BEST IDEAS FOR IP
INTERCOM SOLUTIONS
CATALOGUE 2018
We introduce innovative solutions - IP intercom systems.
Having chosen the direction of IP intercoms as Each of the BAS-IP Company’s IP intercoms foreground, the BAS-IP Company has successfully successfully combines a touchscreen, has created and launched the serial production of a ergonomic and straightforward control of internal wide range of equipment, from individual systems monitors, as well as anti-vandal outdoor panels. to complex solutions in a relatively short time, Since 2016, BAS-IP has been included in the meeting the requirements of the modern user. international KNX Association. As a result, the We pay particular attention to the product’s company officially develops, produces, and design, simplicity, and convenience of use, as well presents KNX-certified devices to manage your as ensuring that all devices function efficiently. smart home. The rapid growth and popularity of IP intercom systems requires the constant release of new devices. BAS-IP diligently keeps track of all the market trends, introducing new technology and producing stylish and functional devices that will suit all segments of housing – from budget to luxury.
Individual BAS-IP IP-intercom systems are an ideal solution for both ordinary
apartments and private houses. Each device allows you to connect up to
accommodation 16 IP cameras and 10 outdoor panels, as well as manage the functions of
intercom and video monitoring.
Multi apartment By combining one outdoor panel with any number of video intercoms on
the house in one system, you can manage the whole residential complex
decision with a central server or work entirely independently. The system can
operate in an existing network without disturbing its operation.
4
Office buildings The BAS-IP intercom system is installed seamlessly as it does not require
additional wiring. This system allows you to communicate with all offices
and complexes in the building, with a central control and monitoring of entries by security
remote control.
Cottage settlements BAS-IP video intercoms will not only allow communication with visitors
outdoors but also gives you the powerlet them in the house. With the
and townhouses integrated system “smart house,” you can control the light, curtains and
air conditioning. Manage your home in just a few clicks.
CATALOGUE 2018 5
BAS-IP equipment is ideal for such objects as: • Hospitals • Tourist places • Business Centers • Hotels • Shopping centers • Trails • Parking • Metro • Warehouses • Airports • Prisons • Banks • Parks • Fire station Life Republic KSL Residence Daya India Malaysia 690 apartments 1064 apartments Evian Riviera Vista Verde China Singapore 794 apartments 662 apartments 6
Hayat Seblax Dirizhabl Turkey Russia 520 apartments 444 apartments Novopecherskij Dvor D3 Ukraine Belarus 411 apartments 162 apartments Greenfield Halcyon Glades Russia Australia 127 houses 70 houses CATALOGUE 2018 7
Support for open SIP Integration into any ACS
protocol system
BAS-IP supports the open SIP 2.0 protocol due to The system supports Wiegand 26, which enables
which calls are made possible by IP telephony to the use of panels as readers (without using internal
BAS-IP devices just like any other SIP device and in controllers) and is compatible with any controllers
the opposite direction. of other ACS producers.
IP video surveillance Work in the system
“Smart Home”
The system lets you broadcast IP cameras to Support of KNX protocol provides vast opportunities
monitors and use RTSP stream from the outdoor for the use of BAS-IP monitors as the elements of the
panels for record into any IP video surveillance house control. It enables to control home automation,
system. intercom system and video surveillance from the single
device replacing multiple devices.
8Features of each monitor
Elevator
IP intercoms
control
IP video monitoring 8 dry contacts
for alarm sensor
connection
Windows Climate
control control
Smart Home
Ventilation Air conditioning
control control
Curtains 8 groups of light in
control each room
CATALOGUE 2018 9Adapter Video
intercom
Video intercom Video intercom
Network switch Network switch
Adapter
Video
intercom
Video intercom Video intercom
Audio-video
switching Analogue
Video intercom Video intercom IP audio handset
unit audio handset
Network switch Network switch
Video intercom Video intercom
IP audio handset Switching unit
Analogue
audio handset
Router
SIP PBX
Network switch Network switch
Computer
(optionally)
Concierge Outdoor 220 V Lock Lock 220 V Outdoor Exit
monitor panel Uninterruptible Uninterruptible panel button
Power Supply Power Supply
Exit
button
General connection scheme
Network cable
Internet
Signal cable
Power cable
10Outdoor panels Multi apartment outdoor panel Multi apartment outdoor panel BAS-IP AA-07 BAS-IP AA-09 Multi apartment outdoor panel Multi apartment outdoor panel BAS-IP AA-11 BAS-IP AA-12 Call station Call station BAS-IP CV-01 BAS-IP CV-02 CATALOGUE 2018 11
Outdoor panels Multi apartment outdoor panel Multi apartment outdoor panel BAS-IP BA-04 BAS-IP BA-08 Multi apartment outdoor panel Individual outdoor panel BAS-IP BA-12 BAS-IP AV-01K Individual outdoor panel Individual outdoor panel BAS-IP AV-01 BAS-IP AV-01T 12
Outdoor panels Individual outdoor panel Individual outdoor panel BAS-IP AV-02 BAS-IP AV-02T Emergency outdoor panel Emergency outdoor panel BAS-IP AV-02FP BAS-IP AV-02IC Individual outdoor panel BAS-IP AV-07T CATALOGUE 2018 13
Indoor monitors Indoor monitor Indoor monitor BAS-IP AK-10 BAS-IP AQ-07 Indoor monitor Indoor monitor BAS-IP AP-07L BAS-IP AU-04LA 14
Indoor monitors Concierge monitor Operator monitor BAS-IP AM-01 BAS-IP CM-01 The BAS-IP program software New application BAS-IP Intercom The BAS-IP SIP service - Free application for iOS and Android; - Absolutely free for all buyers of BAS-IP products; - Receive push-notifications for incoming calls; - Simple adding of BAS-IP devices into service using - Support push-notifications for alarm triggering; QR-code; - Saving photos from outdoors panel’s cameras; - User-friendly and easy, intuitive service management; - Phonebook of subscribers; - Call statistics. - Additional button to open the second lock. CATALOGUE 2018 15
BAS-IP AA-07
Multi apartment The multi apartment metal outdoor panel BAS-IP AA-07 – is the
outdoor panel perfect solution for office buildings, apartment complexes and cottage
settlements.
