DC Product Catalogue 2021 - 2022 Australia and New Zealand DC Product Solutions Smarter energy. Smarter solutions
Contents
DC Power Systems Software and Communications
DU-X Electronic Fuse Distribution..................................... pg 6 Visual Power Manager ......................................................pg 52
Enterprise Power Solutions............................................... pg 8 DCTools Configuration Software.......................................pg 54
Access Power Solutions - APS3 & APS6................................ pg 10
Rectifier Modules
Access Power Solutions - APS6-600...................................... pg 12
Rectifier Module - APR24.................................................. pg 55
Access Power Solutions - APS12...................................... pg 14
Energy Saver Rectifier - LPR48-ES.....................................pg 56
Wall Mount Power Solution - WMPS............................... pg 16
Rectifier Module - APR48..................................................pg 57
Access Power Solutions with Batteries............................ pg 18
Energy Saver Rectifier - APR48-ES.................................... pg 58
Small Power System with Batteries.................................. pg 20
Energy Saver Rectifier - NPR48-ES....................................pg 59
Metro Power Solutions...................................................... pg 22
Metro Power Solutions Extension.....................................pg 24 Solar
Core Power Solutions........................................................ pg 26 Solar Charger - ASC48-ES.................................................pg 62
Industrial High Reliability.................................................. pg 28 Control and Monitoring
DC Utility Power System....................................................pg 30 SC300 System Controller................................................... pg 63
Inverter Power Solutions DC Energy Meter................................................................pg 65
Matrix™ Modular Inverter................................................. pg 32 Siteure................................................................................pg 67
Matrix™ 2000 Standalone Inverter................................... pg 34 IOBSS-10 SiteSure-3G.......................................................pg 68
Telecom Inverter Solution..................................................pg 36 Matrix Network Management Card...................................pg 69
DC Distribution Module - DCD3.........................................pg 70
DC-DC Solutions
DC Distribution Module - DCM1000/DCM1600................pg 71
Modular Converter Solutions.............................................pg 38 DC Distribution Module DCM2400.................................... pg 72
DC-DC Converter Modules................................................. pg 40
DC Distribution Module DCM2000-21RX.......................... pg 73
Outdoor Enclosures Battery Maintenance Point................................................ pg 74
Whisper Cabinet................................................................ pg 42 PWTC12F-55FR-2............................................................... pg 75
ORC Roadside Telecom Equipment Enclosures.................pg 44 PWTC12F-100FR-2............................................................. pg 76
ExoCab18 Outdoor Enclosure .............................................. pg 46 PWTC12F-150FR-2............................................................. pg 77
ExoCab26 Outdoor Enclosure...................................................pg 48 PWTC12F-180FR-2............................................................. pg 78
ExoCab34 Outdoor Enclosure...................................................pg 50 PWTLFeLi-48100F-E.............................................................pg 79
Eaton's DC power solutions business
Our Business Environmental standards
Eaton is a power management company providing Eaton strives for the highest
energy efficient solutions that help our customers environmental standards across both
effectively manage electrical, hydraulic and our operations and products and our
mechanical power. A global technology leader, Eaton commitment goes beyond compliance
serves the needs of customers located in over 175 with existing regulations. We wish
countries. to become recognised as an industry
At Eaton, we’re energised by the challenge of leader in creating safe workplaces and
powering a world that demands more. With over 100 conserving world resources.
years experience in electrical power management, Eaton is committed to environmental
we have the expertise to see beyond today. From stewardship and participates in a
ground breaking products to turnkey design and number of volunteer government
engineering services, critical industries around the partnership programs worldwide.
globe count on Eaton. We were among the first diversified
We power businesses with reliable, efficient and safe industrial companies to pursue global
electrical power management solutions. Combined ISO 14001 certification - a rigorous
with our personal service, support and bold thinking, standard for managing and improving
we are answering tomorrow’s needs today. Follow environmental performance.
the charge with Eaton. Visit eaton.com/electrical. Today, virtually all of Eaton's facilities
worldwide have earned this designation.
Design for Environment (DfE) and Life
Unsurpassed experience Cycle Assessment are core parts of the
Eaton has in excess of 40 years experience of Eaton product development process.
working closely with customers to deliver tailored They ensure that a product is safe, uses
power management solutions. for communications resources wisely, and fully sustainable
networks around the world. over the whole life cycle.
4 EATON DC Product Catalogue
Customer led solutions Delivery On-Site Services
Eaton’s insight into customer needs is Eaton’s global scale manufacturing and Eaton’s fully trained field service
demonstrated through its products in logistic capability means that products and engineers can carry out all installation
terms of reliability, efficiency, smart services can be delivered with maximum tasks or supervise and assist local staff.
energy features, power density, and ease cost effectiveness and with the delivery
of installation, Intelligent monitoring and speed and flexibility that you expect. Design Services
control capabilities add flexibility, precision,
Skilled engineering staff can provide a full
reliability, and automation - without added Training
design service for DC power systems to
complexity. Eaton offers a comprehensive range of specifically suit individual applications and
training courses designed to provide the sites.
Comprehensive range right level of product knowledge with
Our telecom power solution range includes practical demonstrations and hands-on
AC and DC power systems, power and opportunities. Courses can be arranged at
Integration Services
ancillary equipment management software, an Eaton location or at a customer’s site. Our telecommunications integration
cabinets and enclosures, and other services provide complete install, testing
and integration services for any type
products. Eaton also offers a wide range of Services Capability
DC services including design, installation of communications or other electronic
Eaton offers a wide range of DC secure equipment, to world leading standards of
and commissioning remote monitoring,
power services including power quality service.
turnkey integration and site support, to
evaluation, sizing, design consultancy,
provide a seamless solution.
installation and commissioning, full project
management and turnkey integration.
Eaton’s global presence ensures quick
response times for all of our customers.
EATON DC Product Catalogue 5
DU-X Electronic Fuse Distribution
The Eaton® DU-X Electronic Distribution (e-Fuse) is the ideal
solution for next generation 5G wireless networks, fibre-based
deployments and other low power telecommunications
applications requiring compact, efficient and flexible DC power
supplies.
Each load and battery system connection is controlled and
protected using a semiconductor device allowing for precise
control of overcurrent trip, fault currents and connection. All
terminations are made via the front of the unit to ensure ease of
use in space constrained installations.
The DU-X distribution embeds a full featured system controller
with a front access 100BaseT Ethernet port. This provides access
for easy system setup and outbound network communications.
Also available from the front are digital and analogue inputs, and
digital outputs.
