2021 PRODUCT CATALOG
WE KNOW
THE SCIENCE
OF COLD
K2 Scientific is on a mission to provide industry-leading cold
storage solutions to the life sciences market at value prices.
With K2, pharmacies, clinics, hospitals, laboratories don’t have
to compromise quality to meet budget requirements.
K2’s high-performance line is EnergyStar certified and manufactured
under the highest ISO and UL standards.
High-Performance Line
Powered by: Desmon, A Middelby Company
K225SDF K249SDF Freezer
CLINICAL APPLICATIONS VACCINES & MEDICATIONS BIOLOGICS DIAGNOSTICS KITS MOLECULAR BIOLOGY INDUSTRIAL TESTING
• Visual and audible hi or low
temperature, senor failure, door ajar
alarms
• Keyed door locks
• Magnetically sealed door with rapid
cool-down mode after door opening for
quick temperature recovery
• Door-activated and exterior switch-
activated interior LED lighting
• Cabinet constructed of 304 steel with
CFC-free, high-density insulation (2.4-
inch thick)
K225SDF K225SDF-SS
• R290 refrigerant, an environmentally
green option compliant with future
MODEL CAPACITY INTERIOR EXTERIOR SHIPPING WT.
NUMBER CU. FT. / liters Width x Depth x Height Width x Depth x Height kg / LBS. EPA, and SNAP non-ozone depleting
W-600mm (23,62”) W-720mm (28.35”) 115KG mandates
K225SDF 25/700 D-665mm (26.18”) D-800mm (31.5”) (253LBS) • Easy swivel casters
K225SDF-SS H-1520mm (59.84”) H-2013mm (79.25”)
• Remote dry alarm contacts
• 0.75-inch temperature probe and, one
data logger access port
• Shelves are adjustable by 1 inch
increments
• Energy Star high performance certified
• UL listed (61010-1) listed
• Built and shipped from ISO 9001:2016
manufacturing and distribution facilities
• Each cabinet undergoes three quality
control checks prior to shipping
• Warranty: two-year full-replacement
for parts or compressor failure plus
three additional years for compressor
K249SDF K249SDF-SS replacement
MODEL CAPACITY INTERIOR EXTERIOR SHIPPING WT.
NUMBER CU. FT. / Width x Depth x Height Width x Depth x Height kg / LBS.
liters
W-1320mm (51.97”) W-1440mm (56.69”) 205KG
K249SDF 49/1400 D-665mm (26.18”) D-800mm (31.5”) (450LBS)
K249SDF-SS H-1520mm (59.84”) H-2048mm (79.25”)
High-Performance Line
Powered by: Desmon, A Middelby Company
K225 K230 Refrigerators
USES: CLINICAL APPLICATIONS VACCINES & MEDICATIONS BIOLOGICS DIAGNOSTICS KITS MOLECULAR BIOLOGY INDUSTRIAL TESTING
• Visual and audible hi or low temp, sensor
failure, door ajar alarms
• 1˚ to 12˚C - Preset 4˚C
• Keyed door locks
• Magnetically sealed door with rapid cool-
down mode after door opening for quick
temperature recovery
• Remote dry alarm contacts
• Door-activated and exterior switch-
activated interior LED lighting
• Cabinet constructed of white powder-
coated 304 steel with CFC-free, high-
K225SDR K225GDR K225GDR-SS K225SDR-SS density insulation (2.4’ thick)
• R290 refrigerant. Fully compliant with new
MODEL CAPACITY INTERIOR EXTERIOR SHIPPING WT. EPA/SNAP/UL
NUMBER CU. FT. / Width x Depth x Height Width x Depth x Height kg / LBS.
liters • Easy swivel casters
K225SDR W-600mm (23,62”) W-720mm (28.35”) • 0.75-inch temperature probe and, one
K225GDR 25/700 D-65mm (26.18”) D-800mm (31.5”) 115KG data logger access port
K225GDR-SS H-1520mm (59.84”) H-2013mm (79.25”) (253LBS)
K225SDR-SS • Shelves are adjustable by 1 inch
increments
• UL listed (61010-1)
• Energy Star certified and listed
• Each cabinet undergoes three quality
control checks prior to shipping
• Warranty: two-year full-replacement
for parts or compressor failure plus
three additional years for compressor
replacement
K230SDR K230GDR K230GDR-SS K230SDR-SS
MODEL CAPACITY INTERIOR EXTERIOR SHIPPING WT.
NUMBER CU. FT. / Width x Depth x Height Width x Depth x Height kg / LBS.
liters
Monoblock Technology
K230SDR W-700mm (27,50”) W-860mm (33.85”) 190KG (420LBS) Mechanical components are housed
K230GDR 30/850 D-782mm( 30.80”) D-960mm (37.80”) 200KG (440LBS) in an easily-removable, one-piece unit.