BAS-IP AA-07 In this model there are vandal-proof metal mechanical buttons.
Because of the button’s lighting, it will be easy to dial the number of the
apartment at night.
GENERAL PARAMETERS
Panel type Night backlight Case
Multi apartment 6 LEDs Metal
Display Light sensitivity Colors
4“ TFT, color, with backlight 0.01 Lux Silver-grey
Camera Protection class Dimensions for installation
1/3”, camera direction IP65 355×140×56 mm
adjustment/control
Operating temperature Dimensions of panel
Angle -40 – +65 0С 375×155×50 mm
80° horizontal × 64° vertical
Power consumption Installation
Resolution 6,5 W, in standby – 3,6 W Flush mount, wall mount with BR-AA
1,3 Mp
Power supply Keyboard
Output video +12 V Mechanical buttons with backlight
HD (1280×720), H.264 Main Profile,
BaseLine Profile
FUNCTIONALITY
Interface Buttons for quick dialing Talking mode
English, WEB-interface Concierge call button Duplex
Lock opening Number of ringtones Additionally
With the monitor, by code, by card 4 polyphonic ringtones SIP P2P
Built-in relay
Access control Authentication
EM-Marin or MIFARE card reader Separate password to the settings,
WEB-interface
Integration with ACS
Output WIEGAND-26
CATALOGUE 2018 17BAS-IP AA-09
Multi apartment The multi-apartment metal outdoor panel, BAS-IP AA-09, is the perfect
outdoor panel solution for office buildings, apartment complexes, and cottage
settlements.
BAS-IP AA-09 In this model, there are vandal-proof metal mechanical buttons.
The backlit buttons make it easy to dial the number of the apartment at
night.
GENERAL PARAMETERS
Panel type Night backlight Case
Multi apartment 6 LEDs Metal
Display Light sensitivity Colors
4,3“ TFT, color, with backlight 0.01 Lux Champagne + black
Camera Protection class Dimensions for installation
1/3 IP65 320×192×55 mm
Angle Operating temperature Dimensions of panel
80° horizontal × 64° vertical -40 – +65 0С 328×205×48 mm
Resolution Power consumption Installation
1,3 Мp 6,5 W, in standby – 3,6 W Flush mount
Output video Power supply Keyboard
HD (1280×720), H.264 Main Profile, +12 V Mechanical buttons
BaseLine Profile
FUNCTIONALITY
Interface Buttons for quick dialing Talking mode
English, WEB-interface Concierge call button Duplex
Lock opening Number of ringtones Additionally
With the monitor, by code, by card 4 polyphonic ringtones SIP P2P
Built-in relay
Access control Authentication
EM-Marin or MIFARE card reader Separate password to the settings,
WEB-interface
Integration with ACS
Output WIEGAND-26
CATALOGUE 2018 19BAS-IP AA-11
AA-09Multi apartment The multi-apartment metal outdoor panel, BAS-IP AA-11, is the perfect
outdoor panel solution for office buildings, apartment complexes, and cottage
settlements.
BAS-IP AA-11 This model features touch buttons. The backlit buttons make it easy to
dial the number of the apartment at night.
GENERAL PARAMETERS
Panel type Night backlight Case
Multi apartment 6 LEDs Metal
Display Light sensitivity Colors
4,3“ TFT, color, with backlight 0.01 Lux Silver + white
Camera Protection class Dimensions for installation
1/3” IP65 320×192×55 mm
Angle Operating temperature Dimensions of panel
80° horizontal × 64° vertical -40 – +65 0С 328×205×48 mm
Resolution Power consumption Installation
1,3 Мp 6,5 W, in standby – 3,6 W Flush mount
Output video Power supply Keyboard
HD (1280×720), H.264 Main Profile, +12 V Touch buttons
BaseLine Profile
FUNCTIONALITY
Interface Buttons for quick dialing Talking mode
English, WEB-interface Concierge call button Duplex
Lock opening Number of ringtones Additionally
With the monitor, by code, by card 4 polyphonic ringtones SIP P2P
Built-in relay
Access control Authentication
EM-Marin or MIFARE card reader Separate password to the settings,
WEB-interface
Integration with ACS
Output WIEGAND-26
CATALOGUE 2018 21BAS-IP АА-12
Multi apartment BAS-IP AA-12 is a multi-apartment outdoor panel. Its modern design and
outdoor panel useful features make it an ideal solution for residential complexes and
cottage settlements. A unique feature of this panel is that its entire buttons
BAS-IP АА-12 are piezoelectric.
