DENTAL UNITS. MADE IN GERMANY.
2018/2019
ULTRADENT. DENTAL UNITS. MADE IN GERMANY. SINCE 1924.
PRODUCT CATALOGUE
Company history – traditionally innovative.
When Hans Ostner founded ULTRADENT in Munich With Ludwig Ostner, the founder‘s nephew, and his
in 1924, he pursued values that we are still bound by son Ludwig Johann Ostner, we are currently headed
today: combining tradition and experience with dy- by business managers from two generations, who
namic inventive genius to continually raise technolo- unite the best of what craftsmanship has to offer with
gical achievements to new heights. ULTRADENT still today’s high technology.
develops and manufactures its products in Munich.
We are a midsize family company dedicated to the
advantages of company-controlled manufacture.
Philosophy. People.
Company-controlled manufacture across-the-board at ULTRADENT As one would expect from a manufacturing company with tra-
makes it possible to offer not only German craftsmanship but dition, numerous ULTRADENT employees have worked for us
also maximum flexibility. This means that we can react to our cus- for many years. Our company is also characterized by flat hie-
tomers’ requirements and special requests quickly and flexibly. As rarchies, short decision-making paths and the distribution of
a result, we guarantee the longevity and absolute reliability of the skills and responsibilities over several key players in addition to
treatment unit produced especially for you. the central executive management. Behind every ULTRADENT
product is a perfectly coordinated team that ensures smooth
processes: from development work and the finishing
manufacturing touches to our products through to
sales, services and customer service.
We work together hand in hand,
day in, day out.
Dedicated staff bring our
philosophy to the market.
Contents
2 ULTRADENT Company history 15 easy Prophy
3 Milestones in development 16 Fridolin
17 Multimedia systems
4 E-matic 18 Carts U 3000 EX I U 6000 F
5 U 6000 S 19 Rear-of-head units
6 U 6000 F 20 Treatment lamps
7 U 1600 21 Vario pillar system
8 U 1302 22 Instruments
9 U 3000 23 Pressurized water bottle systems
10 U 1280 24 Patient chairs
11 U 1301 L/R 25 Dentist‘s stools
12 easy KFO 1
13 easy KFO 2 26 Customers & products
14 easy KFO 3 27 Company head office
Milestones in development.
Technical ideas. Patents and utility models. Functional optimization. When
it comes to innovation, ULTRADENT has always been a decisive step ahead.
Today, the brand stands for comfortable work stations that are used by den-
tists, orthodontists, maxillary surgeons and providers of prophylactic care.
ULTRADENT’s company history began in
1924 with the production of electro-medical apparatus.
In 1930 the company succeeded in breaking into the dental market with Dentostat.
In 1957, ULTRADENT was the pioneer combining electronics and dental treatment:
The U 300 with electronically controlled speed stabilization.
In 1966, the U 500 was presented as a product innovation and developed over six
years to become the most successful post-war model.
By 1972, ULTRADENT had integrated UV polymerization units, turbine and cold-light
conductors, tartar removers and electric surgical devices in height-adjustable
floor-mounted units or trolleys.
In 1980, the U 3000 was launched, the most successful ULTRADENT product thus far.
For the first time, the focus was also on product design.
In 1986, ULTRADENT was once again a pioneer, replacing hydraulic treatment chairs
with electrically driven models.
In 1997, ULTRADENT presented its first own motorized chair from systematic
development in the shape of the GL 2020.
In 1998, multimedia technology was integrated in new treatment units.
In 2008, ULTRADENT fitted treatment chairs with the Full Touch Screen technology.
In 2013, ULTRADENT presented the global innovation vision U, an interlinked,
multifunctional multimedia concept with a large full-touch monitor.
In 2016, ULTRADENT integrated the Primea Advanced Air System – the unique
technology combining turbine and micro motor – in the premium class.
In 2017, ULTRADENT presented the first treatment unit with
pneumatically adjustable dental unit at the IDS.
3
| Premium class
Premium class
E-matic. The innovative dental unit.
E-matic is based on the successful U 6000 premium treatment unit. Its special
feature is the pneumatic parallel movement of the dental unit. A compressed air
cylinder gently moves the dental unit along a slide rail to any required position.