K230GDR-SS H- 1570mm (61.84”) H-060mm (81.12”) 190KG (420LBS)
Replacement takes less than 15 minutes.
K230SDR-SS 200KG (440LBS)
K249 49 cu. ft. Refrigerators
Plug Type
Standard:
NEMA 5-15
Optional:
NEMA 5-20
K249SDR K249GDR K249GDR-SS K249SDR-SS
MODEL CAPACITY INTERIOR EXTERIOR TEMP RANGE DOORS SHELVES DEFROST CERTIFICATION SHIPPING WT.
NUMBER CU. FT. / Width x Depth x Height Width x Depth x Height (SETPOINT) kg / LBS.
liters
K249SDR W-1320mm (51.97”) W-1440mm (56.69”) 1 TO 12˚C 205KG (450LBS)
K249GDR 49/1400 D-665mm (26.18”) D-800mm (31.5”) Preset 2 8 AUTO UL 215KG (474LBS)
K249SDR-SS H-1520mm (59.84”) H-2013mm (79.25”) +4˚C 205KG (450LBS)
K249GDR-SS 215KG (474LBS)
K212GDR 14 cu. ft. Glass Door Refrigerator
MODEL CAPACITY INTERIOR EXTERIOR SHIPPING WT.
NUMBER CU. FT. / liters Width x Depth x Height Width x Depth x Height kg / LBS.
K212GDR 14/400 W-480mm (18.9”) W-600mm (23.62”) 75kg
D-500mm (19.69”) D-642mm (25.27”) (165lbs)
H- 1150mm (45.28”) H-183mm (71.75”) K212GDR
K249GDR-SD 49 cu. ft. Sliding Door Refrigerator
MODEL CAPACITY INTERIOR EXTERIOR SHIPPING WT.
NUMBER CU. FT. / Width x Depth x Height Width x Depth x Height kg / LBS.
liters
W-1320mm (51.97”) W-1440mm (56.69”) 215KG
K249GDR-SD-SS 49/1400 D-665mm (26.18”) D-800mm (31.5”) (474LBS)
K249GDR-SD H-1520mm (59.84”) H-2013mm (79.25”)
K249GDR-SD
K272GDR 72 cu. ft. High-Capacity Refrigerator
MODEL CAPACITY INTERIOR EXTERIOR SHIPPING WT.
NUMBER CU. FT. / liters Width x Depth x Height Width x Depth x Height kg / LBS.
W-2040mm (80.31”) W-2160mm (85.04”) 315KG
K272SDR 74/2100 D-665mm (26.18”) D-850mm (33.46”) (694LBS)
K272GDR-SS H-1520mm (59.84”) H-2013mm (79.25”)
K272GDR
Application FREEZER High-performance storage of blood, vaccines, pharmaceuticals and laboratory products
Model# K225 K249
Storage Volume 25 cu ft 49 cu ft
Performance Characteristics
Exterior (W x D x H) 28.35” x 31.5” x 79.25” 56.69” x 31.5” x 79.25”
Interior (W x D x H) 23.62” x 26.18” x 59.84” 51.97” x 26.18” x 59.84”
Insulation CFC-free, high density insulation
Doors 1 2
Door Perimeter Heater Standard
Shelves 4 8
Access Port 0.75” Probe Port
Casters Standard
Unit Weight 253 lbs 465 lbs
Performance
Peak Variance* 3.6oC 4.4oC
Uniformity 2.2 C
o
1.9oC
Recovery (in minutes) 14 22
Stability + 0.88 C / - 1.87 C
o o
+ 1.32 C / - 1.34oC
o
Energy Consumption (KWhr/day)* 5.34 7.39
Heat Rejection (BTU/hr) 3586 5095
Pull-down time to -25oC (in Minutes) 62 76
Adjustable Set Point Range - 10oC to -30oC
Factory Set Point - 25oC
Electrical Power/ Current 120v 60 Hz
Building Supply Rating 15 Amp
Power Plug/Cord Length NEMA 5-15 / 10ft cord
Agency Listings UL, FDA
VFC Compliant Yes
Energy Star Yes
Indoor/Outdoor Use Indoor use only
Application Environment Non-corrosive, non-flammable, non-explosive
Ambient Operating Temp. (oC) 25oC to 32°C
Refrigeration
Refrigeration System Vapor compression system, forced-air
Compressor Hermetic sealed compressor
Condenser Type Steel tube and fins
Expansion Device Capillary tube
Evaporator Type Copper aluminum coated (1000 hours tested salty fog)
Defrost Smart- hot gas
Refrigerant R290 (Propane)- EPA, SNAP compliant