Once partnered with high efficiency rectifiers and fitted into a small
1U high system shelf, operators have available to them one of the
Shown fitted into an RM3 magazine most compact and innovative small systems on the market,
providing up to 2000Watt of power.
e-Fuse-based load protection offers benefits such as: rapid late
point definition of protection outputs, reduced lead-times, energy
metering, and remote reset preventing costly truck rolls.
Features
Include providing secure power for
Radio Base Stations
Fibre networks
Customer premises equipment
Roadside cabinets
Converged VoIP/data networks, PoE, and IP routers.
Features
Super compact design
Local or remote setting of load and battery protection
Full current output at chosen setting, no derating
Full front connection
Rapid late point definition to reduce lead-times
Embedded system controller
On-board secure web server
SNMP agent
Energy metering function
Setup via web, keypad or configuration file
Compatible with Eaton’s Energy Saver (ES) rectifier
6 EATON DC Product Catalogue
Technical specifications
Input
DC Input Voltage Range 37 – 59.5V
Output
DC Output Voltage Range 43 – 57.5V
Nominal: 2.0kW 48V DC, 42Amp (APR48-ES)
DC Output Power* LVD†: 1.72kW 41V DC, 42Amp (APR48-ES)
* Assumes two rectifiers fitted with one used for redundancy and battery recharge. † Low Voltage Disconnect point (example voltage)
System
Load Load Outputs: 6
e-Fuse rating: 5-25Amp each (1Amp steps) *1
*1 300Amp max fault, 10kA thermal inline fuse
Each pair of output leads must be less than 3m long or 4uH in inductance. Maximum non-current limited load capacitance that any output will start into
is 10uF with a minimum ESR of50mR at the end of 0.5m 2.5mm2 leads.
Load Battery Inputs: 2
e-Fuse rating: 10-50Amp each (1Amp steps)*2
*2 550Amp max fault, 10kA thermal inline fuse Maximum 200AH string per connection. Battery connection leads shall be less than 3m long or 4uH in inductance
Battery/Load Disconnect LVD and PLD
Communication
Physical 100BaseT Ethernet
Communications TCP/IP, https, SNMP, and on board web server
System Inputs Temperature (battery)
User Display 128*32 Dot matrix display
Indicators General: Power on, no alarms. Active alarm Load/Battery: On, Pending, Tripped
Keypad 5-way navigation control
Input / Output
Digital Inputs 5 x TTL level compatible inputs, all common return.
2 x inputs can be configured as 0 to +10V analogue
input, or 0 to -60VDC for battery midpoint.
3 x inputs can be configured as digital input /output.
Digital Outputs 5 x relays (2 x isolated commons), all normally open
Datalogging
Event Log 10,000 lines
Data Log 10,000 lines
Energy Log 10,000 lines
Environmental
Operating Rated: -10°C to +65°C [14°F to +149°F]
Temperature Extended*: -25°C to +70°C [-13°F to +158°F]
Range *Output current from the rectifiers is derated above 50°C
Mechanical
Dimensions 42mm [1.65”], 3U: 133mm [5.25”], 266mm [10.45”] overall
H,W,D
Weight 1kg
Software
DU-X-GUI Configuration file software.
System
Compatible RM3-440-0120
Systems - 1x DU-X, space for 2x APR48-ES rectifiers - 335mm deep*3, 19” mounting, 1U high
- 2 x AC blunt cords (no plug) - CE and UL compliant
RM3-440-0620
- 1x DU-X, space for 2x APR48-ES rectifiers - 335mm deep*3, 19” mounting, 1U high
- 2 x IEC320 AC sockets - CE and UL compliant
RM3-340-0120
- 1x DU-X, space for 2x APR48-ES rectifiers 300mm deep*4, 19” mounting, 1U high
- 2 x AC blunt cords (no plug) - CE compliant
*3 Additional rear space is required for exhaust air. *4 Additional vertical space is required for exhaust air.
Certifications
All products comply with North America – UL Recognised (Canada, USA), FCC,
International Standards. Europe CE
Australia and New Zealand RCM
EATON DC Product Catalogue 7
Enterprise power solutions - EPS2 series
The Eaton® Enterprise Power Solutions are the ideal solution
for converged data networks and low power telecommunications
applications requiring compact, efficient and flexible DC power
supplies.
This EPS2 series is a 19” rack mounted system and is available
with up to two of the Eaton Enterprise or Access 48V rectifier
modules providing a total output of up to 4000W. The versatile
SC300 system controller features a front access USB port for
ease of system setup along with a RS232 rear port and a 100BaseT
Ethernet port for remote networking and communications.
Communication features of the SC300 system controller include
TCP/IP, SNMP and an onboard web server allowing access with
standard web browsers.
The Enterprise systems include an integral DC distribution panel
with easy to fit push-in circuit breakers and low voltage disconnect
contactor to prevent over discharging of the optional backup
batteries.
Typical applications include providing secure power for customer
premises equipment, roadside cabinets, converged VoIP/data
networks, PoE, IP routers and small cellular sites.
Features
19” rack mounting
High power density
Intelligent system controls
Pre-configured software
Onboard secure web server
Push-in easy to fit circuit breakers
Low voltage disconnect
Fast on-line expansion of rectifiers (hot-swap)
High efficiency and unity power factor
Easy to use menu & full color display
Optional batteries
Compatible with Eaton’s Energy Saver (ES) rectifier
Compatible with sealed lead acid/lithium batteries
Technical specifications
Input
Nominal: 120V, 240V
AC Supply
Operating Range: 90V – 275V
Power Factor † >0.99 (50 – 100% Output Current)
>96% peak
Efficiency †
>95% (20% to 100% load, 230Vac)
Output
DC Output Voltage Range 43 – 57.5V
APR48-ES: 4.0kW
240V AC: APR48-3G: 3.6kW
EPR48-3G: 1.8kW
DC Output Power (maximum*) †
APR48-ES: 2.3kW
120V AC: APR48-3G: 2.2kW
EPR48-3G: 1.1kW
* Based on two rectifiers fitted, refer to rectifier data sheets.
Environmental
Rated: -10°C to +50°C [-14°F to +122°F]
Operating Temperature Range
Extended*: -40°C to +70°C [-40°F to +158°F]
*Output current is derated above 50°C [122°F]
8 EATON DC Product Catalogue
Mechanical
Dimensions (H,W,D) 2U , 19” mounting, 14.1” [360mm]*
* Additional clear depth space is required for exhaust air.
