Pattern Recognition
and Applications Lab
Open Source Intelligence
Giorgio Fumera
fumera@unica.it
source: Davide Ariu – davide.ariu@pluribus-one.it
University
of Cagliari, Italy
Department of Electrical
and Electronic
Engineering
Intelligence
• Definition: the process and product of identifying,
collecting, analyzing and refining information to make it
useful to policymakers in making decisions —
specifically, about potential threats to national security
• Intelligence gathering
– clandestine operations, secret or covert means, known
only at the highest levels of government
– information that is widely available
• Can be used for both legitimate and nefarious purposes
http://pralab.diee.unica.it https://www.fbi.gov/about-us/intelligence 1
Intelligence collection disciplines (*INT)
Five intelligence collection disciplines:
1. HUMan INTelligence (HUMINT): the process of gaining intelligence
from humans or individuals by analyzing behavioral responses
through direct interaction
2. SIGnal INTelligence (SIGINT): electronic transmissions that can be
collected by ships, planes, ground sites, or satellites –
Communications Intelligence (COMINT): interception of
communications between two parties
3. IMagery INTelligence (IMINT), or PHOTo INTtelligence (PHOTINT)
4. Measurement And Signatures INTelligence (MASINT): advanced
processing and use of data gathered from overhead and airborne
IMINT and SIGINT collection systems (e.g.: identifying chemical
weapons)
• TELemetry INTelligence (TELINT): data relayed by weapons during tests
• ELectronic INTelligence (ELINT): electronic emissions picked up from modern
weapons and tracking systems
5. Open Source INTelligence (OSINT): the process of gathering
intelligence from publicly available resources (including the Internet)
http://pralab.diee.unica.it 2
OSINT – Definitions
• Open Source Information (OSINF): publicly available
data – not necessarily free
• OSINF collection: monitoring, selecting, retrieving,
tagging, cataloguing, visualising & disseminating data
• Open Source Intelligence (OSINT): proprietary
intelligence recursively derived from OSINF, as a result of
expert analysis
Slide credit: C.H. Best, JRC – European Commission
http://pralab.diee.unica.it 3
OSINT – Origins
• The term 'OSINT' originates from Security Services
• The practice of using OSINT to build intelligence is not new
– Italy: OVRA (Organizzazione per la Vigilanza e la Repressione dell'Antifascismo)
used OSINF since 1930
– Cold war: American and German secret services vs Russia
• HUMINT, SIGINT and Classified information was largey preferred
• Paradigm change:
– 9/11: OSINT could have been use to foresee attacks
– fast growth of the Internet, appearance of Social Networks
• The 9/11 Commission Report:
The need to restructure the intelligence community grows out of six problems that
have become apparent before and after 9/11
– Structural barriers to performing joint intelligence work
– Lack of common standards and practice across the foreign-domestic divide
– Divided management of national intelligence capabilities
– Weak capacity to set priorities and to move resources
– Too many jobs
– Too complex and secret
http://pralab.diee.unica.it 4
OSINT – Who is involved?
Minister
General
Commissioner
CEO
Analyst
OSINF Classified
Collector/Researcher Information
Tool
Builder/Developer
Slide credit: C.H. Best, JRC – European Commission
http://pralab.diee.unica.it 5
Who uses OSINT?
• Security Services, Law Enforcement Agencies and
Military Bodies
• Governmental organisations
– EU, NATO, AU Situation Centre
– IAEA – Nuclear Safeguard
– UN Department for Peacekeeping Operations
– World Health Organisation
– NGOs
• All the large companies
http://pralab.diee.unica.it 6
OSINT – Sources of information
• Media
– newspapers, magazines, radio, television, etc.
• The Internet
– news web sites, Social Networks, blogs, video sharing sites, thematic sites, etc.