This provides the dentist with optimum access to the instruments, while ena-
bling patients to get on and off the chair unhindered. The assistant‘s unit and
the armrests can also be moved individually, thus providing unrivalled comfort.
Try out this innovation for yourself!
Images may differ from the current models. Differences in colour are possible.
4
Solaris 2 (LED)
E-matic Display treatment lamp
Armrest with UV 5090
moveable arm support Intraoral camera
Premium class | U 6000 S
Premium class
U 6000 S. The new premium standard.
This premium treatment unit is impressive due to not only its spectacular de-
sign entirely in white, but also the revolutionary vision U Multimedia system.
With the U 6000 treatment unit, ULTRADENT is setting new standards. The
elegant combination of technology and convenience help you to reach new
goals. There is also a full-touch display available for your dental assistants. Ex-
perience ULTRADENT’s top-of-the-range unit in your dental practice. Your team
and patients will be impressed too.
Indulge in this perfection!
Images may differ from the current models. Differences in colour are possible.
5
Premium
vision U Monitor Assistant‘s element
W&H ImplantMed U 651 Tray table
surgical motor
U 6000 F | Premium class
Premium class
U 6000 F. The mobile premium class.
ULTRADENT’s premium range also includes a treatment unit with a mobile
dental unit. Together with vision U, Primea Advanced Air and ImplantMed, the
dynamic U 6000 F concept opens up a world of possibilities in modern den-
tistry. The new armrests with a moveable arm support mean increased comfort
for patients and thus increased safety for the dentist. The cart allows optimum
access to the instruments in any treatment situation and an ideal view of the
full-touch colour display.
Go ahead and try out this dynamic product!
Images may differ from the current models. Differences in colour are possible.
6
Solaris 2 (LED)
U 6000 F Cart treatment lamp
Armrest with UV 5090
moveable arm support Intraoral camera
Premium class | U 1600
Premium class
U 1600. The mobile premium class.
The U 1600 treatment unit is ULTRADENT’s take on a modern instrument table
unit. Here, the art lies in our expertise. Each instrument is ideally positioned,
ready for you to pick up instinctively. You benefit from the security offered by a
trusted brand, as well as by easy-to-operate full-touch displays on both sides,
while your patients feel comfortable and safe. This can partly be attributed to
high-quality leather, soft or massage upholstery, armrests with a moveable arm
support and various head cushions.
So why not make the most of this comfort for yourself and your patient?
Images may differ from the current models. Differences in colour are possible.
7
U 1600 Premium
dentist‘s element Assistant‘s element
vision U Monitor Foot control
U 1302 | Compact class
Compact class
Special fittings: accent finish
U 1302. The reliable all-round talent.
The U 1302 includes a range of premium features that make this compact
treatment unit a first-rate all-round talent. The dental unit and the tray table
form a single unit and can be moved together to the ideal position. Five auto-
matic programs for chair control, up to three micro motors and an integrable
electrosurgery unit are available. It goes without saying that this bestseller in
the compact class offers all the advantages of the treatment units developed
in Germany and finished in Brunnthal near Munich. A long-term spare parts
supply and ease of servicing mean this investment holds its value
Images may differ from the current models. Differences in colour are possible.
8
U 1302 Solaris 2 (LED)
Dentist‘s element treatment lamp
Assistant‘s element Foot control
Compact class | U 3000
Compact class
U 3000. The mobile compact class.
The dental unit in the compact class U 3000 has a stable, non-tilting frame. Six
holders can be individually equipped with up to three micro motors, an elec-
trosurgery unit, a polymerization lamp and an intraoral camera. With its tried
and tested technology, versatile fittings and innovative modular structure, U
3000 comes very close to meeting the standards of the premium class. Typical
features of the ULTRADENT treatment units also include high reliability as well
as quick and safe operation. In addition to the suspended tray table, the cart
includes a rack for two standard trays. The U 3000 concept therefore particularly
meets a dentist’s need for flexibility and ergonomics.
Images may differ from the current models. Differences in colour are possible.
