BUILDING AUTOMATION SYSTEM AND CONTROLS

  A perfectly tailored Building
  Automation Solution
usa.siemens.com/bas
A perfectly tailored Building - Automation Solution BUILDING AUTOMATION SYSTEM AND CONTROLS - Siemens
Maximize building efficiency
    – today and tomorrow

Buildings face a wide range of demands and Siemens offers fully-integrated solutions
to help achieve your building's desired performance. Siemens building automation can
be tailored any way needed to connect HVAC, lighting, shades, safety, security, fire
systems and more for any building type from school campuses and hospitals to hotels,
airports, museums, commercial buildings, manufacturing plants, etc.

Realize unmatched configuration flexibility with a variety of user interfaces, network
managers, controllers and field devices. The open architecture puts you in command
of all systems and equipment, remotely or onsite, for the access to achieve optimum
building efficiency.

Siemens has what your buildings require today and in the future.

                                                                                         2
A perfectly tailored Building - Automation Solution BUILDING AUTOMATION SYSTEM AND CONTROLS - Siemens
Explore a complete suite of building automation
             software and controls, room automation and
             field devices to perfectly tailor a solution to
             any building's needs.

                                                 Cloud applications               Cloud gateways
                                                    and services

Software

                                                     Desigo CC                      Desigo Optic

Automation
Controls
                              Controllers and                     Desigo Control Point                    Desigo Optic
                               extension I/O

Room
Automation
                    Desigo              Desigo Room              Desigo Control Point              GAMMA                      Critical
                     DXR               operation units                                             lighting                environments

Field
Devices
                Thermostats     Sensors            Actuators             Valves             Meters            Pneumatics           VFDs

             Rely on Siemens for innovative, open solutions that operate with BACnet,
             Haystack, Modbus and other communication protocols for easy system
             integration and future upgrades.
             Centralize and streamline control of HVAC equipment:
             • Chillers                                        • Boilers
             • Air Handling Units (AHUs)                       • Rooftop Units (RTUs)
             • Fan Coil Units (FCUs)                           • Heat Pump Units (HPUs)
             • Variable Air Volume boxes (VAVs)
             Combine all building systems and subsystems into a
             single interface that speaks the same language:
             • Lighting                                        • Power monitoring
             • Security                                        • Closed-circuit video (CCTV)
             • Card and keypad access                          • Fire & life safety
             • Elevators/escalators                            • Plumbing and water monitoring

                                                                                                                                          3
A perfectly tailored Building - Automation Solution BUILDING AUTOMATION SYSTEM AND CONTROLS - Siemens
Connect, monitor and operate
    facilities with ease

Digitalization is driving buildings to become more and more connected
with an increasing need to have all building data easily in sight. Ensure
comfortable, safe, secure and efficient facilities with building management
software solutions to meet any need.

Remotely monitor building performance status real-time with Building Operator
A cloud-based solution for remote monitoring and control of your buildings.
Monitor alarms, trends and histories via a web browser.
•	24/7 remote monitoring via a single, easy interface
• Command building points in real-time
•	Remotely access on-premise web applications such as Desigo CC, Desigo Optic,
  and Desigo Control Point
•	Store trend and point data history for up to 3 years
• Securely upload data to the cloud
•	Supports BACnet, Modbus TCP and Haystack

                                                                                  4
A perfectly tailored Building - Automation Solution BUILDING AUTOMATION SYSTEM AND CONTROLS - Siemens
Manage any size or complexity of facility operation
with Desigo Building Management solutions

Maximize building performance with the                    Simplify and streamline building management
Desigo CC building management                             workflows with Desigo Optic software
software platform                                         Desigo Optic is an open, easy-to-use building
Desigo CC unifies your entire building management         management solution for single-discipline systems.
operations into a single platform for optimized           It is designed to make your building data work better
performance and enhanced insights. It integrates          for you using native Haystack tagging to standardize
multi-discipline systems and devices, provides            data and reduce integration complexity to improve
market specific solutions, automates processes and        insights and real-time decision making. Offered as
is scalable and flexible to meet the requirements         software or as a software-embedded supervisory
of any building or project size.                          controller, users have two flexible deployment
Integrate HVAC, fire, lighting, power management,         options available.
security, video and third-party systems and               Desigo Optic operates on an open platform powered
applications – all accessed through a single interface.   by FIN Framework to provide better workflows for
• Supports BACnet, OPC, Modbus, KNX and SNMP              data integration, graphics creation and trend analysis
•	Flexible user interface that supports multi-           to simplify engineering workflow and speed up
  discipline users                                        integration.
•	Manage power generation, storage, distribution         • Quick, easy access to critical data
  and consumption                                         • Supports BACnet, Modbus, KNX, SNMP, OPC
•	Integrate a variety of systems such as escalators,     • Seamlessly integrates with Niagara
  elevators and electrical vehicle charging stations      • Extensive 3-D graphics library
  and monitor with confidence                             • Best-in-class user interface for data access
•	Application ecosystem harnesses the power of IoT
  to easily connect smart devices
•	IEC62443-3-3 SL2 compliant