System
System Controller SC300
DC Distribution Module 12-way circuit breakers (2 x Battery, 10 x Load) Circuit breaker type: Magnetic/Hydraulic, push fit
Battery circuit breakers: Heinemann AC1R Series Typical ranges available: 30A, 40A, 50A, 60A, 70A
Load circuit Breakers: Heinemann JC1S Series Typical ranges available: 6A,10A, 15A, 20A, 25A, 30A
Rectifier Blank Panels For unused rectifier positions
Communications Interfaces
Physical Ethernet (100BaseT), Micro USB (type AB), RS-485 and RS-232
Software IPV4, http, https (secure web), S3P, Modbus, SMTP (email), SNMP V1, V2c, V3 DHCP and Auto IP
Software
Configuration software.
DCTools
Free download from Eaton.com website
Visual Power Manager Remote control and monitoring software
Options
Battery* Eaton Extended Battery Module (EBM) 5PX version - 5PXEBM48RT (available globally) 5130 version - 103006587-6591
(EMEA only)Weight: 29.5kg [65lb] Dimensions (H,W,D*): 85mm (2U), 432mm (19” mounting), 487mm
*Additional space is required at the rear for cables. Typical Run time values* (see graph).
*Battery times are approximate and vary depending on factors such as:
- load configuration
- battery charge
- battery age and temperature.
* Other battery options available - consult your localEaton agent.
CKBATT-02 Eaton EBM 5130 connection cable, 2000mm long
Battery Cables OR
CKBATT-01 ‘other batteries’ connection cable,2000mm long
Equipment Cable Customer Equipment Connection Cable CKLOAD-00 10-way connection loom, 1000mm long
EBM Rack Mounting Kit Included with the EBM as standard
Certifications
All products comply with International Standards.
North America UL (Canada, USA), FCC Class B
Europe CE
Australia and New Zealand RCM
† Power factor, efficiency and DC output power are dependant on rectifier model fitted. Refer to the rectifier data sheet for further details.
EATON DC Product Catalogue 9
Access power solutions - APS3 & APS6 series
24V and 48V secure DC power up to 8.64kW and 12kW
respectively
The Eaton® Access Power Solutions are ideal for low to
medium power telecommunications applications, offering compact,
efficient, flexible and reliable secure DC power supply.
These 19” rack mount systems are available with up to 3 or 6 of
the Eaton 3G Access power rectifier modules as either 24V or 48V
with output up to 280A. For superior operating efficiency to further
reduce operating costs, these systems are also compatible with
Eaton Energy Saver (ES) Access power rectifiers which provides
operating efficiency in excess of 96%.
The systems include an integral DC distribution panel with a range
of MCB and Low Voltage Disconnect (LVD) options available. The
SC300 series of system controller offers highly advance control and
monitoring features including Smart Alarms – a configurable logic
for automated site energy control.
The SC300 also offers a complete array of communications options
with Ethernet, 4G/5G cellular (including text messaging), standard
modem and TCP/IP communications options.
Typical applications include providing secure power for customer
premises equipment, roadside terminals, data networks and IP
routers. The Access Power Solutions are pre-configured and
all system settings are fully adjustable in software and stored in
transferable, configuration files for repeatable and quick one step
system set-up.
Features
19” sub-rack
Modular 3U and 6U options
Up to 6 rectifier modules
Pre-configured software
High power density (24/48V: 300/250A, 6U, 19”)
Multiple AC option (1Ø, 3Ø, 2Ø)
Fast on-line expansion of rectifiers (hot-swap)
High efficiency and unity power factor
Priority and non priority options for DC distributions
Compatible with Eaton Energy Saver (ES) Rectifiers
Compatible with sealed lead acid/lithium batteries
10 EATON DC Product CatalogueTechnical specifications
Input
100 – 240V, 50 – 60Hz (nominal)
AC Supply† 175 – 275V full power output up to 50°C [122°F]
90 – 175V reduced power output
>0.99 (50 – 100% Output Current)
APR48-3G : 92% (50 – 100% Output Current)
Power Factor† Efficiency†
APR48-ES : >96% peak,
>95% (20% to 100% load, 230Vac)
Output
DC Output Voltage Range 21.5V – 32V / 43-57.5V
48V: 6.00kW
DC Output Power (maximum)* APS3-300
24V: 4.32kW
APS6-300 48V: 8.90kW
48V: 12.0kW
APS6-500
24V: 8.64kW
* Ratings are stated without LVD’s fitted. In some cases lower ratings may result when LVDs are used. Refer to
installation guide for detailed load specs and MCB derating factors.
Environmental
Operating Temperature -40°C to +70°C [-40°F to +158°F]
* Refer to rectifier data sheet for more information. Output current is derated above 50°C [122°F] and below -10°C
Range*
[14°F]
Mechanical
APS3-300: 3U, 19” mounting, 315mm [12.4”]*
Dimensions H,W,D APS6-300: 6U, 19” mounting, 335mm [13.2”]*
APS6-500: 6U, 19” mounting, 335mm [13.2”]*
* Additional clear space is required for exhaust air.
System
System Controller SC300
APS3-300: 12-way circuit breakers (2 x battery, 10 x load)
DC Distribution Module APS6-300: 20-way circuit breakers (4 x battery, 16 x load)
APS6-500: 20-way circuit breakers (4 x battery, 16 x load)
APS3-300: optional battery LVD
Low Voltage Disconnect (LVD) APS6-300: optional 200A LVD’s for battery or load, or both.
APS6-500: optional 400A LVD’s for battery or load, or both.
Rectifier Blank Panels For unused rectifier positions
Options External Surge Protection
Communications Interfaces
Physical Ethernet (100BaseT), Micro USB (type AB), RS-485 and RS-232
Software IPV4, http, https (secure web), S3P, Modbus, SMTP (email), SNMP V1, V2c, V3 DHCP and Auto IP
Software
DCTools Free download from Eaton.com website
Visual Power Manager Remote control and monitoring software
Certifications All products comply with international standards.
† Power factor, efficiency, AC voltage range and output power is dependant on rectifier module fitted. Refer to the rectifier data sheet
for more information.
EATON DC Product Catalogue 11Access power solutions - APS6-600 Series
48V secure DC power up to 18kW.
The Eaton® Access Power Solutions are ideal for low to
medium power telecommunications applications, offering compact,
efficient, flexible and reliable secure DC power supply.
This 19” rack mount system is available with up to 6 of the Eaton,
NPR48-ES Network power rectifier modules with a total output
up to 360A. For superior operating efficiency to further reduce
operating costs, this system is offered as standard with
Eaton Energy Saver (ES) Network power rectifier which provides
operating efficiency in excess of 96%.
The systems include an integral DC distribution panel with a range
of MCB and Low Voltage Disconnect (LVD) options available.