Controller/System Configuration
User Interface Microprocessor with digital display
Power Switch On/Off
Controller Type Digital controller
Security Lockable doors
Control Sensor NTC probe
Remote Alarm Terminals Standard
High/Low Alarms Standard
Power Failure Alarm Standard
Door Ajar Alarm Standard
Options Stainless steel, roll-out drawers
Warranty 2 years parts & labor, 5 years on compressor
*Data according to EPA Energy Star https://www.energystar.gov/productfinder/product/certified-lab-grade-refrigeration/results
Application REFRIGERATION High-performance storage of blood, vaccines, pharmaceuticals and laboratory products
Model# K212 K225 K230 K249-SD K249 K272
Storage Volume 14 cu ft 25 cu ft 30 cu ft 45 cu ft 49 cu ft 72 cu ft
Performance Characteristics
Exterior (W x D x H) 28.35”x 25.27”x 28.35”x 31.5”x 33.85”x 37.8”x 56.69”x 31.5”x 56.69”x 31.5”x 85.04”x 33.46”x
71.75” 79.25” 79.25” 79.25” 79.25” 79.25”
Interior (W x D x H) 23.62”x 26.18”x 23.62”x 26.18”x 27.5”x 37.8”x 51.97”x 26.18”x 51.97”x 26.18”x 80.31”x 26.18”x
59.84” 59.84” 59.84” 59.84” 59.84” 59.84”
Insulation CFC-free, high density insulation
Doors 1 1 1 2- Sliding 2 3
Door Perimeter Heater Standard
Shelves 4 4 4 8 8 12
Access Port 0.75” Probe port
Casters Yes
Unit Weight 195 lbs 253 lbs 440 lbs 465 lbs 465 lbs 694 lbs
Agency Listings UL UL, FDA UL UL UL, FDA UL, FDA
Performance
Peak Variance* 4.4oC 3.6oC 4.5oC 3.4oC 4.4oC 3.4oC
Stability + 2.0oC / - 2.0oC + 0.63oC / - NA + 1.32 C / -
o
+ 1.32oC / - + 0.88oC / -
1.4oC 1.34 C
o
1.34oC 1.87oC
Energy Consumption (KWhr/day)* 3.04 3.85 2.77 3.81 3.81 8.67
Adjustable Set Point Range 1oC to 12oC
Factory Set Point + 4 oC
Electrical Power/ Current 120v 60 Hz
Building Supply Rating 15 Amp
Power Plug/Cord Length NEMA 5-15 / 10ft cord
VFC Compliant Yes
Energy Star Yes
Indoor/Outdoor Use Indoor use only
Application Environment Non-corrosive, non-flammable, non-explosive
Ambient Operating Temp. (oC) 25oC to 32°C
Refrigeration
Refrigeration System Vapor compression system, forced-air
Compressor Hermetic sealed compressor
Condenser Type Steel tube and fins
Expansion Device Capillary tube
Evaporator Type Copper aluminium coated (1000 hours tested salty fog)
Defrost Smart- hot gas
Refrigerant R290 (Propane)- EPA, SNAP compliant
Controller/System Configuration
User Interface Microprocessor with digital display
Power Switch On/Off
Controller Type Digital controller
Security Lockable doors
Control Sensor NTC probe
Remote Alarm Terminals Standard
High/Low Alarms Standard
Power Failure Alarm Standard
Door Ajar Alarm Standard
Options Stainless steel, Roll-out drawers
Warranty 2 years parts & labor, 5 years on compressor parts
*Data according to EPA Energy Star https://www.energystar.gov/productfinder/product/certified-lab-grade-refrigeration/results
2021 VALUE-PERFORMANCE PRODUCT CATALOG
Value-Performance Line
K202 K204 K210 Refrigerators
USES: CLINICAL APPLICATIONS VACCINES & MEDICATIONS BIOLOGICS DIAGNOSTICS KITS MOLECULAR BIOLOGY INDUSTRIAL TESTING
Solid Door Refrigerators
K202SDR K204SDR K210SDR
MODEL CAPACITY EXTERIOR TEMP RANGE DOORS SHELVES DEFROST CERTIFICATION SHIPPING WT.
