analysis of patient     operations
data with a highly scalable and      • Cuts deployment time in half compared with previous solution
flexible IT platform.                • Lowers costs of platform by one-third with converged appliances
                                     • Boosts the effectiveness of IT with faster provisioning

                                                                                          “We can store everything in our Dell EMC
                                                                                           XC web-scale converged appliances and
                                                                                           share the data between systems. We
                                                                                           have increased performance, and we
                                                                                           have cut costs down by one-third.”
                                                                                          Dr. Tomohiro Sawa, Medical Information Systems Research
                                                                                           Center,Teikyo University Hospital

                                                                                                 Read the full case study ›
56
Why Dell EMC XC is the ideal platform for Nutanix

     Built on PowerEdge
                                                        Automation and
      servers with150          BIOS and firmware
                                                        orchestration for
      requirements for        optimized for Nutanix
                                                      system deployment,
      software-defined              software
                                                      update and recovery
            storage

                                                         Support centers in
     Nutanix licensing and
                              Dell Technologies and   167 countries, 1,000+
        support model
                              XC Family ecosystem      parts depots globally,
      options that best fit
                                    integrations         technical experts
          your needs
                                                      fluent in 55 languages

57
57
© 2017 Dell Inc. All rights reserved Dell, the Dell logo, OpenManage, PowerEdge, ProSupport, vWorkspace and Wyse are registered trademarks of Dell Inc. in the United States and other countries. Nutanix, the Nutanix logo, Acropolis and Prism are registered
trademarks of Nutanix, Inc. in the U.S. and/or other countries. Citrix and the Citrix logo are registered trademarks of Citirix Systems, Inc. in the U.S. and/or other countries. Microsoft, the Microsoft logo, Exchange, Office 365, Hyper-V, SQL Server and Windows
are trademarks of Microsoft Corporation in the U.S. and/or other countries. VMware, the VMware logo, Hypervisor ESXi, VMmark and vSphere are registered trademarks of VMware, Inc in the U.S. and/or other countries. NVIDIA, the NVIDIA logo and GRID are
registered trademarks of NVIDIA Corporation in the U.S. and/or other countries. Oracle and the Oracle logo are registered trademarks of Oracle Corporation in the U.S. and/or other countries. Intel, the Intel logo, Intel Inside, Intel Core and Intel Xeon are
registered trademarks of Intel Corporation in the U.S. and/or other countries.
XC640-4 flexible configurations
 Ideal for ROBO, 3 Node Cluster (mission critical)
                                  Registered or Custom: Platinum 8160; Gold 6152,6138,6132,6130,5120,5118; Silver 4114,4108

Intel Xeon CPU (Dual Only)        Custom Only: Platinum 8180,8176,8170,8164,8158,8153;
                                  Gold 6150,6148,6140,6136,6134,6128,6126,5115; Silver 4116,4110

Memory                            16 GB RDIMMS
4 - 24 RDIMMS                     32 GB RDIMMS
2666MT/s                          64 GB LRDIMMS

                                  VMware vSphere® ESXi 6.0, 6.5
Hypervisor options                Microsoft Hyper-V®, 2012, 2016
                                  Nutanix™ AHV
Drive options                     SAS/SATA SSD (Min = 2, Max =4)
4x3.5” drive slots                400 GB, 480 GB, 800 GB, 960 GB, 1.6 TB, 1.9 TB, or 3.8 TB
                                  4 3.5” HDDs (Min/max =2,)
1.9 TB SED FIPS SSDs and 2/4 TB   2 TB, 4 TB, 8 TB
HDDs available
                                  Network Daughter Cards                                  PCIe NICs
                                  Intel i350 4x1G-T                                      Intel i350 4x1G-T
                                  Intel X550 4x 10G-T                                     Intel i350 2x1G-T
Networking options
                                  Intel 550 2x 10G-T & i350 2x 1G-T                      Intel X550 2x10G-T
                                  Intel X710 2x10G SFP+ & i350 2x1G-T                     Intel X710 2x10G SFP+
                                  Intel 710 2x10G SFP+                                    Mellanox Connext X4 LX 2x25G SFP28
                                  Mellanox Connect X4 LX 2x25G SFP28
59
XC640-4i flexible configurations
 Ideal for ROBO, 1 or 2 Node Cluster (non mission critical)
                                  Registered or Custom: Gold 5118, Silver 4114, 4108"