                                                                                                               5
A perfectly tailored Building - Automation Solution BUILDING AUTOMATION SYSTEM AND CONTROLS - Siemens
Optimize building efficiency
    with precise control throughout

With tighter operating budgets, stricter government guidelines and increasing public
awareness, energy savings and resource conservation is key. Sustainable building
operations have become a real balancing act between energy use and occupant
comfort achieved using high-performance automation controls.

Discover a choice of controllers that are open, scalable and networkable for complete
facility management and support energy management applications.

Modular Automation Controllers
High-performance, freely-programmable, modular automation controllers provide
maximum scalability, integration and reliable building operation. All modular controller
models are BTL listed as B-BC with direct control of up to 500 I/O points by adding
TX-I/O modules.

•	Optional supervision of up to 96 devices
• Supports BACnet IP
• Supports third-party integration
• Select models for DC power options
• Support for local user interfaces (PXM10 T/S and HOA)

Compact Automation Controllers
Freely-programmable compact controllers for HVAC and building services are perfectly
matched for small-to-medium sized plants. These controllers feature many options to
satisfy building automation needs, including supervised and routed MSTP networks,
BACnet IP, HMIs, I/O expansion and third-party integration.
All compact controller models are BTL listed as B-BC.

36 integrated I/O points                      24 and 16 integrated I/O points
•	Optional supervision of up to              •	Optional supervision of up to
  96 devices                                    32 devices
•	Expandable up to 4 TX-I/O modules          •	Support for local user interfaces
•	Support for local user interfaces            (PXM10 T/S and HOA)
  (PXM10 T/S and HOA)                         •	Operates at extended temperature
•	Made in USA                                  range for RTUs (24-point unit only)
                                              •	Made in USA

                                                                                           6
A perfectly tailored Building - Automation Solution BUILDING AUTOMATION SYSTEM AND CONTROLS - Siemens
Perform complex monitoring and control with
a wide choice of building automation controllers

TX – I/O Modules for Modular and Compact 36 (units)
Add modules for power and communication including: TX-I/O point modules,
power supply, bus connection, expansion and interface modules.

• High flexibility through distributed I/O’s
•	I/O module range for measuring, reporting, switching, setting and metering
• Support for all HVAC-typical signals
• Compact DIN design
•	Modules with and without manual override
•	LCD status display for quick troubleshooting

Optional user interfaces for all Modular and Compact units

PXM10 T/S                                      HOA
• Optional controller-mounted graphic          • Manual override switches and LEDs
  display to monitor and control local            that provide status indication and
  points and alarm management                     diagnostic information for digital and
• Hot swappable – install/remove without          analog outputs
  facility interruption                        • Hot swappable – install/remove without
                                                  facility interruption

                                                                                           7
A perfectly tailored Building - Automation Solution BUILDING AUTOMATION SYSTEM AND CONTROLS - Siemens
Experience the ultimate
    comfort for any room

A single system for controlling HVAC, lights and shades,
Total Room Automation maximizes performance and energy savings
throughout the life of a building.

Instead of separate systems for HVAC, lighting and shade control, each with its own
network infrastructure, Siemens provides a controller for all three functions in one cost
effective solution. The BACnet-enabled, Desigo DXR automation controllers provide
high-performance direct digital control over standalone or networked units to perform
complex HVAC control, room monitoring and energy management functions at floor,
zone or room levels.