– deep Web (not indexed by traditional search engines): dynamic web pages, sites
behind log-in, sites with a ROBOT.txt file properly configured
– Dark Nets/Web (TOR, I2P)
• Subscription services
– LexisNexis (http://www.lexisnexis.com): a corporation providing computer-assisted
legal research, business research and risk management services. During the 1970s
it pioneered the electronic accessibility of legal and journalistic documents
– Factiva (http://www.dowjones.com/products/product-factiva/): the world’s leading
source of premium news, data and insight, with access to thousands of premium
news and information sources on more than 22 million public and private
companies
– Jane's Information Group (www.janes.com): a British publishing company
specialised in military, aerospace and transportation topics
– BBC Monitoring (https://monitoring.bbc.co.uk) includes news, information and
comment gathered from the mass media around the world for service subscribers
http://pralab.diee.unica.it 7
OSINT – Sources of information
• Commercial Satellites
– http://www.euspaceimaging.com/applications/fields/security-defense-
intelligence
– https://www.maxar.com
• Public Data
– government reports, budgets, demographics, hearings, legislative debates,
press conferences, speeches, marine and aeronautical safety warnings,
environmental impact statements and contract awards
• Professional and Academic
– conferences, professional associations (e.g., IEEE, ACM), academic papers,
and subject matter experts
• Open Data
– https://open-data.europa.eu/en/data
– http://www.dati.gov.it
– http://www.datiopen.it
– Geospatial Data Providers – for an exhaustive list see:
https://en.wikipedia.org/wiki/List_of_GIS_data_sources
http://pralab.diee.unica.it 8
*INT targets: individuals
Potentially interesting information
– physical locations
– OSN profiles for checking on relationships, contacts, content
sharing, preferred web sites, etc.
– e-mail addresses, users’ handles and aliases available on the
Internet including infrastructure owned by the individual such as
domain names and servers
– associations and historical perspective of the work performed
including background details, criminal records, owned licenses,
registrations, etc.:
• public data provided by official databases
• private data provided by professional organizations
– released intelligence such as content on blogs, journal papers,
news articles, and conference proceedings
– mobile information including phone numbers, device type,
applications in use, etc
Source: Targeted Cyber Attacks Multi-staged – Attacks Driven by Exploits
http://pralab.diee.unica.it and Malware, Elsevier, 2014 9*INT targets: corporations and organisations
Potentially interesting information
– determining the nature of business and work performed by target
corporations and organizations to understand the market vertically
– fingerprinting infrastructure including IP address ranges, network
peripheral devices for security and protection, deployed technologies
and servers, web applications, informational web sites, etc.
– extracting information from exposed devices on the network such as
CCTV cameras, routers, and servers belonging to specific organizations
– mapping hierarchical information about the target organizations to
understand the complete layout of employees at different layers
including ranks, e-mail addresses nature of work, service lines,
products, public releases, meeting, etc.
– collecting information about the different associations including
business clients and business partners
– extracting information out of released documents about business,
marketing, financial, and technology aspects
– gathering information about the financial stand of the organization
from financial reports, trade reports, market caps, value history, etc.
Source: Targeted Cyber Attacks Multi-staged – Attacks Driven by Exploits
http://pralab.diee.unica.it and Malware, Elsevier, 2014 10*INT target modes: investigating cyber-attacks
Domains registered by criminals for
• counterfeiting goods
• data exfiltration
• exploit attacks
• illegal pharma
• infrastructure (ecrime name resolution)
• malware C&C
• malware distribution, ransomware
• phishing, business email compromise
• scams (419, reshipping, stranded
traveler…)
http://pralab.diee.unica.it 11OSINT processes TECHNICAL ISSUES
• data mapping
• data deduping
• data cleansing
• data conversion
• data linking
• data normalisation
Visualise
Collect Transform Analyse Collaborate
& Report
• Geo-tagging
• Translation • Link Analysis
• Relationships • Networks
• Intel Wiki
• Entity Extraction
• Relations
• Entity Resolution • Geolinking
• IM
• Trends • Time graphs
• Case DB
• Statistics • Maps
• Publish
• Multilingual Information Retrieval connecting
• Search the dots
• Crawl
• News feeds
generating actionable intelligence
• Machine Translation
http://pralab.diee.unica.it Slide credit: C.H. Best, JRC – European Commission 12Information collection issues
How to search for textual information?
– search engines
• generic, e.g.: Google, Yahoo, Bing, Baidu (Chinese, Japanese), Sogou
(Chinese), Soso.com (Chinese)
• thematic, e.g.: computers and devices (Shodan), maps (Bing, Google,
Nokia, Yahoo!), people (Spokeo), source code (Koders, Krugle, Google
Code Search)
– libraries (e.g.: Lexis Nexis, IEEE Xplore, ACM Digital Library)
How to extract textual information?