The SC300 series of system controller offers highly advanced control
and monitoring features including Smart Alarms – a configurable
logic for automated site energy control. The SC300 also offers a
complete array of communications options with Ethernet, LTE/4G/5G,
cellular (including text messaging), standard modem and TCP/IP
communications options
Typical applications include providing secure power for customer
premises equipment, roadside terminals, data networks and IP
routers. The Access Power Solutions are pre-configured and
all system settings are fully adjustable in software and stored in
transferable configuration files for repeatable and quick one step
system set-up.
Features
19” sub-rack
Compact 6U system
Up to 6 rectifier modules
Pre-configured software
High power density (48V: 360A, 6U, 19”)
Multiple AC option (1Ø, 3Ø, 2Ø)
Fast on-line expansion of rectifiers (hot-swap)
High efficiency and unity power factor
Priority and non priority options for DC distributions
Compatible with Eaton’s Network Energy Saver (ES) Rectifier
Compatible with sealed lead acid/lithium batteries
12 EATON DC Product CatalogueTechnical specifications
Input
AC Supply† 100 – 240V, 50 – 60Hz (nominal) 185 – 275V full power output up to 50°C [122°F] 90 – 185V reduced power output
Power Factor† >0.99 (50 – 100% Output Current)
Efficiency† NPR48-ES : >96% peak, >95% (20% to 100% load, 230Vac)
Output
DC Output Voltage Range 43.2-57.5V
48V: 18kW * Ratings are stated without LVDs fitted. In some cases lower ratings may result when LVDs are used.
DC Output Power (maximum)* Refer to installation guide for detailed load specs and MCB derating factors.
Environmental
-40°C to +70°C [-40°F to +158°F] * Refer to rectifier data sheet for more information. Output current is derated above
Operating Temperature Range*
50°C [122°F] and below -10°C [14°F]
Mechanical
Dimensions H,W,D 6U, 19” mounting, 335mm [13.2”]* * Additional clear space is required for exhaust air.
System
System Controller SC300
DC Distribution Module 20-way circuit breakers (4 x battery, 16 x load)
Low Voltage Disconnect (LVD) Optional 400A LVDs for battery or load, or both.
Rectifier Blank Panels For unused rectifier positions
Options External Surge Protection
Communications Interfaces
Physical Ethernet (100BaseT), Micro USB (type AB), RS-485 and RS-232
Software IPV4, http, https (secure web), S3P, Modbus, SMTP (email), SNMP V1, V2c, V3 DHCP and Auto IP
Software
DCTools Free download from Eaton.com website
Visual Power Manager Remote control and monitoring software
Certifications CE
† Power factor, efficiency, AC voltage range and output power are dependent on the rectifier module. Refer to the rectifier data sheet
for more information.
EATON DC Product Catalogue 13Access power solutions - APS12 Series
48V secure DC power up to 17.2kW.
The Eaton® Access Power Solutions are ideal for low to
medium power telecommunications applications, offering compact,
efficient, flexible and reliably secure DC power supply.
This 19” rack mount system has an integrated distribution panel
and is available with up to 12 of the 48V Eaton 3G Access Power
Rectifier modules or, for superior operating efficiency, with Energy
Saver (ES) Rectifier modules with output up to 360A.
The advanced SC300 system controller offers high-level
communications capability for real time information. It also
has built-in intelligence for optimising system efficiency, and
comprehensive alarm and system status notifications, which are all
designed to minimise operational expenses.
A comprehensive range of other controller features ensures
maximum battery life and optimum system performance under
a wide range of environmental conditions. The Access Power
Solutions are pre-configured and all system settings are fully
adjustable in software and stored in transferable, configuration files
for repeatable and quick one-step system set-up.
Typical applications include providing secure power for cellular base
stations, roadside terminals, data networks and IP routers.
Features
Compact 9U, 19” sub-rack
Up to 12 rectifier modules
Compatible with Eaton Energy Saver (ES) Rectifiers
Pre-configured software
High power density (400A/9U)
Dual AC input
Fast on-line expansion of rectifiers (hot-swap)
High efficiency and unity power factor
Priority and non priority options for DC distributions
Compatible with sealed lead acid/lithium batteries
14 EATON DC Product CatalogueTechnical specifications
Input
100 – 240V, 50 – 60Hz (nominal) 175 – 275V full power output up to 50°C [122°F] 90 – 175V reduced power output
AC Supply†
Dual AC input -1Ø, 2Ø or 3Ø (one supply feed per 6-rectifier shelf)
Power Factor† >0.99 (50 – 100% Output Current)
Efficiency† APR48-3G : 92% (50 – 100% Output Current) APR48-ES : >96% peak >95% (20% to 100% load, 230Vac)
Output
DC Output Voltage Range 43 – 57.5V
APR48-3G : 17.2kW @ 48V APR48-ES : 17.2kW @ 48V * Ratings are stated without LVD’s fitted. In some cases lower
DC Output Power (maximum) *
ratings may result when LVDs are used. Refer to installation guide for detailed load specs and MCB de-rating factors.
Environmental
Operating Temperature Range -40°C to +70°C [-40°F to +158°F] Output current is derated above 40°C [104°F] and below -10°C [14°F]
Mechanical
Dimensions H,W,D 9U, 19” mounting, 335mm [12.4”]* * Additional clear space is required for exhaust air.
System
System Controller SC300
DC Distribution Module 20-way circuit breakers (4 x Battery, 16 x Load)
Low Voltage Disconnect (LVD) Optional battery LVD, or non priority LVD, or battery and non priority LVD’s. (Contactors 400A rated)
Rectifier Blank Panels For unused rectifier positions
Options External Surge Protection
Communications Interfaces
Physical Ethernet (100BaseT), Micro USB (type AB), RS-485 and RS-232
Software IPV4, http, https (secure web), S3P, Modbus, SMTP (email), SNMP V1, V2c, V3 DHCP and Auto IP
Software
DCTools Free download from Eaton.com website
Visual Power Manager Remote control and monitoring software
Certifications
All products comply with international standards. Contact your local Eaton DC representative for details on the specific product versions available with
these safety and EMC approvals:
Europe CE
Australia / New Zealand C-tick
† Power factor, efficiency, AC voltage range and output power is dependant on rectifier module fitted. Refer to the rectifier data sheet
for more information.
EATON DC Product Catalogue 15Wall mount power solution - WMPS2
48V secure DC power up to 2.0kW. 24V secure DC power up to 1.4kW
The Eaton® Wall Mount Power Solution is ideal for low power telecommunications
and industrial applications, offering compact, efficient, and reliable secure DC
power supply.
The WMPS2 can have either Sealed Lead-Acid or Lithium batteries added to produce a
fully battery backed DC-UPS. These systems are available with up to two of the Eaton 3G
Access power rectifier modules of 48V or 24V. Typically one rectifier module is used for
load and battery recharge, whilst the second module if fitted is for redundancy.
