PAVING & FLAGS
SPECIFICATIONS

www.acheson-glover.com
PAVING & FLAGS SPECIFICATIONS - www.acheson-glover.com
Acheson & Glover                                                                                                                                                                                                     www.acheson-glover.com

                                                                                                                     Contents
TerraPave®, Rimini Ground                                                                                                                                    TerraPave® Flags, Rimini & Florento Ground
                                                                                                                     Introduction                       03

                                                                                                                     Nationwide Projects                04

                                                                                                                     FLAGS                              06

                                                                                                                     TerraPave® Flags                   08

                                                                                                                     Manor Stone® Flags                 12

                                                                                                                     Canterra Flags®                    14

                                                                                                                     Plaza Flags                        16

                                                                                                                     Classic Flags                      18

                                                                                                                     Riven Flags                        20

                                                                                                                     Bevelled Flags                     22

                                                                                                                     Tactile & Deterrent Flags          24

                                                                                                                     PAVING                             26

                                                                                                                     Plaza                              28

                                                                                                                     River Stone                        32

                                                                                                                     Country Cobble    ®                36

                                                                                                                     Strada                             40

                                                                                                                     Boulevard®                         42

                                                                                                                     Rectangular                        46

                                                                                                                     Xflo Permeable Paving Solutions
                                                                                                                         ®                              50

                                                                                                                     Circles                            54

                                                                                    We are the experts               Setts                              55
                                                                                    in commercial paving and flags   Kerbs & Steps                      56

                                                                                                                     Complementary Products             58

                                                                                                                     Machine Lay                        59

                                                                                                                     TECHNICAL INFO                     60   PAVING & FLAGS
                            About Acheson & Glover
                                                                                                                     Laying Patterns                    62
                            Established in 1960, Acheson & Glover (A&G) has spent over                                                                       A&G’s paving and flags are versatile to suit the most
                                                                                                                     British & European Standards       65   demanding of imaginations, introducing a completely new
                            50 years designing and manufacturing a wide range of
                            products and solutions in concrete for both the residential                              Design & Installation Guidance     66   dimension to design and construction. Ideal for use in the
                            and the commercial sectors and are recognised as one of                                                                          design and construction of prestigious, private and
                                                                                                                     How to Specify                     67
                            the most trusted concrete producers in the UK and Ireland.                                                                       commercial developments, allowing professional designers
                                                                                                                     Design Support                     67   to create projects with true visual impact.
                            Through advances in manufacturing technology and a                                       BREEAM                             68
                            stringent quality control that stretches all the way from the                                                                    With the best technical expertise in the field we can help
                                                                                                                     Maintenance Guidance               69   you turn your vision into a reality.
                            quarry to the final product, we have a team of people who
                            have the skills and imagination to not only rethink and                                  Health, Safety & The Environment   70
                            re-engineer in concrete, but also to redefine it.
                                                                                                                                                             PRODUCT KEY

                                                                                                                                                             Frost       Pedestrian   Light Duty      Heavy Duty
02                                                                                                                                                           Resistant   Use          Traffic >60mm   Traffic 80mm                      03
                                                            www.acheson-glover.com/cemarking
PAVING & FLAGS SPECIFICATIONS - www.acheson-glover.com
Acheson & Glover                                                                                                                                                                                        www.acheson-glover.com

            Nationwide
                                                  PROJECTS

                                                                                                                                                                                                              LEICESTER COLLEGE

                                                                                                                                                                                                     RATHMORE GRAMMAR SCHOOL

                                                  THE MARSHES, DUNDALK            SELBY COLLEGE, YORKSHIRE

                                                                                                                                                                  BANGOR ACADEMY

                                         Paving & Flags
                                         It's a fact - good design enhances                          the highest industry standards, the options for creating
                                         lives and communities.                                      enduring, cost-effective design solutions have never
                                                                                                     been better.
                                         Professional designers and developers have embraced
                                         the fact that there is a direct link between the standard
                                                                                                     Paving & Flags
                                         of design in the local environment and a community's
                                         quality of life.                                            A&G’s innovative paving and flags range, will satisfy
                                                                                                     the most demanding design brief, be it industrial,           SPRINGFIELD QUAYS, GLASGOW
                                         We have seen the transformation of our cities and
                                                                                                     commercial, residential or public. Paving and flag
                                         want our communities to enjoy similar benefits.
                                                                                                     products are widely used in many prestigious
                                         Already many towns and cities are reaping the
                                                                                                     developments, city roadways, landscape and industrial
                                         aesthetic, economic and practical rewards of
                                                                                                     projects. Durable, versatile and structurally resistant to
                                         pedestrianising streets and enhancing parks, walkways
                                                                                                     frost damage, chemicals, fuel and oils, this quality
                                         and waterfronts.
                                                                                                     paving offers attractive, high-performance solutions for
                                         Today designers, working in partnership with paving         busy urban areas, docks, airports, retail parks and
                                         specialist, A&G, have unsurpassed scope for new ideas.      industrial sites, even domestic driveways.
                                         We are continually developing innovative shapes, sizes,
                                                                                                     Each product range within our extensive line-up has its
                                         textures and colour ranges in paving materials, creating
                                                                                                     own distinctive qualities, allowing you to select paving
                                         a world of inspiring possibilities.
                                                                                                     that exactly matches the character and demands of
                                         Because they are strong, weatherproof, long-lasting         any project. The huge choice, together with the
                                         and versatile, paving and flags are the preferred           expertise of our professional design and technical
                                         materials for hard landscaping and with A&G's               team, means A&G can provide total solutions for all
                                         extensive range of paving and flags, accessories and        your paving needs.
                                         related products, all manufactured in compliance with

                                                                                                         We are the experts
                   EYRE SQUARE, GALWAY
                                                                                                         in commercial paving and flags
04                                                                                                                                                                                                                          05
                                                                                                                                                                  6TH FORM COLLEGE, STOKE-ON-TRENT          WEST PARK SHANNON
PAVING & FLAGS SPECIFICATIONS - www.acheson-glover.com
Acheson & Glover                                                          www.acheson-glover.com

                                                                                 WAKEFIELD COLLEGE
                                                                 TerraPave®, Rimini & Florento Ground

FLAGS
LARGE ELEMENT
A&G’s innovative flags range will satisfy the most
demanding design brief, be it industrial, commercial,
public or residential. A&G flags products are widely
used in many prestigious developments, city roadways,
landscape and industrial projects.

                                                        We are the experts
                                                        in commercial paving and flags

06                                                                                                07
PAVING & FLAGS SPECIFICATIONS - www.acheson-glover.com
Acheson & Glover   < TerraPave®, Rimini Ground                                                                       www.acheson-glover.com

                   PREMIUM NATURAL AGGREGATE FLAGS
                   ENHANCED WITH GRANITE CHIPPINGS

                   TERRAPAVE®
                   Natural Aggregate Flags
                                                                                                                        TerraPave®, Milano Ground

                   A uniquely attractive and cost-effective alternative to      INTERNAL APPLICATIONS
                   traditional paving for professional designers and            The TerraPave® range is suited to internal
                   specifiers. TerraPave® flags are manufactured in             applications due to its exceptional quality
                   complementary ground and textured finishes and will set      and attractive finish. No wonder it's the
                   any project apart with a distinctive and lasting visual      choice of prestigious office projects,
                   impact rich in natural appeal.                               educational establishments and garden
                   We carefully select our aggregate materials from quarries    centres throughout the UK and Ireland.
                   throughout Europe. TerraPave® flags are manufactured         A beautiful solution for those highly
                   to precise tolerances in a state-of-the-art factory, which   pedestrianised areas.
                   employs the most advanced production techniques in
                   Europe to make laying faster and easier. Bespoke colours
                   can be manufactured for large projects.
08                                                                                                                                            09
PAVING & FLAGS SPECIFICATIONS - www.acheson-glover.com
Acheson & Glover                                                                                                                                                                                                                                                                                      www.acheson-glover.com

                                                                                                  NBS PLUS:   Q25 SLAB/BRICK/BRICK/SETT/COBBLE PAVINGS: 31, 315
                                                                                                  BS EN:      1339:2003
                                                                                                  CARBON:     19.0Kg CO2 per m2

                                                                                                  TERRAPAVE®
                                                                                                  Natural Aggregate Flags

                                                                                                  FEATURES & BENEFITS:                                                      STANDARDS & PERFORMANCE:                                                                 Note: During installation care should be taken to protect the
                                                                                                                                                                                                                                                                     product from wet and dark base sand, dirt and detritus while
                                                                                                  Highest quality product available in both ground                          TerraPave® is manufactured in compliance with the
                                                                                                                                                                                                                                                                     remaining construction works are completed. To ensure the
                                                                                                  and textured finishes.                                                    performance levels of BS EN 1339:2003.                                                   flags remain in good condition, regular cleaning is essential
                                                                                                  Specially selected natural aggregates including                           For vehicular access, 400x400mm can be manufactured in                                   after installation.
                                                                                                  granite - gives an outstanding aesthetic appeal.                          depths of 65mm-80mm in compliance with BS 1339:2003                                      Careful consideration should be given to the selection of
                                                                                                                                                                                                                                                                     jointing material. Some sand colours may stain the paving
                                                                                                  Offers exceptional durability with in a full range                        Annex NA (consult our technical department for advice on the                             surface.
                                                                                                  of natural colours.                                                       flag most suitable for specific breaking load requirements.)                             A&G recommends the use of silver granite sand with our
                                                                                                                                                                                                                                                                     Florento, Rimini and Milano flags.
                                                                                                  Contains the latest in chemical additives to reduce                       • Bending Strength:                Min. Class 1 [>3.5 Mpa]
                                                                                                                                                                                                                                                                     TerraPave® flags are manufactured using natural stone which
                                                                                                  water absorption which lessens the effect of                              • Slip Potential:                     Low Slip Potential                                 can vary slightly in tone. Where possible it is advised to order
                                                                                                  naturally occurring efflorescence.                                                                                                                                 from the same production run to avoid the possibility of tone
                                                                                                                                                                            • Abrasion Resistance:                     Class 3
                                                                                                                                                                                                                                                                     variations (shading).
                                                                                                  Resistant to the effects of freeze/thaw that                              • Weathering Resistance:                   Class 3                                       Like all quality concrete products with a high cement content,
                                                                                                  can be caused by de-icing salts.                                              (Resistant to freeze/thaw associated with de-icing salts)                            TerraPave® flags can display the effects of efflorescence.
                                                                                                                                                                                                                                                                     Sometimes known as ‘white bloom’, this naturally occurring
                                                                                                  Dimensionally accurate.
                                                                                                                                                                            CHAMFER SIZE:                                                                            phenomenon will disappear over time and does not effect
                                                                                                                                                                                                                                                                     the structural integrity of the flag.
                                                                                                  MANUFACTURE:                                                              All depths have a chamfer of between 3-5mm. This assists with
                                                                                                                                                                                                                                                                     Care should be taken when handling TerraPave® flags. During
                                                                                                  TerraPave® flags are manufactured from specially selected                 edge protection and sand jointing.                                                       transport and delivery some ‘chipping’ (up to 5%) can be
                                                                                                  granite and other natural aggregates. Their exceptional                                                                                                            expected. These can be used for cuts and detailing.
                                                                                                                                                                            JOINT WIDTH:
                                                                                                  appearance is achieved by using the most up-to-date
                                                                                                                                                                            TerraPave® flags are normally ‘butt jointed’ in pedestrian areas.
                                                                                                  manufacturing and finishing equipment.
                                                           TerraPave®, Rimini & Florento Ground                                                                             However, in areas where vehicular overrun is anticipated,
                                                                                                  TRAFFICKING:                                                              TerraPave® 65-80mm should be laid as a flexible pavement with
                                                                                                  40mm and 50mm depth TerraPave® is suitable for patios,                    5mm joints filled with suitable jointing sand (as per BSEN 1339
                                                                                                  pathways and pedestrian walkways.                                         2003 - National Annex NA (informative)). It is recommended
                                                                                                  >65mm is required for vehicular access.                                   spacers are used to ensure joint width is maintained.

