The N610i digital label press
High print quality at flexo speeds

Combines the productivity of
flexo with the flexibility of digital

                                        Scan the code to find more
                                           about Domino N610i
The N610i digital label press - High print quality at flexo speeds - Combines the productivity of flexo with the flexibility of digital - Domino ...
The smarter way to print labels
                                                    Applications
For label printers, the Domino N610i, with up
                                                    The N610i uses
to seven colours including opaque white, 600dpi
                                                    vibrant UV curable inks
‘native’ print resolution and operating speeds up   designed for a range of
to 75m/min (246ft/min), is the only label press     industry standard self-adhesive
that combines the productivity of flexo printing    label stocks including coated paper,
with the flexibility offered by rapid job change    polypropylene and polyethylene.
digital technology.                                 Applications include industrial, personal care,
                                                    security, health and safety, automotive, chemical,
This means an investment that provides              pharmaceutical, food* and beverage*.
added potential for greater sales growth
and increased profitability, whilst reducing        Textures by Domino
production cost and complexity.                     Increased shelf edge appeal is achieved due to the
                                                    highly reflective nature of the print. Unique digital
                                                    textured effects can open up new applications for
                                                    Domino N610i press owners.
                                                    Unique textured labeling is achievable up to
                                                    50m/min (164ft/min) using the Domino N610i.
                                                    This feature enables standard coated paper, PP and PE
                                                    materials to be turned into textured materials.
                                                                        *Subject to an effective migration barrier being in place.
The N610i digital label press - High print quality at flexo speeds - Combines the productivity of flexo with the flexibility of digital - Domino ...
The highest digital productivity
Production capacity                    Printing at speed                        In-line finishing
                                                                                                                            Customer Quote
With a 1m (40”) diameter roll          The high quality mode can print          Does your job structure suit
unwind capable of handling up to       >90% of Pantone colours plus high        online/offline finishing?                   “Scrap and labor savings, since
340mm (13.4”) wide media and           opacity white at 50m/min (164ft/         The N610i has been designed                 moving this job to the Domino,
the widest print width (333mm          min). In rapid mode, the N610i           to work as a standalone reel-               is huge. With the Domino we
or 13.11”) of any Kyocera based        prints up to 75m/min (246ft/min).        to-reel press or has the option             can run in ONE HOUR what
label press; the N610i can process                                              to be interfaced with industry              we used to run in an entire
up to 3000 linear metres                                                        leading digital finishing solutions         shift on flexo. We have only
(9842 linear feet) or 1000m2                                                    including those from A B Graphic            been running it for one month
(10760 ft2) of material per hour                                                International, GrafiskMaskinfabrik,         and we have already seen an
in high quality mode.                                                           CEI and Delta Industries.                   increase in sales because of the
                                                                                                                            Domino N610i.”
                                                                                                                            Dave Ferguson,
                                                                                                                            President, McCourt Label, US

The N610i Integration Module                                                            Customer Quote
                                                                                        “If we compare the productivity between
The N610i Integration Module can be supplied as part of a fully integrated              traditional presses and the Domino that
hybrid press working with partners such as A B Graphic International,                   we have, printing the jobs is incomparable.”
Converting Equipment International (CEI), Delta Industrial, Gonderflex and MPS.
                                                                                        Christophe Quirantes,
This can include flexo stations before and after the N610i module as well as            Commercial Director, QRT Graphique, France
screen and foiling stations. This meets a wider range of product design needs
but still provides digital quick change for multiple SKUs.