Intel Xeon CPU (Single Only)

Memory                            16 GB RDIMMS
4 - 24 RDIMMS                     32 GB RDIMMS
2666MT/s
                                  VMware vSphere® ESXi 6.0, 6.5
Hypervisor options                Nutanix™ AHV

Drive options                     SAS/SATA SSD (Min = 2, Max =4)
4x3.5” drive slots                400 GB, 480 GB, 800 GB, 960 GB, 1.6 TB, 1.9 TB, or 3.8 TB
                                  4 3.5” HDDs (Min/max =2,)
1.9 TB SED FIPS SSDs and 2/4 TB   2 TB, 4 TB, 8 TB
HDDs available
                                  Network Daughter Cards                                  PCIe NICs
                                  Intel i350 4x1G-T                                      Intel i350 4x1G-T
                                  Intel X550 4x 10G-T                                     Intel i350 2x1G-T
Networking options
                                  Intel 550 2x 10G-T & i350 2x 1G-T                       Intel X550 2x10G-T
                                  Intel X710 2x10G SFP+ & i350 2x1G-T                     Intel X710 2x10G SFP+
                                  Intel 710 2x10G SFP+                                   Intel X710 2x10G SFP+ & i350 2x1G-T

60
XC740xd-12 flexible configurations
 Ideal for capacity-intensive, Microsoft Exchange™/Microsoft SharePoint®, Data Warehouse, Big Data
                                   E5-2620 v4, 8-core, 2.1 GHz      E5-2630 v4, 10-core, 2.2 GHz
 Intel Xeon CPU (single or dual)   E5-2650 v4, 12-core, 2.2 GHz     E5-2660 v4, 14-core, 2.0 GHz
                                   E5-2680 v4, 14-core, 2.4 GHz     E5-2695 v4, 18-core, 2.1 GHz

 Memory                            16 GB RDIMMS
 8 - 24 RDIMMS                     32 GB RDIMMS
 2666MT/s                          64 GB LRDIMMS

                                   VMware vSphere® ESXi 6.0
 Hypervisor options                Microsoft Hyper-V®, 2012, 2016
                                   Nutanix™ AHV

 Drive options                     SAS/SATA SSDs (Min = 2, Max = 12)
 12x3.5” drive slots               400 GB, 480 GB, 800 GB, 960 GB, 1.6 TB, 1.9 TB, or 3.8 TB
 6/10/12 Drive AFA Configs         HDD (Min = 4 Max = 10)
 1.9 TB SED FIPS SSDs and 2/4 TB   2 TB, 4 TB, 8 TB
 HDDs available
                                   Network Daughter Cards (1 per system)                   PCIe NICs (6 full height)
                                   Intel X550 4x 10G-T                                     Intel i350 2x1G-T
                                   Intel 550 2x 10G-T & i350 2x 1G-T                       Intel X550 2x10G-T
 Networking options
                                   Intel X710 2x10G SFP+ & i350 2x1G-T                     Intel X710 2x10G SFP+
                                   Intel 710 2x10G SFP+                                    Mellanox Connext X4 LX 2x25G SFP28
                                   Mellanox Connect X4 LX 2x25G SFP28