– API – information access constraints, subject to change;
platform-specific
– scraping: ad-hoc source code for each platform; noise has to be
removed; open solutions exist (need to merge results)
13
http://pralab.diee.unica.it 1314
Information collection issues
Non-textual information (difficult to automate extraction)
• Images
– people (who)? places? texts? objects?
• Videos
– people (who)? places? text? objects? (same as for images)
– if video contains audio: transcription, translation, speaker
identification
• Audio traces
– transcription
– translation
• Other files
– e.g.; executables files, proprietary formats
http://pralab.diee.unica.it 1415
Information collection: language issues
• Culture • Hi-Tech • Sport • Magazine
• Art • Health-Environment • Politic • Short news
• Religion-Thought • Society • International
• University • Economy • Provinces
Howzeh • Markets • Photo
• Video
http://pralab.diee.unica.it 1516
Information collection: language issues
English version: https://en.mehrnews.com/
http://pralab.diee.unica.it Slide Credit: C.H. Best, JRC – European Commission 1617
Information collection: language issues
Persian version: https://www.mehrnews.com/
• News
• Culture
• Literature
• Religion
• University
• Social
• Economic
• Political
• International
• Sport
• Nuclear
• Photo
http://pralab.diee.unica.it Slide Credit: C.H. Best, JRC – European Commission 1718
Information collection issues:
Social Network analysis
• Privacy restrictions
– third party application developers create applications that ask for unneeded
permissions to gain additional information
• Platform restrictions
– based on social relationships, user-based privacy settings, rate limiting, activity
monitoring, and IP address based restrictions
• Data availability
– users did not provide information
– the target information exists, but is "hidden" by privacy and platform restrictions
• Data longevity
– relationship dynamics change frequently, profiles are updated constantly
– each data access is a snapshot of the social graph at collection time
• Legal issues
– disallowing screen scrapers and other data mining tools through ToS agreements,
but legal enforceability remains unclear
• Ethical issues
– crawling social networks for personal information is an ethically sensitive area
Source: B. R. Holland, Enabling Open Source Intelligence (OSINT) in private social networks
http://pralab.diee.unica.it 18Information collection issues:
Social Network analysis
http://pralab.diee.unica.it 1920
Information collection issues:
Social Network analysis
http://pralab.diee.unica.it 2021
Information transformation:
linguistic requirements
Foreign language skills and knowledge proficiency:
– transcription: both listening and writing proficiency in the
source language are essential
– interpretation: both listening in the source language and
speaking proficiency in the target language are essential
– translation: bilingual competence is a prerequisite for
translation; linguists must be able to
• read and comprehend the source language
• write comprehensibly in the target language
• choose the equivalent expression in the target language that fully
conveys and best matches the meaning intended in the source one
http://pralab.diee.unica.it Source: Open-Source Intelligence, Federation of American Scientists, 2012 2122
Information transformation:
entity resolution
• The problem of identifying and linking/grouping
different manifestations of the same real world object
• Examples of manifestations and objects:
– Different ways of addressing (names, email addresses,
FaceBook accounts) the same person in text
– Web pages with differing descriptions of the same
business
– Different photos of the same object
Source: L. Getoor, A. Machanavajjhala - Entity Resolution Tutorial
http://pralab.diee.unica.it 2223
Information transformation:
entity resolution
Enzo Ferrari e i suoi piloti
«Un padrone delle ferriere». Era questo il modo singolare, ma per certi versi affettuoso, con cui Clay Regazzoni
amava definire Enzo Ferrari. E che il Drake fosse un vero padrone, e fatto che nessuno dei piloti che hanno fatto
tappa a Maranello puo mettere in discussione. Era lui, Ferrari, che stabiliva simpatie e antipatie, ordini e
concessioni, stipendi e provvigioni. Su una cosa soltanto non concedeva margini neppure a se stesso: il valore
di chi correva per lui. A patto, pero, che il nome del pilota non avesse il sopravvento, nella popolarita, sul nome
delle macchine.