For superior operating efficiency to further reduce operating costs, these systems are
also compatible with Eaton Energy Saver (ES) 48V Access power rectifiers which provides
operating efficiency in excess of 96%.
The systems includes the SC300 system controller and an integral IOB-GP control board.
The DC distribution breakers are monitored for tripping, and an optional temperature
compensation sensor is available for temperature based charging control. The system
includes an integrated earth fault detector for situations where a fully floating DC supply
is required.
The SC300 system controller offers highly advance control and monitoring features
including Smart Alarms – a configurable logic for automated site energy control. The
SC300 also offers a complete array of communications options with Ethernet, LTG/4G/5G
cellular (including text messaging), standard modem and TCP/IP communications options.
Typical applications for the WMPS2 include providing secure power backup for Industrial
Switch Boards, SCADA Systems, Telecom Customer Premises equipment, Data Networks
and IP routers.
The Wall Mount Power Solutions are pre-configured and all system settings are fully
adjustable in software and stored in transferable, configuration files for repeatable and
quick one-step system set-up.
Features
Low profile wall / surface mount cabinet
24Vdc or 48Vdc output
Up to 2 rectifier modules
1+1 redundancy option
Fast on-line replacement of rectifiers (hotswap)
Pre-configured software
Remote monitoring & control options via Ethernet, RS232 (TCP/IP or Modbus), and
voltage free relay contacts
Double pole load & battery circuit breakers
AC input circuit breaker and surge diverter
Floating output with earth fault detector
Site monitoring via digital and analogue I/O
Site & Power monitoring options via Power Manager2 and DC Tools software packages
Compatible with Eaton Energy Saver (ES) rectifiers
Compatible with sealed lead acid/lithium batteries
16 EATON DC Product CatalogueTechnical specifications
Input
100 – 240V, 50 – 60Hz (nominal)
AC Supply† 175 – 275V full power output up to 50°C [122°F]
90 – 175V reduced power output
Power Factor† >0.99 (50 – 100% Output Current)
APR48-3G : 92% (50 – 100% Output Current)
Efficiency† APR48-ES : >96% peak,
>95% (20% to 100% load, 230Vac) APR24-3G : 89% (50 – 100% Output Current)
AC Connection 1 * single phase, hardwired to terminal blocks/CB.
Output
DC Output Voltage Range 21.5-32V 43-57.5V
DC Output Power (maximum)* 24V: 0.96kW (40A) 48V: 2.00kW (42A)
* Total load capacity (not including redundancy)
Environmental
-40°C to +70°C [-40°F to +158°F] * Refer to rectifier data sheet for more information. Output current is derated above
Operating Temperature Range*
50°C [122°F] and below -10°C [14°F]
Mechanical
Dimensions H,W,D 610mm, 350mm, 104mm * Additional clear space is required for exhaust air & AC/DC cables.
IP Protection IP21 Protection from falling water droplets.
System
System Controller SC300
DC Distribution Module load:battery:
Battery Shunt 1*100A
Communications Interfaces
Physical Ethernet (100BaseT), Micro USB (type AB), RS-485 and RS-232
Software IPV4, http, https (secure web), S3P, Modbus, SMTP (email), SNMP V1, V2c, V3 DHCP and Auto IP
Input/Output Standard
Current Sensor (1) Bus Voltage (1) Temperature (1)
Analogue Inputs
Battery Midpoint Voltage (4) with optional sens0r cable
Digital Inputs Internal (4) pre-defined, External (6) user-defined
Digital Outputs (6) Voltage free, no-c-nc 0.1A @ 60VDC Screwless terminal block, 0.5mm2 – 2.0mm2
Additional I/O With optional IOB-SS expansion board.
Software
DCTools Free download from Eaton.com website
Visual Power Manager Remote control and monitoring software
Certifications All products comply with international standards.
† Power factor, efficiency, AC voltage range and output power is dependant on rectifier module fitted. Refer to the rectifier data sheet
for more information.
EATON DC Product Catalogue 17Access power solutions with batteries - DV2
48V and 24V integrated systems up to 20kW
The Eaton® Data-Voice-Video Access Power Solutions range of DC power
systems is designed to provide small to medium network applications with
compact, efficient, flexible and secure DC power.
These DC power systems can accommodate either the 24V or 48V rectifier
modules, including Eaton’s Energy Saver Rectifiers, and up to eight 24V or four
48V strings of high capacity VRLA batteries. All systems include an integral AC
and DC distribution with flexible combinations of fuses and MCBs, and an SC300
or SC300 system controller. Low Voltage Disconnect (LVD) options are
also available.
The advanced SC300 system controller offers high-level communications
capability for real time information. It also has built-in intelligence for optimising
system efficiency, and comprehensive alarm and system status notifications,
which are all designed to minimise operational expenses.
A comprehensive range of other controller features ensures maximum battery
life and optimum system performance under a wide range of environmental
conditions. Systems are pre-configured for fast installation and set-up and fully
adjustable and transferable for repeatable one-step system set-up.
Applications are providing secure power for cellular base transceiver stations,
WiMAX nodes, base station controllers, long-distance transmission systems,
local office switches and other telecommunication switch installations requiring
distributed power.
Typical Applications for the DV2 include Wireless BTS sites (LTE/4G/5G),
Transmission terminals, Access nodes and Local and central office switching.
Features
Intelligent system management features
Pre-configured software
High power density
Fast on-line expansion of rectifiers (hot-swap)
High efficiency and unity power factor
Range of DC distribution configurations
Integrated batteries and battery condition monitoring
Wide AC input voltage range
Seismic rated cabinet
Remote monitoring and control
Full length security door (optional)
Compatible with Eaton Energy Saver (ES) Rectifiers
Compatible with sealed lead acid/lithium batteries
18 EATON DC Product CatalogueTechnical specifications
Input
AC Supply† 3P+N+PE, 3P+PE, 2P+PE, 1P+N+PE 50/60Hz (nominal)
Power Factor† >0.99 (20 – 100% Maximum System Current)
Efficiency† >96% peak >95% (20% to 100% load, 230Vac)
Output
DC Output Voltage Range 20 – 57.5V
APR24-3G : 14.4kW (500A @ 28.8V) † or APR48-3G : 18 kW (375A @ 48V) APR48-ES : 20kW (416A @ 48V) * Ratings
Typical DC Output Power†*
are stated without LVD’s fitted. In some cases lower ratings may result when LVDs are used.
Environmental
Operating Temperature Range* -25°C to +50°C * Output current is derated above 50°C [122°F] Refer to rectifier data sheet for more information.
