Price list valid from 01.01.2022
Arto The dynamic compact liner - NIESMANN+BISCHOFF
Content                       Arto
05 Standard Equipment Arto   Models
08 Technical Data
14 Equipment Packs
18 Optional Features
30 Important Information

                                       77 E   79 R

                                       85 E   88 EK   88 LF

                                                       Arto Models   3
Arto The dynamic compact liner - NIESMANN+BISCHOFF
Standard Equipment Arto
Layout variants “Face-to-Face”                                           Chassis
It is possible to order the models 77 E, 85 E, 88 EK / LF in a           • Fiat Ducato                                                    • Independent suspension on front and rear axle
“Face-to-Face” layout (straight kitchen and seat bench, see              • Airbag for driver and passenger seat                           • AL-KO-lightweight low frame chassis with maximum
code V4044023 on page 22):                                               • Turbo diesel engine with electronically controlled Common        frame lowering (220 mm)
                                                                           Rail Direct Injection                                          • Hot-dip galvanised frame elements and wide chassis
                                                                         • Emission class Euro VI E (heavy duty homologation) with          (1 980 mm)
                                                                           exhaust gas recirculation                                      • Bracing of the chassis for more driving dynamics and
                                                                         • Manual 6-speed transmission                                      driving comfort by means of highly resistant hollow steel
                                                                         • Electronically controlled anti-lock braking system (ABS)         sections for along- and cross-bracings, which are
                                                                         • ESC with hill holder and traction + and hill descent control     screwed to the AL-KO low frame
                                                                         • Disc brakes on front and rear axle                             • Fuel tank 90 l + 19l AdBlue tank
                                                                         • Electronic brake pad wear indicator                            • Start / Stop system
                                                                         • Electronic brake force distribution (EBFD)                     • Automatic air conditioning with pollen filter in driver’s cabin
                                                                         • Alternator 14 V / 150 A                                        • Cruise control
                                                                         • Battery 12 V / 95 Ah                                           • Comfort springs at the front axle
                                                                         • Tyres with steel wheel rims 225 / 75 R 16
                                                                         • Tyre sealant with compressor (Fix + Go)
                                                                         • Tyres on front and rear axle with traction profile,
                                                                           M+S designation

    77 E                 85 E                 88 EK              88 LF
                                                                         Driver’s Cab
                                                                         • Panoramic windscreen made of laminated safety glass,           • Belt-integrated driver and passenger seat, rotatable by
                                                                           tinted, with sun shield                                          180°, armrests and lateral parts in real leather
                                                                         • Flush-sealed windscreen                                        • Electric steering
                                                                         • Laterally suspended exterior rear-view mirrors                 • Height-adjustable steering wheel
                                                                         • Original Fiat Crashbox                                         • Battery main switch for chassis battery
                                                                         • Engine bonnet with large opening angle and gas pressure
                                                                           opening mechanism

                                                                         Bodyshell
                                                                         • Outside walls including garage doors made of torsion-          • Box structure completely without wood
                                                                           resistant 2-sided-aluminium sandwich construction              • Lighting protection because of Faraday cage
                                                                           (30 mm) with styrofoam insulation (RTM)                        • Aluminium roof profiles with rain water channel for reducing
                                                                         • Roof in sandwich construction (30 mm), torsion-resistant         side panel soiling
                                                                           with styrofoam insulation (RTM), inside aluminium, outside     • Connection of roof plate and front mask free of displace-
                                                                           corrosion-free GRP High Strength X-treme including gel           ments prevents accumulation of rain water on the roof
                                                                           coat sealing                                                   • Side wall panel smooth, stove-enamelled white
                                                                         • Ceiling-to-wall connections without cold bridges,              • Front mask, fenders, wheel cases and rear panel of highly
                                                                           by means of highly compressed PU hard profiles                   stable and corrosion-free glass fibre composite material

4    Layout variants “Face-to-Face”                                                                                                                                          Standard Equipment Arto     5
Arto The dynamic compact liner - NIESMANN+BISCHOFF
Standard Equipment Arto
• Side skirts of smooth aluminium profiles, stove-              • Rear garage floor coated with highly wear-resistant            Bathroom and Toilet
  enamelled white                                                 dimpled membrane
• Heated and insulated central double floor of 290 mm           • Insulated bodyshell windows, double- glazed plastic            • Spacious bathroom solutions                                   • Shower with acrylic glass door and ­removable clothes rail
  height                                                          window in outer aluminium frame with PU insulation,            • High-quality bathroom door with stainless steel door          • Shower fitting with wall rail and height adjustable shower
• Water and waste water tank frost-proof integrated in the        with pleated darkening blind and insect protection               handle set                                                      head
  heatable double floor                                         • Garage walls covered with needle felt                          • Generously sized mirror cabinet with shelf                    • Cassette toilet with trolley system and ceramic bowl
• Solid entrance door with electric closing aid, double         • LED daytime running- and back light                            • Shower tub made of wear-resistant GRP                         • Bathroom with towel rack and hook
  locking and window                                            • Fly screen door for entrance door                              • Shower grill (optionally orderable for models 77 E, 79 R)     • Roof-light with insect screen and pleated darkening blind
• Exterior, electrically operated double entrance step,         • Tie system in the garage including 4 adjustable eyelets        • Single-lever mixer tap for washbasin made of metal
  hidden behind a cover plate when closed                         in each rail
• Spacious rear garage with lighting, heatable                  • Entire roof safe to walk on
• Rear garage door, passenger side, with low loading height
                                                                                                                                 Heating and Water
                                                                                                                                 • Centralised, heatable water disposal compartment on           • Integrated warm-water heater for the supply of all
Living and Sleeping                                                                                                                driver side, discharge cocks for waste water / fresh water      consuming points
                                                                                                                                   tank with large diameter (1 1/4") for comfortable discharge   • Centralized boosted water supply over silent pump
•   Wall lining made of carpet                                  • Spacious overhead cupboards with push-to-open system           • Fresh and waste water tank in the heatable double floor,        including filter system
•   Wear-resistant floor covering in stone tiles look             (gas pressure buffers) for maximum comfort in use                from 120 to 200 l , depending on the model, 20 l in           • Space for 2 × 11 kg gas bottles and for Euro 14 l gas
•   One level floor between driver's cab and lounge             • Indirect accentuated lighting with LED-­technology for           driving mode                                                    bottles
•   High quality wear-resistant upholstery in 144 different       lounge area (can be dimmed), rear bed and front bed            • Screwable water connection for the pump and the filter        • Heatable double floor
    combinations (plus leather for an additional charge)        • Rear bed with lath frame and comfortable cold foam             • Air heating from Truma (Combi 6)                              • Mono control crash sensor for gas pressure regulator
•   Seat cushions with high comfort thanks to the 3-layer         mattress                                                       • Openings for cleaning on top for fresh and waste water
    foam concept                                                • Overhead front bed (1 910 × 1 320 mm) with lath frame,           tanks, accessible from the lounge area
•   Lounge table with multi-directional displacement              cold foam mattress and comfortable locking and unlocking
    mechanism, extendable tabletop depends on model               system
•   Block for 3-point-belt built in the lounge                  • Power LED reading spots at the front and rear bed as well
•   Shoe compartment in the entrance area                         as in the living room                                          Electronics
•   Convenient storage space in double floor, accessible from   • Bed access with night lighting
    the lounge area                                             • Foldable step with storage space function at bed access        • Central electric system in the garage, easy to access         • Automatic fault current circuit breaker
•   Solid handle covered with leather for easy entry            • Flexible reading lights at the rear bed, 2 spot lights and a   • AGM battery 95 Ah                                             • Centralised control panel with digital display
•   Gathered roller blinds on the windows of the seating unit     LED light-band under the front bed                             • Charging set 16 A with electronic control                     • 4 × 230 V sockets and 1 x 12 V socket and 2 x USB
    and sleeping area                                                                                                            • Battery control system with protection against overload         (depends on model)
                                                                                                                                   and complete discharge                                        • Lights (roof spots, spots under ceiling cup boards and
                                                                                                                                 • 230 V CEE connection on driver’s side                           reading spots) in LED-Technology

