Product Guide
& Specifications
For inquiries and orders, please contact: sales@lubchem.com 1
2 For inquiries and orders, please contact: sales@lubchem.com
PO Box 2626, Spring, TX 77383
23609 W. Hardy Rd., Spring, TX 77373
Order: 800-929-0244 Fax: 281-288-0849
Table of contents........................................................................................................Pages
LUBCHEM – EVERLAST PRODUCTS
• EV1 - Multi-purpose Lubricant
• EV1WG / EV1AG - Low Temp Multi-purpose Lubricant
• EV3 - High Temp / High Pressure................................................................................................................ 5
• EV960 - Hydrocarbon Resistant
• EV960WG - Low Temp Hydrocarbon Resistant
• EV960AG - Extreme Low Temp Hydrocarbon Resistant.......................................................................... 6
• EV3WG / EV3AG - Low Temp / High Pressure
• EV4 - Hydrocarbon Resistant
• EV4B - Gate Valve Lubricant / Sealant....................................................................................................... 7
• EV146 - Hydrocarbon Resistant
• EVK - 1000 High Temp Valve Lube
• EVWR - Severe Corrosive Service.................................................................................................................8
• EV117 - EP Valve Lubricant / Sealant
• 50-300 - Low Temp Valve Lubricant / Sealant
• 50-400 - Valve Lubricant / Sealant (H2S & C02)..........................................................................................9
• 50-400HV - High Viscosity Valve Lubricant / Sealant (H2S & C02)
• 50-400H20 - Frac Valve Lubricant / Sealant (H2S & C02)
• 50-400DA - Low Temp Valve Lubricant / Sealant (H2S & C02)................................................................10
• 50-400WG - Plug Valve Sealant / Ball and Gate Valve Lubricant (H2S & C02)
• 50-400AG - Plug Valve Sealant / Ball and Gate Valve Lubricant (H2S & C02)
• 50-500 - Plug Valve Sealant / Ball and Gate Valve Lubricant (H2S & C02)............................................ 11
• LLM - Longlife Moly Heavy Duty Moly Lubricant
• SVD / SVC - 102 Special – Peanut Butter Type (Standard and Creamy)
• M196 – 196 Sealant for McEvoy Valves..................................................................................................... 12
LUBCHEM – FORMASIL PRODUCTS
• FWR - Valve Sealant
• FRS - Valve Sealant
• FHD - Valve Sealant
• FRG - Valve Sealant
• ARS - Arctic Grade Sealant
• FH2O - Valve Sealant................................................................................................................................... 13
• FSCW - Winter Grade
• FCO2 - Valve Lubricant / Sealant (H2S & C02).......................................................................................... 14
For inquiries and orders, please contact: sales@lubchem.com 3
Table of contents........................................................................................................Pages LUBCHEM – VALVE STEM PACKING • 1900 - TFE Seal ............................................................................................................................................ 14 LUBCHEM – VALVE CLEANERS / VALVE FLUSH • VSAW - Valve Cleaner / Lubricant • VSB - Valve Cleaner • LVF – Honey Oil Valve Flush Cleaner........................................................................................................ 15 LUBCHEM – PREMIUM LUBRICANTS • BPA - Longlife 1600 A Arctic Grade Lubricant • LL1600 - Longlife Multi-Purpose Lubricant • LL1603 - Longlife Multi Purpose Lubricant ............................................................................................. 16 •SRL50 – Longlife SRL50 Sucker Rod Lubricant......................................................................................... 17 LUBCHEM – INDUSTRIAL PRODUCTS • Copper Coat 1800 • 2200 Anti-Seize - Aluminum Flakes • LUBE-ZIT - Penetrating Oil & Lubricant....................................................................................................18 • MOLY-VAP - Dry Moly Lubricant • PROCOAT 690 - Pipe Coating and Corrosion Inhibitor............................................................................19 LUBCHEM – WIRELINE PRODUCTS................................................................................................................20 LUBCHEM – VALVE CAPACITY CHART...........................................................................................................21 LUBCHEM – ORDERING INFORMATION.......................................................................................................22 4 For inquiries and orders, please contact: sales@lubchem.com
Lubchem Valve PO Box 2626, Spring, TX 77383
23609 W. Hardy Rd., Spring, TX 77373
Lubricants / Sealants Order: 800-929-0244 Fax: 281-288-0849
Everlast 1 Everlast 1 WG/AG Everlast 3
Multi-Purpose Lubricant Low Temp Multi-Purpose High Temp/High Pressure
Product Code Product Code Product Code
EV1 Winter Grade - EV1WG EV3
Arctic Grade - EV1AG
Everlast 1 is a biodegradable synthetic Everlast 1 Winter Grade and Arctic Grade Everlast 3 is a synthetic lubricant for
lubricant for use in valves carrying aliphatic are low temp synthetic lubricants for use high-temperature applications in hydrocarbon
hydrocarbon liquids and gases including, in valves carrying aliphatic hydrocarbon service. Everlast 3 is chemically resistant
kerosene, fuel oils, crude distillates; sweet liquids and gases including, kerosene, fuel to aliphatic liquids and gases including
or sour, water, condensate, dilute acids and oils, crude distillates; sweet or sour, water, gasoline and kerosene, fuel and lubricating
caustics. It is waterproof and has excellent condensate, LPG systems, dilute acids and oils, natural gas and brine water. Everlast 3
resistance to oxidation and high metal caustics. It is waterproof, and has excellent is effective at temperatures to 550°F and
adhesion. Everlast 1 should be used as a resistance to oxidation. is fortified with antirust, anti-wear, and
hydrocarbon resistant ball and gate valve corrosion inhibitors. The unique additive
lubricant. Everlast 1 is approved by most package in Everlast 3 bonds to metal
Applications
major valve manufacturers. surfaces reducing the damaging effects of
• Designed for low torque valve operation
in cold environments corrosion and scale deposition on critical
valve components.