                                                                                                  COLOURS:

                                                                                                                                                                                                                                                                                                                               Verona Textured
                                                                                                                                                                                                                                                                               Milano Textured
                                                                                                                                                                              Sorrento Textured

                                                                                                                                                                                                                            Rimini Textured
                                                                                                                               Florento Textured
                                                                                                  Florento Ground                                  Sorrento Ground                                Rimini Ground                                  Milano Ground                                      Verona Ground

                                                                                                                                                                                                                             Arno Textured

                                                                                                                                                                                                                                                                                    Como Textured

                                                                                                                                                                                                                                                                                                                                Tuscany Textured
                                                                                                                                                                              Pollensa Textured
                                                                                                                               Genoa Textured
                                                                    TerraPave®, Verona Ground

                                                                                                  Genoa Ground                                     Pollensa Ground                                Arno Ground                                       Como Ground                                     Tuscany Ground

                                                                                                  PRODUCT DATA:
                                                                                                  SIZE (mm):                                        400x400               600x400                         400x400           600x400
                                                                                                                                                                                                                                                                   NEW SIZE:
                                                                                                  DEPTH:                                             50mm                 50mm                              80mm                      80mm
                                                                                                                                                                                                                                                                  500 x 500mm
                                                                                                  M2 PER PACK:                                        15.36                15.36                              9.6                             9.6
                                                                                                  NO. PER M :  2                                       6.25                4.17                              6.25                             4.17

                                                                                                                                                                                                                                                             >>
                                                                                                  NO. PER PACK:                                         96                  64                                  60                            40                      Please note minimum order quantities are
                                                                                                                                                                                                                                                                      required for certain colours and sizes.
                                                                                                  WEIGHT PER PACK:                                     1.8 t               1.8 t                            1.84 t                       1.84 t                       We advise you speak to a member of the
                                                                                                  COLOURS:                                                     AS ABOVE                                              AS ABOVE                                         sales team in advance of order placement.

                                                                                                  TerraPave® is also available in a depth of 40mm and nominal depths above 50mm and up to 80mm.
10                                                                                                                                                                                                                                                                                                                             11
TerraPave®, Rimini Textured, Country Cobble, Slate Setts          TerraPave®, Florento Textured
PAVING & FLAGS SPECIFICATIONS - www.acheson-glover.com
Acheson & Glover   < Manor Stone, Blackwater                                                                                                 www.acheson-glover.com

                   NBS PLUS:    Q25 SLAB/BRICK/BRICK/SETT/COBBLE PAVINGS: 31, 315
                   BS EN:       1339:2003
                   CARBON:      17.0Kg CO2 per m2

                   MANOR                                                                                    SPECIALLY SELECTED
                                                                                                            AGGREGATES WITH A
                   STONE®                                                                                   UNIQUE UNDULATING
                                                                                                            FINISH

                   Manor Stone® is manufactured from premium aggregates with a                              FEATURES & BENEFITS:
                                                                                                            High quality closed face finish.
                   unique undulating surface finish giving the appearance of natural
                                                                                                            Modular system - each pack contains a multiple
                   riven stone flags. The warm rustic earth colour tones and multiple
                                                                                                            of each of the different sizes available to produce
                   unit sizes make Manor Stone® ideally suited to pathways and                              a distinctive pattern.
                   pedestrian walkways in traditional schemes or conservation areas.                        Beautiful undulating surface and subtle waved
                                                                                                            edge can be used in both contemporary and
                   The Blackwater version contains granite chippings, giving it a
                                                                                                            traditional surroundings.
                   sophisticated seductive shimmer, while the Camborne version has
                                                                                                            Colour blends have been specially chosen to
                   hues of reds and greys, resulting in a distinctly Mediterranean feel.                    complement most settings.
                   To add to the choice, Cotswold with its subtle colour blend, provides                    Can be used indoors.
                   a more traditional, mellow appeal.                                                       Contains the latest chemical additives to reduce
                                                                                                            water absorption which lessens the effect of
                   Manor Stone® is supplied in a mix of four different sizes which                          naturally occurring efflorescence.
                   offers the opportunity to create a distinctive pattern.
                                                                                                            MANUFACTURE:
                                                                                                            Manor Stone is manufactured from specially selected
                                                                                                            premium aggregates to create a high quality, closed
                   COLOURS:                                                                                 face finish. Its unique undulating finish is obtained by
                                                                                                            using the most up-to-date manufacturing processes
                                                                                                            and machinery.

                                                                                                            TRAFFICKING:
                                                                                                            Suitable for patios, pathways, pedestrian walkways and
                                                                                                            indoor use. Not suitable for driveway usage.

                                                                                                            STANDARDS & PERFORMANCE:
                   Blackwater                        Cotswold                          Camborne             Manor Stone is manufactured in compliance with the
                                                                                                            performance levels in BS EN 1339:2003 Concrete
                                                                                                            Flags. Requirements and test methods are
                                                                                                            independently accredited by BSI.
                   PRODUCT DATA:                                                                            BS EN 1339 states the following as minimum
                   SIZE (mm):                                   FLAGS NOT SOLD INDIVIDUALLY                 performance criteria for category I and II flags:
                                               210x315             315x315          420x315       525x315   • Bending Strength:             Min. Class 1 [>3.5 Mpa]
                   DEPTH:                                                    50mm                           • Slip Potential:                 Low Slip Potential

                   M2 PER PACK:                                        15.6m2 per pack                      JOINT WIDTH:
                   NO. PER M2:                                                N/A                           1-3mm spacers on each flag leaving a 3-7mm joint
                                                                                                            when laid.
                   NO. PER PACK:                                  130 flags of 4 assorted sizes
                   WEIGHT PER PACK:                                                                         Note: During installation care should be taken to protect the
                                                                              1.8 t
                                                                                                            product from wet and dark base sand, dirt and detritus while
                   COLOURS:                                               Blackwater                        remaining construction works are completed. To ensure the flags
                                                                          Camborne                          remain in good condition, regular cleaning is essential after
                                                                                                            installation.
                                                                           Cotswold
                                                                                                            Light coloured blocks emphasise marks and oil spills. It must be
                                                                                                            accepted that these products will need more maintenance if the
                                                                                                            overall appearance is to be maintained.

                   Each pack contains 130 flag                                                              Careful consideration should be given to the selection of jointing
                                                                                                            material. Some sand colours may stain the paving surface. A&G
                   units of four assorted sizes:
                                                                                                            recommends the use of silver granite sand with our Blackwater
                                                                                                            flags.
                   210x315mm x13 no.
                   315x315mm x52 no.

                                                                                                            >>
                                                                                                                         Please note minimum order quantities are
                   420x315mm x39 no.
                                                                                                                         required for certain colours. We advise you
                   525x315mm x26 no.                                                                                     speak to a member of the sales team in
                                                                                                                         advance of order placement.

12                                                                                                                                                                               13
PAVING & FLAGS SPECIFICATIONS - www.acheson-glover.com
Acheson & Glover   < Canterra Flags, Silver                                                                                                                    www.acheson-glover.com

                   NBS PLUS:    Q25 SLAB/BRICK/BRICK/SETT/COBBLE PAVINGS: 31, 315
                   BS EN:       1339:2003
                   CARBON:      14.0Kg CO2 per m2

                   CANTERRA                                                ®                                              SUBTLE TEXTURE WITH
                                                                                                                          GRANITE CHIPPINGS &
                   FLAGS                                                                                                  A BRUSHED SEMI-SHEEN
                                                                                                                          FINISH

                   The lightly embossed surface and colours of Canterra® flags make them                                  FEATURES & BENEFITS:
                   ideal for conservation areas and traditional architectural schemes.                                    ‘Brushed’ surface gives a high quality finish with
                   With the inclusion of granite chippings and a brushed semi-sheen                                       a subtle semi-sheen appearance.
                                                                                                                          Granite chippings enhance the look.
                   appearance, Canterra® flags provide a high quality finish.
                                                                                                                          Subtle embossed surface adds texture to
                                                                                                                          complement most surroundings.
                                                                                                                          Light and easily managed.
                                                                                                                          Easy to clean.
                                                                                                                          Available in 3 depths.
                                                                                                                          Frost resistant.

                                                                                                                          MANUFACTURE:
                                                                                                                          Canterra flags are manufactured from locally sourced
                                                                                                                          aggregates. They are finished with a subtle embossed
                                                                                                                          surface and brushed finish.

