Compact, Utility
and Mid-Range
Tractors
Compact, Utility and Mid-Range Tractors
FROM MASSEY FERGUSON
A world of experience. Working with you.
TOUGH. VERSATILE. DEPENDABLE. OUR TRACTORS HAVE
It’s a fact. You can find well-used Massey Ferguson® tractors on farms everywhere. Classic beauties with more than a few hours on them, still
getting the job done, day after day, season after season. These decades-old machines are proven symbols of Massey Ferguson’s commitment
to durability, reliability and good old-fashioned toughness. And like land itself, they’re often handed down from generation to generation.
Today, we’re reinventing what compact, utility and mid-range tractors can be and redefining what they can do. Read on to learn about
our three distinct categories of performance that combine the right features and options to best meet your needs, and get any job done.
Massey Ferguson — the last tractor you’ll ever need.
2 Learn more at masseyferguson.us, or see your dealer for a demo.
E BEEN RUNNING IN FAMILIES FOR GENERATIONS.
compact
Smaller, hardworking tractors with plenty
p. 6
of muscle. Yet easy enough to hop on and
get the job done.
utility
All the horsepower you need for jobs
p. 10
like hay and heavier loading.
mid-range
These tractors pack even more horsepower
p. 14
and are rugged enough for full-on, full-time work.
Hay. Dairy. Municipality. And more.
Learn more at masseyferguson.us, or see your dealer for a demo. 3
“ I KNOW I NEED A TRACTOR,
BUT WHAT KIND?” compact
Tractors come in all shapes and sizes. While many of us only associate tractors with large
farms, the fact is, even if you just have a few acres, a compact, utility or mid-range tractor
can make your life a whole lot easier.
utility
In fact, the right tractor can become one of the most important tools you own. From cutting
grass to moving snow, from digging holes to hauling loads, the possibilities are endless.
But with such an investment, it only makes sense to decide how much tractor you need
before making a purchase.
mid-range
HOW MUCH LAND DO YOU HAVE? Do you WHAT KIND OF OPERATION DO YOU HAVE? WHAT KINDS OF JOBS DO YOU NEED
plan to add more in the future? Since Massey Are you a full-time livestock, dairy or row crop TO GET DONE? Are you cutting grass? Tilling a
Ferguson tractors are built to last, buying the farmer? Do you farm part time or maybe have a garden? Doing some heavy lifting? Will you need
right tractor now can be more cost-effective farm-to-table business? Is your farming more for to move snow? Brush? Hay? Spread manure?
than upgrading later. Match the tractor to the “fun,” or do you have some property to maintain? Match the tractor — and the implements you
land you live and work on. Match the tractor to who you are. need — to the jobs you need to do.
4 Learn more at masseyferguson.us, or see your dealer for a demo.
YOUR DEALER CAN BE A BIG HELP.
Massey Ferguson is an AGCO® brand. At AGCO, we take pride in knowing our dealers
are the best in the business. They’ll be there to advise and support you throughout
the selection and buying process, and help pick the right tractor for you. Then, after Go to page 18 to learn more
the sale, they’ll continue to be there, day in and day out, for as long as you own your about the implements that work
machine — with the service, expertise and parts you need to stay productive. with our tractors.
When you buy a Massey Ferguson tractor, it becomes part of your family
and you become part of ours.
Learn more at masseyferguson.us, or see your dealer for a demo. 5
SO MUCH MORE THAN A MOWER.
compact
6 Learn more at masseyferguson.us, or see your dealer for a demo.
GC1700 SERIES 1526 COMPACT TRACTORS
Whether you’re a small landowner or a hobby farmer, Our customers wanted a small tractor with a
everything about the Massey Ferguson GC1700 mid PTO for more versatility. We responded by
Series is designed to help you get the job done bringing back the versatile Massey Ferguson
right. From mowing, loading and backhoe work to 1526 premium compact tractor. This tractor’s
snow-blowing and more, these multitaskers deliver built especially for a new generation of landowners
impressive performance and unmatched versatility. who want a machine that’s as hardworking and
practical as they are.
