2021 Alarming Conditions of Today's Instrumentation and PLC-based Control Systems in the Oil & Gas and Petrochemical Industries
BRIDGING THE GAP

2021 Alarming Conditions
of Today’s Instrumentation
and PLC-based Control
Systems in the Oil & Gas and
Petrochemical Industries

    Is there a roadmap to embracing the Industrial
    Internet of Things (IIoT)?

                   Is thBased on a 2021 Survey of Major Petrochemical
                                        and Oil & Gas Industry Players
2021 Alarming Conditions of Today's Instrumentation and PLC-based Control Systems in the Oil & Gas and Petrochemical Industries
Executive Summary
In the wake of the pandemic, and volatile pricing on oil and other commodities, many
issues have come to light about the state of Instrumentation and Controls and its impact
on the Oil & Gas and Petrochemical Industries.

In partnership with M S Benbow, Control Engineering recently released its survey as to the
critical and potentially catastrophic conditions of the Instrumentation and Control Systems
of the Upstream, Midstream and Downstream Oil & Gas and Petrochemical landscape.

The report provides insight into the changing and potentially alarming conditions within
the Upstream, Midstream and Downstream Oil & Gas as well as petrochemical landscape
of Instrumentation and PLC-based Control Systems. Questions and topics ranged from
systems challenges to FEED (front-end-engineering and design) and average downtime
due to failures, to status on making current the industrial internet of things (or IIoT).

The long-term success of any company’s Instrumentation and PLC-based Control Systems
strategy includes the adherence to a health, safety and environmental (HSE) policy that
is compliant with standards and applicable laws and regulations where any company
operates. This remains a contributing factor to averting catastrophes, avoiding the pitfalls
of significant penalties and a loss of production profits.

    “This survey is timely and essential.”
    — Leo Holzenthal, Jr., P.E., President M S Benbow

Key takeaways of the Instrumental and Control Systems
Report include:

• Close to half or upwards of 60% of respondents from the chemical manufacturing
 and oil & gas industries respectively expressed concerns about the growing technical
 obsolescence of their current systems. This means the potentiality of catastrophic
 system failure, safety concerns, cybersecurity risks, and financial impact. For facility
 operators and engineers at a petrochemical plant, this could mean, equipment failure,
 uncontrolled release of hazardous chemicals into the environment, and potential
 loss of life.

                                                                                 BRIDGING THE GAP   2
More than 70% of survey respondents from chemical manufacturing industries expressed
 concerns about control software no longer being supported and 47% expressed similar
 concerns about PLCs and HMIs.

• 51% of respondents had 2 to more than 10 unplanned outages in the past 6 months due
 to instrumentation and control system failures. Two thirds of respondents had at least
 1 unplanned outage. In addition to the potential, uncontrolled release of hazardous
 chemicals, it can mean the loss of data measurements that operators and engineers
 need to ensure machinery and processes are operating efficiently. The cost per outage
 can be extremely high, sometimes running more than several million dollars depending
 upon the length of the outage and the related impact to production.

Overview
We all have our own individual relationships to technology. Our personal computers,
our televisions, our cars, our smartphones, the IoT in our homes. The pace of change
keeps accelerating. Our tools quickly become obsolete and require replacement. We
understand, all too well, the costs and losses involved to stay functional — money, time,
and opportunity.

Thankfully the damage caused by our personal technological hiccups is limited in scope.

Stop to consider the impacts of such technological disconnect and turnover on an
industrial scale at our physical facilities and commercial workings.

Many of our most vital systems, facilities and natural resources in the United States are
guided by an aging and crumbling infrastructure composed of similarly vulnerable and
incoherent integrations of digital technology, machinery and controls.

Consider this. You serve as an instrumentation and controls engineer at an oil refinery.
The refinery relies on 22.5 million gallons of water flowing through its system daily. Now
imagine that a system goes down on a microprocessor based control device critical to
the refinery’s ability to enable that water flow function to operate. Because of aging
technology, a lack of the required skilled labor, and outdated documentation on the
microprocessor and complementary control systems, the refinery stops — unable to turn
crude oil into petroleum products. And, it relies on fixing it by replacing one part.

And, that one part is only available by having you, the facility manager, search on eBay™
for a spare.