                                                                                                                          TRAFFICKING:
                                                                                                                          Canterra flags are suitable for pathways, patios and
                                                                                                                          pedestrian walkways.
                                                                                                  Canterra Flags, Slate

                   COLOURS:                                                                                               STANDARDS & PERFORMANCE:
                                                                                                                          Canterra flags are wet cast and are manufactured in
                                                                                                                          compliance with the performance levels of BS EN
                                                                                                                          1339:2003 Concrete Paving Flags.
                                                                                                                          • Bending Strength:       Min. Class 1 [>3.5 Mpa]
                                                                                                                          • Slip Potential:             Low Slip Potential
                                                                                                                          • Abrasion Resistance              Class 2
                                                                                                                          • Weathering Resistance            Class 3
                                                                                                                              (Resistant to freeze/thaw associated with de-icing salts)

                   Sandstone                         Silver
                                                                                                                          CHAMFER SIZE:
                                                                                                                          Canterra flags have a chamfer size of between 3mm-
                                                                                                                          5mm. This assists with edge protection and sand
                                                                                                                          jointing.

                                                                                                                          JOINT WIDTH:
                                                                                                                          Canterra flags are normally butt jointed but spacers can
                                                                                                                          be used if deemed necessary.

                                                                                                                          Note: During installation care should be taken to protect the product
                                                                                                                          from wet and dark base sand, dirt and detritus while remaining
                   Slate                             Light Grey
                                                                                                                          construction works are completed. To ensure the flags remain in good
                                                                                                                          condition, regular cleaning is essential after installation.
                                                                                                                          Careful consideration should be given to the selection of jointing material.
                   PRODUCT DATA:                                                                                          Some sand colours may stain the paving surface. A&G recommends the
                                                                                                                          use of silver granite sand with our Silver, Slate and Light Grey flags.
                   SIZE:                      400x400mm           600x400mm                                               Canterra flags are manufactured using fine aggregates which can vary
                                                                                    ADDITIONAL SIZES:
                                                                                                                          slightly in tone. Where possible it is advised to order from the same
                   DEPTH:                        40mm               40mm            400 x 400 x 50mm                      production run to avoid the possibility of tone variations (shading).

                   M2 PER PACK:                 14.72m2            11.04m2          600 x 400 x 50mm                      Like all quality concrete products with a high cement content, Canterra
                                                                                    600 x 400 x 63mm                      flags can display the effects of efflorescence. Sometimes known as ‘white
                   NO. PER M2:                    6.25               4.17                                                 bloom’, this naturally occurring phenomenon will disappear over time and
                                                                                                                          does not effect the structural integrity of the flag.
                   NO. PER PACK:                   92                 46                                                  Care should be taken when handling Canterra flags. During transport and
                                                                                                                          delivery some ‘chipping’ (up to 5%) can be expected. These can be used

                                                                                    >>
                                                                                         Please note minimum order
                   WEIGHT PER PACK:              1.41 t             1.05 t                                                for cuts and detailing.
                                                                                         quantities are required for
                                                                                                                          Canterra flags are vertically stacked, bound horizontally with a strap at
                   COLOURS:                   SANDSTONE           SANDSTONE              certain colours and sizes.       both the top and bottom of the bale and are not on pallets.
                                                 SILVER              SILVER              We advise you speak to a
                                                 SLATE               SLATE               member of the sales team in
                                              LIGHT GREY          LIGHT GREY             advance of order placement.
14                                                                                                                                                                                                15
PAVING & FLAGS SPECIFICATIONS - www.acheson-glover.com
Acheson & Glover   < Plaza Flags, Sandstone                                                                                 www.acheson-glover.com

                   NBS PLUS:    Q25 SLAB/BRICK/BRICK/SETT/COBBLE PAVINGS: 31, 315
                   BS EN:       1339:2003
                   CARBON:      18.0Kg CO2 per m2

                   PLAZA                                                                 PREMIUM GRANITE
                                                                                         STONE WASHED FLAGS
                   FLAGS
                   Using the finest natural aggregates and sands we have created         FEATURES & BENEFITS:
                                                                                         High quality granite aggregate.
                   a unique flag option, ideal on schemes designed to lead the
                                                                                         Washed finish gives a natural appearance.
                   way. Plaza is a system you can use on every project yet give
                                                                                         Understated colours create a contemporary
                   each client a completely individual result.
                                                                                         backdrop to modern or traditional projects.

                   The superb natural finish is manufactured to tight tolerances         Can be used with Plaza paving blocks to create
                                                                                         different patterning effects.
                   ensuring designs can be brought to life easily and accurately.
                                                                                         Excellent slip resistance.
                   Plaza increases the palette of paving materials available to
                   designers particularly for commercial, retail and housing             MANUFACTURE:
                   schemes - bringing a new dimension to hard landscaping.               Plaza flags are manufactured from specially selected
                                                                                         granite aggregate. The premium stone washed
                                                                                         appearance is obtained using computer controlled
                   COLOURS:                                                              washing machinery which leaves a uniquely natural
                                                                                         finish.

                                                                                         TRAFFICKING:
                                                                                         Plaza flags are suitable for patios, pathways and
                                                                                         pedestrian walkways.

                                                                                         STANDARDS & PERFORMANCE:
                                                                                         Plaza flags are manufactured in compliance with the
                                                                                         performance levels in BS EN 1338:2003 Concrete
                   Sandstone                         Slate                               Paving Flags: Requirements and test methods are
                                                                                         independently accredited by BSI.
                                                                                         BS EN 1338 states the following as minimum
                                                                                         performance criteria for category I and II paving:
                                                                                         • Bending Strength:               Min. Class 1 [>3.5 Mpa]
                                                                                         • Slip Potential:                   Low Slip Potential
                                                                                         • Abrasion Resistance:                    Class 3
                                                                                         • Weathering Resistance:                  Class 3

                                                                                         CHAMFER SIZE:
                   Silver                            Graphite
                                                                                         Plaza flags have a chamfer size of 3mm. This assists
                                                                                         with edge protection and sand grouting.

                   >>
                               Please note minimum order quantities are
                                                                                         JOINT WIDTH:
                               required for certain colours and sizes.
                               We advise you speak to a member of the                    2mm spacers on each flag leaving a 3mm minimum
                               sales team in advance of order placement.                 joint when laid.

                                                                                         Note: During installation care should be taken to protect the product
                                                                                         from wet and dark base sand, dirt and detritus while remaining
                   PRODUCT DATA:                                                         construction works are completed. This is especially true for light
                                                                                         coloured flags. To ensure the paving remains in good condition, regular
                   SIZE:                               400x400mm                         cleaning is essential after installation.
                                                                                         Careful consideration should be given to the selection of jointing
                   DEPTH:                                    50mm                        material. Some sand colours may stain the paving surface. A&G
                                                                                         recommends the use of silver granite sand with our Silver and Slate
                   M2 PER PACK:                          15.36m2
                                                                                         flags.
                   NO. PER M2:                                6.25                       Plaza flags are manufactured using fine aggregates which can vary
                                                                                         slightly in tone. Where possible it is advised to order from the same
                   NO. PER PACK:                               96                        production run to avoid the possibility of tone variations (shading).
                                                                                         Like all quality concrete products with a high cement content, Plaza
                   WEIGHT PER PACK:                          1.725 t                     flags can display the effects of efflorescence. Sometimes known as
                                                                                         ‘white bloom’, this naturally occurring phenomenon will disappear over
                   COLOURS:                              SILVER                          time and does not effect the structural integrity of the flag.
                                                         SLATE                           Care should be taken when handling Plaza flags. During transport and
                                                       SANDSTONE                         delivery some ‘chipping’ (up to 5%) can be expected. These can be
                                                                                         used for cuts and detailing.
                                                        GRAPHITE

                   Also available in 80mm depth for areas requiring vehicular overrun.
16                                                                                                                                                               17
PAVING & FLAGS SPECIFICATIONS - www.acheson-glover.com
Acheson & Glover   < Classic Flags, Sandstone                                                                                                                    www.acheson-glover.com

                   NBS PLUS:    Q25 SLAB/BRICK/BRICK/SETT/COBBLE PAVINGS: 31, 315
                   BS EN:       1339:2003
                   CARBON:      14.0Kg CO2 per m2

                   CLASSIC                                                                                                   RICHLY TEXTURED
                                                                                                                             FLAGS MADE FROM
                   FLAGS                                                                                                     FINE AGGREGATES

                   The Classic Flag range has a mellow rustic character, as                                                  FEATURES & BENEFITS:
                                                                                                                             Richly textured flags made from
                   appealing in conservation areas as they are in contemporary
                                                                                                                             fine aggregates.
                   schemes. Richly textured, they are manufactured from fine
                                                                                                                             Made in 3 specially selected colours that
                   aggregates for a more natural appearance.                                                                 blend in with most landscape requirements.
                                                                                                                             Textured finish is suitable for areas requiring
                                                                                                                             higher levels of slip resistance.
                                                                                                                             Resistant to the effects of freeze/thaw that
                                                                                                                             can be caused by de-icing salts.

                                                                                                                             MANUFACTURE:
                                                                                                                             Made from locally sourced and graded aggregates,
                                                                                                                             Classic Flags’ textured appearance is achieved by using
                                                                                                                             up-to-date manufacturing and finishing technology.

                                                                                                                             TRAFFICKING:
                                                                                                                             40mm Classic Flags are suitable for pathways, patios
                                                                                                                             and pedestrian walkways. >65mm is required for
                                                                                                                             vehicular access.

                                                                                                                             STANDARDS & PERFORMANCE:
                                                                                                                             The Classic Flag is manufactured in compliance with
                                                                                                                             the performance levels of BS EN 1339:2003 Concrete
                                                                                                                             Paving Flags.
                                                                                                                             For vehicular access Classic Flags can be manufactured
                                                                                                                             in depths of 65-80mm in compliance with BS EN
                                                                                                                             1339:2003 Annex NA (consult our technical
                                                                                                       Classic Flags, Grey   department for advice on the flag most suitable for
                                                                                                                             breaking load requirements).
                   COLOURS:                                                                                                  • Bending Strength: Min. Class 1 [>3.5 Mpa]
                                                                                                                             • Slip Potential:              Low Slip Potential
                                                                                                                             • Abrasion Resistance                Class 2
                                                                                                                             • Weathering Resistance              Class 3
                                                                                                                                 (Resistant to freeze/thaw associated with de-icing salts)

                                                                                                                             CHAMFER SIZE:
                                                                                                                             All depths have a chamfer size of between 3-5mm.
                                                                                                                             This assists with edge protection & sand jointing.