Applications • For use in gate, plug and ball valves
• For use in plug, gate and ball valves • Suitable for use in hydrocarbon gases
• Suitable for use in hydrocarbon gases • DO NOT use in oxygen service Applications
• DO NOT use in oxygen service • For use in plug, gate and ball valves
• Suitable for use in hydrocarbon gases
Features
• DO NOT use in oxygen service
Features • Water resistant
• Water resistant • Fully additive treated
• Fully additive treated • High metal adhesion Features
• 100% synthetic • Excellent corrosion resistance • 100% synthetic
• High metal adhesion • Inhibited for H2S • Water resistant
• Inhibited for H2S • Fully additive treated
• High metal adhesion
Physical Properties
• Inhibited for H2S
Physical Properties • Consistency, Cone Penetration
• Consistency, Cone Penetration (D-217) WG 230 to 280 / AG 230 to 250
(D-217) 200-230 • Dropping Point, °F (D-566) Physical Properties
• Dropping Point, °F (D-566) None • Consistency, Cone Penetration
None • Oil Separation, % wt. loss (D-1742) (D-217) 150-200
• Oil Separation, % wt. loss (D-1742) 5 max • Dropping Point, °F (D-566)
5 max • Rust Preventative Test (D-1743) None
• Rust Preventative Test (D-1743) Pass • Oil Separation, % wt. loss (D-1742)
Pass • Temperature Range 5 max
• Temperature Range Winter Grade -40° to 450°F • Rust Preventative Test (D-1743)
-20° to 400°F Arctic Grade -70° to 620°F Pass
• Color • Color • Temperature Range
Amber Amber -10° to 550°F
• Type Oil • Type Oil • Color
Synthetic Synthetic Tan
• Corrosive Inhibitor • Corrosive Inhibitor • Type Oil
Imidazoline Derivative Imidazoline Derivative Synthetic
• EP Additive • EP Additive • Corrosive Inhibitor
Diester Type Diester Type Imidazoline Derivative
• EP Additive
Diester Type
For inquiries and orders, please contact: sales@lubchem.com 5
Lubchem Valve Lubricants / Sealants
Everlast 960 Everlast 960 WG Everlast 960 AG
Hydrocarbon Resistant Low Temp Hydrocarbon Extreme Low Temp
Resistant Hydrocarbon Resitant
Product Code
EV960 Product Code Product Code
EV960WG EV960AG
Everlast 960 is a dual-purpose lubricant/ Everlast 960 Winter Grade offers superb Everlast 960 Arctic Grade is the only valve
sealant formulated using Lubchem’s internal valve protection in cold climates. It lubricant which allows for extreme low tem-
proprietary premium Lube flex base has excellent dual resistance to water and perature pumpability while being insoluble
oils. It is highly insoluble in the most petroleum products. Everlast 960 WG is for- in hydrocarbons. Everlast 960 AG is formu-
extreme hydrocarbon, solvent and gas mulated from Lubchem’s proprietary line of lated from Lubchem’s proprietary Lubeflex
environments. Everlast 960 is a blend of Lubeflex base oils. Lubeflex oils provide an line of base oils. These oils are unique in
synthetic oils for use in valves carrying LPG, insoluble lubricant coating of internal valve that they are insoluble in a multitude of
LNG, aliphatic hydrocarbon liquids and components which shields metal surfaces different hydrocarbons while at the same
gases including kerosene, fuel oils, sweet from the harsh hydrocarbon environments time allowing for minimal valve torque at
and sour crude distillates, dilute acids, and while maintaining ease in pumpability in extreme low temperatures. Everlast 960
caustics. Everlast 960 provides the highest cold environments. AG is a synthetic lubricant formulated for
level of protection by adhering to and high chemical and mechanical stability to
coating internal valve surfaces. It is water general hydrocarbon service. The synthetic
resistant and has excellent resistance to Applications polymer oils used in Everlast 960 AG make
oxidation. • For use in ball, plug, and gate valves this an excellent all purpose valve lubricant
• DO NOT use in oxygen service and sealant for the oilfield in extreme low
• CO2 service 288°C
• Color • Rust Preventative Test (D-1743) – Pass
Charcoal Gray • Color
Charcoal Gray
6 For inquiries and orders, please contact: sales@lubchem.com
PO Box 2626, Spring, TX 77383
23609 W. Hardy Rd., Spring, TX 77373
Order: 800-929-0244 Fax: 281-288-0849
Everlast 3 WG/AG Everlast 4 Everlast 4B
Low Temp/High Pressure Hydrocarbon Resistant Gate Valve Lubricant/Sealant
Product Code Product Codes Product Code
Arctic Grade - EV3WG EV4 EV4B
Winter Grade - EV3AG
Everlast 3 is a premium lubricant for high- Everlast 4 is a biodegradable synthetic EVERLAST 4B is a high performance
pressure applications in low temperature lubricant formulated for high chemical and synthetic valve lubricant and sealant for
hydrocarbon service. Everlast 3 is available mechanical stability to general hydrocar- gate valves. The advanced polymers and
in both arctic & winter grades. It is resistant bon service. The synthetic polymer oils extreme pressure additives used in this
to aliphatic liquids and gases including used in Everlast 4 make this an excellent all product make it an excellent choice for use
gasoline and kerosene, fuel and lubricating purpose plug valve lubricant and sealant for in high-pressure valves carrying natural
oils, natural gas and brine water. Everlast the oilfield and petrochemical industries. gas, crude oil, condensate and ethylene.
3 AG is effective to temperatures to -70°F Everlast 4 is a blend of synthetic oils for Everlast 4B contains unique solid lubricant
and is fortified with antirust, anti-wear and use in valves carrying LPG, LNG, aliphatic additives that prevent metal to metal con-
corrosion inhibitors. The unique additive hydrocarbon liquids and gases including, tact under extreme conditions of pressure
package in Everlast 3 bonds to metal kerosene, fuel oils, crude distillates; sweet and temperature.
surfaces reducing the damaging effects of or sour, water, condensate, dilute acids and
corrosion and scale deposition on critical caustics. It is waterproof and has excellent
Performance
valve components. resistance to oxidation and high metal
Everlast 4B is a specialized lubricant for
adhesion.
close tolerance valves and will provide
Applications outstanding lubricity and high adhesion
• Valves in Arctic Climates Applications to polished metal surfaces. This grease
• For use in plug, gate and ball valves • For use in plug, gate and ball valves provides corrosion protection and is
• Suitable for use in hydrocarbon gases • Suitable for use in hydrocarbon liquids water-resistant.
• DO NOT use in oxygen service and gases
• DO NOT use in oxygen service Physical Properties
Features • Color
• 100% synthetic Features Black
• Water resistant • 100% synthetic • Temperature Range
• Fully additive treated • Water resistant -20°F to 450°F
• High metal adhesion • Fully additive treated • Penetration, 25 Deg. C, WKD, 60 STR.