Kitchen
• Embedded three-flame gas cooker with a 2.4 kw burner          •   Central locking of the lower kitchen cabinets
  and electric ignition, divided glass cover, cast-iron pan     •   Kitchen drawers with pull-in mechanism
  supports and stationary mounted glass splashguard on          •   Wide drawer handles can also be used as tea towel holder
  the side panel                                                •   Mirror on wall next to kitchen
• Switch-off function for gas supply when closing the gas       •   Refrigerator 106 l, with freezer, AES automatic
  hob cover                                                     •   Waste bin in the lower kitchen cabinet
• Single-lever mixer tap made of metal

6     Standard Equipment Arto                                                                                                                                                                                                    Standard Equipment Arto    7
Arto The dynamic compact liner - NIESMANN+BISCHOFF
Technical Data
Arto The dynamic compact liner - NIESMANN+BISCHOFF
Arto 77 E *                           Arto 79 R

Base vehicle                                                                                                           Fiat Ducato, Euro VI E                Fiat Ducato, Euro VI E
Chassis / Frame                                                                                                        AL-KO low frame AMC 45H               AL-KO low frame AMC 45H
Engine                                                                                                                 Heavy Duty Homologation               Heavy Duty Homologation
Output in kW / HP                                                                                                      103/140 (opt.: 132/180)               103/140 (opt.: 132/180)

Maximum torque in Nm                                                                                                   350 (opt.: 450)                       350 (opt.: 450)

Type                                                                                                                   4-cylinder TD with VGT turbocharger   4-cylinder TD with VGT turbocharger
Engine displacement in cm3                                                                                             2,200                                 2,200
Chassis / Tyres
Wheel base in mm                                                                                                       4,350                                 4,000 + 800
Number of axles                                                                                                        2                                     3
Dimensions and weights (without accessories)
Overall length in mm                                                                                                   7,784                                 8,044
Overall width in mm                                                                                                    2,320                                 2,320
Overall height in mm                                                                                                   2,950                                 2,950
Technically permissible laden mass in kg                                                                               4,500 (opt. 4,800)                    5,000 (opt. 5,500)
Mass in running order in kg approx.    1) / 4)                                                                         3,670                                 3,870
Maximum payload in kg2)                                                                                                830 (opt. 1,130)                      1,130 (opt. 1,630)
Technically permissible towing weightbraked in kg       3) / 5) / 6)                                                   1,650                                 1,700
Seats
Seats fitted with 3-point safety belt4)                                                                                4 (3, 5)                              3 (4)
L-shaped sofa (length × width) in mm                                                                                   1,295 × 1,065                         1,315 × 760
Seat bench (length × width) in mm                                                                                      880 × 640                             880 × 640
Beds
Overhead front bed (length × width) in mm                                                                              1,910 × 1,320                         1,910 × 1,320
Rear bed (length × width) in mm                                                                                        2 × 1,960 × 860                       1,960 l 1,960 × 860 l 860 / 660
Filling quantities
Fuel tank in l                                                                                                         90                                    90
AdBlue tank in l                                                                                                       19                                    19
Water tank content in l in driving / camping mode                                                                      20 / 200                              20 / 200
Waste water tank in l                                                                                                  150                                   150
Gas supply in kg                                                                                                       2 × 11                                2 × 11
Dimensions of the garage
Maximum garage height in mm                                                                                            1,260                                 1,260
Maximum available surface (length × width) in mm                                                                       2,175 × 1,400                         2,175 × 1,400

Price in EUR, ex works, VAT not included                                                                               95,353                                100,143

* Also available in the “Face-to-Face” floor plan variant, see code V4044023 (p. 22) and floor plan overview (p. 4).                                                                           1), 2), 3), 4), 5), 6)
                                                                                                                                                                                                                        on page 30

10   Technical Data                                                                                                                                                                                 Technical Data              11
Arto The dynamic compact liner - NIESMANN+BISCHOFF
Arto 85 E *                                Arto 88 EK *                          Arto 88 LF *