Mechanical
Dimensions H,W,D 2000mm [78.7”], 600mm [23.6”], 600mm [23.6”]
Weight 870kg [1914lb] Typical maximum with 10 rectifier modules and 4 x 48V/150Ah battery strings.
System
Rectifiers APR24-3G APR48-3G APR48-ES
System Controller SC300
Batteries Typically up to 4 strings @ 48V, or 8 strings @ 24V, 600Ah total capacity. Other battery configurations available.
Communications Interfaces
Physical Ethernet (100BaseT), Micro USB (type AB), RS-485 and RS-232
Software IPV4, http, https (secure web), S3P, Modbus, SMTP (email), SNMP V1, V2c, V3 DHCP and Auto IP
Options
Coordinated transient protection up to 40kA, 8/20ìs Incoming isolator
AC Distribution
Individual rectifier MCBs
Up to 4 groups of MCBs or fuses. Each group comprises up to:
9 x 18mm MCBs (1-63A),
DC Distribution
or 6 x 27mm MCBs (10-125A),
or 4 x DIN00 HRC fuses (20-160A) Custom options available on request.
Low Voltage Disconnect (LVD) Single or dual LVD configured as battery disconnect.
Rectifier Blank Panels For unused rectifier positions
SiteSure Input/output modules to monitor and control external equipment
CellSure Comprehensive battery monitoring and fault diagnosis system with patented state-of-health algorithms.
Software
Visual Power Manager Remote control and monitoring software
DCTools Free download from Eaton.com website
Certifications
All products comply with International Standards. Contact your local Eaton DC representative for details on the specific product versions available with
these safety and EMC approvals:
Europe CE
Australia / New Zealand C-tick, Seismic rating to NZS4203
† Power factor, efficiency, AC voltage range and output power is dependant on rectifier module fitted. Refer to the rectifier data sheet
for more information.
EATON DC Product Catalogue 19Small power system with batteries - DV2-APS6
48V integrated system up to 12kW*
The Eaton® Data-Voice-Video (APS6) Access Power Solution DC power system is
designed to provide small to medium network applications with compact,
efficient, flexible and secure DC power.
These DC power systems can accommodate up to six 48V rectifier modules,
including Eaton’s Energy Saver Rectifiers, and up to four 48V strings of high
capacity VRLA batteries. As an example 3.2kW can be supported by 4 strings
of batteries for 8 hours backup. The systems include integral AC and DC
distributions with a standard combination of load MCBs, battery MCB’s, and
an SC300 system controller. A 200A Battery Low Voltage Disconnect (LVD) and
Temperature Compensation Sensor is included as standard.
The advanced SC300 system controller offers high-level communications
capability for real time information. It also has builtin intelligence for optimising
system efficiency, and comprehensive alarm and system status notifications,
which are all designed to minimise operational expenses.
A comprehensive range of other controller features ensures maximum battery
life and optimum system performance under a wide range of environmental
conditions. Systems are pre-configured for fast installation and set-up and fully
adjustable and transferable for repeatable one-step system set-up.
Applications are providing secure DC power for cellular base transceiver stations,
WiMAX nodes, base station controllers, long-distance transmission systems,
local office and private switches and industrial plants.
Typical Applications for the DV2-APS6 include Wireless BTS sites (LTE/4G/5G),
Transmission and radio terminals, Fibre Access Nodes, Local and central
office switching, Industrial DC plants and Rail Communications
Features
Intelligent system management features
Pre-configured software
High power density
Fast on-line expansion of rectifiers (hot-swap)
High efficiency and unity power factor
Integrated DC & AC distribution
Integrated batteries and battery condition monitoring
Battery Low Voltage Disconnect & Temperature Compensation
Wide AC input voltage range
Remote monitoring and control
Full length security door (optional self-fit kit)
Compatible with Eaton Energy Saver (ES) Rectifiers
Compatible with sealed lead acid/lithium batteries
20 EATON DC Product CatalogueTechnical specifications
Input
AC Supply† 3P+N+PE, 50/60Hz (nominal)
Power Factor† >0.99 (20 – 100% Maximum System Current)
>96% peak
Efficiency† >95% (20% to 100% load, 230Vac)
>91% (for APR48-3G rectifies)
Output
DC Output Voltage Range 43 – 57.5V
APR48-3G : 10.8 kW (225A @ 48V)
APR48-ES : 12kW (250A @ 48V)
DC Output Power†*
Typical maximum DC load output is 9.7kW (180A) with 6 x APR48-3G rectifiers and allowing for battery recharge and
four battery strings connected.
* Ratings are stated with LVD bypassed. Maximum load current through LVD is limited to 200A.
Environmental
Operating Temperature Range* -25°C to +50°C
* Output current is derated above 50°C [122°F] Refer to rectifier data sheet for more information.
Mechanical
Dimensions H,W,D 2140mm, 600mm, 600mm
Weight 880kg Typical maximum with 6 rectifier modules and 4 x 48V/150Ah battery strings.
System
Rectifiers APR48-3G
APR48-ES
System Controller SC300
Typically up to 4 strings @ 48V 600Ah total capacity. Other battery configurations available. 4 battery trays and cabling
Batteries
included.
Communications Interfaces
Physical Ethernet (100BaseT), Micro USB (type AB), RS-485 and RS-232
Software IPV4, http, https (secure web), S3P, Modbus, SMTP (email), SNMP V1, V2c, V3 DHCP and Auto IP
Distribution
AC Distribution Incoming 3P rectifier MCB /isolator(40A D curve) AC to be hardwired to MCB & terminals
15 MCB’s fitted
5 x 18mm MCBs (10A), for loads
DC Distribution 5 x 18mm MCBs (20A), for loads
1 x 18mm MCBs (63A), for loads
4 x 18mm MCBs (63A) + auxiliary, for batteries
Low Voltage Disconnect (LVD) Single 200A LVD configured as battery disconnect.
Rectifier Blank Panels For unused rectifier positions, 4 off
Options
SiteSure Optional Input/output modules can be added to monitor and control external equipment
Battery Mid Point Optional battery mid point monitoring loom can be added to warn of premature cell failure.
Lockable Door Optional lockable solid door kit is available for user fitment.
Software
Visual Power Manager Optional Remote control and monitoring software
DCTools Free download from Eaton.com website
Certifications
All products comply with International Standards. Contact your local Eaton DC representative for details on the specific product versions available with
these safety and EMC approvals:
Europe CE
Australia / New Zealand C-tick
† Power factor, efficiency, AC voltage range and output power is dependant on rectifier module fitted. Refer to the rectifier data sheet
for more information.
EATON DC Product Catalogue 21Metro power solutions - DV2
48V integrated system up to 80kW*
The Eaton® Data-Voice-Video Metro Power Solutions range of DC power systems
is designed for telecommunications network applications requiring compact,
efficient and flexible DC power.