• Inhibited for H2S • High metal adhesion 195-220
• Inhibited for H2S • Drop Point, Deg. C
None
Physical Properties
• Consistency, Cone Penetration Physical Properties
(D-217) 230-250AG / 235-280WG • Consistency, Cone Penetration
• Dropping Point, °F (D-566) (D-217) 150-200
None • Dropping Point, °F (D-566)
• Oil Separation, % wt. loss (D-1742) None
5 max • Oil Separation, % wt. loss (D-1742)
• Rust Preventative Test (D-1743) 5 max
Pass • Rust Preventative Test (D-1743)
• Temperature Range Pass
Winter Grade -40° to 620°F • Temperature Range -10° to 450°F
• Arctic Grade -70° to 620°F • Color
• Color Brown
Gray • Type Oil
Synthetic
• Corrosive Inhibitor
Imidazoline Derivative
For inquiries and orders, please contact: sales@lubchem.com 7
Lubchem Valve Lubricants
Sealants / Sealants
Everlast 146 Everlast 1000 Everlast WR
Hydrocarbon Resistant High Temp Valve Lube Severe Corrosive Service
Product Codes Product Codes Product Code
EV146 EVK EVWR
Everlast 146 is a synthetic lubricant Premium synthetic oils and inorganic Lubricant for use in valves carrying CO2,
formulated for high chemical and mechani- thickeners make Everlast 1000 a high H2S, NGL, methanol, crude oil, produced
cal stability to general hydrocarbon service. temperature, non-melting lubricant/ waters, strong acids, natural gas, and
The synthetic polymer oils used in Everlast sealant for valves in geothermal, petroleum fuels where extreme temperature swings
146 make this an excellent all purpose gate refineries and natural gas plants. This high may occur. Everlast WR is highly chemical
valve lubricant and sealant for the oilfield. temperature lubricant/sealant is formulated resistant, has a wide temperature range
Everlast 146 is a blend of synthetic oils for for resistance to aliphatic hydrocarbons and is fortified with antirust, anti-wear, and
use in valves carrying LPG, LNG, aliphatic including gasoline, kerosene, propane, corrosion inhibitors. The unique additive
hydrocarbon liquids and gases including, butane, natural gas, steam, hot oil, dilute package in Everlast WR bonds to metal
kerosene, fuel oils, crude distillates; sweet acids and caustic solutions. Everlast 1000 is surfaces reducing wear and the damaging
or sour, water, condensate, dilute acids and an excellent moly/graphite type anti-seize effects of corrosion due to organic acid
caustics. It is waterproof and has excellent compound and should be used to protect attack.
resistance to oxidation and high metal threaded connections from galling, and
adhesion. wear. Everlast 1000 converts to a dry film Applications
lubricant at elevated temperatures and will • For use in plug, gate and ball valves
not harden.
Applications • Suitable for use in hydrocarbon gases
• For use in gate valves • DO NOT use in oxygen service
• Suitable for use in hydrocarbon liquids Features
and gases • Non melting Features
• DO NOT use in oxygen service • Converts to a solid film lubricant • 100% synthetic
• Contains molybdenum disulfide (moly) • Water resistant
Features • Fully additive treated
• 100% synthetic Physical Properties • High metal adhesion
• Water resistant • Consistency, Cone Penetration (D-217) • Inhibited for H2S and CO2
• Fully additive treated 200 to 225
• High metal adhesion • Dropping Point, °F (D-566) Physical Properties
• Inhibited for H2S None • Color
• Oil Separation, % wt. loss (D-1742) White
5 max
Physical Properties • Cone Penetration
• Density, lb./gal
• Consistency, Cone Penetration 185-230
7.85
(D-217) 205-215 • Dropping Point, 5 (ASTM D-566)
• Temperature Range -20° to 1000°F
• Dropping Point, °F (D-566) None
• Color
None • Water Washout ASTM D-1264) 1hr @
Black
• Oil Separation, % wt. loss (D-1742) 105°F - 0.1%
5 max • Rust Preventative Test (ASTM D-1743)
• Rust Preventative Test (D-1743) Pass
Pass • Temperature Range
• Temperature Range -70° to 600°F
-10° to 450°F • Type Oil
• Color Synthetic
Black
• Type Oil
Synthetic
• Corrosive Inhibitor
Imidazoline Derivative
• EP Additive
Diester Type
8 For inquiries and orders, please contact: sales@lubchem.com
PO Box 2626, Spring, TX 77383
23609 W. Hardy Rd., Spring, TX 77373
Order: 800-929-0244 Fax: 281-288-0849
Everlast 117 Everlast 50-300 Everlast 50-400 • H2S & CO2
EP Valve Lubricant Low Temp Valve Lubricant/Sealant
Product Code Product Code Product Code
EV117 50300 50400
Everlast 117 is an extreme pressure Everlast 50-300 is a synthetic valve 50-400 is a dual-purpose valve lubricant/
synthetic valve lubricant and sealant for lubricant/sealant formulated for use in sealant that meets Mil-G-6032
gate, ball, and plug valves. Everlast 117 is highly corrosive, low temperature services. “Grease Plug Valve, Gasoline & Oil Resis-
designed for use in close tolerance valves 50-300 should be used in plug valves and tant.” 50-400 is designed for use in plug
and will provide outstanding lubricity and ball valves handling dry gases including valves as a sealant and in ball and gate
reduced operating torque. Extensive labo- natural gas, manufactured gas, LP gases, valves as a lubricant 50-400 is resistant to
ratory evaluation has shown Everlast 117 to carbon dioxide, sour crude and gas, salt organic acids, caustic solutions and is inhib-
reduce operating torque by up to 50%. The water, hydrocarbons, acids or caustic ited for use in H2S and/or CO2. This product
additive package in this product provides solutions. 50-300 is a tenacious filmer has excellent dual resistance to water and
excellent antioxidant, extreme pressure to metal surfaces and will protect valve petroleum products such as gasoline, jet
and anti-wear properties and should be parts from the corrosive effects of oil and fuel, lubricating oils and mixtures of these
used where extreme pressures prevail. gas production and processing. 50-300 is products. 50- 400 can be used in a wide
excellent body filler in gate valves where variety of applications from the wellhead to
hydrocarbon resistance is important and product pipelines.
Applications corrosion protection is critical.