Base vehicle                                                                Fiat Ducato, Euro VI E                     Fiat Ducato, Euro VI E                Fiat Ducato, Euro VI E
Chassis / Frame                                                             AL-KO low frame AMC 45H                    AL-KO low frame AMC 45H               AL-KO low frame AMC 45H
Engine                                                                      Heavy Duty Homologation                    Heavy Duty Homologation               Heavy Duty Homologation
Output in kW / HP                                                           103/140 (opt.: 132/180)                    103/140 (opt.: 132/180)               103/140 (opt.: 132/180)

Maximum torque in Nm                                                        350 (opt.: 450)                            350 (opt.: 450)                       350 (opt.: 450)

Type                                                                        4-cylinder TD with VGT turbocharger        4-cylinder TD with VGT turbocharger   4-cylinder TD with VGT turbocharger
Engine displacement in cm     3
                                                                            2,200                                      2,200                                 2,200
Chassis / Tyres
Wheel base in mm                                                            4,150 + 800                                4,500 + 800                           4,500 + 800
Number of axles                                                             3                                          3                                     3
Dimensions and weights (without accessories)
Overall length in mm                                                        8,427                                      8,763                                 8,763
Overall width in mm                                                         2,320                                      2,320                                 2,320
Overall height in mm                                                        2,950                                      2,950                                 2,950
Technically permissible laden mass in kg                                    5,000 (opt. 5,500)                         5,000 (opt. 5,500)                    5,000 (opt. 5,500)
Mass in running order in kg approx.1) / 4)                                  4,220                                      4,320                                 4,320
Maximum payload in kg2)                                                     780 (opt. 1,280)                           680 (opt. 1,180)                      680 (opt. 1,180)
Technically permissible towing weightbraked in kg  3) / 5) / 6)             1,700                                      1,700                                 1,700
Seats
Seats fitted with 3-point safety belt4)                                     4 (3, 5)                                   4 (3, 5)                              4 (3, 5)
L-shaped sofa (length × width) in mm                                        1,295 × 1,065                              1,295 × 1,065                         1,205 x 1,065
Seat bench (length × width) in mm                                           880 × 640                                  1,190 × 640                           880 x 640
Beds
Overhead front bed (length × width) in mm                                   1,910 × 1,320                              1,910 × 1,320                         1,910 × 1,320
Rear bed (length × width) in mm                                             2,000 I 2,000 × 860 I 860 / 670            2,000 I 2,000 × 860 I 860 / 670       1,900 × 1,500
Filling quantities
Fuel tank in l                                                              90                                         90                                    90
AdBlue tank in l                                                            19                                         19                                    19
Water tank content in l in driving / camping mode                           20 / 200                                   20 / 200                              20 / 200
Waste water tank in l                                                       150                                        150                                   150
Gas supply in kg                                                            2 × 11                                     2 × 11                                2 × 11
Dimensions of the garage
Maximum garage height in mm                                                 1,260                                      1,260                                 1,260
Maximum available surface (length × width) in mm                            2,175 × 1,475                              2,175 × 1,475                         2,175 × 1,400

Price in EUR, ex works, VAT not included                                    103,698                                    106,286                               106,345

* Also available in the “Face-to-Face” floor plan variant, see code V4044023 (p. 22) and floor plan overview (p. 4).                                                                           1), 2), 3), 4), 5), 6)
                                                                                                                                                                                                                        on page 30

12   Technical Data                                                                                                                                                                                 Technical Data             13
Arto The dynamic compact liner - NIESMANN+BISCHOFF
Equipment Packs   CP Comfort Pack [GB]
                  Code        Description                                                                                   Weight       Price EUR
                                                                                                                            in kg        VAT excl.

                  V8013090    CP – Comfort Pack                                                                                     42
                  V3012014    Skylight for living room                                                                                               664
                  V6014510    Darkening pleats driver / front passenger side window                                                                  580
                  V40310119   142 l Tec-Tower + 35 l freezer (door opens to both sides) incl. 25 l gas oven                                      1,420
                  V4034015    Froli bed system including cold foam mattress for front and rear beds                                                  824
                              Total individual prices                                                                                            3,487
                              Minus price advantage                                                                                             -1,815

                              PACKAGE PRICE                                                                                                      1,672

                  LP Liner Pack
                  Code        Description                                                                                   Weight       Price EUR
                                                                                                                            in kg        VAT excl.

                  V8017510    LP – Liner Pack                                                                                       27
                  V2013012    Exterior mirror with wide angle, electrically adjustable and heated,                                                   580
                              in the same colour as the model
                  V6031010    Aluminium insulation front roller blind electrically driven – can also be used as sun visor                            832
                  V2037710    Double-glazed window on driver and passenger side                                                                      824
                  V2082010    SKA comfort seats for driver and passenger, orientable and adjustable in height                                    1,252
                  V6000510    Micro fibre lining on ceiling instead of carpet lining                                                                 244
                  V3029114    Body windows with one-hand operation                                                                                   580
                              Total individual prices                                                                                            4,312
                              Minus price advantage                                                                                            –1,799

                              PACKAGE PRICE                                                                                                      2,513

                  DCP Driving Comfort Pack
                  Code        Description                                                                                   Weight       Price EUR
                                                                                                                            in kg        VAT excl.

                  V8040098    DCP – Driving Comfort Pack                                                                             1
                  V2096512    Digital cockpit                                                                                                        916
                  V2054512    Steering wheel / gear knob in leather                                                                                  286
                  V20610J     Steering wheel with radio controls                                                                                     219
                  V2117011    Wireless Phone Charger                                                                                                 345
                              Total individual prices                                                                                            1,765
                              Minus price advantage                                                                                              -353

                              PACKAGE PRICE                                                                                                      1,412

                                                                                                                               Equipment Packs         15
Arto The dynamic compact liner - NIESMANN+BISCHOFF
LEP Lithium Energy Pack                                                                                                                   MP1 Multimedia Pack without SAT system
Code          Description                                                                               Weight        Price EUR           Code             Description                                                                          Weight       Price EUR
                                                                                                        in kg         VAT excl.                                                                                                                 in kg        VAT excl.