These DC power systems use Eaton APR-3G or, for superior operating efficiency,
can be fitted with Energy Saver (ES) rectifier modules. AC and DC distribution
is integral with flexible combinations of fuses and MCBs, and an SC300 system
controller. Low Voltage Disconnect (LVD) options are also available. The advanced
SC300 system controller offers high-level communications capability for real time
information. It also has built-in intelligence for optimising system efficiency, and
comprehensive alarm and system status notifications, which are all designed to
minimise operational expenses.
A comprehensive range of other controller features ensures maximum battery
life and optimum system performance under a wide range of environmental
conditions. Eaton DV2 Metro Power Solutions are pre-configured for fast
installation and set-up. All system settings are fully adjustable in software and
stored in transferable configuration files for repeatable one step system set-up.
Applications are providing 48V standby power for end-of-row and centralised
architecture such as local and central office switches and other large switch
installations, wireless switching centres and long-distance transmission systems.
Typical Applications for the DV2 include Wireless MSC sites (LTE/4G/5G),
Transmission terminals Local and central office switching and Point of
presence (POP) sites
Features
Intelligent system management features
Pre-configured software
High power density
Fast on-line expansion of rectifiers (hot-swap)
High efficiency and unity power factor
Range of DC distribution configurations
Battery condition monitoring
Wide AC input voltage range
Seismic rated cabinet
Remote monitoring and control
Full length security door (optional)
Compatible with Eaton Energy Saver (ES) Rectifiers
Compatible with sealed lead acid/lithium batteries
22 EATON DC Product CatalogueTechnical specifications
Input
AC Supply† 3P+N+PE, 3P+PE, 2P+PE, 1P+N+PE 50/60Hz (nominal) Other options available depending on system capacity.
Power Factor† >0.99 (20 – 100% Maximum System Current)
Efficiency† >96% peak >95% (20% to 100% load, 230Vac)
Output
DC Output Voltage Range 40 – 57.5V
APR48-3G : 72kW (1500A @ 48V) APR48-ES : 80kW (1667A @ 48V) * Ratings are stated without LVD’s fitted. In some
Typical DC Output Power†*
cases lower ratings may result when LVDs are used.
Environmental
Operating Temperature Range* -25°C to +50°C * Output current is derated above 50°C [122°F]. Refer to rectifier data sheet for more information.
Mechanical
Dimensions H,W,D 2000mm [78.7”], 600mm [23.6”], 600mm [23.6”]
Weight 200kg [443lb] Typical configuration with 40 APR-3G rectifier modules.
System
Rectifiers APR48-3G APR48-ES
System Controller SC300
Communications Interfaces
Physical Ethernet (100BaseT), Micro USB (type AB), RS-485 and RS-232
Software IPV4, http, https (secure web), S3P, Modbus, SMTP (email), SNMP V1, V2c, V3 DHCP and Auto IP
Options
AC Distribution Coordinated transient protection up to 40kA, 8/20ìs Incoming isolator Individual rectifier MCBs
A wide range of DC distribution elements are available including:
24 x 18mm MCBs (1-63A) 1
6 x 27mm MCBs (10-125A)
10 x DIN00 type HRC fuses (20-160A)
DC Distribution
6 x DIN1 type HRC fuses (63-250A)
6 x DIN2 type HRC fuses (100-400A)
4 x DIN3 type HRC fuses (400-630A)
4 x DIN4 type HRC fuses (800-1200A)
Low Voltage Disconnect (LVD) Single or dual LVD can be configured as battery or load disconnect including non-priority load disconnect.
Rectifier Blank Panels For unused rectifier positions
SiteSure Input/output modules to monitor and control external equipment
CellSure Comprehensive battery monitoring and fault diagnosis system with patented state-of-health algorithms.
Software
Visual Power Manager Remote control and monitoring software
DCTools Free download from Eaton.com website
Certifications
All products comply with International Standards. Contact your local Eaton DC representative for details on the specific product versions available with
these safety and EMC approvals:
Europe CE
Australia / New Zealand C-tick, Seismic rating to NZS4203
† Power factor, efficiency, AC voltage range and output power is dependant on rectifier module fitted. Refer to the rectifier data sheet
for more information.
EATON DC Product Catalogue 23Metro power solutions extension
battery cabinet - DV2
48Vdc : 4 strings | 24Vdc : 8 strings
Eaton Metro Power Solutions are ideal for low to medium power
telecommunications applications requiring compact, efficient and flexible DC
power. Typical applications include standby DC power for customer premises
equipment, outdoor shelters, VoIP, data networks and IP routers.
The Extension Battery cabinet allows customers to easily configure and install
additional battery back-up time for critical telecom and IT equipment. Up to six
Extension Battery Cabinets can be installed in addition to the DV2 Metro cabinet.
This gives a total battery capacity of up to 4200Ahr in 48Vdc solutions, or 8400Ahr
in 24Vdc solutions.
The Extension Battery Cabinet can be fitted with an optional DC Distribution,
extending the number of output circuits available from the power cabinet. These
distributions utilise easy fit, din mount and plug-in hydraulic magnetic circuit breakers.
When connected back to a DV2 Metro power cabinet, features include
automatic temperature compensation, Battery MCB alarm monitoring, automatic
equalising and fast charging, and automatic battery testing.
All cable entry is top access. An optional rear cable duct extension is available to
allow cables to be run to the top of the cabinet in raised floor situations
Features
Optional DC distribution with easy fit din style MCB or plug in hydraulic-magnetic
circuit breakers.
600mm x 600mm footprint cabinet
4 Battery Shelves
Compatible with sealed lead acid/lithium batteries
24 EATON DC Product CatalogueTechnical specifications
System Interconnections
Communications Screw terminals
Power Direct onto busbars
DC Distribution (Optional)*
Load Circuit Breakers Single
20-way total Heinemann AMIR Series 5A, 10A, 20A, 30A, 40A, 50A, 70A, 80A, 100A.
Width Circuit Breakers
Dual Width Circuit Breakers Heinemann AMIP 120A, 150A, 200A,
Triple Width Circuit Breakers Heinemann AMIP 250A,
*Power is feed to the optional DC distribution from a load circuit in the Power Cabinet. See power system documentation for more details.
Batteries*
Type Front access VRLA
48V Batteries Up to 600Ahr per cabinet using four strings of 150Ahr batteries.
24V Batteries: Up to 1200Ahr per cabinet using eight strings of 150Ahr batteries.
*Maximum of 6 battery cabinets added to the power cabinet per system. 150Ahr battery offered as standard, with smaller/larger capacities available.