• For use in gate valves, plug and ball
valves Applications
• Suitable for use in hydrocarbon gases, Applications • For use in plug, gate and ball valves
water, CO2 and H2S • For use in plug, ball and gate valves in low • Suitable for use in hydrocarbon gases
• DO NOT use in oxygen service temperature environments • DO NOT use in oxygen service
• Suitable for use in hydrocarbon gases
• DO NOT use in oxygen service
Features Features
• Fully additive treated • Water insoluble and washout resistant
• 100% synthetic Features • Fully additive treated
• High metal adhesion • Outstanding low temp performance • 100% synthetic
• Inhibited for H2S and CO2 • Water insoluble and washout resistant • High metal adhesion
• Fully additive treated • Excellent corrosion resistance
• 100% synthetic • Inhibited for H2S and CO2
Physical Properties • High metal adhesion
• Color • Excellent corrosion resistance
Yelow to Brown Physical Properties
• Temperature range • Consistency, Cone Penetration
-20°F to 450°F Physical Properties (D-217) 215-230
• Penetration, 25°C, wkd, 60 strokes • Consistency, Cone Penetration (D-217) • Dropping Point, °F (D-566)
160-175 245-255 None
• Drop Point, °C • Dropping Point, °F (D-566) • Oil Separation, % wt. Loss (D-1742)
None None 5 Max
• Specific Gravity @25°C • Oil Separation, % wt. Loss, (D-1742) • Rust Preventive Test (D-1743)
.98 5 Max Pass
• Rust Prevention, (D-1743) • Temperature Range -15° to 400°F
Pass • Corrosive Inhibitor Imidazoline
• Temperature Range Derivative
-60° to 400°F • EP Additive
• Color Diester Type
Gray • Color
• Corrosion Inhibitor Tan
Imidazoline Derivative
• EP Additive
Diester Type
For inquiries and orders, please contact: sales@lubchem.com 9
Lubchem Valve Lubricants
Sealants / Sealants
Everlast 50-400 High Visc Everlast 50-400H20 Everlast 50-400DA
Plug Valve H2S & CO2 Frac Valve Lubricant/Sealant Low Temp Valve Lubricant/
Sealant
Product Code Product Code
50400HV 50400H20 Product Code
50400DA
50-400 is a high viscosity valve lubricant Everlast 50-400H2O is the preferred 50-400DA is a low temperature valve
sealant that meets Mil-G-6032 “Grease Plug lubricant/sealant of frac valve owners and lubricant/sealant resistant to acids, caustic
Valve, Gasoline & Oil Resistant.” 50- 400 is renters. 50400H2OH20 is a 100% synthetic solutions and is inhibited for use in H2S
designed for use in plug valves as a lubri- frac valve lubricant/sealant containing and/or CO2. 50-400DA has excellent dual
cant/sealant. 50-400 is resistant to organic NO solids such as Mica, Titanium Dioxide, resistance to water and aliphatic hydrocar-
acids, caustic solutions and is inhibited cheap abrasive Graphite, Molybdenum bons such as gasoline, jet fuel, lubricating
for use in H2S and CO2. This product has Disulfide, or other fillers. 50-400H2O oils, organic condensates and mixtures of
excellent dual resistance to water and contains Lubchem’s proprietary extreme these products. 50-400DA can be used in a
aliphatic hydrocarbons such as gasoline, jet pressure additive package which provides wide variety of applications from the well-
fuel, lubricating oils, organic condensates superior protection under the most head to product pipelines and frac valves.
and mixtures of these products. 50-400 can demanding conditions. Commonly used
be used in a wide variety of applications frac valve lubricants are washed /dissolved
Applications
from the wellhead to product pipelines. out with each job and valves must be dis-
• For use in plug, ball, and gate valves
sembled and re-lubricated after each job.
• Suitable for use in hydrocarbon gases
50-400H2O does not wash/dissolve out and
Applications • DO NOT use in oxygen service
valves are only required to be “topped” off
• For use in plug valves
before sending out to another job. Simply
• Suitable for use in hydrocarbon gases
put, 50400H2O remains in the valve longer Features
• DO NOT use in oxygen service
providing superior protection of internal • Water insoluble and washout resistant
metal surfaces of the valve without the • Fully additive treated
Features harmful solids found in other lubricants. • 100 % synthetic
• Water insoluble and washout resistant • High metal adhesion
• Fully additive treated • Excellent corrosion resistance
• 100% synthetic Applications • Inhibited for H2S and CO2
• For use in frac valves, ball valves, and
• High metal adhesion • Excellent low temperature pumpability
gate valves
• Inhibited for H2S and CO2
• Suitable for use in hydrocarbon gases
• DO NOT use in oxygen service Physical Properties
Physical Properties • Consistency, Cone Penetration (D-217)
• Consistency, Cone Penetration (D-217) 270-280
170-190 Features • Dropping Point, °F (D-566)
• Water insoluble and washout resistant
• Dropping Point, °F (D-566) None
• Non-Melting
None • Oil Separation, % wt. loss (D-1742) 5 Max
• 100 % synthetic
• Oil Separation, % wt. Loss, (D-1742) • Rust Preventive Test (D-1743) No.2
• Contains no fillers
5 max • Temperature Range
• High metal adhesion
• Rust Prevention, (D-1743) -40° to 400°F
• Excellent corrosion resistance
Pass • Corrosive Inhibitor
• Inhibited for H2S and CO2
• Temperature Range Imidazoline Derivative
-15° to 400°F • Available in an easier to pump winter
• EP Additive
grade formula for cold seasons
• Color Diester Type, containing no phosphorus
Tan sulfur or metal salt
• Corrosion Inhibitor Physical Properties
Imidazoline Derivative • Consistency, Cone Penetration
• EP Additive (D-217) 215-230
Diester Type • Dropping Point, °F (D-566)
None
• Oil Separation, % wt. loss (D-1742) 5 Max
• Rust Preventive Test (D-1743) No.2
• Temperature Range 0° to 450°F
• Corrosive Inhibitor
Imidazoline Derivative
• EP Additive
Diester Type, containing no phosphorus
sulfur or metal salt
10 For inquiries and orders, please contact: sales@lubchem.comPO Box 2626, Spring, TX 77383
23609 W. Hardy Rd., Spring, TX 77373
Order: 800-929-0244 Fax: 281-288-0849
Everlast 50-400 WG Everlast 50-500 • H2S & CO2
Plug Valve Sealant Ball and Valve Lubricant/Sealant
Gate Valve Lubricant
Product Code
Product Code 50500
50400WG
50-400WG is a dual-purpose valve lubricant/ 50-500 is a dual-purpose valve lubricant/
sealant that meets Mil-G-6032 “Grease Plug sealant that meets Mil-G-6032 “Grease
Valve, Gasoline & Oil Resistant”. 50-400WG Plug Valve, Gasoline & Oil Resistant”.
is designed for use in plug valves as a 50-500 is designed for use in plug valves
sealant and in ball and gate valves as as a sealant and in ball and gate valves as
lubricant. 50-400 WG is resistant to acids, a lubricant. 50-500 is resistant to acids,
caustic solutions and is inhibited for use in caustic solutions and is inhibited for use in
H2S and/or CO2. This product has excellent H2S and/or CO2. This product has excellent
dual resistance to water and aliphatic dual resistance to water and petroleum
hydrocarbons such as gasoline, jet fuel, products such as gasoline, jet fuel, lubri-
lubricating oils, organic condensates and cating oils and mixtures of these products.
mixtures of these products. 50-400WG can 50-500 can be used in a wide variety of
be used in a wide variety of applications applications from the wellhead to product
from the wellhead to product pipelines. pipelines.
Applications Applications
• For use in plug, ball, and gate valves • For use in plug, ball and gate valves
• Suitable for use in hydrocarbon gases • Suitable for use in hydrocarbon gases
• DO NOT use in oxygen service • DO NOT use in oxygen service
Features Features
• Meets Mil-G-6032 “Grease Plug • Meets Mil-G-6032 “Grease Plug Valve,
Valve, Gasoline and Oil Resistant” Gasoline and Oil Resistant”
• Water insoluble and washout • Water insoluble and washout resistant
resistant
• Fully additive treated
• Fully additive treated
• 100% synthetic
• 100 % synthetic
• High metal adhesion • High metal adhesion
• Excellent corrosion resistance • Excellent corrosion resistance
• Inhibited for H2S and CO2 • Inhibited for H2S and CO2
Physical Properties Physical Properties
• Consistency, Cone Penetration
• Consistency, Cone Penetration
(D-217) 190-205
(D-217) 260-280
• Dropping Point, °F (D-566)
• Dropping Point, °F (D-566)
None
None
• Oil Separation, % wt. Loss (D-1742) Max
• Oil Separation, % wt. loss (D-1742)
• Rust Preventive Test (D-1743)
5 Max
Pass
• Rust Preventive Test (D-1743) No.