Arrivando a tempi piu recenti, il pilota che piu affascinò Enzo Ferrari fu Niki Lauda. Fortemente parsimonioso e
terribilmente abile nella trattativa economica, in cui eccelleva peraltro anche il Drake, Niki racconta che Ferrari
ad un certo punto gli affibbio un curioso soprannome: «Mi chiamava ebreo, probabilmente perche mi riteneva
anche un buon commerciante della mia professionalità.
A fine luglio 1977, quando l'ex campione del mondo aveva gia firmato per la Brabham Alfa Romeo, Ferrari
rivelo un'ammissione di Lauda. «Fino a quando lei sara vivo io guidero per lei», questo disse Niki al Drake, nel
frattempo da dieci anni ingegnere honoris causa. Ma alla fine di agosto, Lauda si recò a Maranello e disse a
Ferrari che non avrebbe guidato piu le sue macchine. «Se Lauda fosse restato con noi avrebbe almeno
eguagliato il record di Fangio di cinque titoli mondiali vinti», confesso Ferrari tempo dopo. Non perdonò mai
Lauda e non lo rivolle in Ferrari quando l'austriaco si offerse. Il perdono arrivò anni dopo, poco prima della
morte del Drake.
L'ultimo pilota, nella classifica degli amori tecnici di Enzo Ferrari, fu Gilles Villeneuve. Il Grande Vecchio era un
umorale, quando Lauda lo lasciò fece una scommessa con se stesso: prender un signor nessuno e portarlo al
titolo mondiale.
http://pralab.diee.unica.it 2324
Information transformation:
entity resolution
Enzo Ferrari e i suoi piloti
«Un padrone delle ferriere». Era questo il modo singolare, ma per certi versi affettuoso, con cui Clay Regazzoni
amava definire Enzo Ferrari. E che il Drake fosse un vero padrone, e fatto che nessuno dei piloti che hanno fatto
tappa a Maranello puo mettere in discussione. Era lui, Ferrari, che stabiliva simpatie e antipatie, ordini e
concessioni, stipendi e provvigioni. Su una cosa soltanto non concedeva margini neppure a se stesso: il valore
di chi correva per lui. A patto, pero, che il nome del pilota non avesse il sopravvento, nella popolarita, sul nome
delle macchine.
Arrivando a tempi piu recenti, il pilota che piu affascinò Enzo Ferrari fu Niki Lauda. Fortemente parsimonioso e
terribilmente abile nella trattativa economica, in cui eccelleva peraltro anche il Drake, Niki racconta che Ferrari
ad un certo punto gli affibbio un curioso soprannome: «Mi chiamava ebreo, probabilmente perche mi riteneva
anche un buon commerciante della mia professionalità.
A fine luglio 1977, quando l'ex campione del mondo aveva gia firmato per la Brabham Alfa Romeo, Ferrari
rivelo un'ammissione di Lauda. «Fino a quando lei sara vivo io guidero per lei», questo disse Niki al Drake, nel
frattempo da dieci anni ingegnere honoris causa. Ma alla fine di agosto, Lauda si recò a Maranello e disse a
Ferrari che non avrebbe guidato piu le sue macchine. «Se Lauda fosse restato con noi avrebbe almeno
eguagliato il record di Fangio di cinque titoli mondiali vinti», confessò Ferrari tempo dopo. Non perdonò mai
Lauda e non lo rivolle in Ferrari quando l'austriaco si offerse. Il perdono arrivò anni dopo, poco prima della
morte del Drake.
L'ultimo pilota, nella classifica degli amori tecnici di Enzo Ferrari, fu Gilles Villeneuve. Il Grande Vecchio era un
umorale, quando Lauda lo lasciò fece una scommessa con se stesso: prender un signor nessuno e portarlo al
titolo mondiale.
http://pralab.diee.unica.it 2425
Information transformation:
entity resolution
Enzo Ferrari e i suoi piloti
«Un padrone delle ferriere». Era questo il modo singolare, ma per certi versi affettuoso, con cui Clay Regazzoni
amava definire Enzo Ferrari. E che il Drake fosse un vero padrone, e fatto che nessuno dei piloti che hanno fatto
tappa a Maranello puo mettere in discussione. Era lui, Ferrari, che stabiliva simpatie e antipatie, ordini e
concessioni, stipendi e provvigioni. Su una cosa soltanto non concedeva margini neppure a se stesso: il valore
di chi correva per lui. A patto, pero, che il nome del pilota non avesse il sopravvento, nella popolarita, sul nome
delle macchine.
