GLISS MASTER —
VINCENT VAN DUYSEN 2015
1—
39
Molteni&C has extended the possibilities for Gliss Master, renewing the architectural concept of the
nighttime area. The melamine offering is enriched with a new internal finish, a “White” texture, and a new
warm Bronze finish, feminine and sophisticated, which represents the latest interpretation of this metal.
The insides feature new accessories, such as the top of the structure which can be made of glass, to
make the wardrobe even more transparent. The Master chest-of-drawers also has new tops, one made
of transparent glass framed in Pewter and Bronze-coloured aluminium, which, thanks to the LED lighting,
enhances the drawer inside; the other enriched with a stackable and pull-out threelayer trinket tray, which
can be positioned at will. Two new options for the doors: “Swing” door, matt lacqured, which can be
opened at 180°. “Twin” door, with the strong formal appeal typical of Vincent Van Duysen, with a new
Pewter-coloured outer handle.
The Internet Of Things (IOT) joins the world of Molteni&C nighttime systems – Gliss Master and Master
Dressing – with avant-garde solutions and innovations that guarantee wardrobes the best environmental
quality. AIRCUB ® – a Molteni&C exclusive – is an IOT device easily manageable from your smartphone
with a dedicated APP. The air purification and perfuming system works by ionizing and ozonizing wardrobe
interiors, thereby removing up to 95% of agents harmful to health, while releasing delicate fragrances.
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.
GLISS FINISHES
MASTER—
VINCENT
VAN DUYSEN
2015
Finishes melamine melamine matt cartapaglia glossy woods coloured shiny pewter Eco Skin extraclear fine grain
structure front lacquer lacquered lacquer glass/ alumi- colour/ transparent
components colours colours etched nium/ bronze glass/
coloured transparent
glass/ black stopsol/
mirror chrome stopsol
linear module base/lid
and corner module
back panel only linear
wooden central partition
wooden external side panel
extension profile
central partition
or side panel frame
central only
frame or glass glass transparent
START / TWIN door
“A FILO” door
“A FILO” glass door profile
glass
2—
BLADE sliding door
39 GRIP door
DEEP door
NICHE door
GLASS door profile
glass
SWING door
WINDOW door profile
glass
SKIN door profile
panel
melamine melamine Eco Skin fine grain transparent pewter grey larix dark/ matt
structure structure pewter pewter glass colour/ saffiano silver lacquer
pewter colour/ colour/ colour/ bronze melamine cembran colours
internal fittings bronze profile bronze profile bronze profile
shelf
wooden drawer fronts H 126/190/382
tray front (trouser holders/trinket trays)
front for open drawers / pull-out trays
glass drawer fronts/ profile
glass shelf
glass
drawer internal
dividing partitions - grid with shirt /sweater holders
island drawer unit
drawer unit
colours Melamine Matt lacquer/ Glossy Coloured Etched coloured Woods Eco Skin
structure Cartapaglia lacquer glass glass EU eucalyptus grey
YB white shantung lacquered BC chalk white BC chalk white BC chalk white RG grey oak mink
YG grey shantung BC chalk white PE pearl PE pearl PE pearl RF graphite oak hemp
YM larix dark PE pearl DN dune DN dune DN dune ivory
YA silver cembran DN dune PL platinum PL platinum PL platinum dark brown
WW white PL platinum NE black NE black NE black
NE black AT anthracite AT anthracite AT anthracite
Melamine front AT anthracite SE mustard SE mustard SE mustard
KA cartapaglia anthracite SE mustard SI silica SI silica SI silica
KB cartapaglia white SI silica DO dolomite grey DO dolomite grey DO dolomite grey
KS cartapaglia silica DO dolomite grey AL clay AL clay AL clay
WS graffiato silica AL clay MK moka MK moka MK moka
WB graffiato bronze MK moka CM caramel CM caramel CM caramel
ZB silk chalk white CM caramel CZ light blue grey CZ light blue grey CZ light blue grey
ZS silk silica CZ light blue grey SA sand SA sand SA sand
ZT silk dove grey SA sand RU ruby RU ruby RU ruby
RU ruby RE rust RE rust RE rust
RE rust PX pewter colour PX pewter colour PX pewter colour
PX pewter colour RX copper RX copper RX copper
RX copper TO dove grey TO dove grey TO dove grey
TO dove grey
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.
GLISS MODULARITY
MASTER—
VINCENT
VAN DUYSEN Modularity - Structure
2015 The widths 492 - 656 - 820 - 984 - 1312 - 464 (term. element) mm (19 3/8” - 25 7/8” -
32 1/4” - 38 3/4” - 51 5/8” - 18 1/4”) include the left side panel. The total width of the composition will include the final panel of th. 30 mm (1 1/8”).
Heights: tot. H 2343 (92 1/4”), door 2313 (91”), int.2253 (873/4”), sliding or flush sl. door inter. 2163 (85 1/8”)
tot. H 2439 (96”), door 2409 (94 7/8”), int. 2349 (92 1/2”), sliding or flush sl. door inter. 2259 (88 7/8”)
tot. H 2631 (103 5/8”), door 2601 (102 3/8”), int. 2541 (100”), sliding or flush sl. door inter. 2451 (96 1/2”)
tot. H 2919 (114 7/8”), door 2889 (113 3/8”), interior 2829 (111 3/8”), only hinged
Assembly instructions
For the assembling of a sliding and a flush sliding door wardrobe a minimum space of 6 cm (2 3/8”) is required considering the minimum height of the compartment.
Assembly of the corner element (for wardrobe with doors) requires a minimum extra height of 6 cm (2 3/8”).
Assembly of a wardrobe in an alcove requires a minimum extra side space of 4 cm (1 5/8”).
A wardrobe with hinged doors and a lighting system requires a minimum extra height of 5 cm (2”).