2 • Temperature Range -20° to 500°F
• Temperature Range -40° to 400°F • Corrosive Inhibitor Imidazoline
• Corrosive Inhibitor Imidazoline Derivative
Derivative • EP Additive Diester Type,
• EP Additive Diester Type, containing no phosphorus sulfur or
containing no phosphorus sulfur metal salt
or metal salt • Color
• Color Dark Gray
Tan
For inquiries and orders, please contact: sales@lubchem.com 11Lubchem Valve Lubricants / Sealants
Longlife Moly 102 Special – Peanut Butter 196 Sealant for McEvoy
Heavy Duty Moly Lubricant Type • Standard & Creamy Valves - Regular Grade
Product Code Product Code Product Code: M196
LLM Standard Grade - SVD
Creamy Grade - SVC
Longlife Moly - 3% Moly-Lithium. EP Grease 196 Special should be used in both res-
is a fully additive-treated, multipurpose Recommended for properly sealing WKM ervoirs in McEvoy gate valves to insure
grease is water insoluble and is treated for type gate valves handling water, gas and sealing, dependability and easy operation.
extra protection. It contains antirust anti- condensate, oil petroleum products such Recommended for properly sealing valves
wear, extreme pressure, and antioxidant as gasoline, butane, hydrocarbon vapors, that handle gas and condensate, oils,
additives. It is a good quality molybdenum ammonia, glycerin, solvents and sour butane, gasoline, ammonia, glycerin and
disulfide compounded multipurpose gas. 102 Special is available in creamy and sour gas. Use Lubchem 196 Sealant for
grease and is treated with soluble chemical standard grades. leak proof trouble free service in McEvoy,
additives to prevent wear, especially under WKM and other gate valves. Recommended
very highly loaded conditions. Use Longlife temperature range 0°F to + 250°F.
Physical Properties
Moly in general purpose applications where • Appearance Light brown with a
medium to severe conditions prevail. characteristic odor Physical Properties
Meets Caterpillar requirements for 3% • Density • Appearance Tan with a
molybdenum disulfide, lithium soap grease. 9.35 – 9.55 lb. / gal. characteristic odor
• Oil Separation will not occur • Density
Features • Temperature Range 0° to 250°F 9.35 – 9.55 lb. / gal.
• Water insoluble • Cone Penetration: 240-270 • Oil Separation will not occur
• Fully additive treated • Corrosion Inhibitor Imidazoline
• Meets Caterpillar requirements for • EP Additive
3%molybdenum disulfide, lithium soap Diester type
grease • Temperature Range 0° to 250°F
• Cone Penetration: 190-220
Physical Properties
• Thickener
Lithium Stearate
• Texture
Smooth, but slight iber
• Fillers
3% Molybdenum disul ide
• Color, Observed
Gray
• Worked 60 Penetration, D-217
265-295
• Dropping Point, D-566, °F. (°C.)
340 (171)
• Oil Separation, D-1742,
% loss 3.8
• Rust Prevention, D-1743, rating
Pass
• Temperature Range
5°F to 280°F
12 For inquiries and orders, please contact: sales@lubchem.comPO Box 2626, Spring, TX 77383
23609 W. Hardy Rd., Spring, TX 77373
Order: 800-929-0244 Fax: 281-288-0849
Formasil WR - Valve Sealant Formasil RS - Valve Sealant Formasil HD - Valve Sealant
Product Code Product Code Product Code
FWR FRS FHD
For use in valves carrying hot air, steam, Synthetic sealant for use in valves carrying Synthetic sealant for use in valves
CO2, H2S, NGL, methanol, crude oil, natural gas, crude oil; sweet or sour, and carrying natural gas, crude oil; sweet or
produced waters, strong acids, natural water. It is waterproof and has excellent sour, water, condensate, dilute acids and
gas, and fuels where extreme temperature resistance to oxidation and high metal caustics. It is waterproof and has excellent
swings may occur. Formasil WR is highly adhesion. Formasil RS should be used as an resistance to oxidation and high metal
chemical resistant, has a wide temperature emergency sealant in ball and gate valves adhesion. Formasil HD should be used as a
range and is fortified with antirust, anti- or as a plug valve lubricant sealant. hydrocarbon resistant ball and gate valve
wear, and corrosion inhibitors. sealant or as a plug valve lubricant/sealant.
Applications
Applications • For use in plug, gate and ball valves Applications
• Valves in Arctic Climates • Suitable for use in hydrocarbon gases • For use in plug, gate and ball valves
• For use in plug, gate and ball valves • DO NOT use in oxygen service • Suitable for use in hydrocarbon gases
• Suitable for use in hydrocarbon gases • DO NOT use in oxygen service
• DO NOT use in oxygen service Features
• 100% synthetic Features
Features • Water resistant • 100% synthetic
• 100% synthetic • High metal adhesion • Water resistant
• Water resistant • Excellent corrosion resistance • High metal adhesion
• High metal adhesion • Inhibited for H2S • Inhibited for H2S
• Inhibited for H2S • Temperature Range 20° to 400°F • Temperature Range -40° to 400°F
• Temperature Range -55° to 450°F • Color • Color
• Cone Penetration: 200-240 Gray Green
• Cone Penetration: 210-240
Formasil RG - Valve Sealant Formasil RS - Winter Grade Formasil H2O - Valve
Sealant Sealant
Product Code
FRG Product Code Product Code
ARS FH2O
Formasil RG is a general purpose synthetic Formasil RS Arctic is a low temperature, For high-pressure gate valve applications
sealant for use in valves carrying natural synthetic sealant for use in valves carrying in hydrocarbon service. Formasil H2O is
gas, crude oil; sweet or sour, water, natural gas, crude oil; sweet or sour, and chemically resistant to aliphatic liquids and
condensate, dilute acids and caustics. It water. It is waterproof and has excellent gases including gasoline, kerosene, fuel and
is waterproof and has excellent resistance resistance to oxidation and high metal lubricating oils, natural gas and brine water.
to oxidation and high metal adhesion. adhesion. Formasil RS Arctic should be Formasil H2O is effective at temperatures
Formasil RG should be used as a hydro- used as an emergency sealant in ball and to 400°F and is fortified with antirust, anti-
carbon resistant ball and gate valve sealant gate valves or as a plug valve lubricant/ wear and corrosion inhibitors.
or as a plug valve lubricant/sealant. sealant.