Arrivando a tempi piu recenti, il pilota che piu affascinò Enzo Ferrari fu Niki Lauda. Fortemente parsimonioso e
terribilmente abile nella trattativa economica, in cui eccelleva peraltro anche il Drake, Niki racconta che Ferrari
ad un certo punto gli affibbio un curioso soprannome: «Mi chiamava ebreo, probabilmente perche mi riteneva
anche un buon commerciante della mia professionalità.
A fine luglio 1977, quando l'ex campione del mondo aveva gia firmato per la Brabham Alfa Romeo, Ferrari
rivelo un'ammissione di Lauda. «Fino a quando lei sara vivo io guidero per lei», questo disse Niki al Drake, nel
frattempo da dieci anni ingegnere honoris causa. Ma alla fine di agosto, Lauda si recò a Maranello e disse a
Ferrari che non avrebbe guidato piu le sue macchine. «Se Lauda fosse restato con noi avrebbe almeno
eguagliato il record di Fangio di cinque titoli mondiali vinti», confesso Ferrari tempo dopo. Non perdonò mai
Lauda e non lo rivolle in Ferrari quando l'austriaco si offerse. Il perdono arrivò anni dopo, poco prima della
morte del Drake.
L'ultimo pilota, nella classifica degli amori tecnici di Enzo Ferrari, fu Gilles Villeneuve. Il Grande Vecchio era un
umorale, quando Lauda lo lasciò fece una scommessa con se stesso: prender un signor nessuno e portarlo al
titolo mondiale.
http://pralab.diee.unica.it 2526
Information transformation:
entity resolution
Before After
http://pralab.diee.unica.it Slide Credit: L. Getoor, A. Machanavajjhala - Entity Resolution Tutorial 2627
Information transformation:
entity resolution
Traditional challenge: name/attribute ambiguity
Tom Cruise
Michael Jordan
http://pralab.diee.unica.it Slide Credit: L. Getoor, A. Machanavajjhala - Entity Resolution Tutorial 27Information transformation:
entity resolution
Other challenges
– errors due to data entry
– changing attributes
– abbreviations/data truncation
V. Rossi
Valentino Rossi Vasco Rossi Valeria Rossi
28
http://pralab.diee.unica.it 2829
Information transformation:
entity resolution
Abstract problem statement
http://pralab.diee.unica.it Slide Credit: L. Getoor, A. Machanavajjhala - Entity Resolution Tutorial 29Information transformation:
entity resolution
Deduplication: clustering the record mentions that correspond
to the same entity
30
http://pralab.diee.unica.it Slide Credit: L. Getoor, A. Machanavajjhala - Entity Resolution Tutorial 30Information transformation:
entity resolution
Deduplication: clustering the record mentions that correspond
to the same entity
Computing cluster's representatives
31
http://pralab.diee.unica.it Slide Credit: L. Getoor, A. Machanavajjhala - Entity Resolution Tutorial 3132
Information transformation:
entity resolution
Linking records that match across databases
http://pralab.diee.unica.it Slide Credit: L. Getoor, A. Machanavajjhala - Entity Resolution Tutorial 32Information transformation:
entity resolution
33
http://pralab.diee.unica.it Slide Credit: L. Getoor, A. Machanavajjhala - Entity Resolution Tutorial 3334
Open source information reliability
Two types of sources used to collect information
– primary sources: a document or physical object that was written or
created during the time under study
• original documents (excerpts or translations) such as diaries, constitutions,
research journals, speeches, manuscripts, letters, oral interviews, news film
footage, autobiographies, and official records
• creative works such as poetry,drama,novels,music,and art
• relics or artifacts such as pottery, furniture, clothing, artifacts, and buildings
• personal narratives and memoirs
• person of direct knowledge
– secondary sources
• journals that interpret findings
• yextbooks
• magazine articles
• commentaries
• histories
• criticism
• encyclopedias
http://pralab.diee.unica.it Source: Open-Source Intelligence, Federation of American Scientist, 2012 3435
Open source information reliability
http://pralab.diee.unica.it Source: Open-Source Intelligence, Federation of American Scientist, 2012 3536
Open source information credibility
http://pralab.diee.unica.it Source: Open-Source Intelligence, Federation of American Scientist, 2012 3637
Link analysis
• Basic problem for intelligence analysts: putting information
together in an organized way to make it easier extracting
meaning into a graphical format
• Link analysis can be applied to relationships among identified
entities
1. assemble all raw data
2. determine focus of the chart
3. construct an association matrix
4. code the associations in the matrix
5. determine the number of links for each entity
6. draw a preliminary chart (not covered in these slides)
7. clarify and re-plot the chart (not covered in these slides)
http://pralab.diee.unica.it Source: Criminal Intelligence – United Nations Office of Drugs and Crime 3738
Link analysis
http://pralab.diee.unica.it Source: Criminal Intelligence – United Nations Office of Drugs and Crime 3839
Link analysis – Example
1. Assemble all raw data
– sssemble all relevant files, field reports, informant
reports, records, etc.