And when combined with Desigo Control Point touch panels, they are even more
effective. Whenever a room’s conditions deviate from the optimal pre-set state, a
green leaf icon on the room’s display changes to red. The icon is a visual indicator that
a room is not in an energy-efficient mode. Room occupants can easily return their
room to an energy-efficient level by simply tapping the red leaf icon.
Siemens Total Room Automation offers:
• Lower investment and installation costs
• Reduced long-term operating costs
• Improved room energy efficiency
• Greater occupant experience and comfort

                                                                                            8
A perfectly tailored Building - Automation Solution BUILDING AUTOMATION SYSTEM AND CONTROLS - Siemens
Adjust room settings and building floor plans quickly
and easily with Desigo Total Room Automation

Desigo DXR Controller
Combines room HVAC, lighting and/or shade control
systems into one, seamless package. Includes a variety
of standard preloaded HVAC applications: variable air
volume, constant volume, fan powered boxes, fan coil,
unit vent, chilled beam and heat pumps. BTL certified
as BACnet Application Specific Controller and communicates
using BACnet IP or BACnet MS/TP protocol.
•	Dual Ethernet ports for cost optimized BACnet IP daisy chain installations
•	Multiple and flexible operational modes
  (pre-comfort, comfort, economy and protection)
•	Applications compliant with latest ASHRAE energy standards and codes
• Title 24 compliant

Desigo Actuating DXR Controller
Combines a room automation station, for HVAC,
lighting and shading, with an actuator that supports
standard variable air volume and fan-powered box
application types.
• BACnet MS/TP and BACnet IP variants
•	Pressure-independent or pressure-dependent control
•	Support for chilled beam and under floor air distribution applications
• Title 24 compliant

Desigo Control Point for simplified
building operations and monitoring
Desigo Control Point simplifies operation and
monitoring of heating, ventilation, air conditioning,
lighting and shading in small-to-medium sized
buildings. Access your plants via touch panels, or
from any PC or mobile device – wherever you are. Whether
it is for maximizing room comfort, monitoring and operating your primary plant or
displaying your building data, Desigo Control Point is designed to make all tasks easy.
•	Plug & Play features provide ability to view and command points, manage alarms,
  operate schedules and calendars, create and view trends
•	Built-in graphics editor with graphics and dashboard building capabilities
• Monitor important building metrics with no additional software or licensing
•	Remote access via touch panels or from any PC or mobile device – wherever you are
•	Built on the latest technology including HTML5, Haystack and BACnet IP

                                                                                          9
A perfectly tailored Building - Automation Solution BUILDING AUTOMATION SYSTEM AND CONTROLS - Siemens
Achieve greater productivity, comfort
  and energy savings with Total
  Room Automation

I really like how easy the system is to use –
having one system control all aspects of our
building HVAC, lighting, shades, as well as
monitor energy usage and equipment
operation, it really gives us the tools we
need to operate the building optimally.”

                                        Jason Donovan
                                   Senior Vice President
                                   Bangor Savings Bank
                                                           10
The right devices matter for
    complete building efficiency
    and comfort

Thermostats               Sensors
Select from a robust      Accurately measure the
range of communicating    required environmental
and non-communicating     variables to help
thermostats designed      ensure a healthy and
to fit your needs         productive indoor climate

Lighting                  Electronic Damper Actuators
Easily manage all         More torque, greater energy
aspects of a facility’s   efficiency and long-lasting
lighting from a single    reliability gives you an ideal
place                     solution for all your HVAC
                          equipment needs

Power Meters              Valves & Valve Actuators
Power and energy          A versatile range of valves
meters provide the        and actuators designed
information needed        for ease of use, superior
to help control and       control accuracy and
allocate energy costs     energy efficiency

                          Variable Frequency Drives
                          Achieve up to 50% energy
                          savings controlling HVAC
                          fans and pumps

                                                           11
Siemens Industry, Inc.               Providing you a choice to best achieve your
Smart Infrastructure​
                                     building performance goals.
1000 Deerfield Parkway
Buffalo Grove, IL 60089-4513 USA​
Tel. 847-215-1000​                   Our network of Siemens independent field offices and
                                     partners are standing by to help you leverage best-in-class
Siemens Canada Limited
Headquarters                         building management solutions to address your toughest
1577 North Service Road              business challenges. The companies we choose in our
East Oakville, ON L6H OH6 Canada​
                                     partner network bring additional experience in many
Tel. 905-465-8000
                                     different technologies and markets.
© 2021 Siemens Industry, Inc.
(05/2021 Part #153-BAU-130)          Our certified solution partners are experts in Siemens smart
                                     infrastructure solutions for buildings in all industries. They
                                     help create tailored, future-proof solutions and offer expert
Information in this publication is   services for projects of all sizes and complexity levels.
based on current specifications.
The company reserves the right to
make changes in specifications and
models as design improvements
are introduced.
You can also read