Applications
Applications Applications • Applications
• For use in plug, gate and ball valves • For use in plug, gate and ball valves • For use in plug, gate and ball valves
• Suitable for use in hydrocarbon gases • Suitable for use in hydrocarbon gases • Drilling choke manifolds
• DO NOT use in oxygen service • DO NOT use in oxygen service • High Pressure Gate Valves
• Suitable for use in hydrocarbon gases
• DO NOT use in oxygen service
Features Features
• 100% synthetic • 100% synthetic
• Water resistant • Water resistant Features
• High metal adhesion • Inhibited for H2S • 100% synthetic
• Inhibited for H2S • Temperature Range -40° to 400°F • Water resistant
• Temperature Range -15° to 400°F • Inhibited for H2S
• Cone Penetration: 170-210 • Excellent sealing capabilities
• Temperature Range 20° to 400° F
• Cone Penetration: 210-240
For inquiries and orders, please contact: sales@lubchem.com 13Lubchem Valve Lubricants / Sealants
Formasil CO2 - Winter Formasil CO2 - Valve TFE Seal
Grade Lubricant/Sealant Valve Stem Packing
Product Code Product Code Product Code
FSCW FCO2 1900
Synthetic valve sealants formulated for Valve lubricant/sealant that meets Mil-G- A pumpable packing and sealant containing
use in highly corrosive, low temperature 6032 “Grease Plug Valve, Gasoline & Oil high temperature proprietary fillers in a
services. This product should be used to Resistant.” Formasil CO2 is designed for use blend of synthetic oils. Recommended
seal leaking plug valves and ball valves in gate valves as a lubricant/sealant and in for use in high temperature hydrocarbon
handling carbon dioxide, sour crude, gas, ball and plug valves as a sealant. Formasil service, steam, and hot oil services. TFE
salt water, hydrocarbons, acids or caustic CO2 is resistant to acids, caustic solutions Seal #1 contains fine to medium size filler
solutions. and is inhibited for use in H2S and/or CO2. particles. TFE Seal #2 contains medium to
This product has excellent dual resistance large filler particles.
to water and petroleum products such
Applications
as gasoline, jet fuel, lubricating oils and
• For use in plug, ball and gate valves in low Principle Service
mixtures of these products. Formasil CO2
temperature environments • High chemical and mechanical stability
can be used in a wide variety of applications
• Suitable for use in hydrocarbon gases • Good lubricity
from the wellhead to pipelines.
• DO NOT use in oxygen service • High temperature fillers
• EP Additives
Features Features • Oxidation and corrosion inhibitors
• Water insoluble and washout resistant
• Outstanding low temp performance
• 100% synthetic
• 100% synthetic Application
• Inhibited for H2S and CO2
• High metal adhesion • Pumpable with high pressure grease gun.
• Temperature Range 20° to 400° F
• Excellent sealing capabilities • DO NOT use in oxygen service
• Cone Penetration: 170-200
• Inhibited for H2S • Temperature Range -20° to 350°F
• Color
• Temperature Range -40° to 350°F • Cone Penetration: 220-240
Tan
• Cone Penetration: 260-280 • Color
• Color Tan
Tan
14 For inquiries and orders, please contact: sales@lubchem.comLubchem Valve Cleaners / Valve Flush PO Box 2626, Spring, TX 77383
23609 W. Hardy Rd., Spring, TX 77373
Order: 800-929-0244 Fax: 281-288-0849
Valve Saver AW Valve Saver Honey Oil
Valve Cleaner/Lubricant Valve Cleaner Valve Flush Cleaner
Product Code Product Code Product Code
VSAW VSB LVF
Valve Saver AW is a combination valve Valve Saver is a combination valve cleaner Lubchem LVF valve purge is a unique
cleaner and lubricant designed to lubricate and penetrating lubricant engineered to combination of valve penetrant and
and clean deposits common to valves in free up and clean out difficult or impossible moisture displacer engineered for today’s
pipeline & production valves. Valve Saver to operate lubricated valves. Lubchem’s growing valve maintenance market.
AW can be used as a valve cleaner and Valve Saver penetrates and cleans residual
as a lubricant. Valve Saver AW consists gum, lacquer, hardened sealants and Features
of a premium quality non-melting base lubricants. Valve Saver also penetrates • Water resistant
grease, blended with a proprietary additive and loosens rust and corrosion deposits • Stops rust, corrosion, scale inhibitor and
package that includes a dispersant / extending the life and performance of oxidation preventative
surfactant. This unique compound will all types of lubricated valves. When used • Inhibitive for H2S
lubricate the valves internal components regularly it will prevent additional build up. • Dissolves hydrocarbon deposits
and at the same time emulsify a variety of
• Loosens rust and scale
organic and organometallic compounds
Features • Will not harm any valve elastomers
common to pipeline operations. When
• Compatible with all valve lubricants • Non corrosive
used regularly it will prevent additional build
• Cuts gum and lacquer deposits • Color Tan
up of pipeline contaminants. The non-
• Removes rust and corrosion
melting base grease provides good
• DO NOT use in oxygen service
lubrication qualities over a wide temperature Application Procedure
• Temperature Range -40° to 400°F
range of -65° to 300°F. • For use in plug, ball and gate valves
• Cone Penetration: 280-330 • Flushing of seized valves prior to
• Color lubrication / sealing
Valve Saver AW is compatible Black • Suitable for use in hydrocarbon gases
with the following elastomers: • DO NOT use in oxygen service
Polytetrafluoroethylene, Teflon, Perfluoro- Application Procedure
elastomer, Kalrez, Chemraz, TFE-PVDF-Ter- Apply Lubchem Valve Saver with
polymer rubber, Viton, Fluorel, Chlorinated conventional lubricating equipment.
Butyl Rubber & Butadiene Rubber, Butyl Turn valve slowly and repeat the process
Rubber, Ethylene Propylene Rubber, until valve opens freely. After the valve is
Ethylene Propylene Diene Rubber, Vistalon, operable, lubricate with one of Lubchem’s
Nordel, Nitrile Rubber, Hycar, Buna-N, Natu- high quality valve lubricants.