61
XC740xd-24 flexible configurations
Ideal for performance-intensive, VDI, Microsoft SQL Server®, Oracle®
                                  Registered or Custom: Platinum 8160; Gold 6152,6138,6132,6130,5120,5118; Silver 4114,4108 Custom
Intel Xeon CPU (dual only)        Only: Platinum 8180,8176,8170,8164,8158,8153; Gold 6150,6148,6140,6136,6134,6128,6126,5115; Silver
                                  4116,4110
Memory                            16 GB RDIMMS
8 - 24 RDIMMS                     32 GB RDIMMS
2666MT/s                          64 GB LRDIMMS

                                  VMware vSphere® ESXi 6.0, 6.5
Hypervisor options                Microsoft Hyper-V®, 2012, 2016
                                  Nutanix™ AHV
Drive options                     SSD (Min = 2 Max 4)
24x2.5” drive slots               200 GB, 400 GB, 480 GB, 800 GB, 960 GB, 1.6 TB, 1.9 TB, or 3.8 TB
2/14/16/20/24 Drive AFA Configs   4 NVME Drives (Must be combined with 8-20 SSDs)
1.9 TB SED FIPS SSDs and 2/4 TB   800 GB, 1.6 TB, 3.2 TB
                                  2.5” HDD (Min = 4 Max = 22)
HDDs available
                                  1, 2 TB

                                  Network Daughter Cards (1 per system)                  PCIe NICs (6 full height)
                                  Intel X550 4x 10G-T                                    Intel i350 2x1G-T
Networking options                Intel 550 2x 10G-T & i350 2x 1G-T                      Intel X550 2x10G-T
(18 ports max)                    Intel X710 2x10G SFP+ & i350 2x1G-T                    Intel X710 2x10G SFP+
                                  Intel 710 2x10G SFP+                                   Mellanox Connext X4 LX 2x25G SFP28
                                  Mellanox Connect X4 LX 2x25G SFP28

                                  Nvidia M60/M10 (not compatible with NVME)
GPU

   62
XC740xd-12c flexible configurations
 Storage-capacity node that can run in a cluster with any hypervisor
                                  Silver 4108; Bronze 3106
 Intel Xeon CPU (dual only)

 Memory                           16 GB RDIMMS
 4 - 24 RDIMMS                    32 GB RDIMMS
 2666MT/s

 Hypervisor options               Nutanix™ AHV

 Drive options                    SAS/SATA SSDs (Min = 2, Max = 12)
 12x3.5” drive slots              400 GB, 480 GB, 800 GB, 960 GB, 1.6 TB, 1.9 TB, or 3.8 TB
 6/10/12 Drive AFA Configs        HDD (Min = 4 Max = 10)
 1.9 TB SED FIPS SSDs and 2/4/8   2 TB, 4 TB, 8 TB
 TB HDDs available
                                  Network Daughter Cards (1 per system)                  PCIe NICs (6 full height)
                                  Intel X550 4x 10G-T                                    Intel i350 2x1G-T
 Networking options
                                  Intel 550 2x 10G-T & i350 2x 1G-T                      Intel X550 2x10G-T
                                  Intel X710 2x10G SFP+ & i350 2x1G-T                    Intel X710 2x10G SFP+
                                  Intel 710 2x10G SFP+

63
XC740xd-12r flexible configurations
 Single node replication target (not clustered)
                                  Silver 4108, 4114
 Intel Xeon CPU (dual only)

 Memory                           16 GB RDIMMS
 4 - 24 RDIMMS                    32 GB RDIMMS
 2666MT/s

 Hypervisor options               Nutanix™ AHV

 Drive options                    SAS/SATA SSDs (Min = 2, Max = 12)
 12x3.5” drive slots              400 GB, 480 GB, 800 GB, 960 GB, 1.6 TB, 1.9 TB, or 3.8 TB
 6/10/12 Drive AFA Configs        HDD (Min = 4 Max = 10)
 1.9 TB SED FIPS SSDs and 2/4/8   2 TB, 4 TB, 8 TB
 TB HDDs available
                                  Network Daughter Cards (1 per system)                  PCIe NICs (6 full height)
                                  Intel i350 4x1G-T                                      Intel i350 4x1G-T
                                  Intel X550 4x 10G-T                                    Intel i350 2x1G-T
 Networking options
                                  Intel 550 2x 10G-T & i350 2x 1G-T                      Intel X550 2x10G-T
                                  Intel X710 2x10G SFP+ & i350 2x1G-T                    Intel X710 2x10G SFP+
                                  Intel 710 2x10G SFP+