NUMBER CU. FT. / Height x Width x Depth (SETPOINT) LBS.
liters
K202SDR 2.5 / 70 25.75” x 20.1” x 20.9” +2° to +8°C 1 2 +1 88 lbs
K204SDR 4/113 31.68” x 23.75” x 20.89” (+35.6° to +46.4°F) Rt. Swing 2+1 AUTO UL 113.5 lbs
K210SDR 10/283 59.43” x 23.62” x 22.15” 6 176 lbs
Glass Door Refrigerators
K202GDR K204GDR K210GDR
MODEL CAPACITY EXTERIOR TEMP RANGE DOORS SHELVES DEFROST CERTIFICATION SHIPPING WT.
NUMBER CU. FT. / Height x Width x Depth (SETPOINT) LBS.
liters
K202GDR 2.5 / 70 25.75” x 20.1” x 20.9” +2° to +8°C 1 2 +1 88 lbs
K204GDR 4/113 31.68” x 23.75” x 20.89” (+35.6° to +46.4°F) Rt. Swing 2+1 AUTO UL 113.5 lbs
K210GDR 10/283 59.43” x 23.62” x 22.15” 5 176 lbs
Value-Performance Line
K202 K204 K210 Freezers
USES: CLINICAL APPLICATIONS VACCINES & MEDICATIONS BIOLOGICS DIAGNOSTICS KITS MOLECULAR BIOLOGY INDUSTRIAL TESTING
-25 Low Temperature Freezers
K202SDF K204SDF K210SDF
MODEL CAPACITY EXTERIOR TEMP RANGE DOORS SHELVES DEFROST CERTIFICATION SHIPPING WT.
NUMBER CU. FT. / Height x Width x Depth (SETPOINT) LBS.
liters
K202SDF 2.5 / 70 25.75” x 20.1” x 20.9” -10° to -25°C 1 2 +1 88 lbs
K204SDF 4/113 31.68” x 23.75” x 20.89” (+14° to -13°F) Rt. Swing 2+1 MANUAL UL 113.5 lbs
K210SDF 10/283 59.43” x 23.62” x 22.15” 5 176 lbs
• Intelligent microprocessor controller with digital • Forced air circulation aids temperature stability
display and adjustable temperature control and uniformity
• Audible and visual high or low temperature • Leveling legs
alarms • Keyed door lock
• Magnetically sealed door with rapid cool-down • Remote alarm contacts
mode after door opening
• 0.5” temperature probe and data logger access
• Door-activated and exterior switch-activated port
interior LED lighting
• UL listed
• White epoxy-coated wire shelves standard
• Built and shipped from ISO 9001:2008
• Shelves are adjustable by 1 inch increments manufacturing and distribution facilities
• Cabinet constructed of white powder-coated steel • Each cabinet undergoes three quality control
with CFC-free, high density insulation checks prior to shipping
• R600a refrigerant, an environmentally green • Warranty: two year full replacement for parts or
option compliant with future EPA and SNAP non- compressor failure
ozone depleting mandatesValue-Performance Line
K20345C / K20745C / K21045C Freezers
USES: CLINICAL APPLICATIONS VACCINES & MEDICATIONS BIOLOGICS DIAGNOSTICS KITS MOLECULAR BIOLOGY INDUSTRIAL TESTING
-45 Low Temperature Freezers
27.5″ 50″
37″
32.5″ 35.5″
35.5″
20.5″ 26.5″ 26.5″
K20345C K20745C K21145C
• Intelligent microprocessor controller with digital display • Cabinet constructed of white powder-coated 304 steel
and adjustable temperature control with CFC-free, high density insulation (2.4’ thick)
• Visual and Audible hi or low temperature, sensor failure, • Easy swivel casters
door ajar alarms • Built and shipped from ISO 9001:2008 manufacturing and
• Keyed door locks distribution facilities
• Magnetically sealed door with rapid cool-down mode • Each cabinet undergoes three quality control checks prior
after door opening for quick temperature recovery to shipping
• Door-activated and exterior switch-activated interior • Warranty: two-year full replacement for parts or
LED lighting compressor failure plus three additional years for
• One wire basket compressor replacement
MODEL CAPACITY EXTERIOR TEMP RANGE DOORS SHELVES DEFROST CERTIFICATION SHIPPING WT.