EASY TO USE. Providing more than just
great ergonomics, the operator’s station on the IT CAN DO MORE, BECAUSE IT’S MADE TO
GC1700 Series makes the transition from lawn HANDLE MORE. The 1526 is a smaller tractor,
tractor to small compact virtually seamless. but it’s big on comfort, performance and versatility.
All major controls and functional pedals are in That makes it the perfect all-around machine for
familiar, intuitive locations that are easy to reach tackling any number of chores on large acreage
and operate. So if you’re ready for a real tractor, residences, small farms, golf courses and more.
check out the GC1700 Series. With the largest Best of all, it’s not only one of the easiest
engine in its class, it’ll give you all it’s got — tractors in its class to use, it’s also one of the
and then some. Every single day. most comfortable.
MODELS GC1705 GC1710 GC1715 GC1720 MF1526H
Rated Engine HP (kW) 22.5 (16.8) @ 2,600 RPM 22.5 (16.8) @ 2,600 RPM 24 (17.9) @ 3,000 RPM 24 (17.9) @ 3,000 RPM 24.8 (18.5) @ 2,600 RPM
Rated PTO HP (kW) 17.3 (12.9) 17.3 (12.9) 18.9 (14.1) 18.9 (14.1) 20 (14.9)
Engine type Iseki 1.1 L 3-cylinder liquid-cooled diesel, Tier 4 Final 3-cylinder diesel
Transmission 2-range hydrostatic transmission with side-by-side foot pedals and cruise control 3-range hydrostatic w/ cruise control
8.7 gpm (32.9 LPM) total flow;
Hydraulics 6.3 gpm (23.8 LPM) total flow, includes loader joystick 6.8 gpm (25.7 LPM) total flow, includes loader joystick
factory-installed joystick opt.
Learn more at masseyferguson.us, or see your dealer for a demo. 7
1700E SERIES 1700 SERIES PREMIUM
The Massey Ferguson 1700E Series is a compact, If you’re looking for even more power, comfort,
no-nonsense workhorse that’s easy to operate, convenience and control, step up to the Massey
easy to afford and easy to love. These 4WD Ferguson 1700 Series Premium tractors, with
tractors, with standard rear 540 PTO, 3-point advanced engineering that goes above and beyond
hitch and optional backhoe, deliver more than your expectations. You’ll get performance options
comparably-priced machines. common in larger tractors, but with the simplicity
and fuel efficiency of a compact.
THE E STANDS FOR EFFICIENCY AND EASY.
You get durability and legendary performance. EVERYTHING ABOUT THESE MACHINES
Plus, more capability, more functionality and key IS PREMIUM. All 1700 Series Premium compacts
features like a clean-burning, Tier 4 diesel engine, boast a 540 RPM independent rear PTO, or optional
higher flow hydraulics and your choice of mid PTO,* that engages electro-hydraulically with a
transmission. simple twist of a knob on the front dash. These 36.2
to 59 gross horsepower tractors also include a wet
MATCHED FRONT END LOADER. To further clutch for durability and a modulation button for slow,
improve productivity, the Massey Ferguson loader smooth start-up to prevent shock load damage.
features a quick-attach main frame design for
quick and easy loader mounting and dismounting, *Not available on the 1759
as well as a frame-mounted hydraulic joystick for
convenient loader control.