462 30 1 1/8” 626 30 1 1/8” 790 30 1 1/8” 954 30 1 1/8” 1282 30 1 1/8” 434 30 1 1/8”
18 1/4” 24 5/8” 31 1/8” 37 1/2” 50 1/2” 17 1/8”
595/ 420
435 16 1/4”
23 3/8”/ linear element linear element linear element linear element linear element terminal
17 1/8” element
3—
39
1670 78 5/8” 2162 85 1/8”
820 32 1/4” 820 32 1/4” 984 38 3/4” 656 25 7/8” 492 19 3/8”
984 38 3/4” 656 25 7/8” 820 32 1/4” 820 32 1/4” 492 19 3/8”
1834 72 1/4” 2326 91 5/8”
984 38 3/4” 820 32 1/4” 1312 51 5/8” 984 38 3/4”
1312 51 5/8” 492 19 3/8” 820 32 1/4” 820 32 1/4” 656 25 7/8”
2490 98”
1998 78 5/8”
984 38 3/4” 984 38 3/4” 492 19 3/8”
984 38 3/4” 984 38 3/4”
1312 51 5/8” 656 25 7/8” 492 19 3/8”
1312 51 5/8” 656 25 7/8”
820 32 1/4” 820 32 1/4” 820 32 1/4”
2654 104 1/2”
1312 51 5/8” 1312 51 5/8”
984 38 3/4” 984 38 3/4” 656 25 7/8”
492 19 3/8” 820 32 1/4” 820 32 1/4” 492 19 3/8”
2818 111”
656 25 7/8” 984 38 3/4” 492 19 3/8” 656 25 7/8”
984 38 3/4” 820 32 1/4” 984 38 3/4”
2982 117 3/8”
984 38 3/4” 984 38 3/4” 984 38 3/4”
3146 123 7/8”
1312 51 5/8” 1312 51 5/8” 492 19 3/8”
820 32 1/4” 820 32 1/4” 820 32 1/4” 656 25 7/8”
3310 130 3/8”
820 32 1/4” 820 32 1/4” 820 32 1/4” 820 32 1/4”
656 25 7/8” 1312 51 5/8” 1312 51 5/8”
3474 136 3/4”
984 38 3/4” 492 19 3/8” 984 38 3/4” 984 38 3/4”
1312 51 5/8” 820 32 1/4” 1312 51 5/8”
3638 143 1/4”
984 38 3/4” 984 38 3/4” 984 38 3/4” 656 25 7/8”
984 38 3/4” 820 32 1/4” 820 32 1/4” 984 38 3/4”
1312 51 5/8” 1312 51 5/8” 984 38 3/4”
3802 149 3/4”
1312 51 5/8” 984 38 3/4” 984 38 3/4” 492 19 3/8”
656 25 7/8” 1312 51 5/8” 1312 51 5/8” 492 19 3/8”
DATASHEET
REGISTERED 3966 156 1/8”
DESIGN
1312 51 5/8” 1312 51 5/8” 1312 51 5/8”
IX.2018 984 38 3/4” 984 38 3/4” 984 38 3/4” 984 38 3/4”
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.
GLISS DOORS
MASTER—
VINCENT START-TWIN hinged doors “A FILO” hinged doors DEEP-GRIP hinged doors
VAN DUYSEN applicable only on structures applicable only on structures applicable only on structures
2015 with wood sides with wood sides with wood sides
In the pairs of TWIN hinged
doors W 815, 979 and 1307,
are availables 2 handles
or handle only on right door.
total height total height
above floor above floor
1190 46 7/8” 1080 42 1/2”
The pairs of hinged doors START
and “A FILO” always have a handle
mounted on the right door.
NICHE doors WINDOW - SKIN door GLASS-SWING doors, th 35
applicable only on structures applicable on all types applicable on all types
with wood sides of structures of structures
4— In the pairs of hinged doors The hinged doors WINDOW GLASS-SWING doors
W 815, 979 and 1307, are and SKIN are made with are made with
39 availables 2 handles recessed hinges fixed to base 180° hinges
or handle only on right and top, and have a thickness built into the side
door. of 30 mm (a Molteni exclusive)
total height handle total height
above floor height above floor
950 890
35” 1080 42 1/2”
37 3/8”
180° 180°
Sliding doors
maniglia
ad incasso
It is possible to make sliding door wardrobes
with doors of the following types: Detail of side panel
- START with extension profile with BLADE door
- “A FILO”
- GRIP
- DEEP
- BLADE
It is possible to make the external 7 1/4”
sliding door with two handles if 28
using the “A FILO” or BLADE door 25 1” 1 1/8”
(full-height handle) and applying the
4 1/8”
surcharge 5 1/4” 13 5 1/4” 21,5
17,5
1/2” 5/8” 7/8”
30
1 1/8”
Flush sliding doors
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.
GLISS DOORS
MASTER—
VINCENT
VAN DUYSEN
2015
155° opening (only for compartments with wooden sides)
On START - TWIN - “A FILO” - GRIP - DEEP - NICHE doors it is also possible
to use 155° opening hinges, with an extra charge per individual door. In this
case, it is necessary to take special care in inserting internal drawer units, trinket trays
and devices.
It is also necessary to comply with the diagrams provided here.
155° 155°
25 1” 25 1”
YES “A FILO”- NICHE doors
NO START - TWIN
DEEP - GRIP doors
5—
39
155° 155° 155°
30
25 1” 25 1” 1 1/8” 25 1”
YES “A FILO”- NICHE doors
YES START - TWIN
DEEP - GRIP doors
YES WINDOW - SKIN doors
NOT with GLASS doors
Hinged doors with key lock
For the hinged doors specified, a key lock can be fitted to order. There is a
additional cost for one or two doors. It can even be fitted on a terminal element or a
corner element (in compliance with the handle installation rules).
For doors with a lock, the internal drawer units must be suspended.
Installation of only the lock can be requested, without a handle, always considering the
price of the START doors and the additional cost of the lock.
START door START door “A FILO” door
handle type “M” handle type “E”
65 2 1/2” 65 2 1/2” 65 2 1/2”
1149 451/4”
1149 451/4”
1149 451/4”
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.
GLISS CORNER ELEMENT
MASTER—
VINCENT
VAN DUYSEN
2015 Corner element D 595 - open or with GLASS/SWING doors Reductions
The corner element can be reduced in height, width and depth.
The corner element is provided complete with a base, lid and backs (melamine or fine In width, the reduction can be carried out either on one side only or on both sides, up to
grain). Between the corner element and the adjacent modules, it is necessary to insert a minimum width of 1101 mm.
central partitions in melamine, frame or glass.
The corner element can also receive a side panel to close the composition. Reduction in depth can be done on one or on two sides, up to a minimum of 435 mm.
Compartments adjacent to the closed corner element can be open or closed with If only one side is reduced, that will be the side with the longest shelves (*).
GLASS or SWING doors.
Notes *
The shelf is not included in the price of the corner element.
Shelves and lids can be fitted with LED lighting bars, as indicated in the drawing below.
