CATCH R-22 - ACT NOW! - R-22 Refrigerant Changeover Solutions - Wilhelmsen
CATCH R-22
R-22 Refrigerant Changeover Solutions

                     The European Union phases out
                             refrigerant R-22 in 2010

                    ACT NOW!
CATCH R-22 - ACT NOW! - R-22 Refrigerant Changeover Solutions - Wilhelmsen
Regulations
“The European Union phases out
 refrigerant R-22 in 2010”

 REGULATION (EC) No 2037/2000 OF THE EUROPEAN
 PARLIAMENT AND OF THE COUNCIL of 29 June 2000 on
 substances that deplete the Ozone layer.

 Article 5
 Control of the use of hydrochlorofluorocarbons.

 Paragraph 1. (c) (v)
 From 1 January 2010, the use of virgin hydrochlorofluorocarbons shall be
 prohibited in the maintenance and servicing of refrigeration and air-conditioning
 equipment existing at that date; all hydrochlorofluorocarbons shall be prohibited
 from 1 January 2015.

 What does this mean to me?
 The above directives apply to all European Union flagged vessels. Any systems with
 Hydrochlorofluorocarbons (HCFC) refrigerants such as R-22 cannot be maintained, serviced or
 topped up with new refrigerant after January 1, 2010.

 Between that date and January 1, 2015, recycled HCFC may be used. After January 1, 2015, the
 Catch
 use of HCFCyour     R-22
             refrigerants      with prohibited
                          is completely our Changeover
                                               on European Union solution
                                                                 flagged vessels.

 World wide phase out schedule
 MONTREAL PROTOCOL Consumption and Trade restrictions for R-22 as ratified by 191 countries
 including 145 article 5 countries (figures are related to percentages of R-22 quantities from 1989).

 Year 2004 65%
 Year 2010 25%
 Year 2015 10%
 Year 2020 0.5%
 Year 2030 Complete prohibition
CATCH R-22 - ACT NOW! - R-22 Refrigerant Changeover Solutions - Wilhelmsen
Inspection

R-22 has for many years either
accidentally or deliberately been
released into the atmosphere,
causing Ozone depletion.
Our changeover solutions help
“Catch” this problem!                           Evaluation
Catch R-22 with
Wilhelmsen
Ships Service:
Well established and respected marine service
and supply company.
                                                Planning & Scheduling
Strong policy regarding safety at sea and the
environment.

Highly qualified marine refrigeration
technicians.

World wide service and support capabilities
(including flying squads).

Superior sourcing capabilities of all quality
assured spares through our strategic supply     The Changeover
network at competitive prices.

Turn-key changeover solutions including
an option for the safe and legal destruction
of the old R-22 within our Enviro Return
Management Programme.

                                                Destruction
CATCH R-22 - ACT NOW! - R-22 Refrigerant Changeover Solutions - Wilhelmsen
F.A.Q´s

Why is R-22 being phased out?
R-22 contains chlorine, which if released, damages the Ozone layer within the stratosphere. Regardless of every
effort being made to maintain leak free systems, the natural movement of a vessel’s structure always carries the
risk of pipe fractures. To cut out any possibilities of Ozone depletion, R-22 is being phased out.

What is the importance of the Ozone layer?
The Ozone layer in the stratosphere filters out the harmful effects of UV Radiation from the sun. Without this
protective Ozone layer, the following effects could be experienced:
• Possible damage to human immune systems
• Damage to marine life and phytoplankton
• Reduced crop yields
• Increased incidence of skin cancer
• Increased incidence of eye cataracts

Do I need to change my machinery to move away from R-22?
No, there are alternative refrigerants available, some of which can be used with very minor system modifications.

What are these alternatives?
Within our product range, the alternative refrigerants are Unicool R417-A and Unicool R-407C.

Which of these is the better refrigerant?
Every system has to be analysed before a replacement refrigerant is selected. However, over the last 5 years, we
have successfully changed over more than 900 systems using Unicool R-417A.

Why has Unicool R-417A been preferred over Unicool R407C?
Unicool R-417A has the following advantages:
• Similar operating pressures to R-22 so no need for change of gauges, safety valves, condenser etc
• Lower temperature glide of 5.6K compared to 7.4K of Unicool R-407C
• Lower discharge temperature leads to less possibilities of system oil decomposition
• Compatible with all oil types including mineral oil, so negates the need for a thorough and long drawn out
  process to clean out the old oil. Unicool R-407C is only compatible with ester oil.