V8016510      LEP – Lithium Energy Pack                                                                         56                        V8020026         MP1 – Multimedia Pack without SAT system                                                     24
V5012612      3 x 100 AH Lithium battery (instead of AGM battery) incl. charging booster,                                    7,303        V5073014         Radio pre-installation “Sound System” with 4 high-end two-way loud speakers,                                  1,126
              battery monitor and battery management panel                                                                                                 subwoofer, roof antenna
V5033811      100 A combi charger with 3,000 W inverter and battery management panel                                          3,286       V50400128 Navigator unit with 7" touch screen incl. radio with DAB+, Bluetooth and back-up                                 1,597
V5047024      220W solar system incl. MPPT solar regulator                                                                    1,840                 camera behind lily logo

              Total individual prices                                                                                       12,429        V5054513         LED TV 22" in media tower, incl. integrated DVB-S2 / DVB-T2 receiver, DVD slot and                             748
                                                                                                                                                           resonance loudspeaker
              Minus price advantage                                                                                          -4,185
                                                                                                                                                           Total individual prices                                                                                   3,471

              PACKAGE PRICE                                                                                                  8,244                         Minus price advantage                                                                                     -706

                                                                                                                                                           PACKAGE PRICE                                                                                             2,765

                                                                                                                                                           Possible upgrades, surcharge to the MP1:
MMP Multimedia Pack                                                                                                                       V50400129        Navigator unit with 9" touch screen instead of code V50400128                                0                580
                                                                                                                                          V5054514         Smart TV, 32", incl. triple tuner, Bluetooth 4.2 and DVD player,                             -1                757
Code          Description                                                                               Weight        Price EUR
                                                                                                                                                           in media tower instead of code V5054513
                                                                                                        in kg         VAT excl.

V8020012      MMP – Multimedia Pack                                                                             44
V5073014      Radio pre-installation “Sound System” with 4 high-end two-way loud speakers,                                        1,126
              subwoofer, roof antenna
V50400128 Navigator unit with 7" touch screen incl. radio with DAB+, Bluetooth and                                            1,597
          back-up camera behind lily logo
                                                                                                                                          GB Great Britain Line [GB]
V5054513      LED TV 22" in media tower, incl. integrated DVB-S2 / DVB-T2 receiver, DVD slot and                                   748    Code             Description                                                                          Weight       Price EUR
              resonance loudspeaker                                                                                                                                                                                                             in kg        VAT excl.

V50440116     SAT system Oyster Cytrac Vision (without receiver)                                                              3,353                        GB – Great Britain Line
              Total individual prices                                                                                        6,824                         See option’s list, total including pre-cabling for solar system                              59           2,910
              Minus price advantage                                                                                          -1,538

              PACKAGE PRICE                                                                                                  5,286

              Possible upgrades, surcharge to the MMP – Multimedia Pack:
V50400129     Navigator unit with 9" touch screen instead of code V50400128                                      0                580
V50440117     SAT system Oyster Cytrac Vision Twin (without receiver) instead of code V50440116                 0.5                421
V50440106     SAT system Oyster V Vision (without receiver) instead of code V50440116 or                        -4                 421
V50440109     SAT system Oyster V Twin Vision (without receiver) instead of code V50440116                  -3.5                   841
V5054514      Smart TV, 32", incl. triple tuner, Bluetooth 4.2 and DVD player, in media tower instead            -1                757
              of code V5054513

                                                                                                                                          [GB] Great Britain line

16   Equipment Packs                                                                                                                                                                                                                               Equipment Packs          17
Arto The dynamic compact liner - NIESMANN+BISCHOFF
Optional Features

                    Chassis
                    Code          Description                                                                       Weight        In      Price EUR
                                                                                                                    in kg         package VAT excl.
                    V20420A       Automatic gear box ZF AT9                                                                 30                    3,185
                    V2007111      Towing attachment (detachable)                                                            35                    1,420
                    V2009011      Dashboard decor in satine chrome                                                          0.5       GB              138
                    V201104800 Weight upgrade to 4,8 t, (only available for twin axle models in combination                  0                    1,424
                               with 180 HP) only in combination with code V2021033 alloy wheels with high
                                  load tyres. When choosing Goldschmitt air suspension, this position is
                                  without extra charge
                    V201105500 Weight upgrade to 5,5 t (only available for models with 3 axles in                            0                    1,235
                               combination with 180 HP)
                    V2096512      Digital cockpit                                                                            0       DCP              916
                    V2045510      Rear axle supports (manuel operability)                                                   10                        273
                    V2045511      Hydraulic steady legs (AL-KO HY4) with automatic levelling,                               70                    5,874
                                  incl. weighing function
                    V2082010      SKA comfort seats for driver and passenger, orientable and adjustable in height            0        LP          1,252
                    V2082012      Comfort seats with heating and lumbar support                                              2                        646
                                  (only in combination with code V2082010)
                    V2077116      LED front and fog lights                                                                   0                    1,455
                    V2021027      16" alloy wheels (4 pieces)**                                                             –5                    1,168
                    V2021033      16" alloy wheels (4 pieces) including high load tyres**                                   –5                    1,588
                    V2021027      16" alloy wheels (6 pieces) tag axle*                                                 –7.5                     1,840
                    V20610J       Steering wheel with radio controls                                                        0.5      DCP              219
                    V2054512      Steering wheel and shift knob in leather                                                   0       DCP              286
                    V2058022      Goldschmitt full air suspension incl. automatic levelling for twin axle**                 40                   6,967

                    V2021027 Alloy wheels           V20420A Automatic gear box ZF AT9                                 V2082010 Comfort Seats