A
1081
1262
723
543
6— melamine back
180°
or fine grain back
39
det. A
1101
1282
595
1282
1101
lighting bar
position
595
The corner element can be fitted with shelves and clothes rails, or with
this solution of drawer units that have a central partition H 1158 where
the desired drawer unit can be inserted. The drawer unit can be with
fronts W 420 or 584.
No type of drawer unit can be
inserted with frame or glass
sides
1158
30
462/626 195/31
only open or with
GLASS and SWING doors
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.
GLISS STRUCTURE
MASTER—
VINCENT
VAN DUYSEN
2015
Structure for walk-in closet
In version A, the structure (base, lid, central partitions, back and side panels) is in
melamine, in the same finish as the structure.
The back piece can also be provided in fine grain finish.
The side panels are always provided without extension profile (see detail).
In version B, the central partitions and sides are made with an aluminium frame with
pewter colour or bronze finish, with or without glass.
Base, lid and back piece are in melamine, in the same finish as the structure.
The back piece can also be provided in fine grain or glass finish.
Horizontal tags on the base and lid are made in a pewter colour or bronze finish like the
side frames.
In version C, given the presence of frame sides in pewter colour finish, the central and
side partitions in melamine are also made with from tags in pewter colour or bronze,
considering the specific price.
version A - Structure with wooden sides (melamine in the same colour as the structure)
7— 30 30 30
1101
462-626-790-954-1282
39 1282
595
435
1101
1282
corner
element
In this solution the horizontal tags
are always made in the same finish
30 as the structure
version B - Structure with frame or glass sides (H max 2631)
central partition side panel
30 30 30
1101
1282 462-626-790-954-1282 *
The side panel
is always glass
1101
1282
corner
element
In this solution, the horizontal tags Compartments with frame or glass * Excluding module
are made in pewter colour or bronze sides must always include a shelf with glass back
finish, like the sides with frame or a drawer unit
30
or glass
version C - Structure with mixed sides (H max 2631)
A A
In this solution, the horizontal
tags are made in pewter colour
or bronze finish, like the sides
with frame or glass. Melamine
central partitions and sides are
made with front tag in pewter
colour or bronze pewter colour
or bronze
det. A
DATASHEET
A
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.
GLISS STRUCTURE
MASTER—
VINCENT
VAN DUYSEN
2015
Linear modules Side panels
Linear modules are made up of a base and lid always made in melamine in the same finish These are available in melamine, in the same finishes as the structure, frame and glass.
as the structure. The melamine version can be reduced in height and depth.
The back is available in the three versions indicated below. The outside of the side panel is available in the matt lacquer, glossy lacquer or wooden
A1 and A2 can be reduced in height, width and depth if closed by sides and doors that are (vertical grain) finishes.
compatible with the requested reductions. The standard finish on side panels is an extension profile in the coloured matt lacquer,
A3 can be reduced only in height. pewter colour, bronze, shiny alumium or black chrome finishes (to be specified in the
Order). The extension profiles for glossy lacquer or wood side panels always match the
Central partitions side panels of the same finish.
These are available in melamine, in the same finishes as the structure, frame and glass. The frame and glass versions can be reduced only in height.
The melamine version can be reduced in height and depth. Compartments with frame or glass sides must always include a shelf or a drawer unit.
The frame and glass versions can be reduced only in height.
Compartments with frame or glass sides must always include a shelf or a drawer unit.
A1 - Melamine back A2 - Fine grain back A3 - Glass back
(only hinged GLASS, WINDOW
and closet)
8—
39
2343 - 2439 - 2631 - 2919
2343 - 2439 - 2631 - 2919
2343 - 2439 - 2631
595/435 595/435 595
462-626-790 462-626-790 462-626-790
954-1282 954-1282 954
A1 A2 A3
Base, lid and back made Base and lid made in melamine finish Base and lid made in melamine finish
in melamine finish matching the structure matching the structure. matching the structure.
Back with fine grain finish Back in glass, only made
with frame and glass sides.
It is possible to produce single finished
modules W 790/954 with lateral pieces in
glass by using the glass lids
Central partitions, th 30 Side panels, th 30
Warning:
frame sides and glass sides will only have holes at the position of the shelves. Complete hole
series at regular intervals 96 mm will involve an extra charge per side.
Melamine Melamine with Frame Glass Melamine Melamine with Glass
pewter colour or (only hinged (only hinged pewter colour or (only hinged
bronze profile for GLASS, SWING, GLASS, SWING, bronze profile for GLASS, SWING,
matching with WINDOW, SKIN and WINDOW, matching with WINDOW, SKIN
walk-in closet with walk-in closet) SKIN and walk-in walk-in closet with and walk-in closet)
frame or glass sides closet) frame or glass sides
A
2343 - 2439 - 2631 - 2919
2343 - 2439 - 2631 - 2919
2283 - 2379 - 2571
2343 - 2439 - 2631
2343 - 2439 - 2631
2343 - 2439 - 2631
2343 - 2439 - 2631
2343 - 2439 - 2631
595/435 595/435 595 595 595/435 595/435 595
melamine pewter pewter pewter
finish colour/ colour/ colour/
bronze bronze bronze
structure finish finish finish
DATASHEET
det. A
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS WARDROBE REDUCTIONS
MASTER—
VINCENT
VAN DUYSEN
2015 Structure reductions
Type of reduction height width depth
Linear modules D 595 mm melamine back or fine grain back per millimetre per millimetre min -20 mm max -256 wardrobe / flush sliding ward. max -160 mm
Linear modules D 595 mm glass back per millimetre no reductions no reductions
Linear elements D 435 mm per millimetre per millimetre min -20 mm max -96 mm
Corner element for wardrobe with doors per millimetre no reductions no reductions
Corner element open or for GLASS/SWING doors 1 side up to 1101 x 1282 1 side up to mm 435
per millimetre
2 sides up to 1101 x 1101 2 sides up to mm 435
Terminal element per millimetre no reductions no reductions
Wooden central partition or side panel per millimetre reductions depend on linear modules
Frame or glass side panel or central partition per millimetre no reductions
The retailer should remember to verify the stability of wardrobes having a depth inferior to 595 mm and arrange to have anti-tilt devices mounted if necessary.