Is Unicool R-417A the best solution?
We continuously test new products and if we find one that better meets the requirements, we would bring it into
our product range and advise our customers accordingly. At the same time, we would continue to support all
systems we have changed over so far from R-22, using the current choice of products, be it Unicool R417A,
Unicool R407C or any other.

What about price differences between Unicool R-407C and Unicool R-417A?
The prices of both our products are very close to each other.

But currently, R-22 is cheaper than the other options.
The price of R-22 is escalating now due to production caps within the European Union down to only 25% from
2008. This effect has also been seen with much higher prices in the US.
CATCH R-22 - ACT NOW! - R-22 Refrigerant Changeover Solutions - Wilhelmsen
F.A.Q´s

R-22 will be phased out in Jan 1 2010. Why change over now?
Changeover demands far exceed the available service capacity. You need to act now to avoid missing
the deadline.

How long does this changeover procedure take?
It can take between 5 and 15 days, depending upon the size and numbers of onboard systems and the amount
of system modifications required such as the installation of oil separators, suction accumulators etc.

Do we really need an oil separator and a suction accumulator?
Except in very small systems like engine control room units, an oil separator is essential for all the HFC blends.

What about ships trading between very cold and very hot sea water temperatures?
We would strongly recommend that your crew install temperature regulating valves in the water cooling circuits
for the main A/C and provision systems. This will maintain a constant head pressure which leads to a stable
system operation.

Can we do the changeover ourselves, and buy the refrigerant and equipment from you?
Yes, you can. However, the changeover result would depend entirely upon the skill of your vessel staff.
Our refrigeration technicians have carried out over 900 system changeovers during the past five years.

What about our old tonnage? It is hardly worthwhile changing over those vessels?
This is true. You are permitted to recycle the R-22 from your younger vessels and use that product on your older
vessels. The EU permits the use of recycled HCFCs until 2015.

How do we proceed with this changeover?
• Ask your vessels to complete and return the electronic questionnaire we send you
• The returned details will be analysed by our team of experts
• An evaluation of requirements for the changeover will be sent to you with a budget proposal
• We will carry out a physical inspection to verify the condition of the systems to give you a more accurate
  quotation for the changeover
• We schedule the changeover
• We complete the changeover
• We dispose of the recovered R-22 under our Enviro Return Management Scheme and issue
  the necessary certificates

If I have any further technical queries, can I come to you?
Absolutely. We will be more than happy to come in and present a changeover solution for your vessels.
CATCH R-22 - ACT NOW! - R-22 Refrigerant Changeover Solutions - Wilhelmsen
References
  A selection of customers who have trusted
  Wilhelmsen Ships Service to perform the changeover from
  R-22 to an Ozone friendly refrigerant:

Leif Höegh & Co        Scorpio Ship              Broström              OSG Ship           Eletson
                       Management                                      Management

Wallenius Marine       Goliat Shipping           Shell Intl. Trading   P&O Ferries (NS)   ImperialShipping
                                                 & Shipping

  Types of system design:
  • Direct Expansion
  • Water Chillers

  Types of systems on board:
  • Accommodation Air Conditioning Systems
  • Provision Refrigeration Systems
  • Engine Control Room A/C Units
  • Refrigerated Control Air Driers
  • Ice Machines

  Types of Compressors on board working on the
  new alternatives:
  • Hermetic
  • Semi-hermetic
  • Scroll
  • Reciprocating
  • Screw
Contact us
For further information on R-22 system changeover,
please contact your Customer Service Centre or
Account Manager:

Rotterdam                            Piraeus                         Singapore
Phone: +31 (0) 10 487 7777           Phone: +30 210 423 9100         Phone: +65 6395 4545
wss.netherlands.csc@wilhelmsen.com   wss.greece.csc@wilhelmsen.com   wss.singapore.csc@wilhelmsen.com

Dartford                             Dubai                           Houston
Phone: +44 (0) 132 228 2400          Phone: +971 4 324 8035          Phone: +1 281 867 2000
wss.uk.csc@wilhelmsen.com            wss.uae.csc@wilhelmsen.com      wss.northamerica.csc@wilhelmsen.com
Wilhelmsen Ships Service
         Mail: P O Box 33 NO-1324 Lysaker, Office: Strandveien 20, 1366 Lysaker, Norway
         Tel: +47 67 58 45 50, Fax: +47 67 58 45 70
         Internet: www.wilhelmsen.com/shipsservice