                   Sandstone                         Slate                          Grey
                                                                                                                             JOINT WIDTH:
                                                                                                                             Classic Flags are normally ‘butt jointed’ but spacers can
                                                                                                                             be used if a space is deemed necessary.
                   PRODUCT DATA:
                                                                                                                             Note: During installation care should be taken to protect the product
                   SIZE (mm):                                 400x400                                                        from wet and dark base sand, dirt and detritus while remaining
                                                                                    ADDITIONAL SIZES:                        construction works are completed. To ensure the flags remain in good
                   DEPTH:                                      40mm                    600 x 400mm                           condition, regular cleaning is essential after installation.
                                                                                                                             Careful consideration should be given to the selection of jointing material.
                   M PER PACK:
                     2                                        19.2m2                   500 x 500mm                           Some sand colours may stain the paving surface. A&G recommends the
                                                                                                                             use of silver granite sand with our Grey and Slate flags.
                   NO. PER M :  2                              6.25                                                          Classic Flags are manufactured using fine aggregates which can vary
                                                                                                                             slightly in tone. Where possible it is advised to order from the same
                   NO. PER PACK:                                120                                                          production run to avoid the possibility of tone variations (shading).
                                                                                           Please note minimum order         Like all quality concrete products with a high cement content, Classic
                   WEIGHT PER PACK:                             1.7 t

                                                                                    >>
                                                                                           quantities are required for       Flags can display the effects of efflorescence. Sometimes known as ‘white
                   COLOURS:                                  SANDSTONE                     certain colours and sizes.        bloom’, this naturally occurring phenomenon will disappear over time and
                                                                                                                             does not effect the structural integrity of the flag.
                                                               SLATE                       We advise you speak to a
                                                                                           member of the sales team in       Care should be taken when handling Classic Flags. During transport and
                                                                GREY                                                         delivery some ‘chipping’ (up to 5%) can be expected. These can be used
                                                                                           advance of order placement.       for cuts and detailing.
                   Also available in nominal depths from 50mm up to
18                 80mm.                                                                                                                                                                             19
Acheson & Glover   < Riven Flags, Slate                                                                                                                   www.acheson-glover.com

                   NBS PLUS:    Q25 SLAB/BRICK/BRICK/SETT/COBBLE PAVINGS: 31, 315
                   BS EN:       1339:2003
                   CARBON:      14.0Kg CO2 per m2

                   RIVEN                                                                                                LIGHTWEIGHT AND
                                                                                                                        EASY-TO-HANDLE
                   FLAGS                                                                                                PATTERNED FLAGS

                   Riven flags provide an attractive, cost effective option for                                         FEATURES & BENEFITS:
                                                                                                                        An attractive cost effective flag for patios and
                   patios and paths. The deeply coloured Slate co-ordinates
                                                                                                                        pathways.
                   perfectly with contemporary schemes while Sandstone and
                                                                                                                        The riven surface finish gives a textured detail that
                   Grey look elegant in traditional settings. Lightweight and                                           complements most surroundings.
                   easy-to-handle.                                                                                      Suitable for indoors.
                                                                                                                        An embossed riven surface finish.

                                                                                                                        MANUFACTURE:
                                                                                                                        Riven flags are made from locally sourced aggregates.
                                                                                                                        They are finished with an embossed riven surface finish.

                                                                                                                        TRAFFICKING:
                                                                                                                        Riven flags are suitable for pathways, patios and
                                                                                                                        pedestrian walkways.

                                                                                                                        STANDARDS & PERFORMANCE:
                                                                                                                        Riven flags are wet cast and are manufactured in
                                                                                                                        compliance with BS EN 1339: 2003 Concrete Paving
                                                                                                                        Flags.
                                                                                                                        • Bending Strength:                 Class 1
                                                                                                                        • Slip Potential:              Low Slip Potential

                                                                                                                        CHAMFER SIZE:
                                                                                                                        Riven flags have a chamfer size of between 3mm - 5mm.
                                                                                                                        This assists with edge protection and sand jointing.

                                                                                                                        JOINT WIDTH:
                                                                                                                        Riven flags are normally ‘butt’ jointed but spacers can be
                                                                                                   Riven Flags, Slate
                                                                                                                        used if deemed necessary.
                   COLOURS:
                                                                                                                        Note:
                                                                                                                        During installation care should be taken to protect the product from
                                                                                                                        wet and dark base sand, dirt and detritus while remaining construction
                                                                                                                        works are completed. To ensure the flags remain in good condition,
                                                                                                                        regular cleaning is essential after installation.
                                                                                                                        Careful consideration should be given to the selection of jointing
                                                                                                                        material. Some sand colours may stain the paving surface. A&G
                                                                                                                        recommends the use of silver granite sand with our Grey and Slate
                                                                                                                        flags.
                                                                                                                        Riven flags are manufactured using fine aggregates which can vary
                                                                                                                        slightly in tone. Where possible it is advised to order from the same
                                                                                                                        production run to avoid the possibility of tone variations (shading).
                   Sandstone                         Slate                          Grey                                Like all quality concrete products with a high cement content, Riven
                                                                                                                        flags can display the effects of efflorescence. Sometimes known as
                                                                                                                        ‘white bloom’, this naturally occurring phenomenon will disappear
                                                                                                                        over time and does not effect the structural integrity of the flag.
                                                                                                                        Care should be taken when handling Riven flags. During transport and
                   PRODUCT DATA:                                                                                        delivery some ‘chipping’ (up to 5%) can be expected. These can be
                                                                                                                        used for cuts and detailing.
                   SIZE (mm):                   400x400            600x400
                                                                                                                        Flags are vertically stacked, bound horizontally with a strap at both the
                   DEPTH:                        40mm               40mm                                                top and bottom of the bale and are not on pallets.

                   M2 PER PACK:                 14.08m2            10.56m2
                   NO. PER M2:                    6.25               4.17
                   NO. PER PACK:                   88                 44
                   WEIGHT PER PACK:               1.35 t             1.00 t           ADDITIONAL SIZES:

                                                                                                                        >>
                                                                                                                                     Please note minimum order quantities are
                   COLOURS:                   SANDSTONE          SANDSTONE             400 x 400 x 50mm                              required for certain colours and sizes.
                                                SLATE              SLATE               600 x 400 x 63mm                              We advise you speak to a member of the
                                                GREY               GREY                                                              sales team in advance of order placement.

20                                                                                                                                                                                         21
Acheson & Glover   < Bevelled Flags, Slate                                                                                                                        www.acheson-glover.com

                   NBS PLUS:    Q25 SLAB/BRICK/BRICK/SETT/COBBLE PAVINGS: 31, 315
                   BS EN:       1339:2003
                   CARBON:      14.0Kg CO2 per m2

                   BEVELLED                                                                                                     HARD WEARING,
                                                                                                                                ECONOMICAL AND

                   FLAGS                                                                                                        EASY TO HANDLE

                   Bevelled flags have a smooth, slip-resistant finish. A                                                       FEATURES & BENEFITS:
                                                                                                                                Smooth, slip resistant finish.
                   quality product which provides an economical and hard-
                                                                                                                                Available in a range of popular colours.
                   wearing solution for any hard landscape project.
                                                                                                                                Economical and hard wearing solution for
                                                                                                                                practically any hard landscaping project.
                                                                                                                                Through colour mix adds to the flags versatility,
                                                                                                                                especially in the make-up of steps.

                                                                                                                                MANUFACTURE:
                                                                                                                                Bevelled flags are made from locally sourced aggregates.
                                                                                                                                They have a distinctive bevelled edge chamfer.

                                                                                                                                TRAFFICKING:
                                                                                                                                40mm Bevelled flags are suitable for pathways, patios
                                                                                                                                and pedestrian walkways.
                                                                                                                                63mm are required for areas with vehicular access.

                                                                                                                                STANDARDS & PERFORMANCE:
                                                                                                    Bevelled Flags, Sandstone
                                                                                                                                Bevelled flags are dry pressed and are manufactured in
                   COLOURS:                                                                                                     compliance with BS EN 1339: 2003 Concrete Paving
                                                                                                                                Flags.
                                                                                                                                For vehicular access 63mm Bevelled flags are advised in
                                                                                                                                compliance with BS EN 1339: 2003 Annex NA (our
                                                                                                                                technical department will advise on the flags most
                                                                                                                                suitable for breaking load requirements).
                                                                                                                                • Bending Strength:                 Class 1
                                                                                                                                • Slip Potential:               Low Slip Potential

                   Sandstone                         Slate                          Grey                                        CHAMFER SIZE:
                                                                                                                                All depths have a chamfer size of between 3.5 - 5.0mm.
                                                                                                                                This assists with edge protection and sand jointing.

                                                                                                                                JOINT WIDTH:
                                                                                                                                Bevelled flags are normally ‘butt’ jointed but spacers can
                                                          ADDITIONAL SIZE:                                                      be used if a space is deemed necessary..
                                                           400 x 400 x 63mm                                                     Note: During installation care should be taken to protect the product
                                                           600 x 600 x 63mm                                                     from wet and dark base sand, dirt and detritus while remaining
                                                                                                                                construction works are completed. To ensure the flags remain in good
                                                                                                                                condition, regular cleaning is essential after installation.
                   Terracotta                                                                                                   Careful consideration should be given to the selection of jointing
                                                                                                                                material. Some sand colours may stain the paving surface. A&G
                                                                                                                                recommends the use of silver granite sand with our Grey and Slate flags.
                                                                                                                                Like all quality concrete products with a high cement content, Bevelled
                   PRODUCT DATA:                                                                                                flags can display the effects of efflorescence. Sometimes known as
                                                                                                                                ‘white bloom’, this naturally occurring phenomenon will disappear over
                   SIZE (mm):                     400x400             600x600              400x400             600x600          time and does not effect the structural integrity of the flag.
                                                                                                                                Care should be taken when handling Bevelled flags. During transport
                   DEPTH:                          40mm                40mm                50mm                 50mm            and delivery some ‘chipping’ (up to 5%) can be expected. These can be
                                                                                                                                used for cuts and detailing.
                   M2 PER PACK:                     16m2                9m2                 16m2                  9m2           Flags are vertically stacked, bound horizontally with a strap at both the
                                                                                                                                top and bottom of the bale and are not on pallets.
                   NO. PER M :  2                   6.25                2.78                6.25                  2.78
                                                                                                                                Bevelled flags are manufactured using fine aggregates which can vary
                   NO. PER PACK:                    100                  25                                                     slightly in tone. Where possible it is advised to order from the same
                                                                                             80                    20
                                                                                                                                production run to avoid the possibility of tone variations (shading).
                   WEIGHT PER PACK:                 1.5 t               0.8 t               1.5 t                 0.8 t

                                                                                                                                >>
                   COLOURS:                       GREY                GREY               GREY                   GREY                         Please note minimum order quantities are
                                               SANDSTONE           SANDSTONE          SANDSTONE              SANDSTONE                       required for certain colours and sizes.
                                                  SLATE               SLATE              SLATE                  SLATE                        We advise you speak to a member of the
                                               TERRACOTTA          TERRACOTTA         TERRACOTTA             TERRACOTTA                      sales team in advance of order placement.