9— Door reductions
39 Type of reduction height width
Wooden hinged doors (START - TWIN - “A FILO” - GRIP - DEEP - NICHE) per millimetre per millimetre
“A FILO” glass hinged doors per millimetre per millimetre
Wooden sliding doors (START - “A FILO” - BLADE - GRIP - DEEP) per millimetre ONLY doors W 979 and 1307 mm - reducible down to W 815 mm
“A FILO” glass sliding doors per millimetre no reductions
Wooden flush sliding doors (START - TWIN - “A FILO” - GRIP - DEEP)
per millimetre no reductions
Flush sliding doors W 1471 mm cannot be reduced.
“A FILO” glass flush sliding doors per millimetre no reductions
SKIN doors no reductions no reductions
WINDOW / GLASS / SWING doors per millimetre reducible down to W 405 mm
Reductions of internal fittings
Type of reduction height width depth
Wood shelves per millimetre reductions depend on linear modules
Shelves with pewter colour profile per millimetre reductions depend on linear modules
Eco Skin shelves per millimetre reductions depend on linear modules
Glass shelves per millimetre reductions depend on linear modules
Clothes rails per millimetre
Central divider pieces 32 mm intervals reductions depend on linear modules
Internal drawers / trinket trays, trouser holders and
pull-out trays / grid with shirt and sweater holders / no reductions no reductions no reductions
shoe rack shelves /pull-out shirt holders / lighting
shelves / islands / movable trays
* If the corner shelves are reduced on two sides, consider double the cost.
Lighting bars can be reduced with a surcharge included in the fee for cutting the shelf.
Cuts to measure
Diagonal cut doors (only for wardrobes with wooden sides) Standard or cut-to-size doors (only for wardrobes with wooden sides)
When compiling the order, indicate the heights H1 and H2 and the width L as For these solutions you can use either single or double units with hinged doors.
in the example.
The cost of a diagonal cut for each single door is the same as that for the hinged
door in the table on page of the doors.
Compositions with diagonal slant are always built with single-door
compartments. Only fitted with START, TWIN, “A FILO”, GRIP or DEEP hinged
doors. Doors must be hinged to the highest side panel. The door finish options
for slanted wardrobes are restricted to cartapaglia, matt lacquer and matt
lacquered cartapaglia. Structures can be either in standard sizes or customised.
H1
DATASHEET
H2
REGISTERED
DESIGN
IX.2018
L
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS
MASTER—
GLASS TOP FOR WARDROBES FINISHED
VINCENT WITH ONLY ONE COMPARTMENT W 790/954
VAN DUYSEN
2015
To use only with: Glass finish Profile finish
- single linear module W 790 / W 954 transparent glass pewter colour
(no modular arrangement is possible) transparent stopsol glass bronze
- only with glass lateral pieces and glass back panel stopsol glass
Increase valid for depths 595 - 23 3/8”
10— W 790 - 31 1/8” W 954 - 37 1/2”
39
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS START door th 25
MASTER—
VINCENT
VAN DUYSEN
2015 Door with handles mounted on the front. Notes
Sliding doors and flush sliding doors are not available in H 2889.
All the hinged doors have cushion-closing hinges.
The sliding door have a shock absorber mechanism which allows them to open and close softly. With fronts in cartapaglia melamine, graffiato, silk and lacquered cartapaglia
Hinges with 155° opening can be used and a key lock can be installed on finishes, the outside of the side panel can be made with matt lacquer finish
hinged doors. (in the same colour as the front), or in melamine in the same finish as the
inside structure (if the side panel is not visible).
Handles
Type “E”
Type “M”
START door Type “E” Type “M”
standard surcharge for each
melamine cartapaglia Finish
melamine graffiato Pewter colour pewter colour
melamine silk structure shiny aluminium
matt lacquer col\ours black chrome
with front insert: bronze
cartapaglia lacquered colours pewter colour
glossy lacquer colours
2 1/4”
matt lacquer colours
57
vertical grain wood woods
11— coloured glass
etched coloured glass
39
hole 286
11 1/4”
Structure and front
insert:
shiny aluminium
black chrome
bronze
hole 232
9 1/8”
45 1/4”
1150
hole 232
9 1/8”
hole 286
11 1/4”
15 3/4”
400
hole 286
11 1/4”
25 1”
2 1/4”
57
finishes
melamine matt lacquer cartapaglia vertical grain glossy lacquer
front colours lacquered wood colours
hinged doors colours
width 487 (19 1/8”)
width 651 (25 5/8”)
width 815 (32 1/8”)
width 979 (38 1/2”)
width 1307 (51 1/2”)
door for terminal element
sliding doors
width 815 (32 1/8”)
width 979 (38 1/2”)
width 1307 (51 1/2”)
width 1471 (57 7/8”)
flush sliding doors
width 815 (32 1/8”)
DATASHEET
width 979 (38 1/2”)
REGISTERED
DESIGN width 1307 (51 1/2”)
width 1471 (57 7/8”)
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS TWIN door th 25
MASTER—
VINCENT
VAN DUYSEN Door with pewter colour or bronze finish handle mounted on the front. Notes
2015 Flush sliding doors are not available in H 2889.
All the hinged doors have cushion-closing hinges. The sliding door have a shock absorber
mechanism which allows them to open and close softly. With fronts in cartapaglia melamine, graffiato, silk and lacquered cartapaglia
Hinges with 155° opening can be used and a key lock can be installed on finishes, the outside of the side panel can be made with matt lacquer finish
hinged doors. (in the same colour as the front), or in melamine in the same finish as the
inside structure (if the side panel is not visible).
TWIN door Handle finish
pewter colour
melamine cartapaglia bronze
melamine graffiato
melamine silk
matt lacquer colours
cartapaglia lacquered colours
glossy lacquer colours
vertical grain wood
12—
39
hole 128 - 5”
240 - 9 1/2”
25 1”
finishes
melamine matt lacquer cartapaglia vertical grain glossy lacquer
front colours lacquered wood colours
hinged doors colours
width 487 (19 1/8”)
width 651 (25 5/8”)
width 815 (32 1/8”)
width 979 (38 1/2”)
width 1307 (51 1/2”)
door for terminal element
flush sliding doors
width 815 (32 1/8”)
DATASHEET
width 979 (38 1/2”)
REGISTERED
DESIGN width 1307 (51 1/2”)
width 1471 (57 7/8”)
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS “A FILO” door th 25
MASTER—
VINCENT
VAN DUYSEN
Door with full-height handle included in the thickness of the door. Notes
2015
The door is available in the versions wood and glass. Sliding doors and flush sliding doors are not available in H 2889.
Glass hinged doors are not available in H 2889.
All the hinged doors have cushion-closing hinges. Flush sliding glass doors cannot be used in compositions with 3 doors.