The BAS-IP AA-12 is available in silver, gold, and black.
GENERAL PARAMETERS
Panel type Night backlight Case
Multi apartment 6 LEDs Metal
Display Light sensitivity Colors
4“ TFT, color, with backlight 0.01 Lux Gold, silver, black
Camera Protection class Dimensions of panel
1/3”, camera direction IP65 158×380×57 mm
adjustment/control
Operating temperature Installation
Angle -40 – +65 0С Flush mount, wall mount with BR-AA
80° horizontal × 64° vertical
Power consumption Keyboard
Resolution 6,5 W, in standby – 3,6 W Piezo buttons
1,3 Mp
Power supply
Output video +12 V
HD (1280×720), H.264 Main Profile,
BaseLine Profile
FUNCTIONALITY
Interface Buttons for quick dialing Talking mode
English, WEB-interface Concierge call button Duplex
Lock opening Number of ringtones Additionally
With the monitor, by code, by card 4 polyphonic ringtones SIP P2P
Built-in relay
Access control Authentication
EM-Marin or MIFARE card reader Separate password to the settings,
WEB-interface
Integration with ACS
Output WIEGAND-26
CATALOGUE 2018 23BAS-IP CV-01/BAS-IP CV-02
Call station These call stations work within the system with operator monitor, CM-01.
The ‘Call’ button dials the operator monitor and the ‘Alarm’ button sends
BAS-IP CV-01 an alarm signal to the operator monitor.
The CV-01/CV-02 can operate as a call station or an individual outdoor
BAS-IP CV-02 panel with BAS-IP monitors.
GENERAL PARAMETERS
Panel type Light sensitivity Colors
Call station 0.01 Lux Titanium grey
Display Protection class Dimensions for installation
No IP65 167×83×39 mm
Camera Operating temperature Dimensions of panel
1/4” CMOS IP -40 – +65 0С 164×80×34 mm
Angle Power consumption Installation
56° horizontal × 48° vertical 6,5 W, in standby – 3,6 W Flush mount, wall mount
Resolution Power supply
1,3 Мp +12 V
Night backlight Case
4 LEDs Metal
FUNCTIONALITY
Interface Buttons for quick dialing Additionally
WEB-interface 1 call button (CV-01) Connecting two locks
1 call button and 1 alarm button (CV-02) Connecting two door sensors
Lock opening Connecting the alarm
With the operator monitor Number of ringtones Connecting the turn-off alarm button
2 polyphonic ringtones Connecting an external microphone
Access control Connecting an external dynamic
Separate control for two Authentication SIP P2P
locks WEB-interface Calls to the BAS-IP monitors
Linear output for recording
Integration with ACS Talking mode
No Duplex
CATALOGUE 2018 25BAS-IP BA-04/BAS-IP BA-08
Multi apartment The panel allows you to call the internal monitors directly, restricting
outdoor panel uninvited guests from the stairwell. The panels are also well suited for
small offices.
BAS-IP BA-04 The BA-04 and BA-08 panels feature a built-in card reader that supports
the EM-Marin or MIFARE cards. The panel also features a concierge call
BAS-IP BA-08 button.
GENERAL PARAMETERS
Panel type Night backlight Case
Multi apartment 6 LEDs Metal
Display Light sensitivity Colors
No 0.01 Lux Silver-grey
Camera Protection class Dimensions for installation
1/3”, camera direction IP65 250×150×60 mm
adjustment control
Operating temperature Dimensions of panel
Angle -40 – +65 0С 270×155×50 mm
78° horizontal × 56° vertical
Power consumption Installation
Resolution 6,5 W, in standby – 3,6 W Flush mount, wall mount with BR-BA
800 TVL
Power supply Keyboard
Output video +12 V Mechanical buttons with backlight
D1 (704×576), H.264 Main Profile,
BaseLine Profile
FUNCTIONALITY
Interface Buttons for quick dialing Talking mode
WEB-interface Concierge call button, direct subscribers Duplex
buttons
Lock opening Additionally
With the monitor, by card, with Number of ringtones SIP P2P
the concierge monitor 4 polyphonic ringtones Built-in relay
Access control Authentication
EM-Marin or MIFARE card reader Separate password to the settings,
WEB-interface
Integration with ACS
Output WIEGAND-26
CATALOGUE 2017 27BAS-IP BA-12
Multi apartment The panel allows making direct calls to the monitors of internal subscribers.
outdoor panel The panel is intended for 12 subscribers, and so it is suitable for small
offices. A built-in card reader supports EM-Marin or MIFARE cards.
BAS-IP BA-12 The panel also features a concierge call button.