64
XC940-24 flexible configurations
Designed for memory and performance-intensive
Microsoft SQL Server®, Oracle® OLTP
                                        Registered or Custom: Platinum 8160; Gold 6152,6138,6132,6130,5120,5118; Silver 4114,4108 Custom
Intel Xeon CPU (quad only)              Only: Platinum 8180,8176,8170,8164,8158,8153; Gold 6150,6148,6140,6136,6134,6128,6126,5115

                                        16 GB RDIMMs
Memory
                                        32 GB RDIMMs
24 – 48 RDIMMS                          64 GB LRDIMMs
2666MT/s                                128GB LRDIMMs

                                        VMware vSphere® ESXi 6.0, 6.5
                                        Microsoft Hyper-V® 2016
Hypervisor options                      Nutanix™ AHV

Drive options                           SSD (Min = 2 Max 4)
24x2.5” drive slots                     200 GB, 400 GB, 480 GB, 800 GB, 960 GB, 1.6 TB, 1.9 TB, or 3.2 TB
                                        4 NVME Drives (Must be combined with 20 SSDs)
2/14/16/20/24 Drive All flash Configs
                                        800 GB, 1.6 TB, 3.2 TB
1.9 TB SED FIPS SSDs and 2/4 TB         2.5” HDD (Min = 4 Max = 22)
HDDs available                          1, 2 TB

                                        Network Daughter Cards (1 per system)                  PCIe NICs (8 full height)
                                        Intel X550 4x 10G-T                                    Intel i350 2x1G-T
                                        Intel 550 2x 10G-T & i350 2x 1G-T                      Intel i350 4x1G-T
Networking options                      Intel X710 2x10G SFP+ & i350 2x1G-T                    Intel X550 2x10G-T
                                        Mellanox Connext X4 LX 2x25G SFP28                     Intel X710 2x10G SFP+
                                        ,                                                      Mellanox Connext X4 LX 2x25G SFP28
  65
XC6420-6 flexible configuration
Ideal for Rack Dense VDI, service providers, enterprise cloud environments

                                       C35/F95: 5120, 5118, 5115, 4116, 4114, 4110, 4108
 Intel Xeon CPU (dual only)*           C30/F86: 8170, 8164, 8160, 8158, 8153, 6152, 6150, 6148, 6140, 6138, 6136, 6134, 6132, 6130, 6128,
                                       6126
 Memory*                               16 GB RDIMMS
 8 - 16 RDIMMS                         32 GB RDIMMS
 2666MT/s                              64 GB LRDIMMS

                                       VMware vSphere® ESXi 6.0, 6.5
 Hypervisor options                    Microsoft Hyper-V®, 2012, 2016
                                       Nutanix™ AHV
 Drive options*                        SSD (Min/max – 2 for hybrid configurations)
 6x 2.5” drive slots                   SAS/SATA SSDs: 400GB, 480GB, 800GB, 960GB, 1.6TB, 1.9TB, 3,8TB.. All flash SAS/SATA available,
 4/6 Drive All flash Configurations    2.5” HDD (Min/max = 4)
 1.9 TB SED FIPS SSDs and 2.4 TB       12Gb SAS, 1.2TB, 1.8TB, 2.4TB,
 HDDs available

                                       PCIe NICs (max 1 low profile)
                                       Intel i350 2x1G-T
                                       Intel X550 2x10G-T
 Networking options*
                                       Intel X710 2x10G SFP+
                                       Mellanox Connext X4 LX 2x25G SFP28

                                      * - per node

  66
You can also read