The sliding door have a shock absorber mechanism which allows them to open and close softly.
Hinges with 155° opening can be used and a key lock can be installed on With fronts in cartapaglia melamine, graffiato, silk and lacquered
hinged doors. cartapaglia finishes, the outside of the side panel can be made with
matt lacquer finish (in the same colour as the front) or in melamine in the
same finish as the inside structure (if the side panel is not visible).
“A FILO” wooden door “A FILO” glass door
melamine cartapaglia Glass:
melamine graffiato coloured
melamine silk etched coloured
matt lacquer colours mirror
cartapaglia lacquered colours
glossy lacquer colours Profile and “a filo” handle:
vertical grain wood pewter colour
13— bronze
39
pewter colour
matt lacquer colours
glossy lacquer colours
shiny aluminium
black chrome
bronze
25 1”
finishes
melamine matt lacquer cartapaglia vertical grain glossy lacquer colouerd glass/
front colours lacquered wood colours etched coloured
colours glass/ mirror
hinged doors
width 487 (19 1/8”)
width 651 (25 5/8”)
width 815 (32 1/8”)
width 979 (38 1/2”)
width 1307 (51 1/2”)
door for terminal element
sliding doors
width 815 (32 1/8”)
width 979 (38 1/2”)
width 1307 (51 1/2”)
width 1471 (57 7/8”)
flush sliding doors
width 815 (32 1/8”)
DATASHEET
width 979 (38 1/2”)
REGISTERED
DESIGN width 1307 (51 1/2”)
width 1471 (57 7/8”)
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS BLADE sliding door th 25
MASTER—
VINCENT
VAN DUYSEN
2015 Door with full-height handle. Notes
BLADE doors are not available with H 2889.
The sliding system automatically aligns the door as it opens and closes.
With fronts in cartapaglia melamine, graffiato, silk and lacquered cartapaglia
finishes, the outside of the side panel can be made with matt lacquer finish
(in the same colour as the front), or in melamine in the same finish as the
inside structure (if the side panel is not visible).
BLADE sliding door
melamine cartapaglia
melamine graffiato
melamine silk
matt lacquer colours
cartapaglia lacquered colours
glossy lacquer colours
vertical grain wood
14—
39
pewter colour
matt lacquer colours
glossy lacquer colours
bronze
25 1”
43
1 3/4”
4,5
1/8”
finishes
melamine matt lacquer cartapaglia vertical grain glossy lacquer
front colours lacquered wood colours
sliding doors colours
width 815 (32 1/8”)
width 979 (38 1/2”)
width 1307 (51 1/2”)
width 1471 (57 7/8”)
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS GRIP door th 25 DESIGN VINCENT VAN DUYSEN
MASTER—
VINCENT
VAN DUYSEN
Door with a handle applied laterally on the edge of the door. Notes
2015
Sliding doors and flush sliding doors are not available in H 2889.
All the hinged doors have cushion-closing hinges. In the pair of hinged doors, the handle is mounted on both doors in the pair.
The sliding door have a shock absorber mechanism which allows them to open and close softly.
Hinges with 155° opening can be used on hinged doors. With fronts in cartapaglia melamine, graffiato, silk and lacquered cartapaglia
finishes, the outside of the side panel can be made with matt lacquer finish
(in the same colour as the front), or in melamine in the same finish as the
inside structure (if the side panel is not visible).
Handles finishes
pewter colour
bronze
pewter colour covered in Eco Skin in the colours (with surcharge per handle)
bronze covered in Eco Skin in the colours (with surcharge per handle)
GRIP door
melamine cartapaglia
melamine graffiato
melamine silk
matt lacquer colours
cartapaglia lacquered colours
15— glossy lacquer colours
vertical grain wood
39
25 1”
49
1 7/8”
finishes
melamine matt lacquer cartapaglia vertical grain glossy lacquer
hinged doors front colours lacquered colours wood colours
width 487 (19 1/8”)
width 651 (25 5/8”)
width 815 (32 1/8”)
width 979 (38 1/2”)
width 1307 (51 1/2”)
door for terminal element
sliding doors
width 815 (32 1/8”)
width 979 (38 1/2”)
width 1307 (51 1/2”)
width 1471 (57 7/8”)
flush sliding doors
width 815 (32 1/8”)
DATASHEET
width 979 (38 1/2”)
REGISTERED
DESIGN width 1307 (51 1/2”)
width 1471 (57 7/8”)
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS DEEP door th 25 DESIGN VINCENT VAN DUYSEN
MASTER—
VINCENT
VAN DUYSEN
2015 Door with recessed handle. Notes
Sliding doors and flush sliding doors are not available in H 2889.
All the hinged doors have cushion-closing hinges. In the pair of hinged doors, the handle is mounted on both doors in the pair.
The sliding door have a shock absorber mechanism which allows them to open and close softly.
Hinges with 155° opening can be used on hinged doors. With fronts in cartapaglia melamine, graffiato, silk and lacquered cartapaglia
finishes, the outside of the side panel can be made with matt lacquer finish
(in the same colour as the front) or in melamine in the same finish as the
inside structure (if the side panel is not visible).
Handles finishes
pewter colour
bronze
pewter colour covered in Eco Skin in the colours (with surcharge per handle)
bronze covered in Eco Skin in the colours (with surcharge per handle)
DEEP door
melamine cartapaglia
melamine graffiato
melamine silk
matt lacquer colours
cartapaglia lacquered colours
glossy lacquer colours
vertical grain wood
16—
39
35 25 1”
1 3/8”
60
2 3/8”
finishes
melamine matt lacquer cartapaglia vertical grain glossy lacquer
hinged doors front colours lacquered colours wood colours
width 487 (19 1/8”)
width 651 (25 5/8”)
width 815 (32 1/8”)
width 979 (38 1/2”)
width 1307 (51 1/2”)
door for terminal element
sliding doors
width 815 (32 1/8”)
width 979 (38 1/2”)
width 1307 (51 1/2”)
flush sliding doors
DATASHEET
width 815 (32 1/8”)
REGISTERED
DESIGN width 979 (38 1/2”)
width 1307 (51 1/2”)
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS NICHE door th 25 DESIGN VINCENT VAN DUYSEN
MASTER—
VINCENT
VAN DUYSEN
2015
Door with recessed handle.
All the hinged doors have cushion-closing hinges.
Hinges with 155° opening can be used on hinged doors.