GENERAL PARAMETERS
Panel type Night backlight Case
Multi apartment 6 LEDs Metal
Display Light sensitivity Colors
No 0.01 Lux Silver-grey
Camera Protection class Dimensions for installation
1/4”, camera direction adjustment/con- IP65 355×140×53 mm
trol
Operating temperature Dimensions of panel
Angle -40 – +65 0С 375×155×47 mm
80° horizontal × 64° vertical
Power consumption Installation
Resolution 6,5 W, in standby – 3,6 W Flush mount, wall mount with BR-AA
1,3 Mp
Power supply Keyboard
Output video PoE and +12 V Mechanical buttons with backlight
HD (1280×720), H.264 Main Profile,
Baseline Profile
FUNCTIONALITY
Interface Buttons for quick dialing Talking mode
WEB-interface Concierge call button Duplex
Lock opening Number of ringtones Additionally
With the monitor, by card, with the con- 4 polyphonic ringtones SIP P2P
cierge monitor Built-in relay
Authentication
Access control Separate password to the settings,
EM-Marin or MIFARE card reader WEB-interface
Integration with ACS
Output WIEGAND-26
CATALOGUE 2018 29BAS-IP AV-01K
Individual outdoor BAS-IP AV-01K is an individual outside panel with excellent technical
panel features and a beautiful design. This panel features a keyboard for unlocking
via passcodes. Also, the AV-01K has a built-in camera, which provides video
BAS-IP AV-01K output in D1 resolution. The AV-01K works durably, thanks to the protection
class IP65.
GENERAL PARAMETERS
Panel type Night backlight Case
Individual 6 LEDs Metal
Display Light sensitivity Colors
No 0.01 Lux Titanium grey
Camera Protection class Dimensions for installation
1/3”, adjustment of the camera direction IP65 180×104×60 mm
Angle Operating temperature Dimensions of panel
78° horizontal × 56° vertical -40 – +65 0С 192×116×45 mm
Resolution Power consumption Installation
800 TVL 5,5 W, in standby – 2,5 W Flush mount, wall mount with BR-AV
Output video Power supply
D1 (704×576), H.264 Main Profile, +12 V
BaseLine Profile
FUNCTIONALITY
Interface Buttons for quick dialing Talking mode
WEB-interface 1 call button Duplex
Lock opening Number of ringtones Additionally
With the monitor 4 polyphonic ringtones SIP P2P
Place for the signature near the call
Access control Authentication button
With monitor, by code, with conierge Separate password to the settings,
monitor WEB-interface
Integration with ACS
No
CATALOGUE 2017 31BAS-IP AV-01
Individual outdoor This individual outdoor panel, AV-01, meets all modern requirements: it has
panel a beautiful design, protected by a dust and waterproof metal case, features
a high-definition camera, and the supports wall and flush mounting.
BAS-IP AV-01
GENERAL PARAMETERS
Panel type Night backlight Case
Individual 6 LEDs Metal
Display Light sensitivity Colors
No 0.01 Lux Titanium grey
Camera Protection class Dimensions for installation
1/3”, adjustment of the camera direction IP65 180×104×60 mm
Angle Operating temperature Dimensions of panel
78° horizontal × 56° vertical -40 – +65 0С 192×116×45 mm
Resolution Power consumption Installation
800 TVL 5,5 W, in standby – 2,5 W Flush mount, wall mount with BR-AV
Output video Power supply
D1 (704×576), H.264 Main Profile, +12 V
BaseLine Profile
FUNCTIONALITY
Interface Buttons for quick dialing Talking mode
WEB-interface 1 call button Duplex
Lock opening Number of ringtones Additionally
With the monitor 4 polyphonic ringtones SIP P2P
Place for the signature near the call
Access control Authentication button
No Separate password to the settings,
WEB-interface
Integration with ACS
No
CATALOGUE 2017 33BAS-IP AV-01T
Individual outdoor BAS-IP AV-01T is an individual outdoor panel with cutting-edge technical
panel features and a beautiful design. The AV-01T supports contactless cards and
has a built-in camera, which provides video output in D1 resolution. This
BAS-IP AV-01T panel works durably, thanks to the protection class IP65.
GENERAL PARAMETERS
Panel type Night backlight Case
Individual 6 LEDs Metal
Display Light sensitivity Colors
No 0.01 Lux Titanium grey
Camera Protection class Dimensions for installation
1/3”, adjustment of the camera direction IP65 180×104×60 mm
Angle Operating temperature Dimensions of panel
78° horizontal × 56° vertical -40 – +65 0С 192×116×45 mm
Resolution Power consumption Installation
800 TVL 5,5 W, in standby – 2,5 W Flush mount, wall mount with BR-AV
Output video Power supply
D1 (704×576), H.264 Main Profile, +12 V
BaseLine Profile
FUNCTIONALITY
Interface Buttons for quick dialing Talking mode
WEB-interface 1 call button Duplex
Lock opening Number of ringtones Additionally
With the monitor, by card 4 polyphonic ringtones SIP P2P
Place for the signature near the call
Access control Authentication button
EM-Marin or MIFARE card reader Separate password to the settings,
WEB-interface
Integration with ACS
Output WIEGAND-26
CATALOGUE 2017 35BAS-IP AV-02
Individual outdoor The touch button of this outside panel has a virtually unlimited number of
panel taps. Regarding design and performance, this individual outdoor panel is
different from the ordinary panels installed in houses and apartments.
BAS-IP AV-02 Due to its protection class IP65, you can easily install this panel in the
street without fear of heavy rain or dust. It also runs on a double power
supply – the standard and PoE – which will allow you to set up the panel
in those places where there is no access to power, making it easy to install.