MODELS 1726E 1734E 1739E 1736 1742 1749 1754 1758 1759
Rated Engine HP (kW) 24.7 (18.4) @ 2,600 RPM 34 (25.4) @ 2,600 RPM 38.5 (28.7) @ 2,800 RPM 36.2 (27.0) @ 2,500 RPM 41.6 (31.0) @ 2,500 RPM 48.3 (36.0) @ 2,500 RPM 53.6 (40.0) @ 2,500 RPM 59.0 (44.0) @ 2,500 RPM 59.0 (44.0) @ 2,500 RPM
20.9 (15.6) Gear 28.9 (21.6) Gear 32.7 (24.4) Gear 27.5 (20.5) Shuttle 32.8 (24.5) Shuttle 39.0 (29.1) Shuttle 42.1 (31.4) Shuttle NA 45.6 (34.0) Shuttle
Rated PTO HP (kW)
19.7 (14.7) HST 27.2 (20.3) HST 30.8 (23.0) HST 26.3 (19.6) HST 31.6 (23.6) HST 37.8 (28.2) HST 40.9 (30.5) HST 44.4 (33.1) HST NA
Engine type Shibaura 1.5 L 3-cylinder diesel, Tier 4 Final 1.7 L 3-cylinder diesel 2.2 L 4-cylinder diesel
Transmission 9 x 3 constant mesh / 3-range hydrostatic (HST) 12 x 12 power shuttle or Servo-HST 12 x 12 power shuttle or Servo-HST Servo-HST 12 x 12 power shuttle
Hydraulics 10.5 gpm (40.0 LPM) 10.5 gpm (40.0 LPM) 11.3 gpm (42.7 LPM) 11.6 gpm (43.9 LPM) 11.6 gpm (43.9 LPM) 11.6 gpm (43.9 LPM) 11.6 gpm (43.9 LPM) 11.6 gpm (43.9 LPM) 12.8 gpm (48.5 LPM)
8 Learn more at masseyferguson.us, or see your dealer for a demo.
compact Massey Ferguson and your dealer support you with an industry-leading parts warranty as well as factory-trained technicians who work as hard at preventing problems as they do repairing them. 9
MORE POWER FOR HAY AND LOADER WORK.
utility
10 Learn more at masseyferguson.us, or see your dealer for a demo.2700E SERIES 2600H SERIES
These hardworking, matter-of-fact tractors combine For more than 160 years, Massey Ferguson has been
the practicality of a compact tractor with the added the benchmark for what a great utility tractor should
functionality of a utility tractor. That makes the be. Now we’ve added to that legacy with the 2600H
versatile 2700E Series ideal for loader work, rotary Series, a rugged line of tough and dependable tractors
cutting or any other rear PTO job that needs doing. that easy to use, easy to like and easy to pay for. Yet
These tractors are perfect for hobby farmers, farm-to- still rugged and durable. Featuring a simple, open
table operations, small businesses or just people with design with a hood and fenders made out of solid
a lot of property and a ton of tasks to wrangle. steel. High capacity hydraulics for loader and
implement work. And, of course, the legendary 3-point
IT’S READY TO GO WHEN YOU ARE. hitch that Massey Ferguson invented so long ago.
At 12.6 gallons (47.7 liters) per minute, the 2700E
tractors have a higher hydraulic flow rate than RE-WRITING THE DEFINITION OF VALUE. The
comparable models, allowing for greater speed in 2600H Series offers four different models, ranging
loader work and tasks using other implements. So from 44.4 to 73 horsepower. Within each model, you
whether you’re bringing in the hay, cleaning the barn get the option of 2- or 4-wheel drive. This helps
or just doing general land maintenance, the two determine your transmission and PTO. Our 8x2
tractors in this series will not just be handy, but Sliding Mesh and Live PTO give you a more
absolutely indispensable. inexpensive option, while the 8x8 Synchro Shuttle and
Independent PTO provide even more great features at
a low price.