Handles finishes
pewter colour
bronze
NICHE door
matt lacquer colours
glossy lacquer colours
vertical grain wood
17—
39
950
37 3/8” 890
above 35”
floor
finishes
matt lacquer vertical grain glossy lacquer
colours wood colours
hinged doors
width 487 (19 1/8”)
width 651 (25 5/8”)
width 815 (32 1/8”)
width 979 (38 1/2”)
width 1307 (51 1/2”)
door for terminal element
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS GLASS door, th 35, 180° opening DESIGN VINCENT VAN DUYSEN
MASTER—
VINCENT
VAN DUYSEN
2015
Glass door with 180° opening made with a special soft close hinge inserted in the profile Notes
and completely hidden in the side (exclusively by Molteni). GLASS doors are not available in H 2889.
A full height handle is designed in the profile. In the pair of hinged doors, the handle is mounted on both doors in the pair.
The GLASS door can also be installed on the open corner module.
GLASS door
18—
39
profile:
pewter colour
bronze
glass:
extraclear transparent
transparent stopsol
stopsol
35
1 3/8”
hinge side handle side
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS SWING door, th 35, 180° opening DESIGN VINCENT VAN DUYSEN
MASTER—
VINCENT
VAN DUYSEN
2015
Matt lacquered door with panel and perimeter profiles with a 180° opening made with Notes
a special soft close hinge inserted in the profile and completely hidden in the side SWING doors are not available in H 2889.
(exclusively by Molteni). A full height handle is designed in the profile. In the pair of hinged doors, the handle is mounted on both doors in the pair.
The SWING door can also be installed on the open corner module.
SWING door
19—
39
matt lacquer
colours
profile
matt lacquer
colours
panel
35
1 3/8”
hinge side handle side
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS WINDOW door th 30 DESIGN VINCENT VAN DUYSEN
MASTER—
VINCENT
VAN DUYSEN Glass hinged door with pewter colour finished aluminium frame and lateral handle. Notes
2015
WINDOW doors are not available in H 2889.
The doors are fitted with recessed hinges inserted in the base and top. In the pair of hinged doors, the handle is mounted on both doors in the pair.
Handle finishes
pewter colour
bronze
pewter colour covered in Eco Skin in the colours (with surcharge per handle)
bronze covered in Eco Skin in the colours (with surcharge per handle)
WINDOW glass door
20—
profile:
39 pewter colour
bronze
glass:
extraclear transparent
transparent stopsol
stopsol
30
1 1/8”
54
2 1/8”
th 4 - 1/8”
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS SKIN hinged door th 30 DESIGN VINCENT VAN DUYSEN
MASTER—
VINCENT
VAN DUYSEN
2015
Eco Skin covered hinged door with pewter colour and bronze finished aluminium frame Notes
and lateral handle. SKIN doors are not available in H 2889.
In the pair of doors, the handle is mounted on both doors in the pair.
The doors are fitted with recessed hinges inserted in the base and top.
Handle finishes
pewter colour
The door is always divided into 3 equal parts. bronze
pewter colour covered in Eco Skin in the colours (with surcharge per handle)
bronze covered in Eco Skin in the colours (with surcharge per handle)
SKIN hinged door
pewter colour
21— bronze
39 H 2601 - 102 3/8”
H 2409 - 94 7/8”
H 2313 - 91”
pewter colour
bronze 867
34 1/8”
803
panels covered in Eco 31 5/8”
771
Skin in the colours: 30 3/8”
grey
mink
hemp
ivory
867
dark brown 803 34 1/8”
771 31 5/8”
30 3/8”
total height
above floor
1080 42 1/2”
803 867
771 34 1/8”
31 5/8”
30 3/8”
30
1 1/8”
54
2 1/8”
4 1/8”
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS SPECIAL ELEMENTS
MASTER—
VINCENT
VAN DUYSEN Column with open compartment Reductions
2015 Reductions are allowed only in height, and costs of cutting the structure and doors are
- Can be inserted only in wardrobes without doors or with hinged doors. applied. Open compartment and lower part cannot be reduced.
- Central partitions and/or lateral pieces close the column and cannot be frame or glass.
- The open compartment is always in matt lacquered colours. Wire passage EPA1 Ø 60 chrome on request on back.
- Doors are always without handles because they protrude with respect to the structure.
- Drawers are fitted with the “E” handle of the START door. Notes
- Front finish: melamine front, matt lacquered colours, glossy lacquered colours and wood. The back of the open compartment cannot hold a mounted TV.
* The price does not include the central partitions or side panels, nor the
internal shelves.
H 2343 H 2439 H 2631 H 2919
22—
39
954/1282
1443
1155
867 963
80
698 934/1262 718
778
W 954 W 1282 W 954 W 1282 W 954 W 1282 W 954 W 1282
MVGC9/23E MVGC13/23E MVGC9/24E MVGC13/24E MVGC9/26E MVGC13/26E MVGC9/29E MVGC13/29E
H 2343 H 2439 H 2631 H 2919
954/1282
1443
1155
867 963
80
678 718
798
W 954 W 1282 W 954 W 1282 W 954 W 1282 W 954 W 1282
MVGA9/23E MVGA13/23E MVGA9/24E MVGA13/24E MVGA9/26E MVGA13/26E MVGA9/29E MVGA13/29E
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS SPECIAL ELEMENTS
MASTER—
VINCENT
VAN DUYSEN Column with external drawers Reductions
2015
Reductions are allowed only in height, and costs of cutting the structure and doors are
- Can be inserted only in wardrobes with hinged doors. applied.
- Central partitions and/or lateral pieces close the column and cannot be frame or glass.
- Pairs of doors always have only one handle mounted on the right door.
- Drawers are fitted with the “E” handle of the START door.
- Front finish: melamine front, matt lacquered colours, glossy lacquered colours and wood.
* The price does not include the central partitions or side panels, nor the
internal shelves.
Doors with
type “E” handle
23— H 2343 H 2439 H 2631 H 2919
39
954/1282
2153
1673 1865
1577
761
W 954 W 1282 W 954 W 1282 W 954 W 1282 W 954 W 1282
MCE9/23E MCE13/23E MCE9/24E MCE13/24E MCE9/26E MCE13/26E MCE9/29E MCE13/29E
Doors with
“A FILO” handle
H 2343 H 2439 H 2631 H 2919
954/1282
2153
1673 1865
1577
761
W 954 W 1282 W 954 W 1282 W 954 W 1282 W 954 W 1282
MCE9/23F MCE13/23F MCE9/24F MCE13/24F MCE9/26F MCE13/26F MCE9/29F MCE13/29F
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS FILLERS AND OPENING SIDE TRIMS
MASTER—
VINCENT
VAN DUYSEN
2015 Horizontal filler
The filler is supplied in two parts, one part to be fixed to the ceiling to which the other will be If this detail is not specified when placing the order, the filler will automatically be placed
hooked on (see diagram below). flush with the structure and the side panel will have the extension profile.