GENERAL PARAMETERS
Panel type Night backlight Case
Individual 6 LEDs Metal with glossy acrylic
overlay
Display Light sensitivity
No 0.01 Lux Colors
Champagne + black
Camera Protection class
1/3” IP65 Dimensions for installation
151×94×45 mm
Angle Operating temperature
78° horizontal × 56° vertical -40 – +65 0С Dimensions of panel
160×100×46 mm
Resolution Power consumption
800 TVL 5,5 W, in standby – 2,5 W IInstallation
Flush mount, wall mount with BR-AV2
Output video Power supply
D1 (704×576), H.264 Main Profile, PoE and +12 V
BaseLine Profile
FUNCTIONALITY
Interface Number of ringtones Talking mode
WEB-interface 4 polyphonic ringtones Duplex
Lock opening Authentication Additionally
With the monitor Separate password to the settings, SIP P2P
WEB-interface
Access control
No
Buttons for quick dialing
1 touch call button
CATALOGUE 2017 37BAS-IP AV-02T
Individual outdoor The outdoor panel, AV-02T, features with a very durable sensor button.
panel The outstanding design and handy features of the AV-02T distinguish it
from others. A built-in proximity card reader ensures seamless access
BAS-IP AV-02T control to your home, office or any other facility. Due to its IP65
protection class and resistance to weather conditions, you can easily
install this model outdoors.
The ability to run on both the standard power supply and PoE makes
it possible to install the outdoor panel there, regardless of access to
electricity.
GENERAL PARAMETERS
Panel type Night backlight Case
Individual 6 LEDs Metal with glossy acrylic
overlay
Display Light sensitivity
No 0.01 Lux Colors
Champagne + black
Camera Protection class
1/3” IP65 Dimensions for installation
151×94×45 mm
Angle Operating temperature
78° horizontal × 56° vertical -40 – +65 0С Dimensions of panel
160×100×46 mm
Resolution Power consumption
800 TVL 5,5 W, in standby – 2,5 W IInstallation
Flush mount, wall mount with BR-AV2
Output video Power supply
D1 (704×576), H.264 Main Profile, PoE and +12 V
BaseLine Profile
FUNCTIONALITY
Interface Buttons for quick dialing Talking mode
WEB-interface 1 touch call button Duplex
Lock opening Number of ringtones Additionally
With the monitor, by card 4 polyphonic ringtones SIP P2P
Access control Authentication
EM-Marin or MIFARE card reader Separate password to the settings,
WEB-interface
Integration with ACS
Output WIEGAND-26
CATALOGUE 2017 39BAS-IP AV-07T
Individual outdoor This IP outdoor panel is a novelty for this year. It has a stylish modern
panel design and vandal-proof case with IP65 protection class. Due to four IRs
and a good camera, you can see your visitor for specific details whether
BAS-IP AV-07T it is day or night.
The AV-07T is an ideal solution for modern exterior design.
GENERAL PARAMETERS
Panel type Night backlight Case
Individual 4 IR Metal
Display Light sensitivity Colors
No 0.01 Lux Titanium grey, black
Camera Protection class Dimensions for installation
1/4” IP65 158×105×60 mm
Angle Operating temperature Dimensions of panel
122° horizontal × 70° vertical -40 – +65 0С 168×115×40 mm
Resolution Power consumption Installation
2 Mp 6,5 W, in standby – 4 W Flush mount, wall mount with BR-AV7
Output video Power supply
720p (1280×720), H.263, H.264 PoE and +12 V
1080p (1920×1080) MJPEG
FUNCTIONALITY
Interface Buttons for quick dialing Additionally
WEB-interface 1 call button SIP P2P
TR-069
Lock opening Number of ringtones 2 SIP accounts
With the monitor, by card 4 polyphonic ringtones Contacts for 2 locks
Separate lock control
Access control Authentication Alarm input
2 card reader inside: EM-Marin and Separate password to the settings, Piezo call button
MIFARE WEB-interface Motion sensor
Gyroscope
Integration with ACS Talking mode
Input/Output WIEGAND-26 Duplex
CATALOGUE 2017 41BAS-IP AV-02IC
Emergency outdoor This panel can is excellent for unique locations where you need to get
panel information or help in the short term. The dispatcher helps organize
feedback for requesting information or reporting incidents.
BAS-IP AV-02IC
GENERAL PARAMETERS
Panel type Light sensitivity Colors
Individual No Champagne + green
Display Protection class Dimensions for installation
No IP65 151×94×45 mm
Camera Operating temperature Dimensions of panel
No -40 – +70 0С 160×100×46 mm
Angle Power consumption Installation
No 4,5 W, in standby – 2 W Flush mount, wall mount with BR-AV2
Resolution Power supply
No +12 V
Night backlight Case
No Metal
FUNCTIONALITY
Interface Buttons for quick dialing Talking mode
WEB-interface 1 call button Duplex
Lock opening Number of ringtones Additionally
With the monitor 4 polyphonic ringtones SIP P2P
Access control Authentication
No WEB-interface
Integration with ACS
No
CATALOGUE 2017 43BAS-IP AV-02FP
Emergency outdoor You can mount this panel on special objects with high fire safety standards. panel The dispatcher helps to organize feedback on fire or emergency situations. BAS-IP AV-02FP GENERAL PARAMETERS Panel type Light sensitivity Colors Individual No Champagne + red Display Protection class Dimensions for installation No IP65 151×94×45 mm Camera Operating temperature Dimensions of panel No -40 – +70 0С 160×100×46 mm Angle Power consumption Installation No 4,5 W, in standby – 2 W Flush mount, wall mount with BR-AV2 Resolution Power supply No +12 V Night backlight Case No Metal FUNCTIONALITY Interface Buttons for quick dialing Talking mode WEB-interface 1 call button Duplex Lock opening Number of ringtones Additionally With the monitor 4 polyphonic ringtones SIP P2P Access control Authentication No WEB-interface Integration with ACS No CATALOGUE 2017 45
BAS-IP AK-10
Indoor monitor Engineering solutions stepped far forward, and we are pleased to present
the monitor running on the Android operating system. Thanks to the
BAS-IP AK-10 Android OS, the video intercom is fluid and reliable. It features a 10”
capacitive touchscreen, which enhances the control of the intercom,
making it even more comfortable and more convenient. It is technically a
perfect intercom with state-of-the-art technical specifications.