MODELS 2705E 2706E MODELS 2604H 2605H 2606H 2607H
Rated Engine HP (kW) 48.8 (36.4) @ 2,600 RPM 57.3 (42.7) @ 2,600 RPM Rated Engine HP (kW) 44.4 (33.1) 54.2 (40.4) 64.1 (47.8) 73.0 (54.4)
41.4 (30.9) 8x8 48.7 (36.3) 8x8
Rated PTO HP (kW) Rated PTO HP (kW) 38.0 (30.1) 46.0 (33.8) 55.0 (40.4) 64.0 (47.0)
39.0 (29.1) HST 45.9 (34.2) HST
Shibaura N4LDI-T, 2.2 L, Shibaura N4LDI-TA, 2.2 L,
Engine type Engine type Simpsons 2.6 L, 3-cylinder, EPA Tier 4 final-compliant
4-cylinder liquid-cooled diesel 4-cylinder liquid-cooled diesel
8 x 8 (4-speed x 2 sub-range) syncro shuttle / 2WD: 8F x 2R sliding mesh with live PTO
Transmission Transmission 8F x 8R synchro shuttle
3-range mechanical HST 4WD: 8F x 8R synchro shuttle with independent PTO
Hydraulics 12.4 gpm (47.8 LPM) Hydraulics 15.7 gpm (59.5 LPM)
Learn more at masseyferguson.us, or see your dealer for a demo. 114600M SERIES 4700 SERIES
Whether it’s rural lifestyle farming, professional You’ve got a ton of different jobs to get done every
or government use, the Massey Ferguson 4600M day, and the last thing you need is a lightweight
Series is ideal for loader work, mowing, hay tractor that shies away from the tough ones. That’s
production and any other job you can throw at it. why Massey Ferguson 4700 Series tractors are built
They’re durable, easy-to-operate tractors in a small, extra tough to handle bigger jobs, while giving you
yet powerful package with just the right mix of added stability and comfort. At a best-in-class base
innovation, technology and comfort. weight of 7,125 lbs., the 4700 Series is purpose-built
for more pulling power, more lift capacity and
YEARS OF INNOVATION LEAD TO THIS. greater maneuverability.
The 4600M Series tractors continue our legacy
for a new generation of customers who demand UTILITY GOES HEAVY DUTY. Hay, dairy
premium quality in a very rugged machine. These operations, small farms and more all need a tough
Tier 4 Final tractors feature a more robust design, do-everything tractor that can handle the heavy
with more stability and more lift capacity than ever lifting. The 4700 Series tractors deliver, giving you
before. Not to mention a new optional deluxe cab. the power and versatility to handle your toughest
jobs so you can get more done faster, regardless
of the kind of operation you have.
MODEL MF4607M* MF4609M MF4610M MF4707* MF4708 MF4709 MF4710
Max Engine HP (kW) @ 2,000 RPM 70.1 (52.2) 89.8 (66.9) 99.0 (74.1) 75 (55.9) 85 (63.4) 95 (70.8) 100 (74.6)
Rated Engine HP (kW) @ 2,200 RPM 70.1 (52.2) 89.8 (66.9) 99.0 (74.1) 70 (52.2) 80 (59.7) 90 (67.1) 100 (74.6)
Rated PTO HP (kW) @ 2,200 RPM 56.0 (41.8) 72.0 (53.7) 80.0 (59.7) 57 (42.5) 66 (49.2) 75 (55.9) 84 (62.6)
Engine type AGCO Power™ 3-cylinder, 3.3 L, intercooled turbocharged, high-pressure common rail direct fuel injection (HPCR)
Classic: 8F x 8R, 2-range, synchro Classic: 8F x 8R, 2-range, syncro shuttle, Classic: 12F x 12R, 2-range, syncro
12F x 12R 2-range Std. or 18F x 18R 3-range (with Opt. creeper gear), shuttle, 4 gears synchronized mechanical shuttle lever shuttle, mechanical shuttle lever
Transmission
power shuttle – 6 gears synchronized, electro-hydraulic shuttle lever Deluxe: 12F x 12R, 2-range, power Deluxe: 12F x 12R, 2-range, power shuttle, Deluxe: 12F x 12R, 2-range, power
shuttle, 6 gears synchronized electro-hydraulic shuttle lever shuttle, electro-hydraulic shuttle lever
Hydraulics 17.5 gpm (66.5 LPM) 17.7 gpm (67 LPM)
*Tier IV Final without the use of a DPF (diesel particulate filter) or DEF (diesel exhaust fluid).
12 Learn more at masseyferguson.us, or see your dealer for a demo.utility
Learn more at masseyferguson.us, or see your dealer for a demo. 13EVEN MORE POWER FOR MORE DEMANDING JOBS.
mid-range
Every Massey Ferguson tractor is backed by a network of local dealers who are as committed to your tractor as you are. You can count on your
14 dealer during critical planting, harvesting, mowing and spraying periods to always be there with emergency part drops and extended hours.5700 SERIES 6700 SERIES
If you need to work efficiently in a variety of Your work is demanding. You want a tractor
conditions, look no further than the Massey Ferguson ready to meet that demand — and then some.