                                                                                                                                  Optional Features    19
Cabin, Living Room
Code             Description                                                                         Weight        In      Price EUR     Code       Description                                                                     Weight        In      Price EUR
                                                                                                     in kg         package VAT excl.                                                                                                in kg         package VAT excl.
V2058022         Goldschmitt full air suspension for front and rear axle incl. automatic levelling           60                 8,302    V8011311   ClouLine Design (black painted radiator grille with chrome elements,                     2                    1,496
                 for 3 axle models*                                                                                                                 flat side windows for driver and passenger, chrome decoration around
V2058021         Goldschmitt rear air suspension incl. lifting and lowering device for twin axle**           30                  4,613              the front lights and on the back)

V2058021         Goldschmitt rear air suspension incl. lifting and lowering device                           30                 5,639
                                                                                                                                         V3003028   “Eifel grey” exterior colour, roof in white colour, only available                       3                   8,395
                 for 3 axle models*                                                                                                                 with Clouline Design, code V8011311

V100601425 2.2 l engine (180 HP)                                                                             16                 3,689
                                                                                                                                         V7004038   Exterior decoration Maxi “Rhodium silver” (decor foil on sidewall)                        1                  1,420

V2035116         16" spare wheel (steel) instead of Tire-Fit                                                 25                   378
                                                                                                                                         V7004037   Exterior decoration Maxi “Champagner Matt” (decor foil on sidewall)                       1                  1,420

V2035127         16" spare wheel as alloy wheel incl. high load tyre instead of Tire-Fit                     23                   558
                                                                                                                                         V7004035   Exterior decoration Maxi “Lava Orange” (decor foil on sidewall)                           1                  1,420
                 (only in combination with alloy wheels, code V2021033)                                                                  V7004036   Exterior decoration Maxi “Miami Blue” (decor foil on sidewall)                            1                  1,420
V2092510         Exterior sliding out storage case on driver side                                             6        GB         504    V7004039   Exterior decoration Maxi “Carbon Optik” (decor foil on sidewall)                        1.5                  1,504
V2092511         Exterior sliding out storage case on passenger side                                          6                   504    V7004119   Accent decoration “Green Elox”                                                          0.5                       587
                 (only available for models 88 EK)                                                                                                  (Design sticker on front and rearpanel, skirts and mirror covers)
V2090510         Wide track for front axle (30 mm each side)                                                  2                   327    V7004117   Accent decoration “Champagner Matt”                                                     0.5                       671
V20391J          Heated windscreen                                                                            0                   584               (Design sticker on front and rearpanel, skirts and mirror covers)

V2117011         Wireless Phone Charger                                                                      0.5      DCP         345
                                                                                                                                         V7004114   Accent decoration “Lava Orange”                                                         0.5                       671
                                                                                                                                                    (Design sticker on front and rearpanel, skirts and mirror covers)
CP Comfort Pack, DCP Driving Comfort Pack, LEP Lithium Energy Pack, LP Liner Pack, MMP Multimedia Pack,                                  V7004115   Accent decoration “Miami Blue”                                                          0.5                       671
MP1 Multimedia Pack without SAT system, GB Great Britain Line
                                                                                                                                                    (Design sticker on front and rearpanel, skirts and mirror covers)
* for models 79, 85, 88, ** for model 77
                                                                                                                                         V7004116   Accent decoration “Carbon Optik”                                                        0.5                       671
                                                                                                                                                    (Design sticker on front and rearpanel, skirts and mirror covers)
                                                                                                                                         V6031010   Aluminium insulation front roller blind electrically driven – can also be                15       LP              832
                                                                                                                                                    used as sun visor
                                                                                                                                         V4052016   Extendable table (standard from 79 models on)                                           14                        419
                                                                                                                                         V2013012   Exterior mirror with wide angle, electrically adjustable and heated, in the              2        LP              580
                                                                                                                                                    same colour as the model
                                                                                                                                         V3020510   Door for driver’s cabin (only available with ClouLine Design, code V8011311)            24                    1,931
                                                                                                                                         V2037710   Double-glazed window on driver and passenger side                                       10        LP              824
                                                                                                                                         V3009011   Fresh-air fan above kitchen                                                              5                        335
                                                                                                                                         V3010011   Fresh air fan in bathroom (only available in models 85, 88 EK / LF )                     5                        335
                                                                                                                                         V4034015   Froli bed system including cold foam mattress                                            0 CP / GB                824
                                                                                                                                         V4017510   Wall cupboards in front part, instead of folding bed                                    20                        458
                                                                     V4034015 Froli bed system                                           V4044023   “Face to Face” floor plan (straight kitchen and seat bench) reduction of belt           -5                         0
                                                                                                                                                    seats to 3, not available in model 79 R (see overview on page 4)
                                                                                                                                         V4062612   Additional belt seat in seat bench on passenger side including ISOFIX                   36                        824

V2092510 Exterior sliding out storage case on driver side            V3009011 Fresh-air fan above kitchen

20   Optional Features                                                                                                                                                                                                                            Optional Features    21
Code           Description                                                                      Weight      In      Price EUR       Code          Description                                                                            Weight       In      Price EUR
                                                                                                in kg       package VAT excl.                                                                                                            in kg        package VAT excl.
V100907004 Furniture decor Verade Oak, “Modern-Line”, Ceiling cupboards in matte                        0                       0   V40220E       Front bed with electrical function                                                              5                       898
               finish white                                                                                                         V3012014      Skylight for living room instead of standard skylight                                          19 CP / GB               664
V4018011       Ceiling cupboards in living room in high-gloss white instead of                          0                       0   V3011014      Panoramic skylight (Medi-Heki) above rear bed instead of standard roof-light                   12                       664
               matte finish white
                                                                                                                                    V30420J       Insulation mats for dashboard and floor around driver and passenger seats                       2                       416
V4018211       Ceiling cupboards in bedroom in high-gloss white instead of                              0                       0
                                                                                                                                                  (not in combination with code V3020510, door for drivers cabin)
               matte finish white
                                                                                                                                    V3052812      Awning, manually operated, incl. dimmable LED lights:
                                                                                                                                    V30522170     Length: 5.0 m (only available for model 77)                                                    50                   1,462
                                                                                                                                    V30522180     Length 5.5 m (only available for models 79 and longer)                                         55                   1,672
                                                                                                                                    V3052813      Awning with electrical function 230 V, incl. dimmable LED lights (without
                                                                                                                                                  inverter, code V5033811, operation only with external power possible):
                                                                                                                                    V30522170     Length 5 m (only possible for model 77)                                                        52                   1,962
                                                                                                                                    V30522180     Length 5.5 m (only possible for models 79)                                                     57                   2,172
                                                                                                                                    V30522190     Length 6 m (only for models 85 and 88)                                                         63                  2,370
                                                                                                                                    V5030010      230 V capsule coffee machine including lift mechanism from the ceiling                          2                       743
                                                                                                                                                  cupbard in the kitchen and storage compartment for coffee capsules
                                                                                                                                    V6000510      Micro fibre lining on ceiling instead of carpet lining                                         0        LP              244
                                                                                                                                    V4001510      Surface made of mineral material with built-in sink for kitchen and bath                       15                   1,160
                                                                                                                                                  instead of laminate
                                                                                                                                    V3029114      Body windows with one-hand operation                                                           0        LP              580
                                                                                                                                    V3031510      Lateral door for garage on driver side                                                          7                       739
                                                                                                                                    V3017512      Shale surface on TV furniture in “Black Star” look                                             0                        412