9
U 3000 Cart Neovo LCD Monitor
wireless foot control U 651 tray table
U 1280 | Compact class
Compact class
Special fittings: accent finish
U 1280. The individual compact class.
The instrument arm dental unit was developed at the request of numerous
dental practitioners. This unit is also based on the U 1302 system, meaning
that it incorporates all the advantages of this well-known and popular treat-
ment unit. It, too, allows straightforward and safe operation, the only difference
being that the position of the instruments has been adapted to meet individu-
al requirements. The instruments can be retrieved with no effort whatsoever
using an instrument arm and return to their storage recess as if by themselves.
A clearly arranged digital display makes it possible to precisely control all treat-
ment instruments, thus providing the familiar ease of operation.
Images may differ from the current models. Differences in colour are possible.
10
U 1280 Display
dentist‘s element Neovo LCD Monitor
wireless foot control Assistant‘s elementCompact class | U 1301 Left/Right
Compact class
U 1301 Left/Right. The versatile unit.
This treatment unit was developed based on the successful U 1301 model,
which means that it provides all the advantages of one of the best-selling
compact class units. Its special feature is that the U 1301 L/R can be switched
between left- and right-handed modes quickly and easily by just one person,
with no need for any tools. The dental unit is available as a classic instrument
table unit, in instrument arm design or as a mobile cart. This makes U 1301 L/R
a unique treatment unit that is able to meet practically any requirement and
offers a solution for every dental practice setting.
Images may differ from the current models. Differences in colour are possible.
11
U 1303 T Solaris 2 (LED)
Dentist‘s element treatment lamp
„Classic“ pressurized Left/Right function
water bottleeasy KFO 1 | easy class (Ortho)
easy class
easy KFO 1. The compact orthodontic unit.
easy KFO 1 is the result of over 35 years’ development in orthodontic dentistry
treatment units. The central operating unit with instrument holder is fixed to
the water supply unit with a multi-articulated arm and can easily be moved
to any required position. This gives patients increased freedom of movement
when they take a seat for the treatment. With easy KFO 1, there are no trailing
hoses or other obstacles on the access side. This prevents possible damage,
while helping to make patients feel comfortable from the outset.
Images may differ from the current models. Differences in colour are possible.
12
Solaris 3 (LED)
easy KFO 1 element treatment lamp
Tray table with cup holder „Solo Bottle“
+ forceps bracket pressurized water bottle(Ortho) easy class | easy KFO 2
easy class
easy KFO 2. The multifunctional orthodontic unit.
easy KFO 2 combines all the benefits of the successful compact class with the
‘easy’ concept. If you prefer to treat patients in the 9 o’clock to 13 o’clock positi-
on, and therefore wish to access the instruments on the right-hand side, then
the easy KFO 2 is the ideal solution for you. The instrument holder is fixed to the
stable, floor-mounted tray rack and can be folded in and out. Up to five holders
are available and the instruments they hold can be selected individually. You
can control all functions in a straightforward manner, with no hygiene risks,
using the foot control. The short chair base also allows maximum free space
for the dentist.
Images may differ from the current models. Differences in colour are possible.
13
easy KFO 2 element Assistant‘s element
Foot control Wireless foot controleasy KFO 3 | easy class (Ortho)
easy class
easy KFO 3. The versatile orthodontic unit.
This new orthodontic model in the easy class is the first choice for a cost-
effective introduction to the orthodontic treatment units from ULTRADENT.
easy KFO 3 is the perfect symbiosis of a proven concept, high reliability and ma-
ximum flexibility. The spittoon basin is actually only needed in very few ortho-
dontic treatments – the easy KFO 1 and easy KFO 2 are available for this. What is
different about easy KFO 3 is that it does not have an integrated spittoon basin.
As a result, the dentist unit can be positioned with a pivoting satellite arm to
the left and right of the chair and therefore offers the practitioner maximum
freedom of movement. The unit is fitted with a pressurized water bottle so a
connection to the building‘s water supply is not required.
Images may differ from the current models. Differences in colour are possible.
14
Solaris 3 (LED)
easy KFO 3 element treatment lamp
Tray table with cup holder Foot control
+ forceps bracketeasy class | easy Prophy
easy class
easy Prophy. The special prophylaxis unit.