     Greener                           consumption of natural resources         a flexo press, it uses less energy        our natural resources. Although UV
                                       and energy and the creation of waste.    resulting in reduced costs.               curable inks are chemicals and need to
     credentials                       Our products are RoHS and WEEE           It creates very little media waste –      be used correctly, they offer significant
Domino’s commitment and                compliant so that they are recyclable.   this can be less than 1m (40”) per job    environmental benefits compared
investment in sound environmental                                               and the capability to ‘print-on-demand’   to solvent alternatives. Solvent inks
practices means we frequently          N610i                                    results in less over-printing and         include up to 95% volatile solvents that
exceed the increasingly demanding      The N610i requires no plates, no         reduced storage requirements.             evaporate into the environment and
governmental, industry and company     plate making process or associated                                                 require regular print head cleaning.
standards and regulations. We                                                   The N610i is supplied with UV curable
                                       materials for washdown purposes
                                                                                inks representing an efficient use of     N610i UV curable inks contain 1%
are committed to minimising the        and with fewer curing lamps than                                                   volatile solvents.
The N610i digital label press - High print quality at flexo speeds - Combines the productivity of flexo with the flexibility of digital - Domino ...
The most consistent print results
It’s just so simple                      Jets that keep jetting                                                      Automated maintenance
Ink jet technology is non-contact,       Domino’s quality controlled                                                 The revolutionary i-Tech
with few moving parts, no printing       UV inks are constantly circulated                                           CleanCap automated print head
plates, no drums, no blankets            around the print head by the                                                cleaning and capping technology is
and no complex maintenance               innovative i-Tech ActiFlow                                                  a consistently controlled process
programmes. The time to change           ink circulation system, even when                                           which reduces manual operator
from printing one job to another         printing has stopped. ActiFlow                                              intervention meaning that daily
is instantaneous with limited            degasses the ink, preventing air                                            manual head wiping is now a
media waste.                             bubbles forming, which can impact                                           thing of the past!
                                         nozzle performance.

The best ink jet print quality
It’s not just about resolution                                                  Our colour range
Even though Domino uses high resolution print heads from Kyocera at             In today’s fast evolving retail
600dpi, delivering more dots per inch than most competitive systems, this       marketplace, the importance
alone does not deliver the best ink jet quality. To achieve this, print head    of colour in product packaging
integration, precise web transport, robust components ie Corona and UV,         cannot be over-emphasised.
workflow and quality inks are all essential to ensure the best print results.   The N610i provides brand             Do you print white?
                                                                                owners and designers the scope       Screen printing technology is the
                                                                                to create designs with a far wider   industry standard for printing
  Customer Quote                                                                colour gamut cost effectively.       tactile, high opacity white, but this
  “It is the quality of the print, the cooperation with the people              Our seven colour press can           is at a cost. Domino’s white ink
  and the service that we receive from our partner, as that is                  achieve in excess of 90% of the      delivers a silk-screen like tactile
  how we see Domino. We are capable of entering                                 Pantone® colour range without        finish and has the highest opacity
  markets for which I’m 100% convinced we would                                 the need to make plates or the       in the market at over 70% when
  not have reached if we would not have bought                                  complexity of mixing spot colours.   printed up to 50m/min (164ft/min),
  the Domino N610i.”                                                                                                 providing an efficient, cost-effective
  Raf Joos, CEO, ASQ Labels, Belgium                                                                                 alternative to screen printing.
The N610i digital label press - High print quality at flexo speeds - Combines the productivity of flexo with the flexibility of digital - Domino ...
Take a closer look inside the N610i
– not all digital label presses are the same
intelligent Technology
i-Tech components combine to create a system altogether more flexible and reliable.

1. Domino Ink Jetting                2. Ink Jet Engine                    4. i-Tech ActiFlow                   5. i-Tech StitchLink
Assemblies                           The N610i is configured in           The ink circulation system keeps     Micro-motor controller
Proprietary Domino ink               either a 4, 5, 6 or 7 colour         the ink continuously moving          technology ensures that all
jetting assemblies incorporate       print combination printing           around the print head, maintaining   heads are positioned precisely,
Kyocera print heads that deliver     333mm (13.11”)                       a constant temperature and           calibrated to print as one,
consistent print results and                                              removing micro air bubbles,          enabling seamless print across
                                                                          ensuring consistent print quality    the full web width
higher reliability than any other    3. i-Tech CleanCap
press using similar technology                                            and reliability
                                     Automated print head cleaning
                                     and capping station ensures
                                     the highest print quality and
                                     productivity – all heads are
                                     cleaned within one minute!
                                                                                                                                      6
                                    Kyocera

                     Domino
                                                                                                           1
                                                                                           3       4
                                                                                                                               13
                                                                                                               7
                                                                                   5
                                                                                                   2

                                                                                               7

                                                                                                                   9
                                                                                                       8

                                                                           10
                           14

                                                                                       9
                                                                             11
                                                                     12                                        Esko Workflow
                                                                                                               The industry standard Esko
                                              13
                                                                                                               RIP and colour management.
                                                                                                               This includes a simple to use
                                                                                                               spot colour matching feature,
                                                                                                               accurately matches your
6. Ink Cabinet                       10. Web Guide                        13. Unwind & Rewind                  customers’ colours job after job.