                                                                                                                                    Standard Equipment              V4018011 / V4018211               V3017512 Shale surface on TV
                                                                                                                                    Ceiling cupboards               Ceiling cupboards                           furniture “Black Star”
                                                                                                                                    matte finish white              high-gloss white

V100907004 Furniture decor Verade Oak, “Modern-Line”, Ceiling cupboards in matte finish white

22   Optional Features                                                                                                                                                                                                                                Optional Features    23
Gas, Water, Heating
Code            Description                                                                          Weight       In      Price EUR    Code            Description                                                                          Weight         In      Price EUR
                                                                                                     in kg        package VAT excl.                                                                                                         in kg          package VAT excl.
V4048016        Lowerable and extendible table with roll mattress to turn the couch into a bed                4                  828   V50100J         Shower in the garage                                                                            1                       248
V4012598        Storage space system in double floor                                                          1                  231   V40210J         Grill for shower base (only for models 77, 79, standard in models 85, 88)                     3                         179
V40310119       142 l Tec-Tower + 35 l freezer (door opens to both sides) incl. 25 l gas oven                22 CP / GB        1,420   V5003510        Hose for waste water disposal in storing tube                                                 2                         152
V602107001 Carpet (loose mats)                                                                               10       GB         671   V5053013        120 l fixed toilet tank with electrical function and ceramic toilet bowl                     20                     1,172
V6014510        Darkening pleats for driver and passenger side windows                                        1 CP / GB          580                   (only for models 85, 88 EK / LF)

V6001014        Front plissé (variable sight protection for the windscreen)                                   3                  529
                                                                                                                                       V50230J         Gas supply connection in side wall                                                              1                       164

V7006011        Fire extinguisher                                                                             3                  108
                                                                                                                                       V5027510        Towel dryer in the toilet room (only available in models 85, 88 EK / LF,                     10                         496
                                                                                                                                                       only in combination with warm water heating, code V5028014)
V60260J         Additional mattress with Froli bed system between single beds                                 5                  167
                                                                                                                                       V5028013        Heating system Truma with heating cartouche Combi 6 E                                        0                          566
CP Comfort Pack, DCP Driving Comfort Pack, LEP Lithium Energy Pack, LP Liner Pack, MMP Multimedia Pack,                                V5028014        Warm water heating with thermostat. control and heating cartridge                            20                     2,412
MP1 Multimedia Pack without SAT system, GB Great Britain Line
                                                                                                                                                       (Alde 3020) with touch screen control panel
                                                                                                                                       V5072013        Inet Box control for warm water heating and underfloor air conditioning                      0                          492
                                                                                                                                                       (Sim-Card required, not in price included)
                                                                                                                                       V5062010        Engine heat exchanger (uses the engine cooling water to heat the living area,                 6                         916
                                                                                                                                                       only in combination with warm water heating system, code V5028014)
                                                                                                                                       V5028210        Extended heating for warm water heating in the driver’s cab (original                         3                     1,336
                                                                                                                                                       Fiat ventilation connected with warm water heating, only in combination
                                                                                                                                                       with warm water heating and engine heat exchanger, operable over
                                                                                                                                                       separate touch screen panel)
                                                                                                                                       V3064012        SOG toilet ventilation                                                                          1                       248
                                                                                                                                       V5026013        Truma DuoControl CS gas flow control                                                            1                       239
                                                                                                                                       V50250J         2 gas filters for camping gas bottles (only in combination with Truma                           1                       171
                                                                                                                                                       ­ uoControl, code V5026013)
                                                                                                                                                       D

                                                                                                                                       CP Comfort Pack, DCP Driving Comfort Pack, LEP Lithium Energy Pack, LP Liner Pack, MMP Multimedia Pack,
                                                                                                                                       MP1 Multimedia Pack without SAT system, GB Great Britain Line

V4012598 Storage space system in double floor                        V4001510 Surface made of                                         V40210J Grill for shower base                                       V5027510 Towel dryer in the toilet room
                                                                               mineral material