ral Rubber, Butadiene Rubber, Isoprene
Rubber, Epichlorohydrin copolymer rubber,
Epichlorohydrin terpolymer rubber, Polysul-
fide rubber Chlorosulfonated Polyethylene
rubber
Features
• Compatible with all valve lubricants
• Cuts gum and lacquer deposits
• Penetrates rust and corrosion
• Do not use in oxygen service
• Temperature Range -65° to 300°F
• Cone Penetration: 280-330
• Color
White
For inquiries and orders, please contact: sales@lubchem.com 15Lubchem Premium Lubricants
Longlife 1600 A Longlife 1600 Longlife 1603
Arctic Grade Lubricant Multi-Purpose Lubricant Multi-Purpose Lubricant
Product Code Product Code Product Code
BPA LL1600 LL1603
Suitable for use as a low temp gate valve body Longlife 1600 (Bentone) is water insoluble, Longlife 1603 is an economical multipurpose
filler or as a ball valve lubricant. Longlife 1600 washout resistant and fully additive treated grease especially suited for normal
is a low temperature multipurpose water with corrosion inhibitors, extreme pressure operating temperatures and other
insoluble grease that will provide low torque additives and oxidation inhibitor additives. noncritical service applications. 1603 is an
operation in very cold operating It is an excellent choice where water excellent corrosion inhibiting grease and
environments. It contains a proprietary anti-
resistance and a light valve grease is recommended for applications requiring
galling additive and corrosion inhibitor
recommended. frequent regreasing due to contaminating
designed to protect seat rings, springs and
sealing surfaces from the corrosive effects of environments. This product is water
oil and gas production and processing. Applications insoluble, washout resistant and fully
additive treated with corrosion inhibitors,
• For use in Ball Valves & Gate Valves as a extreme pressure additives and oxidation
Applications body filler inhibitor additives. It is an excellent choice
• For use in ball and gate valves in low • Protects seat rings and springs where an economical valve grease is
temperature environments • Suitable for use in water and natural gas recommended.
• Suitable for use in hydrocarbon gases services
• DO NOT use in oxygen service • DO NOT use in oxygen service Applications
Features Features • For use in Ball Valves & Gate Valves as a
body filler
• Outstanding low temp performance • Water insoluble and washout resistant • Protects seat rings and springs
• Water insoluble and washout resistant • Fully additive treated • Suitable for use in water and clean
• Fully additive treated • Non-melting multipurpose grease natural gas services
• Non-melting multipurpose grease • Superior protection to lubricate a wide • DO NOT use in oxygen service
• Superior protection to lubricate a wide variety of heavy-duty equipment
variety of heavy-duty equipment
Features
• Low Staining Physical Properties
• Water resistant
• Temperature Range • Fully additive treated
Physical Properties -40° F to 350°F • Multipurpose grease
• Thickener Anhydrous Calcium • Color/Texture
• Temperature Range Tan/Smooth Physical Properties
-75° F to 350° F • Worked 60 Penetration, D-217
• Color/Texture 265-295 • Temperature Range
Gray/Smooth Adhesive • Cone Penetration: 265-295 0° to 265° F
• Rust Prevention, D-1743, rating • Color
Pass Black
• Worked 60 Penetration, D-217 • Worked 60 Penetration, D-217
265-295 265-295
• Dropping Point, D-566°F • Dropping Point, D-566°F, (°C)
365 375 (191)
• Oil Separation, D-1742, • Texture
% loss 5 Smooth, medium fiber
• Cone Penetration: 260-330 • Cone Penetration: 265-295
16 For inquiries and orders, please contact: sales@lubchem.comPO Box 2626, Spring, TX 77383
23609 W. Hardy Rd., Spring, TX 77373
Order: 800-929-0244 Fax: 281-288-0849
Longlife SRL-50
Sucker Rod Lubricant
Product Code
SRL50
Longlife SRL-50 is engineered to protect
the threads of sucker rod connections
under severe operating conditions of
high cyclic loading. SRL-50 is a high
temperature, lithium complex EP
grease with excellent low temperature
properties. SRL-50 is a unique blend
of petroleum base oils and synthetic
fluids providing excellent resistance to
oxidation at elevated temperatures with
exceptional performance under extreme
low temperature conditions. SRL-50
contains EP/antiwear additives, rust and
oxidation inhibitors that provide superior
protection from thread galling in sucker rod
connections.
Application:
Clean the connection prior to make up.
Apply a thin coat of SRL-50 to the thread.
CAUTION: Do not lubricate the pin
shoulder face or the coupling shoulder face
or a loss of tightness can occur resulting in
a connection failure.
Physical Properties
• Color/Texture
Blue/Smooth
• Unworked Penetration,
D-217 265-295
• Worked 60 Penetration,
D-217 265-295
• Oil Separation, D-1742, % loss
1.0
• Dropping Point, (D-2265), °F, (°C)
550 (288)
• Temperature Range, °F, (°C)
-10°F to 325°F
For inquiries and orders, please contact: sales@lubchem.com 17Lubchem Valve
Industrial
Sealants
Products
COPPER COAT 1800
Copper Coat 1800 is a anti-seize assembly Anti-Seize 2200 is a special blend of Lubezit is a combination penetrant and
lubricant designed to protect stainless graphite and micro size aluminum flake lubricant engineered for maximum pene-
steel and dissimilar metals against seizure, particles homogenized into a highly viscous, tration and protection of metal surfaces.
galling and heat freeze. It is non-melting nonvolatile carrier. It is non-melting and Lubezit can be used in industrial disman-
and contains a high content of micro-size provides superior protection against gall- tling operations, in the home or anywhere
copper flakes which are homogenized into ing, corrosion and heat freeze. Anti-Seize metal parts are rusted together or difficult
a viscous nonvolatile carrier. Anti-Seize 2200 prevents metal to metal contact to separate. Also, Lubezit provides a
1800 prevents metal to metal contact under under severe variations of temperature, superior corrosion inhibiting film that
variations of temperature, cyclic loading cyclic loading and pressure. protects metal in harsh conditions. This
and pressure. Prevents seizing and galling. product is safe to use and does not contain
It withstands higher temperatures than any environmentally harmful petroleum hy-
Recommended uses include all types of copper based compounds and will not drip drocarbons or chlorinated solvents. Lubezit
electrical connections, fasteners in engines or run. It will provide clean break-outs from is a selected blend of oils with high quality
and turbines and other studs, nuts or bolts high torque and is very economical to use. corrosion inhibiting and extreme pressure
operating in high temperature applications. characteristics. It is not harmful to rubber,
Uses and Features: plastics or painted surfaces. It’s unique
Uses and Features: • Prevents seizure qualities displace moisture, loosen rust,
• Electrical connections • Prevents galling scale and protect metal from corrosion.