GENERAL PARAMETERS
Display Power supply Case
10” TFT LCD, touch, capacitive PoE and +12 V Plastic
Screen resolution Dimensions Installation
1024х600 295×208×25 mm Wall mount
Built-in camera Colors Operating system
Yes White, black Android
Power
6 W, in standby – 2,5 W
CONNECTIONS
Number of ind. outdoor Extra slots Number of IP cameras
panels Slot for SD card (microSDHC) Up to 16 cameras
Up to 9 panels
Memory
Number of multi app. outdoor Recording video and audio to SD card
panels
Up to 9 panels Interface
English, graphic
Connection of additional
monitors
Up to 8 monitors
FUNCTIONALITY
Number of ringtones Support of receiving messages Viewing IP cameras in the standby
9 polyphonic ringtones Yes mode
Quad-splitter, tour
Intercom type Alarm
Video intercom 8 inputs for sensors Software update
Via Ethernet
Home automation Scenes
control Yes Additionally
Light, curtains, elevator Connection of the call button
Voicemail SIP P2P
Multimedia Yes Controlled output when there is an
Viewing video-, photo- and audio files incoming call
from the SD card Photo frame mode The ability to install third party apps
Yes
CATALOGUE 2017 47BAS-IP AQ-07
Indoor monitor This is a stylish and multifunctional IP video intercom. Engineering
solutions stepped far forward, and we are pleased to present the
BAS-IP AQ-07 Android-based monitor. Thanks to Android, the video intercom is fluid
and reliable. It features a 7” capacitive touchscreen, which makes control
of the intercom more comfortable and more convenient.
GENERAL PARAMETERS
Display Power supply Case
7” TFT LCD, touch, capacitive PoE and +12 V Plastic + metal
Screen resolution Dimensions Installation
1024×600 234×144×18 mm Wall mount
Built-in camera Colors Operating system
Yes Black, white, champagne Android
Power
6 W, in standby – 2,5 W
CONNECTIONS
Number of ind. outdoor Extra slots Number of IP cameras
panels Slot for SD card (microSDHC) Up to 16 cameras
Up to 9 panels
Memory
Number of multi app. outdoor Recording video and audio to SD card
panels
Up to 9 panels Interface
English, graphic
Connection of additional
monitors
Up to 8 monitors
FUNCTIONALITY
Number of ringtones Support of receiving messages Viewing IP cameras in the standby
9 polyphonic ringtones Yes mode
Quad-splitter, tour
Intercom type Alarm
Video intercom 8 inputs for sensors Software update
Via Ethernet
Home automation Scenes
control Yes Additionally
Light, curtains, elevator Connection of the call button
Voicemail SIP P2P
Multimedia Yes Controlled output when there is an
Viewing video-, photo- and audio files incoming call
from the SD card Photo frame mode The ability to install third party apps
Yes
CATALOGUE 2017 49BAS-IP AP-07L
Indoor monitor A unique feature of the IP video intercom, AP-07L, is a PoE power supply,
which makes it possible to connect the monitor with just one wire. As a
BAS-IP AP-07L result, it would not need a separate power supply.
This monitor can be installed on a wall or a table, as it comes with a
special table bracket. You can control all your home automation through
the device’s menu: the light, curtains, and even an elevator.
GENERAL PARAMETERS
Display Power consumption Colors
7” TFT LCD, touch 6 W, in standby – 4 W Silver, black, white
Screen resolution Power supply Case
800×480 PoE Metal
Built-in camera Dimensions Installation
No 220×144×26 mm Table installation, wall mount
CONNECTIONS
Number of ind. outdoor Extra slots Number of IP cameras
panels Slot for SD card (SDHC) Up to 16 cameras
Up to 9 panels
Memory
Number of multi app. outdoor Recording video and audio to SD card
panels
Up to 9 panels Interface
English, graphic
Connection of additional
monitors
Up to 8 monitors
FUNCTIONALITY
Number of ringtones Support of receiving messages Viewing IP cameras in the standby
4 polyphonic ringtones Yes mode
Yes
Intercom type Alarm
Audio intercom No Software update
Through SD card, via Ethernet
Home automation Scenes
control Yes Additionally
Light, curtains, elevator SIP P2P
Voicemail
Multimedia Yes
Viewing video-, photo- and audio files
from the SD card Photo frame mode
Yes
CATALOGUE 2017 51BAS-IP AU-04LA
Indoor monitor An exciting feature of the AU-04LA is the ability to connect an additional
handset, SP-AU. This solution is ideal for people stuck with old habits.