24   Optional Features                                                                                                                                                                                                                                     Optional Features    25
Electric Installation, Radio, TV, SAT, Navigation
Code           Description                                                                        Weight       In      Price EUR       Code            Description                                                                          Weight         In      Price EUR
                                                                                                  in kg        package VAT excl.                                                                                                            in kg          package VAT excl.
V5005012       Alarm system (body and garage doors, control of the interior rooms                          3                  995      V20650J         Reverse driving alarm                                                                           1                       319
               can be switched off)                                                                                                    V50440116       SAT system Oyster Cytrac Vision (without receiver)                                            20      MMP          3,353
V3001410       Indirect lighting at the media tower (different colours, can be dimmed)                     2                  189      V50440117       SAT system Oyster Cytrac Vision Twin (without receiver)                                   20.5                     3,773
V3001612       “Green Grass” ambiance lighting in the living room door, can be dimmed                      5                  441      V50440106       SAT system Oyster V Vision (without receiver)                                                 16                   3,773
V3001812       “Green Grass” ambiance lighting in the rear bedroom                                         3                  353      V50440109       SAT system Oyster V Twin Vision (without receiver)                                           16.5                   4,193
V3001611       “Reed” ambiance lighting in the living room door, can be dimmed                             5                  441      V5047024        220W solar system incl. MPPT solar controller                                                 13       LEP         1,840
V3001811       “Reed” ambiance lighting in the rear bedroom                                                3                  353      V5047027        Extended solar system by 220W (only available in combination with solar                        8                   1,504
V5012612       3 x 100 AH Lithium batteries (instead of AGM batteries) incl. charging                     28      LEP       7,303                      system, code V5047024, 440W in total, not available for model 77 E)
               booster, battery monitor and battery management panel (only in combination                                              V5047026        Extended solar system by 110W (only available in combination with solar                        7                    1,252
               with 100A combi charger, code V5033811)                                                                                                 system, code V5047024, 330W in total, only available for model 77 E)
V5012511       Additional AGM battery for living room, 95 Ah (2 batteries in total)                       27                  293      V5050510        230 V plug in the garage                                                                     0.5                        206
V5012611       Additional AGM battery for living room, 95 Ah                                              27                  293      V5054513        LED TV 22" in media tower, incl. integrated DVB-S2 / DVB-T2 receiver,                          6     MMP /              748
               (only in combination with code V5012511, 3 batteries in total)                                                                          DVD slot and resonance loudspeaker                                                                    MP1
V5034012       Strengthened battery charger, 32 A                                                         8                   271      V5054514        Smart TV, 32", incl. triple tuner, Bluetooth 4.2 and DVD player,                               5                   1,504
V50270J        Narcotic gas alarm                                                                          1                  416                      in media tower
V50400128      Navigator unit with 7" touch screen incl. tuner, radio with DAB+, Bluetooth                8     MMP /        1,597     V5055098        LED TV 22", incl. integrated DVB-S2 / DVB-T2 receiver, DVD slot on                             6                        748
               and back-up camera behind lily logo (only in combination with radio                               MP1                                   bedroom wall (only available for models 77, 79, 85, 88 in combination with
               precabling, code V5073013 or V5073014)                                                                                                  Twin system, code V50440117 or V50440109)
V50400129      Navigator unit with 9" touch screen incl. tuner, radio with DAB+, Bluetooth                8                 2,265      V5033811        100 A combi charger with 3,000 W inverter and battery management panel                        14       LEP         3,286
               and back-up camera behind lily logo (only in combination with radio                                                                     (only in combination with AGM batteries, code V5012511 and V5012611,
               precabling, code V5073013 or V5073014)                                                                                                  or Lithium batteries, code V5012612)
V5073013       Radio pre-installation “Basic” consisting of 4 loud speakers and roof antenna               5                  579      V5033611        Underfloor Saphir Comfort RC air conditioning, 2,400 watt                                     33                   2,933
V5073014       Radio pre-installation “Sound System” with 4 high-end two-way loud                         10    MMP /        1,126     V3053810        Gooseneck light as second reading light above the front bed (not in                          0.5                         67
               speakers, subwoofer, roof antenna                                                                 MP1                                   combination with front cupboards, code V4017510)
V50400100      Radio with DAB+, CD and DVD slot (only in combination with                                  1                  496      V3071017        Central locking for body and garage doors                                                      2                        662
               code V5073013 or V5073014)
                                                                                                                                       CP Comfort Pack, DCP Driving Comfort Pack, LEP Lithium Energy Pack, LP Liner Pack, MMP Multimedia Pack,
                                                                                                                                       MP1 Multimedia Pack without SAT system, GB Great Britain Line

                                                                                                                                       V5054514 Smart TV, 32"

V50400129 Navigator unit with 9" touch screen                  V3001611 “ Reed” ambiance          V3001612 “Green Grass” ambiance   V5012612 Lithium batteries       V5047024 Solar system
                                                                         lighting in the living               lighting in the living
                                                                         room door                            room door

26   Optional Features                                                                                                                                                                                                                                     Optional Features    27
Upholstery                                                                                                                 Seat cushions               Incl. driver’s and passenger’s seats

Code            Description                                                                 Weight       Price EUR
                                                                                            in kg        VAT excl.

                Seat cushions including driver and passenger’s seats
V100707006      Grey (textile, grey)                                                                0                 0
V100707002      Shadow (textile, anthracite)                                                        0                 0    Grey textile, grey                    Shadow textile, anthracite

V100707003      Temptation (leather, beige)                                                         2            2,429
V100707004      Attraction (leather, anthracite)                                                    2            2,429
V100707008      Sensation (leather, brown)                                                          2            2,429
                Backrest cushions, style “Cloud”
V100807001      Grand Cru No. 1, including cushion 40 × 40 cm and 30 × 30 cm                        0                 0    Temptation leather, beige             Sensation leather, brown        Attraction leather, anthracite
V100807003      Grand Cru No. 3, including cushion 40 × 40 cm and 30 × 30 cm                        0                 0
V100807004      Grand Cru No. 4, including cushion 40 × 40 cm and 30 × 30 cm                        0                 0
V100807006      Grand Cru No. 6, including cushion 40 × 40 cm and 30 × 30 cm                        0                 0
V100807007      Grand Cru No. 7, including cushion 40 × 40 cm and 30 × 30 cm                        0                 0    Backrest cushions                  Incl. cushions 40 × 40 cm and 30 × 30 cm