2. Determine the focus of the chart
– identify the entities that will be the focus of your chart
(names of people and/or organizations, auto license
numbers, addresses, etc.)
3. Construct an association matrix
– an essential, interim step
to identify associations
between entities
http://pralab.diee.unica.it Source: Criminal Intelligence – United Nations Office of Drugs and Crime 3940
Link analysis – Example
4. Code the associations in the matrix
http://pralab.diee.unica.it Source: Criminal Intelligence – United Nations Office of Drugs and Crime 4041
Link analysis – Example
5. Determine the number of links for each entity
http://pralab.diee.unica.it Source: Criminal Intelligence – United Nations Office of Drugs and Crime 41Preparation & Tools http://pralab.diee.unica.it
Questions to ask before an investigation
• Should you hide your activities from bad actors?
– criminals may block IPs of known investigators
– they may also monitor activity
• Do you want to leave crumbs associated with
investigations that are traceable back to you?
– log records, metadata at third party intelligence sources
• Do you want resources you use to leave crumbs on your
devices
– cookies, plug-ins, or worse…
http://pralab.diee.unica.it 43OnionWRT: Tor router
1. Buy a $20 micro router or Raspberry Pi
2. Install OpenWRT and OnionWRT
3. Investigate over TOR from behind router
4. Put all your devices behind your router
WiFi Encryption
http://www.securityskeptic.com/2016/01/how-to-turn-a-nexx-wt3020-router-into-a-tor-router.html
http://pralab.diee.unica.it 44Software to anonymize traffic
•
https://www.torproject.org/projects/projects.html.en
– Amnesic Incognito Live System (TAILS) Linux distribution
– Tor browser
• Disposable, anonymous inboxes
– https://mailinator.com/
• Browser tricks
– Incognito/private mode can still be tracked
– User agent changes (can do with cURL as well)
http://pralab.diee.unica.it 45Recon-Ng
https://github.com/lanmaster53/recon-ng
• A full-featured open-source Web reconnaissance
framework written in Python
– geolocating an IP address
– finding the domains associated with a given email address
– ...
• A completely modular framework with independent
modules, database interaction, built in convenience
functions
http://pralab.diee.unica.it 46Recon-Ng modules
– Discovery
• discovery/info_disclosure/interesting_files
– Exploitation
• exploitation/injection/command_injector
• exploitation/injection/xpath_bruter
– Import
• import/csv_file
• import/list
– Recon (60 modules)
• recon/companies-multi/whois_miner
• recon/domains-credentials/pwnedlist/leak_lookup
• recon/hosts-hosts/ipinfodb
• recon/profiles-profiles/twitter
– Reporting
• reporting/csv
• reporting/html
• reporting/json
• reporting/list
http://pralab.diee.unica.it 47Case Study http://pralab.diee.unica.it
49
Maltego
Open Source Intelligence tool
Maltego (Community Edition, CE)
https://www.maltego.com
http://pralab.diee.unica.it 49You can also read