The distance of the filler from the door is the client’s decision.
In the cartapaglia finish, the grain direction is always vertical. Opening fillers
In the wood and graffiato finish, the grain direction is always horizontal. Can be made with START and “A FILO” door. For handles, see surcharge.
Always have the 155° hinges.
Vertical filler Are the same height as the other doors in the composition.
The vertical filler can be placed flush with the structure or the door. Have a closing strip on their lower part.
This detail must be specified in the order to prepare the side panel (see example). In the wood finish, the grain direction is always vertical.
Horizontal filler side sections Vertical filler horizontal sections Opening filler horizontal sections
Flush with structure
ceiling 3
min 40 - max 268 min 180 - max 487
24— min 88 filler
max 273
39
10 structure structure
solid wood
structure to wall
door
wall filler side door min 180 - max 487 side
rubber partition partition
with without
extension extension
profile profile
Flush with door
ceiling 3
min 40 - max 256
min 117 filler
max 302
39/45 for 3-door flush sl. doors wardrobe
structure
door
wall filler side door
rubber partition
without
extension
profile
Set back
min 40 - max 268
structure
wall filler door
rubber
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS LIGHTING SYSTEM
MASTER—
VINCENT
VAN DUYSEN
2015
Lighting bars with front LEDs Lighting shelves
Internal compartments of Gliss Master wardrobes can be equipped with front LED lighting. It is possible to insert one or more lighting shelves in Gliss Master compartments.
The lighting bar can be applied to lids or to wooden, transparent glass and Eco Skin shelves. Using the electrified wire strip mounted on the side panel, the lighting shelf can be moved.
Using the electrified wire strip installed on the side (wood, frame or glass), the shelf can Lighting shelves can be connected to the wire strip on the left side panel or
be moved. For each compartment length, we have make specific lighting bars with wiring can be mounted without wire strip.
compliant with European safety standards.
A wire strip is not needed if the compartment only has lighting on the top piece. Notes
Lighting bars can be reduced with a surcharge for the shelf cutting. When placing the order, the customer must indicate how many shelves with lighting bars or
lighting shelves are required. Lighting bars or lighting shelves can be placed in the same
compartment. For assembly: a lighting system on wardrobe with hinged
doors requires a minimum extra height of 5 cm (2”).
Individual wire strip is always installed on the left side panel of the
compartment, with the exception of corner units for walk-in wardrobes and of
the compartment next to the corner unit.
When ordering, indicate compartments with wire strip.
lighting bars W 462 W 626 W 790 W 954 W 1282 open corner element
3000 K 6 watt 8 watt 10 watt 12 watt 16 watt 20 watt
25—
39
EBI4C EBI6C EBI8C EBI9C EBI13C EBA13C
lighting shelves W 626 W 790 W 954 W 1282
D 538 th 30 12 watt 15 watt 18 watt 30 watt
3000 K
RSL/6C RSL/8C RSL/9C RSL/13C
components power supply sensor electrified wire strip connector radio control kit power supply unit
per system unit 100W (max 6 lighting bars) with brightness block 100W
(see the diagram for setting with watertight box
component use and to wire strip (1 per power for wardrobe with
calculate system cost) supply unit) glass top
optional
EAL1 ESE1 ECA1 ECO1 EKRR1 EAB1
position of position of
bar and wire strip bar and wire strip
on wooden partitions on glass partitions
lighting bar lighting bar
66 66
2 5/8” 2 5/8”
wire strip wire strip wire strip
48 48
1 7/8” 1 7/8”
84 84
3 1/4” 3 1/4”
shoe rack
DATASHEET
led light
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS LIGHTING SYSTEM
MASTER—
VINCENT
VAN DUYSEN
2015 System construction diagram
A composition (wardrobe) can be equipped with more than one system and more than one
power supply unit. The system with sensor must be autonomous from the system with
remote controlled electrical socket.
types of systems system with sensor + wire strip system with sensor
with sensors suggested for wardrobes with doors (not for use with glass backs)
suggested for wardrobes with doors and
bars positioned only on the top piece
partition in wood, partition in wood,
frame or glass frame or glass
26—
39
* each power supply unit can power a max. of 100W or:
max 6 sensors
max 6 wire strip or 6 LED lights
sensor (1 per compartments)
power supply unit (per composition )
*
wire strips on lateral pieces (per compartment)
connector (for compositions of 4 power supply units max.)
types of systems with remote control system with wire strip for remote control system with remote control electrical socket
electrical socket or radio remote electrical socket (not for use with glass backs)
control suggested for wardrobes without doors (walk-in suggested for wardrobes without doors (walk-in wardrobes)
one radio remote control unit can control wardrobes) and glass doors and glass doors
systems with 2 power supply units max.
Otherwise, more radio remote control units
must be used.
partition in wood, partition in wood,
frame or glass frame or glass
* each power supply unit can power a max. of 100W or:
max 6 wire strips or 6 LED lights
power supply unit (per composition )
*
wire strips on lateral pieces (per compartment)
connector (for compositions of 4 power supply units max.)
radio remote control (optional) (optional) (optional)
DALI kit
(for DOMOTICA)
n. 1 for each power supply unit
cannot be used with
radio remote control
DATASHEET
REGISTERED
DESIGN
IX.2018 EKDA1
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS INTERNAL ACCESSORIES
MASTER—
VINCENT
VAN DUYSEN
2015
Aircub is an air purifier and aroma diffuser that eliminates up to 95% of the harmful agents inside wardrobes through a process of ionisation and ozonation. Aircub can be managed
easily from your smartphone with a dedicated app. Aircub can be installed on the back panel of each compartment. Just plug it into the electrical socket and turn it on. Every Aircub has
a single plug. Up to 3 Aircubs per wardrobe can be installed using the specific multi-socket connector.