22                                                                                                                                                                                                 23
Acheson & Glover   < Corduroy Flags, Buff                                                                                                                      www.acheson-glover.com

                   NBS PLUS:        Q25 SLAB/BRICK/BRICK/SETT/COBBLE PAVINGS: 31, 315
                   BS EN:           1339:2003 / DD CEN/TS 15209:2008
                   CARBON:          13.3 - 17.4Kg CO2 per m2

                   TACTILE &                                                                                                  DISTINCTIVE
                                                                                                                              SURFACE PROFILES
                   DETERRENT FLAGS                                                                                            AND COLOURS

                   Distinctive surface profiles and colours to enable the visually                                            FEATURES & BENEFITS:
                   impaired and partially sighted to recognise various hazards.                                               Suitable for areas where paving surface
                                                                                                                              indicators are required.
                                                                                                                              Distinctive colours and surface profiles gives
                                                                                                                              guidance or warning of potential hazards to
                                                                                                                              the visually empaired.
                                                                                                                              The deterrent flags profile discourages access.

                                                                                                                              MANUFACTURE:
                                                                                                                              Dry pressed.

                                                                                                                              TRAFFICKING:
                                                                                                                              50mm depth flags are suitable for areas of pedestrian
                                                                                                                              walkways and light vehicular overrun.
                                                                                                                              For areas of regular vehicular overrun use 63mm depth.

                                                                                                                              STANDARDS & PERFORMANCE:
                                                                                                                              Tactile and deterrent flags are manufactured in
                                                                                                         Blister Flags, Red   compliance with the performance levels of BS EN
                                                                                                                              1339:2003 Concrete Paving Flags.
                   COLOURS:
                                                                                                                              Also manufactured to DD CEN/TS 15209:2008.

                                                                                                                              CHAMFER SIZE:
                                                                                                                              There is no chamfer on Tactile or Deterent flags.

                                                                                                                              JOINT WIDTH:
                                                                                                                              Tactile flags are normally ‘butt jointed’ in pedestrian
                                                                                                                              areas. However, in areas where vehicular overrun is
                                                                                                                              anticipated, 65-80mm should be laid as a flexible
                                                                                                                              pavement with 5mm joints filled with suitable jointing
                   Buff - Blister                        Buff - Corduroy                  Grey - Deterrent
                                                                                                                              sand (as per BSEN 1339 2003 - National Annex NA
                                                                                                                              (informative)). It is recommended spacers are used to
                                                                                                                              ensure joint width is maintained.

                                                                                                                              Note: During installation care should be taken to protect the
                                                                                                                              product from wet and dark base sand, dirt and detritus while
                                                                                                                              remaining construction works are completed. To ensure the flags
                                                                                                                              remain in good condition, regular cleaning is essential after
                                                                                                                              installation.
                                                                                                                              Careful consideration should be given to the selection of jointing
                                                                                                                              material. Some sand colours may stain the paving surface.
                                                                                                                              Tactile flags are manufactured using fine aggregates which can vary
                   Red - Blister                         Grey - Corduroy                                                      slightly in tone. Where possible it is advised to order from the same
                                                                                                                              production run to avoid the possibility of tone variations (shading).
                                                                                                                              Like all quality concrete products with a high cement content, Tactile
                                                                                                                              flags can display the effects of efflorescence. Sometimes known as
                   PRODUCT DATA:                                BLISTER                 CORDUROY              DETERRENT       ‘white bloom’, this naturally occurring phenomenon will disappear
                                                                                                                              over time and does not effect the structural integrity of the flag.
                                                                400x400                  400x400                  600x600
                                                                                                                              Care should be taken when handling Tactile flags. During transport
                   DEPTH (mm):                                    50mm                    50mm                      50mm      and delivery some ‘chipping’ (up to 5%) can be expected. These can
                                                                                                                              be used for cuts and detailing.
                   M2 PER PACK:                                    12.8                   12.8                        5.4
                   NO. PER M :      2
                                                                   6.25                   6.25                       2.78
                   NO. PER PACK:                                    80                     80                         15
                   WEIGHT PER PACK:                                1.5 t                  1.5 t                     0.63 t

                                                                                                                              >>
                                                                                                                                           Please note minimum order quantities are
                   COLOURS:                                        BUFF                   BUFF                        -                    required for certain colours and sizes.
                                                                   RED                      -                         -                    We advise you speak to a member of the
                                                                   GREY                   GREY                      GREY                   sales team in advance of order placement.

                   63mm depth is also available for Blister and Corduroy only.
24                                                                                                                                                                                                 25
Acheson & Glover                                                                  www.acheson-glover.com

                                                                  SOUTH WEST ACUTE HOSPITAL, ENNISKILLEN
                                                                                                Plaza, Silver
                                                                          Reconstituted Granite Kerbs, Grey

PAVING BLOCKS
SMALL ELEMENT
Durable, versatile and structurally resistant to frost
damage, chemicals, fuel and oils, A&G’s range of quality
paving offers attractive, high-performance solutions for
busy urban areas, docks, airports, retail parks, industrial
sites and even domestic driveways.
Each product range within our extensive line-up has its
own distinctive qualities, allowing you to select paving
that exactly matches the character and demands of any
project. The huge choice, together with the expertise of
our professional design and technical team, means A&G
can provide total solutions for all your paving needs.

                                                              We are the experts
                                                              in commercial paving and flags

26                                                                                                        27
Acheson & Glover   < Plaza, Slate & Silver                                                                          www.acheson-glover.com

                   PREMIUM GRANITE STONE
                   WASHED PAVING

                   PLAZA
                                                                                                                            Plaza, Silver & Slate

                   Using the finest natural aggregates and sands we have        Plaza increases the palette of paving
                   created a unique paving option, ideal on schemes             materials available to designers
                   designed to lead the way. Plaza is the one system you        particularly for commercial, retail and
                   can use on every project yet give each client a completely   housing schemes - bringing a new
                   individual result.                                           dimension to hard landscaping.

                   The superb natural finish is manufactured to tight
                   tolerances ensuring designs can be brought to life easily
                   and accurately.

28                                                                                                                                           29
Acheson & Glover   < Plaza, Slate & Silver                                                                                                                                    www.acheson-glover.com

                   NBS PLUS:    Q24 INTERLOCKING BRICK/BLOCK ROADS/PAVINGS: 10, 110, 112, 113
                                Q25 SLAB/BRICK/BRICK/SETT/COBBLE PAVINGS: 31, 315
                   BS EN:       1338:2003
                   CARBON:      20.0Kg CO2 per m2

                                                                                                                                                                                  Also available as

                   PLAZA
                                                                                                                                                                                      See page 53

                   FEATURES & BENEFITS:                                      (Private drives, paths and patios) as outlined in BS         CHAMFER SIZE:
                   High quality granite aggregate.                           7533-2:2001.                                                 60mm / Xflo: pencil round.
                   Washed finish gives a natural appearance.                 Its small plan dimensions or its 80mm thickness              80mm: minimum 3mm horizontally and vertically.
                   Understated colours create a contemporary                 make it ideally suited for the heavier traffic loadings
                                                                             of categories I and II.                                      JOINT WIDTH:
                   backdrop to modern or traditional projects.
                                                                                                                                          60mm: 1.5mm spacers on each paver leaving a 2mm
                   Modular pavers can be used to create different            msa* - Millions of Standard Axles expected
                                                                                                                                          minimum joint when laid.
                   patterning effects.                                       throughout 20 year design life of pavement.
                                                                                                                                          80mm: 2mm spacers on each paver leaving a 3mm
                   Four colours in multiple sizes.                                                                                        minimum joint when laid.
                                                                             STANDARDS & PERFORMANCE:
                   Excellent slip resistance.
                                                                             Plaza is manufactured in compliance with the                 Note: During installation care should be taken to protect the product from
                                                                             performance levels in BS EN 1338:2003 Concrete               wet and dark base sand, dirt and detritus while remaining construction
                   MANUFACTURE:                                                                                                           works are completed. To ensure the paving remains in good condition,
                                                                             Paving Blocks: Requirements and test methods are
                   Plaza is manufactured from specially selected granite                                                                  regular cleaning is essential after installation.
                                                                             independently accredited by BSI.
                   aggregate. Its premium stone washed appearance is                                                                      Careful consideration should be given to the selection of jointing material.

                   obtained using computer controlled washing                BS EN 1338 states the following as minimum                   Some sand colours may stain the paving surface. A&G recommends the
                                                                                                                                          use of silver granite sand with our Silver, Slate and Graphite pavers.
                   machinery which leaves a uniquely natural finish.         performance criteria for category I and II paving:
                                                                             • Tensile splitting strength:    >3.6 Mpa

                                                                                                                                          >>
                   TRAFFICKING:                                                                                                                         Please note minimum order quantities are
                                                                             • Slip Potential:                Low Slip Potential
                   Within our Plaza range you will find a block size for                                                                                required for certain colours and sizes.
                                                                             • Abrasion resistance:           Class 3                                   We advise you speak to a member of the
                   every application, from category I (Heavy Duty
                                                                             • Weathering resistance:         Class 3                                   sales team in advance of order placement.
                   Pavements of between 0.5 - 12msa*) to category IV

                   COLOURS:

                   Sandstone                          Slate

                   Silver                             Graphite                                                                                                                     Plaza, Sandstone & Slate