V100807010      Grand Cru No. 10, including cushion 40 × 40 cm and 30 × 30 cm                       0                 0
V100807030      Grand Cru No. 14, including cushion 40 x 40 cm and 30 x 30 cm                       0                 0
V100807031      Grand Cru No. 15, including cushion 40 x 40 cm and 30 x 30 cm                       0                 0
V100807032      Grand Cru No. 16, including cushion 40 x 40 cm and 30 x 30 cm                       0                 0
V100807011      Beige leather including cushion 40 × 40 cm and 30 × 30 cm                           2                832
                                                                                                                                                                                                 Grand Cru No. 1                  Grand Cru No. 3
V100807012      Anthracite leather including cushion 40 × 40 cm and 30 × 30 cm                      2                832
V100807036      Brown leather including cushion 40 x 40 cm and 30 x 30 cm                           2                832
                Backrest cushions, style “Kiss”
V100807013      Grand Cru No. 1, including cushion 40 × 40 cm and 30 × 30 cm                        0                 0
V100807015      Grand Cru No. 3, including cushion 40 × 40 cm and 30 × 30 cm                        0                 0
                                                                                                                                                                                                 Grand Cru No. 4                  Grand Cru No. 6
V100807016      Grand Cru No. 4, including cushion 40 × 40 cm and 30 × 30 cm                        0                 0
V100807018      Grand Cru No. 6, including cushion 40 × 40 cm and 30 × 30 cm                        0                 0
V100807019      Grand Cru No. 7, including cushion 40 × 40 cm and 30 × 30 cm                        0                 0
V100807022      Grand Cru No. 10, including cushion 40 × 40 cm and 30 × 30 cm                       0                 0
V100807033      Grand Cru No. 14, including cushion 40 x 40 cm and 30 x 30 cm                       0                 0
V100807034      Grand Cru No. 15, including cushion 40 x 40 cm and 30 x 30 cm                       0                 0    Backrest cushions Style “Kiss”                                        Grand Cru No. 7                  Grand Cru No. 10
V100807035      Grand Cru No. 16, including cushion 40 x 40 cm and 30 x 30 cm                       0                 0
V100807026      Beige leather including cushion 40 × 40 cm and 30 × 30 cm                           2                832
V100807027      Anthracite leather including cushion 40 × 40 cm and 30 × 30 cm                      2                832
V100807037      Brown leather including cushion 40 x 40 cm abd 30 x 30 cm                           2                832
V6025210        Back covers for driver and passenger seats with practical storage pockets            1               251                                                                         Grand Cru No. 14                 Grand Cru No. 15
                (not available with leather backrest cushions)

                                                                                                                                                                                                 Grand Cru No. 16                 Leather beige

                                                                                                                           Backrest cushions Style “Cloud”                                       Leather brown                    Leather anthracite

28   Optional Features                                                                                                                                                                                                                    Optional Features   29
Important Information                                                                                                                   Imprint

Technical data Arto
1)    he “mass in running order” according to EU directive
     T                                                              5)    he indication regarding the technically permissible
                                                                         T                                                              Publisher                         Your dealer:
     ­accepted in VO (EU) no. 1230 / 2012 includes: the empty            ­towing weight braked represents a maximum value, which        Niesmann+Bischoff GmbH
       mass with standard equipment, driver (75 kg), filling              depends on the real vehicle mass incl. persons and            Clou-Strasse 1 | D-56751 Polch
      quantities for fuel (90 %), fresh water in driving mode             ­loading. The technically permissable maximum towable         T +49 2654 933-0
      (20 l.), 100 % filled gas bottle, tool kit, Tire-fit and             mass shall not be in any case exceeded.                      F +49 2654 933-100
      ­connecting cables. Differences as part of the manufacturer                                                                       M info@niesmann-bischoff.com
     tolerance are possible and allowed.                            6)    eight upgrade does not raise the total towing weight. All
                                                                         W                                                              W niesmann-bischoff.com
                                                                         information concerning the total towing weight is valid for
2)    he payload is the difference between the technically
     T                                                                   a maximum incline of 12 % at an uphill start.                  Concept + Design
     permissible laden mass and the total effective vehicle                                                                             3st kommunikation GmbH, Mainz
     mass. Weights of the optional equipment have to be added
     to the “Mass in running order”.                                 Due to the different materials, manufacturing procedures           Photography
                                                                    and light conditions, colour deviations can occur on                mooi Studios, Mendig
3)    he permissible total towing weight must not exceed
     T                                                              ­body­work and attachment parts. Colour deviations do               BUTTER. GmbH, Düsseldorf
     6,000 kg.                                                      not ­authorise complaints or warranty claims. All the
                                                                    dimensions and weights are rounded figures and can vary             Tech. Presentation + Renderings
4)    urther persons are allowed to ride along as far as the
     F                                                              according to the different homologation directives!                 Studio SYN, Rüsselsheim
     technically permissible laden mass is not exceeded and
     respective seats with safety belts are present.
                                                                                                                                        Last updated: 20.12.2021

Important information
This brochure is subject to change without notice. After the        and are valid for all purchase and licensing in the Federal
copy deadline of this price list (12/2021) changes as to            ­Republic of Germany. Deviations of the values within a range                                         Design diversity
models and products, floor plans, technical data, equipments,        of ± 5 % are ­possible. The measures of the mattress may
etc. may have ­occurred. The illustrations also ­contain optional    slightly vary from the given bed measures. E. g. data on the                                         Personality comes from within. The same applies
 features, and / or ­accessories which are not included in the       capacity of the refrigerators refer to producer information.                                         to your Arto. How would you like yours to look?
­standard equipment and decoration respectively which is not         Prices for optional features are only valid when installed dur-                                      Would you prefer classic-chic or something a bit
 included in Niesmann+Bischoff’s range of supply. Descriptions       ing production. In case of subsequent ­installation additional                                       bolder? No matter what decision you make, you
 may have been garbled due to graphic conversion, photo-             ­installation and servicing expenditures are accrued at cost.                                        will always feel right at home, as the fabrics and
 graphic processing or technical reasons. All data on range of        We reserve the right to change ­prices, construction and                                            materials are all of high quality.
 supply, appearance, performance, weights and measures,               equipment without notice. With the issue of this b­ rochure all
 as well as fuel consumption of the vehicles are in compliance        previously issued information and price lists become void.                                          Build your very own Arto now at:
 with the knowledge existing at the time of the copy deadline
                                                                                                                                                                          https://konfigurator.niesmann-bischoff.com/

30      Important Information                                                                                                                                                                                        Imprint   31
www.niesmann-bischoff.com
You can also read