Mechanical
Dimensions
2000mm [78.7”], 600mm [23.6”], 600mm [23.6”]
H, W, D
With rear cable duct extension
2000mm [78.7”], 600mm [23.6”], 750mm [29.6”]
H,W,D
Weight DV2-EBC4-xxxx: 850kg [1870lb]. Typical maximum with 4 x 48V/150Ah battery strings.
Operating Temperature Range -25°C [-13°F] to 40°C [104°F]
HumidityCore power solutions - DV2-N
48V integrated systems up to 126kW
The Eaton® Data-Voice-Video Core Power Solutions range of DC power systems
is designed for telecommunications network applications requiring compact,
efficient and flexible DC power.
These DC power systems use the Eaton Energy Saver NPR-ES rectifier module
for superior operating efficiency. AC and DC distribution is integral with flexible
combinations of fuses and MCBs, and an SC300 system controller. Low Voltage
Disconnect (LVD) options are also available. The advanced SC300 system
controller offers high-level communications capability for real time information. It
also has built-in intelligence for optimising system efficiency, and comprehensive
alarm and system status notifications, which are all designed to minimise
operational expenses.
A comprehensive range of other controller features ensures maximum battery
life and optimum system performance under a wide range of environmental
conditions. Eaton DV2 Core Power Solutions are pre-configured for fast
installation and set-up. All system settings are fully adjustable in software and
stored in transferable configuration files for repeatable one-step system set-up.
Applications are providing 48V standby power for end-of-row and centralised
architecture such as local and central office switches and other large switch
installations, wireless switching centres and long-distance transmission systems.
Typical Applications for the DV2-N include Wireless MSC sites (LTE/4G/5G),
Transmission terminals, Local and central office switching, and Point of
presence (POP) sites
Features
Intelligent system management features
Pre-configured software
High power density
Fast on-line expansion of rectifiers (hot-swap)
High efficiency and unity power factor
Range of DC distribution configurations
Battery condition monitoring
Wide AC input voltage range
Seismic rated cabinet
Remote monitoring and control
Full length security door (optional)
Standard fitment of the Eaton Energy Saver (ES) Rectifier
Compatible with sealed lead acid/lithium batteries
26 EATON DC Product CatalogueTechnical specifications
Input
AC Supply† 3P+N+PE, 3P+PE 50/60Hz (nominal) Other options available depending on system capacity.
Power Factor† >0.99 (20 – 100% Maximum System Current)
Efficiency† >96% peak >95% (20% to 100% load, 230Vac)
Output
DC Output Voltage Range 43.2 – 57.5V
NPR48-ES : 126kW (2520A @ 50V) * Ratings are stated with LVDs not fitted. In some cases lower ratings may result
Typical DC Output Power†*
when LVDs are used.
Environmental
Operating Temperature Range* -25°C to +45°C * Output current is derated above 50°C [122°F]. Refer to rectifier data sheet for more information.
Mechanical
Dimensions H,W,D 2200mm [86.6”], 600mm [23.6”], 600mm [23.6”]
Weight 230kg [443lb] Typical configuration with 42 NPR-ES rectifier modules.
System
Rectifiers NPR48-ES – up to 42 rectifiers
System Controller SC300
Communications Interfaces
Physical Ethernet (100BaseT), Micro USB (type AB), RS-485 and RS-232
Software IPV4, http, https (secure web), S3P, Modbus, SMTP (email), SNMP V1, V2c, V3 DHCP and Auto IP
Options
AC Distribution Coordinated transient protection up to 40kA, 8/20ìs Incoming isolator Individual rectifier MCBs
A wide range of DC distribution elements are available including:
24 x 18mm MCBs (1-63A)
16 x 27mm MCBs (10-125A)
10 x DIN00 type HRC fuses (20-160A)
DC Distribution
6 x DIN1 type HRC fuses (63-250A)
6 x DIN2 type HRC fuses (100-400A)
4 x DIN3 type HRC fuses (400-630A)
4 x DIN4 type HRC fuses (800-1200A)
Low Voltage Disconnect (LVD) Single or dual LVD can be configured as battery or load disconnect including non-priority load disconnect.
Rectifier Blank Panels For unused rectifier positions
SiteSure Input/output modules to monitor and control external equipment
CellSure Comprehensive battery monitoring and fault diagnosis system with patented state-of-health algorithms.
Software
Visual Power Manager Remote control and monitoring software
DCTools Free download from Eaton.com website
Certifications
All products comply with International Standards. Contact your local Eaton DC representative for details on the specific product versions available with
these safety and EMC approvals:
Europe CE
Australia / New Zealand C-tick, Seismic rating to NZS4203
† Power factor, efficiency, AC voltage range and output power aredependent on the rectifier module. Refer to the rectifier data sheet
for more information.
EATON DC Product Catalogue 27Industrial high reliability (DC/AC) UPS
The Eaton High reliability Uninterruptible Power Supplies feature
the rugged industrial design and performance Eaton High
reliability UPS range is designed to meet the toughest product
customisation requirements.
This UPS comes in variety of cabinet solutions with different
level of ingress protection up to IP55. There are various AC input
options available, single phase, three phase and neutral, 240AC,
110VAC. Multiple output voltage options, 240VAC, 110VAC,
24VDC, 48VDC, 110VDC, 120VDC. The output voltage can be
single or multiple in any combination.
The SC300 controller has an inbuilt Web server application which
allows multi-user remote access to the configuration and UPS
operating information via a Web Browser such as Microsoft’s
Internet Explorer for configuration changes and alarm analysis.
Site-specific configuration settings that need to be input to the
SC300 controller during installation are set with Eaton’s laptop
software application DCTools®.
Typical Applications:
Telecom with both 48VDC and 240V AC output
Oil & Gas (Petrochemicals Offshore, Onshore, Pipelines) with
ruggedised cabinets
Mining Rail Networks
Water (Desalination, Treatment)
Instrumentation & Process Control (Chemicals, Mining, Steel,
Paper) with 24VDC and 240VAC
Emergency Lighting
Energy & Electricity generation (Power Generation,
Transmission, Distribution) Switch tripping supply with 110VDC
and 240VAC
Features
Highly Customised
Specific mechanical protection degree
Specific input & output voltage
Multi voltage output (eg 48VDC, 24VDC, 12VDC, 110VDC, 240VAC)
Specific battery and autonomy Time
Modular AC-DC Charger / power supply
Modular DC-AC Inverter
Higher reliability, MTBF and overload capacity
Redundant inverter and DC rectifier modules.
Capability to function even in case of controller failure
In built generator control function.
Unity Power factor at rectifier input
Wide AC input
Compatible with sealed lead acid/lithium batteries
28 EATON DC Product CatalogueYou can also read