                   PRODUCT DATA:
                   SIZE (mm):            300x150               150x150      200x150           400x400          400x200              200x200            200x100 +               200x150               150x150
                   DEPTH:                    60mm                60mm        60mm                80mm            80mm               80mm                  80mm                   80mm                  80mm
                   M2 PER PACK:              12.6                12.6        12.6                 9.6              9.6                  9.6                9.72                      9                    9
                   NO. PER M :  2            22.2                44.4        33.3                6.25             12.5                 25.0                  50                   33.3                  44.4
                   NO. PER PACK:              280                 560         420                 60              120                   240                 486                    300                   400
                   WEIGHT / PACK:            1.75 t              1.75 t      1.75 t              1.76 t          1.76 t                1.76 t              1.7 t                  1.24                  1.22
                   COLOUR                SILVER                 SILVER       SILVER           SILVER            SILVER              SILVER              SILVER                 SILVER                SILVER
                   AVAILABILITY:         SLATE                  SLATE        SLATE            SLATE             SLATE               SLATE               SLATE                  SLATE                 SLATE
                                       SANDSTONE              SANDSTONE    SANDSTONE        SANDSTONE         SANDSTONE           SANDSTONE           SANDSTONE              SANDSTONE             SANDSTONE
                                        GRAPHITE               GRAPHITE     GRAPHITE         GRAPHITE          GRAPHITE            GRAPHITE            GRAPHITE               GRAPHITE              GRAPHITE
                   + Do not mix with other Plaza 80mm
30                                                                                                                                                                                                                31
Acheson & Glover   < River Stone, Slaney                                       www.acheson-glover.com

                   UNIQUE GENTLY RIPPLED SURFACE

                   RIVER
                   STONE
                                                                                     River Stone, Glenarm

                   The gently undulating surface of River Stone is available
                   in 3 unique colour blends and creates a completely new
                   paving option. In a contemporary scheme it will add
                   texture and form yet maintaining a crisp, clean, feel.
                   While in a traditional scheme it will add depth and
                   character.

32                                                                                                    33
Acheson & Glover   < River Stone, Blackwater                                                                                                         www.acheson-glover.com

                   NBS PLUS:    Q24 INTERLOCKING BRICK/BLOCK ROADS/PAVINGS: 10, 110, 112, 113
                   BS EN:       1338:2003
                   CARBON:      19.8Kg CO2 per m2

                   RIVER
                   STONE
                                                                                                                      FEATURES & BENEFITS:
                                                                                                                      Unique undulating surface.
                                                                                                                      Sharp edge finish.
                                                                                                                      Three / four distinct colour blends will
                                                                                                                      complement most landscape settings whether
                                                                                                                      contemporary or traditional.
                                                                                                                      Highly durable finish.

                                                                                                                      MANUFACTURE:
                                                                                                                      River Stone is manufactured from specially selected
                                                                                                                      premium aggregates to create a high grade finish. The
                                                                                                                      latest manufacturing processes are used to create its
                                                                                                                      unique undulating surface.

                                                                                                                      TRAFFICKING:
                                                                                                                      River Stone is suitable for driveways, pedestrian
                                                                                                                      walkways, patios and light duty traffic.

                                                                                                                      STANDARDS & PERFORMANCE:
                                                                                                                      River Stone is manufactured in compliance with the
                                                                                                                      performance levels in BS EN 1338:2003 Concrete
                                                                                                                      Paving Blocks: Requirements and test methods are
                                                                                                                      independently accredited by BSI.
                                                                                                                      BS EN 1338 states the following as minimum
                                                                                                                      performance criteria for category I and II paving:
                                                                                                                      • Tensile Splitting Strength:        >3.6 Mpa
                                                                                                                      • Slip Potential:                    Low Slip Potential
                                                                                                River Stone, Slaney   • Abrasion Resistance:               Class 3
                   COLOURS:                                                                                           • Weathering Resistance:             Class 3
                                                                                                                      CHAMFER SIZE:
                                                                                                                      River Stone has a sharp edge and no chamfer.

                                                                                                                      JOINT WIDTH:
                                                                                                                      60mm: 2mm spacers on each paver leaving a 3mm
                                                                                                                      joint width when laid.

                                                                                                                      Note: During installation care should be taken to protect the
                                                                                                                      product from wet and dark base sand, dirt and detritus while
                                                                                                                      remaining construction works are completed. To ensure the
                   Blackwater                         Glenarm                         Slaney                          paving remains in good condition, regular cleaning is essential
                                                                                                                      after installation.
                                                                                                                      Careful consideration should be given to the selection of
                   PRODUCT DATA:                                                                                      jointing material. Some sand colours may stain the paving
                                                                                                                      surface. A&G recommends the use of silver granite sand with
                   SIZE (mm):                   200x150           150x150                                             our Blackwater paving.
                                                                                                                      A&G recommend the use of a rubber plate vibrator when
                   DEPTH:                        60mm              60mm                                               vibrating sand into joints to minimise surface marks.
                   M2 PER PACK:                  12.96             12.96                                              To create optimum colour blend A&G advise mixing from 3 bales
                                                                                                                      in vertical sections where possible.
                   NO. PER M2:                    33.3              44.4
                   NO. PER PACK:                  432               576
                   WEIGHT PER PACK:               1.8 t             1.8 t

                                                                                                                      >>
                                                                                                                                  Please note minimum order quantities are
                   COLOURS:                    BLACKWATER       BLACKWATER                                                        required for certain colours and sizes.
                                                 GLENARM         GLENARM                                                          We advise you speak to a member of the
                                                  SLANEY          SLANEY                                                          sales team in advance of order placement.

34                                                                                                                                                                                  35
Acheson & Glover   < Country Cobble, Cashel, Slate & Grey                    www.acheson-glover.com

                   RECLAIMED APPEARANCE THAT
                   ADDS CHARACTER & HERITAGE

                   COUNTRY
                   COBBLE®
                                                                             Country Cobble, Burren & Grey

                   Country Cobble captures the old world charm of stone
                   setts associated with so many of our eminent historical
                   sites. Employing versatile modern paving systems, you
                   can easily achieve a structured design solution, which
                   harmonises with traditional environments.

36                                                                                                     37
Acheson & Glover                                                                                                                                                                                                       www.acheson-glover.com

                                                         NBS PLUS:    Q24 INTERLOCKING BRICK/BLOCK ROADS/PAVINGS: 10, 110, 112, 113
                                                         CARBON:      15 - 17Kg CO2 per m2

                                                         COUNTRY
                                                                                                                                                                                   >>
                                                                                                                                                                                                   Please note minimum order quantities are
                                                                                                                                                                                                   required for certain colours and sizes.

                                                         COBBLE®                                                                                                                                   We advise you speak to a member of the
                                                                                                                                                                                                   sales team in advance of order placement.

Country Cobble, Cashel                                                                                                                                                                FEATURES & BENEFITS:
                                                                                                                                                                                      Country Cobble’s rumbled edges give an aged,
                                                                                                                                                                                      re-claimed appearance with the advantages of
                                                                                                                                                                                      an easy-to-lay paving system.
                                                                                                                                                                                      Its blend of colours suits both traditional and
                                                                                                                                                                                      contemporary settings.
                                                                                                                                                                                      Available in various sizes to allow a variety of
                                                                                                                                                                                      laying patterns.
                                                                                                                                                                                      Through colour mix.
                                                                                                                                                                                      Highly durable finish.

                                                                                                                                                                                      MANUFACTURE:
                                                                                                                                                                                      Country Cobble is manufactured from high grade locally
                                                                                                                                                                                      sourced aggregates. Its unique three colour blends are
                                                                                                                                                                                      obtained by using the latest computerised mixing
                                                                                                                                                                                      systems.
                                                                                                                                          Country Cobble, Killyleagh & Slate
                                                                                                                                                                                      TRAFFICKING:
                                                         COLOURS:                                                                                                                     50mm and 60mm are ideal for pathways, patios,
                                                                                                                                                                                      pedestrian walkways and driveways.
                                                                                                                                                                                      80mm is suitable for heavy vehicular access.

                                                                                                                                                                                      STANDARDS & PERFORMANCE:
                                                                                                                                                                                      • Tensile Splitting Strength:          >3.6Mpa
                                                                                                                                                                                      • Slip Potential:                      Low Slip Potential

                                                                                                                                                                                      CHAMFER SIZE:
                                                         Cashel                               Killyleagh                         Slate
                                                                                                                                                                                      Rumbled finish.

                                                                                                                                                                                      JOINT WIDTH:
Country Cobble, Grey     Country Cobble, Cashel & Grey                                                                                                                                Country Cobble is butt jointed when installed.
                                                                                                                                                                                      The rumbled finish gives an average width joint of
                                                                                                                                                                                      approximately 2mm.

                                                                                                                                                                                      Note: During installation care should be taken to protect the product
                                                                                                                                                                                      from wet and dark base sand, dirt and detritus while remaining
                                                                                                                                                                                      construction works are completed. To ensure the paving remains in
                                                                                                                                                                                      good condition, regular cleaning is essential after installation.
                                                                                                                                                                                      Careful consideration should be given to the selection of jointing
                                                         Burren                               Corrib                             Grey                                                 material. Some sand colours may stain the paving surface. A&G
                                                                                                                                                                                      recommends the use of silver granite sand with our Slate and Grey
                                                                                                                                                                                      paving.