BAS-IP AU-04LA The Intercom system can be managed not only using mechanical keys but
also via the touchscreen.
The enclosure comes in classic black and white color, suitable for any style
of your interior.
GENERAL PARAMETERS
Display Power supply Case
4” TFT LCD, touch, capacitive PoE and +12 V Plastic
Screen resolution Dimensions Installation
480×272 135×185×25 mm (without SP-AU) Wall mount
195×185×25 mm (with SP-AU)
Built-in camera
No Colors
Black, white
Power
6 W, in standby – 2,5 W
CONNECTIONS
Number of ind. outdoor Extra slots Number of IP cameras
panels Slot for SD card (microSDHC) Up to 8 cameras
Up to 9 panels
Memory
Number of multi app. outdoor Recording video and audio to SD card
panels
Up to 9 panels Interface
English, graphic
Connection of additional
monitors
Up to 5 monitors
FUNCTIONALITY
Number of ringtones Support of receiving messages Viewing IP cameras in the standby
9 polyphonic ringtones Yes mode
Yes
Intercom type Alarm
Audio intercom 4 inputs for sensors Software update
Via Ethernet
Home automation Scenes
control Yes Additionally
Light, curtains, elevator Connection of the call button
Voicemail SIP P2P
Multimedia No
Viewing video-, photo- and audio files
from the SD card Photo frame mode
Yes
CATALOGUE 2017 53BAS-IP AM-01
Concierge monitor The monitor concierge for convenient organization of communication
with the whole system, with internal monitors, outside panels, receiving
BAS-IP AM-01 messages from the internal monitors, and private conversation with
visitors using the handset. Also, it is possible to view images from any
outside panel in the system with the AM-01.
GENERAL PARAMETERS
Display Power supply Case
9” TFT LCD, touch +12 V (PSU included) Aluminum
Screen resolution Dimensions Installation
800×480 303×195×29,5 mm Table installation
Power consumption Colors
6,7 W, in standby – 4,7 W Silver metallic
CONNECTIONS
Connection of additional Memory Number of IP cameras
monitors Recording video and audio to SD card Up to 16 cameras
Up to 8 monitors
Interface
Intercom English, graphic
With all monitors in the system
Connections
Extra slots Multi apartment – up to 100
Slot for SD card (SDHC) Individual – up to 1000
FUNCTIONALITY
Number of ringtones Receiving messages Software update
4 polyphonic ringtones Receives alarm messages from Through SD card, via Ethernet
monitors
Intercom type Additionally
Video intercom Voicemail SIP P2P
Yes
Home
automation control Speed dialing
No Last made and received calls
CATALOGUE 2017 55BAS-IP CM-01
Operator monitor Operator monitors which works in tandem with the call stations, CV-01
and CV-02. These are combined in the IP alarm system with feedback.
BAS-IP CM-01 This system is the perfect solution for places like parking lots, hospitals,
factories, and industrial plants; areas where high-quality IP communications
can help solve emerging problems. This system can also be used where
analog transmissions cannot be applied due to the technical limitations
associated with distance. Assistance poles (Help stations) in the parks or
along the highways, for example, are an excellent solution for this system.
GENERAL PARAMETERS
Display Power supply Case
9” TFT LCD, touch +12 V (PSU included) Aluminum
Screen resolution Dimensions Installation
800×480 303×195×29,5 mm Table installation
Power consumption Colors
6,7 W, in standby – 4,7 W Silver metallic
CONNECTIONS
Connection of call stations Memory Connections
Up to 80 call stations on 1 operator Previously recorded audio fragments External microphone
monitor for broadcast on a schedule or External speaker
manually Line output for recording
Intercom
With all operator monitors in the Interface Number of monitors in the system
system English, graphic Up to 400 operator monitors
Extra slots Number of IP cameras
Slot for SD card (SDHC) Up to 40 cameras
FUNCTIONALITY
Number of ringtones Monitoring of door status on the Hands-free
4 polyphonic ringtones call stations Yes
Yes, can open all the locks at the same
Intercom type time Software update
Video intercom Through SD card, via Ethernet
Control of the availability of call
Intercom stations in the network Control of the noise level near
With all call stations, with all the Yes call stations
operator monitors Can open all the locks at the same time
Incoming calls
Receiving messages Put on waiting, call transfer, secondary
Receives alarm messages from call incoming call
stations
CATALOGUE 2017 57Accessories
IP audio handset SP-02
This comfortable and stylish IP audio handset can receive calls from multi-apartment outdoor panels and
concierge monitors. You can also conduct a conversation with a visitor before opening the door, if necessary.
Also, you can activate it and talk directly to the concierge or the multi-apartment panel.
GENERAL PARAMETERS
Supported VoIP accounts Supported codec types Configuration method
2 G.711μ/A; G.722; ILBC; G.729 WEB-interface
Display Sound processing algorithms Installation
No VAD; CNG; AEC; PLC; AJB; AGC Wall mount and table installation
Supported network protocol Reception and transmission Dimensions
types method of audio signals 203×55×55 mm
IPv4 и IPv6 Full Duplex
Colors
Connection to network Number of keys Black, white
Ethernet RJ45 18 keys
Power
PoE (IEEE 802.3af)
58Module SH-61
Protocol converter
Description: Converts the internal monitor control commands
into signals to directly control end executive home automation
modules. You need one protocol converter module SH-61 for
connection to end modules SH-62 and SH-63 to one internal
monitor. For connection to the end KNX modules, you require
the converter protocol SH-81.