• Protects stainless steel • Provides smooth torque readings
• Contains copper flake • Color - silver Applications:
• Color - copper • Lead free • Rusted Nuts & Bolts
• Lead free • Temperature Range: • Drilling, Cables
• Temperature Range: -65° to 2200°F • Lawn Mowers & Tractors
-65° to 1800°F -54° to 1200°C • Pulleys & Industrial Parts
-54° to 982°C • Flash Point: 380°F • Automobiles & Boats
• Flash Point: 380°F • Dropping Point: None • Locks & Hinges
• Dropping Point: None • Fishing Gear & Bicycles
Applications:
Applications: • Bolts & Bushings
Features:
• Bolts & Burner Assembles • Low RPM Bearings & Gears
• Nonflammable & Biodegradable
• Bushings & Pumps • Spark Plugs
• Lubricates & Penetrates
• Conveyors Spark Plugs • Chains & Drives
• Nondrying & Nonconductive
• Chains & Drives • Cylinder Head Assembles
• Dissolves Carbon Deposits
• Cylinder Head Assembles • Gaskets
• Stops Rust & Protects metal
• Steam Turbines • Furnaces
• Exhaust Manifolds • Rollers and Conveyors
• Shaft Couplings Lubezit is available in:
Part Number Description
Anti-Seize 1800 is available in: 19119 ...................1 gal. / 6 cans per case
Part Number Description Anti-Seize 2200 is available in: 19145 ................................... 5 gallon pail
11211 ................. 24-8 oz. brush top cans Part Number Description
19155 ............................. 55 gallon drums
11217 ................ 12-16 oz. brush top cans 13111 ................. 24-8 oz. brush top cans
11223 .........................................10 lb. pail 13117 ................ 12-16 oz. brush top cans
11235 .............................. 5 gal./40 lb. pail 13123 .........................................10 lb. pail
13135 .............................. 5 gal./40 lb. pail
18 For inquiries and orders, please contact: sales@lubchem.comPO Box 2626, Spring, TX 77383
23609 W. Hardy Rd., Spring, TX 77373
Order: 800-929-0244 Fax: 281-288-0849
Moly-Vap is a dry film lubricant When your specification requires a self
containing molybdenum disulfide and healing pipe storage compound then
graphite to withstand broad temperature PROCOAT 690 is the product you need.
and pressure limits. Moly-Vap film has a The self leveling properties of this product
low coefficient of friction ranging from 0.31 allows minor defects in the coating such as
to 0.06 and provides excellent lubricating nicks and scratches heal themselves. It’s
properties without the attraction of dust self leveling property recovers blemishes
and dirt where oils and greases would while it’s balanced system has just the right
be unsuitable. The carrier solvent in this thixotropy or gel strength to enable PRO-
formulation drys quickly, bonding the COAT 690 to remain in place on the pipe.
tenacious solid Moly-Vap coating to ferrous
and nonferrous metals.
Applications:
PROCOAT 690 is engineered to provide
Moly-Vap resists water, oils, alkali and most
corrosion protection to pipe threads during
acids.
periods of extended storage. It contains
inhibitors to minimize the corrosion effects
Applications: of salt water, downhole treating chemicals
• Threaded Connections and contaminants.
• Assembly
• Running In Lubricant Features:
• Wire Drawing PROCOAT 690 forms a protective film
• Stop-off Coating which deactivates metal surfaces, inhibits
• High Temperature Conveyors oxidation and seals out moisture. It resists
• Bearings attack from ultraviolet degradation, rust
• Chain Lubrication and galvanic corrosion.
• Gears
• Machine Tools
PROCOAT 690 is available in:
Moly-Vap prevents friction, fretting, wear, Part Number Description
sticking, galling, seizing, binding and 21019 ................................ 6 - 1 gal. Cans
chattering. 21045 ........................................ 5 gal can
21056 ................................. 55 gal. Drum
Moly-Vap is available in:
Part Number Description
15112 ............... 12 oz. Aerosol - 12 / case
15119 .................. 6 - 1 gal. cans per case
15145 ........................................ 5 gal. can
15156 ................................... 55 gal. drum
For inquiries and orders, please contact: sales@lubchem.com 19Valve Sealants
Lubchem Wireline Products
Bio WL-800 Series WL-700 SERIES Wireline Sprays
Biodegradable Grease Seal Standard Wireline Fluids
Product Code
Product Code Product Code WS1113 & WS1500
BWL-816, 820, 824 & 828 WL-716, 720, 724 & 728
Physical Properties
Lubchem BWL-800 series grease seals are Lubchem WL-700 wireline grease seals WS 1113
based on biodegradable & renewable base are premium viscous tacky lubricants and ASTM D 445 @ 40 °C, Viscosity 28-48 est
oils. Developed to protect wireline exposed sealants designed specifically for use in oil
to environments where conventional and gas well logging operations and other
WS 1500
wire line sealants fail. Our BWL-800 wireline applications where a lubricating
ASTM D 445 @ 40 °C, Viscosity 1350-1650
series is formulated for high temperature dynamic seal is required. Formulated with
applications where high levels of H2S and/ advanced corrosion inhibitors to protect
or CO2 may be encountered. against corrosion in harsh high pressure
down-hole environments where exposure Ashless Hydraulic Oils
to moisture, H2S, and corrosive fluids occur.
Applications Lubchem Ultra HFA - Ashless
Lubchem BWL-800 series is recommended
for braided wireline, cables and wire rope. Applications Visc Grades 32, 46, 68 and 100
It is applied by grease injector control Lubchem WL-700 series is recommended
heads and cable lubricators. for braided wireline, cables and wire rope. Lubchem Ultra HFA hydraulic fluids are
It is applied by grease injector control environmentally acceptable ashless
heads and cable lubricators. hydraulic oils designed to provide superior
Features
• Completely biodegradable oxidation stability, anti-wear & rust
• Non-hazardous Benefits preventive properties
• Protects against H2S • Enhanced corrosion package Lubchem Ultra HFA meets and exceeds the
• Protects against CO2 • Provides lubrication & sealing performance requirements of all major
• Fully additive treatment • Minimizes loss of well fluids during pump manufacturers.
operation
Solubility • Resistant to H2S & CO2 Features
• Reduces drip and splatter • Contain no zinc or heavy metals
• Toluene Insoluble @ 77 °F
• Cyclohexane Insoluble @ 77 °F • Environmentally friendly
• Water Insoluble @ 77 °F • Excellent thermal and oxidation stability
• Blended from highly refined base oils
• Compatible with all OEM fluids
Benefits
• Enhanced corrosion package
• Provides lubrication and sealing Applications
• Reduces loss of well fluids during operation • High and low pressure hydraulic systems
• Reduces corrosive effects of H2S & CO2 where additive-treated product is required
• Reduces drip and splatter • Vane, piston and gear pumps.
• Pumps which require an R&O or R&O/AW
hydraulic or turbine oil.
• Construction, farm, oilfield, mining, and
logging equipment.
Meets Performance Standards
• Cincinnati Machine P-68; P-69; P-70.
• US Steel 127, 136.
• Din 5124 (Parts 1&2); Din 51506.
• VDL Performance also for lower grades.
Typical Properties
Ultra HFA 32
Viscosity @ 40 °C, D445 31.5 - 33.5
Flash Point COC, D92 Min 420 °F
Pour Point, D97 Max 5 °F
Ultra HFA 42
Viscosity @ 40 °C, D445 45 - 47
Flash Point COC, D92 Min 420 °F
Pour Point, D97 Max 15 °F
Ultra HFA 68
Viscosity @ 40 °C, D445 66 - 69
Flash Point ,D92 Min 420 °F
Pour Point, D97 Max 30 °F
20 For inquiries and orders, please contact: sales@lubchem.comYou can also read