                                                         PRODUCT DATA:
                                                         SIZE (mm):                200x150             150x150      100x150              200x150          150x150          100x150                 200x150             150x150            100x150
                                                         DEPTH:                     50mm                50mm         50mm                 60mm             60mm                60mm                  80mm               80mm                80mm
                                                         M2 PER PACK:              12.00m2             11.25m2       12.0m2                9.6m2            9.0m2              9.6m2                 7.2m2              6.75m2              7.2m2
                                                         NO. PER M :  2              33.3                  44.4       66.6                  33.3             44.4              66.6                   33.3                44.4               66.6
                                                         NO. PER PACK:                400                  500         800                  320              400                640                    240                300                 480
                                                         WEIGHT PER PACK:            1.32 t                1.2 t      1.32 t               1.28 t           1.23 t             1.28 t                1.24 t              1.22 t             1.28 t
                                                         COLOURS:                   CASHEL               CASHEL       CASHEL               CASHEL          CASHEL           CASHEL                  CASHEL              CASHEL             CASHEL
                                                                                    CORRIB               CORRIB       CORRIB               CORRIB          CORRIB           CORRIB                  CORRIB              CORRIB             CORRIB
                                                                                  KILLYLEAGH           KILLYLEAGH   KILLYLEAGH           KILLYLEAGH      KILLYLEAGH       KILLYLEAGH              KILLYLEAGH          KILLYLEAGH         KILLYLEAGH
                                                                                     SLATE                SLATE        SLATE                SLATE           SLATE            SLATE                   SLATE               SLATE              SLATE
                                                                                    BURREN               BURREN       BURREN               BURREN          BURREN           BURREN                  BURREN              BURREN             BURREN
                                                                                     GREY                 GREY         GREY                 GREY            GREY             GREY                    GREY                GREY               GREY

38                                                                                                                                                                                                                                                    39
Country Cobble, Corrib     Country Cobble, Killyleagh
Acheson & Glover   < Strada, Cashel                                                                                                                           www.acheson-glover.com

                   NBS PLUS:   Q24 INTERLOCKING BRICK/BLOCK ROADS/PAVINGS: 10, 110, 112, 113
                   CARBON:     16.0Kg CO2 per m2

                   STRADA                                                                                                    TRADITIONAL APPEARANCE
                                                                                                                             WITH A RUMBLED FINISH

                   Created in two colour blends the rumbled finish gives a                                                   FEATURES & BENEFITS:
                   rustic aged appearance. Strada is ideal for conservation                                                  Rectangular shaped paving product with a
                                                                                                                             distressed, rumbled finish.
                   areas and equally practical for modern projects.
                                                                                                                             Provides an ‘olde world’ appearance to any
                   Complementing the overall paving and flag range
                                                                                                                             project.
                   Strada provides more options for your design.                                                             Ideal for winding pathways and subtle detailing
                                                                                                                             in larger areas.
                                                                                                                             Through colour mix makes Strada a versatile
                                                                                                                             product suitable for a variety of applications.

                                                                                                                             MANUFACTURE:
                                                                                                                             Strada is manufactured from locally sourced high grade
                                                                                                                             aggregates. By using the latest computerised mixing
                                                                                                                             systems, we can create Strada’s individual colour
                                                                                                                             blends.

                                                                                                                             TRAFFICKING:
                                                                                                                             Strada is ideal for pathways, patios and edge detailing.
                                                                                                                             It’s dimensions also make it suitable for areas requiring
                                                                                                                             heavier traffic loads such as private driveways.

                                                                                                                             STANDARDS & PERFORMANCE:
                                                                                                                             • Tensile Splitting Strength:          >3.6 Mpa
                                                                                                                             • Slip Potential:                      Low Slip Potential

                                                                                                                             CHAMFER SIZE:
                                                                                                                             Rumbled finish.

                                                                                                                             JOINT WIDTH:
                                                                                                            Strada, Basalt
                                                                                                                             Strada does not have spacers and is butted together
                   COLOURS:                                                                                                  when installed. The rumbled finish gives an average
                                                                                                                             joint of approximately 2mm.

                                                                                                                             Note:
                                                                                                                             During installation care should be taken to protect the product from
                                                                                                                             wet and dark base sand, dirt and detritus while remaining
                                                                                                                             construction works are completed. To ensure the paving remains in
                                                                                                                             good condition, regular cleaning is essential after installation.
                                                                                                                             Light coloured blocks emphasise tyre marks and oil spills. It must be
                                                                                                                             accepted that these products will need more maintenance if the
                                                                                                                             overall appearance is to be maintained.
                                                                                                                             Careful consideration should be given to the selection of jointing
                   Cashel                           Basalt                                                                   material. Some sand colours may stain the paving surface. A&G
                                                                                                                             recommends the use of silver granite sand with our Basalt paving.

                                                                                                                                                                                 Strada, Cashel
                   PRODUCT DATA:
                   SIZE:                       200x60mm
                   DEPTH:                        60mm
                   M PER BAG:
                     2                            8.2m2
                   NO. PER M2:                     83.3
                   NO. PER BAG:                    684

                                                                  >>
                                                                            Please note minimum order quantities are
                   WEIGHT PER BAG:                1.05 t
                                                                            required for certain colours and sizes.
                   COLOURS:                      CASHEL                     We advise you speak to a member of the
                                                 BASALT                     sales team in advance of order placement.

                   Supplied in tote bags.
40                                                                                                                                                                                            41
Acheson & Glover   < Boulevard, Cashel                                         www.acheson-glover.com

                   CONTEMPORARY, CLEAN APPEARANCE
                   & TROLLEY FRIENDLY SURFACE

                   BOULEVARD®
                                                                                        Boulevard, Corrib

                   Where a contemporary appearance with clean crisp
                   lines is essential, Boulevard is the smart, sharp option.
                   Available in a range of sizes and colour blends,
                   Boulevard gives you freedom and flexibility to create
                   striking modern designs.

42                                                                                                    43
Acheson & Glover   < Boulevard, Burren                                                                                                                                   www.acheson-glover.com

                   NBS PLUS:    Q24 INTERLOCKING BRICK/BLOCK ROADS/PAVINGS: 10, 110, 112, 113
                   BS EN:       1339:2003
                   CARBON:      17.0Kg CO2 per m2

                                                                                                                                                                             Also available as

                   BOULEVARD®
                                                                                                                                                                                 See page 53

                   FEATURES & BENEFITS:                                    Pavements of between 0.5 - 12msa*) to category IV          • Abrasion Resistance:                     Class 3
                   A flat wearing surface in a range of                    (Private drives, paths and patios) as outlined in BS       • Weathering Resistance:                   Class 3
                   contemporary colours.                                   7533-2:2001.
                   Especially suitable as a trolley friendly surface.      Its small plan dimensions or its 80mm thickness            CHAMFER SIZE:
                   The range of sizes can be used to create                make it ideally suited for the heavier traffic loadings    60mm / 80mm / Xflo: Pencil round.
                   striking modern designs.                                of categories I and II.
                                                                                                                                      JOINT WIDTH:
                   Sharp edges allow minimal maintenance.                  msa* - Millions of Standard Axles expected
                                                                                                                                      60mm: 1.5mm spacers on each paver leaving a
                   Clean, crisp, modern look.                              throughout 20 year design life of pavement.
                                                                                                                                      minimum 2mm joint width when laid.
                                                                           STANDARDS & PERFORMANCE:                                   80mm: 2mm spacers on each paver leaving a minimum
                   MANUFACTURE:
                                                                           Boulevard is manufactured in compliance with the           3mm joint width when laid.
                   Boulevard is manufactured from specially sourced
                   premium aggregates. Its unique colours are obtained     performance levels in BS EN 1338:2003 Concrete             Note: During installation care should be taken to protect the product from

                   using the latest computerised mixing system,            Paving Blocks: Requirements and test methods are           wet and dark base sand, dirt and detritus while remaining construction
                                                                                                                                      works are completed. To ensure the paving remains in good condition,
                   creating a spectrum of 3 and 4 colour blends.           independently accredited by BSI.                           regular cleaning is essential after installation.
                                                                           BS EN 1338 states the following as minimum                 Careful consideration should be given to the selection of jointing material.
                   TRAFFICKING:                                            performance criteria for category I and II paving:         Some sand colours may stain the paving surface. A&G recommends the
                                                                                                                                      use of silver granite sand with our Slate and Grey paving.
                   Within our Boulevard range you will find a block size   • Tensile Splitting Strength:      >3.6 Mpa
                   for every application, from category I (Heavy Duty      • Slip Potential:                  Low Slip Potential

                   COLOURS:

                   Burren                        Cashel                        Corrib

                   Killyleagh                    Slate                         Grey                                                                                                       Boulevard, Corrib

                   PRODUCT DATA:
                   SIZE (mm):               200x150         150x150            200x150          150x150             200x150          150x150
                   DEPTH:                    50mm            50mm               60mm             60mm                 80mm           80mm
                   M PER PACK:
                     2                        12m  2        11.25m    2        12.96m     2     12.96m    2            9m  2          9m2
                   NO. PER M2:                33.3            44.4               33.3             44.4                 33.3           44.4
                   NO. PER PACK:               400             500                432             576                  300             400
                   WEIGHT PER PACK:           1.32 t          1.2 t              1.75 t          1.75 t               1.24 t          1.22 t

                                                                                                                                                        >>
                   COLOURS:                 CASHEL          CASHEL             CASHEL     CASHEL                     CASHEL     CASHEL                                 Please note minimum order
                                            BURREN          BURREN             BURREN     BURREN                     BURREN     BURREN                                 quantities are required for
                                             SLATE           SLATE              SLATE      SLATE                      SLATE      SLATE                                 certain colours and sizes.
                                          KILLYLEAGH      KILLYLEAGH         KILLYLEAGH KILLYLEAGH                 KILLYLEAGH KILLYLEAGH                               We advise you speak to a
                                             GREY            GREY               GREY       GREY                       GREY       GREY                                  member of the sales team in
                                            CORRIB          CORRIB             CORRIB     CORRIB                     CORRIB     CORRIB                                 advance of order placement.

44                                                                                                                                                                                                          45
Acheson & Glover   < Rectangular, Slate                                                                              www.acheson-glover.com

                   CLEAN LINES & A FINE
                   TEXTURED FINISH

                   RECTANGULAR
                                                                                                                            Rectangular, Crieve Mix

                   Rectangular is manufactured with a fine textured finish       For high visual impact and clean lines,
                   to give a distinctive richness of colour. The lasting         edge with either a complementary or
                   durability of this quality paving will provide a decorative   contrasting colour to achieve the result
                   finish to enhance any traditional or contemporary area,       you want.
                   which requires minimal maintenance.

46                                                                                                                                              47
Acheson & Glover   < Rectangular, Slate                                                                                                                     www.acheson-glover.com

                   NBS PLUS:    Q24 INTERLOCKING BRICK/BLOCK ROADS/PAVINGS: 10, 110, 112, 113
                   BS EN:       1339:2003
                   CARBON:      20.0Kg CO2 per m2

                                                                                                                                                               Also available as

                   RECTANGULAR
                                                                                                                                                                   See page 53

                   COLOURS:                                                                                                FEATURES & BENEFITS:
                                                                                                                           Flat wearing surface in a range of colours.
                                                                                                                           Especially suitable for commercial projects
                                                                                                                           where cost is a main consideration.
                                                                                                                           Highly durable finish.
                                                                                                                           Suitable for a wide range of applications.
                                                                                                                           Traditional paved appearance.
                                                                                                                           Machine lay available.
                   Creagh Peat Brindle               Crieve Mix                         Rustic Red                         MANUFACTURE:
                                                                                                                           Rectangular is manufactured from locally sourced
                                                                                                                           premium aggregates. Its colour blends are achieved
                                                                                                                           by using the latest computerised mixing systems.