                                                                                BRIDGING THE GAP   3
The supply chain is arrested. Products used for
    everyday life disappear.

Imagine the vast cost of the continual integrations, patches, and system stoppages that
touch so many facilities and industries. The challenges of ever more complex system
maintenance grow exponentially.

Just as one maintains their home under budgetary constraints, so goes industry.
Companies that may need to prepare for remote environments weigh costs and benefits
and increase unstable or unsafe conditions as systems grow in complexity. These tradeoffs
are in part due to human-machine interfaces (HMIs) where newer operators may not
have a full understanding of complex legacy systems. In turn, the operators and decision-
makers may postpone necessary capital expenditures because those operators sometimes
do not know how to assess risk.

Facilities continue to hesitate to upgrade given the need to have experienced
professionals “reverse engineer” obsolete systems prior to designing their replacements,
as the legacy obsolete systems are rarely well documented. The hesitation then results in
a further gap in the ability to upgrade and correct the future potentiality of failure.

The impact on the oil & gas industry is clear — the problems at plants and facilities will
only get more expensive and harder to fix. Only by looking clear-eyed at the state of play
and planning for the needed upgrades will disaster be deterred.

                                                                                 BRIDGING THE GAP   4
Critical Findings
      1. No Clear Path Forward To Resolve Timely and Pressing Issues
      Some Systems Patched Together With Parts Companies Can Only Find on eBay™
      When asked the top two concerns related to Instrumentation Control and Systems, at
      least 40% of respondents cited the lack of skilled resources and technical obsolescence
      and more than 25% cited no clear upgrade plans, no budget and a lack of standardization.
      While the oil & gas industry’s in-house instrumentation and control professionals are
      most concerned about staffing and obsolete technologies, they sorely need a budget,
      a sound ability to measure system interactions and a way to standardize their current
      patchwork of systems and controls.

                   This survey reveals mounting concerns for
                   instrumentation and control systems in the Oil &
                   Gas and Petrochemical industries

     What are your top 2 concerns related to your current instrumentation and controls
     system configuration?

          60

          50

          40
Percent

          30

          20

          10

          0

                   Lack of skilled      Technical     No clear upgrade     No budget       Lack of          Lack of       Connectivity            Other
                     resources        obsolescence          plans                         reliability   standardization     issues           (please specify)

               This report compares data from the Oil & Gas industry segments –
               Upstream         Midstream     Downstream        Chemical Manufacturing segment

                                                                                                                                         BRIDGING THE GAP       5
2. Falling Further Behind Today’s IT Technology
     With Many Skilled Resources Laid off or Furloughed During the Pandemic,
     Indicators Show a Rising Knowledge Gap With a Lack of Basic Blueprints
     Over 40% of respondents lack critical elements to help remedy the complex problems of
     the current state of Instrumentation and Control systems. This includes the lack of a basis
     blueprint for existing software and systems, component parts and software that are no
     longer supported by the manufacturer, and obsolete systems that fall far behind today’s
     technologies available to the market.

     Which of the following is a challenge to your control engineers and technicians?

          80

          60
Percent

          40

          20

          0

                  Lack of accurate      Parts or          Systems are        High frequency     Control system        Lack real-time         Lack of       Cyber risk        Other
                    blueprint of       software          obsolete given      of breakdowns    struggles to deliver     visibility into   standardization                (please specify)
                  current systems      no longer       today’s IT-driven        or system      required product      processes due to    with respect to
                   and software      supported by          advanced              failures        characteristics     lack of machine      PLCs, Control
                       used              OEM            control systems                                               and equipment         Software,
                                      or supplier                                                                      connectivity         and HMIs

               This report compares data from the Oil & Gas industry segments –
               Upstream          Midstream          Downstream             Chemical Manufacturing segment

                                                                                                                                                                  BRIDGING THE GAP         6
3. Unplanned Systems Outages and Potential Cybersecurity Risks
     Present Future Challenges
     The Cost of System Outages and Cybersecurity Risk Can Be Devastating Especially
     In Critical Infrastructure
     Systems migrations, upgrades and maintenance are planned far in advance, especially as
     it relates to those that operate 24/7 consecutively. However, 51% of respondents had 2
     to more than 10 unplanned outages in the past 6 months due to instrumentation and
     control system failures. Two thirds of respondents had at least 1 unplanned outage, with
     20% being longer than 12 hours. The financial cost combined with potential physical
     safety and cybersecurity risks requires a cost-benefit analysis for future risk.