The streamlined shape of easy Prophylaxis and the small amount of space it re-
quires make this unit the first choice, especially for small rooms. The fully equip-
ped dental unit even includes an integrated prophylaxis air polishing unit. The
pivoting instrument holder is positioned on the side facing the dentist. This
opens up new dimensions in ergonomics and practical efficiency during treat-
ment and preventative work, such as professional tooth cleaning.
Images may differ from the current models. Differences in colour are possible.
15
Neovo LCD Monitor Assistant‘s element
„Solo Bottle“ Wireless foot control
pressurized water bottleFridolin | Individual class
Individual class
Fridolin. Professional paediatric dentistry.
Treating children poses a particular challenge for patients and dentists alike.
Working with experienced paediatricians, ULTRADENT has developed this
treatment unit specifically to meet the requirements of modern paediatric den-
tistry. The height-adjustable dental unit can be concealed beneath the couch,
helping to make treatment as relaxing and worry-free as possible. In addition
to turbines, Fridolin can also be fitted with high-torque micro motors. This unit
is produced in accordance with the German Medical Products Act (MPG) and
has CE certification.
Images may differ from the current models. Differences in colour are possible.
16
Fridolin Solaris 3 (LED)
Dentist‘s element treatment lamp
Optional pressurized
suction device water bottleMultimedia system | vision U
vision U Toushscreen Monitor UV 5090 Intraoral Camera
Multimedia systems
Screenshot 3D data Screenshot maintenance overview Screenshot hygienic measures
Multimedia system | Basic
Neovo LCD monitor S-617 intraoral camera
vision U. Much more than just multimedia.
With vision U, ULTRADENT realizes many technical visions and achieves the fas-
cination of a future-oriented dental practice even today. vision U now provides
enhanced hardware functions such as the high-resolution presentation of ima-
ges and videos. The entertainment mode now shows images and videos in full
HD. Thanks to the additional HDMI input, vision U can be integrated effortlessly
into the existing practice network. In addition, the camera workflow has been
simplified and optimized.
The “Basic” multimedia package is also available as an affordable alternative.
Images may differ from the current models. Differences in colour are possible.
17
Screenshot
patient images USB connection
vision U Online info Basic multimedia system
online InfoU 3000 EX | U 6000 F | Mobile dental units
Mobile dental units
Unit-mounted
supply unit
U 6000 F
U 3000 EX
U 3000 EX. U 6000 F. Mobil und variabel.
These mobile dental units in the form of autonomous carts that can be indivi-
dually equipped provide even more flexibility. The compact design makes them
easy to connect to existing connection boxes or quick couplings for air and elec-
tricity. In addition, both dental units can be fitted with the wireless radio foot
control F9 and provide increased hygiene, especially for use in surgery rooms.
The U 3000 EX cart is also filled with its own, unit-mounted supply unit and a
pressurised water bottle.
Images may differ from the current models. Differences in colour are possible.
18
U 6000 F Display
U 3000 EX DisplayRear-of-head units | U 1300 HK | U 753
Rear-of-head units
U 1300 HK (dental unit with/without suction) U 753 (suction only)
Rear-of-head units.
The individual treatment situation.
ULTRADENT’s rear-of-head treatment systems are ideally suited for installati-
on outside of the patient’s direct field of vision. For example, they fit into a
cabinet module to the rear or side of the head and can be effortlessly moved
towards the patient. This not only allays children’s fears, but makes all patients
more relaxed. Moreover, the units save space and fit in perfectly with your
dental practice setting.
Images may differ from the current models. Differences in colour are possible.
19
U 1300 HK Display
Pressurised water Multifunctional syringe
bottle systemsSolaris 2 / Solaris 3 | Treatment lamps
Solaris 2
Treatment lamps
Solaris 3
Solaris 2/3 LED. Light as it is meant to be.
Solaris 2 provides the best CRI value ever achieved to date using LED technolo-
gy: CRI ≥ 95. This treatment lamp features adjustable light output of between
2,500 and 42,500 lux while the colour temperature remains constant at 5000 K.