NUMBER CU. FT. / Height x Width x Depth (SETPOINT) LBS.
liters
K20345C 3.5 / 100 32.5” x 27.5” x 20.5” -10°C to -45C°C 1 1 basket 102 lbs
K20745C 7/198 35.5” x 37” x 26.5” Preset -40°C Lid 1 basket MANUAL UL / cUL 113.5 lbs
K21145C 11/311 35.5” x 50” x 26.5” 2 baskets 176 lbsValue-Performance Line
K205ULT / K210ULT / K221ULT / Ultra-low Temp Freezers
USES: CLINICAL APPLICATIONS VACCINES & MEDICATIONS BIOLOGICS DIAGNOSTICS KITS MOLECULAR BIOLOGY INDUSTRIAL TESTING
-86 Ultra-Low Temperature Freezers
Plug Type
Standard
NEMA
5-15
Initial
Power
Draw
K205ULT
9 amps
39.25″
K210ULT
83.5″ 11 amps
75.6″
K221ULT
13 amps
32.25″
28.75″ 32.0″
27.0″ 30.71″
36.22″
K205ULT K210ULT K221ULT
• Intelligent microprocessor digital LCD • Senor failure alarm • 0.5” temperature probe and data
display, password protected. • Refrigerant: CFC-Free logger access port
• Cabinet and ambient air temperature • Shelves are adjustable by 1” inch • CE listed
displays increments • Built and shipped from ISO 9001:2008
• Adjustable temperature control • Exterior and interior cabinet manufacturing and distribution
• Audible and visual high or low constructed of stainless steel with facilities
temperature alarms PUF-VIP, high density insulation • Each cabinet undergoes three quality
• Power failure audible alarm • Casters control checks prior to shipping
• Low battery audible alarm • Remote dry alarm contacts • Warranty: two-year full replacement for
parts or compressor failure
MODEL CAPACITY EXTERIOR TEMP RANGE DOORS SHELVES DEFROST CERTIFICATION SHIPPING WT.
NUMBER CU. FT. / liters Height x Width x Depth (SETPOINT) LBS.
K205ULT 5 / 140 39.25” x 32.25” x 28.75” -50°C to 0 275 lbs
K210ULT 9.88 / 280 83.5” x 27.0” x 32.0” -86C°C 1 3 AUTO UL / cUL 305 lbs
K221ULT 20.84 / 590 75.60” x 36.22” x 30.71” 3 685 lbsApplication FREEZERS REFRIGERATORS
Model# K202 K204 K210 K202 K204 K210
Storage Volume 2.5 cu ft 4 cu ft 10 cu ft 2.5 cu ft 4 cu ft 10 cu ft
Performance Characteristics
20.1”x 20.9”x 23.6”x 20.9”x 23.6”x 22.2”x 20.1”x 20.9”x 23.6”x 20.9”x 23.6”x 22.2”x
Exterior (W x D x H) 25.8” 31.7” 59.4” 25.8” 31.7” 59.4”
Insulation CFC-free, high density insulation CFC-free, high density insulation
Doors 1 1 1 1 1 1
Door Perimeter Heater Standard Standard
Shelves 3 3 5 3 3 5
Access Port 0.5” Probe port 0.5” Probe port
Leveling Legs Standard Standard
Unit Weight 88 lbs 113 lbs 176 lbs 88 lbs 113 lbs 176 lbs
Performance
Peak Variance* 6.69oC 7.25oC 7.19oC 4.73oC 6.51oC 5.42oC
Recovery
Stability + / - 2.0oC + / - 2.0oC + / - 2.0oC + / - 2 oC + / - 2 oC + / - 2 oC
Energy Consumption
0.58 1.15 2.42
(KWhr/day)* 0.75 0.97 1.9
Adjustable Set Point Range - 10oC to -30oC 2oC to 8oC
Factory Set Point - 25oC + 4 oC
Electrical Power/ Current 120v 60 Hz 120v 60 Hz
Building Supply Rating 15 Amp 15 Amp
Power Plug/Cord Length NEMA 5-15 / 10ft cord NEMA 5-15 / 10ft cord
Agency Listings UL UL
VFC Compliant Yes Yes
Energy Star Yes Yes
Indoor/Outdoor Use Indoor use only Indoor use only
Refrigeration System Vapor compression system, forced-air Vapor compression system, forced-air
Compressor Hermetically sealed compressor Hermetically sealed compressor
Condenser Type Foamed in Foamed in
Expansion Device Capillary tube Capillary tube
Evaporator Type Cold wall evaporator Cold wall Evaporator
Defrost Variable (cycle) Variable (cycle)
Refrigerant R600a (Isobutane)- EPA, SNAP compliant R600a (Isobutane)- EPA, SNAP compliant
Controller/System Configuration
User Interface Microprocessor with digital display Microprocessor with digital display
Power Switch On/Off On/Off
Controller Type Digital controller Digital controller
Security Lockable doors Lockable doors
Control Sensor NTC probe NTC probe
Remote Alarm Terminals Standard Standard
High/Low Alarms Standard Standard
Warranty 2 years Parts & Labor 2 years parts & labor
3029 Horseshoe Lane, Suite D
Charlotte, NC 28208
K2Sci.com
800.218.7613
info@k2sci.comYou can also read