     To the best of your knowledge, approximately how many unplanned unit outages
     have occurred at your facility in the past 6 months that were caused by
     instrumentation and controls system failures?

          60

          50

          40

          30
Percent

          20

          10

          0
                           None                            1                        2 to 5       6 to 10     More than 10

               This report compares data from the Oil & Gas industry segments –
               Upstream       Midstream       Downstream        Chemical Manufacturing segment

                                                                                                           BRIDGING THE GAP   7
4. With an Eye Toward the Future – How can we build a Roadmap
     to Embracing the Industrial Internet of Things (IIoT)
     Are we ready for widespread migration and upgrades in the United States?

     The benefits of IIoT related to instrumentation and controls are well documented in
     helping to enhance productivity. Manufacturers and end-users can gain greater insights
     into machinery health and help prevent the potential for outages due to system failures or
     obsolescence. Further, data analytics help guide instrumentation and controls engineers
     to increasing productivity and maximizing efficiency.

     How ready are Oil & Gas Upstream, Midstream, and Downstream providers to embrace
     the future? More than 45% of respondents do not have the in-house resources to plan
     and execute a smooth migration to safe and modern systems and technologies. Further,
     more than half of respondents reported at least four or more different brands of industrial
     controllers in use at their facilities. It is extremely important to note that this can be
     difficult to find replacements, and ensure smooth future integrations.

     With more than half of respondents (55%) either confident or very confident that their
     existing suppliers/integrators had the automation efforts needed to carry them into the
     future, budget and planning will be tantamount to helping optimize operations through
     automation to ensuring compliance with cybersecurity and safety standards.

     How confident are you that the IIoT technology integrators (or suppliers) bringing
     new solutions into your facility have the viability to support your automation efforts
     over the long haul?

          80

          70

          60

          50
Percent

          40

          30

          20

          10

          0
                             Very confident                        Confident                     Not too confident   Not at all confident

               This report compares data from the Oil & Gas industry segments –
               Upstream       Midstream       Downstream        Chemical Manufacturing segment

                                                                                                                        BRIDGING THE GAP    8
5. Obsolescence of Control Systems Components
     Even More Widespread at Facilities Than Anticipated – Pose Major Safety Risks
     and Reveals Vulnerabilities

     Plant and facility personnel know that “rip and replace” is not the solution in addressing
     the obsolescence of existing equipment for a multitude of reasons ranging from cost,
     to planned outages. However, mitigation recommendations that align around lifecycle
     statuses and the availability of parts and services are critical.

     For 2021, the survey has revealed that from Programmable Logic Controllers (PLCs)
     to Control Software to Human-Machine Interfaces (HMIs), close to 65%, on average, of
     facilities have obsolete control systems components and software.

     If applicable, which of the following control system components have you identified
     as obsolete at your facility?

          80

          60
Percent

          40

          20

          0
                   Programmable logic controllers         Control software          Human machine interfaces   Don’t know     Not applicable
                             (PLCs)                                                        (HMIs)

               This report compares data from the Oil & Gas industry segments –
               Upstream         Midstream           Downstream         Chemical Manufacturing segment

                                                                                                                            BRIDGING THE GAP   9
Action Items
The survey findings have revealed the vulnerabilities of critical infrastructure in the United
States in 2021. Facility Managers, Operators and Plant Engineers are in dire need of a
clear path forward. Based on the data results of the survey, combined with M S Benbow’s
distinct expertise in site audits, feasibility studies, and front end engineering design, it is
clear that in order to avoid an ominous and potentially dangerous future for the oil & gas
and petrochemical industries, it is necessary for all plants to ensure:

    1. Skilled Human Resources – to plan and implement solutions. In large waves,
    personnel who have operated the instrumentation and controls at plants for years
    have retired. The pandemic has led to widespread layoffs at plants — of skilled
    and knowledgeable employees who can operate, maintain and analyze data of
    Instrumentation and Control Systems.