The high-quality LEDs of both lamps have an extremely long service life. Solaris
lamps are thus not only efficient, high-performance working lamps, but also a
cost-effective investment. In the premium class, the operating lamps can also
be switched on or off via the assistant’s unit. As there is no tangible increase in
temperature thanks to the modern LED technology, Solaris lamps operate silent-
ly, without a cooling fan. One poly switch is provided with Solaris 2 as standard.
Images may differ from the current models. Differences in colour are possible.
20
Solaris 2 (LED)
treatment lamp Wall-mounted
Solaris 3 (LED) Ceiling-mounted
treatment lampPillar system | Vario
Vario floor stand large
Pillar system
Vario floor stand small
Vario floor stands.
For flexible and individual application.
Special treatment rooms usually require special solutions. The Vario floor stands
with their versatile pillar systems open up new possibilities for equipping den-
tal practice rooms. The systems can also be integrated flexibly and reliably for
subsequent partial upgrades or for equipping new treatment rooms that have
particular space requirements. With the small Vario floor stand and the ceiling-
mounted pole, for instance, it is possible to add intraoral x-ray equipment,
Dr. Mach operating lamps or microscopes to a treatment unit.
Images may differ from the current models. Differences in colour are possible.
21
Vario Small: adapter Vario Small:
for operating lamp adapter for X-ray
Dentist‘s elements Treatment lamps
e.g. U 1280 e.g. Solaris 2Instruments
Instruments
W&H Primea Multifunctional Siringe Ultradent Slim-LED ScanWave
Advanced Air System with/without Mediaheating Light-Polymerisation
W&H ImplantMed ULTRADENT K 2 micro motor w. fibreoptic KL 7 S - LED micro motor w. fibreoptic Electrosurgery unit
surgical motor surgical motor 4.000 - 40.000 U/min 100 - 40.000 U/min
W&H ImplantMed. Instruments.
The integrated surgical motor The integration of dental instruments into the treatment
for the premium class. unit increases safety, saves space and facilitates hygiene in
the treatment room. Bearing this in mind, ULTRADENT offers
With a motor torque of 4.3 Ncm and motor speed range of
a large number of instruments that are fully incorporated
300 to 40,000 rpm, ImplantMed impressively demonstrates
into its treatment units. The instruments are thus ideally
its power. The automatic torque control, which can be set
positioned, and are also controlled via the dental unit or
in a range from 5 to 70 Ncm, provides the required safety.
assistant’s unit.
Images may differ from the current models. Differences in colour are possible.
22Pressurized water bottle systems
Pressurized water bottle systems
Duo Bottle Solo Bottle Classic
2 pressurized water bottles 1 pressurized water bottle Pressurized water bottle
Pressurized water bottle systems.
For every treatment situation.
ULTRADENT offers the right pressurized water bottle for every treatment sys-
tem, for example the patented “Duo Bottle” system. This consists of two bottles,
a level display and a facility to switch over to the full bottle automatically.
As a result, the empty bottle can be removed and refilled without the need to
interrupt treatment.
* on request also available as an add-on kit for third-party units.
Images may differ from the current models. Differences in colour are possible.
23
“Duo Bottle” bottle exchange systemT 10 | T11 | UD 2010 | UD 2015 | UD 2021 | UD 2022 | Patient chairs
T 10 T 11
(Available with fixed or 345° rotating base plate) (Available with fixed or 345° rotating base plate)
Patient chairs
UD 2010 UD 2015
UD 2021 UD 2022
Patient chairs. Practical and comfortable.
ULTRADENT treatment chairs are available with a range of individual upholstery,
headrest and backrest options. This allows you to offer patients maximum com-
fort when sitting and lying down. The broad range of equipment and wide ran-
ge of movement provide dentists with useful application options even when
space is restricted – for everything from general dental treatment to paediatric
dentistry and even prophylaxis, orthodontics and surgery.
Images may differ from the current models. Differences in colour are possible.
24
T 10 with with fixed base plate
T 11 with 345° rotating base plateDentist‘s stools | IRON A/D/S
IRON A IRON D
Dentist‘s stools
IRON S
Dentist‘s stools. The definition of sitting correctly.