5700 Series. These tractors are engineered from the The heavy-duty 6700 Series is ready to go when
ground up for smart, versatile, long-lasting operation. you are, with the power to pull larger, heavier
They won’t let you down, no matter how demanding implements and take on even the most rigorous
the job, and are especially easy to use, with a price tasks in a variety of conditions and environments.
point seldom found on this size tractor.
SPACIOUS AIR-CONDITIONED CAB FOR
A BIGGER TRACTOR AND MORE HP FOR OPERATOR COMFORT. These strong, agile
YOUR MONEY. Built as part of Massey Ferguson’s machines come with the largest cab in the sector,
commitment to developing a completely new range offering industry-leading comfort, control and
of modern and versatile tractors, the 5700 Series functionality. Plus you get lower cab noise than
tractors are ideally suited to get the job done right, everyone in the industry. The low cost of ownership
wherever you work, from livestock and dairy is an added bonus and makes them well-suited to
enterprises to mixed farms, transport and loader working in fleets on large enterprises, or as
applications. complimentary tractors on large farms.
MODELS MF5710 MF5711 MF6712 MF6713*
Max Engine HP (kW) @ 2,000 RPM 100 (74.6) 110 (82) 120 (89.4) 130 (96)
Rated Engine HP (kW) @ 2,200 RPM 95 (70.8) 105 (78.3) 115 (85.8) 125 (93.2)
Rated PTO HP (kW) @ 2,200 RPM 82 (61.2) 92 (68.6) 99 (73.8) 109 (81.3)
Engine type AGCO Power 4-cylinder, 4.4 L, intercooled turbo-charger, high-pressure common-rail direct fuel injection (HPCR)
™
Classic: 5710 & 5711: 12F x 12R, 2-range, syncro shuttle, mechanical shuttle lever
Transmission Deluxe: 5710 & 5711: 12F x 12R, 2-range, power shuttle, electro-hydraulic shuttle lever
Deluxe: 6712 & 6713: 12F x 12R, 2-range, power shuttle, electro-hydraulic shuttle lever
Classic: Main pump 15.1 (57)
Deluxe: Main pump 15.1 (57) & Auxiliary
Hydraulics Deluxe: Main pump 15.1 (57) & Auxiliary pump 10.8 (41),
pump 10.8 (41), Total combined 25.9 (98)
Total combined 25.9 (98)
*Not currently for sale in the state of Nebraska
Learn more at masseyferguson.us, or see your dealer for a demo. 15mid-range 16 Learn more at masseyferguson.us, or see your dealer for a demo.
5700SL SERIES
The Massey Ferguson 5700SL Series is one of the most advanced,
premium, mid-range tractor we’ve ever made. With its smart and stylish
award-winning design, the 5700SL Series features the best visibility on the
market, and the latest on-board technologies, too.
THE ULTIMATE DO-ANYTHING, GO-ANYWHERE WORKHORSE.
Because of its small size, this tractor offers excellent maneuverability,
even in tight quarters. Its powerful 110-130 horsepower four cylinder, 4.4
liter engine means it can get any job you need done fast and done right.
Plus, our exclusive Hi-Vis hood coupled with the multi-function joystick
makes this tractor the best loader tractor on the market.
PLENTY OF OPTIONS
The 5700SL Series offers 540/540e/1000 PTO options or an integrated
front hitch and PTO. You can also choose closed center hydraulics and up
to four rear valves. Lastly, our Visio Roof option gives you better visibility for
all types of loader and implement work.
MODELS MF5711SL MF5712SL MF5713SL*
Max Engine HP (kW) @ 2,000 RPM 110 (82) 120 (89.5) 130 (96.9)
Rated Engine HP (kW) @ 2,200 RPM 105 (78.3) 115 (85.8) 125 (93.2)
Rated PTO HP (kW) @ 2,200 RPM 85 (63.4) 95.0 (70.8) 105 (78.3)
AGCO Power™ 4-cylinder, 4.4 L, intercooled turbocharger,
Engine type
high-pressure common rail direct fuel injection (HPCR)
Dyna-4 16 x 16 Powershift and power shuttle transmission,
Transmission
available 13:68:1 creeper
15 gpm (57 LPM) (open center), 26 gpm (100 LPM) (twin flow)
Hydraulics
29 gpm (110 LPM) Opt. (closed center)
*Not currently for sale in the state of Nebraska
Learn more at masseyferguson.us, or see your dealer for a demo. 17WE’VE GOT THE TOOLS YOU NEED TO GET THE JOB DONE RIGHT.