7. UV LED Pinning for
                                     FMS                                  Rolls up to 1000mm (40”)             Variable Data Printing
                                                                          diameter supported.
   CMYKOV and White                  11. Corona                           Web width between                    With the increase in product
                                                                          200 - 340mm (7.9” - 13.4”)           personalisation, Domino’s full
8. UV Curing                         Vetaphone                                                                 colour variable data workflow
                                                                          14. Temperature 		                   using Esko not only allows
   GEW                               12. Web Cleaner                          controlled electronic            variable data and images to be
                                                                                                               printed, but also ensures the
9. Tension Control                   Teknek dual sided web cleaner            cabinet                          colours match your non-variable
                                                                                                               jobs, even for 7 colour printing.
The N610i digital label press - High print quality at flexo speeds - Combines the productivity of flexo with the flexibility of digital - Domino ...
Technical Specification:
          Technology                                                                                                        Unwind/Rewind                                                                                                                                  Dimensions
          • Piezo Drop on Demand ink jet                                                                                    • 1000mm (40”) diameter                                                                                                                        • 5.614m (L) x 1.735m (H) x 1.925m (W)
                                                                                                                            • Maximum roll weight: 300kg (661lbs)                                                                                                            (1.0m minimum clearance required)
          Printing Speed                                                                                                    • Servo driven tension control                                                                                                                 • 18.5ft (L) x 5.9ft (H) x 6.4ft (W)
          • Up to 50m/min (164ft/min) high quality mode                                                                     • Corona treatment module                                                                                                                        (3.3ft minimum clearance required)
          • Up to 75m/min (246ft/min) rapid mode                                                                            • Web cleaning                                                                                                                                 • Ink cabinet: 1202mm (L) x 807mm (H)
                                                                                                                            • Web guide module                                                                                                                               x 520mm (W) 47.3” (L) x 31.8” (H)
          Image Resolution
                                                                                                                                                                                                                                                                             x 20.5” (W)
          • 600dpi native including 4 greyscales                                                                            Workflow
           (nominal 1340dpi)                                                                                                • Esko DFE                                                                                                                                     Weight
                                                                                                                                                                                                                                                                           • Unwind: 600kg (1323lbs)
          Image Format                                                                                                       Central Print Module
                                                                                                                                                                                                                                                                           • Printing section: Nominal 1500kg (3307lbs)
          • 333mm (13.11”) maximum print width                                                                               • Anti-static control
                                                                                                                                                                                                                                                                           • Rewind: 400kg (882lbs)
                                                                                                                             • 4-colour print section (CMYK standard),
          Web Width                                                                                                                                                                                                                                                        • Power cabinet: 350kg (772lbs)
                                                                                                                               5th , 6th and 7th colours (optional)
          • 200mm (7.9”) to 340mm (13.4”)                                                                                                                                                                                                                                  • Ink supply unit: 200kg (441lbs)
                                                                                                                             • UV LED pinning
          Media Type                                                                                                         • UV curing module                                                                                                                            Services
          • Polyethylene, polypropylene and paper self                                                                                                                                                                                                                     • Three phase power - one 380-420V drop
                                                                                                                            Options
            adhesive label stock                                                                                                                                                                                                                                           • Compressed air - one drop @ 6-8 bar
                                                                                                                            • In-line finishing interface
          • Selected unsupported materials (films)                                                                                                                                                                                                                           (90-115psi), clean and dry
                                                                                                                            • In-line inspection
          Inks                                                                                                              • Variable data printing                                                                                                                       Environment
          • UV curable Cyan, Magenta, Yellow, Black,                                                                        • Load cells                                                                                                                                   • Optimal temperature range 20-22˚C (68-72°F)
            Orange, Violet and White                                                                                        • Chilled roller                                                                                                                               • Maximum temperature range 20-25˚C (68-77°F)
                                                                                                                                                                                                                                                                           • Ink storage 20-25˚C (68-77°F)
                                                                                                                                                                                                                                                                           • Optimum humidity range 40-60%
                                                                                                                                                                                                                                                                           • Dust controlled environment preferred
