WINE ON TAP DRAFT GUIDE F R E E F LO W W I N E S
WHY WINE ON TAP? 96% reduction in CO2
footprint with reusable
NO WASTE stainless steel kegs
No oxidized wine. No trash to throw CO2
away.
ECO FRIENDLY One steel keg saves the
Steel kegs are 100% reusable. 28 TREES CO2 equivalent to that
sequestered by 28 trees
FRESHNESS
Guaranteed freshest glass of wine
from the 1st pour to the last. Each steel keg put
2 YEARS
into service eliminates
the carbon emissions
SPEED OF SERVICE ON THE ROAD
equivalent to taking a
No corks to pull, bottles to stock or car off the road for
two years
recycle.
TRENDING
Each steel keg will save
Hottest new trend in the food &
2,340 lbs of trash from
beverage programs across the country. 2,340 lbs the landfill over its
lifetime
GREENER, FRESHER, BETTER
Average cost savings per keg = $18
Most accounts see a Return on
Investment within 6 months!
Calculate the ROI for your program at
TRYWINEONTAP.COM /restaurant/cost
MEET OUR KEGS
HEIGHT 24” X 9.5” Sixth Barrel Kegs
WEIGHT 58 lbs full
5.16 gallons
26 bottles
132 5 oz pours 26 bottles
132 5 oz. glasses
FRESHNESS 18 months untapped 5.16 gallons
3 months tapped 19.5 liters
STANDARD American Sankey D Fittings 58 lbs full
9.25” wide x 24” tall
WHY STAINLESS STEEL?
WINE QUALITY
Only stainless steel kegs are impermeable
to oxygen and stay fresh up to 18 months
untapped & 3 months once tapped.
STANDARD SIZE + PARTS
Our 1/6th barrel kegs have standard
dimensions & fit into all draft systems.
ENVIRONMENTAL
Reusable steel kegs save millions of pounds
of trash from the landfill every year.
Compared to disposable plastic kegs, steel
kegs reduce the carbon footprint 30-50%
& up to 96% better than wine in bottles.
HOW DOES IT WORK?
Free Flow Wines is a kegging &
logistics company. We facilitate
connections between winery
clients, distributors, sales reps
& draft system installers to
make wine on tap easy for you.
Free Flow Distributor
Free Fow Invoices Distributor
Premium $30 deposit per Keg
Wine
FULL FULL FULL FULL FULL FULL
Free Flow Fill Kegs Distributor Sells Kegs
Distributor Invoices
Free Flow Credits Restaurant $30 deposit
Distributor $30 deposit per Keg
per reurned, empty Keg
Restaurant
Distributor
FULL FULL FULL
EMPTY EMPTY EMPTY
Distributor Credits
Restaurant $30 deposit
per returned, empty Keg EMPTY EMPTY EMPTY
Distributor consolidates
empty kegs
Restaurants empty kegs
COMMON WINE DRAFT SYSTEM INSTALLATIONS
304-GRADE STAINLESS 304-GRADE STAINLESS
STEEL FAUCETS STEEL COUPLER
DIRECT DRAW WINE SYSTEM
Kegs are located in refrigeration unit REGULATOR & GAS
beneath taps. Perfect for restaurants and (75% NITROGEN / 25% CO2)
bars that have space at or very near the
point of dispense. The short draw maxi-
mizes loss and ensures best serving tem-
perature.
WINE-GRADE LINES
+ PLUS FITTINGS, MISC PARTS, ETC.
LONG DRAW WINE SYSTEM
Kegs are located away from taps. Tempera-
ture controlled lines carry wine from kegs
to taps. The long draw system ensures the
wine arrives at the point of dispense at the 304-GRADE STAINLESS
STEEL COUPLER GLYCOL TRUNK LINE
correct temperature and is protected along AND GLYCOL LINES
the way. Long draw systems vary widely
on installation complexity, time and cost. 304-GRADE STAINLESS STEEL FAUCETS
POWER PACK (COOLING SYSTEM)
REGULATOR & GAS WINE-GRADE LINES
(75% NITROGEN / 25% CO2)
+ PLUS FITTINGS, MISC PARTS, ETC.