Ergonomics is the key factor for a dentist’s health. ULTRADENT dentist’s chairs
feature comfortable seat upholstery (seamless) and various settings. The seat
height, the armrests and the inclination of the backrest can be adjusted,
thus increasing the seating comfort and dentist’s endurance. All ULTRADENT
saddle chairs have a seat with an adjustable tilt.
Images may differ from the current models. Differences in colour are possible.
25
IRON A rotating backrest
IRON A/D/S chromed frameCustomers & products – trust through competence and commitment.
With fully-developed high-tech expertise, we tap new Our products are highly regarded, not only in Germany,
potential in the areas of comfort, efficiency and safety Austria and Switzerland but also further afield. In the
– for dentists and their patients. ULTRADENT offers a area of sales, we work with numerous capable dental
complete range of treatment chairs for dentists, ortho- depots. We provide their employees with specific in-
dontists, maxillary surgeons and providers of prophyl- struction and regular training for current products.
actic dental care.
You can find an overview of our products online at:
www.ultradent.de/en
Quality multiplied by individuality.
What makes us strong? The fact that we naturally provide
you with excellent quality, from the material or design right
down to the smallest technical details. This means that we
produce every one of our products in our manufacturing
facilities in Munich. What is more, the components we use
also come from Germany, where possible from partners in
the Munich region.
Our customers appreciate the service ULTRADENT offers:
“ULTRADENT Model easy KFO impressed me im- “ULTRADENT completely equipped our clinic’s den-
mediately. I am still fascinated by the tal department with its modern treatment units.
excellent mix of function, ergonomics, What I found particularly good was the fact it was
production quality and design.” absolutely no problem for the company to meet
Dr. Kirchner, Orthodontist, Munich our many special requirements.”
Dr. Udo Paeske, Haranniklinik Herne
26 “ULTRADENT has a wonderful dental chair that was
specially developed for children: Fridolin. Congra-
tulations on this unique concept!”
Dr. Brem, Children’s dentist, MunichCompany head office – presence and professionalism.
If you stand still, you‘ll get left behind. ULTRADENT takes As a result, our customers and business partners can
this to heart, not only in product development. Back in reach us easily. But it doesn‘t stop there. We have even
2010, we embarked on a new chapter in our history of more room here to develop new ideas.
company-controlled dental manufacture and took an We warmly invite you to visit us and gain your own
important step for the future. ULTRADENT relocated impression of the ULTRADENT products.
and moved into a new head office in south Munich.
Are you interested in ULTRADENT and the treatment units we to demonstrate the latest ULTRADENT products live. Contact us
manufacture? If so, please contact us. We would love to see you! directly to arrange a personal appointment for a showroom visit:
In addition to our unique dental museum at the head office in Tel.: +49 89 420 992-71
south Munich, you can also visit the ULTRADENT showroom by
prior appointment. Our qualified customer advisors will be happy
The following figures illustrate our success. You’ll be impressed!
Over 20,000 ULTRADENT treatment units are in use in practices in Germany.
At the ULTRADENT site, several hundred treatment units
are produced over an area of 4,000 square meters.
ULTRADENT’s high-tech expertise is documented, for example,
by numerous patents and utility models.
A look at our business development is also indicative:
Within the last 10 years, ULTRADENT’s annual sales have doubled.
Highly qualified employees are the reason behind this impressive performance.
Our focus on quality is also clearly documented. We are certified by TÜV Süd
to EN ISO 13485 Medical Devices - Quality Management Systems and comply
with all the standards and regulations specified by the medical devices act.
27Order. no. 368821
Published: August 2018, 1st edition
We reserve the right to make technical changes
and accept no liability for typesetting or printing errors.
© Concept & implementation: MMS. The Agency.
(QR-Code is a registered trademark
of DENSO WAVE INCORPORATED)
ULTRADENT Website
www.ultradent.de/en
Your ULTRADENT specialist dental retailer
D E N TA L U N I T S . M A D E I N G E R M A N Y.
Dental-Medizinische Geräte GmbH & Co. KG
D-85649 Brunnthal | Eugen-Sänger-Ring 10
Tel. + 49 89 420 992 - 70 | Fax + 49 89 420 992 - 50
www.ultradent.de | info@ultradent.deYou can also read