                                                                                                                           TRAFFICKING:
                                                                                                                           Rectangular can be used for most applications, from
                                                                                                                           Category I (Heavy Duty Pavements of between 0.5 –
                                                                                                                           12msa*) to Category IV (Private drives, paths, patios
                                                                                                                           and pedestrian walkways) as outlined in BS7533-
                   Autumn Brown                      Olde Gold                          Grey                               2:2001.
                                                                                                                           Its 80mm thickness is ideally suited for the heavier
                                                                                                                           traffic loads of categories I and II.
                                                                                                                           msa* - millions of Standard Axles expected
                                                                                                                           throughout 20 year design life of pavement.

                                                                                                                           STANDARDS & PERFORMANCE:
                                                                                                                           Rectangular is manufactured in compliance with the
                                                                                                                           performance levels in BS EN 1338:2003 Concrete
                                                                                                                           Paving Blocks. Requirements and test methods are
                   Slate
                                                                                                                           independently accredited by BSI.
                                                                                                                           BS EN 1338 states the following as minimum
                                                                                                                           performance criteria for category I and II paving:
                                                                                                                           Tensile Splitting Strength:               >3.6Mpa

                   >>
                               Please note minimum order quantities are
                                                                                                                           Slip Potential:                           Low Slip Potential
                               required for certain colours and sizes.
                               We advise you speak to a member of the                                                      Abrasion Resistance:                      Class 3
                               sales team in advance of order placement.                                                   Weathering Resistance:                    Class 3
                                                                                                                           CHAMFER SIZE:
                                                                                                                           60mm & 80mm: Standard 5mm straight chamfer.

                                                                                                                           JOINT WIDTH:
                   PRODUCT DATA:
                                                                                                                           60mm: 1.5mm spacers on each paver leaving a
                                                                                                        MACHINE LAY        minimum 2mm joint width when laid.
                   SIZE (mm):                    200x100                      200x100                     200x100
                                                                                                                           80mm: 2mm spacers on each paver leaving a
                   DEPTH:                         60mm                         80mm                        80mm
                                                                                                                           minimum 3mm joint width when laid.
                   M2 PER PACK:                   12.48m2                     9.72m2                        10m2
                                                                                                                           Note: During installation care should be taken to protect the product
                   NO. PER M :  2                    50                          50                          50            from wet and dark base sand, dirt and detritus while remaining
                   NO. PER PACK:                    624                         486                          500           construction works are completed. To ensure the paving remains in
                                                                                                                           good condition, regular cleaning is essential after installation.
                   WEIGHT PER PACK:                 1.8 t                       1.7 t                       1.75 t         Light coloured blocks emphasise tyre marks and oil spills. It must be
                                                                                                                           accepted that these products will need more maintenance if the overall
                   COLOURS:                   CRIEVE MIX                  CRIEVE MIX                     CRIEVE MIX
                                                                                                                           appearance is to be maintained.
                                              RUSTIC RED                  RUSTIC RED                     RUSTIC RED
                                                                                                                           Careful consideration should be given to the selection of jointing
                                                SLATE                       SLATE                          SLATE
                                                                                                                           material. Some sand colours may stain the paving surface. A&G
                                          CREAGH PEAT BRINDLE         CREAGH PEAT BRINDLE            CREAGH PEAT BRINDLE   recommends the use of silver granite sand with our Grey & Slate paving.
                                                GREY                         GREY                           GREY
                                              OLDE GOLD                   OLDE GOLD                      OLDE GOLD
                                            AUTUMN BROWN                AUTUMN BROWN                   AUTUMN BROWN
48                                                                                                                                                                                            49
Acheson & Glover   < Xflo Rectangular, Slate                                                                       www.acheson-glover.com

                   HIGHLY EFFECTIVE, SUSTAINABLE METHOD
                   OF DEALING WITH STORM WATER CONTROL

                   XFLO PERMEABLE
                   PAVING SOLUTIONS
                                                                                                                   < Xflo Rectangular, Crieve Mix

                   Xflo® permeable paving block systems have been specially    unable to cope, resulting in severe
                   developed by A&G to provide specifiers with an extensive    surface flooding in many areas of the
                   range of high quality aesthetically pleasing block paving   country following periods of intense
                   finishes and unit sizes combined with the functional        rainfall.
                   permeability performance required in a sustainable urban
                   drainage system (SUDS).                                     SUDS such as the range of Xflo®
                                                                               permeable paving solutions are designed
                   Increased rainfall and unchecked urban development          to mimic the natural movement of storm
                   have left conventional storm water drainage systems         water and replace conventional storm
                                                                               water drainage systems.

50                                                                                                                                            51
Acheson & Glover                                                                                                                                                                                                       www.acheson-glover.com

                                                            NBS PLUS:     Q24 INTERLOCKING BRICK/BLOCK ROADS/PAVINGS: 12, 115, 117, 119
                                                            BS EN:        1339:2003
                                                            CARBON:       26.9Kg CO2 per m2

                                                            XFLO PERMEABLE                                                                                                           FEATURES & BENEFITS:
                                                                                                                                                                                     Highly effective permeable paving blocks.
                                                                                                                                                                                     Offers a variety of surface finish options to form

                                                            PAVING SOLUTIONS                                                                                                         an integral part of SUDS (Sustainable Urban
                                                                                                                                                                                     Drainage System).
                                                                                                                                                                                     All products perform to the standards expected
                                                                                                                                                                                     but each one offers different aesthetics.
                                                                                                                                                                                     Suitable for areas of heavy traffic.
                                                                                                                                                                                     Machine lay available in Xflo Rectangular.

                                                                                                                                                                                     MANUFACTURE:
                                                                                                                                                                                     Xflo Rectangular and Xflo Boulevard are manufactured
                                                                                                                                                                                     from locally sourced premium aggregates.
                                                                                                                                                                                     Xflo Plaza is manufactured from specially
                                                                                                                                                                                     selected granite aggregates.

                                                                                                                                                                                     TRAFFICKING:
                                                                                                                                                                                     Xflo 80mm is suitable for areas of traffic from Category
                                                                                                                                                                                     I (Heavy Duty Pavements of between 0.5-12 msa*)
                                                                                                                                                                                     Category IV (private drives, paths and patios) as
                                                                                                                                                                                     outlined in BS 7533-2: 2001.
                                                                                                                                                                                     The small plan dimensions and 80mm thickness make
                                                                                                                                                                                     it ideally suited for the heavier traffic loading of
                                                                                                                                                                                     Categories I and II.

                                 Xflo Plaza, Sandstone
                                                                                                                                                                                     msa* - millions of Standard Axles expected throughout
                                                            COLOURS:                                                                                                                 20 year design life of pavement.

                                                            PLAZA                                                                                                                    STANDARDS & PERFORMANCE:
                                                                                                                                                                                     Xflo is manufactured in compliance with the
                                                                                                                                                                                     performance levels of BS EN 1338:2003 Concrete
                                                                                                                                                                                     Paving Blocks. Requirements and test methods are
                                                                                                                                                                                     independently accredited by BSI.
                                                                                                                                                                                     • Tensile Splitting Strength:    > 3.6 Mpa
                                                            Silver                 Graphite                Slate                     Sandstone                                       • Slip Potential:             Low Slip Potential
                                                                                                                                                                                     • Abrasion Resistance:             Class 3
                                                            BOULEVARD
                                                                                                                                                                                     • Weathering Resistance:           Class 3
                                                                                                                                                                                     CHAMFER SIZE:
                                                                                                                                                                                     Xflo Plaza and Xflo Boulevard - pencil round.
                                                                                                                                                                                     Xflo Rectangular - standard 5mm straight

                                                                                                                                                                                     JOINT WIDTH:
                                     Xflo Rectangular,      Burren                 Cashel                  Killyleagh                Grey                  Slate                     3.25mm by 2 no. spacers leaving a minimum 7mm
                                     Crieve Mix & Grey                                                                                                                               joint when laid.
                                                            RECTANGULAR
                                                                                                                                                                                     Note: During installation care should be taken to protect the product
                                                                                                                                                                                     from wet and dark base sand, dirt and detritus while remaining
                                                                                                                                                                                     construction works are completed. To ensure the paving remains in
                                                                                                                                                                                     good condition, regular cleaning is essential after installation.
                                                                                                                                                                                     Careful consideration should be given to the selection of jointing
                                                                                                                                                                                     material. Some sand colours may stain the paving surface. A&G
                                                                                                                                                                                     recommends the use of silver granite sand with our Silver, Slate, Grey
                                                            Creagh Peat Brindle    Crieve Mix              Rustic Red                Grey                  Slate                     and Graphite paving.

                                                            PRODUCT DATA:
                                                                                                                                                                                                         NEW DEPTH:
                                                            PRODUCT:                     PLAZA                       BOULEVARD                            RECTANGULAR                                      60mm
                                                            SIZE (mm):              255x170 / 170x170              255x170 / 170x170                   200x100     200x100                            Xflo Rectangular
                                                            DEPTH:                              80mm                      80mm                          80mm #              60mm
                                                            M PER PACK:
                                                               2
                                                                                                9.6m   2                  9.6m   2                      10.56m     2       12.48m2

                                                                                                                                                                                                  >>
                                                            NO. PER M2 :            Mix of 2 sizes in pack         Mix of 2 sizes in pack                  50                 50                                Please note minimum order
                                                                                                                                                                                                                quantities are required for
                                                            NO. PER PACK:                        270                       270                            528                624                                certain colours and sizes.
                                                                                                                                                                                                                We advise you speak to a
                                                            WEIGHT / PACK:                      1.75 t                    1.75 t                          1.8 t              1.8 t
                                                                                                                                                                                                                member of the sales team in
                                                            COLOURS:                        AS ABOVE                    AS ABOVE                       AS ABOVE            AS ABOVE                             advance of order placement.

52                                                                                                                                               # Machine lay available                                                                               53
Xflo Rectangular, Crieve Mix   Xflo Plaza, Slate & Silver
You can also read