Every Massey Ferguson compact, utility and mid-range tractor is designed to be versatile, but
it’s important to remember that your tractor’s usefulness can go well beyond cutting grass and
plowing fields.
With the right implements and attachments, these tractors can be ready to handle whatever job
you throw at them, from moving and spreading manure, clearing snow, digging post holes, tilling
soil, cutting hay, clearing brush and much more.
Best of all, Massey Ferguson and our dealer network offer a wide selection of front loaders,
backhoes, rotary cutters, shredders, rakes, seeders and more that are all made to attach quickly
and easily to your tractor.
MASSEY FERGUSON WOODS EQUIPMENT
Dozer blades Batwing rotary cutters
Rotary brooms Single spindle rotary cutters
Loaders Multi-spindle rotary cutters
Backhoes Rear-discharge finish mowers
Snow blowers Mid-mount finishing mowers
Mower decks Center drive flail shredders
End drive flail shredders
Snow blowers
HAY IMPLEMENTS Rear blades
Round balers Box scrapers
Small square balers Grading scrapers
Disc mowers Landscape rakes
Mower conditioners Precision super seeders
Rakes Post hole diggers
Tedders Forward and reverse rotary tillers
Disc harrows
18 Your dealer is happy to help you get the right attachments designed to work with your new tractor.THE LAST TRACTOR YOU’LL EVER NEED.
Learn more at masseyferguson.us, or see your dealer for a demo. 19Compact, Utility and Mid-Range Tractors
masseyferguson.us
FIVE-YEAR POWERTRAIN WARRANTY LOW-RATE, FLEXIBLE FINANCING SHOW YOUR MASSEY FERGUSON PRIDE
We’ve been making tractors for a With competitive rates and easy terms, your Choose from collectibles, toys, work and
long time, and we believe in what we Massey Ferguson dealer and AGCO Finance® offer leisure wear, accessories and more. Visit
make. That’s why we offer a five-year great ways to buy, lease or rent your new machine. shopagco.com today.
powertrain warranty. Some restrictions
may apply. Please see dealer for full details. QUALITY PARTS AGCO ANSWERS
Genuine Massey Ferguson replacement At AGCO, customer care isn’t just a department,
TOTAL SUPPORT — ALWAYS AVAILABLE parts are made to the same high standards it’s a commitment. We’ll do our best to answer
The Massey Ferguson distributor and dealer as those used on the assembly line, so you any questions promptly, or put you in touch
network comes with the support and service you can always keep your Massey Ferguson with someone who can. AGCO Answers:
need to keep working — whenever and wherever tractor running like new. (877) 525-4384 or agcoanswers@agcocorp.com
you need it.
We proudly support:
For more than 25 years, in more than 140 countries worldwide, AGCO has been on a mission to become the single resource farmers can
depend on for innovative, leading-edge thinking, equipment and technology. And, today, you know AGCO brands, even if you don’t know
the AGCO name. While AGCO equipment may not all share the same logo or same color, they all have one thing in common – the ability to
help farmers be as productive and profitable as they possibly can be, regardless of the tasks at hand. agcocorp.com
©2016 AGCO Corporation. Massey Ferguson is a worldwide brand of AGCO Corporation. AGCO and Massey Ferguson are trademarks of AGCO ®. All rights reserved. MF16B009CR
AGCO may at any time, and from time to time, for technical or other necessary reasons, modify any of the data, specifications or warranty of the products described herein. Some equipment shown may be
optional. Attention: Photographs in this publication may show protective shields and guards open or removed for the purposes of illustration. Be certain all shields and guards are in place during operation.You can also read