MOBILE DISPENSE OPTIONS 2-4 Tap Kegerator 2 temperature controlled compartments (each hold 2 x 1/6 kegs) Approx. Dimensions: 24.25”W x 31”D x 42”H 6-8 Tap Kegerator 2 temperature controlled compartments (each hold 4 x 1/6 kegs) Approx. Dimensions: 59.5”W x 28.25”D x 37.25”H Exterior Options: Black 1-4 Tap Bartop Dispenser 1-4 temperature controlled lines carry wines from keg to taps Approx. Dimensions: 7”W x 17”D x 15”H RETROFIT YOUR BEER LINES FOR PREMIUM WINE ON TAP! A beer draft system can be modified for a consistent premium wine on tap pour every single time. For an existing direct draw system retrofit, all you need is: 1. Wine-certified Hardware, NO BEER PARTS! Any metal that touches wine needs an upgrade to 304 grade stainless steel (this includes your tower, faucets and couplers) 2. Wine Grade Tubing to prevent oxygen leaks, flavor transfer and off tastes. Lines and hardware need to be cleaned quarterly, or when a keg is changed or replaced. 3. A blend of 75% Nitrogen and 25% CO2 (AKA Guinness Gas or BevGas) should be used. For direct draw, a pressure setting of 4-7 PSI is all that’s needed.
BEST PRACTICES
DISPENSING TEMPERATURES
STILL WINE 40 - 45° for Whites
55 - 60° for Reds
GAS
75% Nitrogen/ 25% CO2, AKA 15
100
Beverage Gas or “Guinness Gas”, 0 30 0 200
ensures that the wine tastes
exactly as the winemaker intended, Pressure
from the first pour to the last glass
G as Ta n k
GAS PRESSURE
Pressure gauge reading should be
between 4 - 10 PSI
STORAGE
Store untapped kegs with other
wines. Wine stays fresh – tapped 3
months, untapped 12 months
LINE CLEANING FREQUENCY
Every 3 months, or at change of
product
EQUIPMENT
Use a Flow Control Faucet (sold by every SPARKLING WINE
major draft parts supplier) to control
foaming
Use only wine-certified 304-grade Stainless
Steel (No 303-grade steel or Beer Parts!) &
non-oxidizing “flavorlock” tubing
DISPENSING TEMPERATURE
35-40° F
GAS
Use beverage grade CO2 gas only
Keep the pressure around 20 PSI 50
(will vary depending on tubing length) 100%
0 100 CO2
STORAGE
Store sparkling wine kegs with other
wines in chilled room. Once
sparkling wine is kegged the keg
should be tapped within 12 months
Once sparkling wine keg is tapped it
stays fresh up to 3 months
LINE CLEANING FREQUENCY
Every 3 months, or at change of
productADJUSTMENTS
FLOW OF WINE Wine coming out too fast or too slow?
Wine coming out too fast or too slow?
Locate the regulator (attached to the gas).
Check upper gauge (0-60 psi). LOW PRESSURE
Using a flat head screw driver, twist the screw to the right GAUGE
to increase flow; twist left to decrease flow.
REPLACING GAS
If the left gauge of the regulator reads less than 300 psi, It’s time
to change the gas. Here’s how:
Turn off the gas by closing screw valve at the top of the tank.
Unscrew the brass nut connecting the regulator to the tank CONNECTOR
Pull old tank out & replace with a new one.
Screw in the regulator and then turn on the tank.
ADJUSTING
SCREW
HIGH PRESSURE SAFETY
GAUGE RELEASE VALVE
SHUT OFF/
TROUBLESHOOTING BACKFLOW
PREVENTER
FOLLOW THESE STEPS, THEN TEST FOR SUCCESS
Make sure couplers are properly attached to kegs, REGULATOR
handles pushed down & locked
A regulator adjusts and controls the flow of gas from any
source. Each regulator typically has at least one and often
Are you out of wine? Might be time to change your keg... two pressure gauges that help in setting pressures and
Confirm gas is turned on (see large valve at top of gas monitoring gas levels: one high-pressure gauge showing
the tank or supply pressure, and a second low-pressure
tank)
gauge showing what is being delivered to the keg.
Check that the red valve on gas is open (not
perpendicular to gas line)
Check the reading on left gauge of the regulator
(attached to the gas tank behind the red wine)
If it’s less than 300 psi, change the gas tank (see
“Adjustments”)
For more helpful info
& resources, visit
TRYWINEONTAP.COM
855-KEG-WINE