Power: Directly from the internal monitor or +12 V
Interface connection to internal monitor: RS485
Interface connection to end modules: RS485 (SH-61), KNX
(SH-81)
Mounting (installation): 4 screws on a flat surface
Dimensions: 82×70×25 mm
Module SH-62
Light control
Description: Manages four independent light channels based
on the trigger on and off principle. It is possible to connect
up to 8 light modules to one internal monitor. Altogether,
there are 32 channels, 8 channels in one room.
Power: + 24 V (140 mA)
Interface connection to protocol converter: RS485
Power outputs on the execution units: Relay contact group, 1,1
kW per channel (alternating voltage)
Mounting (installation): DIN racks
Dimensions: 144×91
Module SH-63
Curtains control
Description: Manages two independent channels for opening
and closing the curtains with a possibility to pause (stop in any
position). Up to 8 curtain modules can be connected to one
internal monitor. Altogether 16 channels, one in each room.
Power: + 24 V (140 mA)
Interface connection to protocol converter: RS485
Power outputs on the execution units: Relay contact group, 2
kW per channel (alternating voltage)
Mounting (installation): DIN racks
Dimensions: 72×91×66 mm
CATALOGUE 2017 59Module EVRC-16 Module SH-16
Manages elevator equipment with a possibility of calling The expansion module is designed to connect 16 alarm inputs
the elevator at any of the 16 floors. The management is for sensors and control them from the internal monitor. You
handled by the central supervising unit of the elevator connect this module to the internal monitor via the RS485
equipment or using a connection with the wiring block interface between the module and the monitor.
of elevator call buttons. This module can be used in systems where it is necessary to
use more inputs for sensors than is provided by the design
of the monitor used (4 or 8).
Module SH-40 Module SH-42
The module is designed to adjust the delay time of opening This module controls two locks, electromagnetic and
electromagnetic and electromechanical locks. It can be electromechanical. You connect the module to the outside
used separately as a third-party access control system, with panel RS485 bus and manage separate locks with special
electromagnetic and electromechanical locks and an extra internal monitor’s firmware.
connected exit button.
60Exit button SH-45 SIP-PBX-100
SIP-PBX allows you to make internal and external calls from
Power supply: 12 V
outdoor panels to the internal monitors, to clients installed
Service life: more than 50 million clicks
on the mobile phones or the PC, and on the IP-phones both
Protection class: IP68
within the local network and across the Internet, anywhere
Humidity: 10% -90%
in the world. It supports up to 100 simultaneous connections.
The ability to change the illumination color
Trigger mode
Stainless steel overlay
Temperature range: -30 ... + 60 °C
Handset SP-AU SH-01
An additional handset that connects directly to the AU-04L. Contactless chips keychain with EM-Marin.
This solution is ideal for those who want privacy in conversa- Keychain ID is engraved with laser
tions. Dimensions: 185×60 mm. Only read mode
Diameter: 33 mm
Colors: red, black
Protection class: IP68
Used chip: EM4102
Weight: 3 g
Reading distance: up to 2,5-5 cm (depending on the reader)
CATALOGUE 2018 61SH-20.4 SH-20.8 SH-20.16
Unmanaged 4-Port 10/100Base- Unmanaged 8-Port 10/100Base- Unmanaged 16-Port 10/100Base-
TX PoE Switch with RJ45 TX PoE Switch with RJ45 TX PoE Switch with RJ45
interface, intended for connection interface, intended for connection interface, intended for connection
network devices with network devices with network devices with
Power over Ethernet support. Power over Ethernet support. Power over Ethernet support.
Uninterruptible power sup- Network reader of contact- Cards reader for PC
ply unit UPS-DP less cards CR-01 TR-01
Uninterruptible power supply unit for An external network reader of It is used to transfer the identifiers (cards
multi-apartment outdoor panels with contactless cards and keychains and key fobs) to the Management
built-in control of electromagnetic and EM-Marin or MIFARE. The reader has Software database. The connection is
electromechanical lock. It can also be an integrated controller for access made by connecting to the USB
used with individual panels or the control via electromagnetic and connector of the PC, followed by
concierge monitor. electromechanical locks control. emulating the virtual COM port in the
Windows drivers.
62Bracket BR-AA Bracket BR-BA Bracket for the wall mount for multi apartment outdoor panels Bracket for the wall mount for multi apartment outdoor panels AA-05, AA-07, AA-12 and BA-12. BA-04 and BA-08. Bracket BR-AV Bracket BR-AV2 Bracket BR-AV7 Bracket for the wall mount for individual Bracket for the wall mount for individual Bracket for the wall mount for individual outdoor panels AV-01, AV-01T and AV- outdoor panels AV-02, AV-02T, AV-02FP outdoor panel AV-07T. 01K. and AV-02IC. CATALOGUE 2018 63
BEST IDEAS FOR IP
INTERCOM SOLUTIONS
BAS-IP has direct distributor cooperations in 23 countries all over the world and
constantly developing its business to new countries.
www.bas-ip.comYou can also read