Aircub - air purifier product advantages
W 270 D 28 H 120 - improves air quality
W 10 5/8” D 1 1/8” H 4 3/4” - reduces bacteria that cause foul odours
(cable length L3m) - prevents mould and mites from forming
- dispenses fragrance
- does not have filters that require maintenance or changes
- includes n.1 fragrance pod
L3m
27— EAC1
39
multi-socket connector
cable length 3m
W 250 D 60 H 40
W 9 7/8” D 2 3/8” H 1 5/8”
L3m
EAC2
=
= =
= =
=
For correct function it is advisable
to position the Aircub at the centre
of the compartment
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS INTERNAL FITTINGS
MASTER—
VINCENT
VAN DUYSEN
2015 Internal fittings Internal fittings
with wooden sides with frame or glass sides
1 2 2
8A 1
5
8B
7
9 11
4
6 10
28—
39 3
1 Shelf th 30 mm 4 Trouser holder 7 Shirt and sweater holder grid 10 Floor standing drawer unit only for compart.
(wood, glass, Eco Skin) only for wood sides with frame or glass sides
5 Central divider piece
2 Clothes rail th mm 30 only for compart. 8A Inclined shoe rack shelf 11 Suspended drawer unit only for compart.
with wooden sides only for wooden sides with frame or glass sides
3 Modular drawer unit
only for wooden sides 6 Swivel pull-out 8B Horizontal shoe rack shelf
mirror only for compart. only for frame or glass sides
with wooden sides
9 Pull-out shirt holder
only for wooden sides
Section of internal fittings
595 - 23 3/8”
575 - 22 5/8”
266-10 1/2” 309-12 1/8” 435 - 17 1/8” for use
only with wooden sides
clothes rail
538 - 21 1/8” 378 - 14 7/8”
shelf th 30 mm (1 1/8”) shelf th 30 mm (1 1/8”)
378 - 14 7/8”
grid with shirt and grid with sweater
sweater holders holders
shoe rack shelf
th mm 30 (1 1/8”)
for compartments clothes rail
with wood sides
always inclined
shoe rack shelf
th mm 30 (1 1/8”)
538 - 21 1/8” for compartments
36 - 1 3/8”
with wood sides
always inclined
46 - 1 3/4”
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS INTERNAL FITTINGS - SHELVES, SHOE RACK SHELVES
MASTER—
VINCENT
VAN DUYSEN
2015
wood shelves - top shelves (only D 538) shelf for open corner element
D 538 th 30 th 30
D 378 th 30
W 298 W 462 W 626 W 790 W 954 W 1282 1081x1081 1262x1262
RI/3 RI/4 RI/6 RI/8 RI/9 RI/13 RIA/11 RIA/13
glass shelves can be fitted transparent glass shelves not for use in compartments
with front LED light bars D 538 th 30 adjacent to the corner element in
and comply with the wiring D 378 th 30 wardrobes with doors
standards
W 462 W 626 W 790 W 954 W 1282
RV/4 RV/6 RV/8 RV/9 RV/13
Eco Skin shelves can be Eco Skin shelves - shelves with Eco Skin cover (only D 538) Eco Skin shelf for open
29— fitted with front LED light D 538 th 30 corner element
39 bars and comply with the D 378 th 30 th 30
wiring standards
When ordering,
specify the finish
Eco Skin and profile
W 298 W 462 W 626 W 790 W 954 W 1282 1081x1081 1262x1262
RE/3 RE/4 RE/6 RE/8 RE/9 RE/13 REA/11 REA/13
Shoe rack shelves Notes
Shoe rack shelves can be used with wood sides and with frame or glass sides. To hook to the frame or glass sides, add the price of the relative metal profiles.
When inserted between wood sides, this part will always be inclined (example 1).
When there are frame or glass sides, this part will always be horizontal (example 2).
example 1 shoe rack shelves example 2
D 538 th 30
W 462 W 626 W 790 W 954 W 1282
RSP/4 RSP/6 RSP/8 RSP/9 RSP/13
example 1 shoe rack shelves
D 368 th30
W 462 W 626 W 790 W 954 W 1282
RQP/4 RQP/6 RQP/8 RQP/9 RQP/13
metal profile metal profile metal profile for attaching
for attaching shelves for attaching shelves shelves with LEDs to frame side
to frame side to glass side (always on the left, except in corner
shelves)
DATASHEET
REGISTERED PST PSV PSE
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS INTERNAL FITTINGS - CLOTHES RAILS, HANGER RAILS, PULL-DOWN HANGERS,
MASTER—
VINCENT CENTRAL DIVIDER PIECES
VAN DUYSEN
2015
clothes rails clothes rail for
corner compartment
with doors
W 298 W 462 W 626 W 790 W 954 W 1282
PO/3 PO/4 PO/6 PO/8 PO/9 PO/13 POA/6
clothes rail clothes rails
for D 435 for open corner
to mount on wood shelves or compartment
top only with hinged doors
nr. 1 piece on compartment W 626/790
30— nr. 2 pieces on compartment W 954/1282
39
W 723 W 1262
POQ/4 POA/7 POA/13
pull-out coat hanger rail hanger hanger with clips
for melamine shelf (without profile) th 30 W 450 W 450
beech stained grey beech stained grey
(package of 10 pieces) (package of 3 pieces)
OP7 OP10 OP11
Maximum pull-down hanger
load-bearing capacity H mm 1040
10 kg for compart. W 626 for compart. W 790 for compart. W 954 for compart. W 1282
SER/6 SER/8 SER/9 SER/13
When ordering, specify floor standing 1734
the finish of the front profile: central divider pieces
pewter colour or bronze 1542
D 538 th 30
1350
1158
966
774
582
390
SDT/04 SDT/05 SDT/07 SDT/09 SDT/11 SDT/13 SDT/15 SDT/17
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.GLISS GLASS LID FOR CHEST OF DRAWERS
MASTER—
VINCENT
VAN DUYSEN
2015
To be used only in compartments with wooden sides
Modular chests of drawers can be made with a transparent glass lid in the module widths
790/954/1282.
It is mandatory that the first drawer be H 190 in wood (special measure).
The top can be fitted with a LED lighting bar, but it cannot be connected to the cable holder.
The connection to the power cord has to pass behind the back panel.
Eco Skin bottoms in grey can be inserted.
W 790 W 954 W 1282
CSV/08 CSV/09 CSV/13
31—
39
Example of use
H 190 wood
DATASHEET
REGISTERED
DESIGN
IX.2018
Dimensions in millimeters and inches. The right to discontinue and make changes is reserved. This information is based on
moltenigroup.com the latest product information available at the time of printing.You can also read