    Survey respondents see a widening gap in the talent pool of the future in terms
    of being able to avert cybersecurity and safety risks and manage technical
    obsolescence. Oil & Gas and Petrochemical Companies must put plans into place to
    train resources and seek outside help to manage the future of their systems for the
    forthcoming decades. Plants must find the talent pools for the next generations.

    2. Clear Upgrade Plans – Crises cannot be averted without a clear path forward
    that takes into account the latest technology, standardization, personnel training,
    cybersecurity risks, and a myriad of issues that an upgrade presents.

    For Oil & Gas and Petrochemical Companies to move forward, internal measures must
    be taken to document clear, upgrade plans. External resources can be utilized to help
    develop migration paths for the future. The survey results clearly showed gaps in
    existing system definition and other documentation to help guide those who may
    be in timely and sensitive situations to avoid disaster.

    3. Leadership & Support – A C-suite that recognizes the seriousness of this problem
    and budgets for a solution. The survey results show that information is not always
    communicated from the C-suite to plant operators, managers and engineers. The
    pandemic has clearly shown us alternate ways to convey messaging to all employees,
    especially around awareness of complex, difficult, and evolving ideas and information.
    The benefits of open, healthy communication and support of employees clearly lead
    to dynamic and motivated employees helping focus resources on achieving optimal
    outcomes. In the case of a plant, this means committed employees working to help
    optimize success.

                                                                                   BRIDGING THE GAP   10
Conclusion
The 2021 Instrumentation and Controls survey results are staggering. The vulnerabilities
in the United States’ most critical systems, facilities and natural resources have been
exposed, in part, by these results.

The key concerns exposed by this survey are well placed. A significant number of critical
control systems in use today are on the verge of obsolescence, or are already obsolete.
Additionally, those who are familiar with troubleshooting and maintaining these legacy
systems are retiring and no longer able to provide support. In order to address the many
issues associated with these obsolete systems, it is imperative to first identify, via field
audit, the offending systems, put together a standardization/replacement strategy, and
develop a migration path that takes into account available downtimes (i.e. scheduled
turnarounds) for system replacement and how best to take advantage of the new
features/functionality of today’s systems, including connectivity via IIoT.

A complete assessment of any instrumentation and control system, its intent, and
development of a comprehensive plan to meet the operational and reliability needs now
and in the future is a clear step forward.

Survey Methodology
Respondents in critical roles in the Oil & Gas and Petrochemical Industries provided
responses related to questions related to internal Instrumentation and Control Systems.

                                                                                  BRIDGING THE GAP   11
About M S Benbow

Keeping you on-line. Moving you ahead.
We keep you on-line with pragmatic responses to your most urgent challenges. When
your operations are halted or otherwise compromised due to faulty instrumentation
and control systems infrastructure, every single minute counts — in lost dollars and
disappointed customers. Your team at M S Benbow understands the need for speedy, but
smart responses to such disruptions. We are expert troubleshooters who identify both
direct and indirect causes, propose pragmatic solutions, and rapidly assemble the right
equipment, software and expertise to get your operation going again. What’s more, in an
era when experienced instrumentation professionals are hard to come by, our team brings
instant expertise and insight to bypass a costly learning curve.

We sustain your momentum by delivering savvy, product-neutral solutions. Many facility
managers and engineers struggle with a dual challenge: investing in instrumentation
and control systems infrastructure upgrades to enhance performance while also dealing
with a cluster of failing, obsolete or underperforming equipment. Our team of engineers
and instrument and control system specialists helps you emphasize the forward-leaning
aspects of your business plan by selecting the best products and solutions available —
without the bias often seen from manufacturers’ service reps. Our loyalty and focus always
remain on you.

We move you ahead by applying disciplined, dependable approaches that anticipate
the future. When you are ready to plan for and invest in comprehensive upgrades of your
instrumentation and controls systems infrastructure M S Benbow provides a rigorous,
proven design process to achieve success. Our team members act as an extension of your
team — as true partners — to move you from conception, to design, to installation, testing
and implementation. You will appreciate our team’s commitment to make your “ideal
world” come closer to reality by positioning you to succeed.

For more information, contact www.msbenbow.com

Dallas | Houston | Mandeville | New Orleans                                   BRIDGING THE GAP   12
You can also read
